SCHUNK SGB 32 User instructions

Translation of the original manual
2-finger angular gripper
SGB 32 - 50
Assembly and Operating Manual
Superior Clamping and Gripping
www.comoso.com

Imprint
2 03.02|SGB 32 - 50 |en
Imprint
Copyright:
This manual remains the copyrighted property of SCHUNK GmbH & Co. KG. It is solely
supplied to our customers and operators of our products and forms part of the product.
This documentation may not be duplicated or made accessible to third parties, in particu-
lar competitive companies,
without our prior permission.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 0389402
Edition: 03.02 |31/01/2014|en
© SCHUNK GmbH & Co. KG
All rights reserved.
Dear customer,
congratulations on choosing a SCHUNK product. By choosing SCHUNK, you have opted for
the highest precision, top quality and best service.
You are going to increase the process reliability of your production and achieve best
machining results – to the customer's complete satisfaction.
SCHUNK products are inspiring.
Our detailed assembly and operation manual will support you.
Do you have further questions? You may contact us at any time – even after purchase.
Kindest Regards
Yours SCHUNK GmbH & Co. KG
Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
Tel. [phone]
Fax [phone]
[email protected]
www.schunk.com
www.comoso.com

Table of contents
03.02|SGB 32 - 50 |en
3
Table of contents
1 About this manual .................................................................................................... 4
1.1 Warnings................................................................................................................... 4
1.1.1 Key words...................................................................................................... 4
1.1.2 Symbols ......................................................................................................... 4
1.2 Applicable documents ............................................................................................. 5
2 Basic safety notes .................................................................................................... 6
2.1 Intended use............................................................................................................. 6
2.2 Not intended use ...................................................................................................... 6
2.3 Environmental and operating conditions................................................................. 6
2.4 Product safety........................................................................................................... 7
2.4.1 Protective equipment ................................................................................... 7
2.4.2 Demands on the top jaws ............................................................................. 7
2.4.3 Constructional changes, attachments, or modifications.............................. 7
2.5 Personnel qualification............................................................................................. 7
2.6 Using personal protective equipment...................................................................... 8
2.7 Notes on particular risks........................................................................................... 8
3 Warranty................................................................................................................. 10
4 Scope of delivery ..................................................................................................... 10
5 Accessories.............................................................................................................. 11
5.1 Sensors.................................................................................................................... 11
6 Technical Data ........................................................................................................ 12
7 Assembly................................................................................................................. 13
7.1 Mechanical connection .......................................................................................... 13
7.2 Air connection ........................................................................................................ 14
7.3 Sensors.................................................................................................................... 15
7.3.1 IN 40 inductive proximity switch ................................................................ 15
8 Maintenance ........................................................................................................... 17
9 Translation of original declaration of incorporation................................................. 19
www.comoso.com

About this manual
4 03.02|SGB 32 - 50 |en
About this manual
This instruction is an integral part of the product and contains im-
portant information for a safe and proper assembly, commission-
ing, operation, maintenance and help for easier trouble shooting.
Before using the product, read and note the instructions, especial-
ly the chapter "Basic safety notes".
Warnings
The following key words and symbols are used to highlight dan-
gers.
Key words
DANGER Dangers for persons.
Non-compliance will inevitably cause irreversible injury or death.
WARNING Dangers for persons.
Non-compliance may cause irreversible injury or death.
CAUTION Dangers for persons.
Non-observance may cause minor injuries.
NOTICE Information about avoiding material damage
Symbols
Warning about a danger point
Warning about hand injuries
General mandatory sign to prevent material damage
1
1.1
1.1.1
1.1.2
www.comoso.com

About this manual
03.02|SGB 32 - 50 |en
5
Applicable documents
•General terms of business
•Catalog data sheet of the purchased product
•Assembly and Operating manuals of the accessories
The documents listed here, can be downloaded on our homepage
www.schunk.com
1.2
www.comoso.com

Basic safety notes
6 03.02|SGB 32 - 50 |en
Basic safety notes
Intended use
The product was designed to grip and to temporarily and securely
hold workpieces and objects.
The product is intended for installation in a machine/system. The
requirements of the applicable guidelines must be observed and
complied with.
The product may be used only in the context of its defined applica-
tion parameters (6, Page 12).
SCHUNK assumes that application in question was tested with the
calculation program for gripping modules (SSG).
The product is designed for industrial use.
To use this unit as intended, it is also essential to observe the
technical data and installation and operation notes in this manual
and to comply with the maintenance intervals.
Not intended use
Use which is not specified as an intended use is for instance when
the product is for example used as a pressing tool, stamping tool,
lifting tool, guide for tools, cutting tool, tensioning mean, boring
tool.
Environmental and operating conditions
•Make sure that the product and the top jaws are a sufficient
size for the application.
•Make sure that the environment is free from splash water and
vapors as well as from abrasion or processing dust. Exceptions
are products that are designed especially for contaminated en-
vironments.
2
2.1
2.2
2.3
www.comoso.com

