Seabreeze PTAC49CH3ZC Operating instructions

PTAC
Air Conditioner/Heat Pump
INSTALLATION/OWNER'S LMANUA
FOR MODELS
PTAC49CH3ZC PTAC49HP3ZC PTAC412CH3ZC
PTAC412HP3ZC PTAC415CH3ZC PTAC415HP3ZC
PTAC49CH3VC PTAC49HP3VC PTAC412CH3VC
PTAC412HP3VC PTAC415CH3VC PTAC415HP3VC
Please read carefully before installing or operating this unit. Retain this manual for future reference.
950-0253revD 07/ /201717

PROPERLY DISPOSE OF WASTE
SAFETY CONSIDERATIONS...................................................1
GENERAL INFORMATION......................................................1
UNIT FEATURES.....................................................................2
ELECTRICAL DATA.................................................................4
INSTALLATION........................................................................5
HOW TO CONNECT.................................................................8
SYSTEM CONFIGURATION...................................................9
AUXILIARY CONTROLS............................................................12
OPERATION............................................................................14
PANEL OPERATING...................................................................14
OPTIONAL REMOTE & RECEIVER....................................................16
CARE AND CLEANING............................................................17
PREVENTATIVE MAINTENANCE & HEATER SWITCHES......18
A C C E S S O R I E S . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 8
TROUBLESHOOTING.............................................................19
SCHEMATIC/FAILURE CODES FOR HEAT PUMP...................20
SCHEMATIC/FAILURE CODES FOR A/C .............................21
SPECIFICATIONS FOR 208 / 230 UNITS...................................22
SPECIFICATIONS FOR 265 / 277 UNITS...................................23
SPECIFICATIONS FOR POWER CORDS...................................24
WA R R A N T Y. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 5
TECHNICAL ASSISTANCE..............................................25
CONTENTS
Unit Inspection: After unpacking examine unit for damage
that may have occurred during shipping. Contact shipping
company immediately if damage is found.

Failure to follow this warning could result in personal injury, death and/.or property damage.
For your safety, the information in this manual must be followed to minimize the risk of fire or explosion, electric
shock, or to prevent property damage, personal injury, or loss of life.
• This unit must be properly installed in accordance with the Installation Instructions before it is used.
• Immediately repair or replace all electric service cords that have become frayed or otherwise damaged.
• Unplug or disconnect the unit at the fuse box or circuit breaker before making any repairs.
Recognize safety information. This is the safety alert symbol . When you see this symbol on
the unit and in instructions of manuals be alert to the potential for personal injury.
Understand these signal words: DANGER, WARNING, and CAUTION. These words are
used with the safety alert symbol. DANGER identifies the most serious hazards which will
result in severe personal injury or death. WARNING signifies hazards which could result in
personal injury or death. CAUTION is used to identify unsafe practices which may result in
minor personal injury, product damage, or property damage. NOTE is used to highlight
suggestions which will result in enhanced installation, reliability, or operation.
1
SAFETY CONSIDERATIONS
PERSONAL INJURY AND/OR PROPERTY DAMAGE HAZARD
NOTE: We strongly recommend that any servicing be performed by a qualified technician.
GENERAL INFORMATION
Fig. 1 – Sample Data Information Plate
!WARNING
!
See Breeze package terminal air conditioners and heat pumps provide a high standard of quality in performance,
workmanship, durability and appearance as they heat and cool the occupied air space year round.
This manual provides information for ease of installation, operation and maintenance.
All models are designed for through the wall installation. Separate installation instructions are
included with all accessory components.
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT: Save these instructions for local inspector’s use.
IMPORTANT: Observe all governing codes and ordinances.
NOTE TO INSTALLER
Be sure to leave these instructions with the owner.
NOTE TO OWNER
Keep these instructions for future reference. Be sure to write down the model and serial number of unit on
space provided on back page. The model and serial number can be located on the serial number plate
attached to unit. These numbers are required for service. (See Fig. 1.)
PACKAGE D TERMINA L AIR CONDI TIONER
Product Code: 425-0045
XYYZ
INTERNATIONAL REFRIGERATION
PRODUCTS, INC.
CAUTION: RISK OF ELECTRIC SHOCK. DISCONNECT POWER BEFORE SERVICING UNIT. WARNING: USE ON SINGLE OUTLET CIRCUIT ONLY.
Energy Verified Only
219425 SA11088
MODEL: PTAC49CH3ZC
VOLTS: 208/230VAC-1PH-60HZ
RATED COOLING: 9200/9400 BTU/HR
RATED HEATING: N/A
EER: 12.1/12.1
ELEC. HEAT: 3.45KW(2.45KW)
FULL LOAD: 15A(10.7A)
ELECTRIC SHOCK PROTECTION: CLASS I
WATERPROOFING: IP24
AIRFLOW H/L: 330/294 CFM
NOISE INDOOR/OUTDOOR: 52/61 dB(A)
MAX. HIGH SIDE PRESSURE: 638 PSIG
MAX. LOW SIDE PRESSURE: 377 PSIG
REFRIGERANT: R410A/23.6 OZ.

