Schweitzer Engineering Laboratories, Inc. SEL-3360 Data Sheet
Improve Reliability, Availability, and
Serviceability With a Rugged, Compact
Industrial Automation Controller
The SEL-3360 Automation Controller uses a high-performance x86-64 architecture processor to support
modern operating systems like Microsoft Windows and Linux. The extremely rugged SEL hardware of the
SEL-3360 enables you to use your choice of automation controller operating system and software in very
harsh environments not suitable for general-purpose computers.
Integrate the SEL-3360 in computing applications that demand high performance, reliability, and low mainte-
nance in extreme, harsh environments. The SEL-3360 offers a mean time between failure (MTBF) of at least
ten times that of typical industrial computers by eliminating all moving parts, including rotating hard drives
and fans; using high-quality solid-state drives; and by using error-correcting memory technology. By elimi-
nating vent holes, the SEL-3360 significantly reduces dust buildup and foreign contaminants. Power the
SEL-3360 from 12 Vdc power sources with voltage ranging from 10.0–16.6 Vdc, enabling simple integration
with common power sources and battery-powered systems with high float-charge levels. You can install soft-
ware from SEL and third-party software vendors to customize the SEL-3360 for your specific applications.
Every SEL-3360 comes with the unprecedented ten-year, worldwide SEL warranty.
Key Features and Benefits
The SEL-3360 provides a rugged, easy-to-use automation controller platform for substation, industrial, or
other harsh environments.
➤x86-64 Architecture. The SEL-3360 uses the latest Intel Core i7 microprocessor architecture to
deliver very high performance and broad operating system and software compatibility. Multiple pro-
cessor cores and Intel Hyper-Threading Technology enable you to run multiple time-critical applica-
tions simultaneously.
➤Operating System Choices. The SEL-3360 may be purchased as hardware only, or with a variety of
modern Microsoft Windows operating systems to provide extreme flexibility and functionality along
with enhanced security features.
SEL-3360 Automation Controller

SEL-3360 Data Sheet Schweitzer Engineering Laboratories, Inc.
2
➤Form Factor. The SEL-3360 provides a compact wall-mount chassis, designed for substation and
industrial control applications. The system includes rear-panel I/O connectors for network, peripherals,
storage, video, audio, alarm, and serial I/O—all with protection against electrical shock and surge.
➤Power Supply. The SEL-3360S can be powered from any 12 Vdc source, such as the robust, reliable
SEL-9331 power supply module. The SEL-3360E has an integral power supply that can be powered
from low- and high-voltage ac and dc power sources.
➤Mass Storage. The SEL-3360 supports two 2.5-inch SATA drives, which are hot-swappable and
accessible after removing the right side panel. High-performance, industrial-rated solid-state drives
(SSD) are available as ordering options.
➤RAID. The integrated SATA controller supports Redundant Array of Independent Disks (RAID) con-
figurations to maximize data availability and improve storage volume performance.
➤Display Interfaces. DVI, DisplayPort, VGA, or HDMI video connections enable you to connect one
or two simultaneous, independent, high-definition displays.
➤Audio Interface. Analog HD audio inputs and outputs enable connection to amplified speakers,
microphone, and audio sources for clear audible user feedback, audio capture and analysis, and voice
recognition. Digital audio can be streamed through the digital display interfaces for simple integration
and high-definition surround-sound.
➤USB Connectivity. The SEL-3360 has four rear-panel and two front-panel USB ports for connection
to a local keyboard, mouse, and any USB peripherals. Each port is individually current limited, pro-
tecting the system from external short circuits, and enabling high-power devices such as USB hard
drives to be powered from any USB port.
➤PCIe Expansion. The SEL-3360E supports as many as two standard PCIe form factor expansion
cards, enabling you to customize the system I/O to meet your application needs. Choose from a selec-
tion of SEL PCIe expansion cards, or install your own custom third-party expansion card.
➤Ethernet. Two 10/100/1000 Mbps Ethernet connections on the rear panel support high-speed network
connectivity and enable connections to independent networks, or redundant paired network connec-
tions. Network interface cards such as the SEL-3390E4 quad-gigabit Ethernet card can be added to the
SEL-3360E for additional network connectivity.
