Sencore Impulse 100E User manual

July 2020
www.sencore.com | 1.605.978.4600 Revision 1.0
Impulse 100E
Network Encoder and Streamer
User Manual

Impulse 100E–User Manual
Page 2
(48)
Copyright
© 2020 Sencore, Inc. All rights reserved.
3200 Sencore Drive, Sioux Falls, SD USA
www.sencore.com
This publication includes confidential, proprietary, and trade secret information. No part of this document may
be copied, photocopied, reproduced, translated, or reduced to any machine-readable or electronic format
without prior written permission from Sencore. Information in this document is subject to change without notice
and Sencore Inc. assumes no responsibility or liability for any errors or inaccuracies. Sencore, Sencore Inc,
and the Sencore logo are trademarks or registered trademarks in the United States and other countries. All
other products or services mentioned in this document are identified by the trademarks, service marks, or
product names as designated by the companies who market those products. Inquiries should be made directly
to those companies. This document may also have links to third-party web pages that are beyond the control
of Sencore. The presence of such links does not imply that Sencore endorses or recommends the content on
those pages. Sencore acknowledges the use of third-party open source software and licenses in some
Sencore products. This freely available source code can be obtained by contacting Sencore Inc.
About Sencore
Sencore is an engineering leader in the development of high-quality signal transmission solutions for the
broadcast, cable, satellite, IPTV, telecommunications, and professional audio/video markets. The company’s
world-class portfolio includes video delivery products, system monitoring and analysis solutions, and test and
measurement equipment, all designed to support system interoperability and backed by best-in-class
customer support. Sencore meets the rapidly changing needs of modern media by ensuring the efficient
delivery of high-quality video from the source to the home. For more information, visit www.sencore.com.

Impulse 100E–User Manual
Page 3
(48)
Revision History
Date
Version
Description
Author
05/28/2020
1.0
Initial Release
ACP

Impulse 100E–User Manual
Page 4
(48)
Safety Instructions
Read these instructions
Keep these instructions
Heed all warnings
Follow all instructions
Do not use this apparatus near water
Clean only with dry cloth
Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions
Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat
Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong is
provided for your safety. If the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
Only use attachments/accessories specified by the manufacturer.
Unplug this apparatus during lightning storms or when unused for long periods of
time.
Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or
has been dropped.
Do not expose this apparatus to dripping or splashing and ensure that no objects
filled with liquids, such as vases, are placed on the apparatus.
The mains plug of the power supply cord shall remain readily operable.
Damage Requiring Service: Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the following conditions:
oWhen the power-supply cord or plug is damaged.
oIf liquid has been spilled, or objects have fallen into the product.
oIf the product has been exposed to rain or water.
oIf the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of the controls may result in
damage and will often require extensive work by a qualified technician to
restore the product to its normal operation.
oIf the product has been dropped or damaged in any way.
oThe product exhibits a distinct change in performance.

Impulse 100E–User Manual
Page 5
(48)
SAFETY PRECAUTIONS
There is always a danger when using electronic equipment.
Unexpected high voltages can be present at unusual locations in defective
equipment and signal distribution systems. Become familiar with the equipment
that you are working with and observe the following safety precautions.
Every precaution has been taken in the design of your Impulse 100E to ensure
that it isassafe as possible. However, safe operation depends on you the operator.
Always be sure your equipment is in good working order. Ensure that all points of
connection are secure to the chassis and that protective covers are in place and
secured with fasteners.
Never work alone when working in hazardous conditions. Always have another
person close by in case of an accident.
Always refer to the manual for safe operation. If you have a question about the
application or operation, email [e-mail].
WARNING –To reduce the risk of fire or electrical shock never allow your
equipment to be exposed to water, rain or high moisture environments. If it is
exposed to a liquid, remove power safely (at the breaker) andsend your equipment
to be serviced by a qualified technician.
To reduce the risk of shock the Impulse 100E must be connected to a mains socket
outlet with a protective earthing connection.
For the Impulse 100E, the mains plug is the main disconnect and should remain
readily accessible and operable at all times.
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.

