INSTRUCTIONS FOR:
GALVANIZED STEEL SHED
MODEL No: GSS1508
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND
CAUTIONS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY
CAUSE DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
Before commencing the assembly, we recommend that you read the instructions thoroughly. Your
new shed comes with all the holes pre drilled to make for fast easy assembly. We recommend
that you assemble the shed using a trestle table or sawhorses and planks. This will ensure that
you are working off the ground and make it easier for you. Assembly is a two person job and
should not be attempted in windy conditions.
Step 1: Check all parts against the component list.
Step 2: Assemble the rear wall panels.
Step 3: Assemble the side wall panels.
Step 4: Assemble the roof panels.
Step 5: Assemble the front wall panels.
Step 6: Assemble the front door.
Step 7: Fit the panels together.
Concrete Slab: It is recommended that your new shed is secured to a concrete slab as per the
specications in this manual.
WARNING! Ensure Health & Safety, local authority, and general workshop practice
regulations are adhered to when building this shed.
Keep the work area clean, uncluttered and ensure there is adequate lighting.
Keep children and unauthorised persons away from the working area.
DO NOT use the shed for any purpose other than that for which it is designed.
Use appropriate safety clothing including eye protection.
Note! The assembly of this product will require assistance.

Concrete slab: Please ensure that your site is level. It is recommended that your slab is 100mm
thick and you use builders plastic and F52 reinforcing mesh. We recommend that you make your
slab 100mm bigger than the base dimensions of your shed. This will allow for a 50mm edge
around your shed. We recommend that you slope the 50mm edges downward by 10 mm so that
rain water can be drained away from your shed.

Tools Required:

Step 1. Check all parts against the component list.
Lay out all parts with number facing outwards and check off against parts list.
Picture Description Component Location Part
No. QTY Check
Sheet Sheet 1980x770 cream-
left rear wall 1L 1
Sheet Sheet 1980x770 cream-
right
rear wall 1R 1
Sheet Sheet 1900-1980x770
cream-left side wall 2L 1
Sheet Sheet 1900-1980x770
cream-right side wall 2R 1
Sheet Sheet 855x770 cream roof 3 2
Sheet 1900x708 cream front 4 1
Door Sheet 1845x770 cream door 5R 1
Channel channel 1508 off white roof 20A 2
Channel channel 1508 off white rear wall 20B 1
Channel channel 1508 off white rear wall 20C 1
Channel channel 1508 off white front 20D 1
Channel channel 1508 off white front 20E 1
Channel channel 768 off white side wall 21A 2
Channel channel 768 off white side wall 21B 2
Channel channel 1898 off white front 22 1
Channel channel 775 off white front 23 1
Channel channel 1458 off white rear wall 31 1
Channel channel 718 off white side wall 32 2
Channel channel 674 off white front 33R 1

Jamb jamb 1898 white front 41A 1
Jamb jamb 1898 white front 41B 1
Jamb jamb 775 white front 42 1
Lip lip 856 off white roof 50 2
FITTINGS PACK
Picture Component QTY Picture Component QTY
Self tapping
screws(10mm) 120
Self tapping
screws(16mm)
10
4*10mm Rivet 12 3*10mm Rivet 6
Pad bolt 1 Keeper 1
Bracket 8 M8*18m/m Hexagonal bolt 8
M8 Hexagonal Nut 8 Mid wall brace bracket 3
Self tapper safety cover 25 Channel safety cover
(L type) 1
Channel safety cover
(R type) 1Rawlbolt 8
`
In the unlikely event that you nd you are missing a part, please contact your Sealey dealer.

Shed Overview

Step 2: Assemble rear wall panels.
You will nd it easier to assemble your shed using sawhorses with timber studs attached ( timber
needs to be the same length as the shed (1.5M) or alternatively, a trestle table.
Place 1R and 1L on the sheeting your work table and join together with the self tapping screws
per the diagram.

Now t 20B top channel and 20C bottom channel to the sheeting by tapping it in (diagram A) or
sliding it in. (diagram B) Be noted that the small lip of the channel is always facing out. This is to
ensure that rain water can not build up inside your shed.

Now t 31 mid wall channel to the sheeting and position it by the self tapping screws. Please
note that the groove should face downwards. Fix the top and bottom channels using the self
tapping screws.

Step 3: Assemble side wall panels
Place 2L the sheeting on your work table and tap or slide in 21A top channel and 21B bottom
channel. Fix and position the 32 mid wall channel by the self tapping screws. Fix 21B the bottom
channel by the self tapping screws but not 21A the top channel in this stage. Note that the small
lip of the channel is always facing out. This is to ensure that rain water can not build up inside
your shed. Repeat the same steps for 2L the other side wall.

Step 4: Assemble the roof panels.
Place 3 and 3 sheeting on your work table and join together with the self tapping screws per the
diagram.
Now tap or slide in 20A and 20A the channels to the sheeting and x them using the self tapping
screws.
Now t 50 and 50 side lips to the sheeting and x them using the self tapping screws.

Step 5: Assemble the front wall panels.
Place 4 the sheeting on the work table. Fit 20D the top channel, 20E the bottom channel, 41B the
jamb (There are pre-drilled holes for next step on both 4 and 41B and must be aligned.) and 33R
the mid wall channel to the sheeting and x them using the self tapping screws. (NOT those with
cross mark in this stage)
Fit the 41A the jamb, 42 the jamb and 23 the bottom channel in following and x them using the
self tapping screws (NOT those with cross mark in this stage). Be aware of the joint details per
the diagrams. (DIAGRAM B IS AS THE SAME AS DIAGRAME A.)

Step 6: Assemble the front door.
Fit 5R the pre-assembled door to the front wall panel per the diagram. Use riveter to x the door
into the pre-drilled holes. Fix the pad bolt (but NOT its keeper in this stage) to the pre-drilled
holes using supplied rivets or self tapping screws.

Step 7: Fit the panels together.
Attach the two side walls to the back wall, then the front wall, then the roof. Fix all the
components by the self tapping screws. Fix the pad bolt keep with rivets or screws.
FOR GREATER SECURITY RIVET AS BELOW

Now t the bolt down kit using the supplied Rawl Bolts as per the diagram. Strengthen your mid
wall brace by applying 72 the mid wall brace bracket on each corner if necessary.
RAWL BOLT

Sealey sheds are weatherproof; however, heavy winds with driving rain could cause your shed to
leak. Condensation will also occur in some weather conditions such as extreme heat or cold. We
would recommend the use of a waterproof sealant to help seal around all joins and wherever you
feel that water may get in under these extreme conditions.
Shed is not to be used to store corrosive substances or as a chemical store.
Apply channel safety cover Ltype on channel 32 and Rtype on channel 33R.
Apply the self-tapper covers on the screws xed on the wall to prevent accidental injuries.

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
If required, the door can be assembled on the opposite side. Align the door with the edge and
drill new holes. Remove the pin from the hinge and reverse it before assembling the door. Fill the
old pre-drilled holes with rivets if required. Perform the same procedure for the pad lock.
