Sealey SS98 User manual

BROADCAST/ SPOT SPRAYER
MODEL NO: SS98/SS60
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
1.1. GENERAL SAFETY
9Only use the sprayer for its intended purpose.
9Familiarise yourself with the applications, limitations, and potential hazards of this product.
9Use original Sealey spare parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
9Ensure containers cannot easily be knocked over during filling.
9Always ensure good contact on the 12V battery.
9Mark fluid containers with hazard labels to show their contents.
9Keep any fluid containers in a well ventilated, lockable store, preferably outside the working area.
9Keep children and unauthorised persons away from the working area, especially when the sprayer is in operation.
9Keep the work area childproof by using padlocks and master switches.
9Maintain the sprayer in top condition. Keep it clean for best and safest performance.
9Follow the same precautions when transferring fluid from the sprayer back into other containers.
9Ensure the sprayer is securely fixed to the ATV.
9Always inspect and prepare the sprayer before use according to the directions provided in this manual.
9Keep the sprayer turned off. Do not turn on power to the sprayer until ready to spray in order to avoid unintentional spray release.
9Never spray when wind speed exceeds 4mph in order to minimize spray drift.
8DO NOT over apply pesticide. Apply at a rate recommended by agents manufacturer. Excess pesticide can be dangerous to humans,
damage desirable plants, and contaminate soil and water sources.
8Never point the spray gun at people or animals.
8DO NOT eat, drink, rub your eyes, or touch any part of your bare skin while handling agents and spraying.
8DO NOT spray near open flames or sources of heat.
9Always clean up spills immediately per instructions on the agent’s label.
9Turn off vehicle and set brake or block wheels, turn off power to sprayer, and relieve system pressure before leaving sprayer
unattended.
8DO NOT use an open flame or smoke anywhere near the sprayer or around stored fluid.
8DO NOT spray fluid into dedicated workshop oil spray equipment.
8DO NOT use any electrical equipment on or near the vehicle while fluid spraying is in progress. This includes the use of inspection
lights, mobile phones or pagers.
8DO NOT use the sprayer if the pump is damaged in any way.
8DO NOT use whilst under the influence of drugs, alcohol or other intoxicating medication, or if you are fatigued.
1.2. ELECTRICAL CONNECTION SAFETY
9If the battery terminals are corroded or dirty, clean them before using the tester.
9Disconnect the power after every use to avoid accidental starting.
8DO NOT disassemble the remote switch for any reason. The tester must only be checked by qualified service personnel.
WARNING! To prevent the risk of sparking, short circuit and possible explosion DO NOT drop metal tools in the battery area, or allow
them to touch the battery terminals.
8DO NOT cross-connect remote switch clamps. Ensure positive (RED) clamp is to positive terminal and negative (BLACK) clamp is to
negative terminal.
1.3. CHEMICAL SAFETY
1.3.1. First and foremost ensure you read the safety data sheet of the substance you are going to spray.
1.3.2. Thesprayerisintendedforuseinsprayingagriculturalpesticidesandothernon-ammableliquids.
1.3.3. Spraying pesticides - Pesticides are hazardous agents that must be handled with caution as directed throughout this manual and
on the pesticide label. The sprayer is intended for use in spraying pesticides in liquid form only. The sprayer is NOT intended for use
in spraying pesticides in dry or in aerosol form, or for use with fumigants. Sprayers SS60 and SS98 come equipped with a spot spray
gun and a tank-mounted broadcast spraying system. Use the spot spray gun if you desire to apply pesticide only on selected plants.
Use the broadcast spraying system if you wish to spray large ground areas.
1.3.4. SprayingOtherLiquids-Inadditiontosprayingpesticides,thissprayermaybeusedtosprayothernon-ammableliquids.Example
uses include: watering plants/trees or spraying water for dust control, applying ice control agents, applying water-based, non-
 ammablesealantorstaintooutdoorwoodsurfaces.
1.3.5. However, WE RECOMMEND THAT THE SPRAYER NOT BE USED FOR OTHER PURPOSES ONCE IT HAS ALREADY BEEN
USED FOR SPRAYING PESTICIDES. Any agents will leave some residual in the tank liner or sprayer components, even after the
 sprayerhasbeenproperlycleaned.Theseresidualagentscanhaveunexpectede󰀨ectsonfutureuses.Forexample,sprayingwater
or other liquids that are contaminated with residual pesticide may result in unforeseen hazards to plant or animal life.
SS98/SS60 | Issue 3 (HF) 26/03/18
Original Language Version
© Jack Sealey Limited
Refer to
instructions
Wear face
shield
Wear protective
gloves

