Sea & Sea YS-1 User manual

日本語 English
UNDERWATER STROBE
03109
7
取扱説明書
Instruction Manual

E-1
Note:
Products bearing this sticker are those that have
passed SEA&SEA’s criteria-based inspection
for pressure resistance.
Introduction
Thank you for purchasing SEA&SEA products.
Please read this instruction manual carefully prior to using
your underwater strobe. Only with a thorough understanding
of this manual's content will you be able to use the strobe
correctly. After reading the manual, please be sure to keep it
in a place where you can easily come back to it at any time.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:(1) this device may not cause harmful
interference, (2) this device must accept any
interference received, including interference that
cause undesired operation.
The product conforms to WEEE standards.
This symbol indicates separate collection of
waste electrical and electronic equipment in
the EU countries. Please do not throw the
equipment into the domestic refuse.
Please contact your local authorities for recycling
program information.

E-2
Contents
Safety Precautions........................................................
Safety Precautions for Use of Battery...........................
Accessories...................................................................
Identification of Parts.....................................................
Operation...............................................................
Slave Sensor Cap................................................
Fixing Bolt............................................................
Installing the Batteries.................................................
Connecting the Strobe................................................
Taking Photographs....................................................
Using the Diffuser........................................................
Maintenance and Storage...........................................
Specifications..............................................................
E-3
E-6
E-8
E-9
E-9
E-11
E-11
E-12
E-13
E-15
E-17
E-18
E-19

E-3
For safe handling of the product, please read the following
precautions carefully before use.
DANGER
●Never attempt to disassemble, repair or alter the product yourself to prevent
significant electrical hazard due to the high-voltage circuitry in the product.
Do not heat the product or put it into a fire, this could result in explosion or
fire. Unauthorized disassembling and/or modification could result in
malfunction or flooding, and avoid product warranty. Take the product to
a SEA&SEA authorized service center for repair or inspection.
●Never short-circuit the terminals of batteries installed in the product, as it
could result in battery leakage, heat generation, fire, explosion, or product
malfunction.
●Move leaking batteries away from fire or open flames immediately.
The leaked fluid and its vapor are combustible.
●If the battery leakage contacts your skin or clothing, flush the affected area
repeatedly with clean water. It may irritate your skin. Should it get into your
eyes, immediately rinse them with plenty of water, avoid rubbing and seek
medical advice.
WARNING
●Use only batteries approved for use in this product. Do not mix oid and new
batteries of different types.
●Remove batteries before transport or storage, or when you are not going to
use the product for an extended period of time, to prevent unexpected
activation.
●Pay praticular attention to opening the battery cap to avoid injury.
Heat from the batteries may cause pressure buildup inside the battery
compartment, and could result in cap explosion with unexpected force.
Safety Precautions
Failure to heed the precautions listed below could result in serious
consequences. To prevent injury or damage to yourself and/or
others, please observe the precautions as they contain highly
important information related to personal and product safety.
DANGER Situations that involve a high risk of severe injury or
death.
WARNING Situations that could result in severe injury or death.
CAUTION Situations that could result in property damage or
personal injury.

E-4
Safety Precautions
●Avoid water or foreign objects inside the product. Discontinue use and turn
it off immediately should you notice flooding or leakage.
Continuous use could result in complete damage to the product.
●Do not handle batteries wet hands to prevent shock hazards.
●Do not use the product in the presence of flammable gas, as this could result
in explosion or fire.
●Do not fire the strobe/light with the reflector touching a person or object to
prevent heat generation. Touching the reflector immediately after firing
could result in burns.
●Do not fire the strobe or illuminate the light towards a driver of a vehicle to
avoid causing accidents.
●Do not operate the product while driving a vehicle. Inattention could result in
accidents.
●For use on land, do not operate the product at precarious foothold.
It may cause falling, injury or product damage.
●Do not leave the product on a slope or an unstable surface. It may be broken
after falling or injure someone below it.
●Keep out of reach of children to prevent accidental ingestion. If swallowed,
seek medical advice immediately.
CAUTION
●Read the instruction manual and observe proper precautions before use of
this product.
●Should you notice somoke or an unusual smell coming from the product,
turn it off and remove the batteries immediately, taking care to avoid burns.
Continued operation could result in injury. After removing the battery, take
the product to a SEA&SEA authorized service center for inspection.
●Discontinue use and turn the product off immediately should you notice
flooding or leakage.
●When the product is flooding, interior pressure may build up. Please be
careful when opening the product as water may spurt out or the cap may
open explosively and cause injuries.
●Do not open the battery cap in the vicinity of open flames.
●The product has been constructed with an airtight seal. When packing the
product for airplane travel, do not seal-up the product to alleviate pressure
build up due to atmospheric changes.
●Do not open the product in a wet or sandy environment. Protect the interior
from moisture and debris in order to prevent malfunction or flooding.
●Keep away from strong magnetic fields. Do not use or store this product in
the vicinity of equipment that qenerates strong electro-magnetic radiation
or magnetic fields. Strong static charges or the magnetic fields could cause
malfunction, or affect the product's internal circuitry.

