MS-H280/MS-PA/MS-PB Magnetic/Hotplate Stirrer

User Manual

MS-H280-Pro BlueSpin LED Digital Hotplate Magnetic Stirrer

MS-PA BlueSpin LED Digital Magnetic Stirrer

MS-PB BlueSpin Classic Magnetic Stirrer

Please read the User Manual carefully before use, and follow all

operating and safety instructions!

www.scilogex.com

12300175

Contents

Preface.................................................................................1

Service.................................................................................1

Warranty ..............................................................................1

1. Safety Instructions.......................................................2

2. Proper Use ...................................................................3

3. Inspection ....................................................................4

3.1 Receiving Inspection .............................................4

3.2 Listing of Items .....................................................4

4. Control.........................................................................4

4.1 Control elements....................................................4

4.2 Display...................................................................7

5. Trial Run......................................................................8

6. Function: Heating ( Digital hotplate model )...............8

6.1 Working with external temperature sensor ............9

6.2 Residual heat warning（HOT）...........................9

7. Stirring.......................................................................10

8. Faults .........................................................................10

9. Maintenance and Cleaning ........................................ 11

10. Associated Standards and Regulations ...................... 11

11. Specifications ............................................................12

12. Ordering Information.................................................14

BlueSpin (Hotplate) Magnetic Stirrer

Preface

Welcome to the “BlueSpin (Hotplate) Magnetic Stirrer”.

Users should read this Manual carefully, follow the

instructions and procedures, and be aware of all the

cautions when using this instrument.

Service

When help needed, you can always contact the Service

Department of manufacturer for technical support in the

following ways:

SCILOGEX, LLC

500 Four Rod Road

Suite 122

Berlin, CT 06037 USA

Tel: 1-860-828-5289

Fax: 1-860-828-5389

E-mail: info@scilogex.com

Http://www.scilogex.com

Please provide the customer care representative with the

following information：

• Serial number（on the rear panel）

•Certification

• Description of problem (i.e., hardware or software)

• Methods and procedures adopted to resolve the problems

• Your contact information

Warranty

This instrument is warranted to be free from defects in

materials and workmanship under normal use and service,

for a period of 24 months from the date of invoice. The

warranty is extended only to the original purchaser. It shall

not apply to any product or parts which have been damaged

on account of improper installation, improper connections,

misuse, accident or abnormal conditions of operation.

For claims under the warranty please contact your local

supplier. You may also send the instrument directly to

manufacturer, enclosing the invoice copy and by giving

reasons for the claim.

BlueSpin (Hotplate) Magnetic Stirrer

1. Safety Instructions

Warning!

•Read the operating instructions carefully

before use.

•Ensure that only trained staff works with the

instrument.

Risk of burn!

•Caution when touch the housing parts and

the hotplate which can reach temperature of

280°C.

•Pay attention to the residual heat after

switching off.

Protective ground contact！

•Make sure that socket must be grounded

(protective ground contact) before use.

• When working wear personal safety guards to avoid the

risk from:

- Splashing and evaporation of liquids

- Release of toxic or combustible gases

• Set up the instrument in a spacious are on a stable, clean,

non-slip, dry and fireproof surface. Do not operate the

instrument in explosive atmospheres, with hazardous

substances or under water.

• Gradually increase the speed, reduce the speed if:

- Stirring bar breaks away due to high speed

- The instrument is not running smoothly, or container

moves on the base plate

• Temperature must always be set at least 50℃lower than

the fire point of the media used.

• Be aware of hazards due to:

- Flammable materials or media with a low boiling

temperature

- Overfilling of media

- Unsafe container

• Process pathogenic materials only in closed vessels.

• Check the instrument and accessories prior to each use.

Do not use damaged components. Safe operation is only

guaranteed with the accessories described in the

“Accessories” chapter. Accessories must be securely

attached to the device and can not come off by themselves.

Always disconnect the plug before fitting accessories.

• When the external temperature sensor needed, the tip of

the measuring sensor must be at least 5-10mm from vessel

bottom and wall.

BlueSpin (Hotplate) Magnetic Stirrer

• The instrument can only be disconnected from the main

power supply by pulling out the main or the connector plug.

• The voltage stated on the label must correspond to the

main power supply.

• Ensure that the main power supply cable does not touch

the hotplate. Do not cover the device.

• The instrument may only be opened by experts.

• Keep away from high magnetic field.

2. Proper Use

The instrument is designed for mixing and/or heating

liquids in schools, laboratories or factories.

• Observe the minimum distances between the devices,

between the device and the wall and above the assembly

(min. 100 mm)

Figure 1

This device is not suitable for using in residential areas or

other constraints mentioned in Chapter 1.

BlueSpin (Hotplate) Magnetic Stirrer

3. Inspection

3.1 Receiving Inspection

Unpack the equipment carefully and check for any damages

which may have arisen during transport. Please contact

manufacturer/supplier for technical support.

