Scotsman Prodigy Plus E Series User manual

Installation and User Manual for Eclipse Cuber
Prodigy Plus E Series model
EH222 Ewith ECC Condensing Unit

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2018
Page 2
Introduction:
This manual covers the assembly, installation, start
up, operation and maintenance of the 800 and 1000
remote low side cuber systems.
Contents
Conguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 3
Specications and Location Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 4
Cabinet Drawings, Ice Making Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 5
Cabinet Drawings, Condensing Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 6
Pre-Installation Details. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 7
Create the System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 8
Completed System Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 9
Place Remote System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 10
Tubing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 11
Place Ice Making Head . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 12
Drain Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 13
Water Supply: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 14
Electrical: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 15
Connect Refrigeration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 16
Complete the Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 17
Reference for Start Up: Controller Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 18
Initial Start Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 19
Ice Thickness and Water Purge Adjustment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 20
Adjustable Ice Level Control. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 21
Cleaning, Sanitation and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 22
Operational Characteristics 800 lb system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24
Operational Characteristics 1000 lb system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 24
What to do before calling for service: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 25
EH222 Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 26
EH222 Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 27
ECC Three Phase Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 28
ECC Three Phase Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 29
ECC Single Phase Schematic Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 30
ECC Single Phase Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 31

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 3
Conguration
A remote low side cuber system includes two sub
systems: an ice making head and a remote air cooled
condensing unit. This manual covers the EH222 head
and the condensing units that go with it.
The ice making heads are designed for use indoors
in a controlled environment. The remote condensing
units are designed to operate outdoors. Each sub-
system has limits for power, water and temperature.
Operational Limitations:
Minimum Maximum
Air Temp (at head) 50oF 100oF.
Air Temp (CU) -20oF. 120oF.
Water Temp 40oF. 100oF.
Water Pressure 20 psi 80 psi
Water Conductivity 10 microSiemens/cm any
Voltage (at head) 104 126
Voltage (CU) 198 253
CU= Condensing Unit
Do Not operate the machine in conditions beyond
these limitations. Doing so will void the warranty.
Scotsman ice systems are designed and
manufactured with the highest regard for safety and
performance. They meet or exceed common agency
standards.
Scotsman assumes no liability of responsibility of
any kind for products manufactured by Scotsman
that have been altered in any way, including the use
of any part and/or other components not specically
approved by Scotsman.
Scotsman reserves the right to make design changes
and/or improvements at any time. Specications and
design are subject to change without notice.
Warranty
Refer to the warranty coverage in effect when the
equipment was sold. Warranty statements are
included with each product.
Systems:
Ice making heads and condensing units have their
own model and serial numbers. They must be
combined to create a remote cuber low side system.
Notes: Voltage Codes are at the end of the model
number. Codes read Voltage/Hertz/Phase. Those
related to these products include:
-1 = 115/60/1
-3 = 208-230/60/3
-32 = 208-230/60/1
System Information
Tubing kits are required to connect the head to the
condensing unit.
Interconnecting 24 volt control wire ships with the
condensing unit.
System Size Condensing Unit (CU) Ice Making Head
Model Electrical (volts/Hz/phase Model Electrical (volts/Hz/phase)
800 ECC0800-32E 208-230/60/1 EH222SL-1E 115/60/1
800 ECC0800-3E 208-230/60/3 same same
1000 ECC1410-32E 208-230/60/1 same same
1000 ECC1410-3E 208-230/60/3 same same