UNIT FEATURES
This premium unit has many features that
are different from those found on standard PTAC
models. The owner must be familiar with these
features in order to fully understand the operation and
capability of the unit.
• Intelligence – Your unit has an on board
computer that utilizes real time diagnostics to prolong
the life of the unit. There is an LED indicator on the
control board behind the front panel that will flash
an error code if the unit has detected some kind of
fault condition. In many cases the unit will
automatically clear the fault condition and continue
operating with no interruption. In some cases the
condition cannot be cleared and the unit will require service. In such cases an “Fx” failure mode will be
displayed on the digital display. For a detailed list of all error codes and “Fx” conditions, see Table 6.
Status LED Indicator Definitions for further details.
• Memory – This unit also has memory, so if power is lost all of the control settings (set point,
mode, fan speed, on/off and configuration) are retained. When power is restored the unit will
start back up in the mode and configuration it was in when power was lost.
• Sound Reduction – The unit has 2 fan motors and a tangential blower wheel for noise reduction.
The indoor fan will start a minimum of 10 seconds before the compressor. This helps reduce compressor
noise on start up.
• Random Compressor Restart - To help prevent power surges after a power outage (occurs when many
PTACs start at the same time) the compressor is equipped with a 2:45 min. to 3:15 min. random
restart delay feature. When the unit is plugged in or power has been restarted a random compressor
restart will occur.
• Compressor Protection - To prevent short cycling of the compressor and maximize it’s life, there is a
random start up delay of 3 minutes for the compressor and a minimum compressor run time of 3 minutes.
•Automatic Room Freeze Protection – Keeps the temperature in a room above freezing where pipes might
freeze. If the unit is configured for the freeze protection feature to be active, (which is the default condition),
when power is applied to the unit and the unit senses temperature below 40°F the fan motor and electric
heater are turned on and will warm the room to 50 °F. If Freeze Protection is not required change the
configuration switch to turn the feature off (see section on unit configuration).
• Automatic Defrost Protection (for heat pump models only) – When the outdoor temperature gets
to approx. 35 °F and the unit can no longer effectively heat with the compressor, the unit will
automatically switch to electric heating. The unit will then heat with electric heat until the outside
temperature rises to approx. 40 °F then compressor can be used again.
• Automatic Quick Warm-up (for heat pump models only) - If the room temperature falls to 5 °F
below the set point temperature the reverse cycle heat is shut off and the electric strip heat is turned on
for one cycle until heating set point is satisfied.
If the room temperature is less than 5°F from set point the compressor will be turned on in the heating function and
run until the room temperature is satisfied.
The electric strip heaters and the compressor will not operate simultaneously.
•LED Indicator’s and Buttons - The touch pad has buttons for MODE, FAN SPEED, ON/OFF,
SET POINT WARMER and SET POINT COOLER. It also has LEDs that correspond to the MODE,
FAN SPEED and SET POINT operation, to indicate the unit’s status. The LEDs below the MODE button,
FAN, COOL, and HEAT, indicate what operating mode is active. The LEDs below the FAN button, LOW,
MED and HI, indicate the fan speed that is selected. The LED located in the lower right corner is the unit
On/Off status LED. If the unit is in ON mode the LED will be green. If the unit is OFF, the LED will be red.
• Configure Fan to Optimize Selected Application - Unit can be optimized to selected application by
configuring the fan to run in continuous mode or cycle on and off with the compressor and electric
heater (can be different for both heating and cooling modes). In cycle mode, fan will continue to run after
compressor or electric heater stops in order to disperse any residual heat or cool left on the coil.
2
Fig. 2

UNIT FEATURES CONTINUED
• Unit Configuration – There are many different configuration possibilities, through both dip switches
and the digital keypad. This allows you to configure the unit for your exact application. See section on
unit configuration for more details. Following are the configuration selections that have not been previously
mentioned:
• °F or °C – The unit can display in either °F or °C.
• Indoor Temperature Sensor Biasing – Optimize the room temperature sensor reading to your exact
application (one for cooling and another for heating).
• Emergency Heat (for heat pump only) – Disables the compressor during heating mode operation and heats
with electric heat only.
• Display Set Point or Room Temperature - The unit can be configured to display the room temperature
or set point only during heating and cooling modes. See section on unit configuration for more details.
• Limit the Set Point Range - The unit can be configured to limit the controlling set point range. The
display will always show the complete set point range but the controlling set point will be limited to the
configured minimum and maximum set point selected. See section on unit configuration for more details.
• Energy Management – Sometimes known as Front Desk Control. An input is provided so that the
unit can be manually disabled from a different location. If the unit detects 24 VAC on this input it will
turn itself off. If no voltage is detected on the input the unit will run normally.
• Wall Thermostat Control - An external wall thermostat can be connected to the unit. If connected the
unit must be configured to disable the keypad. See section on wired inputs and unit configuration for
more details.
• Remote Control - Remote control is available by adding a receiver module to the unit. See the 950-0254
installation manual packaged with the remote control and receiver module.
3

