Introduction:
The SE Controls Variable Speed Fan Control Panel is a xed modular
design that is built and tested to provide a method of operating a
single 400 V three phase 50Hz duty / standby fan arrangement.
It must not be used for any other application or in conjunction with
other manufacturers’ products without prior consultation with
SE Controls.
Installation of this equipment must only be carried out by competent
and qualied persons.
This information pack must be retained for future reference by the client
and be made available for reference by persons installing, or servicing
the panel.
Application:
The Variable Speed Fan Control Panel is a control
system designed to operate 400 V/ 3PH/50 Hz
fans in a duty and standby conguration for
smoke control in a powered extract system.
The control of environmental fans is also possible
when specic additional packs are tted.
Operating from a 400 Volt supply, the Variable
Speed Fan Control Panel can control fans
from 15 kW - 22 kW (Standard Versions).
VARIABLE SPEED FAN CONTROL
PANEL 15 kW - 22 kW
Technical information and operating instructions

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 2
Contents
3.17. Push-pull Panel Link Connection
(TB22 if this option pack is tted)
1. General Information
1.1. General Safety Information 4
1.2. Health and Safety 4
1.3. Environment 4
1.4. User Responsibilities 4
1.5. Maintenance 5
1.6. Installation and Connection 5
1.7. Fault Finding 5
1.8. Contact Information 5
2. Specication
2.1. Device Overview 6
2.2. External Indication 6
2.3. Fuses 7
2.4. Minature Circuit Breakers 7
2.5. Recommended Cable Types 8
2.6. Cable Distances and Sizes 8
Disclaimer Information
2.7. Volt free Indication 8
3. Connections
3.1. Connections 9
3.2. Three Phase Power In Connection 9
3.3. Duty Fan and Stand By Fan 10
Connections
3.4. 400 Vac Fan Connection 10
3.5. 230 Vac Fan Connection 11
3.6. System Active 11
3.7. System Healthy (VFC) 12
3.8. Lifts to Ground 12
3.9. 230 Vac Smoke Damper 13
3.10. Generator Signal 13
3.11. Environmental Radial Damper 14
3.12. CloudLink Connection 14
3.13. Generator Status 15
3.14. Pressure Sensors 15
3.15. 24 Vdc Smoke Dampers 1 16
3.16. 24 Vdc Smoke Dampers 2 16
3. Connections, Continued
3.17. Variable Speed Fan Panel 17
Connections
3.18 Activation Contacts 18
3.19 FOS Switch - Boost 19
3.20 OSLink Network 19
3.21 Outside Air Temperature Hot 20
Corridor Solution
3.22 0-10 NV Fan 20
3.23 Test Switch 21
3.24 Battery Connections 21
4. System Design
4.1 System Design 22
4.2 Design Checklist for each VS
Fan Panel 22
5. Installation, Commissioning
and Fault Finding
5.1 Fixing 23
5.2 First power Up Tests 24
5.3 Inverter First Time Set Up and 25
Parameters
5.4 Basic Fault Finding for Standard 26
Version
6. Wiring Schematics
6.1 Circuit Diagram 27
Variable Speed Fan Control Panel 15kW-22kW

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 3
Important Notices
• Failure to follow current
electrical regulations
governing the installation
of xed equipment can
lead to prosecution
and may invalidate
any warranties.
• Where a replacement is
needed for consumable
items e.g. fuses, they
must be replaced with
parts of equivalent
manufacturing standard,
compliance and rating.
SE Controls accepts no liability
for failure to comply with
the these statements or the
installation and operation
guidance in the following
sections of this guide and
reserves the right to invalidate
the warranty of the controller
SE Controls reserves the right to
introduce any modications and
improvements to the contents
of this publication without the
obligation of giving prior notice.
• Do NOT allow abuse or
mishandling of the device.
• Do NOT adjust or
alter the device or its
enclosure including
labelling/marking.
• Do NOT use this controller
for any other purpose
other than that intended
by the manufacturer.
• Do NOT allow installation
of this equipment
by persons not
electrically qualied.
• Damage to the equipment
due to failure to test
the electrical integrity
of external wiring will
invalidate any warranties.
• Failure to install the
device in accordance
with the manufacturer’s
instructions will invalidate
any warranties.

