Sebo AIRBELT C User manual

10
OWNER’S MANUAL
For Household Use Only

Technical Details 2
Important Safety Instructions 3
Special SEBO Product Features 4
S-Class Filtration 4
AIRBELT Shock Absorber 4
Bag Full or Clog Warning – Auto Shut-Off 4
Identification of Parts 5
Assembly 5
Optional Attachments 5
Standard Attachments 5
Operating Instructions 6
Starting the Machine 6
Suction Control 6
Operating the Machine 6
Additional Operating Instructions for C3.1 with Power Head 7
Starting the Machine and Suction Control 7
Operating the Machine 7
Using the Telescopic Tube, Hose & Attachments 8
Use and Maintenance of Brushes and Heads 8
The Parquet Brush 8
The Kombi Nozzle 8
The Turbo Head 8
Vacuum Maintenance 9
Changing the Filter Bag 9
Changing the Micro-Hygiene Filter 9
Changing the Exhaust Filter 9
Changing the AIRBELT 9
Clog Removal 10
Clogs in the Head or Brush 10
Clogs in the Telescopic Tube 10
Clogs in the Hose 10
Clogs in Entrance to Filter Bag 10
Trouble-Shooting Guide 11
AIRBELT C2.1 Schematic and Part Numbers 12
AIRBELT C3.1 Schematic and Part Numbers 13
Warranty 14
How To Contact SEBO 14
2
Vacuum motor 1250 watts (10.6 amps)
Water lift (at motor) 90 inches
Airflow (at motor) 170 CFM
Filter bag capacity 5.3 liter
Sound level 63 dBA
Body weight 16 lbs
Motor protection thermal cut-out
Cord length 22 feet
Range 36 feet
Technical details may be subject to change.
TABLE OF CONTENTS
TECHNICAL DETAILS

IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USING THIS MACHINE
3
1. Do not leave vacuum while plugged in. Unplug from
outlet when not in use and before servicing.
2. Do not use outdoors or on wet surfaces.
3. Do not use near small children or pets. Do not allow to be
used as a toy. Use of this product by children should
always be supervised by an adult.
4. Use only as described in this manual. Use only
manufacturer-recommended attachments.
5. Do not use with a damaged cord or plug. If vacuum is not
working as it should, has been dropped, damaged, left
outdoors, or dropped into water, take it to a SEBO service
center.
6. Do not pull or carry by cord, use cord as a handle, close a
door on cord, or pull cord around sharp edges or corners.
Do not run vacuum over cord. Keep cord away from heated
surfaces.
7. Do not unplug by pulling on cord. To unplug, grasp the
plug – not the cord.
8. Do not plug in if switch is in the “I” (ON) position.
9. Do not use outlets above counters to plug in vacuum –
damage to items in the surrounding area could occur.
10. Always carry the vacuum over steps and sills.
11. Do not handle plug or vacuum handle with wet hands.
12. Do not put any object into vacuum openings. Do not use
machine with any openings blocked. Keep openings free
of lint, hair, and anything that may reduce air flow.
13. Do not re-use filter bags or wash the filters.
14. Do not remove any screws from vacuum.
15. Do not vacuum up anything that is burning or smoking,
such as cigarettes, matches, or hot ashes.
16. Do not use vacuum without filter bag and/or filters in place.
17. Turn off all machine controls before unplugging.
18. Use extra care when cleaning on stairs.
19. Do not use machine to vacuum up flammable or
combustible liquids such as gasoline or use in areas
where they may be present.
20. Machines can cause a fire when operated near flammable
vapors or materials. Do not operate this vacuum near
flammable fluids, dust or vapors.
21. Maintenance and repairs must be done by qualified
personnel.
22. Use only original SEBO replacement parts.
23. Do not use vacuum as a step.
24. If vacuum is used on plush carpet or carpet with thick
padding, do not leave machine standing in one place with
machine turned on.
25. While the vacuum is in use, the power cord should be
unwound from the cable reel at least two thirds of its length.
Hold plug when rewinding onto the cord reel. Do not allow
plug to whip while rewinding.
26. Keep hair, loose clothing, fingers, and all parts of body away
from vacuum openings and moving parts. Do not place
fingers or other body parts under vacuum unless it is
unplugged.
27. Do not place the power head over rug or carpet edges.
28. The vacuum has a manual reset thermal protector. The
protector is reset by switching off the vacuum. The thermal
protector needs some time to cool down after switching off!
Check the vacuum for air blockages or mechanical failures
before switching on.
29. Store the vacuum in a dry place at room temperature. When
the vacuum is not in use, you should rewind the cord onto
the cord reel
30. Any other servicing should be performed by an authorized
service representative.
31. The hose contains electrical wires. Do not use if damaged,
cut, or punctured. Avoid picking up sharp objects.
