Sennheiser HME 26 User manual

Instruction manual
HME 26

Book_523982_200811_SP7.book Seite 4 Montag, 1. Dezember 2008 10:38 10

1
Safety instructions
yPlease read these instructions carefully and
completely before using the headset.
yMake these instructions easily accessible to all users
at all times.
yAlways include these instructions when passing the
headset on to third parties.
yThe headset is capable of producing sound pressure
levels exceeding 85 dB(A). In many countries
85 dB(A) is the maximum legally permissible level for
continuous noise exposure during the working day.
Exposure to sounds of higher volume levels or for
longer durations can permanently damage your
hearing!
yNever repair or attempt to repair a defective headset
yourself. Contact your Sennheiser agent or the
Sennheiser Service Department.
yOnly replace those parts of the headset whose
replacement is described in this manual. All other
parts of the headset must be replaced by your
Sennheiser agent.
yProtect the headset from wetness. Use only a slightly
damp cloth to clean the headset. For information on
how to clean the headset, contact your Sennheiser
agent.
Book_523982_200811_SP7.book Seite 1 Montag, 1. Dezember 2008 10:38 10

2
Intended use of the headset
Intended use includes:
• having read this instruction manual especially the
chapter “Safety instructions”.
• using the headset in jet aircraft and within the
operating conditions as described in this instruction
manual.
Improper use
Improper use means using the headset other than as
described in this instruction manual, or under operating
conditions which differ from those described herein.
Book_523982_200811_SP7.book Seite 2 Montag, 1. Dezember 2008 10:38 10

3
HME 26 headset
The HME 26 headset features dynamic, closed head-
phones. The noise-compensating condenser microphone
ensures excellent speech transmission even in noisy
environments. Designed for use in aircraft cockpits.
Features
yLightweight
yExtremely comfortable to wear due to the patented
two-piece automatic headband and soft ear pads
yPeak level protection (switchable) safeguards you
from volume peaks above 110 dB
y“Flip-away” headphone allows single-sided listening
yFlexible microphone boom, can be worn on either left
or right-hand side
yNoise-compensating condenser microphone ensures
excellent speech transmission
ySingle-sided cable, easy to exchange
yVolume control integrated in the cable (HME 26-V-K
only)
yETSO approval C57a/C58a
Book_523982_200811_SP7.book Seite 3 Montag, 1. Dezember 2008 10:38 10

4
Delivery includes
y1 HME 26 headset
y1 cable clip
y1 wind and pop screen
y1 instruction manual
y1 carry bag
y1 EASA Form 1
Operation
Turning the microphone boom
The microphone boom can be rotated. This allows the
headset to be worn with the microphone boom positioned
on either the left or right-hand side of the head.
Book_523982_200811_SP7.book Seite 4 Montag, 1. Dezember 2008 10:38 10

5
Putting on the headset
When putting on the headset, the patented two-piece
headband adjusts automatically.
Positioning the microphone
Bend the flexible microphone boom so that the micro-
phone is placed at the corner of the mouth. Maintain a
distance of approx. 2 cm between microphone and mouth.
Always use the supplied wind and pop screen.
Book_523982_200811_SP7.book Seite 5 Montag, 1. Dezember 2008 10:38 10

6
Flipping away one earcup
The headset features a “flip-away” earcup for single-
sided listening.
Adjusting the volume directly on the audio system
Connect the headset to the corresponding sockets of your
audio system. Adjust the volume directly on the audio
system.
Hearing damage due to high volumes!
This headset is capable of producing high
sound pressure levels. Higher volumes or
longer durations can damage your hearing!
Set the volume to a medium level. Make sure
that you can hear critical sounds such as
warning alarms.
CAUTION!
Book_523982_200811_SP7.book Seite 6 Montag, 1. Dezember 2008 10:38 10

7
Adjusting the volume via the slide volume controls
(HME 26-V-K only)
The two slide volume controls and allow you to
adjust the volume for the left and right channel
separately.
Changing the left and right audio channel
(HME 26-V-K only)
The position “R” or “L” of the BOOM switch 
corresponds to the position of the microphone on the left
or right side of the mouth. When the microphone boom is
rotated to permit left or right side microphone
orientation, the BOOM switch allows you to correctly
assign the audio channels (L/R) to the appropriate
headphone sides. This enables the correct orientation of
the volume controls and any audio signals. To move the
BOOM switch, use a pointed tool.



Book_523982_200811_SP7.book Seite 7 Montag, 1. Dezember 2008 10:38 10

8
Adjusting the microphone sensitivity
The microphone sensitivity has been factory pre-set to
80 mV/Pa as per RTCA DO-214. You can change the
microphone sensitivity by turning a small screwdriver in
the direction of the arrow.
Switching the peak level protection on and off
The peak level protection safeguards your ears from
volume peaks above 110 dB, which can be transmitted
via the audio system or radio equipment. The peak level
protection is factory-preset to “on”. You can switch the
peak level protection off by gently sliding the switch to
the upper position using a pointed tool.
+
–
Book_523982_200811_SP7.book Seite 8 Montag, 1. Dezember 2008 10:38 10