ELECTRICAL DATA
POWER CONNECTION OPTIONS:
The unit ships with a 3KW power cord. Optional power cords 2KW or 5KW are available.
CAUTION: When using cat. no. 2KWPC / 2KWPC265 use a 15 amp breaker, 3KWPC / 3KWPC265
uses a 20 amp breaker and Cat. no. 5KWPC / 5KWPC265 will require a 30 amp breaker.
IMPORTANT: For 265/277 VAC units, if power cord accessory option is selected, the cord is only
18" long and must plug into the accessory electrical 265/277 VAC subbase.
Be sure that your outlet matches the appropriate blade configuration of the plug and that it is within reach of the
service cord.
All wiring, including installation of the receptacle must be in accordance with the NEC and local codes,
ordinances and regulations. National codes require the use of an arc fault or leakage current detection device on
all 208/230 VAC power cords. Be sure to select the correct cord for your installation.
ALL UNITS
Wire Size
Use recommended wire size given in Table 1. Install only on a single branch circuit. The PTAC unit must be the
only device connected to the single branch circuit. All wiring must comply with local and national codes.
NOTE: Use copper conductors only.
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury, death and/or property
damage. DO NOT alter cord or plug or use an extension cord.
WARNING
NAMEPLATE AMPS AWG WIRE SIZES†
Table 1 - SUGGESTED BRANCH CIRCUIT WIRE SIZES*
7.0 to 12
12.1 to 16
16.1 to 24
14
12
10
LEGEND
AWG - American Wire Gauge
* Single circuit from main box.
* Based on copper wire at 140°F (60 °C) temperature rating.
Grounding
For safety and protection, the unit is grounded through the service cord plug or through separate ground
wire provided on hard wired units. Be sure that the branch circuit or general purpose outlet is grounded.
VOLTAGE SUPPLY
Check voltage supply at outlet. For satisfactory results the voltage range must always be within the
ranges found on the data information plate.
Cord Connected Units
The 250 VAC field supplied outlet must match the plug for the standard 208/230 VAC units and be within reach
of the service cord. The standard cord-connected 265/277 VAC units require an accessory electrical subbase for
operation. Refer to Table 2 for proper receptacle and fuse type.
Power Cord Protection
The power cord for 208/230 (250) VAC units are equipped with a LCDI safety feature that provides fire
protection. Power is automatically disconnected when an unsafe condition is detected. Power to the unit can be
restored by pressing the reset button on plug head. Upon completion of installation an operational check should
be performed on the LCDI plug. See instructions on plug. Always use proper Sea Breeze replacement power cord.
NOTE: The 265/277 VAC units do not incorporate this feature as they require us of the electrical subbase
accessory.
4
Table 2 - RECEPTACLES AND FUSE TYPES
15 20 30 15 20 30
250 VAC 250 VAC 250 VAC 265/277 VAC 265/277 VAC 265/277 VAC
15 AMP 20 AMP 30 AMP 15 AMP 20 AMP 30 AMP
RECEPTACLE
(6-15R) / (7-15P) - 15 amps
(6-20R) / (7-20P) - 20 amps
(6-30R) / (7-30P) - 30 amps
AMPS
RATED VOLTS
TIME DELAY TYPE FUSE
or CIRCUIT BREAKER
!

INSTALLATION
Proper installation is the responsibility of the installer. Product failure due to improper installation is not
covered under warranty.
CHASSIS INSTALLATION
Units are shipped without a sleeve. In applications where unit is a replacement, it is recommended that a
Sea Breeze sleeve be used.
The unit will fit General Electric, Amana, Trane, and Friedrich sleeves/grilles (be sure outdoor
grille is installed on the sleeve). See Table 3 for details.
For any sleeve retrofit applications, be sure that the foam seals (factory installed on the tube sheets)
provide a good seal between the grille and outdoor coil tube sheets. These foam seals provide a barrier to
separate outdoor coil leaving air from mixing with the outdoor incoming air (known as air recirculation).
!
CAUTION
UNIT DAMAGE AND/OR OPERATION HAZARD
Failure to follow this caution may result in equipment
damage or improper operation of unit.
For retrofit applications foam seals on outdoor coil tube
sheets must make a seal between the coil and the grill or
loss of performance and premature damage to major
components may result.
Manufacturer Wall Sleeve Part Number
Table 3 - Retrofit Wall Sleeves
* FR - SLEEVE - EXT accessory is required for retrofit into Friedrich
(T - Series) wall sleeves.
5
Sea Breeze Cat. No. 4250019 - Wall Sleeve
Fig. 4 - Unit Components
COIL TUBE
SHEETS
OUTDOOR
ORIFICE
WIRE SCREEN
DISCHARGE
GRILLE
INDOOR-AIR
INLET
FILTERS
FRONT
PANEL INDOOR
COIL
BASEPAN ACCESSORY
WALL
SLEEVE
ACCESSORY
OUTDOOR
GRILLE

