SCHUNK TOOLFIX User instructions

Translation of Original Operating Manual
Modular tool mounting device
TOOLFIX
Assembly and Operating Manual

Imprint
2 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
Imprint
Copyright:
This manual is protected by copyright. The author is SCHUNK GmbH & Co. KG. All rights
reserved.
Technical changes:
We reserve the right to make alterations for the purpose of technical improvement.
Document number: 1510829
Version: 01.00|18/05/2022|en
Dear Customer,
thank you for trusting our products and our family-owned company, the leading
technology supplier of robots and production machines.
Our team is always available to answer any questions on this product and other solutions.
Ask us questions and challenge us. We will find a solution!
Best regards,
Your SCHUNK team
Customer Management
Tel. [phone]
Fax [phone]
[email protected]
Please read the operating manual in full and keep it close to the product.

Table of Contents
Table of Contents
1 General.................................................................................................................... 5
1.1 About this manual ................................................................................................ 5
1.1.1 Illustration of warnings.............................................................................5
1.1.2 Applicable documents ..............................................................................6
1.2 Warranty .............................................................................................................. 6
1.3 Product Overview................................................................................................. 6
2 Basic safety notes .................................................................................................... 7
2.1 Appropriate use.................................................................................................... 7
2.2 Inappropriate use ................................................................................................. 7
2.3 Structural changes................................................................................................ 7
2.4 Spare parts ........................................................................................................... 7
2.5 Ambient conditions and operating conditions .....................................................8
2.6 Personnel qualifications ....................................................................................... 8
2.7 Personal protective equipment............................................................................ 9
2.8 Notes on safe operation ....................................................................................... 9
2.9 Transport ............................................................................................................ 10
2.10 Malfunctions....................................................................................................... 10
2.11 Disposal .............................................................................................................. 10
2.12 Fundamental dangers......................................................................................... 10
2.12.1 Protection during handling and assembly ..............................................11
2.12.2 Protection during commissioning and operation ...................................11
2.12.3 Notes on particular risks.........................................................................12
3 Technical data.........................................................................................................13
3.1 Maximum load values ........................................................................................ 14
4 Screw tightening torques ........................................................................................17
5 Assembly ................................................................................................................18
5.1 Pre-assembly measures...................................................................................... 18
5.2 Assembly ............................................................................................................ 20
6 Description of function ...........................................................................................21
6.1 TOOLFIX MONO basic module............................................................................ 22
6.2 TOOLFIX VARIO basic module............................................................................. 23
6.3 TOOLFIX MONO tool adapter ............................................................................. 24
6.4 TOOLFIX VARIO tool adapter .............................................................................. 25
6.5 TOOLFIX TURN tool adapter ............................................................................... 26
6.6 Various locking mechanisms .............................................................................. 27
6.6.1 Spring latch.............................................................................................27
6.6.2 Screw lever .............................................................................................28
6.6.3 Screw ......................................................................................................29
7 Operation ...............................................................................................................30
301.00 | | TOOLFIX modular tool mounting device | en | 1510829

Table of Contents
8 Maintenance and care ............................................................................................31
8.1 TOOLFIX MONO basic module............................................................................ 32
8.2 TOOLFIX VARIO basic module............................................................................. 33
8.3 TOOLFIX MONO or VARIO tool adapter – ISO ( SK/BTCat ) / HSK ( A+B ) / VDI ..35
8.4 TOOLFIX MONO or VARIO tool adapter – HSK ( E+F )......................................... 36
8.5 TOOLFIX MONO or VARIO tool adapter - Capto ................................................. 37
8.6 TOOLFIX TURN tool adapter ............................................................................... 38
9 Storage ...................................................................................................................39
4 01.00 | | TOOLFIX modular tool mounting device | en | 1510829

General
1 General
1.1 About this manual
This manual contains important information for the safe, correct
use of the product.
The manual is an integral part of the product and must be kept
accessible for personnel at all times.
Personnel must have read and understood this manual before
beginning any work. The observance of all safety notes in this
manual is a prerequisite to ensure safe work processes.
The illustrations in this manual are intended to provide a basic
understanding and may deviate from the actual version.
1.1.1 Illustration of warnings
To make risks clear, the following signal words and symbols are
used for safety notes.
DANGER
Danger to individuals!
Ignoring a safety note such as this will certainly lead to
irreversible injury and even death.
WARNING
Danger to individuals!
Ignoring a safety note such as this can lead to irreversible injury
and even death.
CAUTION
Danger to individuals!
Non-observance can cause minor injuries.
CAUTION
Material damage!
Information about avoiding material damage.
501.00 | | TOOLFIX modular tool mounting device | en | 1510829

