Sencor SSC 3001YL User manual

EN
EN-1
Steam Cleaner
User's manual
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
SSC 3001YL
Prior to using this appliance, please read the user'smanual thoroughly, even in cases, when one has
already familiarised themselves with previous use of similar types of appliances. Only use the appliance
in the manner described in this user’smanual. Keep this user'smanual in asafe place where it can be
easily retrieved for future use.
We recommend saving the original cardboard box, packaging material, purchase receipt and
responsibility statement of the vendor or warranty card for at least the duration of the legal liability for
unsatisfactory performance or quality. In the event of transportation, we recommend that you pack the
appliance in the original box from the manufacturer.
Translation of the original manual

EN-2
EN
Steam Cleaner
SSC 3001YL
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
CONTENTS
IMPORTANT SAFETY INSTRUCTIONS .....................................................................................................................................................................3
DESCRIPTION OF THE STEAM CLEANER................................................................................................................................................................6
OVERVIEW OF THE ACCESSORIES AND THEIR PURPOSE OF USE................................................................................................................7
ATTACHING AND REMOVING ACCESSORIES ......................................................................................................................................................7
FILLING THE WATER TANK ...........................................................................................................................................................................................9
BEFORE FIRST USE.......................................................................................................................................................................................................... 9
USING THE STEAM CLEANER ...................................................................................................................................................................................10
PROBLEMS AND TROUBLESHOOTING.................................................................................................................................................................11
MAINTENANCE AND CLEANING.............................................................................................................................................................................11
STORAGE..........................................................................................................................................................................................................................12
TECHNICAL SPECIFICATIONS...................................................................................................................................................................................12
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING MATERIALS .....................................12
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC APPLIANCES..........................................................................................................12

Steam Cleaner
SSC 3001YL
EN
EN-3
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND STORE FOR FUTURE USE.
■This appliance may be used by persons with physical,
sensory or mental impairments or by persons with
insufficient experience and knowledge, if they are
properly supervised or have been informed about
how to use the appliance in a safe manner and
understand the potential dangers.
■Children must not play with the appliance.
■In the event that the power cord is damaged, have it
repaired at a professional service centre to prevent
causing a dangerous situation. It is forbidden to use
the appliance if it has a damaged power cord.
■Always disconnect the power adapter from the power
socket before cleaning or performing maintenance
on the appliance.
■Use the appliance only with the original power
adapter and accessories that came with it.
WARNING:
Hot steam. Danger of scalding.
■Do not point the sprayer at equipment containing
electrical components such as, for example the inside
of an oven.
■The dirty water tank drain valve must not be open
when the appliance is being used.

EN-4
EN
Steam Cleaner
SSC 3001YL
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
■Always turn off the appliance when you have finished
using it, when leaving it without supervision, prior to
cleaning and before connecting it to a power socket
by means of the power adapter.
■When the appliance is connected to the mains power
supply via the adapter, it must not be left without
supervision.
■Do not use the appliance if it is leaking, if it has fallen
or if it is showing visible signs of damage.
■Keep the appliance out of children’s reach when it
is in operation, when pressurised with steam, when
connected to a power socket or while it is cooling
down.
• Always disconnect the power plug from the power socket before cleaning or performing maintenance on the
appliance.
• When using the appliance, steam must not be directed at other people, animals or equipment containing elec-
trical components such as, for example, baking ovens.
Attention:
The water tank is pressurised with hot water, therefore do not open the lling opening or even
attempt to loosen the safety valve.
• Fill the water tank according to the instructions contained in chapter Filling the water tank. Do not overll the
water tank.
• Do not leave the appliance without supervision when it is connected to a power socket.
• It is forbidden to open the lling opening on the water tank when using the appliance.
• Before connecting the appliance to apower socket, check that the voltage on its rating label matches the elec-
trical voltage in the power socket.
• Connect the appliance only to agrounded power socket.
• This appliance is designed for household use. Do not use it for commercial purposes, in industrial surroundings
or outdoors.
• This appliance serves to clean oor areas, ttings, wash basins, tiles and paving, windows, mirrors, range hoods,
cooktops, oven doors, grills, countertops, upholstered furniture, clothing, toys, etc.
• Do not use the appliance to clean leather materials, vinyl oors, oor areas without thoroughly sealed joints,
oors or furniture treated with wax, synthetic fabrics, products from softened plastics, frozen glass or glass that
is cooled to alow temperature, velvet or suede fabrics or other materials that could be damaged by the eect
of hot steam.
• Do not use the appliance for apurpose other than that for which it is designed.
• Pay increased attention to avoid scalding by the hot steam when operating the appliance.