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail]
4
1. General Information
1.3. Environment
Redundant electronic products are classied as
hazardous waste under the WEEE regulations
(Waste Electrical and Electronic Equipment).
Electronic parts must be disposed by an authorised
and licensed recycler. They must not be disposed
of in household waste or ‘general waste’ skips.
If recycling facilities are not locally available,
contact SE Controls who can arrange for recycling
and disposal of old electronic products.
1.4. User Responsibilities
United Kingdom Only: BS 7346-8:2013 is
a British Standard code of practice for the
planning, design, installation, commissioning and
maintenance of smoke control systems. Section
9 of the standard (Maintenance and Servicing)
states that frequent inspection of the system
should be undertaken by a named suitably-trained
member of the premises management team.
Routine inspection of the system should be carried
out in accordance with BS 9999:2008, Annex V.
For countries outside the United Kingdom:
Please check with the local the re authority in
your area regarding smoke control legislation,
dierent user responsibilities may apply.
Smoke control equipment should
only be maintained by a competent
person with specialist knowledge of
smoke control systems and sucient
information regarding the system.
1.1. General Safety Information
Read and observe the information
contained in these instructions.
Please keep these safety instructions for
future reference and maintenance. Reliable
operation and the prevention of damage
and risks are only assured if the equipment
is assembled carefully and the settings are
carried out according to these instructions and
to the operating instructions of the drives.
Please observe the exact terminal assignment,
the minimum and maximum power ratings (see
technical data) and the installation instructions.
1.2. Health and Safety
Electrical Safety: Warning 230 Vac or 400
Vac mains supply can cause death, serious
injury or considerable material damage.
Competence: This equipment is designed for
professional installation only by qualied, trained
and safety conscious electricians or skilled and
trained sta with considerable knowledge of
electrical equipment installation. These instructions
must be followed and retained for future reference.
Application: this equipment is
designed exclusively for the purposes
of controlling automatically smoke and
natural ventilation equipment.
Personal Protective Equipment: It is
recommended that suitable PPE is worn
at all times during the installation and
connection of products in accordance with
a recommended safe system of work.
Handling and storage: This equipment is
heavy. Care must be taken in transportation to
the installation location and during tting. The
equipment must not be dropped, impacted,
allowed to get wet or abused in any other way.
The panel should be kept in an upright position
at all times and should not be stacked more than
one high during shipping or storage.
Mishandling can result in serious damage to
the housing and the components therein.
Risk of crushing: this equipment can
automatically close windows and other
appliances without warning. Risk of serious
injury from crushing of hands or ngers.

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail]
5
1.5. Maintenance
A smoke control system should be checked
and serviced periodically in accordance
to local smoke control legislation.
Smoke control systems have to be serviced and
checked for defects at least once per year by an
authorised, trained and competent person.
Within the UK a suitable service contract with
SE Controls is recommended for this purpose.
The system must be protected
against unintentional start-up!
After maintenance, modication or repair
the system must be functionally retested.
Compatibility; this equipment should only
be used to operate with motors and other
products approved by SE Controls. No liability
will be accepted and neither guarantee nor
service is provided if unapproved products are
used in conjunction with this equipment.
1.6. Installation and Connection
Installation should be carried out by an
authorised, trained and competent electrician.
Ensure correct cable type is used throughout the
installation. All low voltage cables are to be routed
separately from mains voltage cables and other
electrically noisy cables. Flexible cables must not
be plastered over and freely suspended cables
must be provided with strain relief. Cables must
be installed in such a way that they cannot be
sheared, twisted, pierced or otherwise damaged
during installation or use. Junction boxes should
be accessible for inspection and maintenance.
Do not attempt to install or alter
the installation of the panel whilst
connected to the power supply.
1.7. Fault Finding
In the unlikely event that a problem occurs
with the control panel, users are urged to
contact SE Controls for assistance.
There are no user repairable parts. Fault
rectication must only be carried out by
authorised and competent persons.
1.8. Contact Information
For sales, technical support and
maintenance please contact:
SE Controls
Lancaster House
Wellington Crescent
Fradley Park
Licheld
Staordshire
WS13 8RZ
Tel: [phone]
Fax: [phone]
Website: www.secontrols.com