General
6 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
1.1.2 Applicable documents
• General Terms and Conditions *
• Catalog data for the purchased product
• Product approval drawing
The documents labeled with an asterisk (*) can be viewed and/or
downloaded at www.schunk.com.
1.2 Warranty
The warranty is valid for 24 months from the date of delivery from
the production facility.
Parts touching the workpiece and wearing parts are not covered
by the warranty.
1.3 Product Overview
TOOLFIX tool mounting devices
• Basic modules for mounting the system at the workplace
– TOOLFIX MONO → with permanently mounted tool adapter
– TOOLFIX VARIO → with quick-change function for tool
adapter
• Tool adapters for basic modules in all common sizes ( ISO / SK /
BT / Cat / VDI / HSK / CAPTO)
– MONO system → tool adapters are permanently mounted on
the basic module
– VARIO system → tool adapters can be inserted into the
VARIO basic module via quick-change function
– TURN system → tool adapters for MONO and VARIO system
with additional turning function around the tool axis
including detent positions

Basic safety notes
2 Basic safety notes
2.1 Appropriate use
The TOOLFIX system series is intended for installing toolholder
mountings for cutting machines at industrial workplaces for the
purpose of maintenance or service work on the toolholder
mounting or changing the tool or indexable cutter inserts clamped
in the mounting.
• The products may only be used within the scope of their
technical application
• The products are intended for industrial applications.
• Appropriate use of the product includes compliance with all
instructions in this manual.
2.2 Inappropriate use
TOOLFIX tool mounting devices are being used inappropriately, for
example, if:
• they are used as a clamping device, toolholder, load-handling
device or as lifting equipment.
• toolholder tapers are fixed for the purpose of machining.
• they are used in working environments that are not permissible.
• the technical data specified by the manufacturer are exceeded
during usage.
2.3 Structural changes
Implementation of structural changes
Modifications, changes or reworking, e.g. additional threads,
holes, or safety devices, can damage the product or impair its
functionality or safety.
• Structural changes may only be implemented with the written
approval of SCHUNK.
2.4 Spare parts
Use of unauthorized spare parts
Using unauthorized spare parts can endanger personnel and
damage the product or cause it to malfunction.
• Only use original spare parts and spares authorized by SCHUNK.
701.00 | | TOOLFIX modular tool mounting device | en | 1510829

Basic safety notes
8 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
2.5 Ambient conditions and operating conditions
Required ambient conditions and operating conditions
Incorrect ambient and operating conditions can make the product
unsafe, leading to the risk of serious injuries, considerable material
damage and/or a significant reduction in the product's life span.
• Make sure that the product is only used within its defined
application parameters.
• Ensure that the product is of a sufficient size for the workpiece.
• Ensure that the insertion surfaces of the tool adapters are
always clean. Always ensure that no chips of any kind enter the
insertion surfaces.
2.6 Personnel qualifications
Any work on the product by inadequately qualified personnel can
lead to serious injuries and considerable material damage.
• All work must only be performed by appropriately qualified
personnel.
• Personnel must have read and understood the complete
manual before beginning any work on the product.
• Observe country-specific accident prevention regulations and
the general safety notes.
The following personnel qualifications are required for the various
activities on the product:
Specialist personnel:
Specialist personnel have the specialized training, knowledge, and
experience to perform the tasks entrusted to them, to recognize
and avoid potential dangers, and know the relevant standards and
regulations.
Instructed person:
Instructed persons have been instructed by the operator regarding
the tasks entrusted to them and the potential dangers of
inappropriate behavior.
Manufacturer's service personnel:
The manufacturer's service personnel have the specialized
training, knowledge, and experience to perform the work
entrusted to them and to recognize and avoid potential dangers.

Basic safety notes
2.7 Personal protective equipment
Use of personal protective equipment
Personal protective equipment serves to protect staff against
danger which may interfere with their health or safety at work.
• When working on and with the product, observe the
occupational health and safety regulations and wear the
required personal protective equipment.
• Observe the valid safety and accident prevention regulations.
• Wear protective gloves to guard against sharp edges and
corners and rough surfaces.
2.8 Notes on safe operation
Incorrect manner of working by personnel
An incorrect manner of working can make the product unsafe and
risks serious injuries and considerable material damage.
• Only toolholder mountings suitable for the tool adapter may be
clamped.
• Modified or damaged toolholder mountings must not be
clamped with the Toolfix adapters.
• Do not use a hammer to loosen any stuck screws on clamped
toolholder mountings.
• Avoid any manner of working that may interfere with the
function and operational safety of the product.
• Use the product as intended.
• Observe the safety notes and assembly instructions.
• Do not expose the product to any corrosive media.
• Rectify malfunctions as soon as they occur.
• Observe the care and maintenance instructions.
• Observe the current safety, accident prevention, and
environmental protection regulations for the application field of
the product.
Maintenance specifications
Follow the maintenance and care instructions. These instructions
relate to a normal industrial environment. If the product is to be
operated in an environment with abrasive dusts or corrosive or
aggressive fumes or fluids, prior approval must be obtained from
SCHUNK.
901.00 | | TOOLFIX modular tool mounting device | en | 1510829