Steam Cleaner
SSC 3001YL
EN
EN-5
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
• Do not place the appliance on an electric or gas stove or in its vicinity, on the edge of atable or on an unstable
surface. Only place the appliance on an even, dry and stable surface.
• Fill the water tank only with tap water or distilled water when the tap water is too hard and causes mineral
deposits to form. Before lling the water tank, make sure that the appliance is turned o and disconnected from
the power socket.
• Never add descaling agents, fragrant oils, detergents, alcohol, etc. to the water tank. Otherwise this could result
in damage to the appliance or injury.
• Before attaching, removing or changing accessories check that the appliance is turned o and disconnected
from the power socket.
• Do not use the appliance in areas where there are fumes from oil paint thinners or chemicals used for treating
clothing against moths or other explosive or toxic fumes.
• When using the appliance, do not touch the parts that are hot. Otherwise, this could cause burns.
• When using the appliance, do not turn it upside down, do not block the steam exit holes nor insert any items
into them.
• After use and before cleaning the appliance, always turn it o and disconnect the power cord from the power
socket.
• Allow the appliance to fully cool down before cleaning or storing it.
• Do not let the power cord touch hot surfaces or sharp objects. Position the power cord so that it will not be
tripped over.
• To prevent potential injury by electric shock, do not submerge this appliance or its power cord in water or any
other liquid or rinse it under running water.
• Do not disconnect the appliance from the power socket by pulling on the power cord. This could damage the
power cord or the power socket. Disconnect the cord from the power socket by gently pulling on the plug of
the power cord.
• Do not use the appliance if it has damaged power cord. If the power cord is damaged, have it replaced at apro-
fessional service centre.
• To avoid a hazardous situation arising, do not repair the device yourself or modify it in any way. Have all repairs
or adjustments performed at an authorised service centre. By tampering with the appliance, you risk voiding
your legal rights arising from unsatisfactory performance or quality warranty.

EN-6
EN
Steam Cleaner
SSC 3001YL
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
DESCRIPTION OF THE STEAM CLEANER
A
2
1
3
4
5
6
7
8
9
0
qa
qd
qs
qf
qg
1 Safety valve
2 Steam nozzle
3 350 ml water tank
4 175 ml measuring cup
5Funnel
6 Textile sleeve for the minimop
7 Basic straight nozzle
8 Trigger lock
9 Steam release trigger
0 Flexible hose
qa Indicator light
Signalises the switching of the heating
element that heats the water in the water
tank.
qs Round brush (3 pcs)
qd Minimop head
qf Window and mirror cleaning attachment
qg Bent nozzle

Steam Cleaner
SSC 3001YL
EN
EN-7
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
OVERVIEW OF THE ACCESSORIES AND THEIR PURPOSE OF USE
Type of accessory Purpose of use
Basic straight nozzle A7Serves to clean:
– tiles, paving and other hard oor surfaces with xed joints;
– water taps and sanitary equipment;
– toys, tables and other workbenches;
– hard to reach places.
Flexible hose A0Used for cleaning hard to reach places.
Minimop with atextile
sleeve Aqd aA6
Used for steaming clothing and cleaning clothing, upholstered
furniture, drapes, bed linen, etc.
Bent nozzle Aqg Serves to clean:
– water taps and sanitary equipment;
– toys, tables and other workbenches;
– hard to reach places.
Window and mirror
cleaning attachment Aqf
Serves to clean windows, mirrors and walls of shower cabinets.
Round brush Aqs Serves to clean:
– stoves, grills and grilling accessories;
– tiles, paving and other hard oor surfaces with xed joints;
– water taps and sanitary equipment;
– toys, tables and other workbenches.
Do not use the steam cleaner to clean:
– synthetic fabrics, velvet or suede fabrics or other textile materials that could be damaged by the
effect of hot steam.
– waxed furniture or oor areas. The effect of hot steam may result is aloss of gloss.
– frozen glass or glass that is subjected to alow ambient temperature, otherwise it may be damaged
or crack.
– wooden surfaces without apaint coat.
ATTACHING AND REMOVING ACCESSORIES
• The round brush Aqs and the bent nozzle Aqg can be attached to the nozzle of the steam cleaner
A2, the basic straight nozzle A7 or the exible hose A0. In the event that an even greater reach
is required to the exible hose A0 it is possible to attach the basic straight nozzle A7and then
attach the brush Aqs or the bent nozzle Aqg on to it.
• The minimop Aqd can be attached to the nozzle of the steam cleaner A2 or to the exible hose
A0.

