Schwank 4BN6-CB-24 Operating instructions

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
4BN6-CB-24 4SN5-CB-24
4BL6-CB-24 4SL5-CB-24
24 Vac BURNER SERIES
POST MOUNTED INFRARED PATIO HEATER
FOR OUTDOOR USE ONLY
INSTALLATION / OWNER’S MANUAL
This Operation & Instruction manual is not to be removed from the site.
It MUST be given in its entirety to the consumer and retained for future reference.
Installer: Acquaint consumer with all safety procedures in the manual
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause
property damage, injury, or death. This heater must only be installed and serviced by a
qualified gas service technician. Read and understand this installation, operating and
maintenance instructions thoroughly before installation, operation or service to this appliance.
DANGER
IF YOU SMELL GAS:
1. Shut off gas to the appliance
2. Extinguish any open flame
3. If odor continues, keep away from the appliance and immediately call your gas sup-
plier or fire department
WARNING: Do not store or use gasoline or other flammable vapours and liquids in the
vicinity of this or any other appliance.
This appliance is not for use with a portable LP-cylinder. An LP-cylinder shall not be
stored in the vicinity of this or any other appliance.
FIELD CONVERTIBILITY:This appliance is field convertible between natural gas and propane gas
- see GAS CONVERSION Section 5, page 8
Keep this manual in a secure place for future reference.
Record the following information :
Model #: 4BN6-CB-24 Natural Gas
4BL6-CB-24 Propane Gas
4SN5-CB-24 Natural Gas
4SL5-CB-24 Propane Gas
Serial #:
(located on heater rating label)

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
2
NOTICE:
The Manufacturer reserves the right to make changes to equipment
and specifications without obligation or notification.
This publication, or parts thereof, may not be reproduced in any form,
without prior written consent from the manufacturer.
Unauthorized use or distribution of this publication is strictly
prohibited.
Schwank Group / InfraSave
5285 Bradco Boulevard
Mississauga, Ontario,
L4W 2A6
2 Schwank Way
Waynesboro, Georgia,
USA 30830
Customer & Technical Services
Phone: [phone]
Fax: [phone]
e-mail: [email protected]
www.schwankgroup.com
e-mail: [email protected]
www.infrasave.com

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
3
4BN6-CB-24 4SN5-CB-24
4BL6-CB-24 4SL5-CB-24
24 Vac BURNER SERIES
POST MOUNTED INFRARED PATIO HEATER
FOR OUTDOOR USE ONLY
TABLE OF CONTENTS
TOPIC PAGE NUMBER
1. GENERAL..................................................6
2. INSTALLATION REQUIREMENTS............6
3. SPECIFICATIONS .....................................6
4. GAS SUPPLY ............................................7
5. GAS CONVERSION ..................................8
6. MAIN COMPONENTS & DIMENSIONS ....9
7. ASSEMBLY INSTRUCTIONS..................10
8. GAS CONNECTION AND
LEAK TESTING....................................12
9. SAFE LOCATION OF HEATER...............13
9.1 CLEARANCE TO COMBUSTIBLES.......13
10.ELECTRICAL REQUIREMENTS. ............14
TOPIC PAGE NUMBER
11.LIGHTING, OPERATION, AND
SHUTDOWN INSTRUCTIONS............15
12.MAINTENANCE.....................................16
13.SEQUENCE OF OPERATION....... ........17
14.CONTROL WIRING DIAGRAM .............18
14.1 WIRING WITH REMOTE CONTROL ..18
15.Optional Patio Control Panel..................19
16. Patio Control Panel Wiring Diagram.....20
17.Optional Hand Held Remote ..................21
18.TROUBLESHOOTING ...........................27
19.REPLACEMENT PARTS EXPLODED VIEW
...............................................................28
20.LIMITED WARRANTY .......... BACK PAGE
IMPORTANT INFORMATION - READ FIRST
IMPORTANT SAFETY WARNINGS ........ 4, 5
NOTICE TO INSTALLERS........................... 4
CLEARANCE TO COMBUSTIBLES ........... 4