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 4
Model Electrical
volts/Hz/phase
Minimum
Circuit
Ampacity
Maximum
Fuse Size
System Charge,
oz of R-404A
Cabinet Size*
w” x d” x h”
Unit
Weight (lb)
EH222SL-1E 115/60/1 1.13 15 shipped w/none 22 x 16.5 x 29 ~100
ECC0800-3E 208-230/60/3 10.6 15 192 32 x 39 x 39.75 ~300
ECC1410-32E 208-230/60/1 15.8 30 248 32 x 39 x 39.75 ~310
ECC1410-3E 208-230/60/3 11.6 20 248 32 x 39 x 39.75 ~310
* See cabinet drawings for detailed dimensions.
Location Limitations
Maximum Distance between Head and Condensing
Unit: Limited to the length of the longest available
single tubing kit, 75 feet.
Maximum Condensing Unit Elevation over Ice Making
Head: 35 feet.
Note: Elevations greater than 20 feet require
installation of a suction line trap at the 20 foot mark.
Maximum Ice Making Head Elevation over
Condensing Unit: 15 feet.
Line Routing:
• Allowed: One rise after a drop.
• Allowed: One drop after a rise.
• Not Allowed: More than one rise after a drop
• Not Allowed: More than one drop after a rise.
Model Number Locations
Ice Making Head
The dataplate on the back of the ice machine contains
the model number, serial number and electrical data.
A second plate, located behind the front panel at
the lower right front, also lists the model and serial
numbers.
Condensing unit
The dataplate on the end contains the model number,
serial number, electrical data and system refrigerant
charge.
A second plate, located behind the side panel on the
deck, also lists the model number, serial number and
refrigerant charge.
Specications and Location Information

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 5
Cabinet Drawings, Ice Making Head
22.00
558.80
22.70
576.68
29.00
736.60
TOP VIEW
REAR VIEW
6.00
152.40
3.25
82.55
3.19
80.97 10.75
MINIMUM BIN
TOP OPENING
273.05
19.00
482.60
8.31
211.09
46.24
1.82
82.55
3.25
74.72
2.94
260.80
10.27
A
LINE SET, POTABLE WATER INLET 3/8",
120V AC, AND INTERFACE CABLE
SEE DETAIL "A"
ULTRA SONIC
BIN LEVEL
SENSOR
ICE DROP AREA
15.00
381
16.41
416.92
16.72
424.70
DRAIN 3/4" PVC FEMALE REAR, LEFT AND RIGHT SIDE ACCESS
LEFT SIDE VIEW
24
.95
42.80
1.69
79.38
3.13
115.95
4.57
68.20
2.69
131.70
5.19
24.89
.98
34.04
1.34
67.56
2.66
34.04
1.34
DETAIL A
INTERFACE CABLE
ACCESS HOLE
3/4" SUCTION LINE
POTABLE WATER INLET 3/8"
1/2" COOL VAPOR LINE
3/8" LIQUID LINE
ELECTRICAL CORD
ACCESS HOLE
EH222
ICE HEAD

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 6
Cabinet Drawings, Condensing Unit
992.81
39.09
814.22
32.06
32.05
1.26
TYP.
TOP VIEW
1009.65
39.75
FRONT VIEW
83.67
3.29
74.12
2.92
163.02
6.42
248.87
9.80 491.69
19.36
63.50
2.50
887.73
34.95
750.06
29.53
330.86
13.03
SIDE VIEW
LINE SET AND ELECTRICAL ATTACHMENT SIDE
1/2" COOL VAPOR LINE
3/8" LIQUID LINE
3/4" SUCTION LINE
.88" ELECTRICAL INLET
INTERFACE HARNESS
ACCESS HOLE

