ROADSTART® 1200A 12V LITHIUM-ION JUMP
STARTER POWER PACK
MODEL NO: RS1200
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
Modern vehicles contain extensive electronic systems.
 YouarerequiredtocheckwiththevehicleManufacturer,foranyspecicinstructionsregardingtheuseofthistypeof 
equipment on each vehicle. No liability will be accepted for damage / injury, where this product is not used in accordance
with all instructions.
9Ensure that the vehicle is in a well ventilated area.
9Apply the handbrake and select neutral or ‘park’ before attempting to start.
9Ensure that the ignition switch and all ancillary electrical equipment is switched off.
9Keep clear of any pulleys, belts etc. that will move once the engine starts.
9Take care to ensure correct connection polarity; red clamp to positive, black clamp to negative.
9Energise the unit only at ambient temperatures between -30°C and 40°C.
9When not in use, switch off and store in a cool, dry place out of the reach of children.
8DO NOT allow this power pack to become wet.
8DO NOT dismantle this unit: there are no user serviceable parts inside.
8DO NOT use in explosive atmospheres (e.g. the presence of flammable liquids, gases or dust).
8DO NOT use the unit if it appears damaged in any way.
8DO NOT use this product for any purpose other than that for which it is designed.
8DO NOT leave in direct sunlight or expose to heat.
8DO NOT use abrasive or solvent cleaners on this product.
8DO NOT allow children to play with this product
8DO NOT allow the positive and negative clamps to touch.
1.1. BATTERY SAFETY
WARNING! To reduce the risk of burns or re:
8DO NOT attempt to open, disassemble, modify or service the battery pack.
8DO NOT crush, puncture, short external contacts or dispose of in re or water.
8DO NOT expose to temperatures above 60°C (140°).
9Replace only with the battery pack designated for this product.
9Recycle or dispose of used battery as stipulated by local regulation.
8If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTION
Easily ts in a glove box or backpack and benets from being compact and lightweight. Powered by Lithium-ion technology and fully
protected against short circuit, overload and reverse polarity. Fitted with a 16,000mAh Lithium-ion battery and two USB Type A outlets (5V/3A,
9V/2A,12V/1.5A), Type C input & output leads (5V/3A,9V/3A,12V/2.5A,20V/1.5A), this unit can also supply several full charges for smartphones
and tablets/laptops. Capable of starting an average 8ltr petrol or 6ltr diesel engine. Integral LED ashlight. Waterproof to IP67 rating. Supplied in
a sturdy hard-shell zip up case.
3. SPECIFICATION
Model no: .................................................................. RS1200
Auxiliary Output:.....................................................................
................................USB (x2) both - 5V/3A, 9V/2A, 12V/1.5A
............................. Type C - 5V/3A,9V/3A,12V/2.5A,20V/1.5A
Cable & Clamp Length: .............................................. 385mm
Capacity:.................................16Ah @ 3.7V or 4Ah @ 14.8V
Maximum Current: ....................1200A Peak, 600A Cranking.
Maximum Starting Capacity: .................... 8L Petrol/6L Diesel
Size (W x D x H): ......................................100 x 45 x 185mm
Voltage:............................................................................12V
RS1200 Issue:1 06/06/22
Original Language Version
© Jack Sealey Limited
Refer to
instruction
manual
Wear eye
protection
Wear protective
gloves
Warning:
Electricity

4. OPERATION
4.1. CHARGING THE UNIT
NOTE: Ensure unit is fully charged before rst use.
4.1.1. Connect unit to power source using the Micro USB cable or
USB C cable.
4.1.2. Press On/O󰀨 button to turn on the unit. Charge indicator
lights will ash while charging and fully lit once fully charged.
4.1.3. Unplug cable when fully charged.
4.2. CHARGING EXTERNAL DEVICES
4.2.1. Connect the unit to the external device via the USB cable.
4.2.2. Press On/O󰀨 button to turn on the unit.
4.2.3. Turn unit o󰀨 and disconnect cable when external device is
fully charged.
