Sealey TP6807 User manual

HIGH FLOW HEAVY-DUTY ROTARY PUMP
FOR 205L DRUM
MODEL NO: TP6807
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURYAND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
WARNING! Ensure health & safety, local authority, and general workshop practice regulations are strictly adhered to when using this
equipment.
9Familiarise yourself with the applications, limitations and potential hazards of this product.
9Maintain the pump in good condition (use an authorised service agent).
9Replace or repair damaged parts. Use genuine parts only. Non authorised parts will invalidate the warranty.
9 Useonlywithoils,diesel,anti-freezeandothernon-corrosiveuids.
9Ensure safety eye protection and protective clothing are worn when using this product.
9Keep the work area clean, uncluttered and ensure that there is adequate lighting.
9 Maintaincorrectbalanceandfooting.Ensuretheoorisnotslipperyandwearnon-slipshoes.
9Keep children and unauthorised persons away from the work area.
9Dispose of waste liquids in accordance with local authority regulations.
WARNING! DO NOTallowuncontrolleddischargeofuids,thuspollutingtheenvironment.
8DO NOT dismantle, tamper with or adapt the pump for any purpose other than for which it is designed.
8DO NOT use the pump if it has been dropped or mishandled, check the pump to ensure that it is not damaged.
8DO NOTusethepumpasahandletomovetheuidcontainer.
8DO NOT use the pump to transfer hazardous or harmful chemicals, corrosive liquids, solvents, alkalies, acids or petrol.
8DO NOT use the pump with water.
8DO NOT use the pump for any purpose other than for which it is designed.
8DO NOT use whilst under the infuence of drugs, alcohol or other intoxicating medication, or if you are fatigued.
9Keep the pump clean and well oiled and store in a safe, dry, childproof location when not in use.
2. INTRODUCTION
Heavy-duty cast steel body suitable for use with low viscosity products such as oils, diesel,
antifreezeandothernon-corrosiveuids.Suppliedwith2”BSPadaptorand3pcdip-tube
suitableforuseon205Ldrums.Deliversapproximately1L/revolution,emptyinga205Ldrumin
three minutes.
3. CONTENTS
Refertog.1
1.Handle+screw
2.Pumpbody
3.Lowertubewithlter
4.Uppertubesx2
5.2”BSPdrumtopattachment
6.Outputtube+clip
4. ASSEMBLY
4.1.  Attachthehandle(1)tothepump’sspindleandsecureinplacewithscrew.
4.2.  Assemblethetubesasfollows,rstlyscrewoneoftheuppertubes(4)intothepump
 andthenslidethedrumtopattachment(5)overthetubeandsecureitinplaceby
 tighteningthethumbscrew.Screwtheotheruppertubeintothersttube(iffulldepth
 required),andthenscrewthelowertube(3)intotheuppertube.
4.3.  AttachtheOutputpipe(6)ontothepumpoutletensuringitispushedfullyhome.Secureitinplaceusingtheclip.
4.4.  Beforeusingthepumpforthersttime,itneedstobelledwithoil.Standthepumpinitsnormaluprightpositionandremovetheoil
 llercaponthefrontofthepump.Fillwithsuitableoil(SAE30orequivalent),untilitislevelwiththebottomofthelleraperture.Re-t
 theoilllercapandtighten.
4.5.  Feedlowertubeintouidcontainerandsecurethedrumtopattachmentontothecontainertop(ifrequired).Thepumpisnowreadyto
use.
4.6.  Turnthepumphandleinaclockwisedirectiontopumpuid.
4.7.  Periodicallyremovethelterbyunscrewingitfromthebottomtubeandcleanitinparafnbeforere-ttingit.
Refer to
instruction
manual
Wear eye
protection Wear
protective
clothing
Original Language Version
©JackSealeyLimited TP6807|Issue:2(H,F)12/09/19
fig.1
