INSTRUCTION MANUAL
& REFERENCE GUIDE
1/8 scale Ready To Race electro GT

Page
2
powered by

Page
3
Introduction
Thank you very much for buying this Serpent rc car. You are now member of a large following of Serpent fans
worldwide. This Serpent car will bring you many hours and weekends of racing excitement.
Serpent started as rc racing company in 1980, and has developed many modelcars since. This wealth of
experience and know how is used in our todays cars and that shows!
The Serpent Cobra GT RTR is the best entry in the world of rc racing. Affordable and a very good basis to
start your racing carreer. The Serpent Cobra GT RTR, is based on the high-end competition version of the
Cobra GT and shares geometry and many parts. Still its easy to use, assemble, and set up. The RTR Cobra
is fully upgradable to high end competition spec. The details can be found in our website.You are now part of
the worldwide network of Serpent drivers, which gives you superior technical support and access to many
benets that only Serpent drivers can enjoy.
The Serpent Cobra GT RTR offers state of the art specications and leads the way in 1/8 scale chassis
design, using all the knowledge our designers have gathered from racing GT cars for over 15 years, into this
design too. Continuously pushing the performance envelope.
Designed, tested and raced by Billy Easton, USA. World Champion.
This manual contains a number of steps you need to follow to operate the Serpent cars in the right way. This
manual also contains a quick-start section, a partslist and exploded views, and a FAQ section. A full assembly
manual can be found online in the Serpent.com website. So read this manual with great attention before
racing this car. For your own safety as well as for others, and to ensure you can enjoy your Serpent car a long
time, even if you are an experienced user. Serpent is not only about the car itself. Serpent as company, and
the worldwide network or distributors and dealers are here to help you out.
The Serpent website, social media and forum are available for assistance and additional information as well.
Enjoy your Serpent, the racing experience!
Contents
Introduction
Read this rst 4
Safety matters 4
Quickstart 3
Required equipment 5
Model specs / overview 6
Basic Tuning 7
Default Set Up 8
Maintenance 9
Partslist 10
Exploded views 14

Page
4
Safety matters
Read this rst
All instructions in this manual must be followed to ensure safe use of the car.
This model is not intended for use by children under 14 years .
Quick-start
●This is a highly technical hobby product, intended to be
used in a safe racing environment. This car is capable
of speeds in excess of 80 km/h or 50mph.
●Please follow these guidelines when building and
operating this model.
●Parental guidance is required when the builder/user
●of this car is under 16.
●Follow the building instructions. If in doubt, contact
your dealer or importer.
●Be sure to use the proper tools when assembling the
car. Always exercise caution when using electric tools,
knives and other sharp objects.
●Be careful when using liquids like lubrication oil or
glue.
●Do not swallow.
●Follow the manufacturer’s instruction in case you
●experience irritation after using the product.
●Be careful when operating the car. Stay away from any
rotating parts such as wheels, gears and transmission.
●Stay away from speedo during and immediately after
use, as these parts may be very hot. We advise to use
protective handgloves.
●Only operate this car in a safe environment, like a
special racing track or a closed parking lot.
●Avoid using this car on public roads, crowded places
or near infants.
●Before operating this car, always check the mechanical
status of the car. Check that the batteries of the
transmitter and receiver are fully charged. After use,
always check all the mechanics of the car. We advise
to clean the car immediately after use, and inspect the
parts for wear or fractures. Replace when necessary.
Do not use water, methanol, thinner or other solvents
to clean the car.
●Store the car in a dry and heated place to avoid
corrosion of metal parts.
●Avoid using this car in wet conditions as the water will
cause corrosion on the metal parts and bearings and
these parts will cease to function properly. If driven
in the wet, ensure that all the electric equipment is
waterproofed and after use, that all moving parts are
dried immediately.
Important pre-cautions
●Only run the car is designated areas or areas with very
few people, so no-one can get hurt.
●The car has a lot of power and the turning parts on the
car can cause damage, also some parts of the car like
transmisison and motorparts can become very hot. So
wear protective clothing both as driver and helper and
be carefull when picking up the car.
●Do not operate the car under dark conditions, as both
you and others may not see the car properly and can
get hurt, due to lack of car control.
●Use good common sense while operating the car so
you can fully enjoy your car.
Battery and battery-charging
●The battery and battery-charger are not included with
this model. We advice to use good quality NimH or
Lipo rechargebale battery-packs with 4000 mA or
more. Check carefully to buy batteries with the correct
connector for the speedcontroller, or also purchase
and mount other tting ones.
●Use proper battery-charger specically designed for
that type batteries and follow the instructions of the
battery supplier and the charger correctly.
●Keep the battery and charger always in dry places
only and never leave un-attended during charging.
●When the batteries are at their end of life, dispose
them at a recycling-place, check www.call2recycle.org
for more info.
The quick-start section is not a replacement for the full
instructions. To be able to use the model to its best take
the time to read the full manual.
1. Read the manual and safety pre-cautions ( page 3)
2. Buy and install the batteries in the transmitter ( see
Transmitter manual)
3. Install battery packs in the model, make sure the
speedo is switched off, connect the cables (avoid
reversed polarity) and securely fasten the battery-
pack.
4. Turn on the transmitter (see Transmitter manual).
Always turn on the transmitter rst before to switch
on the car and only turn off the transmitter after you
switched off the car.
5. Check servo operation. Check that the servo works
correctly and check that the car runs straight in neutral
position, trim as neededPerform a range test with the
radio system
6. Personalise the body of your car by applying more
decals if required.
7. Drive your modelcar.
8. Maintain your modelcar (page 9)