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
4
Important Notice To Installer:
Installation and repairs must be done by a trained gas service technician.
This Operation & Instruction manual is not to be removed from the site. This manual
MUST be given in its entirety to the consumer and retained for future reference. Ac-
quaint the end user with Important Information throughout the manual.
IMPORTANT SAFETY NOTICES AND WARNINGS:
Warning
 Improper Installation, adjustment, alteration, service or maintenance
can cause injury or property damage.
 READ the installation, operating and maintenance instructions thor-
oughly before installing or servicing this equipment.
 It is imperative that control compartment, burners and circulating air
passageways be kept clean and unobstructed.
Warning
Clearance to Combustibles
Do not use, store or locate flammable or explosive objects, liquids or vapors in
proximity of the heater. Location of flammable or explosive objects, liquids or va-
pors close to the heater may cause fire or explosion and result in property dam-
age, injury or death.
The clearance to combustible material represents the minimum distance
that must be maintained between the outer heater surface and a nearby
surface. The stated clearance to combustibles represents a surface tem-
perature of 90F° (50C°) above room temperature.
It is the responsibility of the installer and end user to ensure that build-
ing materials with a low heat tolerance which may degrade at lower tem-
peratures are protected to prevent degradation. Examples of low heat
tolerance materials include vinyl siding, fabrics, canvas, plastics, filmy
materials, tri-ply, etc.
 In addition to stored or stationary material, clearance consideration must also be given to
moveable objects such as furnishings and vehicles, and structural objects such as electrical
and gas lines, electrical fixtures, and sprinkler heads.
 Heaters must be located an appropriate distance from sprinkler heads. This distance may be
greater than the certified clearance to combustibles. Check the temperature rating of the sprin-

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
5
kler heads and locate heaters at a safe distance - in some instances the sprinkler heads may
need to be replaced by higher temperature rated heads. Check with the local Fire Marshall
and your insurance carrier.
CLEARANCES TO COMBUSTIBLES
MUST BE MAINTAINED OR EXCEEDED:
Maintain clearances to combustible materials
as shown in Fig. 1:
 Sides of Reflector: 24 inches
 Above Reflector: 18 inches
 Below Reflector: 24 inches
WARNING:
 CHILDREN AND ADULTS SHOULD BE ALERTED TO THE HAZARDS OF HIGH SURFACE
TEMPERATURES AND SHOULD STAY AWAY TO AVOID BURNS OR CLOTHING IGNITION.
 YOUNG CHILDREN SHOULD BE CAREFULLY SUPERVISED WHEN IN THE AREA OF A
HEATER.
 CLOTHING OR OTHER FLAMMABLE MATERIALS MUST NOT BE HUNG FROM, OR PLACED
ON OR NEAR THE HEATER.
 INSTALLATION AND REPAIR SHOULD BE DONE BY AQUALIFIED SERVICE PERSON. THE
HEATER SHOULD BE INSPECTED BEFORE USE AND AT LEAST ANNUALLY BY AQUALI-
FIED SERVICE PERSON.
MORE FREQUENT CLEANING MAY BE REQUIRED AS NECESSARY. ITIS IMPERATIVE THAT
CONTROL COMPARTMENT, BURNERS AND AIR CIRCULATING PASSAGEWAYS OF THE
HEATER BE KEPT CLEAN.
 ANY GUARD OR OTHER PROTECTIVE DEVICE REMOVED FOR SERVICING THE HEATER
MUST BE REPLACED PRIOR TO OPERATING THE HEATER
Do not alter or modify this heater in any way
It is beyond the scope of these instructions to consider all conditions that may be encountered.
Consult local authorities such as the Fire Marshall, insurance carrier, or safety authorities if you
are uncertain as to the safety or applicability of the proposed installation.
Refer to Figure 1 and Table above for the certified clearances to combustibles.
Fig. 1 18”
24”
24”
24”
CLEARANCES TO COMBUSTIBLES

