Selecon High Performance Fresnel User manual

Version 2: September 2004 © 2004 Selecon New Zealand Limited All Rights Reserved
1200 HIGH PERFORMANCE & COMPACT
FRESNELs AND PCs
OPERATION MANUAL
THANK YOU FOR PURCHASING A SELECON LUMINAIRE. WE HAVE
DESIGNED THIS LUMINAIRE TO PROVIDE YOU WITH A SUPERIOR
FITTING IN PERFORMANCE, DESIGN AND ENGINEERING.
WE ARE CONFIDENT THAT IT WILL PERFORM TO YOUR
EXPECTATIONS FOR MANY YEARS TO COME.
Before operating your new luminaire please read this information to assist
you in making maximum use of your luminaire, its maintenance and care.
If you would like further assistance contact your Selecon dealer or
Selecon.
LAMPING YOUR LUMINAIRE
Before lamping – DISCONNECT THE LUMINAIRE FROM THE POWER SUPPLY. Be aware also that the
lamp or luminaire may still be hot, so exercise the necessary caution to avoid burns. Please note also
that these luminaires are not suitable for mounting on a normally flammable surface.
The Selecon 1200W Fresnel and PC range comprises four models: the High Performance Fresnel, High
Performance PC, Compact Fresnel and Compact PC. The Selecon 1200 range is designed for use with
either the T/29 1200W or T/19 1000W lamp.
To facilitate the use of these two lamps which are of different sizes the height of the GX9.5 lampbase is
adjustable. The adjustment is by means of two machined mounting posts. In the lower position the base is
aligned for use with the T/29 1200W lamp. In the top slot the base is aligned for use with the 1000W lamp.
To make the adjustment, loosen the front mounting post with a screwdriver, slide it forward to free the lamp
base. Position the base in the top (1000W) or bottom (1200W) slot, push the post back home and tighten the
screw post.
Lamps able to be used in the 1000/1200 range are: 1200W – T/29: 1000W – T/11, T/19, CP24, CP70.
♦Release the clip fastener and swing down the rear door.
♦Insert lamp taking care not to touch the quartz envelope with your fingers.
♦Close door and lock off the fastener.
The luminaire should be at least 1m away from the nearest object it is
lighting.
IMPORTANT NOTE: Before
discarding the packaging
ensure you have the
suspension bolt set, colour
frame & /or the lamp.

Version 2: September 2004 © 2004 Selecon New Zealand Limited All Rights Reserved
MOUNTING YOUR LUMINAIRE
Your luminaire uses a theatre lamp with a grid filament. To avoid premature
lamp failure it is essential that the luminaire is always mounted so the yoke
is horizontal and with the lamp base down, i.e. the lamp adjustment knob is
at the bottom of the rear lamp plate.
To mount on the theatre standard scaffold pipe (48mm O.D.) use a
theatre hookclamp (G clamp) (Order Code: 20HC). Your luminaire is
supplied with a 10mm setscrew, washers and a nut. Thread the
setscrew through the yoke from the inside, put on a washer, then the
hookclamp, another washer and then do up finger tight with the nut.
To mount on a telescopic stand, reverse the yoke under the luminaire
and bolt the stand’s spigot onto the 10mm set screw.
A Safety Chain (Order Code: 20SC) MUST always be used when rigging luminaires on bars, ladders etc.
The Safety Chain is passed through the luminaire anchor point hole located under the handle and
around the bar. Be careful to allow sufficient slack to allow the luminaire to be focused freely.
Safety Chains are available from Selecon or your distributor.
FOCUSING
The variable beam of the 1200 range is altered by adjusting the position of the lamp /
reflector assembly relative to the lens. Finger tight pressure only is necessary to lock
the lamp / reflector assembly off in the chosen positions. A reference scale is provided
to record focus settings on the 1200 High Performance Fresnel.
When focusing, first spot the beam down, position the luminaire and then flood the
beam to cover the area required. The beam can then be shaped using the barndoors
(Order Code: 20BDSF10).
YOKE PIVOT ADJUSTMENT
The yoke on the 1200 range can be positioned anywhere in the channel that runs the length of the luminaire.
This is useful to achieve the best balance if using a colour changer or other accessory mounted on the front of
the luminaire, or to fit the luminaire in space restricted positions.
The yoke balance point is factory set on the lens tube for normal applications. To move the yoke, loosen the
M8 bolts at the bottom pivot point of the yoke on each side of the luminaire. Slide the yoke to the required
position, check the yoke is evenly positioned on each side and tighten the M8 bolts.
PAN AND TILT ADJUSTMENT
To pan your luminaire loosen the nut and adjust, then retighten. To tilt, loosen the locking clamp handle on the
side of the luminaire, tilt and retighten finger tight.
The nylock nut that secures the yoke on the opposite side to the tilt handle sets the tilt lock friction. The tilt
friction can be adjusted by loosening or tightening up the nylock nut.
Please note that as the handles on the 1200 range can reach high temperatures depending on the position or
orientation of the luminaire, and that gloves should always be worn when focusing these luminaires.