Page
5
Equipment
Included with your model
●Serpent modelcar, factory assembled and set-up
●Dragon-RC DTS-1 transmitter (as shown or similar)
●Dragon-RC DESC speedcontroller
●Dragon-RC brushless motor
●Dragon-RC racing tyres, pre-mounts
●Dragon-Rc digital servo MG
●Dragon-RC prepainted and pre-cut bodyshell
Required for your model
●Multi Charger; to charge transmitter battery and
car battery
●Battery pack 2-S Lipo x 2
●Battery AA x 4 to operate the transmitter
●Tools: selection of allen tools and screw- drivers
●Hobby knife
●Camber gauge
Recommended materials
●Side cutter and nose plier
●Cleaning brush and towel
●Safety glasses and gloves
●Cleaning gum
●Thin bearing oil
●Transmission grease
●CA glue
●Degreaser

Page
6
Model specs/overview
Shockabsorbers
Shocktower front
Front axle
Front bodymount
Front camber link
Front
wishbone
Steering servo
Steering system
Steering link
Chassis
Center diff
Battery cover
Spur gear
Rear camber link
Differental
Central rear driveshaft
Speedcontroller
Brushless motor
Rear anti-roll bar
Rear bodymount
Rear wishbone
Shocktower rear
Shocks rear
Race-tyres
Steeringblock
Receiver

Page
7
Springs
Shock angle
Front anti-roll bar
Rear anti-roll bar
Ackerman
Front camber
Rear camber
Ride Height
Rear Toe-inFront Toe-out Gear-ratio
●Springs: by using a softer spring you will have more sag, more chassis roll/lean,
more dive and a less responsive car this might be better on low-grip surfaces; by
using a harder spring you have less sag, less body lean, less dive and a more
responsive car. What to apply depends on driving style and grip-level surface. This
is more suitable on high-grip surfaces.
●Shock-angle: the angle at which the shocks are mounted create a different
suspension feel; the more vertical, the harder it feels, the more horizontal, the softer
it feels.
●Oil: the viscosity of the shock-oil denes the dampening of the shockabsorber.
Thinner oil will be softer, with slower response, thicker oil will be harder dampening
with faster reponse. The dampening can also be ne-tuned by tting other pistons
with more or less holes, which is an optional.
●Differential: you can make the gear differential harder or softer by using a different
oil viscosity. Lighter oil will create a looser diff which increases rear traction on
acceleration, but also more understeer , and a harder differential will decreases rear
traction on acceleration, but also more on-throttle steering
●Front anti-roll bar: by using a softer anti-roll bar you will have more sag, more
chassis roll/lean, more dive and a less responsive car. But you will have more
steering once you have entered the corner
●Rear anti-roll bar: by using a softer anti-roll bar you will have more sag, more
chassis roll/lean, more dive and a less responsive car. But you will have more rear
traction and a more stable car
●Toe adjustment: Front: adjusted with the track-rods, make longer or shorter. More
toe-in will create more steering, but less stability; toe-out will create a more stabile
car, with less steering.
●Toe adjustment: Rear: adjusted with suspension blocks (optional).
More toe-in will create more traction, more stability, but less speed.
Less toe in will create a less stabile car, with less traction but higher speed.
●Front camber: using more negative camber in the front will give you more steering
but also increases possible traction roll.
●Rear camber: using more negative camber in the rear will create more grip in the
rear meaning also creating more understeer.
●Front caster: use optional caster blocks to change caster, more caster will create
more steering but also increases possible traction roll. And less caster will create
less steering but also decreases possible traction roll.
●Wheel-base length: a longer car will be more stabile and react slower, a shorter
car will be more nervous and more direct.
●Gear-ratio: spur and pinion: for correct gearmesh keep a pieces of notebook paper
at hand, to put between the spur and pinion for correct mesh.
●Ride-height: you can change the ride-height of the car, by applying more or less
pre-load on the springs, turn the pre-load adjusters to set the desired height and
keep left and right the same.
Basic tunning