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
6
2. INSTALLATION REQUIREMENTS
The installation must conform with local codes or, in the absence of local codes, with the National
Fuel Gas Code ANSI Z223.1 / NFPA 54, Natural Gas and Propane Installation Code, CAN/CGA-
B149.1, or Propane Storage and Handling Code, B149.2.
The heater, when installed, must be electrically grounded in accordance with local codes, or in the
absence of local codes, with the National Electrical code, ANSI / NFPA 70, or the Canadian Elec-
trical Code, CSA C22.1.
1. GENERAL
WARNING: Improper operation, installation, adjustment, alteration, servicing or mainte-
nance can cause severe property damage, serious injury or death.
Carefully read this User Guide before installing and setting up the heater.
This heater must only be installed and serviced by a qualified gas service technician. Failure to comply
could result in personal injury, death, fire and/or property damage.
The series 4SN/L5-24 and 4BN/L6-24 heaters must always maintain the proper clearance to com-
bustible materials. (Top 18” sides 24” below 24”). Do not use this heater in an explosive atmos-
phere or indoors. Keep heater away from areas where gasoline or other flammable liquids or va-
pors are stored. Maintain adequate clearance around air openings into the combustion chamber.
This appliance is a gas-fired infrared fixed post patio heater for outdoor use only and shall be
used in a well ventilated area, and shall not be used in a building, garage or any other en-
closed area.
This appliance may be installed with shelter no more inclusive than:
 With walls on all sides, but with no overhead cover
 Within a partial enclosure which includes an overhead cover (maintain clearance to com-
bustibles above heater) and no more than two side walls. These side walls may be paral-
lel, as in a breezeway, or at right angles to each other
 Within a partial enclosure which includes an overhead cover and three side walls, as long
as 30 percent or more of the horizontal periphery of the enclosure is permanently open
 Fixed fuel piping system requirements: Natural Gas Propane Gas
Maximum Gas Supply Pressure 7” w.c. 14” w.c.
Recommended Gas Supply Pressure 5” w.c. 11” w.c.
Manifold Pressure 3.5” w.c. 10.5” w.c.
Operating Input Rating (Btuh) 38,000 38,000
3. SPECIFICATIONS:
 Fuel supply must be regulated (regulator field supplied) to provide proper gas supply
pressure
 Electrical: 24Vac
 Effective radiant range: 8 to 20 foot circle (affected by wind and ambient temperature)
 Heater net weight: 60 lbs
 Certification: CSA International USA and Canada
4SN5 and 4BN6 4SL5 and 4BL6

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
7
4. GAS SUPPLY:
The heater comes with a flexible hose assembly inside the post with 3/8” male flared fitting for
hook-up to a minimum 5” w.c. Natural Gas supply (7” w.c. maximum), OR minimum 11” w.c. LP
Gas (14” w.c. maximum).
The combination gas control valve in the heater has an integral pressure regulator that reduces
gas manifold pressure to the orifice and burner to 3.5” w.c. natural gas, or 10.5” w.c. propane.
The gas valve is convertible between natural gas and LP gas, but must be supplied with the gas
type that has been set for operation. See Section 5. below for conversion between gas types.
Never connect an unregulated gas supply to the heater.
Only use the gas type set for operation of the heater. Do not use LP gas if the gas
valve and gas orifice are set for natural gas, or do not use natural gas if valve and
orifice are set to operate on LP gas. Personal injury, death, and/or property dam-
age can result from using the incorrect gas.
Gas supply to this heater requires a gas pressure regulator (not supplied). Heaters may be con-
nected to a regulator individually or in zones. Gas pressure regulators must be for the correct gas
type, and properly sized for each particular installation.
For your safety a complete gas tightness check of all connections and hoses must be performed at
the installation site, prior to use.
PRESSURE TESTING OF THE GAS SUPPLY PIPING
 This appliance and its individual shutoff valve must be disconnected from the gas supply piping
system during any pressure test of that system at test pressures in excess of 1/2 psi (3.5 kPa)
 This appliance must be isolated from the gas supply piping system by closing its individual
manual shutoff valve during during any pressure testing of the gas supply system at test pres-
sures equal to or less than 1/2 psi (3.5 kPa)
LEAK TEST MUST BE PERFORMED: refer to Leak Test procedures on page 12
Any repairs must be made by a trained and qualified gas service technician.
PRECAUTIONS:
 Periodically, or if the smell of gas is detected, check the whole system for leaks
 Follow leak test procedures on page 12
 Extinguish all open flames.
 Never smoke while leak testing.
 If you detect a leak, turn off the gas supply and call a qualified gas service technician, or
your gas supplier.
 Only replacement parts by the manufacturer are to be used for repair. Substitution can
create a safety issue and result in serious injury or death, and will void the warranty.
 Do not use the heater until all connections have been leak tested and are sound !!!
NATURAL GAS or PROPANE