Impulse 100E–User Manual
Page 6
(48)
Package Contents
The following is a list of the items that are contained along with the Impulse 100E:
1. Quick Start Guide
2. AC Power Supply
3. A/V Adapter Cable
Note: If any option cables were ordered with the Impulse 100E, they will be contained in
the box as well.
If any of these items were omitted from the packaging of the Impulse 100E please call 1-
800-SENCORE to obtain a replacement. Manuals for Sencore products can be
downloaded at www.sencore.com

Impulse 100E–User Manual
Page 7
(48)
Table of Contents
Section 1 Overview.............................................................................................8
1.1 Product Introduction.....................................................................................................9
1.2 Front Panel Overview ..................................................................................................9
1.3 Rear Panel Overview...................................................................................................9
Section 2 Installation........................................................................................11
2.1 Installation Preparation..............................................................................................12
2.2 Equipment Wiring and Connection............................................................................12
2.3 Maintenance ..............................................................................................................12
2.4 Network Setup via Front Panel..................................................................................12
2.4.1 Static IP Address/Subnet Mask/Gateway.............................................................12
2.4.2 DHCP....................................................................................................................14
Section 3 Operating the Front Panel...............................................................16
3.1 Impulse 100E Front Panel Overview.........................................................................17
Section 4 Operating the Web Interface ...........................................................19
4.1 Impulse 100E Web Interface Overview .....................................................................20
4.1.1 Logging in to the Impulse 100E Web Interface ....................................................20
4.1.2 Status Page..........................................................................................................21
4.2 Live Mode ..................................................................................................................22
4.2.1 Advanced Settings................................................................................................26
4.3 Playback Mode ..........................................................................................................30
4.3.1 Basic Settings Tab................................................................................................30
4.4 Recording Mode ........................................................................................................31
4.5 System Settings Menu...............................................................................................32
Section 5 Appendix...........................................................................................38
Appendix A –Acronyms and Glossary.......................................................39
Appendix B –Using Manual RTMP Streaming for YouTube......................41

Impulse 100E–User Manual
Page 8
(48)
Section 1 Overview
Introduction
This section includes the following topics:
1.1 Product Introduction.....................................................................................................9
1.2 Front Panel Overview ..................................................................................................9
1.3 Rear Panel Overview...................................................................................................9

Impulse 100E–User Manual
Page 9
(48)
1.1 Product Introduction
The Impulse 100E is a cost-effective single-channel encoder and streamer for audio and
video processing and transport. It supports professional encoding and IP streaming for
live encoding, uploading, and playback.
1.2 Front Panel Overview
The Impulse 100E can be controlled from the front panel with the LCD screen and buttons
that are shown below in Figure 1. A detailed description of using the front panel can be
found in Section 3.
Figure 1: Impulse 100E Unit Front Panel
1. Reset Button: pressing this will reboot the Impulse 100E.
2. LCD Screen: shows menus for user status and unit control
3. Up, Down, Left, Right, OK and Menu Buttons: provides navigation and entry within
LCD screen menus
4. Error Indicator: light indicates red when the unit is in alarmed condition
5. USB Port: purposed for storage while using the record and playback features.
Note: the Impulse 100E is only compatible with the FAT32 USB/SD format.
1.3 Rear Panel Overview
The Impulse 100E comes standard with all of the hardware back panel features shown
and listed belowexcept where noted as anImpulse 100E-01or Impulse 100E-02 exclusive
option. Refer to the Figure 2 at the top of the next page.
1
2
3
4
5