Page
8

Page
9
Maintenance
Shockabsorbers
- Check for smooth operation of the shockabsorbers, and check
for airbubbles by pushing the shock up and down fast after
removal of the spring. Clean the shockabsorbers as needed
and rell with fresh 100% pure silicone oil as needed.
Tyres
- Replace tyres if case worn or damaged, and clean the surface
in case dirty to obtain better grip.
Wheel-axles and driveshafts
- Remove the wheels, and check the wheel-axles, driveshafts
and adaptors for dirt, play and pins. Clean thoroughly as
needed and lubricate the touching parts with a small amount
of grease or oil.
Differentials
- Check the differentials and gears for wear and dirt and clean
as needed. Check the functionning of the diff by turning the
wheels in opposite direction and feel if still smooth or ‘gritty’.
In case of gritty feel, the silicone oil may need replacement.
The full assembly manual of this model is available online;
check on www.serpent.com and type your modelnumber,
partnumber, or select your car from the car-page; go to the
download section in the menu and download the full manual.
Shockabsorbers
Tyres
Wheel-axles and driveshafts
Differentials

Page
10
Partslist and Optionals list
Description
600045 Cobra GT-e RTR EP 1/8
Manual & Decals
600329 Decal sheet S811 black/white (2)
600332 Decal sheet S811 chrome (2)
Ball Bearings
1311 Ballbearing 5x8x2 (2)
1312 Ballbearing 5x8 anged SS (2)
1315 Ballbearing 5x10x4 SS (2)
1321 Ballbearing 6x10x3 SS (2)
1337 Ballbearing 15x21x4 SS (2)
1393 Ballbearing 13X19X4 SS (2)
1394 Ballbearing 8x14x4 anged SS (2)
1395 Ballbearing 8x19x6 SS (2)
1396 Ballbearing 8x16x5 SS (2)
600466 Bearingset 811-E (26)
600617 Bearingset 811 V2 small (12)
Radio Installation / Battery
1606 Antenna rod black (2)
600131 Balljoint set (19)
600436 Battery radiobox 811-E
600437 Steering balljoint + lever 811-E
600479 Battery foam pad (2)
600499 Pivotball double straight (3)
600500 Servo spacers (8)
Radio Installation / Battery option
600463 Servo lever 23T 811-E alu
600464 Servo lever 24T 811-E alu
600465 Servo lever 25T 811-E alu
Servo Saver & Steering
600105 Servosaver spring
600109 O-ring servosaver nut (4)
600128 Servo saver set nylon (3)
600131 Balljoint set (19)
600167 Steeringrack mount
600169 Servosaver adjust nut
600170 Servosaver shaft outer
600207 Rod steering servo 26mm
600554 Pivot ball steering short 811-S (2)
600555 Pivot ball steering long 811-S (4)
600556 Servo saver post 811-S (2)
600557 Steeringrack alu 811-S
600558 Topdeck front 811-S
Servo Saver & Steering option