➤Serial I/O. Two standard EIA-232 serial ports enable connection to nearby electronic devices such as
automation controllers, communication radios, and modems. As many as two SEL-3390S8 serial
expansion cards can be added to the SEL-3360E for applications that require many serial I/O connec-
tions and IRIG time synchronization and distribution.
➤System Monitoring and Watchdog. An embedded controller works in unison with the SEL SysMon
software to provide an extra level of automation controller system reliability, and detect failures in the
application software or operating system. The system logs any abnormal conditions, enables the sys-
tem alarm to alert operators of a problem, and if necessary, can reboot the system to return to a good
operation state.
➤Alarm Contact Output. SEL SysMon software controls the alarm contact output to signal in case of
system health problems or malfunctions. The Form C contact supports both normally open and nor-
mally closed alarm operation.
➤Remote Management. The SEL-3360 supports remote access over Ethernet by using Windows
Remote Desktop or Intel vPro Active Management Technology (AMT), enabling full access to the sys-
tem video, keyboard, mouse, and storage.

Schweitzer Engineering Laboratories, Inc. SEL-3360 Data Sheet
3
Functional Overview
Figure 1 SEL-3360 in Monitoring and Control Applications
Watchdog Functionality
An embedded controller provides an extra level of auto-
mation controller system reliability. One function of the
embedded controller is to reboot the automation control-
ler if there is an operating system problem or a problem
with specific software services running on the operating
system.
SEL System Monitor
SEL System Monitor software monitors system perfor-
mance and component health. Alerts for alarm condi-
tions are issued on configurable thresholds. Example
thresholds include CPU usage, free disk space, and avail-
able system memory.
Ethernet
Ethernet connections allow the SEL-3360 to connect to
two separate, high-speed Ethernet networks via built-in
Gigabit Ethernet. Aggregate ports for increased perfor-
mance or redundancy or separate local area networks
(LANs) for control, data, or engineering access. Addi-
tional copper or fiber-optic Ethernet ports can be added
to the SEL-3360E by installing PCI Express expansion
cards such as the SEL-3390E4. For information on those
cards, please refer to the appropriate expansion card
instruction manual.
Time
The COM 1 serial port accepts IRIG-B time-code input for
precise time input from a GPS clock or other source.
EIA-232 Serial Ports
The SEL-3360 automation controller platform has two
built-in EIA-232 DB-9 ports, which can provide +5 V
power to run external transceivers, modems, and other
serial-connected accessories. Additional serial ports can
be added to the SEL-3360E by installing PCI Express
expansion cards such as the SEL-3390S8. For informa-
tion on those cards, please refer to the appropriate expan-
sion card instruction manual.
Alarm Output
An alarm contact output on the rear panel can be used to
signal internal errors and operating system malfunctions.
Programmable LEDs
Program three front-panel bicolor LEDs for use with
your custom applications.
Out-of-Band Management
Intel vPro Active Management Technology (AMT) pro-
vides out-of-band management for security, configura-
tion, and monitoring.
Control
Center
Historian
SCADA
Remote Site
Outdoor Control
Cabinet
Outdoor HMI
Display
SEL-3360S
SEL
SEL-2725
Five-Port Ethernet Switch
SEL-
3505
SEL- 3060
SEL

SEL-3360 Data Sheet Schweitzer Engineering Laboratories, Inc.
4
Application Examples
Virtualization for HMI and Other
Applications
Figure 2 SEL-3360 OS and Application Virtualization
Platform
Create your own virtualization appliance by leveraging
Intel Virtualization Technology (VT-x) to allow one
hardware platform to function as multiple “virtual” plat-
forms. Isolate your computing activity onto separate vir-
tual machines to maintain productivity and realize
improved manageability and reduced downtime. For
example, run a virtualized OS specifically for your HMI
or other essential but noncritical applications. Should
your HMI require that the system be rebooted, simply
restart the virtual machine and avoid an outage for your
other critical processes. Similarly, multiple SEL-3360
automation controller platforms may be virtualized and
entire operating systems transparently migrated from one
physical SEL-3360 to another for hardware upgrades,
security or software updates, or testing purposes.
