MDT5N25 – TouchFree® Ice Machine / Dispenser
MDT5N25 – TouchFree® Ice Machine / Dispenser
Scotsman Ice Systems
775 Corporate Woods Parkway
Vernon Hills, IL 60061
1-800-SCOTSMAN
Fax: [phone]
E-mail: customer[email protected]
www.scotsman-ice.com
Features
Nugget Ice Machine / Dispenser
Warranty
• 2 years parts and labor on all components.
• 5 years parts on compressor.
Warranty valid in North, South & Central America.
Contact factory for warranty in other regions.
24 Hour Volume Production
Nugget Ice
Makes and dispenses soft, chewable nugget ice.
Sleek, european design with attractive rounded corners and informative instruction
labels.
Up to 25% less fan noise allows installation of the unit in the quietest hallways.
Improved dispensing with easier access and room for most containers.
TouchFree® actuation provides convenient one-hand operations and eliminates the
risk of cross contamination.
Flexible utility location.
The Original Chewable Ice™!
Easy to chew, cools drinks rapidly.
70˚F/21˚C Air 90˚F/32˚C
50˚F/10˚C Water 70˚F/21˚C
lb/kg lb/kg
523/237 409/186
Air Cooled
Sanitary One Hand Operation
Easily fills various sizes and
types of containers.
70˚F/21˚C Air 90˚F/32˚C
50˚F/10˚C Water 70˚F/21˚C
lb/kg lb/kg
525/239 455/207
Water Cooled

MDT5N25 – TouchFree® Ice Machine / Dispenser
Scotsman Ice Systems
775 Corporate Woods Parkway
Vernon Hills, IL 60061
1-800-SCOTSMAN
Fax: [phone]
E-mail: customer[email protected]
www.scotsman-ice.com
© 2010 Scotsman Ice Systems. SIS-SS-DIS-MDT5N25 10-10
®
Specifications
All Models
208-230/60/1 2 2.6 15
Operating Requirements
MaximumMinimum
Air Temperatures
Water Temperatures
Remote Cond. Temps
Water Pressures
Electrical Voltage
50°F (10°C)
40°F (4.4°C)
-20°F (-29°C)
20 PSIG (1.4 bar)
-5%
100°F (38°C)
100°F (38°C)
120°F (49°C)
120 PSIG (5.5 bar)
+10%
Dimensions (W x D x H):
Unit:
26” x 22.5” x 41”
(66 x 57.2 x 104 cm)
Shipping Carton:
30” x 24” x 46”
(76.2 x 61 x 116.8 cm)
Shipping Weight:
260 lb / 118 kg
Accessories
Model Number Description
* Scotsman recommends all ice machines have water filtration. See Scotsman Sanitation Matrix for details.
Installation Note: Allow 6” space at left, back and right side for ventilation and utility connections.
Specifications and design are subject to change without notice.
All units are stainless steel. Not designed for outdoor installations.
Refrigerant: R-4044a
DMS21S-B
KWB3
KSP5
KPC-MDT
KTPS-MDT
Machine Stand for MDT5N25, MDT5N40
Wall Mounting Kit for MDT5N25, MDT5N40
Splash Panel Kit for MDT5N25, MDT5N40
Portion Control Kit for MDT3, MDT4, MDT5 & MDT6
Tamper Proof Screw Kit (including tool) to convert 1 MDT Dispenser
Model Number
Condenser
Unit
Storage
Capacity
lb/kg
Basic Electrical
Volts/Hz/
Phase
Max. Fuse Size
or HACR Circuit
Breaker (amps)
Circuit
Wires
Min. Circuit
Ampacity
Energy Consumption
kWh/100 lb (45.4 kg)
90˚F(32˚C)/70˚F(21˚C)
Potable
90˚F(32˚C)/
70˚F(21˚C)
Condenser
90˚F(32˚C)/
70˚F(21˚C)
MDT5N25AS-1 Air 26/12 115/60/1 25 2 19.3 5.4 12/45.5 -
MDT5N25WS-1 Water 26/12 115/60/1 20 2 17.8 4.0 12/45.5 97.0/367.8
Water Usage
Gallons/100 lb (liters/45.4 kg)
AIR OUT
AIR IN
MINIMUM CLEARANCE
BOTH SIDES
MIN
MIN
.19”
.48 cm
8.50”
21.59 cm
10.00”
25.40 cm
6.43”
16.33 cm
5.12”
13.00 cm
3.12”
7.92 cm
1.12”
2.84 cm
ELEC. CONN.
4.50”
11.43 cm
3.54”
8.99 cm
3/8” FLARE
.96 cm
POTABLE WATER IN
3/8” FPT
.96 cm
COND. WATER IN
(WATER COOLED)
1/2” FPT
1.27 cm
COND. DRAIN
(WATER COOLED)
3/4” FPT DRAIN
1.90 cm
13.73”
34.92 cm
41.00”
104.14 cm
20.50”
52.07 cm
22.50”
57.15 cm
8.75”
22.22 cm
15.90”
40.38 cm
4.00”
10.16 cm
6.00”
15.24 cm 6.00”
15.24 cm
26.00”
66.04 cm
R