600153 Topdeck front carbon
600171 Steeringrack option 1
600172 Steeringrack option 2
600173 Steeringrack option 3
600272 Steering servo rod titanium
600278 Servo saver post alu (2)
600296 Servosaver alu coated (3)
600330 Servo saver spring hard
Shock Absorbers
600111 Shock membrane (10)
600112 O-ring sho ck bottom (10)
600113 O-ring shock nut (10)
600118 Shock part frame nylon (10)
600145 Shock pistons (4x4)
600158 Adjust nut shock / oring (2)
600180 Washer shock shaft (4)
600184 Pivotball 6.75 double (4)
600234 Shock cartridge stepped (4)
600235 Shock cartridge (4)
600319 Shock revision set (20)
600568 Shock mount 811-S (2)
600573 Shock top 811-S (2)
600574 Shock top nut 811-S (2)
600592 Shock shaft 811GT (2)
600689 Shock body alu 811GT RTR (2)
Shock Absorbers option
600287 Shock spring support alu (4)
600357 Membrane webbed silicone (4)
600595 Shockset fr/rr 811GT (2)
600597 Spring Fr/Rr Red 811GT 18lbs (2)
600598 Spring Fr/Rr Purple 811GT 21lbs (2)
600599 Spring Fr/Rr Yellow 811GT 29lbs (2)
600600 Spring Fr/Rr White 811GT 31.5lbs (2)
600601 Spring Fr/Rr Silver 811GT 34.5lbs (2)
600602 Spring Fr/Rr Black 811GT 37lbs (2)
Chassis / Bodymount
600442 Chassis brace FR + RR 811-E
600581 Body post front 811GT (3)
600582 Bumper 811GT
600583 Bodymount rear 811GT
600624 Chassis 811 E-S
600614 Foam bumper 811GT
Chassis / Bodymount Optional
600300 Post wingmount alu (2)
600461 Chassis brace front alu 811-E
600462 Chassis brace rear alu 811-E
600470 Chassis S811E hard anodized
Front Section
600126 Washer/nut nylon M3 (12+15)
600129 Diff case front set
600131 Balljoint set (19)
600135 Wishbone front L+R
600268 C-Hub 12 L+R
600167 Steeringrack mount
600183 Bushing suspensionarm (4)
600193 Pivotball threaded antirollbar (2)
600197 Driveshaft insert (2)
600222 Wheelnut 17mm (4)
600223 Wheelhexagon (4)
600365 Spacers 1.25mm + 2.5mm wheelbase (4+2)
600481 Steeringblock L+R V2
600503 Steeringblock-wheelaxle set 811 V2
600532 Gear coupler 811-S
600535 Driveshaft FR 811-S (2)
600537 Wheelaxle FR 811-S (2)
600539 Pin steeringblock 811-S (4)
600186 Track rod M4x51 (2)
600187 Track rod M5x46 (2)
600543 Hinge pin 811-S (2)
600544 Antirollbar nut 811-S (4)
600545 Antirollbar bushing 811-S (4)
600546 Pivot ball antiroll bar 811-S (2)
600548 Suspension bracket FR-FR 811-S
600549 Suspension bracket FR-RR 811-S
600553 Pivot ball 7.5 double 811-S (4)
600554 Pivot ball steering short 811-S (2)
600558 Topdeck front 811-S
600581 Body post front 811GT (3)
600690 Shock tower fr alu GT RTR
903343 Antirollbar Spacer 3mm (2)