Basic safety notes
10 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
Safety during assembly and servicing
During assembly, connection, adjustment, commissioning and
testing, make sure that no accidental operation of the system by
the installation technician or other persons is possible.
2.9 Transport
Handling during transport
Incorrect handling during transport can make the product unsafe
and risks serious injuries and considerable material damage.
• When handling heavy weights, use lifting equipment to lift the
product and transport it by appropriate means.
• During transport and handling, secure the product to prevent it
from falling.
• Do not walk under suspended loads.
2.10 Malfunctions
Behavior in case of malfunctions
• Immediately remove the product from operation and report the
malfunction to the responsible departments/persons.
• Order appropriately trained personnel to rectify the
malfunction.
• Do not recommission the product until the malfunction has
been rectified.
• Test the product after a malfunction to establish whether it still
functions properly and ensure no further risks have arisen.
2.11 Disposal
Handling during disposal
Incorrect handling during disposal can make the product unsafe
and risks serious injuries and considerable material and
environmental harm.
• Follow local regulations on dispatching product components for
recycling or proper disposal.
2.12 Fundamental dangers
General
• Observe safety distances.
• Never deactivate safety installations.

Basic safety notes
2.12.1 Protection during handling and assembly
Incorrect handling and assembly
Incorrect handling and assembly can make the product unsafe and
risk serious injuries or considerable material damage.
• All work must only be performed by appropriately qualified
personnel.
• For all work, secure the product against accidental operation.
• Observe the relevant accident prevention regulations.
• Use suitable assembly and transport equipment and take
precautions to prevent jamming and crushing.
Incorrect lifting of loads
Falling loads can cause serious injuries and even death.
• Stand clear of suspended loads and do not step within their
swiveling range.
• Never move loads without supervision.
• Do not leave suspended loads unattended.
2.12.2 Protection during commissioning and operation
Falling components
Falling tools and toolholders can lead to serious injury or death.
• Take suitable protective measures to secure the danger zone.
• Wear suitable protective equipment.
1101.00 | | TOOLFIX modular tool mounting device | en | 1510829

Basic safety notes
12 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
2.12.3 Notes on particular risks
WARNING
Risk of injury from tools or toolholder tapers falling out when
using the TOOLFIX mounting systems.
Parts that have not been properly secured can come loose and
fall out.
•Ensure that the locking mechanism of the tool adapter is
correctly engaged and that the toolholder mounting is
correctly seated.
•Ensure that only suitable toolholder mountings are clamped in
the tool adapters.
•Wear personal protective equipment.
WARNING
Risk of injury to the operating personnel during transport and
assembly of the TOOLFIX mounting system.
•Use a crane or a transport truck when transporting.
•Wear personal protective equipment.
WARNING
Risk of injury from sharp cutting edges. There is a fundamental
risk of injury when working with machining tools.
•When working with machining tools in TOOLFIX mounting
systems, special care is required when standing within direct
reach of the free-standing tool in the TOOLFIX component.
•Wear personal protective equipment.
•Make sure that no other person besides the operator is within
reach of the fixed tool.
CAUTION
There is a risk of limbs being crushed by moving parts during
manual loading and unloading and the clamping procedure.
•Do not reach into the toolholder mounting.
•Use loading devices.
•Wear protective gloves.