2. INTRODUCTION
Spot/broadcast sprayer supplied with tie-down straps to attach to most all terrain vehicles. Powered by 12V battery or connected via 12V
supplyonATV/QuadBikes.Quietrunningdiaphragmpumpispressureactivatedproducingasmoothowfromthetank.Suppliedwithtrigger
operatedlanceprovidingcontrolledapplicationandbroadcastlanceforhands-freeoperation.Featuresremoteoperatedon/o󰀨switchand
batteryclips.Tankismanufacturedusingchemicalresistantmaterialandisttedwithtankdrainagespoutfordrainingunwantedcontents.
Tankalsofeaturesextra-thickwallsandisUV-stabilizedtopreventfading.Suitableforusewithavarietyofdi󰀨erentagentsincludingweed
killer, de-icer and for spraying fertilizer.
3. SPECIFICATION
Model No ........................SS60 .............SS98
Tank Capacity......................60ltr ..............98ltr
Maximum Flow Rate.............. 8.3ltr/m ...........8.3ltr/m
Maximum Pressure ................70psi .............70psi
Maximum Spray Reach ............. 4.3m .............4.3m
Hose Length ...................... 4.5m .............4.5m
Dimensions (W x D x H).864 x 368 x 419mm . 864 x 368 x 622mm
Weight ..........................8.4kg .............9.9kg
4. CONTENTS
4.1 Main Contents 4.3 Broadcast Lance and Fixings
4.2 Accessories and Fixings
SS98/SS60 | Issue 3 (HF) 26/03/18
Original Language Version
© Jack Sealey Limited
Flange Bolt

fig.1 fig.2
5. ASSEMBLY
5.1. Fasten the two lance clips to the sprayer tank with the two screws supplied. See fig.1.
5.2. Press the rubber washer onto the drain pipe, screw on the drain cap. See fig.1.
5.3. Attach Spot Spray Gun Hose to Pump (see fig.2)
5.3.1. Slide the hose clamp over the hose.
5.3.2. Push the hose onto the pump.
5.3.3. Slide the hose clamp over the pump connector and tighten.
5.4. Attach Hose Guide to Tank (see fig.3)
5.4.1. Thread the hose through the hose guide.
5.4.2. Attach the guide to the side of the tank using the flange bolt.
5.5. Attach Hose to Spot Spray Gun (see fig.4)
5.5.1. Slide the hose clamp over the hose.
5.5.2. Push the hose onto the hose barb on the spray gun.
5.5.3. Slide the hose clamp around the hose barb and tighten.
5.6. Attach Broadcast bracket to Tank (see fig.5)
5.6.1. Ensure the bracket is fixed with the two clips at the end facing the pump.
5.7. Attach the sprayer to the vehicle (see fig.7)
5.8. Use the hooked straps supplied to secure each end to an ATV rack (not supplied)
5.9. Assemble Broadcast Kit. (see fig.6)
5.10. Insert the broadcast lance into the bracket, note the orientation in fig.6.
5.11. Screw on the hose connector to the pump, tighten by hand then using a spanner turn once more.
5.12. Slide two hose clamps over the hose.
5.13. Push the hose onto the hose barb on the broadcast lance and onto the connector on the pump.
5.14. Slide the hose clamp around the hose barbs and tighten the connector on the pump.
5.15. Slide the hose clamp around the hose barbs and tighten.
5.16. Assemble Broadcast Kit. (see fig.6)
5.16.1. Insert the broadcast lance into the bracket, note the orientation in fig.6.
5.16.2. Screw on the hose connector to the pump, tighten by hand then using a spanner turn once more.
5.16.3. Slide two hose clamps over the hose.
5.16.4. Push the hose onto the hose barb on the broadcast lance and onto
fig.3 fig.4
SS98/SS60 | Issue 3 (HF) 26/03/18
Original Language Version
© Jack Sealey Limited

