The e912 is a pre-polarized condenser boundary microphone with half-cardioid pick-up
pattern. Its acoustic properties have been optimized for instruments, vocals and
speech. The e912 is an ideal choice for pianos, theater and opera productions, conference
applications, altars and lecterns. To optimally match the installation environment, the e912
is available in black or cream-white.
Features
쑺Frequency response and sensitivity optimized
for picking up instruments, vocals and speech
쑺Unobtrusive, flat housing
쑺Extremely rugged and step-resistant
쑺Shock-absorbing rubber base
쑺Mounting slots for table installation
쑺Gold-plated XLR connector
쑺Integrated pre-amp
Delivery includes
쑺e912 Microphone
쑺Pouch
쑺User manual
Specifications e912
Pick-up pattern . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . half-cardioid
Frequency response . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 – 20,000 Hz
Sensitivity (free field, no load) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10 mV/Pa (–40 dB)
Equivalent noise level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15 µV, CCIR-weighted
4.5 µV, A-weighted
Inherent self-noise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37 dB (CCIR), 26 dB(A)
Max. output voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1.2 V at < 1% THD
max SPL at 10 mV/Pa . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135.6 dB
Phantom powering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48 V / 1.1 mA
Nominal impedance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . < 100 ⍀
Min. terminating impedance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1,000 ⍀
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126.5 x 105 x 26.5 mm
Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . approx. 350 g
Product Variants
쑺
e912 WH cream-white
쑺
e912 BK black
513585 12/05 Printed in Germany Sennheiser is a trademark of Sennheiser electronic GmbH & Co.KG. www.sennheiser.com