Control System Applications
Use the SEL-3360 for process control applications,
including as a human-machine interface (HMI) or for
protocol conversion and high-speed control when work-
ing with other SEL products and solutions.
Figure 3 High-Speed Control With SEL MIRRORED BITS
and IEC 61850 GOOSE Communications
Security Applications
Improve security with a single sign-on, enabled through using
the SEL-3360 as a local Lightweight Directory Access Pro-
tocol (LDAP) server. Centrally manage user accounts and
group memberships with Microsoft Active Directory or with
your choice of back-end database support.
Figure 4 SEL-3360 as Remote Read-Only Domain
Controller Performing Central Authentication Using LDAP
Disturbance Recording System for
PRC-002-2
Figure 5 Reliable Hardware for Running Your
Disturbance Recording System
Event Collection Applications
Figure 6 IED Event Collection With Optional
ACSELERATOR TEAM SEL-5045 Software
SEL-3360
Operating System
Application
SEL-3360
Virtualization
App
OS
App
OS
App
OS
App
OS
Traditional Architecture Virtual Architecture
CPU
3360
6
3
3
3
3
R
421
SEL Relay
RTAC
R
421
R
421
R
421
R
421
4
2
1
R
421
2730M
Other IED
D
SEL Relay
SEL Relay
Other IED
D
SEL Relay
GOOSE
M
essaging
R
R
R
R
R
R
R
R
R
T
T
A
T
T
C
W
eb-
B
sed HMI
a
s
e
se
s
e
SEL Relays or
Other IEDs
SEL Relays or
Other IEDs
Ethernet Switch
M
IRRORED
B
ITS
Communications
DNP3
,
M
,
o
dbus
Log in as Alice.
Engineering Station
3505
User Administration
Yes.
No.
Is Alice an authorized user?
Is Rob an authorized user?
Log in as Rob.
Connection established.
Connection refused.
CPU
3360
6
3
3
3
3
SE
SE
SE
SE
L-
L-
L
L-
35
3
3
35
Is Ali
c
e a
3505
35
35
e a
LD
LD
LD
LD
AP
AP
AP
AP
S
S
S
S
e
e
e
r
r
r
r
r
r
r
v
v
v
v
v
v
v
er
e
2401
SEL-487E Station Phasor
Measurement Unit
SOE Data
Up to 18 CT Inputs
Up to 6 PT Inputs
Up to 55 Digital Inputs
SEL-2401
Satellite-Synchronized
Clock
CPU
3360
6
3
3
3
3
R
487E
M
DDR Data
FR Data
R
351S
CPU
3360
6
3
3
3
3
3505
R
351S
R
351S
R
351S
R
351S
R
351S
3610
Events Collected
Automatically
Analyze, Control,
and Integrate

Schweitzer Engineering Laboratories, Inc. SEL-3360 Data Sheet
5
Diagrams and Dimensions
Figure 7 Front-Panel Diagram
qw e r ytu i
q
q
q
w
w
w
e
e
e
r
r
r
y
y
y
t
t
t
u
u
i
i
i
qLAMP TEST Button. Press and hold to test front-panel LEDs. Can be programmed to be an on/off or reset button.
wENABLED and ALARM LEDs provide operational status. A green ENABLED LED indicates normal operation.
The ALARM LED illuminates red when a nonoptimal system condition exists.
eETHERNET Status Indicators. Link (LNK) indicates that the port is connected, and activity (ACT) indicates when data
are being transmitted and received.
rSERIAL Status Indicators. Transmit (TX) and receive (RX) LEDs indicate activity on serial ports.
tPINHOLE button. Provide reset and power functions, and requires a push-pin to prevent accidental use.
yHDD Activity Indicator. Illuminates when SATA drives are accessed.
uAUXILIARY Status Indicators. Three programmable, bicolor LEDs for your custom application.
iUSB Ports. Two easily accessible ports to connect USB 2.0 peripherals.
qw e r ytu i

SEL-3360 Data Sheet Schweitzer Engineering Laboratories, Inc.