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 7
Pre-Installation Details
Note: The ice making section cannot be stacked
vertically.
Accessories such as bin adapters and tubing kits are
required to complete the installation.
Dispenser Adapter Kits:
• Cornelius ABS: KBTABS ED150: KBT40
• Scotsman ID150: KBT40
• Scotsman ID200 or ID250: KBT41
Bin Adapter Kits:
• B530P or B530S: KBT32
• B948S: KBT34
Tubing Kits:
• 20 foot: 3BRTE20-EH
• 35 foot: 3BRTE35-EH
• 50 foot: 3BRTE50-EH
• 75 foot: 3BRTE75-EH
Note: Line set may have quick connects. The
condensing section may have quick connects. See
refrigeration system detailed instructions connection
details.
Items required for installation:
• Ice making head
• Condensing unit (includes interconnecting control
system wire)
• Tubing kit. 20’, 35', 50’ or 75’ triple line set (liquid,
vapor and suction)
• Bin or dispenser adapter
Special Considerations
The ice making section’s footprint is 22” wide by 16.5”
deep. The refrigeration connections can be routed up
or to the back. The drain may be routed out the back
at any position left to right; it may also be routed to
either side.
Water
Pure water does not exist. All water supplies contain
some amounts of impurities, although potable water
is, by denition, t for human consumption. Because
the contents of the water to an ice machine directly
impact its performance, consideration should be given
to improving the water’s quality.
There are two ways water can contain impurities:
in suspension or in solution. Suspended solids can
be ltered out of the water. In solution or dissolved
solids must be diluted or treated. Water lters are
recommended to remove the suspended solids.
Some lters or lter systems have treatment
chemicals in them for treating the suspended solids.
This ice machine has an adjustment for the amount
of water rinsed or purged. Water use adjustments
are customer convenience adjustments; they are not
factory defects and are not covered by warranty.

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 8
Create the System
Plan the installation. The system consists of three
parts: the ice making head, the condensing unit and
the interconnecting tubing. Of these, the biggest
variable is the interconnecting tubing.
Tubing: The tubing consists of three insulated and
sealed soft copper tubes. One tube, the liquid line,
is 3/8” OD. The vapor tube is ½” OD and the suction
tube is ¾” OD. A site inspection will determine what
length of tubing is required for the installation.
In 2013 Scotsman made a change to the Eclipse
tubing kits:
• Prior Tubing Kits: They each contain a small
holding charge of R-404A and have quick
connects at the ends.
• Current Tubing Kits: The do not contain any
refrigerant and do not have quick connects.
Either type can be used to connect the head and
condensing unit.
Check condensing unit for quick connects. If none,
recover refrigerant from tubing and cut the quick
connects off.
Excess tubing must be shortened at the job site.
Installations with greater than 20 feet of vertical lift
between ice machine and the compressor require
a suction line trap. The suction line requires careful
handling and large radius bends to prevent kinking.
Roof mounting: Some installations will require the use
of a hoist to lift the components to the roof.
Pad mounting: The condensing unit may be located
below the ice making section, up to a limit of 15 feet.
Distance from unit: Limited to the length of the
available tubing.
Elevation: Condensing unit limited to 35 feet above
the ice making section.
Condensing Unit: Electrical power must be supplied to
the condensing unit, it will be separate from the head.
Ice making section location and attachment: The
unique footprint of the EH222 requires adapter kits to
allow placement on dispensers and bins.
The remote tubing connections are at the top of the
machine, and connections should not be made until
the machine is nearly in its nal installed position.
The 115/60 Hz ice making section is cord connected
and requires an outlet within 6 feet of the installation.
Interconnecting wires: An interconnecting wire
harness is included with the condensing unit. One end
plugs into the ice making section and the other into
the condensing unit. The system will NOT operate
without this harness.
Exposed tubing: Minimize the amount of tubing
exposed outdoors.
Lineset Ice machine head and condensing
unit both have stubs
Ice machine head has stubs, condensing
unit has quick connects.
Has Quick Connect Fittings Cut quick connects off both ends Cut off quick connects at condensing unit
end only
Does NOT have Quick
Connect Fittings
Use as supplied Use as is at head, obtain kit KTE6-EH,
use 3 of 6 ttings on condensing unit end.

