Cameo MOVO BEAM 200 User manual

USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D´UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D´USO
MOVO BEAM 200
ENDLESS ROTATION BEAM MOVING HEAD WITH LED RING
CLMB200
RGBW

CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ /
CONTENUTO
ENGLISH
INFORMATION ON THIS USER MANUAL 5
PROPER USE 5
DEFINITIONS AND SYMBOL EXPLANATIONS 5
SAFETY INSTRUCTIONS 6
NOTES FOR MOBILE INDOOR DEVICES 9
INCLUDED 10
INTRODUCTION 10
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS 11
OPERATION 13
SET-UP AND INSTALLATION 24
CARE, MAINTENANCE AND REPAIR 25
DMX TECHNOLOGY 26
DIMENSIONS 28
TECHNICAL DATA 28
DISPOSAL 30
MANUFACTURER’S DECLARATIONS 30
DEUTSCH
INFORMATIONEN ZU DIESER BEDIENUNGSANLEITUNG 32
BESTIMMUNGSGEMÄSSER GEBRAUCH 32
BEGRIFFS- UND SYMBOLERKLÄRUNGEN 33
SICHERHEITSHINWEISE 33
HINWEISE FÜR ORTSVERÄNDERLICHE INDOOR-GERÄTE 36
LIEFERUMFANG 37
EINFÜHRUNG 37
ANSCHLÜSSE, BEDIEN- UND ANZEIGEELEMENTE 38
BEDIENUNG 40
AUFSTELLUNG UND MONTAGE 51
PFLEGE, WARTUNG UND REPARATUR 52
DMX TECHNIK 53
ABMESSUNGEN 55
TECHNISCHE DATEN 56
ENTSORGUNG 57
HERSTELLERERKLÄRUNGEN 58

FRANÇAIS
INFORMATIONS CONCERNANT CE MANUEL D’UTILISATION 59
UTILISATION CONFORME 59
EXPLICATIONS DES TERMES ET DES SYMBOLES 59
CONSIGNES DE SÉCURITÉ 60
REMARQUES CONCERNANT LES APPAREILS INTÉRIEURS MOBILES 63
CONTENU DE LA LIVRAISON 64
PRÉSENTATION 64
RACCORDEMENTS, ÉLÉMENTS DE COMMANDE ET D’AFFICHAGE 65
UTILISATION 67
INSTALLATION ET MONTAGE 78
ENTRETIEN, MAINTENANCE ET RÉPARATION 79
TECHNOLOGIE DMX 80
DIMENSIONS 82
CARACTÉRISTIQUES TECHNIQUES 82
MISE AU REBUT 84
DÉCLARATIONS DU FABRICANT 84
ESPAÑOL
INFORMACIÓN SOBRE ESTE MANUAL DE INSTRUCCIONES 86
USO PREVISTO 86
TÉRMINOS Y SÍMBOLOS 87
INSTRUCCIONES DE SEGURIDAD 87
INDICACIONES PARA EQUIPOS PORTÁTILES DE INTERIOR 90
VOLUMEN DE SUMINISTRO 91
INTRODUCCIÓN 91
CONEXIONES, ELEMENTOS DE MANDO Y ELEMENTOS DE VISUALIZACIÓN 92
FUNCIONAMIENTO 94
INSTALACIÓN Y MONTAJE 105
CUIDADO, MANTENIMIENTO Y REPARACIÓN 106
TECNOLOGÍA DMX 107
MEDIDAS 109
DATOS TÉCNICOS 110
ELIMINACIÓN 111
DECLARACIONES DEL FABRICANTE 112
CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ /
CONTENUTO

