Sealey GSS150819SDG User manual

INSTRUCTIONS FOR: GALVANIZED STEEL
SHED 1.5 x 0.8 x 1.9m WITH SIDE DOOR.
MODEL NO: GSS150819SDG
WARNING! Ensure Health & Safety, local authority, and general workshop practice regulations are adhered to when building this shed.
Keep the work area clean, uncluttered and ensure there is adequate lighting.
Keep children and unauthorised persons away from the working area.
DO NOT use the shed for any purpose other than that for which it is designed.
Use appropriate safety clothing including eye protection.
Note: The assembly of this product will require assistance.
DO NOT attempt to assemble in windy weather.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE THE
PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR PERSONAL
INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
1. SAFETY
2. INTRODUCTION
3. SPECIFICATION
Galvanized, steel panels easily assembled to form a rigid and secure shed. Has skillion (sloping) roof and single door. Door are secured by cross
bolt and eyelet which will accept a padlock (not included) for additional security. Supplied with bolt-down xing kit.
Model No: ........................GSS150819SDG
Overall Size (W x D x H*): ........1500 x 800 x 1900mm
Roof Type: ................................Skillion
* Minimum wall height
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

Concrete Slab: It is recommended that your new shed is secured to a concrete slab as shown below.
Please ensure that your site is level. It is recommended that your slab is 100mm thick, you use a plastic membrane and a suitable
reinforcing mesh. We recommend that you make your slab 100mm bigger than the base dimensions of your shed. This will allow for a
50mm edge around your shed. We recommend that you slope the 50mm edges downward by 10mm so that rain water will drain away from
your shed.
4. CONCRETE PLINTH SLAB
5. TOOLS REQUIRED
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

sheet 1980 x 770
sheet 1980 x 770
sheet 1900-1980 x 770
sheet 80-160 x 770
sheet 855 x 770
sheet 1900 x 770
sheet 1900 x 770
sheet 1780 x 720
channel 1508
Check contents: Lay out all components with the part numbers facing upwards and check off against the parts lists on the next four pages.
In the unlikely event of a missing component please contact you local Sealey dealer.
6. CONTENTS
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

Ø4 x 10mm Rivet Ø3 x 10mm Rivet
Pad shoot bolt
Part No 70
Keeper
Part No 71
Mid height wall bracket
Part No 72
6.1. Please note some component descriptions may differ in manual text to listings, always use pictures from listings to double check
component identity. ie M8 xings may be supplied in lieu of 5/16”.
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