32. Always unplug vacuum before connecting or disconnecting
either hose or power head.
33. Use a SEBO power head only in combination with a SEBO
vacuum cleaner.
34. Do not connect power head to a malfunctioning or damaged
vacuum.
When using an electrical appliance, basic precautions must always be followed.
To reduce the risk of electric shock, this vacuum cleaner has a polarized plug; one blade is wider than
the other. This plug will fit in a polarized outlet only one way. If the plug does not fit fully in the outlet, reverse the
plug. If it still does not fit, contact a qualified electrician to install the proper outlet. Do not change the plug in any
way. Connect only to the outlet type specified on the serial number plate underneath the machine.
SAVE THESE INSTRUCTIONS.
WARNING: To reduce the risk of fire, electric shock, or injury:
!

SPECIAL SEBO PRODUCT FEATURES
4
Your SEBO AIRBELT C canister vacuum is among the most technically advanced vacuum cleaners in the world.
Some of its unique features are:
• S-Class Filtration. Certified by leading Allergy foundations in Europe, the AIRBELT C vacuum provides the
user with S-Class filtration of 99.9% of particles to 0.3 microns. This is accomplished by the SEBO three-step
filtration system. First, the three-layer full-size filter bag (a) collects the vast majority of the debris. Then, the
remainder of the particles are collected by the hospital-grade microfilter (b). Finally, the micro-exhaust filter
(c) cleans the exhaust air that the vacuum emits. The AIRBELT disperses the filtered exhaust air around the
canister which provides quiet, gentle air flow. SEBO’s unwavering attention to the complete sealing of the
machine ensures no dirt escapes around the microfilters. If the microfilters are changed regularly (every 10-
20 bags), the AIRBELT C is perfect for allergy or asthma sufferers.
• AIRBELT Shock Absorber. Your SEBO canister vacuum has a unique soft bumper (d) which protects your
furniture, walls and vacuum from damage. The AIRBELT disperses the filtered exhaust air around the canister
which provides quiet, gentle air flow. Personalize your canister with a replacement AIRBELT textile cover avail-
able in a variety of patterns and colors (part # 6047 AM/01 to 10). See your SEBO Dealer.
• Bag Full or Clog Warning Light – Auto Shut-Off. If the vacuum’s airflow pathway becomes restricted
due to a full bag or the existence of a clog, the amber “BAG FULL OR CLOG” light (located on top of the canis-
ter near the hose connection) will illuminate. If the user ignores this warning, the suction motor will heat up
due to the lack of cooling provided by the airflow. Once the motor reaches a certain temperature it will shut off
to protect itself from damage. The user should turn the switch off, unplug the machine and immediately insert
a new bag or remove the clog (to remove a clog, refer to the Clog Removal section on page 10). After approxi-
mately 30 minutes, the motor will have cooled and the vacuum can be restarted. If the airflow is still restrict-
ed, the “BAG FULL OR CLOG” light will again illuminate and the machine will shut off.
Bag full or clog warning light
a
b
c
d
S
u
p
e
r
q
u
i
e
t
a
i
r
e
x
h
a
u
s
t
a
l
l
a
r
o
u
n
d
!
SEBO three-step filtration system

IDENTIFICATION OF PARTS
5
11. AIRBELT shock absorber
12. Carrying handle
13. Warning lights
14. On/Off pedal
15. Attachment housing door
16. Cable rewind button
17. Power cable
18. Parking holder, rear
19. Mains Cable (C3.1 only)
20. Filter bag cover release flap
21. Filter bag cover
22. Micro-exhaust filter housing
Push the neck (6) of the hose (10) into the suction opening of the canister
(7). The notch in the suction opening will line up with the raised bar on the
neck. When the notches are lined up correctly, the neck will snap firmly into
place. To release the hose from the suction opening, press the release tab
on the neck of the hose, and pull the neck out.
Attach the short mains cable (19 - C3.1 only) on the underside of the handle
by connecting one cable plug where the hose connects to the handle and the
other where the handle connects to the telescopic tube.
Connect the handle (1) to the top of the telescopic tube (4). Snap in place. To
release the telescopic tube (4) from the handle, push the handle release
button (3) and slide the handle out.
Attach the head or brush to the bottom of the telescopic tube (4). Insert the
bottom of the telescopic tube into the neck of the head or brush (26) until it
locks into place; or line up the square hole in the telescopic tube with the
notches in the front of the neck, and snap firmly into place. To release a head
or brush from the telescopic tube (4), push the release button (9), and pull
the head or brush tool off the end of the telescopic tool. The release button
(9) is in the same position on all of the heads, brushes and power heads.
NOTE: To attach a SEBO power head (ET-H, ET-C, ET-1 or ET-2) to your
C3.1 canister, please refer to your power head owner’s manual (page 5)
for instructions. Attaching incorrectly could cause damage.
