Scott PLASMA 4 User manual

WWW.SCOTT-SPORTS.COM
WWW.SCOTT-SPORTS.COM
SCOTT Sports SA
Route du Crochet 17, CH–1762 Givisiez
Phone: [phone] | Fax: [phone]
Email: [e-mail]
All rights reserved © 2016 SCOTT Sports SA
Distribution:
SSG (Europe) Distribution Center SA, P.E.D. Zone C1, Rue du Kiell 60, 6790 Aubange, Belgium
v6.2/15122016
USER MANUAL
SCOTT PLASMA 4

www.scott-sports.com
ENGLISHENGLISH
The Plasma 4 Carbon bikes should be adjusted exactly to the
current rider for reaching maximum safety and performance
while riding.
Please note that all adjustments should be done at your local
SCOTT dealer or following to this manual.
CONTENT
Plasma 4 Concept . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 04
Geometry/Technical Data Plasma 4 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 05
Plasma 4 Frameset Content . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
Specific Torques Values Table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 06
Rear Drop out and Derailleur Hanger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 07
BB Standard and FD Mount Standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
Headset Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
BB Cable Guide and Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 08
Seatpost and Seatube Clamp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 09
Storage Box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Guarantee on SCOTT Bikes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
03 |
BIKE USER MANUAL | PLASMA 4PLASMA 4 | BIKE USER MANUAL
| 02

ENGLISHENGLISH
PLASMA 4 CONCEPT
Plasma 4 is the result of research and development based on the feedback of the
SCOTT-triathlon and time trial athletes searching for one of the most efficient
aerodynamics orientated yet affordable frames in the market.
SCOTT’s focus was not only on the frame and rider aerodynamics but also on the
bike’s ergonomic side and adjustability as well as the frame front end stiffness.
GEOMETRY/TECHNICAL DATA PLASMA 4
Headtube diameter Plasma 4: 1.1/8”
BB housing PF BB 86
Rear brake SHIMANO direct mount
compatible brake calipers
Front brake Compatible with both SHIMANO
direct mount and single bolt front
brake calipers.
Seat post saddle
rails clamps
Different seatpost saddle rail
clamps are available to match with
your saddle: 7x7mm, 8x8.5mm or
7x9.6mm
Rear hanger Compatible Plasma 4 and Plasma 5
Shifting Mechanical and electrical shifting
compatible
S/51 M/54 L/57 XL/60
AHEAD TUBE ANGLE 72.0 ° 73.0 ° 73.0 ° 73.5 °
BHEAD TUBE LENGTH 100.0 mm 3.9 in 128.0 mm 5.0 in 159.0 mm 6.3 in 199.0 mm 7. 8 in
CTOP TUBE HORIZONTAL 526.0 mm 20.7 in 546.0 mm 21.5 in 566.0 mm 22.3 in 583.0 mm 23.0 in
DSTANDOVER HEIGHT 769.0 mm 30.3 in 799.0 mm 31.5 in 829.0 mm 32.6 in 869.0 mm 34.2 in
EBB OFFSET -65.0 mm -2.6 in -65.0 mm -2.6 in -65.0 mm -2.6 in -65.0 mm -2.6 in
FBB HEIGHT 269.0 mm 10.6 in 269.0 mm 10.6 in 269.0 mm 10.6 in 269.0 mm 10.6 in
GWHEEL BASE 965.0 mm 38.0 in 983.0 mm 38.7 in 1,009.0 mm 39.7 in 1,029.0 mm 40.5 in
HBB CENTER TO TOPTUBE CENTER 504.9 mm 19.9 in 534.7 mm 21.0 in 564.4 mm 22.2 in 604.2 mm 23.8 in
IBB CENTER TO TOP OF SEATTUBE 519.9 mm 20.5 in 549.7 mm 21.6 in 579.4 mm 22.8 in 619.2 mm 24.4 in
JSEATTUBE ANGLE 74.0 ° 75.0 ° 75.0 ° 76.0 °
KCHAINSTAY MIN. 403.0 mm 15.9 in 403.0 mm 15.9 in 403.0 mm 15.9 in 403.0 mm 15.9 in
LREACH 383.0 mm 15.1 in 400.0 mm 15.7 in 417.0 mm 16.4 in 430.0 mm 16.9 in
MSTACK 500.0 mm 19.7 in 530.0 mm 20.9 in 560.0 mm 22.0 in 600.0 mm 23.6 in
NSTEM LENGTH
05 |
BIKE USER MANUAL | PLASMA 4PLASMA 4 | BIKE USER MANUAL
| 04