Basic safety notes
03.02|SGB 32 - 50 |en
7
Product safety
Dangers arise from the product, if:
•the product is not used in accordance with its intended pur-
pose.
•the product is not installed or maintained properly.
•the safety and installation notes are not observed.
Avoid any manner of working that may interfere with the function
and operational safety of the product.
Wear protective equipment.
NOTE
More information are contained in the relevant chapters.
Protective equipment
Provide protective equipment per EC Machinery Directive.
Demands on the top jaws
Arrange the top jaws such that when the product is depressurized
it can reach one of the end positions either open or closed and
therefore no residual energy can be released when changing the
top jaws.
Constructional changes, attachments, or modifications
Additional drill holes, threads, or attachments that are not offered
as accessories by SCHUNK may be attached only with permission
of SCHUNK.
Personnel qualification
The assembly, initial commissioning, maintenance, and repair of
the product may be performed only by trained specialist person-
nel. Every person called upon by the operator to work on the
product must have read and understood the complete assembly
and operating manual, especially the chapter "Basic safety notes"
(2, Page 6). This applies particularly to personnel only used oc-
casionally, such as maintenance personnel.
2.4
2.4.1
2.4.2
2.4.3
2.5
www.comoso.com

Basic safety notes
8 03.02|SGB 32 - 50 |en
Using personal protective equipment
When using this product, observe the relevant industrial safety
regulations and use the personal protective equipment (PPE) re-
quired!
•Use protective gloves, safety shoes and safety goggles.
•Observe safe distances.
•Minimal safety requirements for the use of equipment.
Notes on particular risks
Generally valid:
•Remove the energy supplies before installation, modification,
maintenance, or adjustment work.
•Make sure that no residual energy remains in the system.
•Do not move parts by hand when the energy supply is con-
nected.
•Do not reach into the open mechanism or the movement area
of the unit.
•Perform maintenance, modifications, and additions outside the
danger zone.
•Secure the product during all operations against uncontrolled
activation.
•Take a precautionary approach by maintenance and disassem-
bly.
•Only specially trained staff should disassemble the product.
2.6
2.7
www.comoso.com

Basic safety notes
03.02|SGB 32 - 50 |en
9
WARNING
Risk of injury due to squeezing and bumping during movement
of the gripper jaws and breaking or loosening of the gripper fin-
gers !
WARNING
Risk of injury from objects falling and being ejected
•The danger zone must be surrounded by a safety fence during
operation.
WARNING
While disassembling uncontrollable moves of parts of the grip-
per possible!
www.comoso.com

Warranty / Scope of delivery
10 03.02|SGB 32 - 50 |en
Warranty
The warranty is valid for 24 months from the delivery date to the
production facility under the following conditions:
•Intended use in 1-shift operation
•Observe the mandatory maintenance and lubrication intervals
•Observe the environmental and operating conditions
Parts touching the work piece and wear parts are not part of the
warranty.
If necessary, check the application with the calculation program
for gripping modules (SSG).
Scope of delivery
The scope of delivery includes:
•2-Finger-Poly-A-Angular-Gripper SGB in the ordered model.
3
4
www.comoso.com

Accessories
03.02|SGB 32 - 50 |en
11
Accessories
A wide range of accessories are available for this module.
For information about which accessories can be used with the ap-
propriate product version ☞catalog.
Sensors
Overview of the compatible sensors
Designation Type
Inductive proximity switches IN
•Exact type designation of the compatible sensors see
☞catalog.
•If you require further information on sensor operation, contact
your SCHUNK contact person or download information from
our homepage.
5
5.1
www.comoso.com

Technical Data
12 03.02|SGB 32 - 50 |en
Technical Data
SGB
Pressure medium Compressed air, compressed
air quality according to ISO
8573-1:7 4 4
Min. pressure [bar] 4
Max. pressure [bar] 7
Nominal working pressure
[bar]
6
IP rating 20
Min. ambient temperature [°C] -10
max. ambient temperature [°C] 90
Noise emission [dB(A)] ≤ 70
Further technical data can be found in the catalog data sheet.
The most recent version applies.
6
www.comoso.com

Assembly
03.02|SGB 32 - 50 |en
13
Assembly
Mechanical connection
The values relate to the entire bolting surface.
Requirements for levelness of the bolting surface (Dimensions in mm)
Diameter Permissible unevenness
< 100 < 0.02
> 100 < 0.05
Fig. 1 Assembly options
Ite
m
Designation SGB 32 SGB 40 SGB 50
1 Tab width 7 mm 10 mm
2 2x through bores for M3 screw M4 screw
Mounting Screw tightening torques
SGB 32 SGB 40 SGB 50
max. 0.5 Nm max.1.0 Nm
NOTE
•Mount the module using the mounting bores provided.
•Attach the top jaws using the mounting bores provided.
7
7.1
Check the evenness
of the bolting surface
Mounting
www.comoso.com