Brushes, Heads, Optional Attachments
26. Premium Parquet brush - standard for the
C2.1 and C3.1 - Part # 7200 DG
27. Kombi nozzle - optional for the
C2.1 and C3.1 - Part # 7260 DG
28. Turbo head - standard for the C2.1.
Optional for the C3.1 - Part # 6780 ER
29. Radiator brush - Part # 1496 HG
30. Straight tube (20 in.) - Part # 1084 HG
31. Charcoal Filter for odor control -
Part # 6108 AM
Standard Attachments
23. Crevice nozzle
24. Upholstery nozzle
25. Dusting brush
NOTE: All illustrations shown in this manual
represent the C3.1 model except where part
numbers and instructions are different for
each model.
1
2
3
4
5
6
7
8
9
33
10
12
13
14
15
16
17
18
Power Heads - optional for the C3.1
32. ET-C Power head, White, Part # 9254 AM
33. ET-H Power head, White, Part # 9256 AM
ET-H Power head, Red, Part # 9257 AM
34. ET-1 Power head, White, Part # 9258 AM
ET-1 Power head, Red, Part # 9299 AM
35. ET-2 Power head, White, Part # 9259 AM
26
31
28
1. Handle grip
2. Power control slider (C3.1 only)
3. Handle release button
4. Telescopic tube
5. Slide button
6. Hose neck
7. Suction opening
8. Parking holder, side
9. Tool release button
10. Hose
11
19
27
30
29
ASSEMBLY
32 33
26
9
7
6
10
1
4
3
34 35
24
23
25
20
21
22

6
OPERATING INSTRUCTIONS ALL C-SERIES VACUUMS
Starting The Machine - Figures 1 & 2
Before turning on your canister, make sure that you have a firm hold on the
handle grip to keep the machine from moving forward (figure 1).
1. With the canister main power switch (14) in the OFF position, pull the
power cord out from the base of the canister. The power cord (17)
should be unwound from the cable reel at least two thirds of its
length. Note: do not over-extend the cord. The cable rewind is oper-
ated by pressing the rewind button (16). Before rewinding the cable,
always switch off and unplug the vacuum.
2. Plug the polarized power cord into a 120 volt wall outlet located near
the floor.
3. Press the main power switch on the base of the canister (14) gently
with your foot or hand. The green light (13) will illuminate indicating
that the power is on (C3.1 model only).
Operating the Machine - Figure 3
Adjust the telescopic tube (4) to the correct height by pushing the slide button (5) and
gently pulling the tube out to lengthen, or pushing it in to shorten. Release the slide but-
ton (5) to lock the tube to the adjusted height.
When changing heads, always switch the vacuum off with the main power switch (15), and
then unplug the power cord.
The “bag full or clog” light (#13, figure 1) works correctly only at full power. At lower power
levels, the “bag full or clog” light may illuminate incorrectly. Check the status of the filter
bag regularly at full power. If the light remains illuminated at full power, and the filter bag
is not full, check for clogs (see page 10).
To rewind power cord, switch the vacuum off with the main power switch (14), unplug the
machine, then press the rewind button (16). Hold the plug while rewinding the cord onto
the cord reel. Avoid letting the plug whip while rewinding.
WARNING! The quality, condition, coating, texture, age and manufactur-
ing technique of all floor surfaces vary. Therefore, vacuums with rotating brushes, includ-
ing your SEBO, may damage some floor coverings or surfaces. Some types of high-gloss
hardwood floors, cushion vinyl, berber carpets, long shag, and delicate or hand-woven car-
pets are particularly vulnerable to damage by rotating brushes. When possible, consult the
materials supplied by your flooring manufacturer for information on proper upkeep and
cleaning. To ensure that your new SEBO vacuum cleaner is compatible with your floor,
please test the vacuum cleaner on each type of flooring surface in a small inconspicu-
ous area to determine if any damage occurs. If damage occurs, stop using the vacuum
cleaner immediately!
!
4
5
14
16
13
Figure 1
17
Figure 3
Suction Control - Figure 2
C2.1 users: the suction control dial is located on the top side of the canister on the power
switch (14). When the dial shows all yellow, the machine is operating at full suction.
Rotate the dial toward the black to reduce suction for vacuuming curtains or delicate fab-
rics.
C3.1 users: for information on suction control,
refer to page 7 of this manual.
Suction Control dial on
the C2.1 canisters
Figure 2
14

7
Starting The Machine and Suction Control - Figures 4,
5 & 6a
A. Before turning on your canister, make sure that the vacuum handle is
in its upright locked position (figure 4).
1. With the canister main power switch in the OFF position, and the
power control slider on the handle (#2, figure 5) in the OFF position,
pull the power cord out from the base of the canister. The power cord
should be unwound from the cable reel at least two thirds of its length.
The cable rewind is operated by pressing the rewind pedal (16).