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
8
5. GAS CONVERSION:
NATURAL GAS or LP GAS
WARNING: Conversion from one fuel gas to another shall only be done by a trained
and qualified gas service technician. Ensure all gas supply and heater components
are correct for the type of fuel gas in use.
Use only parts and components supplied by the manufacturer to accomplish conversion from one
gas type to another. Incorrect or improper conversion can result in personal injury, death, fire,
and/or property damage, and will void the product warranty.
Conversion from natural gas to LP gas: Requires LP gas orifice (order JP-4009-OL-J from
manufacturer), conversion of gas control valve to LP gas (see below), and an LP pressure regula-
tor (field supplied) in the gas supply line
Conversion from LP gas to natural gas : Requires natural gas orifice (order JP-4009-ON-J from
manufacturer), conversion of gas control valve to natural gas (see below), and a natural gas pres-
sure regulator (field supplied) in the gas supply line
1. Install the proper gas type orifice (see heater exploded view page 29)
2. Convert Gas valve:
 Conversion from NAT to LP (or
vice-versa) is accomplished by in-
verting the position of the conver-
sion screw in the gas valve body,
and replacing the orifice
 The conversion screw is marked
with “NAT ” on one end and “LP ’’
on the other end - the arrow “ ’’
indicates the end to be inserted
into the valve
 Ensure that the gas selection nip-
ple is seated firmly into the valve
body for the correct gas type
2. Check gas pressures:
 Ensure the gas supply pressure
regulator matches the gas type
 Check and set the gas supply
pressure to ensure a minimum 5”
w.c. natural gas (7” w.c. maximum) or minimum 11” w.c. LP gas (14” w.c. maximum)
 The heater manifold pressure can be checked at either of the side ports on the gas control
valve
 Remove one of the threaded plugs at the side of the valve
 Install a hose barb, connect and read manifold pressure with manometer
 The valve is factory-adjusted to 3.5” w.c. natural gas and 10.5” w.c. LP gas
 Replace threaded plug after confirming manifold gas pressure - use sealant on
threads
Conversion screw
Manifold gas
pressure
test port
3/8” FNPT gas supply
Gas type marked in
conversion screw

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
9
Models 4SN/L5-24 include stainless post and base: N = natural gas, L = propane.
Models 4BN/L6-24 has black powder coated post and base: N = natural gas, L = propane.
Gas valve and orifice are specific to gas type, all other components are common for all models.
Note: A gas pressure regulator(s) is required (not supplied ) to regulate gas supply pressure. The
combination gas control valve in the heater has an integral pressure regulator that reduces mani-
fold pressure to the gas orifice and burner to 3.5” w.c. or 10.5” w.c. propane.
6. MAIN COMPONENTS AND DIMENSIONS
95”
18”
Mounting Base
On / Off Switch
Radiant Heat Emitter
2410 mm
813 mm
457 mm
32”
Combustion Air Intakes

