serene living S6064 Installation instructions manual

S6064 Shadow Heat & Beat
Infrared Bluetooth App
Outdoor Heaters
Instructions &
Operation Manual
S6064 Shadow Heat & Beat

Safety Information:
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
When using any electrical appliance, safety precautions should always
be observed. Read these instructions carefully, and retain for future
reference.
When used by, or near, young children or infirm persons, supervision is necessary -
young children should be supervised to ensure that they do not play with the appliance.
Use this appliance only with the voltage specified on rating label.
Do NOT use this appliance other than for its intended use.
Do NOT touch hot surfaces or moving parts.
Do NOT cover the grilles or place any object or material up against
the unit, as this may block entry or exhaust of air.
Do NOT probe any opening.
To ensure trouble free performance it is recommended that on a regular basis the unit be
isolated from the power supply and a vacuum cleaner used to remove dust from the inlet
and outlet grilles.
Caution:
When the heater is operated ensure the heater is not obstructed in
any way. Ensure the heater can operate safely, should the heater switch on when the
ambient temperature drops, or a timer activates the heater.
Do NOT allow the supply cord to come into contact with heated
surfaces during operation.
Regulations require that electrical work be carried out by authorised
persons. For your own safety and that of others, ensure this is done.
If the supply cord becomes damaged, it must be replaced by a
qualified person, in order to avoid a hazard

•
•6•7•7
For additional protection the installation of a residual current device
(RCD) is recommended. ( Refer to local electrical regulations)
Remove all packaging material (including anti-vibration pads on the lamp) and check the
appliance, supply cord and the plug for signs of damage.
Pay attention to the mounting place and all mounting material. Ensure they are suitable
and stable enough for mounting and holding the appliance on your chosen surface.
Before mounting, the minimum safe mounting distances and tilt angles shown in the
figures must be strictly followed.
1.The distance between the bottom edge of the appliance and the floor must be at least 1.8 M.
2. There should be a distance of at least 0.2 M between the appliance and ceilings, roofs or other covers.
3. There should be a distance of at least 0.5 M at each side between the appliance and walls etc..
4 .Recommended degree to mounting surface is 45°. See figure 2.
5. The max. swing degree is 90°
Fix the mounting bracket on the wall first. Ensuring that the area of installation is
secure and firm.
Adjust the desired angle of radiation and tighten all screws. Check regularly as the
screws’ may loosen due to vibrations caused by wind or building movement.
Plug or hard wire into your power source.
Check to ensure that the heater is working.
Figure 1: Mountingbracket (wall bracket)andrawplugs Figure 2: Minimumdistances to floor, ceilingand wall.
provided. Connection from the wall to the infrared heater.
45mm 45mm
45mm
0.2m
0.5m
1.8mm
Installation

•
Installation cont.
Specifications:
Specification S6064 Heat & Beat
Voltage (V) 220-240
Power consumption (W) 2000W
Dimensions W H D mm 740 x 130 x 175
Weight (kg) 3.9
Infrared receiving Angle 60°±5°
Control distance (m) 6
Figure 3: Mounting bracket (wall bracket) and raw plugs
provided. Connection from the wall to the infrared heater.
•45
°
Speaker 2x3 watts weather resistant

•7
•
Bluetooth App Operation
The free Serene Bluetooth App for this heater is available to download for either
your iPhone, iPad or Android device. See back page for QR codes
The Serene ‘Shadow’ App will allow you to connect remotely to many S6066
heaters and control them independently. Control functions include:
•On/Off
•Variable heat output from 0 to 100%
•Timer with auto shut off
•Password connection to heaters
•Individual heater identification and control
To download, search for ‘Serene Living ’ in your App store and add to your device.
1. First Time Setup - Once the App is downloaded to your device follow the onscreen quick start
guide for basic operation of the heater. See below for detailed app operation guide.
•Open the Serene living App
•When setting up the heater for the first time a pairing request will pop up tap Pair
•Now a password window will pop up
•Enter an 8 character minimum password & tap ok

•7
•
Bluetooth App Operation Cont.
2. Pairing the Heater :
•Ensure the Bluetooth function on your device is switched on & Open the Serene Living App
•Select the first tab and swipe down on the screen
•“Serene Heat” will then appear, swipe right to pair
•Heater is paired when switch turns green
3. Adjusting the Heat :
•Select the second tab to open heat control
•Use the slider to control the heat level from 0% - 100%
•Click the power button to turn the heater on/off
4. Setting the sleep Timer :
•Select the third tab to open timer control
•Swipe the switch right to turn timer on
•In the pop-up window select the desired time
•Tap OK to confirm the desired sleep time

•7
•
Bluetooth App Operation Cont.
5. Connecting to Serene Beat Speakers for the First Time : Once the heater is connected to your
device via Bluetooth follow the below steps to connect the speakers
•On the Second Tab, click the music note
•The pairing screen will now appear click the Button to enter paring mode ( Button will turn
orange when in paring mode)
•Ensure the volume is set to high
•Now open your devices Bluetooth settings menu and a paring request will pop-up
•Click Pair and your now able to play Music via the Serene Beat Speakers
6. Connecting to Serene Beat Speakers next time :
•Once the devices are paired , simply open your devices Bluetooth menu and select “Serene
Beat” to play music next time.

•7
•
Bluetooth App Operation Cont.
7. Changing the Mood Lighting :
•Select the 4th Tab to access mood lighting
•Tap the colour palate that appears next to Serene Heat
•Select SMOOTH or BEAT buttons for Auto light changing modes
•Tap the light switch to turn the mood lights off
•Use the magnifying symbols to adjust brightness
•Use the colour wheel to select a custom colour
•Select a Colour and tap save to set it as a pre-set
•Tap pre-set to select from up to 8 pre-set colours
8. Changing Settings :
•Select the 5th tab to change settings
•Tap Password and select “Serene Heat” to change
•Must be 8 Characters long
•Tap Rename to change the heater name
•To turn front LED off tap indicator LED

Button Graphic Feature
Increase
Heat
Press
to increase the heat level
Decrease
Heat
Press
to decrease the heat
level
LED
Lights On
Turns
LED backlights on
LED
Lights
OFF
Turns
LED backlights off
BT Music
Press
to turn speakers on/off
Hold to establish BT
connection.
ON
To
switch the heater on:
Press ON. The patio heater has
a soft start function of 33%
power. 4 seconds after the
heater has been turned on, it
will automatically switch to the
last heating level used. In case
of the first
-time use, after
4seconds the heater will
automatically switch to 100%
power.
OFF
To
switch the heater off:
Press OFF. The heater will
switch to standby mode(the
receiver indicator will light up).
Heat & Beat Remote Control Operation
Heater Controls –left end of Unit
•To rest hold rest button down for 10 seconds until indicator LED flashes
•Use the power switch to turn the unit on/off

Remote Control
NOTE
Use 2 AAA.5V batteries in the remote control. Remove batteries when not use for long periods.
The remote control function may not work if there is a barrier between the remote control and
heater.
Cleaning And Maintenance
1. This appliance is manufactured from a robust and maintenance-free
aluminum.
2. Before cleaning, remove the plug from the power outlet and wait
until the appliance is sufficiently cooled off.
3. Wipe the appliance only with clean and lint-free cloth or a soft
brush.
4. Never use abrasive cleaners, scrubbing brushes and chemical
cleaners for cleaning!
5. You may use alcohol to clean the appliance.
6. To protect against electrical shock, do not immerse cord, plug, or
any part of the appliance in water or other liquid.
6 m max
Remote receiving angle
Remote Control
•60
°
Heater