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 9
Completed System Example

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 10
Place Remote System
Roof preparation
Most installations of this system will place the
condensing unit on the roof of a building. The roof
must be physically able to accept the load of the
equipment and the roong material must be prepared
to prevent water leaks.
Follow local codes for the placement and attachment
of the equipment.
Location
The condensing unit requires unobstructed air ow
to operate efciently. A four foot space between
each intake side and a wall or other cabinet is
recommended.
Do not place where it will pick up hot discharged air
from an air conditioner or other refrigeration system
condensing unit.
Space must also be reserved for service on the
condensing unit.
Roof Piercing:
The roof (or wall) must have a passage large enough
for the three refrigeration tubes and the control wire
to pass through. The minimum recommended size is
4” ID. In most areas the power supply may also pass
through the same passage. If there isn’t a passage
one must be created. In most cases this must be done
by a licensed and bonded roofer in order to maintain
the roof’s integrity.
Roof Pipe Curb or Pitch Pocket:
To avoid potential kinking of the refrigeration tubing,
avoid small, tight radius types of covers on pitch
pockets.
Suggestions:
In most cases a mechanical lift, boom truck or crane
will be required to hoist the condensing unit.
Mount unit to roof rails or curbs and secure with lag
screws or similar eld supplied fasteners.
Orient the assembled unit so that the unit’s mounts
are parallel to the pitch of the roof to allow water to
drain freely.
Do NOT place the unit directly onto roof rock.
In all cases the line set will need to be shortened to t.
Do NOT leave excess line set exposed outdoors,
especially on a roof.
Refrigerant Recovery and System Evacuation Notice
In the event the refrigerant must be recovered from this system and the system evacuated, recover and
evacuate from the three ball valve access valves with the ball valves open.

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 11
Lower Light and Switch Panel
This user accessible panel provides important
operational information and duplicates the lights
and switches on the controller. It also allows
access to the On and Off buttons that operate
the ice machine.
Sometimes access to the switches should be limited
to prevent unauthorized operation. For that
purpose a xed panel is shipped in the hardware
package. The xed panel cannot be opened.
To install the xed panel:
1. Remove the front panel and remove the bezel.
2. Spread the bezel frame open and remove
original door, insert xed panel into bezel. Be
sure it is in the closed position.
3. Return bezel to panel and install panel on unit.
Open door to access
On and Off switch
buttons.
Lower Light and Switch Panel

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 12
Place Ice Making Head
Remove from carton.
Place adapter kit onto bin or dispenser top. If adapter
does NOT have gasket tape install tape such as
Scotsman part number 19-0503-04. The adapter to
ice head base MUST be sealed with gasket tape or
food grade sealant.
Attachment
ABS (Automatic Beverage Dispenser) in drive up
installations: Route refrigerant tubing and install drain
and water supply tubing onto ice making section
before placing unit on the dispenser.
Place EH222 onto adapter, do not secure at this time.
Uncoil power cord and route to the power supply.
Plug interconnecting control wire to the wire harness
in the ice making head.
Located at the top panel:
• Refrigeration connections.
• Interconnecting control wire.
• Access port for water supply.
• Power cord.
The drain may be routed to the left or right, allowing
the ice making section to be placed with its back tight
against a wall.
Water and Drain
The ice maker requires an adequate potable water
supply and a gravity drain.
Determine how the drain will be connected to the ice
making section.
• If access is available behind the unit, route the
drain in from the back.
• If the unit is to be ush mounted to the back of
the dispenser and tight against the wall, route the
drain out either the left or right.
In some tight situations it will be necessary to
assemble the ice making section to the dispenser or
bin and install the water and drain connections before
placing the system in its installed position. A loop of
water supply tubing will aid movement of the system.
In other tight situations the unit should have its water
and drain tubing connected and stubbed out before
placing on the dispenser or bin.
The drain tting is adaptable to drain connections to
the left, right and back.
The unit is shipped ready to drain right. The drain
tting elbow with PVC adapter can be rotated to drain
right, left or back.
Drain Fitting
EH222 Back View