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 6
2.1. Device Overview
Part number 15-22 kW Fan Control Panel
FCS043XXXX
Dimensions 1400 x 1200 x 400mm (H x W x D) – Standard Versions
Mass Approx. 140 - 210kg Dependant on options tted
Supply 400 Vac 50/60 Hz
Output Up to 27.0 A : 15 kW Version
Up to 32.2 A: 18.5 kW Version
Up to 38.5 A : 22 kW Version
Cable Entries Cable entries are via up to 32 o 20 mm cable glands.
IP Rating IP55.
Humidity Range Maximum 90% Non-Condensing
Storage – 25°C to 60°C
Operating Temp -5°C to 40°C
Altitude Up to 1000 metres above sea level without de-rating (2000 metres max)
Rated Short Circuit Capacity (Icn) 10 kA
2.2. External Indication
Lamp Detail
Standby Lit when panel is healthy
Activated Lit when duty fans are running
Fault Lit when the duty fan is faulty or an internal fault has occurred
2. Specication

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 7
2.3. Fuses
Fuse Rating Function
F01 T 3 A Service Socket
F02 4 A
8 A
Without Pressure Sensors
With Pressure Sensors
F03 3 A Main PLC (K20)
F04 2 A Main PLC (K20)
X31 T 1 A 230 Vac Fan Damper (If Fitted)
X33 T 1 A 230 Vac NV Radial Dampers (If Fitted)
X38/F01 T 1 A ATS (If Fitted)
X39/F01 T 6.3 A Pressure Sensors (If Fitted)
X40/F01 T1 A 24 Vdc Smoke Damper (If Fitted)
X41/F01 T1 A 24 Vdc Smoke Damper (If Fitted)
X58 T8 A Battery
SO1 BS 88, A3, 50 A Mains Switch Disconnector
2.4. Miniature Circuit Breakers
MCB Rating Function
Q01 B 10 A, 2P, 10 kA G01 (PSU1) + Cooling Fan + Heater
Q02 B 6 A, 2P, 10 kA Service Socket + 230 Vac Smoke Damper
Q03 B 6 A, 2P, 10 kA G02 (PSU2) + NV Radial Dampers
Q05 B 40 A, 3P, 10 kA T01 INPUT (Variable Frequency Drive 1)
Q06 B 40 A, 3P, 10 kA T02 INPUT (Variable Frequency Drive 2)
Q07 B 40 A, 3P, 10 kA T01 OUTPUT (Variable Frequency Drive 1)
Q08 B 40 A, 3P, 10 kA T02 OUTPUT (Variable Frequency Drive 2)
Q09 B 10 A, 3P, 10 kA
C 16 A, 3P, 10 kA
C 16 A, 2P, 10 kA
T03 INPUT (Variable Frequency Drive 3 - IF 400 Vac Variable Speed
Environmental Fan is tted)
Q11 INPUT (If 400 Vac 3 Phase Environmental Fan is tted)
Q11 INPUT (If 230 Vac 1 Phase Environmental Fan is tted)
Q10 B 10 A, 3P, 10 kA T03 Output (Variable Frequency Drive 3 - If 400 Vac Variable Speed
Environmental Fan is tted)

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 8
2.5. Recommended Cables Types
Cabling For Minimum number of cores Recommended Cable Type
Incoming Supply 4 + Earth FP 600 or equivalent
Incoming Earth Cable 10 mm² minimum or equivalent to live cores when the live cores are thicker than 10
mm²
Standby Fan 3 + Earth FP 600 or equivalent
Network 2 + Earth FP Plus
All cabling will be in accordance with relevant standards and regulations for electrical Installation such as BS7671.
2.7. Volt Free Indication
Terminal Description
X28 Healthy system
X29 Smoke Fan Activated
X30 Lift to Ground
2.6. Cable Size and Distances - Disclaimer Note
Incoming supply (Minimum distance between the power distributor feeder and the panel entrance to guarantee a
10 kA maximum prospective short-circuit current at the input terminals).
Cable Size Distance
2.5 mm² 3 m
4 mm² 5 m
6 mm² 7.5 m
10 mm² 12.5 m
16 mm² 20 m
25 mm² 30 m
35 mm² 43 m
50 mm² 58 m
Incoming Earth Cable
10 mm² minimum or equal to Live cores where the live cores are thicker than 10 mm².
Cable Connecting the Fan
The length of the cable between the panel and load (fan) should be as short as possible and the voltage drop shall
not exceed 5%.