POLSKI
INFORMACJE DOTYCZĄCE NINIEJSZEJ INSTRUKCJI OBSŁUGI 113
UŻYTKOWANIE ZGODNE Z PRZEZNACZENIEM 113
ZASADY BEZPIECZEŃSTWA 114
UWAGI DOTYCZĄCE PRZENOŚNEGO SPRZĘTU WEWNĘTRZNEGO 117
OBJAŚNIENIA TERMINÓW I SYMBOLI 114
ZAKRES DOSTAWY 118
WPROWADZENIE 118
PRZYŁĄCZA, ELEMENTY OBSŁUGI I WSKAŹNIKI 119
OBSŁUGA 121
USTAWIANIE I MONTAŻ 132
CZYSZCZENIE, KONSERWACJA I NAPRAWY 133
TECHNIKA DMX 134
WYMIARY 136
DANE TECHNICZNE 136
UTYLIZACJA 138
DEKLARACJE PRODUCENTA 138
ITALIANO
INFORMAZIONI SUL PRESENTE MANUALE D'USO 140
UTILIZZO CONFORME 140
SPIEGAZIONE DI CONCETTI E SIMBOLI 140
INDICAZIONI SULLA SICUREZZA 141
AVVERTENZE PER DISPOSITIVI INDUSTRIALI PORTATILI 144
DOTAZIONE 145
INTRODUZIONE 145
CONNETTORI, ELEMENTI DI COMANDO E VISUALIZZAZIONE 146
UTILIZZO 148
INSTALLAZIONE E MONTAGGIO 159
PULIZIA, MANUTENZIONE E RIPARAZIONE 160
TECNOLOGIA DMX 161
INGOMBRO 163
DATI TECNICI 163
SMALTIMENTO 165
DICHIARAZIONI DEL PRODUTTORE 165
DMX
DMX CONTROL / DMX STEUERUNG / PILOTAGE DMX / CONTROL DMX /
STEROWANIE DMX / CONTROLLO DMX 167
CONTENTS / INHALTSVERZEICHNIS / CONTENU / CONTENIDO / TREŚĆ /
CONTENUTO

5
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
ENGLISH
YOU HAVE MADE THE RIGHT CHOICE!
This device has been developed and manufactured to the highest quality standards to ensure
many years of problem-free operation. Please read this manual carefully to be able to use your
new Cameo product quickly and optimally. Further information about Cameo Light is available on
our website CAMEOLIGHT.COM.
INFORMATION ON THIS USER MANUAL
•Carefully read the safety instructions and the entire manual before operating the device.
•Observe the warnings on the device and in the user manual.
•Always keep the user manual within reach.
•If you sell or pass on the device, it is important that you also include this user manual, as it is an
integral part of the product.
PROPER USE
The product is a device for event technology!
This product has been developed for professional use in the field of event technology and is not
suitable for use as domestic lighting!
Furthermore, this product is only intended for qualified users with specialist knowledge of event
technology!
Use of the product outside the specified technical data and operating conditions is considered
inappropriate!
Liability for damage and third-party damage to persons and property due to inappropriate use is
excluded!
The product is not suitable for:
• Use by persons (including children) with limited physical, sensory or mental abilities or lack of
experience and knowledge.
• children (children must be instructed not to play with the device).
DEFINITIONS AND SYMBOL EXPLANATIONS
1. HAZARD: The word HAZARD, possibly in combination with a symbol, indicates situations in
which there is an immediate danger or risk of potentially fatal injury.
2. WARNING: The word WARNING, possibly in combination with a symbol, indicates situations in
which there is an immediate danger or risk of potentially fatal injury.
3. CAUTION: The word CAUTION, possibly in combination with a symbol, indicates situations or
conditions that could result in injury.
4. ATTENTION: The word ATTENTION, possibly in combination with a symbol, indicates situations
or conditions that could result in damage to property and/or the environment.