fig.6
fig.7
6. PREPARATION
6.1. Preparation
6.1.1. Ensure the sprayer is securely attached to the vehicle.
6.1.2. Ensure the sprayer has been thoroughly flushed and drained of all residual agents from prior uses.
6.1.3. Clean the suction strainer of any agents residue. It is important to clean the suction strainer before each use to ensure it is not clogged
and to prevent residual agents from contaminating sprayer contents.
6.2. Environment Considerations
6.2.1. The sprayer should not be used when wind is in excess of 4mph.
6.2.2. Consideration should be given to members of the public and/or colleagues when spraying, ensure the area to be sprayed is well
ventilated and cordoned off.
6.3. Filling the sprayer
6.3.1. Choose a safe pesticide mixing and loading area. Choose an outdoor, well-ventilated area away from unprotected people, animals, food,
and other items that might become contaminated.
6.3.2. Wear personal protective equipment.
6.3.3. Turn off power to the sprayer before filling. The vehicle should also be off, with wheels chocked to prevent unintended movement.
6.3.4. Remove the fill cap located on top of the sprayer. (fig.8).
6.3.5. Before filling ensure drain cap is securely tightened.
6.3.6. Mix agents as instructed on that particular product. Do not mix more than needed, to reduce wastage and the need to store excess
agents mix.
6.3.7. Pour agent through the filler cap. When done replace filler cap and tighten.
7. USE - SPOT SPRAYER
7.1. Personal Protective Equipment
7.1.1. Ensure personal protective equipment is used. i.e gloves, goggles, coverall and breathing mask.
7.2. Broadcast Lance Valve
7.2.1. Turn the broadcast lance to the OFF position (fig.9).
7.3. Turn On Power
7.3.1. Turn the remote switch to the ON (I) position.
7.4. Use Spot Spray Gun
7.4.1. To spray squeeze the gun trigger.
7.4.2. Twist the spray nozzle to change from a straight stream to a cone spray pattern. Check with the type of agent which is best to use.
SS98/SS60 | Issue 3 (HF) 26/03/18
Original Language Version
© Jack Sealey Limited
fig.5

8. USE - BROADCAST SPRAYER
8.1. Broadcast Lance
8.1.1. Move the broadcast lance into the broadcast position (fig.11).
8.1.2. Ensure the broadcast lance valve is in the OFF position (fig.11).
8.2. Broadcast Nozzle
8.2.1. If needed, rotate the broadcast nozzle so that the spray pattern is pointed down and evenly distributed. (fig.12)
8.2.2. Ensure gloves are worn when adjusting the lance and nozzle, as dripping may occur.
8.3. Start Spraying
8.3.1. Turn the remote switch to ON (I).
8.3.2. Turn the broadcast lance valve on (fig.13)
8.3.3. To ensure a uniform spray pattern, overlap each spray 300mm (fig.14).
8.3.4. See the speed/application tables to determine the speed for the ATV.
NOTE! It is possible to use the broadcast lance and spot spray gun simultaneously.
8.4. Leaving Unattended
8.4.1. Ifthesprayermustbeleftunattended;A)disconnectthepower.B)relievethesystempressurebypressingtheguntrigger.C)turno󰀨
the vehicle and chock the wheels.
8.5. Sprayer Becomes Inoperable
8.5.1. If the sprayer becomes clogged or stops working do not attempt to repair whist agents are still in the sprayer tank.
8.5.2. Review the troubleshooting table to proceed.
fig.11 fig.12
fig.13
fig.14
SS98/SS60 | Issue 3 (HF) 26/03/18
Original Language Version
© Jack Sealey Limited