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 9
3. Connections
3.1. Connections
The 16 mm terminals (fan connections) have a cable capacity of 4-35 mm2 stranded or solid.
All 4 mm terminals have a cable capacity of 2.5 mm2 stranded or 4 mm2 solid.
Each terminal is identied with a unique reference. Please check the circuit diagram for details.
The following sections are to be used for guidance only and are subject to change.
Strip the outer sheath of all cables back to the entry point of the enclosure. Ensure enough sheath is left to
provide mechanical protection against cable movement over time.
Inner cable cores should be dressed under the edges of the terminals. This provides a neater and more
ordered solution. Only strip inner cores suciently to make a good electromechanical contact with the
terminal blocks.
3.2 Three Phase Power in Connection
Ensure the supply is securely isolated before connecting.
The Earthing cable should be connected to W02 (Earthbar).
Important: The Mains Switch Disconnector will not isolate the circuits linked to connectors X28, X29, X30
and X32. These terminals are used to link the panel to external parts of the system. To isolate that part of the circuit,
please check the devices to which they are linked. These terminals are connected to internal components via
orange cables, which should help to identify which parts of the panel may remain energised even when the
Mains Switch Disconnector is in its OFF position.
The incoming mains ferrite cores must be installed before the cables are connected to the switch dissconnector.
Insert one of the phase line conductors (exclude neutral and ground) through the toroid rings and then wrap it
around the ferrite’s twice. This operation needs to be executed for each phase line conductor L1, L2 and L3.
Please refer to the illustration below for guidance.

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 10
3.3. Duty Fan and Standby Fan Connections (X25 & X26)
3.4. 400 Vac NV Fan Connections (X27, if this option pack is tted)
1.4
CONTROL PANEL DIN RAIL CONNECTIONS
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
1.3
X27
DIN RAIL REF:
DESCRIPTION
L1
L2
PHASE 1
DIN RAIL CONNECTIONS - X27
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
DIN RAIL TERMIAL
L3
E
PHASE 2
PHASE 3
EARTH
EF:03
415V
X27
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
X27 X27(230v)
VARIABLE SPEED PANEL CONNECTIONS VARIABLE SPEED PANEL CONNECTIONS
ENVIRONMENTAL FAN
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
PHASE 1 PHASE 2 PHASE 3 EARTH
INSIDE CONTROL PANEL
IN THE FIELD
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3
DIN RAIL CONNECTIONS - X27
EF:03
230V
ENVIRONMENTAL FAN (230V)
LIVE NEUTRAL
EARTH
INSIDE CONTROL PANEL
IN THE FIELD
V3
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
X27 X27
135
6
4
2
135
6
4
2
JWA 26/09/23 JWA 26/09/23
7
8
7
8
CONTROL PANEL DIN RAIL CONNECTIONS
DUTY FAN
DESCRIPTION
L1
L2
PHASE 1
DIN RAIL CONNECTIONS - X25 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
VARIABLE SPEED PANEL CONNECTIONS
JWA
REVISION:
DIN RAIL TERMINAL
V326/09/23
L3
E
IN THE FIELD
1.1
PHASE 2
PHASE 3
EARTH
EF:01
DUTY
PHASE 1 PHASE 2 PHASE 3
EARTH
X25
DIN RAIL REF:
X25
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
X25
1357
86
4
2
DESCRIPTION
L1
L2
PHASE 1
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
DIN RAIL TERMIAL
L3
E
1.2
PHASE 2
PHASE 3
EARTH
X26
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
X26
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3
STANDBY FAN
DIN RAIL CONNECTIONS - X26 INSIDE CONTROL PANEL
IN THE FIELD
EF:02
STANDBY
PHASE 1 PHASE 2 PHASE 3
EARTH
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
X26
1357
86
4
2
JWA 26/09/23

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 11
3.5. 230 Vac NV Fan Connections (X27, if this option pack is tted)
3.6. System Active (X28)
1.4
CONTROL PANEL DIN RAIL CONNECTIONS
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
1.3
X27
DIN RAIL REF:
DESCRIPTION
L1
L2
PHASE 1
DIN RAIL CONNECTIONS - X27
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
DIN RAIL TERMIAL
L3
E
PHASE 2
PHASE 3
EARTH
EF:03
415V
X27
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
X27 X27(230v)
VARIABLE SPEED PANEL CONNECTIONS VARIABLE SPEED PANEL CONNECTIONS
ENVIRONMENTAL FAN
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
PHASE 1 PHASE 2 PHASE 3 EARTH
INSIDE CONTROL PANEL
IN THE FIELD
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3
DIN RAIL CONNECTIONS - X27
EF:03
230V
ENVIRONMENTAL FAN (230V)
LIVE NEUTRAL
EARTH
INSIDE CONTROL PANEL
IN THE FIELD
V3
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
X27 X27
135
6
4
2
135
6
4
2
JWA 26/09/23 JWA 26/09/23
7
8
7
8
SYSTEM ACTIVE
DIN RAIL CONNECTIONS - X28 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X28
1.5
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
X28
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
BMS
13
24
X28
JWA 26/09/23