6
Figure 8 Rear-Panel Diagram
qDVI-D. Connect digital monitors by using native DVI or an HDMI adapter.
wDVI-I. Connect either digital or analog monitors by using native DVI, an HDMI adapter, or a VGA adapter.
eETH1 and ETH2. Onboard independent Gigabit Ethernet interfaces.
rUSB Ports. Connect as many as four USB 2.0 peripherals at the rear panel.
tAUDIO Ports. Line Input (blue), Line Output (green), and Microphone Input (pink).
yCOM1 and COM2. Standard EIA-232 serial ports with configurable +5 Vdc power on Pin 1.
uDISPLAYPORT. Connect new digital monitors supporting the DisplayPort interface.
iGROUND Terminal Screw. The earth ground connection for the SEL-3360.
oPOWER Input Terminals. The rated input voltage is clearly marked on the chassis near the terminals.
aALARM. The Form C alarm contact output enables both normally closed and normally open wiring connections.
sPCI Expansion Slots. Install SEL or third-party PCI Express expansion cards for additional network, serial, or other
application-specific I/O.
w
q
w
q
u
u
ytre
ytre
ai
i
o
a
s
o

Schweitzer Engineering Laboratories, Inc. SEL-3360 Data Sheet
7
Figure 9 SEL-3360S Dimensions Diagram
Figure 10 SEL-3360E Dimensions Diagram
(mm)
in
CHASSIS WITH
STANDARD HEATSINK
CHASSIS WITH
CONDUCTION-COOLED HEATSINK
in
(mm)
CHASSIS WITH
STANDARD HEATSINK
CHASSIS WITH
CONDUCTION-COOLED HEATSINK

SEL-3360 Data Sheet Schweitzer Engineering Laboratories, Inc.
8
Specifications
Compliance
Designed and manufactured under an ISO 9001 certified quality
management system
47 CFR 15B, Class A
Note: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference, in which
case the user will be required to correct the interference at his own
expense.
UL Recognized to U.S. and Canadian safety standards (File E220228;
NRAQ2, NRAQ8)
CE Mark
UKCA Mark
General
Supported Operating Systems
Microsoft Windows 7
Microsoft Windows 8/8.1
Microsoft Windows 10*
Microsoft Windows Server 2008 R2
Microsoft Windows Server 2012 R2
Microsoft Windows Server 2016*
CentOS Linux 6
CentOS Linux 7
Red Hat Enterprise Linux 6
Red Hat Enterprise Linux 7
VMware ESXi (Contact SEL for hardware and version compatibility)
* Orderable as a factory-installed option.
CPU
Intel Core i7-3555LE Dual-Core Processor
Speed: 2.5 GHz base, 3.2 GHz turbo
Cache: 2 x 256 KB L2, 4 MB L3
Intel Core i7-3612QE Quad-Core Processor (SEL-3360S Only)
Speed: 2.1 GHz base, 3.1 GHz turbo
Cache: 4 x 256 KB L2, 6 MB L3
RAM
4, 8, or 16 GB DDR3 ECC PC3-10600 (1333 MHz)
Chipset
Intel QM77 Express Chipset
Mass Storage
Internal Drive Bay: Supports 2.5 inch SATA drives
two industrial-grade drives
one consumer-grade drives
SATA II 3.0 Gb/s
RAID level 0, 1
Hot-Swap Support
Optional SATA Drives: Industrial-Grade SLC SSD
30–250 GB
10-year warranty
Industrial-Grade iMLC SSD
120–480 GB
5-year warranty
Consumer-Grade MLC SSD
240–1920 GB
3-year warranty
Video
Intel HD Graphics 4000 Controller
Dual Independent Displays
From 2 of the 3 Outputs:
DVI-I (digital + VGA) maximum
resolution 1920 x 1200 @ 32 bpp
DVI-D (digital only) maximum resolution
1920 x 1200 @ 32 bpp
DisplayPort 1.1 maximum resolution
1920 x 1200 @ 32 bpp
Cable length <10 m
Audio
TSI (IDT) 92HD91 HD Audio Codec
3 Analog 3.5 mm TRS
Jacks:
Line input
Line/headphone output
Microphone input
Cable length <2 m
Intel Display Audio
Digital Audio Outputs: DVI-I, DVI-D, DisplayPort
USB
4 Rear-Panel Ports, 2 Front-Panel Ports
USB 2.0 Compliant
800 mA Current Limit
Cable length <10 m
Expansion Cards (SEL-3360E Only)
2 Half-Length, Full-Height
PCI Expansion Card
Slots:
PCI 1: PCIe x1 (Revision 2.0)
PCI 2: PCIe x4 (Revision 2.0)
Ethernet
2 Rear-Panel, 1 Gb Copper RJ45 Ports
ETH1: Intel 82579LM, 10/100/1000 Mbps
RJ45 copper
ETH2: Intel 82574L, 10/100/1000 Mbps
RJ45 copper
Optional SEL-3390E4
PCIe x4 Expansion Card
(SEL-3360E Only):
As many as four additional 10/100/1000
Mbps ports, copper or LC fiber SFP
Serial Ports
Standard Ports: 2 EIA-232 ports, DB-9 connectors
300 to 115200 bps
(Meets EIA/TIA-562 Specifications)
Optional SEL-3390S8
PCIe x1 Expansion Cards
(SEL-3360E Only):
As many as 12 additional EIA-232/EIA-
422/EIA-485 ports, RJ45 connectors
300 to 921600 bps
Time-Code Input
Main Board (Input Only)
Connector: COM1 DB-9 serial port
Time Code: Demodulated IRIG-B TTL compatible
SEL-3390S8 Expansion Card (Input/Output) (SEL-3360E Only)
Connector: RJ45 serial port
Time Code: Demodulated IRIG-B TTL compatible
Note: Output generated from either IRIG-B input or SEL-3360 clock.
Real-Time Clock/Calendar
Battery Type: IEC No. BR-2330A Lithium
Battery Life: 10 years with power
2 years without power

Schweitzer Engineering Laboratories, Inc. SEL-3360 Data Sheet
9
BIOS
Phoenix SecureCore Tiano UEFI
Trusted Platform Module
Integrated TPM 1.2
Intel Active Management Technology
Intel AMT v8.1, accessible through ETH1
Power Supply
See Table 1 for additional burden information.
No power supply (SEL-3360S only)
Voltage Rating: 12 Vdc
Voltage Range: 10–16.6 Vdc
Typical Burden: 25 W
Max Burden: 144 W (cold startup)
Peak Inrush: 15 A
Negative input power terminal is internally tied to chassis ground.
SEL-9331 160 W LV Power Supply
Voltage Rating: 48 Vdc
Voltage Range: 38–58 Vdc
Maximum Constant
Burden: 149 W
Maximum Peak Burden: 225 W
DC Ripple: <15% rated voltage
Peak Inrush: 15.5 A peak, 48 ms duration
Measured per IEC 60255-1,
Section 6.10. Quiescent current level
derived from 40 W input.
Insulation: 3600 Vdc
Isolated From Chassis
Ground: Yes
SEL-9331 160 W HV Power Supply
Voltage Ratings: 125/250 Vdc
120/220/240 Vac; 50/60 Hz
DC Range: 100–300 Vdc
Maximum DC Dropout: 88 Vdc
AC Range: 85–264 Vac
Frequency Range: 45–65 Hz
Maximum Constant
Burden: 155 W, 160 VA
Maximum Peak Burden: 240 W, 248 VA
DC Ripple: <15% rated voltage
Peak Inrush: 16.6 A peak, 4 ms duration, 240 Vac
12.8 A peak, 9 ms duration, 250 Vdc
Measured per IEC 60255-1,
Section 6.10. Quiescent current level
derived from 75 W input.