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
10
7. HEATER ASSEMBLY
Tools Needed: (not supplied)
Adjustable Wrench, Slip Joint Pliers, Phillips Screwdriver-Medium Blade (#2 or #3 blade), Ham-
mer, 3/8” Masonry Drill Bit (if mounting on concrete patio), Plumbing Seal/Tape for Joints, Spray
Bottle of Soapy Water or Paint Brush and soapy water (leak testing)
1. Using nuts and bolts
supplied, fasten the post
stub plate to the base
cover.
2. Align access port in post to
slot in post stub.
Secure the post to the stub
using screws supplied.
5. Tip post/base assembly on its side.
The gas hose can be connected to the gas supply either:
 With hose extended under the heater base (typical)
 Gas connection is concealed and protected under
heater base
 With hose out through the access port in the post
 Gas connection is exposed - sidewall/above deck con-
nection
 Ensure exposed gas hose is protected from physical
damage
6. Make connection from gas supply to gas hose
 Note: Concealed gas connection under heater: Once
heater is fully installed, temporary access to concealed
connections in the gas supply will be required for leak
testing
OR
3. Connect gas hose to burner and secure connection with a
wrench.
4. Feed gas hose and 24V wire down the post and temporarily
secure the burner assembly to post with screws supplied.
HAND TIGHTEN the fastening screws at this time. When the
heater is connected to the gas supply, the burner head will
need to be lifted to leak test the hose connection to the
burner valve.

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
11
ASSEMBLY..... CONTINUED
8. Reflector Assembly to Burner:
OR
7. The type of hardware needed to secure the heater to the
deck or patio is site determined - heater mounting hardware
is field supplied.
The heater can be secured to the deck or patio by one of two
methods:
1) Using lag screws or bolts through the four holes in the
heater base
2) Attach mounting brackets to side of base - bolt or lag to
patio or deck
NOTE: Concealed gas connections: once secured in place, the
hardware will need to be loosened/removed to allow leak testing
access to connections under the heater.
Ensure mounting hardware is of sufficient strength and integrity
to support the heater in windy, and other conditions that may be
encountered.
Stainless steel hardware that does not rust is recommended.
Check that the post and the burner assembly stand vertically plumb.
Make sure all bolts and nuts are tightened.
Ensure all gas connection is sound and the installation conforms to local and national codes.
Perform leak testing of all gas connections (see page 12)
Ensure electrical supply and connection to local and national codes.
Setup is now complete.
 Install a washer onto threaded portion of wing
bolts
 Align holes in reflector to those in the brackets
at top of burner
 Secure reflector to burner with wing bolts.
8. Electrical Connection:
8. Reflector Assembly to Burner:

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
12
This heater must only be serviced by a trained and qualified gas service technician. Failure to
comply could result in personal injury, death, fire and/or property damage.
LEAK TEST:
Prior to putting the assembled heater into service a leak test of all gas supply connections and
hoses must be performed.
Mix equal parts of water and soap, apply mixture liberally to all gas connections.
1. Ensure that the heater is inoperable - shut off electrical supply to heater.
2. Open the gas supply valve
3. Apply the soap solution generously to all connections and hoses.
 If bubbles are detected, there IS a leak.
 Close gas supply valve completely.
 Call a trained and qualified gas service technician to accomplish repairs.
 Tighten, repair or replace components at the leaking connection and repeat leak test proce-
dure
 The heater cannot be put into service until ALL gas leaks have ceased, no matter how small.
 Connect the natural gas supply line to the flexible hose at the base of the post as per local or
national gas code.
 The natural gas supply must be regulated, and piping sized accordingly to provide a minimum
5” w.c. (maximum 7” w.c.) gas pressure to each heater.
8. GAS CONNECTION AND LEAK TESTING:
Locate the gas hose and piping out of pathways where people may trip over them, or in areas
where the hose/piping may be subject to accidental damage.
NATURAL GAS CONNECTION:
PROPANE CONNECTION:
 This appliance is NOT for use with a portable LP-cylinder
 Connect the propane gas supply line to the flexible hose at the base of the pole as per local
or national gas code.
 The LP gas supply must be regulated, and piping sized accordingly to provide a minimum
11” w.c. (maximum 14” w.c.) gas supply pressure to each heater.
WARNING