EN-8
EN
Steam Cleaner
SSC 3001YL
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
Attaching and removing the exible hose
• On to the nozzle of the steam cleaner A2 attach the exible hose A0 so that the symbol “I”
marked on the hose connector A0 is aligned with the same symbol on the steam cleaner. Rotate
the hose connector A0 by 90° anticlockwise. Now the “I” symbol marked on the hose connector
A0 will be aligned with symbol “II” on the steam cleaner.
• Remove the exible hose A0 in the reverse sequence.
Attaching and removing the basic straight nozzle
• On to the nozzle of the steam cleaner A2 attach the basic straight nozzle A7 so that the symbol
“I” marked on the nozzle connector A7 is aligned with the same symbol on the steam cleaner.
Rotate the nozzle A7 by 90° anticlockwise. Now the “I” symbol marked on the nozzle connector
A7 will be aligned with symbol “II” on the steam cleaner.
• It is also possible to connect the basic straight nozzle A7 to the exible hose A0, by seating
the nozzle connector A7 on to the nozzle of the exible hose A0 and turnig nozzle A7 90°
anticlockwise. This will rmly connect these two parts.
• Remove the basic straight nozzle A7 in reverse sequence.
Attaching and removing the round brush and bent nozzle
• You can seat the round brush Aqs and the bent nozzle Aqg on to the nozzle of the steam cleaner
A2, the basic straight nozzle A7 or the exible hose A0. Accessories need to be properly attached
so that they do not come loose during use.
• Remove the brush Aqs and nozzle Aqg in reverse sequence.
Attaching and removing the minimop and textile sleeve
• On to the nozzle of the steam cleaner A2 attach the minimop Aqd so that the symbol “I” marked
on the minimop Aqd is aligned with the same symbol on the steam cleaner. Rotate the minimop
connector Aqd by 90° anticlockwise. Now the “I” symbol marked on the minimop connector Aqd
will be aligned with symbol “II” on the steam cleaner.
• You can also use the minimop Aqd with the exible hose A0. First attach the exible hose A0onto
the steam cleaner according to the instructions contained in subchapter Attaching and removing
the exible hose. Then on to the nozzle of the exible hose A0 attach the minimop Aqd and turn
the minimop connectorqd by 90° anticlockwise. This will rmly connect these two parts.
• Pull the textile sleeve A6 on to the head of the minimop Aqd.
• Remove the minimop Aqd and the textile sleeve A6 in reverse sequence.
Attention:
Allow the minimop Aqd and the textile sleeve A6 to fully cool down before removal.
Attaching and removing the window and mirror cleaning attachment
• On to the nozzle of the steam cleaner A2 or the exible hose A0 attach the minimop Aqd
(without the textile sleeve A6) according to the instructions contained in subchapter Attaching
and removing the minimop and textile sleeve.
• To the head of the minimop Aqd connect the window and mirror cleaning attachment Aqf so
that both tabs at the bottom of the attachment Aqf slide into the holes in the bottom part of the
minimop head Aqd. Then push the attachment Aqf against the head of the minimop Aqd, until the
tab in the top part of the attachment Aqf attaches to the top edge of the minimop head Aqd.
• When removing the attachment Aqf, rst release the tab in the top part of the attachment Aqf by
lifting it up. Then tilt the attachment Aqf away from the minimop head Aqd and slide the tabs in
the bottom part of attachment Aqf out of the openings in the bottom part of the minimop Aqd.