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 12
3.7. System Healthy (VFC) (X29)
3.8. Lifts to Ground (X30)
SYSTEM HEALTHY VFC
DIN RAIL CONNECTIONS - X29 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X29
1.6
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
BMS
X29
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3
X29
JWA 26/09/23
X30
LIFTS TO GROUND
DIN RAIL CONNECTIONS - X30 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X30
1.7
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
BMS
13
24
X30
JWA 26/09/23

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 13
3.9. 230 Vac Smoke Damper (X31)
3.10. Generator Signal (X32)
X31
230 Vac SMOKE DAMPER
DIN RAIL CONNECTIONS - X31 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X31
1.8
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
POWER CLOSE/SPRING OPEN
VARIABLE SPEED PANEL CONNECTIONS
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X31
JWA 26/09/23
LIVE
NEUTRAL
GENERATOR SIGNAL
DIN RAIL CONNECTIONS - X32 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X32
1.9
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
OPENS TO
ACTIVATE
GENERATOR
GENERATOR
X32
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
24
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3
X32
JWA 26/09/23

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 14
3.11. Environmental Radial Damper (X33, if this option pack is tted)
3.12. Cloudlink Connection (X36)
DIN RAIL CONNECTIONS - X36 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X36
1.11
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
CLOUDLINK
X36
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3JWA 26/09/23
RJ45
ETHERNET CONNECTION
X33
1.10
CONTROL PANEL DIN RAIL CONNECTIONS
DIN RAIL CONNECTIONS - X33 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X33
DIN RAIL REF:
3
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
4
+V
0V
V4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
X33
1
2
1A
JWA 26/09/23
RADIAL DAMPERS

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 15
3.13. Generator Status (X38)
3.14. Pressure Sensors (X39)
GENERATOR STATUS
DIN RAIL CONNECTIONS - X38 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X38
1.12
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
GENERATOR
X38
VARIABLE SPEED PANEL CONNECTIONS
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
24
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3
X38
JWA 26/09/23
CLOSED CONTACT
OPENS ON FAULT
3
4
X39
1
2
7
8
5
6
11
12
9
10
13
14
15
16
0V +V GND B A AB GND +V 0V
0V +V GND BA A B GND +V 0V
PRESSURE SENSORS
DIN RAIL CONNECTIONS - X39 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X39
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
MJo
1.16
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
Please see schematic
for additional
pressure sensor
wiring reference
numbers.
V321/09/20
X39
Up to 50
pressure sensors
PRESSURE SENSOR 1
PRESSURE SENSOR 2

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 16
3.15. 24 Vdc Smoke Dampers 1 (X40)
3.16. 24 Vdc Smoke Dampers 2 (X41)
X41
PUSH-PULL PANEL LINK CONNECTIONS
DIN RAIL CONNECTIONS X41
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
PROJECT NAME:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
1.15
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
24
V4
X41
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
X41
INSIDE CONTROL PANEL
JWA 26/09/23
SMOKE DAMPER 2
IN THE FIELD24 Vdc SMOKE DAMPERS
+V
0V
X40
PUSH-PULL PANEL LINK CONNECTIONS
DIN RAIL CONNECTIONS X40
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
PROJECT NAME:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
1.14
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
V4
X40
VARIABLE SPEED PANEL CONNECTIONS
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
X40
INSIDE CONTROL PANEL
JWA 26/09/23
SMOKE DAMPER 1
+V
0V
IN THE FIELD24 Vdc SMOKE DAMPERS

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 17
3.17. Variable Speed Fan Panel Connections (X42)
15
26
X42
9
10
3
4
7
8
11
12
2
6
10 4 8
12
2610
4812 2
6
10 4 8
12
2610
4812
PUSH-PULL PANEL LINK CONNECTIONS
DIN RAIL CONNECTIONS X42
DIN RAIL CONNECTIONS X42 REMOTE
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
PROJECT NAME:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
1.16
MJo
X42
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V230/09/19
X42
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
LOCAL
Up to 4 panels
PANEL 2 PANEL 3