6
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
This symbol identifies hazards that can cause electric shock.
This symbol identifies hazardous areas or hazardous situations.
This symbol indicates hazards caused by hot surfaces.
This symbol indicates hazards caused by intense light sources.
This symbol indicates a device in which there are no user-replaceable parts.
This symbol indicates additional information on the operation of the product.
SAFETY INSTRUCTIONS
HAZARD:
1. Do not open the device and do not perform any modifications.
2. If your device no longer functions properly, if liquids or objects get inside it or if it
has been damaged in any other way, switch it off immediately and unplug it from
the power source. The device may be repaired only by authorised repair techni-
cians.
3. For devices of protection class 1, the protective conductor must be connected
correctly. Never disconnect the protective conductor. Devices of protection class 2
do not have a protective conductor.
4. Ensure that live cables are not kinked or otherwise mechanically damaged.
5. Never bypass the device fuse.

7
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
WARNING:
1. The device may not be operated if it shows obvious signs of damage.
2. The device may only be installed in a voltage-free state.
3. If the device's power cable is damaged, the device may not be used.
4. Permanently connected power cables may only be replaced by a qualified person.
CAUTION:
1. Do not switch on the device if it has been exposed to extreme temperature fluctu-
ations (for example, following transport). Moisture and condensation can damage
the device. Switch on the device only when it has reached room temperature.
2. Ensure that the voltage and frequency of the mains supply match the values
specified on the device. If the device has a voltage selector switch, do not connect
the device until it has been set correctly. Use only suitable power cables.
3. To disconnect the device from the mains on all poles, it is not sufficient to press
the on/off switch on the device.
4. Make sure that the fuse used corresponds to the type printed on the device.
5. Ensure that suitable measures have been taken against overvoltage (e.g. lightning
strikes).
6. Observe the specified maximum output current on devices with a Power Out con-
nection. Ensure that the total current consumption of all connected devices does
not exceed the specified value.
7. Replace pluggable power cables with original cables only.
HAZARD:
1. Choking hazard! Plastic bags and small parts must be kept out of reach of per-
sons (including children) with reduced physical, sensory or mental capabilities.
2. Risk of falling! Make sure that the device is securely installed and will not fall
down. Only use suitable stands or mountings (particularly for fixed installations).
Ensure that accessories are properly installed and secured. Ensure that applicable
safety regulations are observed.

8
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
WARNING:
1. Use the device in the prescribed manner only.
2. Operate the device using only accessories of the type recommended and supplied
by the manufacturer.
3. Observe safety regulations applicable in your country during installation.
4. After connecting the device, ensure that all cables are routed so as to avoid dam-
age or accidents, such as from tripping.
5. Always observe the specified minimum distance to normally flammable materials!
Unless explicitly stated, the minimum distance is 0.3 m.
6. Always observe the minimum distance to the illuminated surface, which can be
read on the device!
CAUTION:
1. Moving components such as mounting brackets may become jammed.
2. In the case of devices with motor-driven components, there is a risk of injury due
to the movement of the device. Sudden movement of the device can cause shock
reactions.
3. The housing surface of the device can become very hot during regular operation.
Ensure that accidental touching of the housing is not possible. Always allow the
lamp to cool sufficiently before removal, maintenance work and charging etc.

9
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
CAUTION:
1. Do not install or use the device in the vicinity of radiators, accumulators, stoves,
or other heat sources Ensure that the device is always installed in such a way
that it is sufficiently cooled and cannot overheat.
2. Do not place any ignition sources, such as burning candles, near the device.
3. Ventilation openings may not be covered and fans may not be blocked.
4. For transport, use the original packaging or packaging provided by the manufac-
turer.
5. Avoid any impacts to or shaking of the device.
6. Observe the IP rating and the ambient conditions such as temperature and hu-
midity according to the specification.
7. Devices can be continuously further developed. In the event of deviating informa-
tion on operating conditions, performance or other device properties between the
user manual and the device labelling, the information on the device always has
priority.
8. The device is not suitable for tropical climate zones or for operation over 2,000m
above sea level.
9. Unless explicitly stated, the device is not suitable for operation under marine
conditions.
CAUTION! IMPORTANT INFORMATION REGARDING LIGHTING PRODUCTS!
1. Never look directly into the beam of light, not even for a short period of time.
2. Never look into the beam of light using optical devices such as a magnifying
glass.
3. Stroboscopic effects may cause epileptic seizures in those susceptible!
4. A permanently installed lamp is installed in this lighting unit which must not be
replaced by the user. In the event of a fault, please contact your sales partner.
NOTES FOR MOBILE INDOOR DEVICES
1. Temporary operation! Event equipment is generally only designed for temporary
operation.
2. Continuous operation or permanent installation can impair the functioning of the
device and cause premature ageing.

