SEON TH8 User manual

TH8 & NH16K 48 V POE Injector Quick Installation Guide
About
This guide covers installation procedures for connecting a POE (Power Over Ethernet) injector kit to a TH8 or
NH16K recorder.
A POE injector kit enables connection of an IP camera to the recorder’s rear expansion port. A maximum of 2
cameras can be connected in this manner. Connecting a second IP camera requires a second POE injector kit.
Pre-requisites
Before proceeding with these procedures, you must have a TH8 or NH16K recorder with FW 2.0 or higher
installed and functioning in a vehicle. Do not proceed with this document if you haven’t installed the recorder.
The TH8 and NH16K installation documentation is available on the Safe Fleet Community (https://community.
safefleet.net).
Note: You will need login credentials to access the documentation. Please contact tech support if you do not
have access to the Community.
Kit Contents (1 kit required per camera added)
Support
• Phone: [phone]
• Email: PTsuppor[email protected]
Warranty
For full warranty information, visit:
• www.seon.com/documents/Seon-Warranty.pdf
2002/96/EC (WEEE directive): This product cannot be disposed of as unsorted municipal waste
in the European Union. For proper recycling, return the product to your local supplier upon the
purchase of equivalent new equipment, or dispose of it at designated collection points, for more
information, see www.recyclethis.info.
2006/66/EC (battery directive): This product does not contain batteries.
© Safe Fleet | 2021 | All rights reserved | Part #: 700-1228 R2
48 V POE Injector Kit (Part #: TH8POEKIT48):
• POE Injector (Part #: 085-1106) - Qty 1
• Y-Power Harness (Part #: 060-1163) - Qty 1
• Microt Ctrl Cable (Part #: 060-0656) - Qty 1
• 1.5 ft CAT5e Cable (Part #: 085-0065) - Qty 1
• 1” Stainless Steel Philips Rounded Head Drilling
Screw (Part #: 600-1022) - Qty 1
Specications
48 V POE Injector
Input 12VDC/1.5A to 16VDC/1.1A.
Output 48 VDC, up to 15.4 W max. IEEE 802.3af compliant. Short circuit protection.
Ethernet Connectivity: RJ45, auto-crossover. Wire type: 4-pair CAT5e.
Distance: up to 100 m. Speed: 10/100BaseT, half/full duplex, auto negotiation.
Indicators (LED) Red LED: Port status.
Yellow & Green LED (by RJ45 jack): IP Link status, 10/100Base-T/active.
Agency Listings UL/cUL: UL60950-1 (Information Technology Equipment).
CE European Conformity.
Dimensions (W x L x H) 2.5” x 3.8” x 1” (63.5 mm x 96.52 mm x 25.4 mm).
Weight (approx.) Product Weight: 0.2 lbs. (0.1 kg). Shipping Weight: 0.25 lbs. (0.11 kg).
Temperature Operating: 0º C to 40º C (32º F to 104º F).
Storage: -40º C to 70º C (-40º to 158º F).
Relative Humidity 85% +/-5%.
Operating Altitude: -304.8 to 3,048 m (-1000 to 10,000 ft.).

Conguring the Recorder to work with C3 Series Cameras
After connecting C3 series cameras, you’ll need to congure the recorder in order for the cameras to work:
1. Congure port(s): the procedure differs depending on the recorder’s rmware version:
For rmware v3.1 or newer:
• Navigate to the Network Settings, choose Port Functions, and select IP Camera for the ports
connected to a 48 V PoE injector.
For rmware older than v3.1:
• Navigate to the Recording Settings, choose HD Cam Expansion 1 or HD Cam Expansion 2 and
select IP Camera.
2. Click Camera, select the IPC1 or IPC2 tab depending on the port used, and choose the appropriate camera
model from the Type dropdown menu.
3. Select C3W9PD or C3Q9PD from the dropdown menu.
MODEM
POE WIFI
G-SENSOR
C
TRL
ALARM 2
GPS
SIGNALS
EX
P
ANSION
P
O
WER
CAM 1
1
2
CAM 2
CAM 3
CAM 4
CAM 5
CAM 6
CAM 7
CAM 8
1
2
3
4
5
6
Y-Power
Harness
Microt
Control
Cable
POE
Inserter
48 V POE Kit Installation Diagram
7
 WARNING: Always use compatible cameras
Adding an incompatible camera to a 48 V POE Injector can
damage the camera and void your warranty. Always ensure
that you’re connecting a compatible camera!
Black
Black
Red Red
Installing the 48 V POE Kit
(Refer to the diagram on page 3)
1. Connect the Y-Power Harness to the recorder’s ACC PWR output
2. Connect the other end of the Y-Power Harness to one end of the Microt Control Cable (MCC)
3. Cut off the other end of the MCC and strip the red and black wires
4. Connect the MCC red wire to the POE Injector’s VDC Input (+), and the black wire to the VDC Input (–)
5. Connect an Ethernet cable from the recorder’s HD CAM EXPANSION port to the POE Injector’s IN port
6. Connect an Ethernet cable from the POE Injector’s OUT port to the camera. For the 48 V POE kit, you can
only connect the following camera models:
• C3 series
• C8 series
• C12 series
7. Secure the casing of the PoE Injector to the vehicle using the provided screw.
8. If installing a second POE Injector, repeat steps 3-7 (you can discard the spare Y-Power Harness).
 WARNING: Ensure Recorder is Powered Down
Do not proceed unless the recorder is shut down.
Conguring the Recorder to work with C8 and C12 Series Cameras
1. Perform Step 1 in “Conguring the Recorder to work with C3 Cameras”, immediately above.
2. In the RTSP Connection Information card (part #700-1237) included with your camera:
• Jump to Step 3, “Congure Recorder Camera Settings”, and perform Step 3 and Step 4.