Note:

If there is any apparent damage to the system,

please do not plug it into the power line.

3.2 Listing of Items

The package includes the following items:

Items Qty

Main unit 1

Power cable 1

Stirrer bar 1

User Manual 1

Table 1

4. Control

4.1 Control elements

Speed Control Knob

LED Display

Temperature Control Knob

( Hotplate model )

Probe

( Hotplate model )

Figure 2 Digital hotplate model



5

BlueSpin (Hotplate) Magnetic Stirrer

Speed Control Knob

LED Display



Figure 3 Digital model

Speed Control Knob

Figure 4 Classic model



Figure5



6

BlueSpin (Hotplate) Magnetic Stirrer

Items Descriptions

Digital hotplate

model

Temperature Control

Knob Heat

Set the temperature parameters. The function “heating” is switched ON or

OFF via push ON/OFF knob.

Speed Control Knob Stir

Set the rotary speed. The function “Stirring” is switched ON or OFF via

push ON/OFF knob.

LED Display LED displays the real working state and all settings.

Probe

When the external temperature sensor PT1000 is plugged in, probe icon

is lit.

Power Switch Switch ON or OFF the instrument.

Digital model

Temperature Control

Knob Stir

Set the rotary speed. The function “Stirring” is switched ON or OFF via

push ON/OFF knob.

LED Display LED displays the real working state and all settings.

Power Switch Switch ON or OFF the instrument.

Classic model

Speed Control Knob Stir The stirring function is switched ON by rotating the knob.

Power Switch Switch ON or OFF the instrument.

Table 2



7

BlueSpin (Hotplate) Magnetic Stirrer

4.2 Display



Figure 6 Digital hotplate model

Characters Descriptions

Temperature

display area

When heating function was switched ON,

LED displays the temperature setting

value and shifts to real value in 5 seconds.

When the heating function is switched

OFF and the hotplate temperature is still

above 50°C, LED displays “Hot”,

otherwise LED displays OFF.

Speed display

area

When stirring function was switched ON,

LED displays the speed setting value and

flashes. The setting value does not flash

until real speed reaches the set point.

Table 3



Figure 7 Digital model

Characters Descriptions

Speed display

area

When stirring function was switched

ON, LED displays the speed setting

value and flashes. The setting value

does not flash until real speed reaches

the set point.

Table 4



8

BlueSpin (Hotplate) Magnetic Stirrer

5. Trial Run

• Make sure the required operating voltage and power

supply voltage match.

• Ensure the socket must be properly grounded.

• Plug in the power cable，ensure the power is on and begin

initializing.

• Add the medium into the vessel with an appropriate

stirring bar.

• Place vessel on the work plate.

• Set the target stirring speed and begin.

• Observe the stirring bar and LED display (digital model).

• Set the target temperature and start heating.

• Observe the LED display (digital hotplate model).

• Stop the heating and stirring functions.

If these operations above are normal, the device is ready to

operate. If not, the device may be damaged during

transportation, please contact manufacturer/supplier for

technical support.

Warning !

Forbid to transfer the vessel when the instrument

working.

6. Function: Heating (Digital

hotplate model )

The device is controlled by digital temperature control

technology, which has two separate safe circuits. The

hotplate is kept at a constant temperature by a digital

control circuit. The hotplate temperature can also be

monitored from a separate, adjustable safe circuit. The two

temperature sensors internal for temperature control are

built into the hotplate. The single external PT1000 can

monitor the temperature of sample.

•Plug in the external PT1000.

•Set the temperature via rotating the temperature

control knob slowly to the target value.

•When the heating function is switched on, the LED

displays the temperature value on the left-hand side.

•The heating function is switched on or off by pushing

heating knob.

The instrument automatically displays the last running

speed and temperature parameters once turned on.

Generally, the LED screen cannot display the actual

temperature of sample in the vessel or hotplate surface,

temperature differences as following:



9

BlueSpin (Hotplate) Magnetic Stirrer

‐Hotplate center and outer edge.

‐The sample in the vessel and hotplate surface.

In order to ensure the accuracy of the temperature inside the

container, please use the external temperature sensor

PT1000.

6.1 Working with external temperature

sensor



Figure 6

The external temperature sensor PT1000 is the

manufacturer’s standard accessory. When PT1000 sensor is

connected and rotate the temperature control knob, LED

displays the temperature setting value and shifts to real

value in 5 seconds. Safe circuit controls hotplate

temperature under 320°C. Comparing with the temperature

control of the hotplate, the external temperature sensor can

control the medium’s temperature more precise. The

heating function will be stopped automatically under

abnormal conditions. Please operate follow the instructions

below:

•Switch OFF the instrument.

•Ensure the external temperature sensor is inserted in

the media heated.

•Switch ON the instrument and run heating function.