Insulation: 3600 Vdc
Power Factor: >0.9 (at full load)
Isolated From Chassis
Ground: Yes
Recommended External Overcurrent Protection
Breaker Type: Standard
Breaker Rating: 20 A at 250 Vdc
Current Breaking
Capacity: 10 kA
Grounded Neutral
Systems:
Devices in series with the HOT or
energized conductor
DC and Isolated Systems: Device in serial with both conductors
Distance from Equipment: Less than 2 m
Fuse Ratings
12 Vdc Input Power Fuse
F1:
15 A, 250 Vac/60 Vdc fast acting
60 Vdc/50 A break rating
LV Power Supply Fuse:
Rating: 15 A
Maximum Rated
Voltage: 500 Vdc, 500 Vac
Breaking Capacity: 20 kA at 500 Vdc
Type: Time-lag T
HV Power Supply Fuse:
Rating: 5 A
Maximum Rated
Voltage: 250 Vdc, 277 Vac
Breaking Capacity: 1500 A at 277 Vac
Type: Time-lag T
Heater Fuses F2, F3: 5 A, 125 V slow blow
125 Vdc/50 A break rating
Fuses are not serviceable.
Alarm Output Contact
Per IEC 255-0-20:1974, using the simplified method of assessment
Output Type: Relay, Form C, break-before-make
Power Supply Burden: <1 W maximum
Mechanical Life: 2000000 operations
Operational Voltage: 250 Vac/Vdc
Make: 30 A at 250 Vdc
Carry: 6 A continuous at 70°C
1 s Rating: 50 A
MOV Protection: 270 Vac/360 Vdc, 75 J
Insulation Voltage: 300 Vac/Vdc
Pickup Time: <8 ms
Dropout Time: <8 ms
Breaking Capacity (10000 operations):
24 V 0.75 A L/R = 40 ms
48 V 0.50 A L/R = 40 ms
125 V 0.30 A L/R = 40 ms
250 V 0.20 A L/R = 40 ms
Cyclic Capacity (2.5 cycles/second):
24 V 0.75 A L/R = 40 ms
48 V 0.50 A L/R = 40 ms
125 V 0.30 A L/R = 40 ms
250 V 0.20 A L/R = 40 ms
Terminal Ratings
Compression Screw Terminal
Power Wiring
Insulation: 300 V min.
Size: 12–14 AWG, length <2 m
Alarm Wiring
Insulation: 300 V min.
Size: 12–18 AWG

SEL-3360 Data Sheet Schweitzer Engineering Laboratories, Inc.
10
Tightening Torque
Minimum: 0.6 Nm (5 in-lb)
Maximum: 0.8 Nm (7 in-lb)
Crimp Ferrule Recommended
Mounting Ear Tightening Torque
Minimum: 0.18 Nm (1.6 in-lb)
Maximum: 0.25 Nm (2.2 in-lb)
Grounding Screw
Ground Wiring
Insulation: 300 V min.
Size: 12 AWG, length <3 m
Tightening Torque
Minimum: 0.9 Nm (8 in-lb)
Maximum: 1.4 Nm (12 in-lb)
Ring Terminal Recommended
Serial Port
Tightening Torque
Minimum: 0.6 Nm (5 in-lb)
Maximum: 0.8 Nm (7 in-lb)
Video Port
Tightening Torque
Minimum: 0.6 Nm (5 in-lb)
Maximum: 0.8 Nm (7 in-lb)
Temperature Range
Operating
SEL-3360S With
i7-3555LE CPU: –40° to +75°C (–40° to +167°F)
SEL-3360S With
i7-3612QE CPU: –40° to +60°C (–40° to +140°F)
SEL-3360E With
i7-3555LE CPU: –40° to +60°C (–40° to +140°F)
Note: Not applicable to UL applications.
