SCOTT ADDICT DISC/GRAVEL/CX
USER MANUAL 2016

WWW.SCOTT-SPORTS.COM
ENGLISHENGLISH
Geometry/Technical Data Addict Disc/Gravel/CX . . . . . . . . . . . . . . 04
General Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05
Headset Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
Seat Post/Clamp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
BB Standards/FD Mounting Details . . . . . . . . . . . . . . . . . . . . . . . .07
RD Hanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
Rear Brake Mount . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
Axis Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
•CONTENTS
The Addict Disc/Gravel/CX should be adjusted exactly to the
current rider for reaching maximum safety and fun while riding.
All adjustments should be done at your local SCOTT dealer or
following this manual’s instructions.
In order to avoid technical problems or any harm please contact
in case of doubts your authorized SCOTT dealer.
03 |
2016 BIKE USER MANUAL | ADDICT DISC/GRAVEL/CXADDICT DISC/GRAVEL/CX | 2016 BIKE USER MANUAL
| 02

ADDICT CX
XS /49 S/52 M/54 L/56 XL/58
AHEAD TUBE ANGLE 70.0 ° 70.0 ° 71.0 ° 71.0 ° 71.0 °
BHEAD TUBE LENGTH 95.0 mm 3.7 in 120.0 mm 4.7 in 140.0 mm 5.5 in 160.0 mm 6.3 in 180.0 mm 7.1 in
CTOP TUBE HORIZONTAL 505.0 mm 19.9 in 525.0 mm 20.7 in 545.0 mm 21.5 in 568.0 mm 22.4 in 590.0 mm 23.2 in
DSTANDOVER HEIGHT 749 . 8 mm 29.5 in 775.7 mm 30.5 in 796.2 mm 31.3 in 814.1 mm 32.1 in 832.0 mm 32.8 in
EBB OFFSET -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in
FBB HEIGHT 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in
GWHEEL BASE 984.0 mm 38.7 in 1,002.0 mm 39.4 in 1,017.0 m m 40.0 in 1,043.0 mm 41.1 in 1,056.0 mm 41.6 in
HBB CENTER TO TOPTUBE CENTER 431.5 mm 17.0 in 462.7 mm 18.2 in 483.0 mm 19.0 in 503. 2 mm 19.8 in 523.3 mm 20.6 in
IBB CENTER TO TOP OF SEATTUBE 490.0 mm 19.3 in 520.0 mm 20.5 in 540.0 mm 21.3 in 560.0 mm 22.0 in 580.0 mm 22.8 in
JSEAT ANGL E 74.5 ° 74.0 ° 73.5 ° 73.0 ° 73.0 °
KCHAIN S TAY 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in
LREACH 360.0 mm 14.2 in 369.0 mm 14.5 in 378.0 mm 14.9 in 390.0 mm 15.4 in 405.0 mm 15.9 in
MSTAC K 521.8 mm 20.5 in 545.5 mm 21.5 in 564.4 mm 22.2 in 583.3 mm 23.0 in 602.2 mm 23.7 in
NSTEM LENGTH 90.0 mm 3.5 in 100.0 mm 3.9 in 110.0 mm 4.3 in 120.0 mm 4.7 in 120.0 mm 4.7 in
0TRAIL
ADDICT GRAVEL
XS /49 S/52 M/54 L/56 XL/58
AHEAD TUBE ANGLE 70.0 ° 70.0 ° 71.0 ° 71.0 ° 71.0 °
BHEAD TUBE LENGTH 95.0 mm 3.7 in 120.0 mm 4.7 in 140.0 mm 5.5 in 160.0 mm 6.3 in 180.0 mm 7.1 i n