Page
11
Front Section Optional
600153 Topdeck front carbon
600176 Suspension bracket alu FR RR std
600177 Suspension bracket alu FR FR std
600240 Antiroll bar front 2.3mm
600241 Antiroll bar front 2.5mm
600242 Antiroll bar front 2.7mm
600263 Washer M3 alu (12)
600297 Lightwheight wheel nut 17mm (4)
600303 C-hub 10 L+R alu
600304 C-hub 12 L+R alu
600336 Antiroll bar front 1.8mm
600337 Antiroll bar front 2.0mm
600497 Steeringblock L+R V2 alu
600611 Steeringblock Alu 0-Deg L+R
600612 Shocktower carbon fr 811GT
Middle Section
600131 Balljoint set (19)
600197 Driveshaft insert (2)
600443 Center diff cover 811-E
600446 Motormount set 811-E
600447 Motor slider 811-E
600532 Gear coupler 811-S
600559 Spur gear 46T 811-S
600625 Driveshaft center RR 811 E-S
600626 Driveshaft center FR 811 E-S
Middle Section Option
600198 Spurgear 46T
600279 Spur gear 44T
600280 Spur gear 48T
600381 Gear coupler rubber boot (2)
600444 Driveshaft center FR 811-E
600471 Driveshaft center RR 811-E
600472 Gear coupler V3
600473 Gear coupler sleeve (2)
600606 Spurgear 46T composite
600607 Spurgear 48T composite
600608 Spurgear 50T composite
Rear Section
600126 Washer/nut nylon M3 (12+15)
600130 Diff case rear set
600131 Balljoint set (19)
600193 Pivotball threaded antirollbar (2)
600222 Wheelnut 17mm (4)
600365 Spacers 1,25mm + 2,5mm for wheelbase (4+2)
600365 Spacers 1.25mm + 2.5mm wheelbase (4+2)
600499 Pivotball double straight (3)
600188 Track rod M5x53 (2)
600543 Hinge pin 811-S (2)
600544 Antirollbar nut 811-S (4)
600545 Antirollbar bushing 811-S (4)
600546 Pivot ball antiroll bar 811-S (2)
600547 Hinge pin RR outer 811-S (2)
600550 Suspension bracket RR-FR 811-S
600551 Suspension bracket RR-RR 811-S
600552 Transmission brace mount RR 811-S
600553 Pivot ball 7.5 double 811-S (4)
600583 Bodymount rear 811GT
600584 Wheelhexacon 811GT (2)
600633 Wishbone rear L+R 811 2.0
600634 Upright L+R 811 2.0
600679 Driveshaft RR 811 2.0 S (2)
600680 Wheelaxle RR 811 2.0 S (2)
600691 Shock tower rr alu GT RTR
903343 Antirollbar Spacer 3mm (2)
Rear Section option
600155 Suspension bracket RR RR 3
600156 Suspension bracket RR FR 2
600237 Antiroll bar rear 2.3mm
600238 Antiroll bar rear 2.5mm
600239 Antiroll bar rear 2.7mm
600263 Washer M3 alu (12)
600265 Suspension bracket RR FR 2.5 - 4.5
600266 Suspension bracket RR RR HR 3
600267 Suspension bracket RR RR LR 3
600297 Lightwheight wheel nut 17mm (4)
600338 Antiroll bar rear 1.8mm
600339 Antiroll bar rear 2.0mm
600434 Antiroll bar rear 2.4mm
600613 Shocktower carbon rr 811GT
600661 Upright L+R 811 2.0 alu
Differential
600147 Diff gasket (3)
600205 Shim 13x16x0.2 (10)
600209 Diff pin 10T (2)
600210 Diff pin outdrive (2)
600354 Shim 14x15.5x 0.65 (4)
600356 Shim 14x15.5x0.2 (10)
600421 Oring centerdiff V2 (10)
600425 Diff housing V2
600495 Diff pinion 13T
600559 Spur gear 46T 811-S
600561 Diff outdrive center 811-S (2)
600562 Diff outdrive FR-RR 811-S (2)
600623 Dif gear 44T 811E-S
600627 Diff gear 10T + 20T (4+2) V2
Differential Optional
600501 Complete FR/RR 44T diff
Pinions
600452 Pinion 12T
600453 Pinion 13T
600454 Pinion 14T
600455 Pinion 15T
600456 Pinion 16T
600457 Pinion 17T
600458 Pinion 18T
600459 Pinion 19T
600460 Pinion 20T
Body
1667 Body-clip medium (10)
170311 Body 1/8 Cobra GT /RTR pre painted
600581 Body post front 811GT (3)
600583 Bodymount rear 811GT
Hardware
110101 Screw allen countersunk m4x8 (10)
110102 Screw allen countersunk m4x10 (10)
110103 Screw allen countersunk m4x16 (10)
110104 Screw allen countersunk m3x8 (10)
110105 Screw allen countersunk m4x12 (10)
110106 Screw allen anged roundhead m5x12 (10)
110107 Screw allen cilinderhead m3x16 (10)
110108 Screw allen roundhead m3x6 (10)
110109 Screw allen roundhead m3x10 (10)
110110 Screw allen roundhead m3x16 (10)
110111 Screw allen roundhead m3x14 (10)
110112 Screw allen roundhead m3x12 (10)
110113 Screw allen roundhead m4x8 (10)
110114 Setscrew allen m3x8 (10)
110115 Setscrew allen m3x4 (10)
110116 Setscrew allen m3x3 (10)
110117 Setscrew allen m3x12 (10)
110118 Setscrew allen m4x4 (10)
110119 Setscrew allen m4x6 (10)