Impulse 100E–User Manual
Page 10
(48)
Figure 2: Impulse 100E Unit Back Panel
1. SMA Antenna
2. SDI In (exclusive to the Impulse 100E-01)
3. RF out –for QAM modulation (exclusive to Impulse 100E-02)
4. YPbPr In
5. AV/CCIN –Audio/Video or closed caption input
6. Digital Video Input Connector (HDMI)
7. RJ45 –management and UDP output port (10/100)
8. DC Input –power input (12V –2A)
1
1
2
3
4
5
7
8
6

Impulse 100E–User Manual
Page 11
(48)
Section 2 Installation
Introduction
This section includes the following topics:
2.1 Installation Preparation..............................................................................................12
2.2 Equipment Wiring and Connection............................................................................12
2.3 Maintenance ..............................................................................................................12
2.4 Network Setup via Front Panel..................................................................................12

Impulse 100E–User Manual
Page 12
(48)
2.1 Installation Preparation
This chapter includes information for the technicians installing the equipment.
Before starting, confirm the device is in good condition and the necessary cabling is
present to complete the installation.
When unpacking the unit, inspect it for shipping damage. If any damage is found, contact
Sencore customer service.
2.2 Equipment Wiring and Connection
Only use the supplied power connector or a 12V, 2A equivalent.
Connect to the RJ45 port with a CAT5 cable. Access the Impulse 100E management
interface with a PC on the same network or directly connected to the Impulse.
2.3 Maintenance
The Impulse 100E is a maintenance-free piece of equipment. There are no user
serviceable parts inside unit.
2.4 Network Setup via Front Panel
The Impulse 100E can be accessed on a network connection to allow remote
management. For these features to work, the network settings for the Impulse 100E must
first be configured properly for the network it is connected to.
2.4.1 Static IP Address/Subnet Mask/Gateway
To setup the Impulse 100E with a static IP address, use the following steps:
1. The default screen on the Impulse 100E is the “Status”
page. This will report the name of the unit, its current IP,
the Mode as well as the status of the input (used in
tandem with the red/green LED light on the front panel).
2. Press the button to enter the page where settings
can be viewed and configured.
IMPULSE 100E
192.168.1.100
Mode Live ON
HDMI No Signal
OK
Live
Playback
Record
Setting

Impulse 100E–User Manual
Page 13
(48)
3. Use the and buttons to move the cursor to
“Setting”, and then press the button to enter the
system menu.
4. Use the and buttons to move the cursor to
“Network”, then press the button to enter the
network menu.
5. Use the and buttons to move the cursor to
“NetMode”, then press the button.
6. Confirm that the unit is currently set to “DHCP: Disable”.
If it is, press the MENU button to return to the network
menu. If it is not, press the button to disable DHCP
and repeat Step1~4.
7. Use the and buttons to move the cursor to “Host
IP”, then press the button to enter the menu where
Host IP can be viewed and configured.
8. Press the button to initiate changing the IP. Use the
and buttons to change the value of the digit and
the and buttons to change the location. Press
to finish and apply, and then repeat Step1~4 to return to
the network menu.
9. Use the and buttons to move the cursor to “Host
Gateway”, then press the button to enter the menu
where Host GateWay can be viewed and configured.
10. Press the button to initiate changing the GateWay.
Use the and buttons to change the value of the
digit and the and buttons to change the location.
Press to apply, and then repeat Step1~4 to return
to the network menu.
Work Mode
System
Network
AP
Version
Recovery
NetMode
Host IP
Host GateWay
Host Mask
DHCP: Disable
DNS: Static
NetMode
Host IP
Host GateWay
Host Mask
192.168.1.100
NetMode
Host IP
Host GateWay
Host Mask
192.168.1.1