Technical data
3 Technical data
Installation position Mount basic modules in the vertical axis
Operating temperature +5°C - +60°C
Basic modules
Type Mounting Quick change Suitable adapters
TOOLFIX MONO 4 x M10 or 4 x M12 No MONO and TURN
tool adapters
TOOLFIX VARIO 4 x M10 or 4 x M12 Yes VARIO and TURN
tool adapters
Tool adapter
Type Quick change Rotatable around the
tool axis
Possible sizes
MONO
tool adapter
No No ISO: (SK, BT) 20, 25,
30, 35, 40, 45, 50, 60
VDI: 16, 20, 25, 30,
40, 50, 60, 80
HSK: 32, 40, 50, 63,
80, 100, 125 (forms A
- F)
Capto: C3, C4, C5, C6,
C8, C10
VARIO
tool adapter
Yes No
TURN
tool adapter
Yes Yes
1301.00 | | TOOLFIX modular tool mounting device | en | 1510829

Technical data
14 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
3.1 Maximum load values
For the following calculation values, it should be noted that
hammer blows and impulses are not taken into account.
Maximum load TOOLFIX MONO basic module:
Fmax = 1,000 N Mmax = 200 Nm
Maximum load TOOLFIX VARIO basic module:
Fmax = 1,000 N
Mmax = 300 Nm
Maximum load TOOLFIX TURN basic module:
Fmax = 1,000 N
Mmax = 150 Nm

Technical data
Maximum load of the tool adapter:
Tool adapter type Size Maximum
loading
weight M
Permissibl
e torque M
HSK-A 32 3.5 kg 150 Nm
42 7 kg 150 Nm
50 6.5 kg 300 Nm
63 7 kg 300 Nm
80 5 kg 300 Nm
100 6 kg 300 Nm
125 6 kg 300 Nm
ISO 30 5 kg 100 Nm
35 6 kg 120 Nm
40 5 kg 120 Nm
45 5 kg 200 Nm
50 3 kg 300 Nm
60 5 kg 300 Nm
Tool adapter type Size Maximum
loading
weight M
Permissibl
e torque M
VDI / VDI-W (Index) 20 5 kg 80 Nm
25 4 kg 80 Nm
30 4 kg 200 Nm
40 4.5 kg 250 Nm
CAPTO C3 50 kg -
C4 100 kg -
C5 100 kg -
C6 100 kg -
C8 100 kg -
1501.00 | | TOOLFIX modular tool mounting device | en | 1510829

Technical data
16 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
Tool adapter type Size Maximum
loading
weight M
Permissibl
e torque M
KM 40 100 kg 200 Nm
50 100 kg 100 Nm
ISO TURN 30 - 150 Nm
40 - 150 Nm
50 - 300 Nm
60 5 kg 300 Nm
Tool adapter type Size Maximum
loading
weight M
Permissibl
e torque M
HSK-A Turn 40 - 150 Nm
63 6.5 kg 100 Nm
80 6 kg 150 Nm
100 4 kg 150 Nm
Capto Turn C4 100 kg 150 Nm
C6 100 kg 150 Nm
C8 100 kg 150 Nm

Screw tightening torques
4 Screw tightening torques
Screw tightening torques for fastening TOOLFIX MONO and
VARIO basic modules to the workstation (screw quality 10.9).
Screw size M10 M12
Maximum admissible torques MA
[Nm]
69 121
1701.00 | | TOOLFIX modular tool mounting device | en | 1510829

Assembly
18 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
5 Assembly
5.1 Pre-assembly measures
CAUTION
Risk of injury due to sharp edges and rough or slippery surfaces.
•Wear personal protective equipment, particularly protective
gloves.
Check that the delivery is complete and that there is no transport
damage. Assembly, dismantling and modification work on the
products may only be carried out by specialist personnel.
When selecting the location for mounting the TOOLFIX system,
ensure there is suitable and ergonomic accessibility and take heed
of the ambient conditions. Mounting the Toolfix system is only
permitted on firmly anchored work tables or cabinets. Slippery or
uneven surfaces in front of the mounted system must be avoided
to enable the employee to stand as safely as possible.
The mounting surface for the TOOLFIX basic module should be
level and free of chips and other contamination.
If the TOOLFIX basic module is to be screwed on from above, four
M10 threads of sufficient depth must be produced in a 90 mm x 90
mm arrangement.
If the TOOLFIX basic module is to be screwed on from below, four
Ø13 holes must be drilled through. If the screw heads are
countersunk due to sinks, care must be taken to ensure that the
countersinks are made in accordance with the standards.

Assembly
1901.00 | | TOOLFIX modular tool mounting device | en | 1510829

Assembly
20 01.00 | | TOOLFIX modular tool mounting device | en | 1510829
5.2 Assembly
WARNING
Risk of injury to the operating personnel during transport and
assembly of the Toolfix components
•Use a crane or a transport truck when transporting.
•Wear personal protective equipment.
During installation, observe the correct tightening torques of the
mounting screws as well as a sufficient depth of engagement.
Below is an example of M10 mounting from above (1) and an
example of M12 mounting from below (2).