Steam Cleaner
SSC 3001YL
EN
EN-9
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
FILLING THE WATER TANK
1. Filling the water tank before use
• Make sure that the steam cleaner is turned off and disconnected from the power socket.
• Unscrew the safety valve A1 anticlockwise out of the steam cleaner.
• Fill the measuring cup A4 with clean water up to the 175 ml mark. Place the funnel A5into the
lling opening and hold it there. Pour the water from the measuring cup A4 into the water tank
A3. You may add another 75 ml of water into the water tank A3. This will utilise the maximum
capacity of the water tank A3, i.e. 250 ml of water. Do not overll the water tank A3 with more
water, otherwise steam will not be able to form inside it and the steam cleaner will not work
correctly.
• Again, close the lling opening with the safety valve A1. Firmly tighten the safety valve A1 by
turning it clockwise.
Attention:
Always ll the water tank A1 only with clean tap water or distilled water when the
tap water is hard or very hard. Never add descaling agents, fragrant oils, detergents,
alcohol, etc. to the water tank A1. Otherwise this could result in damage to the steam
cleaner or injury.
2. Relling the water tank
• Turn off the steam cleaner and disconnect it from the power socket. Release the trigger lock A8
by sliding it towards the open padlock symbol and press the steam release trigger A9. Hold down
the trigger A9 until all steam is released from the water tank A3.
• Turn the safety valve A1 anticlockwise until it is partially released. In this phase, do not fully screw
out the safety valve A1. In this way, you will ensure the gradual release of residual steam. Wait
approximately 5 minutes for the remaining water in the water tank A3 to cool down and then you
can screw out the safety valve A1 and take it off the lling opening.
• Pour the remaining water out of the water tank A3 and allow the steam cleaner to cool down
for approximately 10 minutes. Add water to the water tank A3according to the instructions
contained in the previous subchapter. Take care not to overll it. There should not be more than
250ml of water in the water tank A3.
• Screw the valve A1 back on to the lling opening and tighten it rmly in the clockwise direction.
Then you can continue using the steam cleaner.
Note:
In the event that the steam cleaner is pressurised with alarger amount of steam, the valve
mechanism will not enable the safety valve A1 to be screwed out. The safety valve A1 will
keep slipping and it will not be possible to release it. In such acase, rst release all the steam
and then try again to release the safety valve A1. Wait approximately 5 minutes for the
remaining water in the water tank A3 to cool down before fully screwing out the safety
valve A1.
BEFORE FIRST USE
• Make sure that the steam cleaner is turned off and disconnected from the power socket.
• Wipe the outer surface of the steam cleaner and its accessories with aclean lightly dampened cloth
and then thoroughly wipe everything dry.

EN-10
EN
Steam Cleaner
SSC 3001YL
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
USING THE STEAM CLEANER
• The steam cleaner generates hot steam which quickly and effectively removes grease, accumulated
dirt and grime without using any chemical agents.
• We recommend always testing the effects of the steam on asmaller area. After cleaning, allow the
test surface to dry completely so that you can observe whether the surface of the cleaned area does
not become damaged, discoloured, etc.
• Make sure that the accessories that you wish to use are attached to the steam cleaner and that the
water tank A3 is lled with water.
• Connect the steam cleaner to apower socket. When it is connected to apower socket, the indicator
Aqa will be lit indicating that water in the water tank A3 is being heated.
Attention:
Before connecting the steam cleaner to apower socket, rst check that the trigger lock
A8 is not released so that trigger A9 cannot be accidentally pressed.
• It takes approximately 2.5minutes for the water to heat up. Then the indicator Aqa will turn off.
This signalises that the water has been heated to the operating temperature and that the steam
cleaner is ready for use.
Note:
The indicator Aqa regularly turns on and off during operation which signals that water
temperature is being maintained.
• Steam will be released when the trigger lock A8 is released and the trigger A9 is pressed. If you
wish to stop the steam ow, release the trigger A9. The trigger lock A8 will return to the initial
position. This means that the trigger A9 is secured against being accidentally pressed.
• When you have nished using the steam cleaner, turn it off and disconnect it from the power
socket. Release the remaining steam and allow the steam cleaner to cool down. When it has cooled
down, screw out the safety valve A1, and remove the remaining water from the water tank A3
and clean the steam cleaner according to the instructions contained in the chapter Maintenance
and cleaning.
Instructions for cleaning clothing
• To clean clothing, use the minimop head Aqd with the textile sleeve A6.
• Make sure that the material from which the clothing is made is suitable for cleaning with hot
steam. Hang the clothing and ride over it with the minimop head Aqd with the sleeve A6in the
vertical and horizontal direction.
Instructions for cleaning mirrors, windows and other glass surfaces.
• To clean mirrors, windows and other glass surfaces, use the window and mirror cleaning attachment
Aqf.
• Ride over the surface of the glass surface or mirror in the horizontal or vertical direction. When
cleaning windows, we recommend to release the steam in short bursts.
• Never use the steam cleaner on frozen glass or glass that is subjected to alow ambient temperature,
otherwise it may be damaged or crack.
Instructions for cleaning oor surfaces with xed joints (tiles, etc.)
• To clean oor surfaces, use the exible hose A0 with round brush Aqs or bent nozzle Aqg.
• Ride over stains and soils that need to be removed with the hot steam. In the case of heavy soiling,
apply alarger amount of steam to the respective areas.
• When using the round brush Aqs, do not push too hard on it.
• Do not use the steam cleaner on waxed surfaces. Hot steam may cause the loss of gloss.