Impulse 100E–User Manual
Page 14
(48)
11. Use the and buttons to move the cursor to “Host
Mask”, then press the button to enter the menu
where Host Mask can be viewed and configured.
12. Press the button to initiate changing the Mask. Use
the and buttons to change the value of the digit
and the and buttons to change the location.
13. Use the and buttons to move the cursor to “Host
Mask”, then press the button to enter the menu
where Host Mask can be viewed and configured.
Host DNS
14. Press the button to initiate changing the DNS. Use
the and buttons to change the value of the digit
and the and buttons to change the location
8.8.8.8
15. Press to apply. The IP will now be accessible on the
network it was configured to!
2.4.2 DHCP
The Impulse 100E can be configured to use DHCP to obtain an IP address/Subnet
Mask/Gateway.
1. The native screen on the Impulse 100E is the “Status”
page. This will report the name of the unit, its current IP
as well as the status of the input (used in tandem with
the red/green LED light on the front panel).
2. Press the button to enter the page where settings
can be viewed and configured.
3. Use the and buttons to move the cursor to
“Setting”, and then press the button to enter the
system menu.
NetMode
Host IP
Host GateWay
Host Mask
255.255.255.0
IMPULSE 100E
192.168.1.100
Mode Live ON
HDMI No Signal
OK
Live
Playback
Record
Setting
Work Mode
System

Impulse 100E–User Manual
Page 15
(48)
4. Use the and buttons to move the cursor to
“Network”, then press the button to enter the
network menu.
5. Use the and buttons to move the cursor to
“NetMode”, then press the button.
6. If the DHCP setting is currently set to “Disable”, press the
OK button to enable DHCP.
Note: It may take up to a minute for the Impulse 100E to obtain an IP address.
Network
AP
Version
Recovery
NetMode
Host IP
Host GateWay
Host Mask
DHCP: Disable
DNS: Static

Impulse 100E–User Manual
Page 16
(48)
Section 3 Operating the Front
Panel
Introduction
This section includes the following topics:
3.1 Impulse 100E Front Panel Overview.........................................................................17

Impulse 100E–User Manual
Page 17
(48)
3.1 Impulse 100E Front Panel Overview
The Impulse 100E front panel allows the user to configure all settings that are present in
the web interface using the buttons indicated in Figure 3.
Figure 3: Front Panel Navigation Keys
The screen below is the idle screen of the Impulse 100E. This idle screen shown in Figure
4 displays the management IP address of the unit as well as the status of the input/output.
Figure 4: Idle LCD Screen
1. IP address of RJ45 port
2. Status of input/output
IMPULSE 100E
192.168.1.100
Live
HDMI No Signal
1
2

Impulse 100E–User Manual
Page 18
(48)
Press the button in order to view and change additional configuration or exit from
additional menus. Use the arrow keys to cycle through the options and to enter
additional menus and toggle settings. Figure 5 on the next page shows the first front panel
menu after the idle screen.
The highlighted line indicates the cursor, which can be moved with the and arrow
keys. The button will select the highlighted line and proceed to the next menu.
Pressing the will go back the previous menu, in this case returning to the idle
screen.
Figure 5: Menu Selection Screen
Live
Playback
Record
Setting

Impulse 100E–User Manual
Page 19
(48)
Section 4 Operating the Web
Interface
Introduction
This section includes the following topics:
4.1 Impulse 100E Web Interface Overview.....................................................................20
4.2 Live Mode ..................................................................................................................22
4.3 Playback Mode ..........................................................................................................30
4.4 Recording Mode ........................................................................................................31
4.5 System Settings Menu...............................................................................................32

Impulse 100E–User Manual
Page 20
(48)
4.1 Impulse 100E Web Interface Overview
4.1.1 Logging in to the Impulse 100E Web Interface
To open the Impulse 100E web interface, use one of the following supported browsers
and navigate to the unit’s IP address:
Firefox 3.5 & above
Google Chrome
The user will need to login to the web interface. The default login credentials
(username/password): admin/admin. After entering “admin”into both fields shown in
Figure 6, click the login button or press the enter key.
Figure 6: User Login Prompt
If this menu does not appear when navigating to the IP address on the front panel of the
unit, confirm the PC is configured with an IP address in the same range.