ENGLISHENGLISH
PLASMA 4 FRAMESET CONTENT
1. Frame
2. Fork
3. Headset
4. Seatpost
5. Storage box
REAR DROP OUT AND DERAILLEUR HANGER
- Setup screw: Dropout length can be set to adjust the rear wheel tire clearance with
the frame (100) thanks to the rear dropout adjustement screws. The chainstays
length can be set from 403mm to 413mm.
- Loosen the screw to set a longer chainstays length,
- Tighten the screw to set a shorter chainstays length.
Make sure right and left side are set at the same length by assembling the rear wheel
and verifying it is centred with the chainstays.
- Rear derailleur hanger: place the rear derailleur hanger in the cavity and tighten
the 2x M5 screws to their specified torques.
Rear derailleur hanger: SCOTT Part number 239178
Drop out adjustment screws: Standard M5*10mm headless screw available in any
hardware shop.
SPECIFIC TORQUES VALUES TABLE
07 |
BIKE USER MANUAL | PLASMA 4PLASMA 4 | BIKE USER MANUAL
| 06

ENGLISHENGLISH
BB STANDARD AND FD MOUNT STANDARD
The BB standard on Plasma 4 is PF86.
FD Mount Standard: Brazed on standard same as other SCOTT road frames: Solace,
Addict or Foil.
HEADSET OPTIONS
Plasma 4 headset Syncros Drop-In 1 1/8” black part number: 238600
Bearings standard: IS41/28.6 | IS41/30
BB CABLE GUIDE AND CABLE ROUTING
BB cable guide set Plasma 4 Di2 + mechanical part number: 239179
SEATPOST AND SEATUBE CLAMP
SADDLE ASSEMBLY:
•IMPORTANT
Before assembling the saddle, make sure the seatpost saddle rail clamps (524/525)
are compatible with your saddle rails!
1. measure your saddle rails height and width (HxW)
2. Ritchey WCS Carbon One-Bolt Saddle Rail Clamp outer-pieces specifications
should be compatible with your saddle rails
3. if the saddle rails dimensions you measured are different from the saddle clamps
specifications, purchase the required saddle rail clamps parts at your retailer’s
4. following dimensions are available: 7x7mm, 8x8.5mm or 7x9.6mm
5. set the right saddle tilt and position the saddle rails so that the saddle rail clamps
are in the middle of the usable rail clamping area
6. tighten the M6 screw (527) to the specified torque (T13) to assemble the saddle
7. use the seatpost adjustment barrel to adjust your BB-Saddle horizontal offset
8. once the right offset is set, tighten the two M5 barrel screws (521) to the specified
torque (T12)
9. in some cases, you will need to remove the saddle to access the two M5
barrel screws.
09 |
BIKE USER MANUAL | PLASMA 4PLASMA 4 | BIKE USER MANUAL
| 08

ENGLISHENGLISH
SEATPOST ASSEMBLY:
•IMPORTANT
Before assembling the seatpost into the frame, make sure the rear side of the
seatpost (side where head is longer) is at the rear end of the frame
1. push gently the seatpost into the frame
2. for electronic shifting: make sure the battery does not get stuck into the frame
3. once the desired seatpost height is achieved pre-assemble the seatpost wedge:
position the upper wedge part (505) over the mid wedge part (504) and the low
wedge threaded part (503) below the mid wedge part
4. position the M6 wedge screw (506) into the assembly head up and pre-tighten it
over 3 turns
5. position the wedge assembly into the seattube insert in front of the seattube, its
concave face should correspond to the seatpost front surface
6. tighten the M6 screw to the specified torque (T11) while making sure the upper
surface of the wedge coincides with the upper surface of the top tube.
Seatpost and seatclamp assembly are fully compatible between Plasma 4 and
Plasma 5 frames.
- Seatpost Plasma 4/5 SCOTT part number: 239318
- Seat Clamp Plasma 4/5 SCOTT part number: 239544
STORAGE BOX
Plasma 4 framesets and complete bikes are delivered with an additional storage box
that can be fitted to the top front end of the Toptube via 2 M5 Allen screws as shown
on the sketch below.
11 |
BIKE USER MANUAL | PLASMA 4PLASMA 4 | BIKE USER MANUAL
| 10

