2L RECHARGEABLE PRESSURE SPRAYER
MODEL NO: SCSG2R
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGEAND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
SGSG2R Issue 2 (2) 27/02/23
Original Language Version
© Jack Sealey Limited
Refer to
instructions Wear eye
protection Wear protective
gloves Wear protective
clothing Wear a mask
1. SAFETY
9Only use the sprayer for it’s intended purpose.
9Familiarise yourself with the applications, limitations and potential hazards of this product.
9Replace or repair damaged parts. Use recommended parts only. Unauthorised parts may be dangerous and will invalidate the
warranty.
9Always inspect and prepare the sprayer before use according to the instructions contained in this manual.
8DO NOT use the sprayer if it is damaged, altered, modied, in poor condition, leaking uids or has any missing components.
8DO NOT alter the sprayer in any way.
8DO NOT use the sprayer for spraying ammable materials.
WARNING! Ensure you are fully aware of all the potential hazards of the material being sprayed. Read and understand the
warnings and instructions on the container or the supplied manufacturers information.
8DO NOT spray any material where the hazards are not known.
9 Ensure that the spray containers cannot easily be knocked over during lling.
9 Mark uid containers with hazard labels to show it’s chemical contents, even if it’s water.
9 It is highly recommended that individual uid containers should be used only for one type of specic agent.
9 Keep any uid containers in a well ventilated, lockable store.
9Keep children and unauthorised persons away from the working area, especially during the spraying operation.
9Maintain the sprayer in good condition and keep clean to maintain safest performance.
9 Ensure that the uid containers cannot easily be knocked over when transferring unused uid back into it.
9 Keep the sprayer turned o󰀨.
9 Keep the uid reservoir tank rmly closed to prevent any spillage.
9Be aware of wind direction whilst spraying. Spray from upwind to downwind to prevent direct chemical contact with your body.
8DO NOT spray when the wind speed is in access of 4mph.
8DO NOT over apply pesticide. Only apply at the manufacturer’s recommended rate. Excess pesticide can be hazardous to
humans, wild life, damage plants and contaminate soil and water sources.
8DO NOT eat, drink, rub your eyes, or touch any part of your bare skin whilst handling uids or when spraying. If chemical(s)
come into contact with skin, immediately wash thoroughly with soap and water.
8DO NOT spray near open ames or other sources of heat.
8DO NOT smoke or use an open ame anywhere near the sprayer or around stored uids.
9 Maintain correct balance and footing. Ensure the oor is not slippery and wear non-slip shoes.
8DO NOT operate the sprayer when you are tired or under the inuence of alcohol, drugs or intoxicating medication.
9 Always clean up any spills immediately as per uid manufactures instructions.
8DO NOT spray at people, animals or protected insect species.
9 Select the appropriate chemical which o󰀨ers the best solution to your pest or weed problem.
WARNING! When mixing chemicals, thoroughly read and understand the manufacturers instructions.
WARNING! Inappropriately mixed chemicals may harm people and damage crops or plants.
9Always mix chemicals prior to adding the solution to the sprayers tank reservoir.
9Ensure the sprayers tank reservoir is full prior to use. Operating the sprayer with an empty tank may damage the pump.
WARNING! If the spraying stops running, or an abnormal sound is emitted immediately switch o󰀨.
WARNING! Wear appropriate PPE (Personal Protective Equipment). To avoid inhalation and/or skin or eye contact with the
chemical wear, protective goggles, protective mask, rubber gloves, long sleeved waterproof jacket, long trousers and Wellington
boots.
9Operators, whose physical, sensory or mental capabilities prevents them from safely using the sprayer, must be under the
supervision of a person who has a thorough knowledge and experience of the sprayer and the appropriate regulations.
8DO NOT allow children or untrained persons to operate the sprayer.
8DO NOT Overll or Tilt the bottle to the point where the liquid covers the air inlet as the pump/motor will still run but the
unit will stop dispensing and can cause possible damage to the unit.
WARNING! The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible
conditions and situations that may occur. It must be understood that common sense and caution are factors
which cannot be built into this product, but must be applied by the operator.
Wear respiratory
protection

2. INTRODUCTION
Suitable for use with most detergents, pesticides and non solvent based uids. Powered by an Electric motor with an integrated 3.6V 2.5Ah
Li-ion battery capable of 110 minutes of continuous use. LED battery indicator shows how much battery is left. Convenient screw top for
storing the USB charging cable. Adjustable nozzle with mist and jet spray patterns. 2L Working capacity with level indicator. USB charging
cable supplied.