CTOP TUBE HORIZONTAL 505.0 mm 19.9 in 525.0 mm 20.7 in 545.0 mm 21.5 in 568.0 mm 22.4 in 590.0 mm 23.2 in
DSTANDOVER HEIGHT 749 . 8 mm 29.5 in 775.7 mm 30.5 in 796.2 mm 31.3 in 814.1 mm 32.1 in 832.0 mm 32.8 in
EBB OFFSET -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in -68.0 mm -2.7 in
FBB HEIGHT 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in 281.0 mm 11.1 in
GWHEEL BASE 984.0 mm 38.7 in 1,002.0 mm 39.4 in 1,0 17.0 mm 40.0 in 1,043.0 mm 41.1 in 1,056.0 mm 41.6 in
HBB CENTER TO TOPTUBE CENTER 431.5 mm 17.0 in 462.7 mm 18.2 in 483.0 mm 19.0 in 503. 2 mm 19.8 in 523.3 mm 20.6 in
IBB CENTER TO TOP OF SEATTUBE 490.0 mm 19.3 in 520.0 mm 20.5 in 540.0 mm 21.3 in 560.0 mm 22.0 in 580.0 mm 22.8 in
JSEAT ANGL E 74.5 ° 74.0 ° 73.5 ° 73.0 ° 73.0 °
KCHAIN S TAY 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in 422.0 mm 16.6 in
LREACH 360.0 mm 14.2 in 369.0 mm 14.5 in 378.0 mm 14.9 in 390.0 mm 15.4 in 405.0 mm 15.9 in
MSTAC K 521.8 mm 20.5 in 545.5 mm 21.5 in 564.4 mm 22.2 in 583.3 mm 23.0 in 602.2 mm 23.7 in
NSTEM LENGTH 90.0 mm 3.5 in 100.0 mm 3.9 in 110.0 mm 4.3 in 120.0 mm 4.7 in 120.0 mm 4.7 in
0TRAIL
ADDICT DISC
XXS/47 XS/49 S/52 M/54 L/56 XL/58 XXL/61
AHEAD TUBE ANGLE 70.5 ° 71.0 ° 72.0 ° 72.5 ° 73.0 ° 73.3 ° 73.3 °
BHEAD TUBE LENGTH 100.0 mm 3.9 in 105.0 mm 4.1 in 120.0 mm 4.7 in 140.0 mm 5.5 in 160.0 mm 6.3 in 180.0 mm 7.1 in 200.0 mm 7.9 in
CTOP TUBE HORIZONTAL 510.0 mm 20.1 in 520.0 mm 20.5 in 535.0 mm 21.1 in 550.0 mm 21.7 in 565 .0 mm 22.2 in 580.0 mm 22.8 in 595.0 mm 23.4 in
DSTANDOVER HEIGHT 721.8 mm 28.4 in 734.7 mm 28.9 in 757.4 m m 29.8 in 777.0 mm 30.6 in 796.6 mm 31.4 in 815.9 mm 32.1 in 839.1 mm 33.0 in
EBB OFFSET -67.0 m m -2.6 in - 6 7.0 mm -2.6 in -67.0 m m -2.6 in - 6 7.0 mm -2.6 in - 67.0 m m -2.6 in - 6 7.0 mm -2.6 in - 67.0 m m -2.6 in
FBB HEIGHT 272.0 mm 10.7 in 272.0 mm 10.7 in 272.0 mm 10.7 in 272.0 mm 10.7 in 272.0 mm 10.7 in 272.0 mm 10.7 in 272.0 mm 10.7 in
GWHEEL BASE 972.0 mm 38.3 in 978.0 mm 38.5 in 980.1 mm 38.6 in 987. 0 mm 38.9 in 994.2 mm 39.1 in 1’002.9 mm 39.5 in 1’012.0 mm 39.8 in
HBB CENTER TO TOPTUBE CENTER 410.0 mm 16.1 in 430.0 mm 16.9 in 460.0 mm 18.1 in 480.0 mm 18.9 in 500.0 mm 19.7 in 520.0 mm 20.5 in 550.0 mm 21.7 in
IBB CENTER TO TOP OF SEATTUBE 455.0 mm 17.9 i n 475.0 mm 18.7 in 505.0 mm 19.9 in 525.0 mm 20.7 in 545.0 mm 21.5 in 565.0 mm 22.2 in 596.0 mm 23.5 in
JSEAT AN G LE 74.5 ° 74. 5 ° 74.0 ° 73.6 ° 73.3 ° 73.0 ° 72.5 °
KCHA I N STAY 405.0 mm 15.9 in 405.0 mm 15 .9 in 405.0 mm 15.9 in 405.0 mm 15.9 in 405.0 mm 15.9 in 405.0 mm 15.9 in 405.0 mm 15.9 in