E-5
Safety Precautions
●Before using the product in an airplane or a hospital, check if it is allowed.
Electromagnetic waves emitted by the product may interfere with the
measuring instruments or medical equipment.
●Do not cover or wrap the product with a cloth. This could result in deformation
of the product or in fire.
●Using the strobe close to your subject's eyes could cause temporary visual
impairment. Particular care should be observed if photographing infants, the
strobe should be no less than one meter (3 feet) from the subject.
●Be careful when touching the product immediately after firing repeatedly or
lighting for a long time. The product may get hot enough to burn you.
●Avoid strong shocks/impacts or excess stress to prevent malfunction,
damage or breakdown. Make sure that the product has been securely
mounted to other products in order to prevent injury, fall or missing.
●Do not carry the camera or housing by holding the accessories such as
arm, cable, strobe, etc. Heavy components may fall and cause damage or
injury.
●Do not rest heavy weight on the product. It might deform the outer casing,
damage internal parts, make the waterproofing fail, or result in fire or
electric shock.
●Rinse the product with fresh water, after underwater use. Ensure that the
product is waterproofed before rinsing. Refer to [Maintenance and Storage]
for details.
●Make sure that the connectors have been secured with the connector caps
before rinsing the product with fresh water, after removal from other products.
●Never use chemicals, cosmetics, any petroleum solvents such as paint
thinner, or neutral detergent on the product. They may deform and damage
the product.
●Do not leave the product in places with hot temperatures such as inside of
a car or in a car trunk in summer. The heat may deform plastic parts of the
product, damaging internal parts and resulting in potential fire or electric
shock. If the product is sealed tight in hot conditions, heated air expanding
inside the product may deform the casing and ruin the waterproofing.
●Do not store the product in wet or high humidity place, to avoid mold, rust,
corrosion or malfunction.
●Do not store the product with naphthalene or camphor mothballs, or in
locations such as a laboratory where chemicals are used. This environment
can cause mold, rust, corrosion or malfunction.
●If you do not use the product for an extended period of time, periodic
maintenance will keep internal electronic parts from deterioration.
Once a month, install batteries and fire a test flash/light on. Operate all other
switches as you would in normal operation. Turn the power off, then remove
batteries while the ready lamp (red) is on for the strobe.