RETROFIT SLEEVE PREPARATION
IMPORTANT: Inspect wall sleeve thoroughly prior to installation. Manufacturer does not
assume responsibility for costs or damages due to defects in sleeve or improper installation.
Remove any existing foam baffles that are installed on competitive outdoor grille, if present. See Fig. 5.
GE Sleeves Only
GE Metal Wall Sleeve - Remove metal clip on mounting rail located on left, inside bottom, of metal
sleeve and discard. See Fig. 6.
GE Plastic Sleeve - Remove bottom seal from plastic sleeve. See Fig. 7.
INSTALLATION OF A CARRIER WALL
SLEEVE USING A NON CARRIER
GRILLE
This application has become more common due to pre-manufactured windows with built-in grilles or
renovations where a Carrier sleeve is used with an existing non-Carrier grille.
Use of a Carrier wall sleeve with a non-Carrier grille requires installation of an Accessory Baffle Kit (see
Fig. 8), which ensures a good seal between the unit and exterior grille to prevent air recirculation. Air
recirculation is a large contributor to performance loss and premature damage to major components.
WARNING
!
ELECTRICAL SHOCK HAZARD
Failure to follow this warning could result in personal injury
or death.
Disconnect all power to unit to avoid possible electrical shock
during installation.
6
BAFFLES
Fig. 5 - Remove Existing Outdoor Grille Baffles on
Competitive Grille
Fig. 7 - Remove Bottom Seal From GE Plastic Sleeve
Fig. 6 - Remove Metal Clip on GE Metal Sleeve
Fig. 8 - Accessory Baffle Kit
Note: Contact with your unit supplier to get the kit and
it may be different from the shape shown above.

INSTALLING UNIT INTO WALL SLEEVE
1. Carefully remove shipping tape from the front panel and vent door. See Fig. 9.
2. Remove shipping screw from the vent door, if present. See Fig. 10.
3. Remove front panel. See Fig. 11.
4. Lift unit level and slide unit into wall sleeve until foam seal rests firmly against front of wall sleeve.
5. Secure with four screws (supplied) through the unit flange holes. See Fig. 12.
6. Reinstall front panel. See Fig. 13.
UNIT DAMAGE HAZARD
Failure to follow this caution may result in equipment
damage or improper operation.
Failure to remove shipping tape and screw will prevent
fresh air vent door from opening and may result in damage
to vent door cable
!
CAUTION
Pull out at the bottom to release it
from the tabs. (1) Then lift up. (2)
Fig. 11 - Removing Front Panel
Fig. 9 - Shipping Tape Location.
Fig. 12 - Securing Unit
Remove
shipping
screw if
present.
Fig. 10 - Shipping Screw Location. Fig. 13 - Replacing Front Panel.
Place tabs over top rail (1).
Push inward at bottom until
panel snaps into place (2).
7
Shipping
tape

HOW TO CONNECT
IMPORTANT: Please read following electrical safety data carefully.
ELECTRICAL SHOCK AND/OR UNIT OPERATION AND DAMAGE HAZARD
Failure to follow this warning could result in personal injury or death and/or unit operation and damage.
• Follow the National Electrical Code (NEC) or local codes and ordinances.
• For personal safety, this unit MUST BE properly grounded.
• Protective devices (fuses or circuit breakers) acceptable for unit installations are specified on the nameplate of each unit.
• Do not use an extension cord with this unit.
• Aluminum building wiring may present special problems -- consult a qualified electrician.
• When unit is in STOP position, there is still voltage to electrical controls.
• Disconnect power to unit before servicing by:
1. Removing power cord (if it has one) from wall receptacle.
2. Removing branch circuit fuses or turning circuit breakers off at panel.
1. Remove front panel. See Fig. 11.
2. Remove junction box.
• Remove junction box cover by removing three screws from front. Remove junction box by taking
out top, rear and side screws. See Fig. 14.
3. Connect accessory power supply cord or hard wire connector to unit connector. See Fig. 15.
• Units must be installed with the appropriate power supply kit. See Table 4 POWER CONNECTION
CHART. These connections must be followed.
4. Reinstall junction box and cover.
• Use wire clamp to attach power cord to base pan. Secure with screws (included) See Fig. 16.
• Replace junction box and cover with screws removed from Step 2. Tighten securely.
5. Replace front panel. See Fig. 13.
6. Connect power to unit.
WARNING
!
Unit connector
Junction box cover Junction box
Fig. 14 – Junction Box Location
Accessory
Power Supply Cord
or Hard Wire
Fig. 15 – Power Connection
Wire clamp
Fig. 16 – Wire Clamp
Table 4—POWER CONNECTION CHART
8
Unit Model 2KWPC230
(2450W) 15A
3KWPC230
(3450W) 20A
5KWPC230
(5000W) 30A
PTAC49CH3ZC X X NOT USED
PTAC49HP3ZC X X NOT USED
PTAC412CH3ZC X X X
PTAC412HP3ZC X X X
PTAC415CH3ZC X X X
PTAC415HP3ZC X X X
Unit Model 2KWPC277
(2450W) 15A
3KWPC277
(3450W) 20A
5KWPC277
(5000W) 30A
PTAC49CH3VC X X NOT USED
PTAC49HP3VC X X NOT USED
PTAC412CH3VC X X X
PTAC412HP3VC X X X
PTAC415CH3VC X X X
PTAC415HP3VC X X X
Units can be used with the following power cords.
CAUTION - DO NOT modify or substitute power cord. All units
are shipped with 3KW power cord.