LREACH 370.6 mm 14.6 in 378.8 mm 14.9 in 384.0 mm 15.1 in 388.9 mm 15.3 in 394.5 mm 15.5 in 400.1 mm 15.8 in 403.4 mm 15.9 in
MSTACK 502.6 mm 19.8 in 509.0 mm 20.0 in 526.7 mm 20.7 in 547.5 mm 21.6 in 568.3 mm 22.4 in 588.5 mm 23. 2 in 607.7 mm 23.9 in
NSTEM LENGTH 80.0 mm 3.1 in 90.0 mm 3.5 in 100.0 mm 3.9 in 110.0 mm 4.3 in 110.0 mm 4.3 in 120.0 mm 4.7 in 120.0 mm 4.7 in
ENGLISHENGLISH
•GEOMETRY/TECHNICAL DATA ADDICT DISC/GRAVEL/CX
•GENERAL FEATURES
ADDICT DISC
The all new Addict Disc comes with all the great features of the Addict, but is now equipped
with disc brakes to create a lightning fast climber that performs at its best in ALL weather
conditions.
ADDICT GRAVEL
The Addict Gravel Disc has been set up to allow you to ride any road, anywhere and in any
weather conditions. To give you a rig that will let you get your adventure on, no matter what.
ADDICT CX
The Addict CX is back, and it’s fitter than ever. We have embraced our lightweight obsession
to create a state of the art Cyclo-Cross bike that features excellent stiffness values combined
with race-driven geometry for immediate power transfer, direct handling, A-level integration
and a handful of unexpected extras while maintaining an incredibly low weight.
05 |
2016 BIKE USER MANUAL | ADDICT DISC/GRAVEL/CXADDICT DISC/GRAVEL/CX | 2016 BIKE USER MANUAL
| 04

ENGLISHENGLISH
•HEADSET OPTIONS
The Addict Disc/Gravel/CX features a tapered head tube and fork system.
The fork steerer is a 1 1/8” to 1 1/2”.
241901 Headset Syncros Drop-In 1-1/8" - 1-1/2"
•SEAT POST/CLAMP
The diameter of the seat post is 27.2mm. Please be aware to just use seat clamps with the
size of 30.2mm which fit the frame.
235429 Seatclamp 30.2mm bolt Addict MY14
•BB STANDARDS/FD MOUNTING DETAILS
The Addict Disc/Gravel/CX is constructed with a Shimano press fit 86 bottom bracket. The
diameter of the cartridge is 41mm
The chain guide from the two-by shifting system is the same as the one from the SCOTT
Scale # 219578, for the front derailleur (FD) hanger use the part# 242435
219578 Chainguide System Scale 2011
242435 Chainguide set Addict CX '16
In case of a one-by shifting system the chain catcher is included in the same kit as the FD
hanger. Part# 242435
242435 Chainguide set Addict CX '16
Chainguide set Addict CX '16
Chainguide set Addict CX '16
Chainguide System Scale 2011
07 |
2016 BIKE USER MANUAL | ADDICT DISC/GRAVEL/CXADDICT DISC/GRAVEL/CX | 2016 BIKE USER MANUAL
| 06

Ø12mm
142mm
Rear:
• 12mm through axle
• pitch 1.5mm
• 142mm hub
ENGLISHENGLISH
•RD HANGER
The Addict Disc/Gravel/CX uses the same design as the Solace Disc, so the derailleur hanger
is interchangeable.