E-6
DANGER
●Never expose the battery to flame or fire, or to excessive heat.
●Never attempt to disassemble, alter or directly solder the battery. There are
no user-serviceable parts. Tampering with battery may expose you to
dangerous voltage, battery acid, or electrical shock.
●Never short-circuit the terminals of a battery, as it could result in battery
leakage, heat generation, fire, or explosion. Avoid contact with all metal
objects during transporting and storage.
●When recharging batteries such as nickel metal-hydride or lithium-ion
batteries, use a charger designed specifically for them and follow the
recharging instructions. Recharging in an inappropriate charger may cause
battery leakage, overheating, and explosion.
●Move leaking batteries away from fire or open flames immediately.
The leaked fluid and its vapor are combustible.
●If the battery leakage contacts your skin or clothing, flush the affected area
repeatedly with clean water. It may irritate your skin.
Should it get into your eyes, immediately rinse them with plenty of water,
avoid rubbing and seek medical advice.
●Never attempt to insert the battery upside down or backward, as it could
result in battery leakage or exposion. Always confirm the direction of plus
and minus before installation.
●Never connect a battery directly to a plug outlet or car cigarette lighter.
WARNING
●Keep dry. The battery is not waterproof, and may malfunction if immersed in
water or exposed to high levels of humidity. Rusting of the internal mechanism
can cause irreparable damage.
Safety Precautions for Use of Battery
●SEA&SEA SUNPAK Co., Ltd. assumes no liability for compensation of loss
of captured images or expenses caused by loss of images, even if you are
unable to shoot due to a product defect or malfunction.
●SEA&SEA SUNPAK Co., Ltd. will not be responsible for the replacement or
compensation for cameras, lenses or those accessories damaged due to
your invalid operation.
●Carefully observe the O-ring maintenance manual for the handling of O-rings
befor use.
●SEA&SEA SUNPAK Co., Ltd. assumes no liability for errors or discrepancies
in this manual.
●Specifications and appearance are subject to change without notice.
Safety Precautions

E-7
CAUTION
●Avoid strong shocks/impacts or excess stress to batteries.
●For handling and recharging of a battery, refer to the instruction manual of
the battery/dedicated charger.
●Do not use or discharge the battery at ambient temperatures below 0℃(32°F)
or above 50℃(122°F).
●During recharging, the temperature should be in the vicinity from 0℃to 40℃
(32°F to 104°F).
●Always recharge the rechargeable battery before use after an extended
time of storage.
●Do not recharge battery in a cold environment below 0℃(32°F).
Severe cold may cause battery leakage, deterioration in performance, or
shortened life.
●Dirt on the battery terminals can prevent the product from functioning.
Should the battery terminals become dirty, wipe them with a clean, dry cloth
before use.
●Turn the equipment off after use. Remove batteries from the equipment
when not in use.
Store in dry area with temperatures ranging from -20℃to 30℃(-4°F to 86°F).
●Used rechargeable batteries are valuable resource. Please recycle used
rechargeable batteries in accordance with local regulations.
●Do not remove and/or damage the case of a battery. It may cause battery
leakage, overheating or explosion.
●Do not charge a rechargeable battery beyond the specified charging time,
it may cause battery leakage, fire hazard or explosion.
●Never use batteries should you notice any changes such as leakage,
discoloration or deformation. When you notice the situation as abnormal,
discontinue use immediately and take the product to a SEA&SEA authorized
service center for inspection.
●Keep out of reach of children to prevent accidental ingestion.
If swallowed, seek medical advice immediately.
●Do not leave or use batteries in an extreme hot environment. This may
cause battery leakage, overheating or battery performance deterioration.
Safety Precautions for Use of Battery

E-8
Before using this model, check to make sure that all accessories
are present.
Accessories
YS-17 Diffuser
Slave Senor Cap
Diffuser String
Sillicon Grease
●O-ring Maintenance Manual
●YS-17 Instruction Manual （this manual）

E-9
Identification of Parts
Reflector
Fixing bolt
（P.E-11) Slave sensor （P.E-11)
Battery cap（P.E-12)
Arm installation nut（P.E-11)
Light level switch
（P.E-10)
ＴＴＬ lamp（P.E-10)
Mode switch
（P.E-10)
Ready lamp
（P.E-10)

E-10
Identification of Parts
OFF Turns the power off. Set
the mode switch to [OFF]
when you are not using
the strobe.
MSet the mode switch to this
position when you shoot
with manual flash.
TTL Set the mode switch to this
position when you shoot with TTL flash.
Ready lamp Illuminates in red when the strobe is ready
to fire.
ＴＴＬ lamp Illuminates in green for
approx. 3 seconds after
firing with TTL flash output.
Operation
Mode Switch
Light amount can be adjusted in 2
increments (FULL or 1/2) when the mode
switch is set to [M].
Light Level Switch
Ready lamp
ＴＴＬ lamp

E-11
Identification of Parts
This model may fire when you turn the power on without
attaching the slave sensor cap or connecting a fiber-opticcable
(optional) to the slave sensor. To avoid unexpected emissions,
block the slave sensor with the cap when a fiber-optic cable
is not connected.
Slave Sensor Cap
CAUTION
The slave sensor cap has a string
eyelet in it. Pass a string through
the eylet to prevent losing the cap.
Fixing Bolt
To mount the strobe to an arm,
insert the fixing bolt in the direction
of the arrow.
CAUTION
Take care not to insert the fixing
bolt from the wrong side, as this
can result in damage to the arm
installation nut.