Version 2: September 2004 © 2004 Selecon New Zealand Limited All Rights Reserved
ACCESSORIES
♦Suspension Hook Clamp (Order Code: 20HC)
♦Safety Chain (Order Code: 20SC)
♦Lens Safety Mesh (Order Code: 20SM6)
♦Colour Frame – the luminaire is supplied with a colour frame 184mm square. Additional colour frames are
available (Order Code: 20CFSF12).
♦Barndoor (Order Code: 20BDSF10)
CLEANING
Open the down-swinging door, and clean the lens and/or reflector with a soft lint-free cloth.
This is the only maintenance task, which can be safely carried out by non-approved
personnel. Refer below – Safety & Maintenance note.
SAFETY & MAINTENANCE
Selecon has manufactured this luminaire in accordance with recognised best practices to recommended
international safety standards. It is your responsibility to maintain this luminaire in good and safe working
condition.
Repairs should only be carried out by suitably qualified persons. Do not operate the luminaire with cracked
lens, damaged cables etc. Consult your Selecon distributor for assistance. Only replace damaged parts with
authorised Selecon spares.
N.B. Luminaire Cable – your Selecon luminaire is fitted with a special heat-resistant, flexible cable, replace with
genuine Selecon spare part cable kit only – refer to your Selecon distributor. (Replacement cables are supplied
complete with necessary terminal connectors).
Cable Conductor colour codes: Brown -Phase, Live
Blue -Neutral, Return
Green/ Yellow -Earth
LIMITED WARRANTY
Selecon New Zealand Ltd. (“Selecon”) warrants its luminaires against defects in
materials or workmanship. The term of this warranty is based on the product usage
and is from the date of delivery.
Usage – Entertainment, Theatre Term - Three Years
Entertainment, Theatre relates to the typical conditions found in a theatre performance venue viz:
4 – 6 hrs per day, six days per week.
Other – ALL Electromechanical / Electronic DevicesTerm - One Year
This warranty is void in any of the following circumstances: (a) The luminaire has been misused, neglected,
damaged or abused. (b) The luminaire has been improperly installed, operated, repaired or maintained. (c)
The luminaire has been modified. (d) The luminaire has been connected to other equipment with which it is not
compatible. (e) The luminaire has been used or stored in conditions outside its electrical or environmental
specifications. (f) The luminaire has been used for purposes other than for which it was designed. (g) The
luminaire has been used outside its stated specifications and operating parameters.
Correct installation of the luminaire is the owner’s responsibility.
To assert a warranty claim, complete Selecon’s return authorisation form (available from Selecon). Return the
luminaire to Selecon or its authorised agent.

Version 2: September 2004 © 2004 Selecon New Zealand Limited All Rights Reserved
If Selecon accepts the warranty claim, Selecon will provide, or arrange for, service, repair or replacement as
Selecon shall determine in its sole discretion. Selecon shall bear the cost of such service, repair or
replacement. However, the owner shall bear the cost of freight and insurance on the luminaire, both ways. If
Selecon does not wish to service, repair or replace the defective luminaire, it shall refund the purchase price.
Selecon’s sole responsibility is to repair, replace or service a luminaire subject to a valid warranty claim. Under
no circumstance will Selecon be liable for direct, indirect, incidental, special or consequential costs or damages,
including dismantling and re-installation costs, loss of operations or profits, to the maximum extent permitted by
law.
Selecon accepts no liability for personal injury or property damage resulting from failure to heed relevant
operating and safety procedures specified by Selecon or imposed by law.
This is an express warranty. Selecon disclaims any other express or implied warranties, including warranties of
merchantability or fitness for purpose, to the maximum extent permitted by law.
Some jurisdictions do not allow limitations or disclaimers of implied or statutory warranties. Some jurisdictions
do not allow disclaimers or exclusions of consequential or incidental damages. Therefore, the above
disclaimers, limitations and exclusions may not apply in all jurisdictions in which Selecon sells its luminaires.
This warranty gives the owner specific legal rights. The owner may have other rights or remedies pursuant to
the laws in its territory. Nothing in this limited warranty should be construed as limiting or restricting any other
statutory right or remedy of the owner, except for such limitations or restrictions herein as may be allowed by
the law of the territory.
Selecon has a policy of continual product improvement and specifications are subject to change without notice.
SELECON DISTRIBUTOR NETWORK
Your Selecon distributor is a theatre professional with a broad knowledge and understanding of performance
requirements. Most can offer you a full service including not only stage lighting equipment but, all your theatre
needs including curtains, scenic paint, sound equipment, as well as supplies of lamps, filter, gaffer tape etc.
The Selecon dealer network is an international group of lighting professionals throughout Australasia, Asia,
United Kingdom and Europe, North and South America.
Manufacturer:
Selecon New Zealand 19-21 Kawana Street, Northcote 1310, Auckland, New Zealand
Ph: 64 9 481 0100 Fax: [phone]
Internet: www.seleconlight.com Email: [e-mail]