3. SPECIFICATION
Model No:........................................................ SCSG2R
Battery; .........................................3.6V 2500mAh Li-ion
Charging time:...................................................210mins
Operating time: ...................................................110min
Working capacity:............................................. 2.0 litres
4. FEATURES
5. OPERATION
NOTE: Ensure all Safety Instructions in Section 1 are read and understood and carried out before use and save the instructions and
warnings for future reference.
5.1. CHARGE BATTERY
5.1.1. Charging port is located in bottom of handle assembly. Charging cable is stored in screw top, g.1.
5.2. POWER SWITCH
WARNING! To prevent sudden spraying ensure that the trigger lever is in the stop position and the power switch is in the OFF
position.
5.2.1. Grip the handle and rotate the vessel to separate (fig.1).
FILLING THE TANK
WARNING! When lling the tank wear appropriate PPE.
WARNING! DO NOT ll tank in a poorly ventilated area.
WARNING! Ensure that all chemical mixtures are thoroughly dissolved prior to use.
WARNING! Take extreme care when handling chemicals. Wear appropriate PPE. Wash thoroughly away any chemicals that comes
into contact with bare skin.
WARNING! Chemicals are harmful. Always read and fully understand the manufacturer’s instructions before use.
5.2.2. Fill to a maximum of 2 litre (observe the graduated scale moulded into the vessel).
5.2.3. Re-attach vessel keeping vertical, rotate until hand tight against neck seal.
5.2.4. To turn the sprayer on, press down the I (ON) on the power switch (g.2.).
5.2.5. To turn the sprayer o󰀨, press down the O (OFF) on the power switch (g.2).
5.2.6. The spray pattern may be changed by rotating the adjustable nozzle.
SPRAY ADJUSTMENT
5.2.7. To adjust the intensity of the spraying turn the adjustment button clockwise to increase and anticlockwise to decrease
8DO NOT operate the sprayer with an empty tank. Turn OFF immediately.
WARNING! Prolonged continuous use of the sprayer will drain the battery and may cause damage to the pump. Switch OFF the
sprayer whenever possible.
WARNING! If the sprayer starts to make abnormal noises and/or the spray splutters this indicates that the tank is empty.
Switch OFF immediately.
6. MAINTENANCE
6.1. DO NOT attempt any maintenance or repairs that are not included in this manual.
8DO NOT use solvents to clean sprayer.
6.2. AFTER USE MAINTENANCE
6.2.1. Dispose of any residual liquid from the sprayer tank, by returning it back to it’s original container. Clean up any spills immediately
as per uid manufactures instructions.
6.2.2. Wash out the tank with clean water and after cleaning, pour the water into a suitable container.
6.2.3. Wipe away any remaining moisture with a dry cloth.
NOTE: Dispose of any contaminated water properly according to local regulations.
6.3. Wash out the sprayer as section and ensure that the sprayer is completely free from moisture.
6.4. Store the sprayer in a child free, safe, clean, dry indoor location that is away from direct sunlight, has good ventilation and does not
freeze.
Original Language Version
© Jack Sealey Limited
g.2
g.1
SGSG2R Issue 2 (2) 27/02/23

WARNING! Frozen liquids that remain in the sprayer may cause breakdown or damage to the pump during operation.
7. TROUBLESHOOTING
Original Language Version
© Jack Sealey Limited
PROBLEM POSSIBLE CAUSE SOLUTION
Motor (pump) will not work Switch set at
OFF The switch is set to OFF Set switch to ON
Switch set at
ON No battery charge Recharge the battery.
Wiring connector is disconnected Repair at authorised Sealey service centre
Wiring break Repair at authorised Sealey service centre
ON-OFF switch broken Repair at authorised Sealey service centre
Motor (pump) not working Repair at authorised Sealey service centre
Pump is working but no spray is coming
out Blocked nozzle Clean or replace
Chemical tank is empty Refill with required liquid
Blocked piping Repair at authorised Sealey service centre
Broken or cracked piping Repair at authorised Sealey service centre
Disconnected or broken piping Repair at authorised Sealey service centre
Blocked piping Repair at authorised Sealey service centre
Broken or cracked piping Repair at authorised Sealey service centre
Disconnected or broken piping Repair at authorised Sealey service centre
Blocked control handle strainer Remove and clean
Abnormal sound when sprayer is switched
ON Broken pump drive coupling Repair at authorised Sealey service centre
Blocked nozzle Clean or replace
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 [e-mail] www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