E-12
1
2
3
4
6
This model can be powered by the following batteries.
Use two of each type.
Make sure that the mode switch is
in the OFF position
Turn the battery cap counterclockwise
and remove (Fig.1)
●Take care to insert the batteries in the
correct direction.
Apply silicon grease to the O-ring
●Check the O-ring to make sure there are
no scratches or debris, and apply a light
coating of the included silicon grease.
After closing the battery cap completely,
turn back the cap to align the concave
marks (Fig.4)
5Align the ▲mark inside the battery
cap with the ▼mark (salient) on the
battery compartment (Fig.3), and turn
the cap clockwise to close
CAUTION
●When installing or removing batteries, thoroughly wipe water off the
strobe and dry your hands. Pay particular attention not to allow water
from your hair or wetsuit to drip into the battery compartment. This is
in order to prevent an electrical hazard, mold, malfunction or flooding.
●Never mix old and new batteries or batteries of different types.
●Always replace all batteries with new batteries at the same time.
Installing the Batteries
AA alkaline battery、AA Ni-MH battery、AA oxyride battery
Insert two batteries aligned to the
+ and - marks (Fig.2)
Fig.1
Fig.2
Fig.3
Fig.4

E-13
Connecting the Strobe
When you use this strobe with a compact digital camera,
connect the strobe to the camera (housing) with a fiber-optic
cable (optional). Using a built-in slave sensor, this strobe is
triggered by sensing the light from a digital camera's built-in
flash. If the fiber-optic cable is not used, depending on the
shooting conditions the strobe may either not fire, or not obtain
TTL flash exposure compensation.
CAUTION
Some housings are not compatible with fiber-optic cable.
1Insert the fiber-optic cable's
connector into the slave sensor
socket of the strobe until it stops
2Connect the other end of the
fiber-optic cable's connector to
the socket in the housing
●When the housing is not equipped
with the socket, attach the strobe
mask (A: optional) to the flash
window of the housing, and then
connect the fiber-optic cable (B:
optional). A
B

E-14
Connecting the strobe
CAUTION
●When you shoot with a compact digital camera, set the built-in
flash of the camera to the forced-flash mode. The strobe will
not fire unless the built-in flash of the camera fires. Refer to
the digital camera instruction manual for setting the forced-
flash mode.
●Refer to the fiber optic-cable instruction manual before use.
●When using this model together
with the SEA&SEA DX-8000G/
DX-1G set, please attach the fiber-
optic cable adapter (in-cluded in the
DX-8000G/DX-1G) to the housing,
and then use a fiber-optic cable.
●Refer to the housing instruction
manual before use.
Fiber-optic cable adapter

E-15
Taking Photographs
When you shoot with a compact digital camera, set the built-in
flash of the camera to the forced-flash mode. The strobe will
not fire unless the built-in flash of the camera fires.
1
2Set the mode switch to [TTL]
Take a photograph
TTL Photography
Photography based on the camera's photometric data of the
subject's brightness, which is used to regulate the light amount
of the strobe so that the correct exposure is achieved.
Even if the distance from the subject has changed, the light
amount will be controlled automatically and you can easily
obtain the correct exposure. After shooting with TTL automatic
light control, the TTL lamp on the light level switch will illuminate
in green for approximately 3 seconds. When automatic light
control was not used, the TTL lamp will not illuminate.
TTL Photography