4.3. LED TORCH/FLASHLIGHT
4.3.1. Press and hold the On/O󰀨 button for approximately 3 seconds to turn
the torch on constantly.
4.3.2. To cycle through settings, press once more for S.O.S. ash, once more for
constant ash and once more for O󰀨.
4.4. JUMP STARTING
NOTE: Before attempting to start your vehicle, ensure that at least 3 of
the 4 Charge Indicator lights are lit.
NOTE: When the Jump Start Connector is connected to the unit, DO NOT
allow the battery clamps to touch each other.
4.4.1. Insert Jump Start Connector into the unit and connect the battery clamps to the battery terminals.
4.4.2. The Clamp Indicator LED will ash red and green indicating it is safe to proceed.
NOTE: If only the red Clamp Indicator LED is lit, the Clamps may be connected in reverse. Reverse connections.
4.4.3. If the engine does not start, disconnect the Clamps, wait for 30 seconds and try again.
4.4.4. After 3 attempts, it is possible to use the Force Start function as described below.
4.4.5. Force Start method: Connect the clamps to the battery terminals and hold the Force Start Button down for 3 seconds. If the
indicator light of the Clamp is solid green, you need to start the vehicle within 30 seconds.
4.4.6. Once started, remove the unit from the battery.
5. TROUBLESHOOTING
6. MAINTENANCE
6.1. After use and before performing cleaning, unplug and disconnect the unit.
6.2. Use a dry cloth to wipe all battery corrosion and other dirt or oil from the battery clamps, cords, and the outer case.
Original Language Version
© Jack Sealey Limited
Item no. Description
1 On / O󰀨 Button
2 Charge Indicator LEDs
3 LED Torch / Flashlight
4 USB Output Port 1 (QC 3.0)
5 USB Output Port 2 (QC 3.0)
6 USB C Input & Output (PD30W)
7Micro USB Input Port (Charging)
8 Jump Start Port
9 Negative (Black) Clamp
10 Positive (Red) Clamp
11 Jump Start Connector
12 Clamp Indicator Light
13 Force Start Button
LED State Status
The red/green light will ash Ready to work
The red light is always on 1. Battery clamp is reverse connected.
-Check whether the clamp is reverse connected. Correct if required.
2. The clamp is short-circuited.
-Check whether two clamps are touching or connected to the same metal surface.
The red light is always on Reverse charging protection, the voltage of the car battery is higher than 12.6V.
-No jump starter needed, the car battery is enough to start your car.
The red light ashes quickly The temperature of the clamp exceeds 65(+/-5) degrees.
-Remove the clamp until the red/green light ashes.
The green light ashes slowly The voltage of the jump starter is too low.
-Recharge unit.
RS1200 Issue:1 06/06/22

Original Language Version
© Jack Sealey Limited
Sealey Group, Kempson Way, Suffolk Business Park, Bury St Edmunds, Suffolk. IP32 7AR
01284 757500 01284 703534 [e-mail] www.sealey.co.uk
Note: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts
without prior notice.
Important: No Liability is accepted for incorrect use of this product.
Warranty: Guarantee is 12 months from purchase date, proof of which is required for any claim.
WEEE REGULATIONS
Dispose of this product at the end of its working life in compliance with the EU Directive on Waste Electrical and Electronic Equipment
(WEEE). When the product is no longer required, it must be disposed of in an environmentally protective way. Contact your local solid
waste authority for recycling information.
ENVIRONMENT PROTECTION
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be sorted, taken to
a recycling centre and disposed of in a manner which is compatible with the environment. When the product becomes completely
unserviceable and requires disposal, drain any fluids (if applicable) into approved containers and dispose of the product and fluids
according to local regulations.
BATTERY REMOVAL
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential purchasers of products
containing batteries (as defined within these regulations), that they are registered with Valpak’s registered compliance scheme. Jack
Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