Before rewinding the cable, always switch off and unplug the vacuum.
2. Plug the polarized power cord into a 120 volt wall outlet located near
the floor.
3. Press the main power switch on the base of the canister gently with
your foot or hand. The green light (13) will illuminate indicating that
the power is on.
4. Slide the Power Control Slider (#2, figure 5) to the ON position (the
slider will “click” when it is pushed out of the OFF position). It will then
slide freely between 0 suction and MAX suction. Set the slider to the
suction desired. Release the foot pedal (ET-1, ET-2, ET-C) on power
head (#36, figure 6a) or, for the ET-H, lower the handle (figure 6b).
Switch Position - #2, Figure 5
0 = Zero Suction
MAX = Maximum Suction
ON position - Slide the slider down toward
0 suction till it “clicks” out of position.
OFF position - Pull the slider up to 0 suc-
tion then continue pulling the slider up
until it “clicks” into the OFF position.
Operating The Machine - Figures 6a & 6b
B. When the power head is on with the handle in the upright locked posi-
tion (see figure 4 above), the brush roller will not spin.
To release the ET-C, ET-1 or ET-2 power head from the upright locked
position, press down on the foot pedal (#36, figure 6a) and lower the han-
dle into the normal operating position. The brush roller will then start
spinning and the green light on the power head will illuminate.
To release the ET-H power head from the upright locked position, gently
place your foot on the power head for leverage and lower the handle into
the operating position (figure 6b). The brush roller will then start spinning.
The amber indicator light may flicker for a few seconds when you lower
the handle - this is normal.
The handle can be lowered to a horizontal position useful for vacuuming
under beds.
You may adjust the suction control with the power control slider (#2, fig-
ure 5) as you vacuum different surfaces or when using the accessory tools.
For optimal cleaning and brushing, operate the machine at the maximum
suction power setting and push the power head slowly over the carpet.
When the canister’s main power switch is in the ON position, you may turn
the power head off and on with the power control slider (#2, figure 5). To
turn the power head off using the power control slider, pull the slider to 0
suction, then continue pulling the slider up until it “clicks” into the OFF
position. The green power head light will then shut off (the green light on
the canister (10) will remain illuminated until the vacuum is powered off
using the main power control knob).
Always turn the power off on both the canister and the power head when
changing heads or unplugging the vacuum. Slide the power control slid-
er on the power head to its OFF position, press the main power switch on
the base of the canister gently with your foot or hand, then unplug the can-
ister to completely shut down the power when changing heads or storing
the vacuum. Hold the plug while rewinding the cord onto the cord reel.
Avoid letting the plug whip while rewinding.
Figure 6b
Please refer to your power head owner’s manual for more information
ET-C power head
ET-2 power head
ADDITIONAL OPERATING INSTRUCTIONS FOR C-3.1 WITH POWER HEAD
Figure 6a
Figure 4
Figure 5
2
36
ET-H power head

8
To remove a brush or power head, switch off the power and unplug the
vacuum. Then, press the tool release button (9) and pull the tube out.
NOTE! C3.1 users with ET-C, ET-H, ET-1 or ET-2 power heads, please refer to your
power head user’s manual for more detailed instructions for operating and main-
taining your power head.
Premium Parquet nozzle - Figure 9
The parquet nozzle is specially designed for use on hard surfaces. The brush should be
cleaned regularly. Remove the parquet brush from the telescopic tube to clean. Fibers
and hair can be pulled out of the bristles manually, or vacuum the bristles with with the
telescopic tube. The brush strips are removable for cleaning and replacement.
Kombi nozzle - Figure 10
The Kombi nozzle is adjustable for carpet or hard floors. To set for carpet, slide the up
arrow button (37) to the right until it clicks into place. The hard floor dusting brush will
raise up allowing the head to move over the carpet. To set for hard floors, slide the down
arrow button (38) to the left until it clicks into place. The brush will lower to gently sweep
your floors. The slider in Figure 10 is set in the position for carpet. The brush should be
cleaned regularly. Remove the Kombi nozzle from the telescopic tube to clean. Fibers
and hair can be pulled out of the bristles manually, or vacuum the bristles with with the
telescopic tube. The brush strip is removable for cleaning and replacement.
Turbo head - Figure 11
The Turbo head has an air-driven rotating brush for gentle brushing of carpets. The
Turbo head can be adjusted for high and low pile carpet. To adjust the head for high
pile carpet, push the slider button (39) to the right. For low pile carpet, push the slid-
er button (39) to the left. The slider in Figure 11 is set in the high pile position. The
rotating brush should be cleaned regularly. Remove the Turbo head from the tele-
scopic tube to clean. Remove fibers and hair from the brush manually.
