SECO-LARM Mini Timer Module SA-026 User manual

The ENFORCER SA-026 is a low-voltage miniature delay timer module
which operates on 12 to 24 volts AC or DC. This timer module will extend
the activation time of a momentary contact switch for 1~60 seconds
via a field-adjustable rotary pot. It is ideal for electrical locks which do
not have a built-in time delay function. Its compact size makes it small
enough to fit in a single-gang box or inside a door frame cavity.
Adjustable timer from 1~60 seconds via a pot on board.
N.O./N.C. switch trigger.
Compact design: 1.2” X 2.28” X 0.62” (30 x 58 x 16 mm)
Operating voltage: 12~24 volts AC or DC.
Current: 2mA (stand-by), 75mA (active).
Relay output: Form-C (SPDT) via terminal blocks.
Contact rating: 2 Amps @ 24VDC.
With built-in beeper output (100mA @ 24VDC).
Includes double-sided foam tape.
1.949.261.2999 (CA & Int’l) 1.800.662.0800 Fax: [phone]
Email: [email protected] Website: www.seco-larm.com
16842 Millikan Avenue, Irvine, CA 92606 SA-026TIMERMODULE.cdr
Mini Timer Module
Features:
The SECO-LARM policy is one of continual development. For that reason, SECO-LARM reserves the right to change prices and specifications without notice. SECO-LARM is not responsible for misprints.
Copyright 2007 SECO-LARM U.S.A., Inc. Allrights reserved.
SA-026
SA-026
SECO-LARM®
Electrical exit
locking devices
such as magnetic locks
and electric strikes.
Beeper
Power (non polarity)
TRG.(COM)
TRG.(N.C.)
TRG.(N.O.)
-
+
To N.O. switch
To N.C. switch
Relay O/P (N.C.)
Relay O/P (N.O.)
Relay O/P(COM)
(Buzzer, -)
(Buzzer, )
+
To N.O. device
To N.C. device
Sample Connection Diagram:
For Fail-Safe Electronic Locks
Also available:
SD-7202GC-PT
Illuminated Push-To-Exit
PlatewithBuilt-inTimer
SD-7201GA-PT1
Push-To-ExitPlate with
Built-inTimer
SA-025
Multi-Function
ProgrammableTimer
SR-2224-C5
DPSTRelay Board
(Actual size)
Power (non polarity)
PUSH
TO
EXIT
12~24 volts
AC or DC
Power Supply
Trigger Devices:
Push-to-Exit
Switches,
Keypads, Control
Panels, etc.
