Quick Guide
Name: PUFF
Registration No: WN5739NZ
LOA: 34’-6”
Make/Model: J/105
Draft: 6’-6”
Year: 1995
Beam: 11’-0”
FCC call sign: WDJ668
Mast Height (above waterline): 50’-4”
Engine: Yanmar 2GM20F
Location/Access
Behind companionway steps
Engine Control Panel
In cockpit - port aft of binnacle
Engine Battery Switch
To port of engine cover in cabin
Engine Hour Meter
Port aft bulkhead in cabin
Fuel Gauge
Under port side settee
Ignition/Start
On Engine Control panel
Throttle
Combines direction and speed.
Shifting
● To engage transmission, push the lever starboard (fwd) or port (reverse)
until it “clicks” into place. To increase speed, continue to move the lever
forward or reverse, watching the tachometer to ensure speed isn’t too high.
● To disengage transmission, pull out the silver button and move the lever to
port. Speed can be adjusted when the lever is moved port or back;
transmission is disengaged as long as the silver button is out.
Engine Starting
1. Pull out the silver button to the starboard of the throttle lever.
2. With button out, push the throttle lever to port about 1/3
3. Insert key and turn to “on” position (alarm will sound)
4. Push in the start button for about 5-10 seconds and the engine should start
5. At this point the audible alarm should turn off. If not, Stop the engine
Stop Engine
Engine stop is on the port side of the binnacle

Electrical
AC Electrical Panel
AC panel located on aft starboard bulkhead in main cabin
House Battery Switch
Main DC breaker is located above chart table to the left. Selector switch is located to
port of engine cover. Use “1” or “2” to start engine.
Battery Charging
Charged by either shore power (make sure AC power and battery charger switch are
turned ON) or by running the engine.
Monitoring Batteries
Monitor levels when using DC services while the engine is not running.
Battery voltmeter is below the DC panel.
DC Electrical Panel
Located above the chart table, with the main breaker to the left of the chart table.
Electronics
GPS/Chartplotter
N/A
Depth/Speed/Wind
Instruments
Located on either side of the helm. To Use:
1. In main cabin, turn “Instruments” switch on the DC panel to “on”
2. Depth, speed and wind will read automatically.
Sails
Headsail
Jib that can be furled in to work as a storm jib. Unfurl slowly on windy days.
Mainsail
Outhaul is under the boom. Cunningham attaches at the mast above gooseneck. Boom vang
adjustments run back to cockpit cleats. Halyard runs along the port side to the cockpit clutch.
Tankage
Water Tanks
One tank onboard with a total capacity of 5 gallons. Please do not fill.
Tank is located beneath starboard settee
Fuel Tank
Location: Under port side setee
Fill Cap: Port forward of shrouds
Capacity: 12 gallons
Holding Tank
Capacity: 12 gallons
Location: Behind vanity
Pump-out Deckfill: Located on port midship; labeled “Waste”. Never pump the tank
overboard.

Head
Operation
Nothing goes in
the bowl that has
not been
consumed first.
Do not flush toilet
paper → put TP
in trash.
Make sure the water intake seacock is open (usually left open), which is under the v-berth,
port side
Head Operation:
1. Move selector switch to wet bowl
2. Pump 3-5 times to allow water into the bowl
3. After use, move the selector switch to “dry bowl” and pump contents until the bowl
is empty.
4. Move the switch back to “wet bowl”, pump again a few times to bring in water, then
change to “dry bowl”, pumping water through until the bowl is empty.

Bilge Pump
Bilge Pump
(Electric)
3-way switch below DC panel. Hold to “manual” for continuous or “auto” for intermittent
with a float switch. Always leave the switch on “auto” before leaving the boat.
Bilge Pump
(Manual)
Socket located aft portside in the cockpit next to the start panel. Handle is stowed in the
chart table.
To operate:
1. Insert handle into socket
2. Move handle up and down to allow the pump to prime. When the pump is
primed, moving the handle will be harder, but keep pumping as water is moving
through and out the bilge exit thru hull. Pumping will become easier as water
exits the boat.
3. Remove handle and place back in chart table.
2nd manual bilge pump is located in the port aft locker. Handle is stowed next to the
pump. Extend hose to bilge before use. Operation is the same as above.
General Notes
Refrigeration
N/A
Stove
Alcohol-based
Galley Sink
Seacock located in a cabinet under the sink.
Foot pump operates water; no water pump aboard
Head Sink
Seacock located under sink. Keep closed except for use.
Hot Water Heater
N/A
Anchor
Primary anchor: 33lb. Danforth anchor with 30 feet of chain and 200 feet of line marked
in 30 foot intervals from the chain.
Located in starboard locker in head.

Inventory
Item
Qty
Location
Air Horn & Can
1
Safety Box (clear tupperware in cabin)
Boat Hook
1
Starboard above setee
Bilge Pump Handle
2
1. Inside chart table 2. With manual bilge pump
Coast Guard
Regulation Placards
3
Oil discharge placard: above engine cover. MARPOL trash placard: above
engine cover. CO2 placard: port side of companionway
Deck Key
1
Inside chart table
Emergency Tiller
1
Under port settee, aft end
Fire Extinguishers
2
Port side of companionway & starboard galley
First Aid Kit
2
1. Galley 2. Head
Flashlight
1
Inside yellow safety box located in starboard locker in head area
PFD’s Type I
7
Hanging in starboard locker in head area
PFD Type IV -
throwable
2
1. Square cushion behind port settee
2. Life ring behind starboard setee
Tool & Repair Kit
1
Drawer under chart table
Vessel registration
1
Taped to bulkhead above chart table
Visual signal flares
3
Safety box (clear box)
Winch handles
2
Inside navigation table
Portable nav lights
2
Yellow safety box
Rigging knife
2
1. Yellow safety box 2. Binnacle
Beamlight
1
Yellow safety box

Safety Equipment Diagram