10
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
INCLUDED
Remove the product from the packaging and remove all packaging material.
Please check the completeness and integrity of the delivery and notify your distribution partner
immediately after purchase if the delivery is not complete or if it is damaged.
Product includes:
XDevice
XPower cable
X2 x Omega mounting brackets
XUser manual
INTRODUCTION
FEATURES
1 x high-power 60 W COB RGBW LED. RGBW colour mix. 2° beam angle. 2 high-speed motors for
pan and tilt. Endless pan and
tilt movement. DMX-512 control. Master/slave operation. Programmable scenes. Operating volta-
ge 100–240 V AC/50–60Hz. Power consumption 120 W. Omega mounting bracket included.
The spotlight features the RDM standard (Remote Device Management). Remote device manage-
ment allows the user to view the status and configuration of RDM terminals via an RDM-capable
controller.
CONTROL FUNCTIONS
4-channel, 15-channel, 16-channel, 20-channel, 35-channel, 42-channel and 89-channel DMX
control
Master/slave operation
Standalone functions
RDM

11
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
CONNECTIONS, OPERATING AND DISPLAY ELEMENTS
410 mm
214 mm
287 mm
206 mm
FRONT VIEW BASE
BACK VIEW BASE
Control: DMX
25C FAN: Normal
DMX Address
001
4 CH Mode
5 2 4
31
1POWER IN
Blue Power Twist mains input socket. Operating voltage 100–240 V AC/50–60 Hz. A suitable
power cable is included.
2POWER OUT
White Power Twist mains output socket for supplying power to additional Cameo spotlights (for
maximum output current, see label on back of housing).
3DMX IN
Male 3-pin and 5-pin XLR sockets for connection to a DMX control device (e.g. DMX console). Use
the sockets only as an alternative.
4DMX OUT
Female 3-pin and 5-pin XLR sockets for sending the DMX control signal. Use the sockets only as
an alternative.
5FUSE
Fuse holder for 5 x 20 mm micro fuses. IMPORTANT: Replace the fuse only with a fuse of the
same type and of the same value (see stamp on back of device). In the event of repeated fuse
failure, please contact an authorised service centre.

12
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
410 mm
214 mm
287 mm
206 mm
FRONT VIEW BASE
BACK VIEW BASE
Control: DMX
25C FAN: Normal
DMX Address
001
4 CH Mode
76
6. LC DISPLAY
The illuminated LC display shows the currently activated operating mode (main display), the menu
items in the main menu and the numerical value or operational status and options in the corre-
sponding menu items in the submenus. If there is no input for approx. one minute, the display
automatically returns to the main display. Note regarding the main display in operating modes
with external control: As soon as the control signal is interrupted, the characters in the display
begin to flash. When there is a control signal again, the flashing stops.
7. ROTARY-PUSH ENCODER
Rotary-push encoder for navigating in the editing menu and for adjusting system settings and
changing values in the corresponding menu items. Starting from the main display, press the
encoder to enter the main menu. Select the individual menu items in the main menu (Control,
Settings, Info, Service, Quicklight) and in the submenus by turning the encoder and confirm the
selection by pressing the encoder. Change the value or status in a menu item by turning the
encoder and confirm the change by pressing the encoder. To move up one level in the menu
structure, select the arrow symbol <= and confirm by pressing the encoder.