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 13
Drain Connections
Right Draining:
1. Connect ¾” PVC to the female PVC tting.
If copper is required by code, remove the PVC
connector and install a ¾” FPT female copper tting
onto the ¾” NPT male tting. Do all soldering before
connecting to the male tting.
2. In tight locations do the next step after the unit is
placed on the dispenser or bin.
3. Connect rigid drain tubing to the reservoir drain
tube. Route the drain either out the back, under the
unit (through the notch in the base) to the left side
or to the right side. A vent is built into the unit, so no
external vent is required.
Run the drain tubing to the building drain. Do not
“Tee” into any other drain, including the bin or
dispenser drain.
Left Draining: Rotate elbow to the other direction.
Connect ¾” PVC to the PVC tting.
Back Draining: Rotate elbow to face the back or
connect PVC directly into the ¾” FPT drain tting.
No external drain vent is required, venting is internally
provided for.
Note: External drain tubing must be supported to
insure that it does not move and kink the internal
rubber tube.

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 14
Water Supply:
A 3/8" are nut on tubing is located at the top panel,
near the refrigeration tubing.
Inside the hardware bag, inside the cabinet, a
3/8" inch double male are adapter (are union) is
supplied. Use the supplied adapter to make a 3/8"
male are tting for the water inlet.
Connect a cold, potable water supply to the 3/8” water
inlet tting installed above. Use 3/8" OD copper or
other comparable sized tubing for the water supply.
Note: This is an NSF listed ice machine and contains
provisions for back-ow prevention in its design. No
external back ow preventer is required.
Water Supply Connection
Communication Cable
Suction Line Insulation

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 15
Electrical:
Condensing Unit
Route interconnecting control wire through proper
hole end of condensing unit and plug into the
connection on the control box.
Route power conduit (liquid tight) and wires to the
junction box of the ECC unit. Secure with the proper
type of connector.
Note: The power supply wires must be the correct
size and type per the National Electric Code.
Locate the nameplate on the ECC unit for the Voltage,
Phase, Minimum Circuit Ampacity and Maximum Fuse
Size. Either fuses or HACR type circuit breakers may
be used.
Follow all Local, State and National Codes.
Three Phase Notice: Check voltage between legs
at contactor. If there is a “wild leg” in the three phase
power supply move supply wires at the contactor so
the higher voltage is on L3, which connects to the
compressor motor only.
Head
Plug head’s power cord into a nearby 115 volt
electrical outlet.
Communication Cable
Connect Cable Here
Electrical Junction Box
Dataplate Location

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2018
Page 16
Connect Refrigeration
Requires brazing, steps must be performed by an
EPA certied type II or higher technician.
At Head:
1. Remove protective plugs from all three
connections and vent the nitrogen from the ice
machine.
2. Route the each of the three tubes to its
connection.
3. Remove the top panel and attach a refrigeration
hose with depressor to the 1/2” vapor line access
valve so the valve is OPEN. This is a vent for
nitrogen purging.
4. Remove screws holding tubing bracket to back
panel and lower it out of the way for brazing.
5. Clean tubing ends and position into couplings.
At Condensing Unit
1. Conrm connection
valves are fully
closed.
2. Remove protective
plugs from all three
connections.
3. Remove caps from access valve connections.
4. Remove cores from access valves.
5. Connect refrigeration hoses to access valves.
6. Connect dry nitrogen source to liquid line
connection and vapor line connection.
7. Shorten tubing to correct length, clean ends and
insert them into valve ends and couplings.
Note: Be sure tube and stubs are round, dress with
swage tool if needed.
8. Add heat sink material to ball valve body.
9. Open nitrogen and ow 1 psi nitrogen into liquid
line and vapor line tubes and braze the liquid
line, vapor line and suction line tubes to the valve
stubs.
At Head
1. With nitrogen owing from condensing unit, braze
the liquid, vapor and suction line connections.
2. Remove refrigeration hose from head. Be sure
valve cap is on tight.
3. Pull tubing bracket up and secure to back panel.
At Condensing Unit
1. Remove nitrogen source.
2. Return valve cores to access valves.
3. Connect vacuum pump to all three access valves
(use two manifolds or two extra hoses and a tee)
and evacuate the tubing and head to at least a
300 micron level.
4. Remove vacuum pump and add R-404A vapor to
all three tubes to provide a positive pressure.
5. Leak check the braze connections and repair any
leaks.
6. Open all three valves to full open.
Note: The full refrigerant charge is contained in the
receiver of the ice machine.
Valves Closed
Refrigeration Connections
Liquid
Vapor
Suction