Assembly
14 03.02|SGB 32 - 50 |en
Air connection
NOTICE
The maximum permissible mass per jaw is exceeded:
•Attach flow control couplings to the module.
NOTICE
Observe the requirements for the air supply.
(6, Page 12)"Technical Data"
Fig. 2 Air connection
Item Designation SGB 32 SGB 40 SGB 50
1 Air connection M3 M5
7.2
www.comoso.com

Assembly
03.02|SGB 32 - 50 |en
15
Sensors
The module is prepared for a number of sensors. Other sensors
can be used with a mounting kit.
•If you require further information on sensor operation, contact
your SCHUNK contact person or download information from
our homepage.
•Technical data for the sensors can be found in the data sheets
(included in the scope of delivery).
IN 40 inductive proximity switch
4
25
Fig. 3
Fig. 4
Types that can be ordered (☞catalog):
The inductive proximity switches used are equipped with reverse
polarity protection and are short-circuit-proof.
Make sure that you handle the proximity switches properly:
•Do not pull on the cable.
•Do not allow the sensor to dangle from the cable.
•Do not overtighten the mounting screw or mounting clip.
•Please adhere to a permitted bend radius of the cable (☞ca-
taolg).
•Avoid contact of the proximity switches with hard objects and
with chemicals, in particular nitric acid, chromic acid and sul-
phuric acid.
7.3
7.3.1
www.comoso.com

Assembly
16 03.02|SGB 32 - 50 |en
The inductive proximity switches are electronic components,
which can react sensitively to high-frequency interference or elec-
tromagnetic fields.
•Check to make sure that the cable is fastened and installed cor-
rectly. Provide for sufficient clearance to sources of high-
frequency interference and their supply cables.
•Parallel switching of several sensor outputs of the same type
(npn, pnp) is permissible, but does not increase the permissible
load current.
•Note that the leakage current of the individual sensors (approx.
2 mA) is cumulative.
NOTICE
Max. indentation force (F) of the locking pins is 20 N.
1
2
3
Fig. 5
1 Locking pin
2 Control cam
3 Proximity switch
1 Close the gripper jaws.
2 Press the locking pin (1) out with a screwdriver until the prox-
imity switch (3) can be inserted.
3 Carefully insert the proximity switch (3) until it touches the
control cam (2).
4 Pull the proximity switch (3) back by about 0.5 mm and press
against the locking pin (1) with the arbor until the proximity
switch (3) has been secured.
Mounting and
adjust
ing of the
proximity switch
www.comoso.com

Maintenance
03.02|SGB 32 - 50 |en
17
Maintenance
The 2-Finger-Poly-A-Angular-Gripper SGB is maintenance-free.
Recommended relubrication of the finger axes:
Size 32 - 50
Interval [Mio. cycles] 2
8
www.comoso.com

Notes
18 03.02|SGB 32 - 50 |en
Notes
www.comoso.com

Translation of original declaration of incorporation
03.02|SGB 32 - 50 |en
19
Translation of original declaration of incorporation
in terms of the Directive 2006/42/EG, Annex II, Part 1.B of the European Parliamen
t and of
the Council on machinery.
Manufacturer/
Distributor
SCHUNK GmbH & Co. KG Spann- und Greiftechnik
Bahnhofstr. 106 – 134
D-74348 Lauffen/Neckar
We hereby declare that on the date of the declaration the following incomplete machine
complied with all basic safety and health regulations found in the directive 2006/42/EC of
the European Parliament and of the Council on machinery. The declaration is rendered
invalid if modifications are made to the product.
Product designation: 2-Finger-Poly-A-Angular-Gripper / SGB 32 - 50 /
ID number 0305199 ... 0305201
The incomplete machine may not be put into operation until conformity of the machine
into which the incomplete machine is to be installed with the provisions of the Machinery
Directive (2006/42/EC) is confirmed.
Applied harmonized standards, especially:
EN ISO
12100:2011-03
Safety of machinery - General principles for design - Risk assessment
and risk reduction
The manufacturer agrees to forward on demand the relevan
t technical documentation for
the partly completed machinery to state offices.
The special technical documents according to Appendix VII, Part B belonging to the in-
complete machine have been compiled.
Person authorized to compile the technical documentation:
Robert Leuthner, Address: see manufacturer's address
Lauffen/Neckar, January 2014
p.p. Ralf Winkler, Head of Gripping
Systems Development
9
www.comoso.com

20 03.02|SGB 32 - 50 |en
www.comoso.com