Steam Cleaner
SSC 3001YL
EN
EN-11
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
PROBLEMS AND TROUBLESHOOTING
Problem Possible cause Solution
Low steam pressure. The water tank A3
is overlled.
Do not attempt to screw out the safety valve A1.
Otherwise scalding could result. Release the trigger
lock A8, press the trigger A9, hold it down and wait
awhile. When the volume of water in the water tank
A3 is reduced, space for the formation of steam will be
created and pressure will increase.
Steam pressure falls
suddenly. The water tank A3
is almost empty.
Add water to the water tank A3according to the
instructions contained in chapter Filling the water tank.
Water is being
released from the
steam cleaner
instead of steam.
The water tank A3
is overlled.
Turn off the steam cleaner and disconnect it from the
power socket. Allow it to cool down. Then remove all
water from the water tank A3. Fill the water tank A3
with max. 250 ml of water according to the instructions
contained in the chapter Filling the water tank.
It is not possible
to press the steam
release trigger A9.
The trigger lock A8
is not released.
Slide the trigger lock A8 forward towards the open
padlock symbol to release it. Hold down the trigger lock
A8 in this position and press the steam release trigger
A9.
The safety valve A1
cannot be screwed
out.
The pressure in the
water tank A3is
too high and when
opened there would
be arisk of scalding.
Release the trigger lock A8, press trigger A9and hold
it down until all the steam is released from the water
tank A3. Then carefully release the safety valve A1.
Wait approximately 5 minutes for the water in the
water tank A3 to cool down. Then you can completely
screw out the safety valve A1 and take it off the lling
opening.
MAINTENANCE AND CLEANING
Cleaning
•Make sure that the steam cleaner is turned off and disconnected from the power socket. Before
cleaning, release the remaining steam and allow the steam cleaner to cool down.
• Slowly screw out the safety valve A1 in the anticlockwise direction.
• Pour the unused water out of the water tank A3.
• To prevent the formation of mineral deposits inside the water tank A3, rinse it out with clean
water after every use. Do not leave water inside it.
• Remove any accessories that you used from the steam cleaner. Wipe the accessories with
adampened cloth or wash it in warm water using aneutral kitchen detergent. Then rinse under
clean running water and thoroughly wipe dry.
Attention:
The accessories are not designed to be washed in adishwasher.
• You may wash the textile sleeve A6 by hand or in awashing machine at atemperature of 40 °C.
Do not use bleaches or fabric softeners when washing it.
• Wipe the outer surface of the steam cleaner with alightly dampened cloth and then wipe dry.
• Never use cleaning agents causing abrasion, petrol, solvents, etc. to clean the steam cleaner and its
accessories.
• To prevent potential injury by electric shock, do not submerge the steam cleaner or its power cord
in water or any other liquid.

EN-12
EN
Steam Cleaner
SSC 3001YL
Copyright © 2020, Fast ČR, a.s. Revision 05/2020
STORAGE
• Store the steam cleaner that has been cleaned according to the provided instructions in adry, clean
place out of the reach of children.
TECHNICAL SPECIFICATIONS
Rated voltage range ...........................................................220−240 V
Rated frequency .................................................................50/60 Hz
Rated power. ................................................................900–1050 W
Protection level against harmful ingress of water .........................................IPX4
Explanation of technical terminology
The protection level against harmful ingress of water IPX4 means that the appliance is protected
against splashing water.
We reserve the right to change text and technical specications.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED
PACKAGING MATERIALS
Dispose of used packaging material at a site designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
The meaning of the symbol on the product, its accessory or packaging indicates that this
product shall not be treated as household waste. Please, dispose of this product at your
applicable collection point for the recycling of electrical & electronic equipment waste.
Alternatively in some states of the European Union or other European states you may
return your products to your local retailer when buying an equivalent new product.
The correct disposal of this product will help save valuable natural resources and help
in preventing the potential negative impact on the environment and human health,
which could be caused as a result of improper liquidation of waste. Please ask your
local authorities or the nearest waste collection centre for further details. The improper
disposal of this type of waste may fall subject to national regulations for nes.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier
for the necessary information.
Disposal in other countries outside the European Union.
This symbol is valid in the European Union. If you wish to dispose of this product, request
the necessary information about the correct disposal method from the local council or
from your retailer.
This product meets all the basic requirements of EU directives related to it.