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 17
Complete the Installation
After the utilities and refrigeration connections have
been made, secure the unit to the dispenser or bin
top.
Secure ice making section to dispenser or bin
adapter.
Use strap/clips to secure unit:
• When used with Cornelius ABS adapter, install
clip on the side of the cabinet. Clip under edge of
adapter and secure to ice making section using
the screws provided in the hardware bag.
Note: If one side will be against a wall, do not use a
clip on that side. One clip is sufcient to secure the
unit.
• For use on bin adapter, use clip (as a strap) on
back.
If the ice maker & bin or dispenser is not yet in its nal
position gently move it there.
Note: The refrigerant lines above the machine must
be able to move freely while the machine is being
moved into position.
Final Check List Before Initial Start Up
1. Conrm that the ice making section is installed
indoors in a controlled environment.
2. Conrm that all packing materials have been
removed from all products.
3. Conrm that the ice making section is level.
4. Conrm that all the refrigerant connections have
been made and checked for leaks.
5. Conrm that the proper power supply has been
turned on to the condensing unit.
6. Conrm that cold, potable water has been supplied
to the ice making section and checked for leaks.
7. Conrm that the water supply is adequate.
8. Conrm that there is adequate water pressure and
that any water lters have been checked to conrm
that the cartridges do not need changing.
9. Conrm that the proper size drain tubing has been
installed and properly routed.
10. Conrm that the ice making section has been
connected to the proper power supply.
11. Conrm that the interconnecting wire has been
routed and connected between the ice making section
and the condensing unit.
Clip

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 18
Reference for Start Up: Controller Operation
The controller has four indicator lights, a code display,
four push buttons, and eleven component indicator
lights.
Indicator Lights
• Power - on when there is power to the controller
• Status - on in ice making mode
• Water - on and blinking when there is no water
• De-scale & Sanitize - on when it is time to clean
the machine
Code Display
• Displays status and diagnostic codes
Push Buttons
• On
• Off
• Manual Harvest
• Clean
Component indicator lights
• Fan - not used on this model
• Water Pump - on when the pump is
• Purge Valve - on when the purge valve is
• Water Solenoid - on when the inlet water solenoid
valve is
• Hot Gas - on when the vapor inlet valve and
harvest assist solenoid have power
• Compressor - on when the compressor contactor
is energized
• Ready to Harvest - on when the ice thickness
sensor has water touching it
• Sump Empty - on when there is no water touching
the mid-length probe
• Sump Full - on when water is touching the
shortest probe
• SW2 - on when the curtain is open
• SW1 - on when the curtain is open
Cycle Denitions:
Freeze: The refrigeration system is operating to
remove heat from the evaporators. The compressor,
fan motor, and water pump are on.
Harvest: The refrigeration system and water system
are operating to harvest the ice and rinse the
reservoir. The compressor is on for the full cycle, the
pump is on until the purge valve closes.
The inlet water valve opens and rells the reservoir.
The vapor and condenser by-pass valves are open
during the entire harvest cycle, as is the harvest assist
mechanism.