SCOTT Bikes
Gambler, Voltage FR, Volt-X
5
ENGLISHENGLISH
limited warranty does not cover purchases of not completely assembled bikes. This
limited warranty does not cover any defect caused by “wear and tear” (a complete list
of all parts of “wear and tear” can be found in the general manual that came with your
bike), accident, neglect, improper handling, colour fade due to exposure to sunlight,
abuse, misuse, an act of God, improper assembly, non-compliance with recommended
maintenance and care procedures, improper or incorrectly performed maintenance or
repairs performed by someone other than an authorized SCOTT dealer, use of parts or
devices not consistent with the Product, and alteration of the Product.
All Products come with a manual; please carefully follow the instructions located there
or affixed elsewhere to the Product. To the extent permitted by law, consequential and
incidental damages are not recoverable under this limited warranty.
How do you make a claim under this limited warranty?
To make a claim under this limited warranty, you must notify SCOTT of the claimed defect
within the warranty period and timely return the Product to SCOTT at your expense for
inspection. Please contact your authorized SCOTT dealer, call SCOTT’s customer service
or the national SCOTT distributor (dealer locator: www.scott-sports.com). All returned
Products must be accompanied by proof of purchase (receipt) from an authorized
SCOTT dealer or this limited warranty will not apply. In case of replacement or refund,
returned Product becomes the property of SCOT T.
A protocol for the handing over of the Product (which you will find at the end of the
manual) will remain in copy at the SCOTT dealer after acceptance and signature of
the consumer. It is obligatory to show this protocol of handing over together with the
defective part in case of a warranty claim given that it provides evidence of purchase or
this limited warranty will not apply.
How do state laws affect your rights under this limited warranty?
This limited warranty gives you specific legal rights, and you may also have other rights,
which vary from state to state.
Recommendation
We strongly recommend that you use only authorized SCOTT dealers for yearly
maintenance services and for repairs, as improper or incorrectly performed maintenance
or repairs voids this limited warranty. Costs for maintenance service have to be borne by
the consumer.
•WARNING!
SCOTT Sports SA is not responsible or liable for any injury caused by any missing
compliance with these instructions, particularly but not limited to misuse, incorrect
maintenance, incorrect set-up and handling, neglect or abuse. Failure to follow these
instructions can result in component failure, serious personal injury. Component failure
can lead to loss of control of the bicycle and result in serious personal injury.
What is Covered?
This warranty covers defects in materials and workmanship at the time of transfer of risks
in frames, swingarms and forks (provided it is a fork of SCOTT) on SCOTT branded bikes
sold completely assembled by SCOTT or an authorized SCOTT dealer (“Product”).
How long does coverage last?
This voluntary manufacturer’s warranty is limited to five years for frames and swingarms,
respectively two years for forks, from the date of purchase of the Product and is limited
to the first purchaser of the Product and subject to the prior registration of your SCOTT
bike on www.scott-sports.com within 10 days as of the date of purchase. Transfer of
the Product from the first purchaser to another person terminates this limited warranty.
The limited warranty of five years for the frames and swingarms shall only be granted
in case once a year a maintenance service has been effected according to maintenance
requirements as set forth in the manual. The effected annual maintenance service shall
be confirmed by stamp and signature. In case such an annual maintenance service has
not been effected the warranty of five years for the frame shall be reduced to three years.
Costs for maintenance and service have to be borne by the owner of the Product.
On Gambler, Voltage FR and Volt-X the warranty period is limited to two years.
Repaired or replaced Products are covered for the remainder of the original warranty
period and subject to the conditions outlined in the original warranty, to the extent
permitted by law.
Hereby SCOTT grants a worldwide voluntarily manufacturer’s warranty. To the extent
permitted by law and unless a shorter duration is stipulated by law, any warranties
implied by law are limited in duration to maximum five, respectively two years, from the
date of purchase of the Product and are limited to the first purchaser of the Product.
What will SCOTT do?
SCOTT will replace or repair any defective Product, or will refund your purchase price (as
evidenced by your tendered receipt of purchase of the Product), at SCOTT’s option. You
must pay charges in connection with replacement of any non-defective parts. In such a
case, you will be alerted to the advisability of replacing non-defective parts, so you can
pre-authorize the costs.
What does this limited warranty not cover?
This limited warranty does not cover defects which did not exist before the transfer
of risks. This limited warranty does not cover Products used in rental operations. This
GUARANTEE ON SCOTT BIKES
13 |
BIKE USER MANUAL | PLASMA 4PLASMA 4 | BIKE USER MANUAL
| 12