The telescopic tube (4) is useful for vacuuming corners and hard-to-reach areas. You
may use the telescopic tube without a brush, power head or attachment. To remove a
brush or power head, switch off the power and unplug the vacuum. Then, press the
tool release button (9) and pull the tube out. The standard attachments [the crevice
nozzle (23), upholstery nozzle (24) and dusting brush (25)] may be inserted onto the
end of the tube. It is not necessary to turn off the vacuum while switching the stan-
dard attachments (the crevice nozzle, upholstery nozzle or dusting brush). After use,
switch off the power, unplug the vacuum and remove attachment. Re-insert the
attachment tube into the power head or brush, turning the tube if needed, until you
hear it click into place.
NOTE! C3.1 users with ET-C, ET-H, ET-1 or ET-2 power heads, please refer to your
power head user’s manual for more detailed instructions for connecting your power
head.
To use the hose without the telescopic tube, switch off the power and unplug the vacu-
um. Push the handle release button (3) and pull the HANDLE out of the end of the tele-
scopic tube. Do not try to separate the hose from the handle! Insert an attachment tool,
if desired, onto the end of the handle. After use, switch off the power, unplug the vacu-
um, remove attachment. Re-insert the handle into the telescopic tube making sure it
is seated correctly and snap it into place.
Figure 7
Figure 8
33
9
Using the Telescopic Tube, Hose & Attachments - Figures 7 & 8
4
3
Figure 9
Figure 11
Figure 10
38
▲
▲
Always unplug vacuum from outlet before
dismantling any part of machine!
!
USE AND MAINTENANCE OF BRUSHES AND HEADS
37
39
▲
▲
▲
▲

9
VACUUM MAINTENANCE
Changing the Filter Bag - Figures 12 & 13
To change the filter bag, set the canister upright (as shown in figure 13), pull the
cover release flap outward (20) and lift the cover (21) from the filter bag housing.
The cover release flap must remain in an outward “pulled-out” position to
change filter bags and lock them into place. Squeeze the clamps (42) on both
sides of the filter bag sealing plate (41), slide the plate from the holder (40) and
push the filter bag cap on to seal the bag. Slide the sealing plate (41) of a new bag
into the holder and push it in firmly until it locks into place. Re-insert cover (21)
into filter bag housing, push it forward, then lock it in place by pushing down the
cover release flap (20). You may find it convenient to store the bag cap inside the
filter bag housing below the filter bag. Do not re-use the filter bags. Note: the
nature of the contents of the filter bag will affect the point at which it needs chang-
ing. Fine dust may require an earlier change even though the bag is not full. Fluff
or hair allows air to pass through easily, so the filter bag may overfill before the
amber “bag full” light illuminates.
Changing the Exhaust Filter - Figures 13 & 14
The exhaust filter (43) needs to be changed when it becomes extremely dirty or
clogged with dust, or after approximately 10 to 20 filter bags have been used. To
remove the exhaust filter, set the canister upright (as shown in figure 13), pull the
cover release flap (20) outward and lift the cover (21) from the filter bag housing.
Then, slide the exhaust filter housing (44) out. Pull the filter out. To replace, slide
the new filter into the exhaust filter housing. Replace the exhaust filter housing
(44), re-insert cover (21) into filter bag housing, push it forward, then lock it in
place by pushing down the cover release flap (20).
Figure 13
Figure 14
Figure 15
Always unplug vacuum from outlet
before dismantling any part of machine!
!
Micro-Hygiene
Filter
Part #6191 AM
Exhaust Filter
Part #6033 AM
Changing the AIRBELT - Figure 15
If damage occurs to the AIRBELT cover, it will need to be replaced. To remove the
AIRBELT (11), pry off the clip (46) by inserting the tip of a slot-head screwdriver
under the bottom side of the clip. Push downward on the screwdriver until the clip
pops off. Grasp the edge of the AIRBELT cover and pull - the AIRBELT cover will
peel off. The foam bumper (47) remains on the vacuum. To replace the AIRBELT,
insert the side ribs into the grooves (48). Start at the back, insert rib into one
groove (48), and while holding it down, stretch the AIRBELT cover around the foam
into the opposite groove (48). Continue around the vacuum. Secure the ends with
the clip (46).
SEBO AIRBELT covers are available in a variety of colors and patterns. See your
SEBO dealer for available selection.
Changing the Micro-Hygiene Filter - Figures 13 & 14
After 10 to 20 bags have been used, change the micro-hygiene filter (45). To
remove the micro-hygiene filter, set the canister upright (as shown in figure 13),
pull the cover release flap (20) outward and lift the cover (21) from the filter bag
housing. Then, slide the filter (45) out. To replace, slide in the new filter, re-
insert cover (21) into filter bag housing, push it forward, then lock it in place by
pushing down the cover release flap (20).
Figure 12
20
21
22
21
40
41
42
43
45
44
Note: Never operate the vacuum with incorrectly attached filters or without
filters, bag, AIRBELT or filter bag housing cover (21). Do not re-use filter bags.