13
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
OPERATION
PLEASE NOTE
As soon as the spotlight is correctly connected to the power supply, the following will be displayed
in succession during the start-up process: “Software update ...Please wait” (for service purposes
only), the software version, then “Welcome to Cameo” and “Reset”. After this process, the spotli-
ght is ready for operation and the previously selected mode will be activated.
Note regarding the main display in operating modes with external control: As soon as the control
signal is interrupted, the characters in the display begin to flash. When there is a control signal
again, the flashing stops.
MAIN DISPLAY
The main display shows different operating mode-relevant information and information on the
device status in the different operating modes.
DMX start address
DMX operating
mode
DMX operating mode
Temperature of the LED unit Fan mode
Slave mode
Temperature of the LED unit Fan mode
Operating
mode
Operating
mode
Standalone mode Scene
Operating
mode
Operating
mode
and
Scene
Temperature of the LED unit Fan mode
Temperature of the LED unit Fan mode

14
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
CONFIGURE DMX START ADDRESS
Starting from the main display, press the rotary-push encoder to enter the main menu (MENU).
Select the menu item Control by turning and pressing the encoder. Turn the encoder to select
DMX and press the encoder again to confirm. Now select Address, confirm by pressing the
encoder and then select the desired DMX start address again by turning the encoder. Confirm your
selection by pressing the encoder.
CONFIGURE DMX MODE
Starting from the main display, press the rotary-push encoder to enter the main menu (MENU).
Select the menu item Control by turning and pressing the encoder. Turn the encoder to select
DMX and press the encoder again to confirm. Now select Channel Mode, confirm by pressing
the encoder and then select the desired DMX mode again by turning the encoder. Confirm your
selection by pressing the encoder.
SLAVE MODE
Starting from the main display, press the rotary-push encoder to enter the main menu (MENU).
Select the menu item Control by turning and pressing the encoder. Turn the encoder to select
Slave and press the encoder again to confirm. To activate slave operation, select Yes and confirm
by pressing the encoder. To deactivate, select No and also confirm by pressing the encoder.
Connect the slave and the master units (same model, same software version) with a DMX cable
and enable a scene in the master unit in the standalone mode Scenes (Run Scene 1–8/Master/
Alone ->Master). The slave unit will now follow the master unit.

15
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
STANDALONE OPERATION (SCENES)
Similar to when using a DMX control unit, the standalone operating mode Scenes makes it
possible to set pan, tilt, dimmer, RGBW, LED ring etc. directly on the device with values from 000
to 255. A total of 8 individual scenes (Scene 1–8) can be created, edited, saved and recalled. It is
also possible to record scenes via DMX controller (Record Scene) and transfer scenes completely
to a slave unit (Copy to Slave).
Starting from the main display, press the rotary-push encoder to enter the main menu (MENU).
Select the menu item Control by turning and pressing the encoder. Turn the encoder to select the
menu item Scenes and press the encoder again to confirm.
This will take you to the submenu for setting the submenu items. See table (rotate the encoder to
select and push the encoder to confirm selection, change value or status by rotating, confirm by
pressing encoder, go back with <=):
SYSTEM SETTINGS (SETTINGS)
Starting from the main display, press the rotary-push encoder to enter the main menu (MENU).
Turn the encoder to select the system Settings menu and press the encoder.
This will take you to the submenu for configuring the submenu items, see table:

16
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Scenes <=
Run Scene
(start scene)
<=
Scene 1–8 Start Scene 1–8:
select and confirm scene
Select and confirm scene
Record Scene <=
Scene 1–8 NO Cancel operation
YES Set scene
in control-
ler, confirm
with YES
Edit Scene <=
Scene 1–8 <=
Pan 000–255
Tilt 000–255
P/T Macro 000–255
P/T Speed 000–255
Dimmer Beam 000–255
Strobe Beam 000–255
Red Beam 000–255
Green Beam 000–255
Blue Beam 000–255
White Beam 000–255
Dimmer Ring 000–255
Strobe Ring 000–255
Red Ring 000–255
Green Ring 000–255
Blue Ring 000–255
Ring Macro 000–255
Ring Speed 000–255
Master/Alone
(send/do not send
output control signal
via DMX OUT)
<=
Master Signal DMX OUT
Alone Signal DMX OUT
Copy to Slave <=
NO Cancel operation
YES Transfer all scenes to slave unit (scenes on
slave unit will be overwritten)

