Grove - Recorder V3
This is the latest version of Grove-recorder, and also the best
version. Comparing the previous one, there are some updates that
we would like to mention.
First change is MCU. In V3.0, the MCU is upgraded from to be
ISD9160FI, which is more powerful than the old one ISD1820PY.
How is it more powerful? Together with the newly added 2Mbytes

7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
2/12
ash, it allows you to record up to 83 seconds, much longer than
previous 12 sec record.
Secondly, if you have ever used previous version, you would know
that if you want to play back what you have recorded, you need to
press another button on the Grove button that connected
separately. In V3.0, we integrated the record button and play back
button in to one button. By holding the button for 2 sec, it starts
recording, by push the button quickly, it plays back what has been
recorded.
What's new in V3
MCU from ISD1820PY to ISD 9160FI
Record and playback button
Record switch
2Mbytes ash
Features
Very long record time, up to 83s
Built-in button to operate
Built-in led indicator
Stand alone or control by MCU
Built-in Microphone
Tip


7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
3/12
Platform Support
Arduino Wio BeagleBone Raspberry
Pi
LinkIt
Specication
Working Voltage: 3.⅗V
Working Current (@5V, 25℃)
Standby: 25-30mA
Recording: 29-35mA
Playing: 110-150mA
Working Current (@3.3V, 25℃)
Standby: 23-25mA
Recording: 25-30mA
Playing: 70-150mA
Working Temperature: 0~85℃
Size: 40x20mm
More details about Grove modules please refer to Grove System
[https://wiki.seeedstudio.com/Grove_System/]

7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
4/12
Weight: 31.5g
Hardware Overview
1.Speaker Connector - JST2.0
2.Microphone
3.Voice Control
4.Button
Short Press and Release: Play
Long Press: Start recording until release the button
5.Led Indicator
Red led, lights when button press
6.Grove Connector
7.REC Switch

7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
5/12
Switch to ON if you want to control the module to record vis
Software
8.MCU
Getting Started
Here we will show you how this Grove - Recorder V3.0 works via a
simple demo. First of all, you need to prepare the below stuffs:
Seeeduino V4 Grove - Recorder
Get ONE Now
[https://www.seeedstudio.com/Seeeduino-
V4.2-p-2517.html]
Get ONE Now
[https://www.seeedstudio.com]
Hardware Connection
Thanks to the benet of Grove series module, you don't need to
make soldering or bread board, what you need to do is connect the

7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
6/12
modules to the right port of Base Shield. For this demo, we connect
Grove - Recorder to D2.
Standalone
This module can work standalone without coding.
Record - Press the button until the LED light, and it's recording,
release the button when nish recording.
Play - Press and release the button to play the voice that had
been recorded.
If you want to control the module by code. please go ahead.
Software

7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
7/12
Copy the below code and paste to your Arduino IDE, and upload to
your Seeeduino V4. After upload the code to an Arduino, then open
the Serial monitor.
1/* Grove - Recorder Test Code
2+-------------------------------------------------------
3| Open Serial Monitor and input command to control the
4| r - start recording
5| s - stop recording
6| p - play
7+-------------------------------------------------------
8
9const int pinRec = 3;
10 const int pinPlay = 2;
11
12 void setup()
13 {
14 Serial.begin(115200);
15 Serial.println("Grove - Recorder V3.0 Test Code");
16 Serial.println("cmd: \r\nr: record\r\ns: stop recordi
17
18 pinMode(pinRec, OUTPUT);
19 pinMode(pinPlay, OUTPUT);
20 digitalWrite(pinRec, HIGH);
21 digitalWrite(pinPlay, HIGH);
22 }
23
24 void loop()
25 {
26 if(Serial.available())
27 {
28 char c = Serial.read();
29 if(c == 'r') // begin to record
30 {
31 digitalWrite(pinRec, LOW);
32 Serial.println("start recording...");
33 }
34 else if(c == 's') // stop recording
35 {



7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
8/12
Enter Command
You can enter some command in Serial monitor:
Start recording - Enter a 'r'
Stop recording - Enter a 's'
Play - Enter a 'p'
Play with Codecraft
Hardware
Step 1. Connect a Grove - Record to port D2 of a Base Shield.
Step 2. Plug the Base Shield to your Seeeduino/Arduino.
Step 3. Link Seeeduino/Arduino to your PC via an USB cable.
Software
36 digitalWrite(pinRec, HIGH);
37 Serial.println("stop recording...");
38 }
39 else if(c == 'p') // play
40 {
41 digitalWrite(pinPlay, LOW);
42 delay(100);
43 digitalWrite(pinPlay, HIGH);
44 Serial.println("play...");
45 }
46 }
47 }

7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
9/12
Step 1. Open Codecraft [https://ide.chmakered.com/], add Arduino
support, and drag a main procedure to working area.
Step 2. Drag blocks as picture below or open the cdc le which can
be downloaded at the end of this page.
Note
If this is your rst time using Codecraft, see also Guide for Codecraft using
Arduino
[https://wiki.seeedstudio.com/Guide_for_Codecraft_using_Arduino/].


7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
10/12
Upload the program to your Arduino/Seeeduino.
Schematic Online Viewer
Success
When the code nishes uploaded, you can use Recorder to record and play
via Serial Monitor.


7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
11/12
Resources
Schematics in PDF
[https://les.seeedstudio.com/wiki/Grove_Recorder_V3/res/Gr
ove%20-%20Recorder%20v3.0a.pdf]
Schematics in Eagle
[https://les.seeedstudio.com/wiki/Grove_Recorder_V3/res/ea
gle.zip]

7/24/22, 10:40 AM
Grove - Recorder V3 - Seeed Wiki
https://wiki.seeedstudio.com/Grove-Recorder_v3.0/
12/12
Codecraft CDC File
[https://les.seeedstudio.com/wiki/Grove_Recorder/res/Grove_
Recorder_CDC_File.zip]