Do not wash and re-use filters.
46
11
47
11
48
48
Filter Bag
Part #5093 AM
AIRBELT cover
Part #6047 AM/01-08

CLOG REMOVAL
10
NOTE! C3.1 users with ET-C, ET-H, ET-1 or ET-2 power heads, please refer
to your power head user’s manual for more detailed instructions for remov-
ing clogs in your power head.
If the “bag full or clog” warning light (10) remains illuminated after the fil-
ter bag has been changed and the filters are in good condition, there is like-
ly a clog in the system.
Clogs in the Head or Brush - Figure 15
Clogs in the swivel neck (49) of a head or brush can be cleared by first press-
ing the tool release button (9) and removing the brush or head. Check inside
the swivel neck channel (49), and clean out pathway.
Clogs in the Telescopic Tube - Figure 15
Remove head from telescopic tube (4) by pushing the tool release button and
pulling the tube out. Remove the hose from the top of the telescopic tube by
pushing the handle release button (3). A stiff wire or stick can be used to push
the clog out of the tube.
Clogs in the Hose - Figure 16
To clear blockages in the hose (10), remove the telescopic tube (4) by pushing
the tool release button and pulling the tube out. Hold the hose upright with
one hand blocking the top and switch on the machine. If necessary, quickly lift
your hand on and off the end of the hose. If that does not clear the clog, you
may also clear clogs by reversing the hose. After removing the telescopic
tube, push the release button on the hose neck (6) and remove the hose from
the machine. Insert the opposite end of the hose (10) into the suction neck (7).
Hold the hose upright with one hand blocking the top and switch on the
machine. If necessary, quickly lift your hand on and off the end of the hose.
Note: Do not insert a wire or stick into the hose. Doing so may cause dam-
age to the hose.
Clogs in Entrance to Filter Bag - Figure 17
Remove hose (10) from vacuum cleaner (see figure 16) and remove filter bag
cover (figure 13, page 9). Clean out entrance to bag (50).
Figure 16
Always unplug vacuum from outlet before removing
any clogs!
!
4
3
9
Figure 17
6
1
7
Figure 15
49
10
50

TROUBLE-SHOOTING GUIDE
11
PROBLEM
Does not turn on
Bag full or clog light on
Bag full or clog light on
& machine shuts off
Does not pick up
Filter bag door won’t
fully close
REASON
1. Telescopic tube not inserted properly.
2. Not plugged into working outlet.
3. Cable worn.
4. C3.1: The power control slider
switch is set to “0” (“off” position).
1. Bag full.
2. Clog in hose, telescopic tube,
brush or head, or entrance to
filter bag.
3. Micro-hygiene filter dirty.
4. Exhaust filter dirty.
1. Hose/handle assembly not
correctly inserted.
2. The suction control dial is rotated
to no suction setting
3. Filter bag cover not closed.
1. Cover release flap not fully closed.
2. Bag not inserted properly
3. Micro-hygiene filter not properly
inserted.
SOLUTION
1. See page 5.
2. Use another outlet.
3. Replace cable.
4. C3.1: Set slider switch to “on”
position. See page 7.
1. Replace filter bag. See page 9.
2. See Clog Removal on page 10.
C3.1 users with clog in power
head attachment: refer to clog
removal in the ET-C, ET-H, ET-1
or ET-2 owner ’s manual.
3. Replace micro-hygiene filter.
See page 9.
4. Replace exhaust filter. See page 9.
1. Reinsert hose/handle assembly
making sure that it is lined up
properly and is snapped into
place. See page 5.
2. C1.1 & C2.1: Rotate suction control
dial to yellow setting. See page 6.
3. See below.
1. Reinsert bag. Lock the cover
release flap (20) down firmly.
2. Reinsert bag with cover release
flap (20) up, until firmly latched in
bag holder (see pg. 9, figures 12 &
13).
3. Remove the filter bag cover (21) and
make sure the micro-hygiene filter
housing is seated firmly in place
(see pg. 9, figure 14).
Always unplug vacuum from outlet before dismantling any part of the machine!
!

12
Teal Machine
Pos. Part # Description
16383 TK Attachment cover - C2.1 teal
6382 AM C1.1 teal
26045 Spring
36168 DG Bearing block / hinge
46117 ER Attachment clip set of 3
56083 DG Release button
66128 Foam seal
76309 TK On/Off pedal (incl. Pos. 8)
86143 Spring
96006 TK Seal
10 6008 DG Parking holder, rear
11 6127 TK Top Casing - C2.1 teal
13 6007 DG Plug surround
14 6192 Motor cover
15 6023 Spring
16 6022 Rod
17 6165 Vacuum motor 120 V 1250 W
5101 Carbon brush vac motor
18 6306 Seal, motor cover
19 6193 Motor cover
20 6188 ER Rubber mounting (2 pcs.)