Storage
–40° to +85°C (–40° to +185°F)
Relative Humidity
5% to 95% noncondensing
Maximum Altitude
5000 m
Atmospheric Pressure
80–110 kPa
Overvoltage Category
Category II
Insulation Class
1
Pollution Degree
2
RoHS Compliance
Compliant with European Union’s RoHS directive
Weight
4.1 kg (9 lb) maximum (SEL-3360S)
6.8 kg (15 lb) maximum (SEL-3360E)
Product Standards
Communications
Equipment in Utility
Substations:
IEC 61850-3:2013
IEEE 1613-2009
Severity Level: Class 1
Industrial Environment: IEC 61000-6-2:2005
IEC 61000-6-4:2006
Electrical Equipment for
Measurement, Control,
and Laboratory Use:
IEC 61010-1:2010
UL 61010-1:2016,
C22.2 No. 61010-1-12
IEC 61010-2-201:2013
Measuring Relays and
Protection Equipment:
IEC 60255-26:2013
IEC 60255-27:2013
Type Tests
Note: To ensure good EMI and EMC performance, type tests were
performed using shielded Ethernet and serial cables with the shell
grounded at both ends of the cable, and the USB, video, and audio
cables with ferrite chokes. Double-shielded cables are recommended
for best EMI and EMC performance.
Electromagnetic Compatibility Emissions
Conducted and Radiated
Emissions:
CISPR 11:2009+A1:2010
CISPR 22:2008
CISPR 32:2015
IEC 61000-6-4:2006
IEC 61850-3:2013
FCC 15.107:2014
FCC 15.109:2014
Severity Level: Class A
Harmonic Current: IEC 61000-3-2:2014
Severity Level: Class A
Voltage Flicker: IEC 61000-3-3:2013
Electromagnetic Compatibility Immunity
Conducted RF: IEC 61000-4-6:2013
Severity Level: 10 Vrms
Electrostatic Discharge: IEC 61000-4-2:2008
IEEE C37.90.3-2001
Severity Level:
2, 4, 6, 8 kV contact discharge;
2, 4, 8, 15 kV air discharge
Fast Transient/Burst: IEC 61000-4-4:2012
Severity Level: Class A
4 kV, 5 kHz on power supply and outputs;
2 kV, 5 kHz on communications lines
Magnetic Field: IEC 61000-4-8:2009
Severity Level:
1000 A/m for 3 s
100 A/m for 1 m
Power Supply: IEC 61000-4-11:2004
IEC 61000-4-17:1999+A1:2001+A2:2008
IEC 61000-4-29:2000
Radiated Radio Frequency: IEC 61000-4-3:2006+A1:2007+A2:2010
Severity Level: 10 V/m
IEEE C37.90.2-2004
Severity Level: 20 V/m
Surge Withstand
Capability:
IEC 61000-4-18:2006+A1:2010
Severity Level:
Power supply and outputs
2.5 kV peak common mode
1.0 kV peak differential mode
Communications ports
1.0 kV peak common mode
IEEE C37.90.1-2012
Severity Level:
2.5 kV oscillatory
4 kV fast transient

Schweitzer Engineering Laboratories, Inc. SEL-3360 Data Sheet
11
Surge Immunity: IEC 61000-4-5:2005
0.5, 1 kV line-to-line
0.5, 1, 2 kV line-to-earth
0.5, 1, 2 kV communications ports
Environmental
Change of Temperature: IEC 60068-2-14:2009
Severity Level:
5 cycles, 1°C per minute ramp
IEC 60255-1:2009
IEC 61850-3:2013
SEL-3360S With
i7-3555LE CPU: –40°C to +75°C
SEL-3360S With
i7-3612QE CPU: –40°C to +60°C
SEL-3360E With
i7-3555LE CPU: –40°C to +60°C
Cold, Operational: IEC 60068-2-1:2007
Severity Level: 16 hours at –40°C
Cold, Storage: IEC 60068-2-1:2007
Severity Level: 16 hours at –40°C
IEC 60255-1:2009
IEC 61850-3:2013
Damp Heat, Cyclic: IEC 60068-2-30:2005
Severity Level:
12 + 12-hour cycle
25° to 55°C, 6 cycles, >93% r.h.
Damp Heat, Steady: IEC 60068-2-78:2012
Severity Level:
40°C, 240 hours, >93% r.h.