E-16
Taking Photographs
Light amount of the strobe can be adjusted with the light
level switch.
1
2
Set the mode switch to [M]
3
Adjust with the light level switch (Set to [FULL] or [1/2])
Take a photograph
Pre-flash
With some types of digital cameras, the light amount is
adjusted with the first flash and the image is taken with the
second flash (main flash). The first flash for adjusting the light
amount is called a pre-flash. When the mode switch is set to
[M] and the light level switch is set to [FULL], the strobe will
fire in synchronization with the pre-flash. As a result, it will
recharge during the second flash (main flash) and be unable
to fire.
Manual photography
CAUTION
FULL：●For a compact digital camera that does not pre-
flash, or acamera that has apre-flash cancel
function.
Refer to the digital camera instruction manual for
details.
●If your camera pre-flashes, set the light level switch
to [1/2].
●The light amount (Guide Number) of the main flash
of this strobe will differ depending on the number
of pre-flashes.
1/2 ：

E-17
Taking Photographs
Use of Diffuser is highly recommended
for shooting short camera-to-subject
distances. Fit and press the diffuser
to the front of the strobe.
CAUTION
●Always make sure that the diffuser
is properly attached before use.
If not properly attached, it may
fall off, get lost or become damaged.
●Both the diffuser and the strobe
have string eyelets in them.
Attach the included diffuser string
to each of these eyelets.
Using the Diffuser

E-18
CAUTION
●Never use chemicals, cosmetics, any petroleum solvents such
as paint thinner, or neutral detergent on the product. They may
deform and damage the product.
●After each use in salt water,
make sure the battery and
connector caps are attached,
then in a watertight condition
soak it sufficiently in fresh water.
●Insufficient soaking causes
damage by salt to the product.
Salty residue may be left on the product where it will crystallize
as it evaporates. Crystallized salt is hard to dissolve and difficult
to be removed once formed, and it will result in water leakage.
●After rinsing, dry the product well with a soft dry cloth, then let
the product dry in the shade, out of direct sunlight.
●Do not dry the product by heating (using a hair dryer, for example).
Heating can deform and damage the product.
●If you will not use the product for an extended period of time,
store it away from high temperatures, high humidity, direct sunlight,
or exterme cold.
●Do not store the product with naphthalence or camphor mothballs,
or in locations such as a laboratory where chemicals are used.
This environment can cause mold, rush, corrosion or malfunction.
●Always remove batteries from the product after use.
●After using the product, maintain the O-rings before storing.
Examine the O-rings before and after each dive. We recommend
early exchange of the O-rings, at least once a year.
●Every two years we recommend a complete overhaul of O-rings
regardless of the frequency in use, for the best performance of
the product.
●If you do not use the product for an extended period of time, periodic
maintenance will keep internal electronic parts from deterioration.
Once a month, install batteries and fire a test flash. While the
ready lamp is red (strobe is ready to fire), set the mode switch
to [OFF], then remove the batteries. In addition, operate all other
switches as you would in normal operation.
Maintenance and Storage

E-19
* The specifications and appearance are subject to change without notice.
* The performance values above may change depending on variables
such as frequency of use, battery consumption, recharge level, and
so on.
* The above specifications are based on normal roomtemperature (25℃/
77°F)
Specification
Controls and functions Mode switch (OFF / M / TTL)
Light level switch (FULL / 1/2)
Indicator Ready lamp (Illuminates in red when the strobe
is ready to fire.)
TTL lamp (Illuminate in green for approx. 3 sec.
after firing with TTL flash output.)
Guide number 14 (at full flash) / 7-5.8 (at 1/2 flash)
* Depending on the camera models.
* Land, ISO100/m
Beam angle 70°×53°
Color temperature 5600°K (land, at full flash)
5100°K (with Diffuser)
Battery life Alkaline：Approx. 200 flashes
Ni-MH (2700mAh)：Approx. 400 flashes
Oxyride：Approx. 230 flashes
Recycle time Alkaline：Approx. 3 sec.
Ni-MH (2700mAh)：Approx. 3 sec.
Oxyride：Approx. 3 sec.
Battery requirements 2×AA Alkaline,
2×AA Ni-MH (2700mAh),
2×AA Oxyride
Construction Acrylic resin, Polycarbonate resin
Weight 425g / 14.9oz (excl. batteries)
Weight underwater -10g / -0.35oz (incl. batteries)
Operating temperature 0℃-40℃/ 32°F-104°F
Depth rating 60m (200ft)
Dimensions （WxHxD）90×110×140mm / 3.6×4.4×5.6inch