21 6173 Engine mounting
22 6189 Engine mounting
23 6368 US Cable rewind unit
24 6293 Air Adapter
25 6291 Internal cable
26 6295 ER Electronic Controller C2.1 120 V
27 6088 Elbow
28 6186 Seal
29 6197 DG Bottom casing - dark gray
30 6319 UL Suction neck
31 6014 Seal
32 6042 Spring lock
33 6009 DG Parking holder - side
34 6027 ER Pin
35 6095 DG Castor, complete
36 6191 AM Hospital grade microfilter
37 6187 Seal, bag cover
38 6034 Seal, microfilter
39 6003 DG Microfilter holder
40 6033 AM Exhaust filter
6108 AM Carbon-anti-odor filter (optional)
41 6093 DG Bag cover, complete
42 6036 DG Cover release with seal
43 6039 Bearing cover
44 6094 Bag holder cpl. (incl Pos. 45)
45 6170 ER Safety catch with spring
46 6300 HG Handle grip cpl. - light gray
6300 DG Handle grip cpl. - dark gray
47 6303 HG Retaining ring - light gray
6303 DG Retaining ring - dark gray
48 6355 AM Hose with end couplings - 7 ft.
6343 DG Hose with end couplings - 6 ft.
49 1726 HG Telescoping tube C2.1 - light gray
6271 DG Telescoping tube C2.1 - dark gray
50 6120/3 Foam seal
51 5091 Safety catch spring
52 6213 Foam seal
53 6086 ER Casing clip / set of 3
54 6046 UL Foam bumper
55 6047 AM/01 AIRBELT textile cover - dark gray
56 6048 DG AIRBELT clip
57 0102 Screw F 3.9 x 13
58 0199 Screw M4 x 12
59 1491 DG Upholstery nozzle
60 1092 DG Crevice nozzle
61 1329 DG Dusting brush
62 6780 ER Turbo head- dark gray
(Standard with C2.1)
63 7200 DG Premium Parquet nozzle-dark gray
(Standard with C2.1)
C2.1 AIRBELT SCHEMATIC AND PARTS LIST
Canister with Handle/Hose
Red Machine Exceptions
Pos. Part # Description
16383 AM Attachment cover - C2.1 red
76309 DR On/Off pedal (incl. Pos. 8)
96006 DR Cable rewind pedal - red
11 6127 DR Top casing - C2.1 red
62
63
# 9648 AM C2.1 (Teal) # 9646 AM C2.1 (Red)

13
C3.1 AIRBELT SCHEMATIC AND PARTS LIST
White Machine
Pos. Part # Description
16215 AM Attachment cover - white
26045 Spring
36168 DG Bearing block / hinge
46117 ER Attachment clip set of 3
56083 DG Release button
66128 Foam seal
76005 GW On/Off pedal (incl. Pos. 8)
86143 Spring
96006 GW Cable rewind pedal
10 6008 DG Parking holder, rear
11 6397 GW Top casing C3.1 - white
13 6007 DG Plug surround
14 6192 Motor cover
15 6023 Spring
16 6022 Rod
17 6165 Vacuum motor 120 V 1250 W
05101 Carbon brush vac motor
18 6306 Seal, motor cover
19 6193 Motor cover
20 6188 ER Rubber mounting (2 pcs.)
21 6173 Engine mounting
22 6189 Engine mounting
23 6368 US Cable rewind unit
24 6293 Air Adapter
25 6291 Internal cable
26 6407 ER Electronic Controller C3.1 120 V
27 6088 Elbow
28 6186 Seal
29 6197 GW Bottom casing - white
30 6318 UL Suction neck
31 6014 Seal
32 6042 Spring lock
33 6009 DG Parking holder - side
34 6027 ER Pin
35 6095 DG Castor, complete
36 6191 AM Hospital grade microfilter
37 6187 Seal, bag cover
38 6034 Seal, microfilter
39 6003 GW Microfilter holder
40 6033 AM Exhaust filter
6108 AM Carbon-Anti-odor filter (optional)
41 6093 GW Bag cover, complete
42 6036 DG Cover release with seal
43 6039 Bearing cover
44 6094 Bag holder, cpl. (incl Pos. 45)
45 6170 ER Safety catch with spring
46 6348 AM Handle w/hose C3.1, cpl.
Light Gray - 6 ft.
6349SE Handle w/hose C3.1 & K3, cpl.
Dark Gray - 6 ft.
6349 AM Handle w/hose C3.1 & K3, cpl.
Dark Gray - 7 ft.