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
13
9. SAFE LOCATION OF HEATER:
CAUTION: THIS HEATER IS FOR OUTDOOR USE ONLY
See also “Installation Requirements”, section 2, page 6
Locate the heater out of pathways where people may come into contact with it, or in areas where
the heater may be subject to accidental damage.
This heater can be used to provide radiant heat comfort outdoors, at poolside, spa areas, ter-
races, patios and work areas, etc. Not for indoor use. (refer to section 2, page 6)
It is necessary to provide “wind breaks”, against wind and breezes to maximize comfort.
If objects are left under a heater in operation, such objects will be subject to radiant heat.
Always maintain at least the minimum certified clearances to combustibles from the heater to any
adjacent combustible materials. Refer to Fig 12 below.
 Install heater on a level, solid and stable surface.
 Do not install in an explosive environment. Keep away from areas where gas vapours
are present or inflammable liquids are stored or used.
 In case of high winds, completely shut-off the heater and gas valve. Remove reflector
dome to secure storage if necessary
9.1 CLEARANCES TO COMBUSTIBLES MUST BE MAINTAINED:
The clearances to combustibles represent a
surface temperature of 90F° (50C°) above am-
bient temperature.
It is the installer’s and end user’s responsibil-
ity to ensure that materials with a low heat tol-
erance which may degrade at lower tempera-
tures are protected to prevent degradation.
Examples of low heat tolerance materials in-
clude vinyl siding, fabrics, canvas, plastics,
filmy materials, tri-ply, etc.
Maintain clearances to combustible materials
as shown in Fig. 12:
 Sides of Reflector: 24 inches
 Above Reflector: 18 inches
 Below Reflector: 24 inches
 Children and Adults should be alerted to the hazards of high surface temperatures and
should stay away to avoid burns or clothing ignition.
 Young children should be carefully supervised when in the area of a heater.
 Clothing or other flammable materials must not be hung from, or placed on or near the
heater.
Fig. 12 18”
24”
24”
24”
CLEARANCES TO COMBUSTIBLES

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
14
10. ELECTRICAL REQUIREMENTS
The heater, when installed, must be electrically grounded in accordance with local codes or, in the
absence of local codes with the National Electrical Code, ANSI/NFPA 70, or the Canadian Electri-
cal Code, CSA C22.1. All wiring and electrical connection must conform to the requirements of the
above codes.
Single heater requires 24 Vac, 60 Hz electrical transformer sized at 40 VA. If multiple heaters are
connected to a single transformer, the proper transformer is 24 Vac, 60 Hz, sized at 40 VA for the
first heater, plus 20 VA for each subsequent heaters. For example, four heaters wired together
(parallel), require a transformer of 100 VA. It is not recommended to install more than 12 heaters
per zone. PROPER WIRING POLARITY MUST BE MAINTAINED, particularly when grouping the
heaters in a zone.
Total wiring distances of up to 200' must use minimum 16 gauge electrical wire, and wiring dis-
tances of over 200' must use minimum 14 gauge electrical wire. The heater when installed must
be electrically grounded in accordance with the local codes or, in the absence of local codes, with
the National Electrical Code, ANSI/NFPA 70. Malfunction of the heating system will result if the
voltage varies by more than +10% or -10%.
The heater can be controlled by:
 The “on / off” switch located in the control cover on the heater
 An optional radio frequency hand-held remote control
 Power to the heater or zone of heaters can be controlled / isolated by a switch or switching
panel located in a secure central location
 Total load of all heaters must be considered in determining the required contact rating of
the controlling switch.
Keep any electrical supply cord or wiring away from any heated surfaces.