Fig. 19 Adjusting Louvers
9
Air discharge upward
Fig. 18 Backside of Front Panel
Louver screws
Louver screws
Air discharge outward (Default)
Fig. 17 Ventilation Control Location
Vent Control (Pull
lever through label
to operate.)
SYSTEM CONFIGURATION
VENTILATION CONTROL
The ventilation control lever is located at left side of
unit, behind front panel.
NOTE: The vent door shipping hardware must be
removed before using vent control lever.
See installation instructions.
When set to CLOSE only the air inside the room is
circulated and filtered.
When set to OPEN some outdoor air will be drawn
into the room. This reduces heating or cooling
efficiency.
Energy Tip: Keep the vent control in the CLOSE position. Room
air will be filtered and recirculated.
ADJUSTING AIR DIRECTION
To adjust air direction:
1. Remove front panel. See Fig. 11.
2. Remove louver screws that hold louver insert in place (from back side of front panel). See Fig. 18.
3. Turn louver insert and rotate 180_. See Fig. 19.
4. Replace louver insert.
5. Replace screws and front panel.

DIP SWITCHES
Auxiliary dip switch controls are located behind front
panel, through an opening below the control panel.
To access, remove front panel. See Fig. 11.
Dip switches are accessible without opening the
control box. Unit must be powered OFF to
effectively change their status.
Factory settings for dip switches will be in the
DOWN position. See Table 5 -- Dip Switch
Functions for functions of each dip switch position.
Electric Heating Only / Emergency Heat (For Heat Pump Units Only)
This setting is typically used for Emergency Heating.
Wall Thermostat Enable
A wired wall thermostat can be connected to the unit. If it is this dip switch must be moved to the wall
thermostat enable position before the wall thermostat will begin control.
Heat and Cool Fan CON/CYC Dip switches
Allows the fan to operate in continuous or cycle modes while the unit is in heating or cooling mode
(continuous or cycle):
CON (Continuous)
Allows fan to run continuously, circulating air even when the temperature setting has been satisfied. This switch helps to
maintain the room temperature closer to the thermostat setting.
CYC (Cycle)
This setting allows the fan to cycle on and off with the compressor or electric heater. The fan stops a short time after
the temperature setting is satisfied.
Set point Temperature Limits
Provides a restricted range of temperature control.
Room Freeze Protection
If unit senses a room temperature below 40°F, the fan motor and electric strip heat will turn on and warm
the room to 50°F. The fan stops a short time after the temperature is satisfied.
UP
Dow
No. UP DOWN REMARKS DEFAULT
1 Electric Heat Only Heat Pump/Electric Heat For Heat Pump unit only. DOWN
2 Wall Thermostat Enable Control Panel Enable DOWN
3 Fan Runs Continuous for Heating Fan Cycles for Heating DOWN
4 Fan Cycles for Cooling Fan Runs Continuous for Cooling DOWN
6*5
6UP*5UP
68 --- 75 °F
20 --- 24 °C
6UP*5DOWN
63 --- 80 °F
18 --- 28 °C
6DOWN*5UP
65 --- 78 °F
19 --- 26 °C
6DOWN*5DOWN
61 --- 86 °F
16 --- 30 °C
(full range)
Two configurations (5*6)
combine to select set point
range.
When set point limit set, dis-
play always shows full
range.
DOWN*DOWN
61 --- 86 °F
16 --- 30 °C
7 Freeze Guard Disable Freeze Guard Enable DOWN
Freeze guard
Setpoint Limit 2
Setpoint Limit 1
Fan CON/CYC for cooling
Fan CON/CYC for heating
Wall Thermostat enable
Electric heat only (for Heat Pumps)
10
Dip Switches
Fig. 20 Dip Switch Location on Unit
Fig. 21 Dip Switches
Table 5 Dip Switch Functions