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 18
3.19. Activation Contacts (X43,X44, X45, X46)
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X43 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X43
1.17
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X43
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X43
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X44 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X44
1.18
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X44
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X44
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X45 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X45
1.19
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X45
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X45
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X46 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X46
1.20
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X46
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X46
JWA 26/09/23
ACTIVATION 1 ACTIVATION 2 ACTIVATION 3 ACTIVATION 4
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X43 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X43
1.17
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X43
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X43
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X44 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X44
1.18
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X44
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X44
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X45 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X45
1.19
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X45
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X45
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X46 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X46
1.20
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X46
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X46
JWA 26/09/23
ACTIVATION 1 ACTIVATION 2 ACTIVATION 3 ACTIVATION 4
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X43 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X43
1.17
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X43
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X43
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X44 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X44
1.18
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X44
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X44
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X45 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X45
1.19
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X45
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X45
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X46 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X46
1.20
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X46
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X46
JWA 26/09/23
ACTIVATION 1 ACTIVATION 2 ACTIVATION 3 ACTIVATION 4
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X43 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X43
1.17
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X43
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X43
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X44 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X44
1.18
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X44
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X44
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X45 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X45
1.19
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X45
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X45
JWA 26/09/23
ACTIVATION CONTACT
DIN RAIL CONNECTIONS - X46 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DIN RAIL REF:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X46
1.20
CONTROL PANEL DIN RAIL CONNECTIONS
1
2
NORMALLY CLOSED
X46
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V4
X46
JWA 26/09/23
ACTIVATION 1 ACTIVATION 2 ACTIVATION 3 ACTIVATION 4

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 19
OSLINK NETWORK
DIN RAIL CONNECTIONS - X48 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X48
DIN RAIL REF:
AI2
SP1
AOC
SCR
NTA NTA NTA
SCR
SP3
0VA
SCR
SP2 0VA
SCR
NTB NTB NTB
SCR
SP4
CN10
RV1
135
DESCRIPTION
NTA
NTB
NETWORK TERMINAL A
DIN RAIL TERMIAL
SCR
NETWORK TERMINAL B
NETWORK SCREEN
CONTROL PANEL DIN RAIL CONNECTIONS
1.22
X48
VARIABLE SPEED PANEL CONNECTIONS
2 4 6
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3
DESCRIPTION
NTA
NTB
NETWORK TERMINAL A
DIN RAIL TERMIAL
SCR
NETWORK TERMINAL B
NETWORK SCREEN
X48
JWA 26/09/23
3.20. OSLink Network (X48)
FOS SWITCH - BOOST
DIN RAIL CONNECTIONS
X47
INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X47
BOOST SWITCH
1.21
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
FIREMANS
OVERRIDE
SWITCH
X47
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
4
2
+V
0V
0V
+V
V4
X47
5
7
6
8
JWA 26/09/23
3.19. FOS Switch - Boost (X47)

[phone]
[e-mail]
www.secontrols.com
Please keep these operating instructions for future reference and maintenance.
Subject to technical modications. Diagram is not binding.
For a larger version of this diagram, please contact: [e-mail] 20
3.22. 0-10 NV Fan (X50)
OUTSIDE AIR TEMPERATURE SENSOR
DIN RAIL CONNECTIONS - X49 INSIDE CONTROL PANEL
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
IN THE FIELD
X49
1.23
DIN RAIL REF:
CONTROL PANEL DIN RAIL CONNECTIONS
X49
HOT CORRIDOR SOLUTION
+t
o
VARIABLE SPEED PANEL CONNECTIONS
S:\TechnicalSupportTeam\supperhidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
V3
S:\TechnicalSupport Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
2 4
5
6
WIDE
TASC
BOARD
WIDE
RANGE
X49
JWA 26/09/23
3.21. Outside Air Temperature Sensor Hot Corridor Solution (X49)
PUSH-PULL PANEL LINK CONNECTIONS
DIN RAIL CONNECTIONS X50
DRAWING TITLE:
E-mail: [email protected]
Website: www.secontrols.com
Lancaster House, Wellington Crescent
Staffordshire, WS13 8RZ
Tel: [phone] Fax: [phone]
Fradley Park, Lichfield
PROJECT NAME:
DRAWN BY: DATE:
POR REF:SOR REF:
REVISION:
1.24
X50
S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
13
24
V4
X50
VARIABLE SPEED PANEL CONNECTIONS S:\Technical Support Team\supper hidden new logo\SED_3036_SE Controls Colour Logo 2018 TIFF.tif
X50
JWA 26/09/23
0-10NV FAN
+V
0V
IN THE FIELD