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
15
11. LIGHTING, OPERATION, AND SHUTDOWN INSTRUCTIONS
LIGHTING:
1. A gas hose located inside the post supplies fuel to the burner.
Prior to each use of the heater inspect any visible portion of
the hose that is exposed. If there is any damage or wear to
the exposed hose, call a qualified gas service technician to
replace the damaged hose with one supplied from the manu-
facturer.
2. An “On / Off” toggle switch is located on the control cover be-
low the burner. To turn the heater “On” (start ignition se-
quence) place the toggle switch up to the “On” position.
3. After completing a 3 second pre-purge cycle the direct spark
ignition (DSI) control generates high voltage to the spark ig-
niter, and 24 volts to energize the gas valve.
3. The Burner will light and establish a steady flame.
4. Once the flame sensor determines there is a steady flame
established, the spark igniter is then de-energized.
5. If a flame is not established during the first 20 second Trial for Ignition (T.F.I.), the unit will per-
form an inter-purge and a second T.F.I. If a flame is not established during this attempt, an-
other inter-purge and T.F.I. will be performed. If a flame is not established during the third
(final) attempt, the unit will enter the soft lockout mode. The soft lockout mode is a 30 minute
time-delay after which the unit will reset to try to ignite the gas again, as in normal operation,
and will repeat the T.F.I. sequence.
6. If there is a loss of flame during the run mode, the unit will energize the spark within 0.8 sec-
onds and perform a T.F.I., without the gas valve being closed first, this is called Spark Resto-
ration. If a flame is not established during Spark Restoration the unit will repeat the process in
step number 5 (above).
10. If a flame is present with the Gas Valve de-energized the unit will enter a hard lockout mode.
If there is an internal fault detected within the control, this will also cause hard lockout. Any
hard lockout will require service by a qualified service person.
SHUTDOWN:
1. An “On / Off” toggle switch is located on the control cover below the burner. To turn the heater
“Off” place the toggle switch down to the “Off” position.
2. If the heater will not be used for some longer time period, or requires service, shut off the elec-
trical and gas supplies to isolate the heater.

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
16
12. MAINTENANCE
1. Prior to each use, inspect the heater for damage - a qualified gas service person must repair
or replace any damaged or malfunctioning components as supplied by the manufacturer.
2. Periodically (monthly) perform a leak test of all visible gas connections to ensure safe opera-
tion - see page 12 for leak test procedures
3. Annually inspect the gas hose that is concealed inside the confines of the post. Refer to the
assembly instructions (pages 10 -11) in reverse order to expose the hose for inspection. If
there is evidence of excessive abrasion or wear, replace the gas hose or any worn or defective
components only with replacement parts available from the manufacturer.
4. Reassemble the heater and leak test all connections as instructed on page 12.
5. Keep the appliance area clear and free form combustible materials, gasoline and other flam-
mable vapors and liquids
6. Ensure that there is no obstruction to the flow of combustion and ventilation air
7. Visually inspect the burner flame performance.
 The burner area is likely to attract spiders, especially inside the orifice. Annually before
the heater is put into service, the heater should be inspected by a qualified gas service
technician for spider webs, insects, and debris around burner and orifice. A plugged in-
jector or orifice will obstruct the gas flow to the burner. This will result in burner malfunc-
tion and possible damage.
 A heater that is operating properly will produce a relatively uniform ‘orange glow’ over
the surface of the emitting mantel. (Caution: Wind conditions can cool portions of the
emitter surface below the temperature of the visual spectrum.)
 A poorly performing burner will exhibit uneven ‘orange glow’ at the bottom of the mantle,
and the top portion of the mantle will be dark (below the visual spectrum temperature)
 Other indicators of poor burner performance are:
 A gas ‘smell’ combined with yellow tipped flames on burner
 Heater does not provide expected heat output capacity
 Burner makes small popping sounds while operating. Note: When heater is warming
up or cooling down a pinging metallic noise is normal.
 A heater in this poor performance condition requires service by a qualified gas service
(Continued on page 17)
Good Burner Performance:
Uniform color and heat output
Poor Burner Performance:
Irregular color, dark top,
and heat output at bottom
Dark zone at top
Possible uneven
yellow-tipped
flame, small
‘popping’ sound
Uniform
‘orange’
colored
mantle