KEYPAD CONFIGURATION
Allows further configuration of system to desired application. Changes do not take effect until power is
cycled on the unit.
To enter Keypad configuration
Cycle power to unit. Press and hold the FAN SPEED button and the COOLER button for 5 continuous
seconds, within 30 seconds of the unit being powered up. If the unit has had power for more than 30
continuous seconds keypad configuration cannot be entered. When keypad configuration mode is first
entered it will default to Fahrenheit/ Celsius Display Mode (F/C).
To scroll through the Keypad Configuration Options
Press and release the Fan Speed button. The stored value will be displayed.
To modify configuration settings
Press and release the Set Point Up or Set Point Down buttons.
To exit Keypad Configuration
Keypad Configuration will end on its own 30 seconds after the last button press or when the MODE button
on the keypad is pressed.
Fahrenheit/ Celsius Display Switch:
Change between degrees Fahrenheit and Celsius on the display. An “F” indicates Fahrenheit display and
‘C’ indicates Celsius. Default is degrees “F”.
Indoor Air Temperature Sensor Biasing for Cooling mode:
Sometimes known as an anticipator the air temperature sensor bias is used to adjust the room air temperature
reading when in cooling mode. (Not normally required.)
Indoor Air Temperature Sensor Biasing for Heating mode:
Sometimes known as an anticipator the air temperature sensor bias is used to adjust the room air
temperature reading when in heating mode. (Not normally required.)
Indoor Temperature Display:
Change between showing set point only on the display during heating and cooling modes “SP” or displaying
room temperature during heating and cooling modes “AA”. “SP” mode is the default mode.
• If “SP” is selected, only the set point will be displayed during heating and cooling modes, regardless of what
the real temperature is in the room.
• If “AA” mode is selected, the room temperature will be displayed during heating, cooling and fan only modes.
• If the mode button has been changed to either heating or cooling modes, set point will be displayed
for 10 seconds. After 10 seconds the room temperature will again be displayed.
• If the on/off button is pressed (when the unit is off) and the last mode was either cooling or heating mode the set
point will be displayed for 10 seconds before displaying room temperature.
• During heating and cooling modes, if either the up or down set point key is depressed, the
display will show the set point for 10 seconds after the last up or down key has been pressed. The room
temperature will be displayed again.:
Switch Emergency Auto Cooling Allowed and Emergency Auto Cooling Rejected:
Press WARMER or COOLER to switch between the display of Emergency Auto Cooling Allowed and
Emergency Auto Cooling Rejected.
Emergency Auto Cooling Allowed: the diode displays CA.
Emergency Auto Cooling Rejected: the diode displays Cd.
Room temperature will be displayed again.
11

AUXILIARY CONTROLS
WALL THERMOSTAT TERMINAL
NOTE: Sea Breeze thermostats are recommended.
IMPORTANT: Only trained qualified personnel should access electrical panel on unit and install electrical accessories.
Please contact your local electrical contractor or distributor for assistance.
Thermostat Wire Routing
Thermostat wire is field supplied. Recommended wire gauge is 18 to 20 gauge solid thermostat wire.
NOTE: It is recommended that extra wires are run to unit in case any are damaged during installation.
Thermostat wire should always be routed around or under, NEVER through the wall sleeve. The wire should then be routed
behind the front panel to the easily accessible terminal connector.
Wiring Thermostat to Unit
Wire wall thermostat input as defined in Fig. 25.
NOTE: Terminal connector can be removed and replaced to
simplify the wiring.
NOTE: For heat pump models, anytime there is a second-stage
call for heating from the wall thermostat, the unit will automatically
switch over to electric heating.
Install Thermostat wiring.
1. Check to be sure power to unit is disconnected.
2. Pull terminal connector to remove NOTE: Terminal connector can be removed and replaced to simplify thermostat wiring.
3. Connect wires from the thermostat to terminals on unit terminal connector.
4. Reinstall terminal connector.
5. Ensure that unit is configured for wall thermostat enable.
6. Restore power to unit.
NOTE: Refer to thermostat installation instructions for details on installing wall thermostat.
NOTE: For thermostats that have only one fan speed output (on or auto ) the fan speed is determined by how the terminal
connector is wired. If low fan is desired, wire the G output from the thermostat to GH on the unit’s terminal block. If HIGH
fan is desired, wire the G output from the thermostat to GH on the unit's terminal block.
NOTE: After proper installation, if your thermostat is not working properly, refer to the Troubleshooting section.
Fig. 23 - Terminal Connector Removal and Replacement
12
THERMOSTAT WIRE ROUNTING
(UNDER SLEEVE, BEHIND FRONT PANEL)
R W Y O Gh Gl C
Fig. 22 - Proper Wire Routing Beneath Unit

TYPICAL WALL
THERMOSTAT
Energy
Management
24 VAC Input
Common
R
W
Y
O SEE NOTE 1
GH
GL
C SEE NOTE 2
Notes:
1. Use terminal "O" for heat pump connection only.
2. Terminal "C" (common) is typically only required
for digital thermostats.
TERMINAL DESIGNATION
CCommon
GL Low Fan
GH High Fan
OReversing Valve
YCompressor
WElectric Heat
R24 VAC
UNIT DAMAGE HAZARD
Failure to follow this caution may result in
equipment damage or improper operation.
Improper wiring may damage unit electronics.
CAUTION
!
ENERGY MANAGEMENT INPUT (FRONT DESK CONTROL)
The controller can handle a switch signal from remote energy management input, called EM signal or
front desk control Input must be 24VAC. If the system receives a 24 VAC signal, it will turn unit off.
Otherwise the unit runs in normal mode. This function will be disabled under Freeze Guard protection.
See Fig. 24 and Fig. 25 for terminal connections.
INTELLIGENT SELF-CHECKING CONTROL
Your PTAC has a computer board that continuously monitors key components of the unit to ensure they are
operating properly. Under normal operation unit status indicator (STATUS, on main PCB) light is steadily
ON.
lf there is a major problem the unit will shut down and display a diagnostic failure code on the unit 's
display. If it is only a minor failure and unit will try to correct the fault. The diagnostic code will be flashed
on the status LED that can easily be seen when the front panel is removed (See Fig. 24). Failure STATUS
codes are defined in the table below.
13
Status LED
Dip Switches
Wall thermostat terminal
connections (removable)
Energy management
terminal (removable)
Fig. 24 - Terminal Connector and LED Location Fig. 25 - Thermostat Wiring Connections
NOTE: Any illegal input combinations will be captured as thermostat
wiring failures and will light the STATUS LED indicator on the
main board (See Intelligent Self - Checking Control section).
Remove front panel to gain access to STATUS LED,
TERMINAL STRIP and DIP SWITCHES.

OPERATION
IMPORTANT: When unit is first started, high humidity conditions can cause condensation to form on
discharge grille. Keep doors and windows closed. Room humidity will decrease and moisture will
evaporate.
PANEL OPERATING
It displays the function immediately while press the button, and the corresponding function will be started
up in 2 seconds.
ABOUT THE CONTROLS ON YOUR UNIT
NOTE: In case of a power failure, the unit will retain the last programmed settings and will
restart to those settings
.
1. TEMP CONTROL
Temp Control is used to maintain room temperature. Compressor will cycle on and off to keep room at the
requested level of comfort.
COOLER - Lowers temperature. (Min. temperature setting is 61 °F/16 °C)
WARMER - Raises temperature. (Max. temperature setting is 86 °F/30 °C)
2. FAN SPEED, MODE & ON/OFF
FAN SPEED - Set fan operation for High, Low, or AUTO speed.
MODE - Dry - Set unit to dehumidifying.
MODE - COOL - Set unit to cooling.
MODE - HEAT - Set unit heating.
NOTE: If unit is a heat pump raising the heat setting 5°F will cause unit to use its electric heating
elements for one cycle in order to reach the new requested temperature quickly.
MODE - FAN - For fan only operation.
ON/OFF - Turns the unit on or off.
NOTE: The LED above the ON/OFF button will be green when unit is ON and red when the unit is OFF.
Fig. 26 – PTAC CONTROL PANEL
See settings for
dip switches 5 &6.
}
14

1. TEMP CONTROL
Temp Control is used to maintain room temperature. Compressor will cycle on and off to keep room at the
requested level of comfort.
COOLER ▼- Lowers temperature. (Min. temperature setting is 61 °F/16 °C)
WARMER ▲- Raises temperature. (Max. temperature setting is 86 °F/30 °C)
2. FAN SPEED, MODE & ON/OFF
FAN SPEED - Set fan operation for High, Low or Auto speed.
NOTE: In Auto setting, the indoor fan runs in different speed according to modes or room temperature to achieve
higher comfort.
MODE - DRY - Set point temperature can be set as Cooling. The FAN runs at LOW speed only (Fan speed
cannot be changed).
MODE - COOL - Set unit to cooling.
MODE - FAN - For fan only operation.
MODE - HEAT - Set unit heating.
NOTE: If unit is a heat pump raising the heat setting 5°F will cause unit to use its electric heating
elements for one cycle in order to reach the new requested temperature quickly.
ON/OFF - Turns the unit on or off.
NOTE: 1. Press ▲ / ▼ button while unit is OFF, the diode display will show indoor temperature for 15 seconds
and then turn off. 2. Press MODE button while unit is OFF, the unit will restart automatically.
The LED above the ON/OFF button will be green when unit is ON.
All other LEDs will be off when unit is set to OFF mode.
3. TIMER FUNCTION
Timer function can be set either by buttons on the panel or by remote control.
1) Timer ON: When the unit is off, Timer ON can be set. Setting range is 0.5-24 hours. When set time is reached,
the unit will operate according to the set mode.
2) Timer OFF: When the unit is on, Timer OFF can be set. Setting range is 0.5-24 hours. When set time is
reached, the unit will stop operating.
3) Timer Setting: Press TIMER button to set timer function and timer icon will be on the remote and the LED
lamp will illuminate on the panel . Diode display will shown selected time which can be adjusted by pressing
▲ / ▼ buttons. The timer function will be activated and TIMER LED will be on after 5 seconds later of the
setting. If “--” is displayed, that means the timer setting is deactivated.
4) Timer Preview: When timer function has been set, press TIMER button to preview the remaining time of
timer.
5) If Time function has been set, turning ON/OFF the unit or power failure will cancel timer setting.
4. SLEEP FUNCTION
This function can only be set by remote control. It will bring a more comfortable sleeping environment. This
function is not available under FAN mode.
5. EMERGENCY COOLING OPERATION
Emergency cooling, subject to your choice - allowed or rejected. See page 11 for detail setting and display.
When the room temperature ≥86 °F/30 °C, the unit will start cooling automatically. When the room temperature
reaches 80 °F/27 °C, the unit will stop operating.
NOTE: Power remains connected to unit.
15

16
OPTIONAL REMOTE CONTROL AND RECEIVER MODULE
This PTAC unit can be operated with a remote control. The item number is 425-0057. It includes a remote
control and receiver.
The installation procedure and operating functions are included with the remote control / receiver module.
NOTE: Be sure there is no obstruction between receiver and remote control. Do not drop or throw the
remote control. Do not let any liquid in the remote control and put the remote control directly under the
sunlight or any place where is very hot.
REMOTE CONTROL
RECEIVER MODULE
KEY PAD FUNCTIONS
ON/OFF – Turns unit on or off.
• MODE – Select mode, Cool, Dry, Fan, Heat.
• - – Lower set point.
• + – Raise set point.
• FAN – Set fan speed, High, Low, Auto.
• SWING – Set louver swing.
• TIMER – Set timer on/off time.
• SLEEP – Toggle on/off SLEEP mode.
• Backlight – Turns Remote backlight on or off.
• LOCK KEY PAD – No changes can be made.
• º F or º C – Select º F or º C
Not All Features Are Activated
Please check manual 950-0254 for detail.
•
Mounting Holes
and Connector
Receiver Mounting Position

CARE AND CLEANING
FRONT PANEL AND CASE
Turn unit off and disconnect power supply.
To clean, use water and a mild detergent. DO NOT use bleach or abrasives. Some commercial cleaners may
damage the plastic parts.
OUTDOOR COIL
Coil on outdoor side of unit should be checked regularly. Unit will need to be removed to inspect dirt build--up
that will occur on the inside of the coil. If clogged with dirt or soot, coil should be professionally cleaned.
NOTE: Never use a high pressure spray on coil.
UNIT DAMAGE HAZARD
Failure to follow this caution may result in equipment
damage or improper operation.
Airflow restriction may cause damage to the unit.
Coils
Grille
Clean inside and outside of outdoor coils regularly.
Fig. 27 – Outdoor Coil
BASE PAN
In some installations, dirt or other debris may be blown into unit from outside and settle in base pan (bottom of
unit). Check base pan periodically and clean, if necessary.
UNIT DAMAGE HAZARD
Failure to follow this caution may result in equipment damage or improper operation.
Do not operate unit without filters in place. If a filter becomes torn or damaged, it should be replaced immediately.
Operating without filters in place or with damaged filters will allow dirt and dust to reach indoor coil and reduce
cooling, heating, airflow and efficiency of unit. Airflow restriction may cause damage to unit.
!
The most important thing you can do to maintain unit efficiency is to clean the filters at least every 30 days
(or sooner depending on conditions). Clogged filters reduce cooling, heating and airflow.
Keeping filters clean will:
• Decrease cost of operation.
• Save energy.
• Prevent clogged indoor coil.
• Reduce risk of premature component failure.
To Clean Air Filters:
• Vacuum off heavy soil.
• Run water through filters.
• Dry thoroughly before replacing.
Dirty filter-
Needs cleaning
Clogged filter -
Greatly reduces cooling,
heating and airflow.
CAUTION
17
2 Air filters
Pull up Push down
Removing Air Filter Replacing Air Filter
!
CAUTION
AIR FILTERS
IMPORTANT: TURN UNIT OFF BEFORE CLEANING
Fig. 28 – Identifying Clogged Filter
Fig. 28 – Removing and Replacing Air Filter

PREVENTATIVE MAINTENANCE
Preventative maintenance is essential to proper unit operation, efficiency and longevity.
To ensure equipment operates properly, it must be properlymaintained. Equipment operation should be checked
and verified several times during each year. During regular unit inspection and maintenance, follow the
guidelines below:
• Clean both sides of outdoor coil. (Never use high pressure spray on coils.)
• Clean basepan and outdoor vent filter.
• Clean outdoor orifice and fan.
• Clean indoor coil. (Never use high pressure spray on coils.)
• Clean indoor fan, wire screen and front panel.
• Clean or install new indoor--air inlet filter(s).
• Clean wall sleeve and outdoor grille.
• Inspect cord and receptacle.
• Secure electrical connections.
• Ensure front panel is properly mounted and not damaged.
• Ensure wall sleeve is installed properly.
• Ensure heat and cool cycles operate properly.
Note: The Electric heater has two limit switches.
1) The lower limit switch will turn the heaters off at 140°F and turn the heater on
when the heater temperature is below 140°F.
2) The second limit switch will turn the heaters of at 176°F. This switch is not re-
setable. It is a failsafe switch - the heater assembly must be replaced.
ACCESSORIES
Additional accessories for the Sea Breeze PTAC include:
CAT. NO. DESCRIPTION
2KWPC230 PTAC Power Cord, 15 amp, for 2KW heater, LCDI plug.
3KWPC230 PTAC Power Cord, 20 amp, for 3KW heater, LCDI plug. (Unit ships with a 3KW power cord.)
5KWPC230 PTAC Power Cord, 30 amp, for 5KW heater, LCDI plug.
4250024 Outdoor grill, stamped aluminum, standard grill.
4250025 Outdoor grill, clear anodized, architectural grill.
4250026 Outdoor grill, powder coated dark bronze, architectural grill.
4250027 Outdoor grill, powder coated soft dove, architectural grill.
4250028 Drain kit.
4250029 Leveling legs.
425-0057 Remote Control & Receiver Module.
2KWPC277 PTAC Power Cord, 15 amp, for 2KW heater of 265/277 VAC units
3KWPC277 PTAC Power Cord, 20 amp, for 3KW heater of 265/277 VAC units. (Unit ships with a 3KW
power cord.)
5KWPC277 PTAC Power Cord, 30 amp, for 5KW heater of 265/277 VAC units.
18