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 19
Initial Start Up
Pre Start
A soak-out period of four hours is optional for this
system. If desired, powering the compressor unit
for four hours prior to start up allows the crankcase
heater to warm up the oil in the compressor.
Start Up
1. Connect power to the condensing unit and move
its toggle switch to Run or On.
2. Open the water supply valve.
3. Switch on the electrical power to the EH222.
Observe that some of the lower control’s indicator
lights glow and its display shows O.
4. Locate lower light and control panel.
5. Push and release the ON button on the lower
panel. The code display will begin to blink F.
The purge valve opens, the water pump starts and the
inlet water valve opens to add water to the reservoir.
In a few seconds the purge valve closes and the
water pump stops. Water will ow into the machine
until the reservoir is full. The vapor valve and harvest
assist device will activate, then the compressor and
water pump will start. Fwill be on steady.
Note: Because the condensing unit is external to the
ice making section, no visible signs of operation will
be noticeable until the water begins to cool and frost
forms on the evaporator tubing.
6. Go to the condensing unit and conrm that the
compressor and fan motor are operating. Warm
air will be discharged from the condenser.
Observe the Ready for Harvest indicator light. It may
blink early in the cycle, that is normal. The control will
ignore that signal for the rst 6 minutes of freeze.
During the Freeze cycle move the curtain and observe
that either the SW1 or SW2 light on the control
board blinks On when the curtain moves away from
the evaporator and Off when returned to its normal
position.
Note: Moving the curtain during the Freeze cycle has
no affect on control function, but will cause water to
ow into the cube chute.
When enough ice has frozen, the Ready for Harvest
indicator light will be on steady. After it’s been on
steady for a few seconds Harvest will begin.
The display shows an H. The vapor valve in the
EH222 opens, and the harvest assist mechanism
activates. In the CU the condenser bypass valve
opens and the receiver inlet valve closes. In the
EH222, the purge valve opens to drain some water,
when it does the inlet water valve opens to rell the
reservoir. After a few seconds the purge valve closes
but the inlet water valve continues to ll the reservoir.
Harvest continues until the ice is released as a unit
and forces the curtain to open.
When the curtain opens it signals the controller that
harvest is complete, and it returns the unit to a freeze
cycle.
7. Check the ice harvested for proper bridge
thickness. The ice bridge is factory set at 1/8 inch.
If needed, adjust bridge thickness. Do NOT make
it too thin.
8. Instruct the user in the operation of the machine
and its maintenance requirements.
9. Fill out and mail the warranty registration form or
register it on line at www.scotsman-ice.com.

EH222 E and Condensing Unit
Remote Low Side Cuber User Manual
June 2017
Page 20
Ice Thickness and Water Purge Adjustment
Bridge Thickness - For the Service Tech Only
1. Push and hold Off till the machine stops.
2. Remove evaporator cover.
3. Remove curtain.
4. Use a hex wrench and rotate the bridge thickness
adjustment screw in 1/16 turn increments CW to
increase bridge thickness.
5. Rotate CCW to decrease bridge thickness.
Caution: Do not make the bridge too thin or the
machine will not harvest properly. Bridge thickness
adjustments are not covered by warranty.
6. Return curtain and evaporator cover to their
normal positions.
7. Push and release the On button. Check next
harvest of ice. Repeat steps 1-6 if needed.
Water Purge Setting
The water purge is factory set to the automatic
position, suitable for most water conditions. The
setting can be changed to one of 5 manual settings or
left on automatic.
Setting Water Type
1 Minimum - RO water or equivalent
2 Moderate - Low TDS, non RO
3 Standard - Use with typical water
4 Heavy - High TDS
5 Maximum - Very high TDS
A Automatic - Factory setting
To set:
1. Switch the machine OFF by holding the Off button
in until a number or the letter A shows on the
display.
2. Press and release the On button repeatedly until
the number on the display corresponds to the
desired setting.
3. Press and release the Off switch again to return to
the normal control state.
1/8 to 3/16”
Bridge
Adjustment
Screw
Bridge Thickness Adjustment Mechanism
ice Bridge Thickness