239530 Dropout hanger Solace Disc '15<
•REAR BRAKE MOUNT
The front and rear brake mount on the Addict Disc/Gravel/CX is the new Shimano flat
standard.
The brake mount is as well compatible with the post mount standard. In this case it’s
essential to use an appropriate adapter.
•AXIS STANDARDS
To improve the stiffness, the Addict Disc/Gravel/CX has some threaded through axis in the
front and rear.
The front axle is a 100mm x 12mm
242431 Axle RWS Front Road
Disc >16 / Ø12MM
The rear axle is a 142mm x
12mm axle
239528 Axle 12mm rear Solace
Disc '15
•CABLE ROUTING
The Addict Disc/Gravel/CX features a total internal cable routing and is compatible with
every common shifting system. Whatever shifting system is installed on the bike, there is one
replacement kit which includes every necessary part.
242433 Cable fixing set Addict CX '16
Dropout hanger Solace Disc '15<
09 |
2016 BIKE USER MANUAL | ADDICT DISC/GRAVEL/CXADDICT DISC/GRAVEL/CX | 2016 BIKE USER MANUAL
| 08

ENGLISHENGLISH
•WARRANTY
SCOTT bikes are made using the most innovative production and quality methods. They are
equipped with best components of well known parts suppliers.
Doing so SCOTT warrants its frames and swingarms for five years (subject to compliance
with maintenance ranges, see below) and SCOTT forks (provided it is a fork of SCOTT) for
two years for defects in material and/or workmanship in case of purchase of completely
assembled bikes.
This warranty of 5 years for the frames shall only be granted in case once a year a
maintenance service has been effected according to maintenance requirements as set forth
in this manual by an authorised SCOTT dealer.
The authorised SCOTT dealer shall confirm the effected annual maintenance service by
stamp and signature.
In case such an annual maintenance service has not been effected the warranty of 5years
for the frame shall be reduced to 3 years.
Costs for maintenance and service have to be born by the owner of the SCOTT bike.
On Gambler, Voltage Fr and Volt-X the warranty period is limited to 2 years.
The warranty period starts at the day of purchase. This warranty is limited to the first buyer,
what means the first person who uses the bike and only with the use it was made for.
Furthermore, this warranty is limited to purchases via authorized SCOTT-dealers
The warranty is solely granted in case of purchase of a completely assembled bike to the
explicit exclusion of purchases of not completely assembled bikes.
In case of a warranty claim the decision to repair or to replace the defective part is up to
SCOTT. Non defective parts will only be replaced at the guarantee’s own expense.
Fair wear and tear is not covered by the warranty.
A complete list of all parts of wear and tear can be found in the next chapter of this manual.
In addition, you will find at the end of this manual a protocol for the handing over of the
bike which will remain in copy at the SCOTT dealer after acceptance and signature of the
consumer.
It is obligatory to show this protocol of handing over together with the defective part in case
of a warranty claim given that it provides evidence of purchase. Otherwise no warranty is
granted.
In principle, this warranty is granted worldwide. Claims must be made through an authorized
dealer, for information regarding the nearest dealer, write or call this company or the national
SCOTT distributor.
Normal wear, accident, neglect, abuse, improper assembly, improper maintenance by other
than an authorized dealer or use of parts or devices not consistent with the use originally
intended for the bicycle as sold are not covered by this warranty.
Hereby SCOTT grants a voluntarily manufacturer’s warranty. Additional entitlements
according to national warrant of merchantability are reserved.
For warranty info on the Fox Nude shock please refer to the attached manual of Fox Nude.
•WARRANTY
Model ...................................................................................
Year .....................................................................................
Size ......................................................................................
Frame Nr. ................................................................................
Shock Nr. ................................................................................
Date of purchase .........................................................................
