Sealey Workshop Series User manual

SPRAY GUN GRAVITY FEED 2MM SET-UP
MODEL NO: SSG5.V3
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Familiarise yourself with the application, limitations and potential hazards peculiar to the spray gun.
WARNING! Disconnect the spray gun from the air supply before changing accessories, servicing or performing any maintenance.
8Paint cup remains pressurised after gun is disconnected from air line. DO NOT pull the trigger, but de-pressurise by gently opening cup.
9Maintain the spray gun in good condition (use an authorised service agent).
9Replace or repair damaged parts. Use authorised parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9Keep the spray gun clean for best and safest performance.
9Ensure that the compressed air system can supply the spray gun air consumption for the model to be used.
9Wear approved safety respiratory protection and safety eye goggles.
9If spraying isocyanate based finisher, wear approved respirator/clean air breathing apparatus and cover exposed skin with latex gloves
and an impervious hooded coverall.
9Remove ill-fitting clothing. Remove ties, watches, rings and other loose jewellery and tie back long hair.
9Locate the spray gun in a suitable work area. Keep area clean and tidy and free from unrelated materials and ensure that there is
adequate ventilation and lighting.
9Keep children and unauthorised persons away from the work area.
9When not in use, ensure that the air supply is turned off.
9Avoid unintentional operation of spray gun.
9The spray gun has been treated with an anti-corrosive agent at the factory and MUST be flushed out thoroughly with thinner before use.
8DO NOT point spray gun at yourself, other persons or animals.
8DO NOT direct air from the air hose at yourself, other persons or animals.
8DO NOT carry the spray gun by the hose, or yank the hose from the air supply.
8DO NOT exceed the working pressure of 50psi (3bar).
8DO NOT use the spray gun for any purpose other than that for which it is designed.
8DO NOT allow untrained persons to operate the spray gun.
8DO NOT get the spray gun wet or use in damp or wet locations or in areas where there is
condensation.
8DO NOT operate the spray gun if any parts are missing or damaged as this may cause
failure and/or personal injury.
9When not in use, disconnect the spray gun from the air supply, clean thoroughly and store
safely.
2. INTRODUCTION
Ideal for applying undercoats, primers and adhesives. Features adjustable paint ow, fan width and
air regulator controls. Supplied with composite gravity feed pot. Suitable for use with water based
paints. Alternative set-ups available separately.
3. SPECIFICATION
Standard Set Up: ........................................................ 2.0mm
Available Set-Up(s): ...................................... 1.2, 1.4, 1.8mm
Recommended Air Pressure: ........................................ 50psi
Air Consumption: ...................................................... 7-14cfm
4. AIR SUPPLY CONNECTION
4.1. Air Supply
4.1.1. Ensure spray gun air valve (or trigger) is in the “o󰀨” position before connecting to the air supply.
4.1.2. You will require an air pressure of 50psi and an air ow according to specication.
WARNING! Ensure the air supply is clean and does not exceed 50psi while operating the spray gun. Too high an air pressure and
unclean air will shorten the product life due to excessive wear and may be dangerous causing damage and/or personal injury.
4.1.3. Drain the air tank daily. Water in the air line will ruin the paint nish and damage the spray gun.
4.1.4. Clean air inlet lter weekly. Recommended hook-up procedure is shown in g.1.
4.1.5. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter should
be 1/4” I.D. and ttings must have the same inside dimensions.
SSG5.V3 Issue 3 03/05/18
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear eye
protection
Wear respiratory
protection
Wear protective
clothing

4.1.6. Keep hose away from heat, oil and sharp edges. Check hose for wear and make certain that all connections are secure.
4.2. Couplings.
4.2.1. Do not t a quick change coupling directly to the spray gun. A leader hose should be tted to the spray gun and then a quick
change coupling may then be used to connect the leader hose to the air line recoil hose. See g.1 & 2.
5. OPERATION
5.1. For best results, make sure to handle the gun correctly. It should be held perpendicular to the surface being sprayed and moved
parallel to it. Start the stroke before squeezing the trigger and release the trigger before nishing the stroke. This will enable you to
accurately control the gun and material (g.3).
5.2. Spray from a distance of about 150mm (6”) to 250mm (10”) depending on the material and the atomizing pressure. The material
deposited should always be even and wet. Each stroke must overlap the preceding stroke to obtain a uniform nish. To reduce over
spray and obtain maximum e󰀩ciency, spray with the lowest possible atomizing air pressure.
5.3. Controlling the fan spray and the uid.
A) The atomizing air ow is controlled by knob (g.4.1).
B) Use the needle adjustment knob (g.4.2) to increase or decrease the amount of paint ow.
C) The width of the spray can be adjusted using knob (g.4.3).
D) As width of spray is increased more material must pass through the gun to obtain the same coverage on the increased area.
E) Turn the air nozzle (g.4.4) to achieve a horizontal or vertical fan spray. Lock the nozzle with retaining ring (g.4.5).
The spray pattern of the gun is variable from round to at with all patterns in between. In normal operation, the wings on the nozzle
are horizontal as g.4, this provides a vertical fan-shaped pattern which gives maximum uniform and even coverage when moving
the gun back and forth, parallel to the work surface (g.5).
6. CLEANING THE GUN
FOR OPTIMUM PERFORMANCE IT IS VERY IMPORTANT TO ENSURE THE GUN IS CORRECTLY CLEANED AFTER EACH USE.
Disconnect from the air supply before attempting any cleaning or maintenance.
6.3.1. Immerse the front end of the gun only in solvent. The solvent should just cover the uid connection.
6.3.2. Use a bristle brush and solvent to wash o󰀨 accumulated paint.
6.3.3. Do not immerse the entire gun in solvent as this will cause lubricants on the rubber seals to dissolve. Dirty solvent may also clog
narrow passages in the gun.
6.3.4. Flush the gun through with clean thinners.
6.3.5. Wipe the outside of the gun with a dampened solvent rag.
6.3.6. Air nozzle, uid nozzle and needle assembly
6.3.7. To clean the nozzles, soak them in solvent to dissolve any dried material then blow them clean with air. Handle all nozzles carefully
and do not make any alterations in the gun.
6.3.8. If you need to probe the holes in the nozzles, be sure to use a tool that is softer than brass; do not use metal instruments.
g.1
g.2
g.3
g.4
g.5
SSG5.V3 Issue 3 03/05/18
Original Language Version
© Jack Sealey Limited

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
6.3.9. Adjust the uid needle valve so that when the gun is triggered, air ow occurs before uid ow.