47 6270 DG Telescoping tube C3.1
48 6369 DG Mains cable - dark gray
6369 UL Mains cable - light gray
51 6120/3 Foam seal
52 6213 Foam seal
53 6086 ER Casing clip / set of 3
54 6046 UL Foam bumper
55 6047 AM/01 AIRBELT textile cover
56 6048 DG AIRBELT clip
57 0102 Screw F 3.9 x 13
58 0199 Screw M4 x 12
59 1491 DG Upholstery nozzle
60 1092 DG Crevice nozzle
61 1329 DG Dusting brush
63 7200 DG Premium Parquet nozzle - dark gray
(Standard with C3.1)
64 6421 DG Slider button, cpl.
65 6420 DG Tube release button, complete
# 9630 AM C3.1 (White) # 9652 AM C3.1 (Red)
Canister with Handle/Hose
63 Red Machine Exceptions
Pos. Part # Description
16383 C3 Attachment cover - C3.1 red
76005 DR On/Off pedal (incl. Pos. 8)
96006 DR Cable rewind pedal - red
11 6397 DR Top casing - C3.1 red
29 6197 DG Bottom Casing C3.1 - dark gray
41 6093 DG Bag Cover cpl. - red

SEBO VACUUM CLEANER WARRANTY
Five Years Non-Wear Parts - Five Years Motor - One Year Labor
1. Your authorized SEBO dealer or SEBO will provide the
original product purchaser with replacement of Non-
Wear Parts which fail due to a material or workman-
ship defect for a period of five (5) years from the orig-
inal date of purchase of new product. SEBO America
will provide a five (5) year warranty on suction motors
and brush drive motors.
2. Your authorized SEBO dealer or SEBO will repair (or will
cover labor charges associated with repair) a defective
SEBO vacuum cleaner at no cost to the original pur-
chaser, within one (1) year of original purchase of new
product.
3. SEBO America or an authorized SEBO dealer must
complete all warranty repairs.
4. To locate an authorized SEBO dealer in your area, or to
register a warranty claim in the United States of
America, please visit our website at www.sebo.us.
5. To locate an authorized SEBO dealer in your area, or to
register a warranty claim in Canada, please call Floor
Care Equipment, Ltd. at [phone].
6. The warranties provided for above apply exclusively to
SEBO Vacuum Cleaners which are used residentially.
No warranty is provided for SEBO vacuum cleaners
used commercially.
7. The Wear Parts excluded from warranty coverage
include filter bags, micro-hygiene filters, exhaust
14
filters, the cable (external cord), the attachment hose,
the brush rollers, the front bottom plate, the rear
bottom plate, the telescopic tube, the crevice nozzle,
the upholstery nozzle, the dusting brush and all of the
optional attachments. (See “Optional Attachments” on
page 5 of this manual).
8. This warranty applies only while your SEBO Vacuum
Cleaner is physically located within the United States of
America and its territories or Canada.
9. The purchase receipt showing the date, price, and item
of purchase is the initial document of proof of purchase
and determines the validity of warranty. To be certain
that your warranty claim can be processed as quickly
and efficiently as possible, please retain your original
purchase receipt and mail in the warranty card provided
with your new SEBO vacuum cleaner. You may also reg-
ister on our website at www.sebo.us.
10. This warranty gives you specific legal rights. You may
also have other legal rights, which vary from
state/province to state/province.
11. SEBO America will not process nor will it accept
responsibility for warranty claims for machines pur-
chased from dealers located in Canada. Floor Care
Equipment, Ltd. will not process nor will it accept
responsibility for warranty claims for machines pur-
chased from dealers located in the United States.
EXCLUSIVE REMEDY: The remedies provided under the terms of this Warranty are the purchaser’s exclusive remedies
and are in lieu of any other remedies otherwise available.
THE WARRANTY DOES NOT COVER:
• Used or secondhand products.
• Products outside of the warranty period.
• Items not manufactured by SEBO.
• Normal maintenance service.
• Equipment damaged by improper use, accident,
other casualty or negligence.
• Machines equipped with nonauthorized
attachments or modifications.
•Machines on which the serial number has been
altered or removed.
LIMITATIONS AND EXCLUSIONS:
SEBO MAKES NO OTHER REPRESENTATIONS OR WARRANTIES,
EXPRESSED OR IMPLIED AND SPECIFICALLY EXCLUDES THE
IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE.
SEBO WILL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUEN-
TIAL DAMAGES OF ANY KIND OR NATURE.
THIS DISCLAIMER OF IMPLIED WARRANTIES SHALL NOT
APPLY TO THE EXTENT SAID DISCLAIMER IS NOT ALLOWED BY
APPLICABLE STATE/PROVINCIAL LAW.
To contact SEBO in the United States of America:
SEBO America, LLC
Telephone: [phone]
Fax: [phone]
Website: www.sebo.us
To contact SEBO in Canada:
Floor Care Equipment, Ltd.
Telephone: [phone]
Fax: [phone]
Website: www.sebocanada.ca
© Copyright SEBO America, LLC • All rights reserved.
