serene living S207T Operating instructions

Serene S2078
Serene Wall Mounted Fan Heater
Specification & Operating
Instructions
Model S207T
Serene Wall Mounted Fan Heater with
(optional*) Electronic Timer. Model S207T
* AU and NZ only

Introduction
Designed for easy installation, your Serene S207T Wall & Bathroom Fan Heater complies to
the highest electrical safety standards, includes an ‘easy-fix’ wall-mounting bracket for
faster and easier installation and is fitted with a power saving resettable timer.
Safety Information
•When using any electrical appliance, safety precautions should always be observed.
Read these instructions carefully, and retain for future reference. For service, contact
your nearest authorised service agent.
•Under no circumstances should an unauthorized person open the heater to adjust
the thermostat.
•This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
•Children should be supervised to ensure that they do not play with the appliance. Do
NOT use this appliance other than for its intended use.
•Use this appliance only with the voltage specified on the rating label.
•Be very careful not to touch hot surfaces or moving parts.
•Do NOT cover the grilles or place any object or material up against the unit as this
may block the entry or exhaust of airflow.
•Do NOT probe any opening to remove fluff. To ensure trouble-free performance, it is
recommended that the unit be isolated from the power supply and a vacuum cleaner
used to remove dust and fluff from the inlet and outlet grilles on a regular basis.
•Installation must be performed by a licensed electrician. Regulations require that
electrical work be carried out only by properly qualified person. For your own safety
and that of others, ensure this is done.
•Do NOT allow the supply cord to come into contact with heated surfaces during
operation.

Installation
Installation must be performed by a licensed electrician
This appliance MUST be installed in accordance with relevant wiring rules and
regulations which cover installation of appliances and accessories in damp
situations, such as bathrooms, showers, laundries and other areas, fixed water
containers according to local safety regulations.
Distances
The heater must be mounted a minimum distance
of:
•1800mm from floor level
•200mmm below the ceiling
•250mm from adjacent wall
•500mm between the heater and any objects
immediately below it.
Important
The heater must NOT be located immediately below a socket outlet.
The heater is to be installed so that switches and other controls cannot be touched by a
person in the bath or shower.

Safety Cut-out
Your Serene S207T Wall & Bathroom Fan Heater is fitted with an thermal cut-out and a
fusible link.
Either of these devices will automatically switch off the element, should the unit reach an
abnormal temperature.
This is very unlikely to happen with the introduction of our ‘Airslip’ technology that
largely prevents dust and bathroom lint build- up in the heater other than in very
abnormal conditions.
However, should this occur:
Switch Off / Disconnect the heaters power supply at source .
Check for blockage of the air inlet and outlet.
If the heater still fails to operate, contact the installer or place of purchase.
Operation
Timer function:
The model S207T is fitted with a (optional) clever 30 minute resettable timer that turns
OFF the heater automatically if it is accidentally left running and using costly power.
To instantly restart at any time just pull the operation cord or turn the heater on at the
wall switch.
*NOTE - AU and NZ only: The timer can be overridden at the time of installation so that
the timer no longer operates.
Air is drawn through the inlet grill in the top cover of the heater by the fan, blown over
heating elements, and then blown out through the front grille into the room.
The heater can be controlled by a directly installed wall switch or the pull-cord switch.
The heat output is regulated by an automatic, pre-set step-down thermostat which will
reduce the output from 2000 Watts to 1000-1200 Watts when a comfortable room
temperature (of between approximately 28 to 34 degrees C is reached
The blue LED indicator lights when the heater is operating.
Care
The heater requires regular cleaning (every 6 months) to ensure trouble free operation.
Isolate the heater from the mains power supply.
Use a damp cloth to clean the exterior of the heater. Do not use any abrasive cleaners.
The S207T is fitted with our “Airslip” metal fan blade that alleviates any dust build up
inside the heater.
Use a vacuum cleaner to remove dust and fluff visible on the heater inlet and outlet
grilles. First making sure that the heater is turned OFF.
Ensure the heater is dry before turning heater back on.
PCB
Jumper cap
TO DELETE THE TIMER FUNCTION
SIMPLY PULL OUT THE JUMPER
CAP FROM THE PCB BOARD PRIOR
TO INSTALLATION.

Specifications: Serene S2078
Electrical Supply 220-240 voltsA.C. 50 Hz
Wattage 2000W, thermostatically controled
Wiring Hard wired or pull cord operation
Ingress Protection Rating IP20
Serene Industries Limited reserves the right to alter specifications without notice.
Contact:
HONG KONG
Head Office - Serene Industries Limited
t: [phone]
f: [phone]
e: [e-mail]
w: www.serene-ind.com
Suite 1010,10F, Block A, Alexander Industrial Building, 62 King Lam Street,
Cheung Sha Wan, Kowloon Hong Kong SAR
NEW ZEALAND
t: + 64 (3) 344 5550
f: 0800 437 264- Freefax
e: [e-mail]
w: www.serene-ind.com
PO BOX 33501, Barrington, Christchurch 8024
AUSTRALIA
t: 1800 844 942
e: [email protected]
w: www.serene-ind.com
UNITED KINGDOM and EUROPE
t: [phone]
e: [e-mail]
w: www.serene-ind.com
Unit 2, Royd's Mill Trading Estate, Dyehouse Lane, Brighouse,
West Yorkshire, HD6 1LL
Dimensions
Height 220mm
Width 375mm
Depth 140mm (includes mounting base)
Weight 2.45kg