9
Care and maintenance
Cleaning the headset
Use a soft, slightly damp cloth to clean the headset from
time to time. If the headset is very dirty, use a cloth
dampened with mild, soapy water. Do not use any
solvents or cleansing agents.
Replacing the earpads
For reasons of hygiene, the black earpads should be
replaced from time to time. Grasp the edge of the earpad
and pull sharply. Attach the new earpad to the earcup by
pressing firmly around the earpad until you hear the
12 latches lock into place. Repeat for the other earcup.
Danger of short-circuit due to the ingress of
water!
Water entering the housing of the headset
can cause a short-circuit and damage the
electronics.
CAUTION!
Book_523982_200811_SP7.book Seite 9 Montag, 1. Dezember 2008 10:38 10

10
Accessories and spare parts
By changing the cable, you can simply retrofit your
headset (see “Product variants” on page 11).
yCable -C Cat. No. 500840
yCable -K Cat. No. 500841
yCable -N Cat. No. 500843
yCable -V-K Cat. No. 500847
yMZQ 2002 cable clip Cat. No. 044740
yHZC 08 cable clip Cat. No. 525787
yHeadband padding, 1 pair Cat. No. 515629
yEarpads, leatherette, 1 pair Cat. No. 529766
yEarpads, leatherette, 100 pairs Cat. No. 529767
yEarpads, velour, 1 pair Cat. No. 532724
yHZH 26 hygiene pads, 200 pairs Cat. No. 502595
yWind and pop screen, 1 item Cat. No. 515297
yWind and pop screen, any quantity Cat. No. 514127
yCarry bag Cat. No. 077408
Book_523982_200811_SP7.book Seite 10 Montag, 1. Dezember 2008 10:38 10

11
Cable clips
Product variants
* This is the headset supplied without a cable and must be used with
one of the cables listed above (see page 10)
Variant
(Cat. No.)
(Part Number)
Description Single-sided round
cable
HME 26*
(502395)
(026-55)
Headset with
condenser
microphone
–
HME 26-K
(502396)
(026-55-999-0131)
Headset with
condenser
microphone
with ¼“ (6.3 mm) jack
plug (headphones)
and PJ-068 equivalent
(microphone),
length 1.85 m
HZC 08 MZQ 2002
(for round or flat cable)(for round cable only)
Book_523982_200811_SP7.book Seite 11 Montag, 1. Dezember 2008 10:38 10

12
Connector assignment
HME 26-K
Cable -C
Cable -N
¼" (6.3 mm) jack plug PJ-068 equivalent
1
2
3
Audio Hi
not assigned
Audio Lo
1
2
3
not assigned
Microphone Hi
Microphone Lo
12 3 12 3
Solder side
1
2
3
Audio Hi
Audio Lo
Microphone Hi
4
5
1
234
5Microphone Lo
not assigned
Solder side
1 Audio Hi
2 Audio Lo
3 not assigned
4 Microphone Lo
5 Microphone Hi
6 not assigned
7 not assigned
8 not assigned
Book_523982_200811_SP7.book Seite 12 Montag, 1. Dezember 2008 10:38 10

13
Cable -V-K
¼" (6.3 mm) jack plug PJ-068 equivalent
1
2
3
Audio Hi left
Audio Hi right
Audio Lo
1
2
3
not assigned
Microphone Hi
Microphone Lo
12 3 12 3
Book_523982_200811_SP7.book Seite 13 Montag, 1. Dezember 2008 10:38 10

14
Specifications HME 26 headsets
Headphones
Transducer principle dynamic, closed
Ear coupling supra-aural
Frequency response 20–14,000 Hz
Impedance mono/stereo 600 Ω/1,200 Ω
Characteristic SPL 92 dB SPL at 1 kHz, 1 mW, mono
97 dB SPL at 1 kHz, 1 V
Max. SPL 120 dB SPL at 1 kHz
(peak level protection = ON)
> 125 dB SPL at 1 kHz
(peak level protection = OFF)
THD < 1 % at 110 dB SPL
(350–3,000 Hz)
Contact pressure approx. 3.6 N
Microphone
Type MKE 46
Transducer principle pre-polarized condenser
microphone,
noise-compensating
Frequency response 100–6,000 Hz
Output voltage adjustable from 17–100 mV/Pa,
80 mV/Pa -2 dB
(factory pre-set)
800 mV -2 dB at 114 dB SPL
Terminating impedance 150–2,200 Ω
Supply voltage 8–16 V DC
Book_523982_200811_SP7.book Seite 14 Montag, 1. Dezember 2008 10:38 10

15
General data
Temperature range operation: –15 °C to 55 °C
storage: –55 °C to 70 °C
Weight without cable approx. 200 g
Book_523982_200811_SP7.book Seite 15 Montag, 1. Dezember 2008 10:38 10

16
Manufacturer Declarations
Warranty
Sennheiser electronic GmbH & Co. KG gives a warranty of 5 years on this
product.
For the current warranty conditions, please visit our web site at
www.sennheiser.com or contact your Sennheiser partner.
CE Declaration of Conformity
This equipment is in compliance with the essential require-
ments and other relevant provisions of Directive 89/336/EU.
The declaration is available at www.sennheiser.com.
Before putting the device into operation, please observe the respective
country-specific regulations!