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
17
The 4N/L-51/62-24, 44N/L-5/6-24 Patio Heater
direct spark ignition, sequence is as follows :
13. SEQUENCE OF OPERATION - GASLITER MICRO 50N IGNITION CONTROL
1. 24 volts supplied to the DSI control initiates the 3 second pre-purge cycle.
2. After completing the 3 second pre-purge cycle the DSI control generates high voltage to the
Spark Igniter, and 24 volts to energize the Gas Valve.
3. The Burner will light and establish a steady flame.
4. Once the flame sensor determines there is a steady flame established, the spark igniter is
then de-energized.
5. If a flame is not established during the first 20 second Trial for Ignition (T.F.I.), the unit will
perform an inter-purge and T.F.I. If a flame is not established during this attempt, another in-
ter-purge and T.F.I. will be performed. If a flame is not established during the final attempt,
the unit will enter the soft lockout mode. ) (The soft lockout mode is a 30 minute delay time
after which the unit will reset to try to ignite the gas again as in NORMAL OPERATION
6. If there is a loss of flame during the run mode, the unit will energize the spark within 0.8 sec-
onds and perform a T.F.I., without the gas valve being closed first, this is called Spark Resto-
ration. If a flame is not established during Spark Restoration the unit will repeat the process in
step number 5 (above).
7. If a flame is present with the Gas Valve de-energized the unit will enter a hard lockout mode.
If there is an internal fault detected within the control, this will also cause hard lockout. A
qualified gas service person is required to repair or replace defective components with parts
from the manufacturer.
person
 Refer to trouble shooting guide page 28
8. Periodically clean the heater with a mild detergent solution and rinse with clear water, or use a
commercially available specialty cleaner. In particular keep the surface clean and clear at the
base of the burner where air is taken in for combustion.
A complete replacement parts list is on page 29. Replacement parts are available from a local dis-
tributor in your area. Contact information for the manufacturer is available inside the front cover of
this manual.

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
18
14. WIRING DIAGRAM:
14.1 WIRING DIAGRAM: WITH REMOTE CONTROL RECEIVER

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
19
15. OPTIONAL 24 Vac PATIO HEATER CONTROL PANEL
This panel and all heaters in the system must be installed and grounded in accordance
with all applicable local and national codes.
Each panel is supplied with switches for 4, 8 or 12 zones (maximum two heaters per zone).
Total wiring distances must be considered and low voltage wire correctly sized to suit the total
VA rating of the transformer. All low voltage wire must be adequately sized for the total
load - total wiring distances up to 200 feet must use minimum 16 gauge electrical wire,
and wiring distances over 200 feet must use minimum 14 gauge electrical wire.
Confirm the electrical wiring system capacity with ALL heaters ON under full load by taking volt-
age readings at the ignition module terminals of each heater . To avoid system malfunction,
the voltage range must be within 21.6 volts to 26.4 volts (± 10%). Also ensure proper po-
larity.
The patio panel allows for ‘On/Off’ control of up to 4, 8 or 12 individual heaters or zones of heat-
ers (two heaters per zone max.). If a thermostat is to be incorporated in the system, it must be
installed in the circuit between the panel and the heater(s). Total load of the heaters being con-
trolled must be considered in determining the contact rating of the thermostat.
If the installation provides an individual transformer for each heater, size each of the 24 Vac,
60Hz transformers at 40VA. A single transformer sized for a multiple heater installation, requires
40 VA for the first heater only, and 20 VA for each additional heater.
Example: 5 heaters wired in parallel require a calculated 120 VA (40 + 20 + 20 + 20 +20) -> se-
lect the closest rated transformer HIGHER than the calculated 120 VA = 150 VA.
The best mode of control for each individual heater is by “ON/OFF” switch. If a thermostat is to
be incorporated into the system it must be installed downstream of the control panel.
For central control of patio heater installations:
Patio heater control panels are available with switches for 4
zones (PCP-4), 8 zones (PCP-8), or 12 zones (PCP-12). At
most, one switch can control maximum two heaters in a zone.
The panel is designed to be surface mounted INDOORS only,
and preferably located in a secure staff area, beyond the reach
of patrons.
WARNING
Must be used for low voltage (24V) wiring only. To avoid
system malfunction, PROPER WIRING POLARITY MUST
BE MAINTAINED.
PCP-8 shown
Part # Heater
Zones Height Width Depth
PCP-4 JM-0204-NT Up to 4
PCP-8 JM-0208-NT Up to 8
PCP-12 JM-0212-NT Up to 12
Maximum #
of Heaters
Up to 8
Up to 16
Up to 24

4BN/L6-24,4SN/L5 -24 Manual
IM100310
RD: MAR, 2010
RL: 1A - BA
20
16. OPTIONAL PATIO HEATER CONTROL PANEL WIRING 24 Vac