IEC 61850-3:2013
Dry Heat, Operational: IEC 60068-2-2:2007
Severity Level:
SEL-3360S With i7-3355LE CPU:
16 hours at 75°C
SEL-3360S With i7-3612QE CPU:
16 hours at 60°C
SEL-3360E With i7-3555LE CPU:
16 hours at 60°C
IEC 60255-1:2009
IEC 61850-3:2013
Dry Heat, Storage: IEC 60068-2-2:2007
Severity Level: 16 hours at 85°C
IEC 60255-1:2009
IEC 61850-3:2013
Free Fall: IEEE 1613-2009
Severity Level: 100 mm
Vibration: IEC 60255-21-1:1988
Severity Level:
Endurance Class 2
Response Class 2
IEC 60255-21-2:1988
Severity Level:
Shock Withstand, Bump Class 1
Shock Response Class 2
IEC 60255-21-3:1993
Severity Level:
Quake Response Class 2
Safety
Enclosure Protection: IEC 60529:1989+A1:1999
Severity Level: IP30
Dielectric Strength: IEC 60255-27:2013
IEEE C37.90-2005
Severity Level:
3600 Vdc on power supply
2500 Vac on contact output
1500 Vac Ethernet ports
Type tested for one minute
Impulse: IEC 60255-27:2013
IEEE C37.90-2005
Severity Level:
5 kV common mode, power supply,
contact outputs
1.5 kV Ethernet ports

12
© 2015—2022 by Schweitzer Engineering Laboratories, Inc. All rights reserved.
All brand or product names appearing in this document are the trademark or registered
trademark of their respective holders. No SEL trademarks may be used without written
permission. SEL products appearing in this document may be covered by U.S. and Foreign
patents.
Schweitzer Engineering Laboratories, Inc. reserves all rights and benefits afforded under
federal and international copyright and patent laws in its products, including without lim-
itation software, firmware, and documentation.
The information in this document is provided for informational use only and is subject to
change without notice. Schweitzer Engineering Laboratories, Inc. has approved only the
English language document.
This product is covered by the standard SEL 10-year warranty. For warranty details, visit
selinc.com or contact your customer service representative. *PDS3360-01*
2350 NE Hopkins Court • Pullman, WA 99163-5603 U.S.A.
Tel: +1.509.332.1890 • Fax: +1.509.332.7990
SEL-3360 Data Sheet Date Code 20221221
Technical Support
We appreciate your interest in SEL products and services. If you have questions or comments, please contact us at:
Schweitzer Engineering Laboratories, Inc.
2350 NE Hopkins Court
Pullman, WA 99163-5603 U.S.A.
Tel: +1.509.338.3838
Fax: +1.509.332.7990
Internet: selinc.com/support
Email: [email protected]
Table 1 System Power Consumption (at 12 Vdc Input Voltage)
Power Consumptiona
Component Minimum Typical Maximum
Base System (Dual-Core CPU, 4 GB RAM, 1 SATA Drive): 15 W 25 W 40 W
Additional Consumption From Optional Components
SEL-9331 Power Supply (standard on SEL-3360E) +10 W +10 W +10 W
Quad-Core CPU: +2 W +5 W +13 W
2nd RAM Module (included with 8 GB and 16 GB
ordering options):
+2 W +2 W +3 W
2nd SATA Drive: +1 W +2 W +3 W
SEL-3390E4 Ethernet Card +6 W +8 W +10 W
SEL-3390S8 Serial Card +4 W +5 W +7 W
Chipset Heaterb
cold startup (<5°C [41°F]):
continuous operation (0°C [32°F]):
continuous operation (–40°C [–40°F]):
N/A
0W
0W
N/A
+5 W
+20 W
+90 W
+10 W
+40 W
aMinimum: 0% load on all components; minimum power consumption booted up and idle.
Typical: 25–50% load on all components; good indication of most application loads.
Maximum: 100% load on all components; generally cannot be reached in normal applications.
bChipset heaters operate at low temperatures to keep the CPU and PCH within specified operating limits.
Table 2 Peripheral Connection Current Limits
Connection Current Limit
DVI-I and DVI-D 0.2 A, +5 Vdc, 1 W total for both
DisplayPort 0.6 A, +3.3 Vdc, 2 W
COM1 and COM2 0.5 A, +5 Vdc, 2.5 W each
USB Ports 0.8 A, +5 Vdc, 4 W each