7. PARTS DIAGRAM
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8. ASSEMBLY
8.1. ASSEMBLE THE REAR WALL PANELS
8.1.1. You will nd it easier to assemble the shed using trestles with timber studding of equal or greater panel length. Trestles can be supplied
separately by your Jack Sealey dealership. Attach the studding to trestles with equal overhang using nylon cable ties or similar “safe”
method.
8.1.2. Place panel 1A and 1L on your work table and join them together with the 10mm long self tapping screws.
See the pre-punched holes and both diagrams.
8.1.3. Fit top and bottom channels 20B and 20C to panels by rstly sliding and nally tapping into place as indicated by arrows in the diagrams.
Note that the smaller ange on the channels should always be adjacent to the out side face of the panel; this prevents rainwater entering
the compartment of the shed. The outside face is the top face in both diagrams.
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.1.4. Fit item 38A the mid height wall channel to the panel and position it by the pre-punched holes and 10mm long self tapping screws.
Note this channel is tted with the at face uppermost.
8.1.5. With self tapping screws x items 20B and 20C to top and bottom edges.
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.2.1. Place panel 2E on your work table.
8.2.2. Fit top and bottom channels 21A and 21B to panel by rstly sliding and nally tapping into place as indicated by arrows in the diagrams.
Note that the smaller ange on the channels should always be adjacent to the out side face of the panel. The outside face is the top face
in both diagrams.
8.2.3. Fit item 32D the mid height wall channel to the panel and position it by the pre-punched holes and 10mm long self tapping screws.
Note this channel is tted with the at face uppermost, ie. nearest the “top”.
8.2.4. With self tapping screws x item 21B to bottom edge, but do not screw x item 21A to top edge at this stage,see places marked with
asterisk *.
8.2. ASSEMBLE THE END WALL PANEL (oppposite door).
*
**
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.3. ASSEMBLE THE FRONT WALL PANELS
8.3.1. Place panel 9A and 9S on your work table and join them together with the 10mm long self tapping screws.
See the pre-punched holes and both diagrams.
8.3.2. Fit top and bottom channels 20B and 20C to panels by rstly sliding and nally tapping into place. Note that the smaller ange on the
channels should always be adjacent to the outside face of the panel. The outside face is the diagram. Fix both with 10mm long self
tapping screws except for positions marked with asterisk *, which are not xed at this stage.
*
*
*
*
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.3.3. Fit item 38B the mid height wall channel to the panel and position it by the pre-punched holes and 10mm long self tapping screws.
Note this channel is tted with the at face uppermost, ie. nearest the “top”.
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.4.1. Place both panels item 3 on your work table and join them together with the 10mm long self tapping screws.
See the pre-punched holes and both diagrams.
8.4.2. Fit top and bottom channels item 20A to panels by rstly sliding and nally tapping into place as previously explained in 8.1.3.
Note that the smaller ange on the channels should always be adjacent to the outside face of the panel. The outside face is the top face
in both diagrams.
8.4. ASSEMBLE THE ROOF PANEL
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.4.3. Fit item 50 (angles) to each edge, refer to diagram this page for ange orientation. Fix with 10mm long self tapping screws.
50
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.5. FIT THE SUB ASSEMBLED REAR SIDE AND FRONT PANELS TOGETHER.
8.5.1. Attach the side wall 2E to the rear wall 1A & 1L, then the front wall 9A & 9S. Fix all walls with the 10mm long self tapping screws.
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.6. INSTALL THE DOOR FRAME
8.6.1. Install the front frame per following diagrams. The door mullion sections are xed with 16mm long self tapping screws. Do not x self
tapping screws marked * in enlarged ballooned views at this stage.
FIX DOOR MULLION SECTIONS WITH
SIX 16mm LONG SELF TAPPING SCREWS
*
*
*
*
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.6.2. Fit the panel item 2F and the channel item 21H, x with 16mm long self tapping screws.
Fix the channel item 21H with
16mm long self tapping screws.
8.6.3. Slide and tap on top channel item 21J, but do not screw x at this stage.
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.7. INSTALL THE DOOR
8.7.1 Fit the pre assembled door item 5C to the rear panel via the hinges. Fix hinges into pre-punched holes with 4mm diameter rivets. Check
action of door before crimping rivets.
8.7.2 Fit the shoot bolt item 70 and the bolt keeper item 71 and x with 10mm long self tapping screws or 4mm diameter rivets, (tting method A
or B)
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.8. INSTALL THE ROOF
8.8.1. Self tapping screw x the pre-assembled roof panel from 8.4.2; comprising items 3, 20A and 50.
8.8.2. With the shed located centrally about the plinth slab, position the 6 anchor steel angles, M8 machine screw x to internal compartment.
This will require “spotting” and drilling 8mm diameter holes through to shed panels. Spot through holes to plinth slab, remove anchor
angles and masonry drill slab for anchor bolts.
Please note anchor bolts and M8 machine screws are supplied, see “FITTINGS PACK”.
8.8.3. Insert anchor bolts, re-t steel angles and anchor shed to plinth slab.
GSS150819SDG Issue: 1 - 27/08/14
© Jack Sealey Limited Original Language Version

8.9. SHED RIGIDITY AND USER SAFETY.
8.9.1. For shed rigidity, self tapping screw x the 2 mid height wall brace brackets, item 72.
8.9.2. Fit safety covers L to 38B and R to 38A and any projecting screws to be made safe with self tapper covers.
GSS150819SDG Issue: 1 - 27/08/14