17
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
DEVICE INFORMATION (INFO)
Starting from the main display, press the rotary-push encoder to enter the main menu (MENU).
Turn the encoder to select the Info menu for device information and press the encoder.
Settings (bold = factory setting)
Select by turning the encoder, confirm by pressing, change value or status by turning, confirm
by pressing. Back with <=.
Display Display settings <=
Flip Floor Use No display rotation
Rig Use Display is rotated
through 180° (e.g. for
overhead installation)
OFF Timer 1 Minute Off Deactivation of display
illumination after approx.
1 minute without input
Always On Display lighting perma-
nently on
Intensity 001–010 Display brightness
Signal
Fail
Operational status on
control signal
interruption
<=
Hold Value Last command is
retained
Run Scene 1 Activates Scene
1
Black Out Activates blac-
kout

18
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
Dimmer Selects dimmer
curve and dimmer
response
<=
Curve <=
Linear Light intensity increases
linearly with DMX value
Exponential Light intensity can be
finely adjusted at lower
DMX values and broadly
adjusted at higher DMX
values
Logarithmic Light intensity can be
broadly adjusted at lower
DMX values and finely
adjusted at higher DMX
values
S-curve Light intensity can be
finely adjusted at lower
and higher DMX values
and broadly adjusted at
medium DMX values
Response <=
LED Lamp responds abruptly
to changes in DMX value
Halogen Spotlight behaves like a
halogen spotlight with
soft brightness changes

19
DMX DEUTSCHFRANCAIS
ESPAÑOL ENGLISH
ITALIANO POLSKI
Pan/Tilt
Motors
Device head settings <=
Pan/Tilt
Speed
000–255 000 = maximum, 255 =
minimum speed
Pan Reverse <=
Normal Does not reverse pan
direction
Reverse Reverses pan direction
Tilt Reverse <=
Normal Does not reverse tilt
direction
Reverse Reverses tilt direction
Sensors <=
ON Automatic position cor-
rection is enabled
OFF Automatic position cor-
rection is disabled
Blackout
Moving
<=
Off No blackout during
head movement
On Blackout during
head movement
Fan
Settings
Fan control <=
Automatic The fan speed is automatically adjusted to
the temperature in the device head
Normal Reduced maximum fan speed, resulting in
slightly reduced brightness if necessary
Silent Consistently low fan speed with reduced
brightness if necessary
Auto
Lock
Automatic
locking of
rotary-push
encoder
<=
60 Seconds Automatic locking of the rotary-push encoder
after 60 seconds without input. Unlock: Keep
encoder pressed for approx. 5 seconds
No Lock Deactivates automatic locking

20
DMX
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
DEUTSCHENGLISH
In order to have the required information displayed, select the relevant menu item by turning the
encoder and then press the encoder to confirm.
Info
<= Back
Firmware Displays the firmware of the device components
Temperature Displays the temperature of the device base (Base) and the LED unit (LED) in
degrees Celsius and Fahrenheit
Fan Speed Displays the rotational speed of the two fans in the device head in RPM
Run Time Displays the running time of the LED unit (LED), the total running time (Total)
and the running time since the last service (Service)
RDM UID Displays the RDM UID
DMX Values Displays the applied DMX values
Error Info Status display of the device components (OK / Error)
DMX Tables Tables of the various DMX modes
SERVICE
Starting from the main display, press the rotary-push encoder to enter the main menu (MENU).
Select Service by turning the encoder and press the encoder to enter the service menu.
This will take you to the submenu for editing the submenu items, see table:
