SealerSales SS Series User manual

Sealer Sales | www.sealersales.com | Tel: [phone] | E-mail: [e-mail]
SS-Series L-Bar Sealers
Model: SS-1622HK
Distributed By:
Version 1.0
Last Updated: 2/20/20

Sealer Sales | www.sealersales.com | Tel: [phone] | E-mail: [e-mail]
Copyright © 2019 by Stephanie Hwang
All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any means, including photocopying,
recording, or other electronic or mechanical methods, without the prior written permission of the publisher, except in the case of brief quotations
embodied in critical reviews and certain other noncommercial uses permitted by copyright law. For permission requests, write to the publisher,
addressed “Attention: Permissions Coordinator,” at the address below.
Sealer Sales, Inc.
8820 Baird Avenue
Northridge, Ca 91324
www.sealersales.com
Printed in the United States of America

Sealer Sales Page 2
SS-1622HK Sealer Service Manual
IMPORTANT - PLEASE READ THIS CAREFULLY
The development of a good safety program, that is rigidly
enforced, is absolutely imperative when involved in the operation of
industrial equipment. Our machinery is well designed and includes
extremely important safety features. The part you the user play
through proper installation and maintenance procedures is of far
greater significance than our designs. Only properly trained
individuals following rigidly enforced safety rules, as recommended
by A.N.S.I. and O.S.H.A., should be allowed to operate these
machines.

Sealer Sales Page 3
SS-1622HK Sealer Service Manual
TABLE OF CONTENTS
___________________________________________________________
Preface
Unpacking 4-7
Warranty Notice 8
Warranty 9-10
Warranty Exceptions 11
Warnings 12-14
Sealer Section
Description and Specifications 15
Installation and Basic Set-Up 16-22
Film Threading Diagram 23
Sequence of Operation 24-27
Temperature Control Adjustment 28
Troubleshooting 29-46
Maintenance 47-58
Electrical Schematic 59
Electrical Panel Diagram 60
Parts Nomenclature 61
Replacement Parts List 62-64
Spare Parts List 65

Sealer Sales Page 4
SS-1622HK Sealer Service Manual
UNPACKING
UNPACKING
THOROUGHLY INSPECT EQUIPMENT UPON ARRIVAL.
If goods are received short or in a damaged condition, it
is important that you notify the carrier’s driver before he leaves
your company and insist on anotation of the loss or damage
across the face of the freight bill. Unless this is done, no claim can
be enforced against the transportation company.
If concealed loss or damage is discovered, notify the
carrier at once and insist on an inspection. This is absolutely
necessary! Aconcealed damage report must be made no later than
ten (10) days from the date the shipment was delivered. Unless
you do this, the carrier will not consider any claim for loss or
damage. The carrier’s agent will then make an inspection and grant
aconcealed damage notation. If you give the transportation
company aclear receipt for the goods that have been damaged or
lost in transit, you do so at your own risk and expense.
All claims must be filed within 10 days of delivery date or
carrier will not accept them.
Sealer Sales is willing to assist in every possible
manner to collect claims for loss or damage; however, this does
not hold Sealer Sales responsible for collection on claims or
replacement of material.
Do not throw away damaged pallets or box until
freight inspection has occurred.

Sealer Sales Page 5
SS-1622HK Sealer Service Manual
UNPACKING
Your new L-Bar Sealer comes bolted to a pallet and
has a tri-walled corrugated box strapped to the pallet to protect it.
1. If your machine does not arrive in this condition, write on
shipping paperwork that outside of box is damaged.
Concealed damage may have occurred.
2. Remove stretch film and Poly Bag covering machine.

Sealer Sales Page 6
SS-1622HK Sealer Service Manual
UNPACKING
3. Remove film rack from under L-Bar Sealer.
4. Check film rack. You should have
(a) (1) Film Rack
(b) (4) mounting bolts
(c) (1) adjustable knob
(d) (2) film roll guides

Sealer Sales Page 7
SS-1622HK Sealer Service Manual
UNPACKING
5. Mount film rack roll guides as shown. See page 17 for Film
Rack installation.
6. Remove bolts holding L-Bar Sealer to pallet using 13-mm
wrench.
7. Place forks of forklift under center of lower support bar of
L’Sealer frame and lift off pallet.
8. Place in desired location and use locking casters to set in place.

Sealer Sales Page 8
SS-1622HK Sealer Service Manual
WARRANTY NOTICES
IMPORTANT WARRANTY NOTICES
OPERATING AND MAINTENANCE MANUAL
The operating and maintenance manual has been
carefully prepared to provide the user with all the information needed
to properly install, operate, and maintain your Preferred Packaging
equipment.
Please read this manual carefully and refer to it for
information on the care and use of your Preferred Packaging
equipment. It is recommended that additional copies be ordered for
use by production, maintenance, and supervisory personnel.
Although the design of this equipment incorporates safeguards to
protect personnel, care should be used in operating, adjusting, and
servicing.
Attention is directed to the warranty that accompanies all
your equipment. The terms and conditions of this warranty apply
only to unmodified units. Any unauthorized modifications to
the equipment automatically voids this warranty.

Sealer Sales Page 9
SS-1622HK Sealer Service Manual
WARRANTY
Sealer Sales
WARRANTY
Sealer Sales, Inc. warrants each new product
manufactured to be free from defects in material and
workmanship for a period of (1) year from date of shipment by
Sealer Sales.
This warranty is not transferable with any subsequent resale.
Defective parts under warranty must be returned to Sealer
Sales freight prepaid. Sealer Sales’sole obligation and purchaser’s
sole remedy in the event of a warranty dispute shall be, at
Sealer Sales' option , to repair or replace the part in question.
Labor incurred in removing or installing the defective part is
not covered by this warranty. Prior to returning any parts for
any reason, contact
Sealer Sales for a Return Authorization Number. This number
must accompany all returns.
This warranty shall not apply if equipment has been tampered
with, misused, improperly installed, altered, or has received damage
due to abuse, carelessness, accident or failure to follow
recommended regular maintenance procedures or has been serviced
by someone other than a duly authorized factory
representative without the express written consent of Sealer Sales,
Inc.
This warranty is in lieu of all other warranties, expressed or
implied, including but not limited to warranties of merchantability and
fitness for a particular purpose, non-infringement or any
other matter.

Sealer Sales Page 10
SS-1622HK Sealer Service Manual
WARRANTY
Sealer Sales shall have no liability to any person for direct,
indirect, incidental or consequential damages or delay resulting from
any defect negligence, or tort and customer hereby waives for itself
any and all claims for punitive damages and all claims of negligence
of strict liability or both. In no event shall our liability exceed the
purchase price of the product that was actually paid.
Sealer Sales reserves the right to make changes,
additions, or improvements to our products with no obligation to
make such changes in any previously shipped product covered by this
warranty.
Sealer Sales shall not be held liable for any damages
arising out of nor in connection with the operation of the equipment
should customer or its agent fail to maintain equipment in safe
operating condition. This warranty shall become unenforceable if and
to the extent the customer or its agents remove, disconnect, or
otherwise render useless any safety device and or parts designed or
affixed by us or fails to maintain and service equipment in a manner
as advised.
Sealer Sales provides a one-year warranty on parts,
excluding shipping or freight costs for
replacement parts. All warranty parts are shipped
F.O.B. Rancho Cucamonga,California. Service Labor to
install part is not covered under warranty!

Sealer Sales Page 11
SS-1622HK Sealer Service Manual
WARRANTY EXCEPTIONS
WARRANTY EXCEPTIONS
The following parts are an exception to the general
warranty list on page 9. Each part listed below shall carry a 30-day
warranty unless designated otherwise.
SS-1622HK Sealer Parts
1. Conveyor Belt
2. Fuses
The following sealer parts are considered to be consumable and
not under warranty:
1. Silicone Sponge
2. PTFE Tapes

Sealer Sales Page 12
SS-1622HK Sealer Service Manual
WARNINGS
WARNINGS
Every effort has been taken to ensure your safety while
operating this machine; however, there still remain certain risks. Do
not allow this machine to be operated before informing all personnel
of the following warnings.
WARNING........
Do not tamper with the electrical wiring. Only use a
licensed electrician for maintenance. Always disconnect the electrical
power before attempting any maintenance to all electrical and/or
moving parts.
WARNING........
In order to prevent injury to personnel and/or machinery
DO NOT INCREASE SETTINGS OR RATINGS ON EITHER ELECTRICAL
OR MECHANICAL OVERLOAD SAFETY DEVICES.
WARNING........
KEEP HANDS AWAY FROM MOVING CONVEYORS AND
ASSEMBLIES. Conveyor belts that have become worn or frayed are
capable of being hazardous. They should be replaced promptly.
WARNING........
NEVER OPERATE THIS OR ANY MOVING EQUIPMENT
WITHOUT ALL COVERS AND GUARDS IN PLACE. The internal
mechanism of most packaging machinery contains numerous shear,
pinch, and inrunning nip points, many of which are capable of
causing severe injury and/or permanent disfigurement.

Sealer Sales Page 13
SS-1622HK Sealer Service Manual
WARNINGS
WARNING........
To minimize the potential for personnel injury, always be
sure that machine operators and others working on the machinery
are properly trained in the correct usage of the equipment and
properly instructed regarding the safety procedures for operation.
WARNING........
Heat sealing arms and sealing jaws on packaging
machinery can become very warm after a period of use. KEEP
HANDS AWAY WHILE IN OPERATION AND USE CAUTION IF THE
MACHINE HAS BEEN RUNNING RECENTLY.
WARNING........
ANY MODIFICATIONS TO EITHER THE ELECTRICAL
CIRCUITRY OR THE MECHANICAL ASSEMBLIES OF THE MACHINERY
WILL VOID ANY WARRANTIES ASSOCIATED WITH THIS
EQUIPMENT. Such modifications may introduce hazards that
would not otherwise be associated with this machinery. Sealer
Sales will not be responsible for any consequences resulting
from such unauthorized modifications.
WARNING........
The use of certain types of plastic films in sealing and/or
shrinking equipment may result in the release of HAZARDOUS FUMES
due to the degradation of the film at high temperatures. Before
using any plastic film in this equipment, the manufacturer or supplier
of the film should be contacted for specific information concerning
the potential release of hazardous fumes. ADEQUATE VENTILATION
MUST BE PROVIDED AT ALL TIMES.

Sealer Sales Page 14
SS-1622HK Sealer Service Manual
WARNINGS
WARNING........
It is important that the machine operator turn off the
Main Power Switch when he/she has finished operating the unit.
WARNING........
Turn off machine and disconnect power cord from power
source before attempting to work on machine.

Sealer Sales Page 15
SS-1622HK Sealer Service Manual
DESCRIPTION AND SPECIFICATIONS
DESCRIPTION AND SPECIFICATIONS OF
MODEL SS-1622HK SEALER
DESCRIPTION
The purpose of a SS-1622HK Sealer is for medium to
high volume packaging requiring excellent seals and minimal
maintenance. It features aHot Knife seal bar for sealing of
films. This model incorporates an electromagnetic hold-down
system, allowing the operator to load another package while the
preceding package is being sealed. This system provides
consistent seals through precision temperature control of seal
bars. In addition, a package take-away conveyor increases
production speed by automatically discharging product into the
tunnel.
SPECIFICATIONS
Model:
Seal Area:
Machine Size:
Volts:
Amperage:
Weight:
SS-1622HK
Width: 16”
Length:
22” Length:
63” Width:
27” Height:
220
15
300 lbs.

Sealer Sales Page 16
SS-1622HK Sealer Service Manual
INSTALLATION
INSTALLATION AND BASIC SET-UP
IMPORTANT
Read this manual carefully, and make it available to
everyone connected with the supervision, maintenance, or production
of this machine. Additional copies are available at your request.
(Contact your distributor for this information.) Be very careful when
operating, adjusting, or servicing this equipment. If in doubt, stop
and obtain qualified help before proceeding.
INSTALLATION OF SS-1622HK SEALER
Place the L-Bar Sealer in the desired location with
the required electrical power source available. (See
power requirements.) Make certain that proper electrical wiring is
provided to guard against low voltage. If the voltage is too
low, the equipment will not function properly.
Finding the proper location is a most important function
of the initial set-up. One must take several factors into
consideration:
1. Adequate power source.
2. Relationship to source of product.
3. Relationship to L’Sealer.
4. Relationship to any conveyors necessary to remove
finished product.
5. Convenience of operator.
An electrician should install a plug on the end of the main
power cord. If there is any doubt, get qualified assistance to do the
initial installation. Do not take any chances!

Sealer Sales Page 17
SS-1622HK Sealer Service Manual
INSTALLATION
Do not attempt to install, adjust, or operate this machine
without first reading the contents of this manual. Although the
design of the equipment incorporates safeguards to protect operating
and maintenance personnel, care should be used in operating,
adjusting, and servicing.
INSTALLING FILM RACK
IMPORTANT: Remove film rack from under sealer and
install at the end of the sealer on the right hand side with the four
bolts an center knob provided. Mounting holes are slotted for
adjustment, set film rack flush with backside of the machine frame.

Sealer Sales Page 18
SS-1622HK Sealer Service Manual
INSTALLATION
MOUNTING FILM
Select the proper width of centerfold film for the item being
packaged, allowing for width and height of package. With the
package properly positioned within the film in the sealing area, allow
sufficient film to overlap the sealing bars so that a seal may readily
be made without any possibility of open areas due to insufficient film.
Place film roll on cradle mount film rack. The centerfold is to
be placed away from the operator, toward the rear of the machine.
Position film roll on rack and tighten film guide nuts to hold film roll
in position.
Thread film through the Pin Perforator. Note that the
perforator wheel turns freely and is not binding.

Sealer Sales Page 19
SS-1622HK Sealer Service Manual
INSTALLATION
Once threaded, separate film top from bottom and insert
product tray between. Make sure that the centerfold of film is placed
at the rear of the product tray. This allows the operator to insert
product between the layers of film on the product tray and to
prepare to move product and film into the sealing area. When
threading film, make sure to pull more than sufficient film through
the rollers, across the product tray, and into the sealing area to
ensure sufficient film to begin operation.
Place product against rear of film separator tray. Then move
product into seal area. Be sure to leave the bag loose around the
product when making the seal. This helps eliminate the seals from
blowing out in the shrink tunnel. This completes threading and/or
mounting film.
PIN PERFORATOR
Located between the lower idler rollers, the pin perforator
creates holes for air escape as the operator pulls on the film. This
allows the air to escape as the package travels through the tunnel.
The pin perforator is adjustable and must be properly placed in
conjunction with the width of the desired package. The positioning
should always be re-evaluated when setting the machine for different