If the heating function does not work, please contact

manufacturer/supplier for technical support.

6.2 Residual heat warning（HOT）

In order to prevent the risk of burns from a hotplate, digital

hotplate has a residual heat warning function. When the

heating function is switched off and the heating plate

temperature is still above 50°C, “Hot” will flash to warn

that there is a hazard of burns from the hotplate. When the

unit is powered off, the LED screen displays the

temperature of hotplate and Hot in turn. When the hotplate

temperature drops to below 50°C, the unit will

automatically switch off. If users want to turn off the LED

immediately, just pull out the plug directly. When the plug

is pulled out, the residual heat warning function cannot be

run.



10

BlueSpin (Hotplate) Magnetic Stirrer

7. Stirring

The function “stirring” of LED digital model is switched on

or off via pushing on/off speed control knob. The speed

range of 100 to 1500 rpm and in steps of 10 rpm.

The function “stirring” of classic model is switched on or

off via rotating speed control knob. The speed range of 0 to

1500 rpm.

8. Faults

•Instruments can’t be power ON

‐Check whether the power line is unplugged

‐Check whether the fuse is broken or loose

•Fault in power on self test

-Switch OFF the unit, then switch ON and reset

the instruments to factory default setting.

•Stir speed cannot reach set point

-Excessive medium viscosity may cause abnormal

speed reduction of the motor

•Unit cannot be powered off when switched off.

-Check if the residual heat warning function is still

ON and hotplate temperature is above 50℃(the

LED screen still work and “Hot” flash).

If these faults are not resolved, please contact

manufacturer/supplier.



11

BlueSpin (Hotplate) Magnetic Stirrer

9. Maintenance and Cleaning

•Proper maintenance can keep instruments working

properly and lengthen its lifetime.

•Do not spray cleanser into the instrument when

cleaning.

•Unplug the power line when cleaning.

•Only use recommended cleansers:

Dyes Isopropyl alcohol

Construction materials Water containing tenside

/ Isopropyl alcohol

Cosmetics Water containing tenside

/ Isopropyl alcohol

Foodstuffs Water containing tenside

Fuels Water containing tenside

•Before using other method for cleaning or

decontamination, the user must ascertain with the

manufacturer that this method will not harm the

instrument. Wear the proper protective gloves during

cleaning of the instrument.

Note:

•Electronic device can not clean with

cleanser.

•If you require maintenance service, must be

cleaned the instrument in advance to avoid

pollution of hazardous substances, and to

send back into original packing.

•If the instrument will not use for a long time,

please switch off and place in a dry, clean,

room temperature and stable location.

10.Associated Standards and

Regulations

Construction in accordance with the following safety

standards:

EN 61010-1

UL 3101-1

CAN/CSA C22.2(1010-1)

EN 61010-2-10

Construction in accordance with the following EMC

standards:

EN 61326-1

Associated EU guidelines:

EMC-guidelines: 89/336/EWG

Instrument guidelines: 73/023/EWG



12

BlueSpin (Hotplate) Magnetic Stirrer

Changes or modifications not expressly approved by the

party responsible for compliance could void the user's

authority to operate the equipment.

NOTE: This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful

interference when the equipment is operated in a

commercial environment. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may

cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be

required to correct the interference at his own expense.

11.Specifications

Items Specifications

Digital model Classic

model

Voltage [VAC] *100~120/200~240

100~240

Frequency [Hz] 50/60 50/60

Power [W] *515/15 10

Stirring point position

quantity 1 1

Max. stirring quantity

(H2O) [l] 3 3

Max. magnetic bar [L×Ø,

mm] 50 50

Motor type DC motor

Max. power input of

motor [W] 5 5

Max. power output of

motor [W] 3 3

Speed range [rpm] 100 – 1500,

increment:10 0 – 1500

Rotary speed display LED Scale



13

BlueSpin (Hotplate) Magnetic Stirrer

Items Specifications

Digital model Classic

model

Plate material *Ceramic coated/Plastic

Dimensions of

workplate (mm) φ135 φ135

*Heating power [W] 500 -

*Temperature range [°C] RT-280,

increment:1 -

*Temperature display

[°C] LED -

*Temperature display

accuracy [°C] 1 -

*The safe temperature

of hotplate [℃] 320 -

*Temperature sensor in

medium PT1000 -

*Control accuracy of

heating temperature

with temperature sensor

[℃]

±0.5 -

*Residual heat warning 50℃-

Dimensions (mm) *220×160×95

Items Specifications

Digital model Classic

model

220×160×75

Weight [kg] *1.4/0.7 0.7

Permitted ambient

temperature [°C] 5－40

Permitted relative

humidity 80%

Protection class acc. to

DIN 60529 *IP21/IP42

*Hotplate model

Table 5



14

BlueSpin (Hotplate) Magnetic Stirrer

12.Ordering Information

Cat No. Descriptions

861431019999