SYMPTOMS REASON REMEDY
Pump will not start. 1. Poor electrical connection.
2. Short in wires
3. Low voltage.
1. Ensure good connections.
2. Check conditions of wires.
3. Check the battery voltage.
Low pressure. 1. Worn spray gun nozzle.
2. Worn boom nozzle.
1. Replace spray gun nozzle.
2. Replace boom nozzle.
Lowow. 1. Clogged intake tube.
2. Clogged suction strainer.
3. Low voltage.
1. Remove obstruction to intake tube.
2. Clean suction strainer.
3. Check the battery voltage.
Poor spray distribution. 1. Clogged intake tube.
2. Clogged suction strainer.
3. Worn spray gun nozzle
1. Remove obstruction to intake tube.
2. Clean suction strainer.
3. Replace spray gun nozzle.
Pump operates while not spraying. 1. Leak in the system 1. Find leak and tighten hose clamps or fittings.
Replace spray gun.
9. AFTER USE
9.1. Drain Tank
9.1.1. Disconnect the power supply and relieve the system pressure by squeezing the spray gun trigger.
9.1.2. Use a suitable container to drain excess agent into, place it beneath the drain hole.
9.1.3. Remove the drain cap to drain into container. Ensure all personal protective equipment is used.
9.1.4. When the tank is fully drained, replace drain cap and tighten.
9.2. Unused Chemicals
9.2.1. If unused agents are to be kept for future use store in the original container or a similarly suitable one. Also ensure such container is
suitably labelled.
9.2.2. When remaining agents need to be disposed of, refer to the manufactures label and local authority guidelines.
9.3. Flush Sprayer
9.3.1. Refer to agents manufacturer for flushing procedure and recommendation on a cleaning solution.
9.4. Decontaminate
9.4.1. After handling chemicals and other agents, remove all clothing and wash separate to other clothing.
9.4.2. Wash all exposed skin thoroughly with soap and water.
10. STORAGE
10.1. Preparing for Storage
10.1.1. Add an antifreeze (not automotive) into the tank.
10.1.2. Turn on the pump and squeeze the gun trigger until the antifreeze sprays briefly. Store the gun in the lance clips and disconnect the
power.
10.2. Removing form Storage
10.2.1. Drain the antifreeze into a suitable container.
10.2.2. Fill the sprayer tank with fresh clean water, connect the power, use the spray gun and flush the system. Be sure to have a container to
collect the flushed antifreeze.
10.2.3. Dispose of antifreeze along with local authority guidelines.
11. TROUBLE SHOOTING
12. SPRAY CALIBRATION
Follow the below tables to determine the correct speed that the ATV should travel.
12.1. Table 1
12.1.1. Use the table that corresponds with the agents manufacturer’s suggested application rate (litres per hectare, litres per 100 sq.m or
litres per 10 sq.m).
SS98/SS60 | Issue 3 (HF) 26/03/18
Original Language Version
© Jack Sealey Limited
Litres per Hectare
Application Rate 800 400 267 200 160 133 144
Speed (km/h) 1 2 3 4 5 6 7
Litres per 100Sq.m.
Application Rate 8.0 4.0 2.6 2.0 1.6 1.3 1.1
Speed (km/h) 1 2 3 4 5 6 7
Litres per 10Sq.m.
Application Rate 0.80 0.40 0.26 0.20 0.16 0.13 0.11
Speed (km/h) 1 2 3 4 5 6 7

Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme.
Jack Sealey Ltd Batteries Producer Registration Number (BPRN) is BPRN00705.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior
notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
SS98/SS60 | Issue 3 (HF) 26/03/18
Original Language Version
© Jack Sealey Limited
Speed (km/h) Time Required in Seconds to Travel a Distance of:
10m 50m 100m
1 36 180 360
2 18 90 180
3 12 60 120
4 9 45 90
5 7 35 70
6 6 30 60
7 5 25 50
12.1.2. Find the application rate that is closest to the agents manufacturer’s recommendations.
12.2. Table 2
12.2.1. Use this table to set the speed of the ATV.