Page
12
110120 Setscrew allen m4x10 (10)
110121 Setscrew allen m5x6 (10)
110122 Screw allen countersunk m3x6 (10)
110123 Screw philips roundhead 3.5x13 (10)
110124 Screw allen roundhead m3x8 (10)
110125 Screw allen countersunk m3x20 (10)
110126 Screw allen countersunk m2.5x12 (10)
110127 Screw allen countersunk m3x12 (10)
110128 Screw allen roundhead m3x5 (10)
110129 Screw allen cilinderhead m3x10 (10)
110130 Screw allen roundhead m2.5x6 (10)
110131 Screw allen roundhead m2.5x10 (10)
110132 Screw allen countersunk m3x16 (10)
110133 Screw philipshead countersunk 2.5x8 wide (10)
110134 Screw philipshead countersunk 2.5x10 wide (10)
110135 Screw allen countersunk M2.5x10 (10)
110136 Screw allen countersunk M2.5x8 (10)
110137 Setscrew allen M3x6 (10)
110138 Screw allen countersunk M4x14 (10)
110139 Screw allen countersunk M3x40 (10)
110140 Screw allen roundhead M3x20 (10)
110141 Screw allen roundhead M3x22 (10)
110142 Screw allen roundhead M3x25 (10)
110143 Screw allen roundhead M4x18 (10)
110144 Screw allen roundhead M3x18 (10)
110145 Screw allen roundhead anged M3x12 (10)
110146 Screw allen roundhead anged M3x16 (10)
110147 Screw ph roundhead M2.5x5 (10)
110148 Setscrew allen M5x4 (10)
110149 Screw allen countersink M2x10 (10)
110150 Screw M6x12 nylon black (2)
110151 Screw allen cilinderhead M4x10 (10)
110152 Screw allen cilinderhead M3x8 (10)
110153 Screw allen roundhead M2.3x4(10)
110154 Setscrew allen M3x10 (10)
110155 Setscrew allen M3x5 (10)
110156 Screw allen countersunk M2.2x6 (10)
110157 Screw allen countersunk M3x5 (10)
110158 Screw allen countersunk M3x15 (10)
110159 Screw allen countersunk M3x18 (10)
110160 Screw allen cilinderhead M2.2x12 (10)
110161 Screw allen cilinderhead M2x6 (10)
110162 Setscrew allen M3x2.5 (10)
110163 Setscrew allen M3x2 (10)
110164 Screw allen roundhead M3x4 (10)
110165 Screw allen cilinderhead M2x5 (10)
110166 Screw allen countersunk M2.5x5 (10)
110167 Screw allen roundhead anged M3x18 (10)
110168 Screw allen roundhead anged M3.5x10 (10)
110169 Screw allen roundhead anged M4x10 (10)
110170 Screw allen roundhead anged M3x28 (10)
110171 Screw ph roundhead widethread 2.5x6 (10)
110172 Screw allen roundhead anged M3X6 (10)
110173 Screw ph countersunk widethread 2.5x12 (10)
110174 Screw allen countersunk M4x6 (10)
110175 Screw allen cilinderhead M3x40 (10)
110176 Screw allen cilinderhead M3x18 (10)
110177 Screw allen roundhead M4x12 (10)
110178 Screw allen cilinderhead M3x14 (10)
110179 Screw allen roundhead M2.5x8 (10)
110180 Setscrew allen M5x10 (10)
110181 Screw M5x10 + Nut nylon black (4+4)
110182 Screw allen roundhead M2x4 (10)
110183 Screw allen countersunk M3x10 (10)
110184 Screw allen countersunk M3x14 (10)
110185 Screw allen cilinderhead M3x30 (10)
110186 Screw allen cilinderhead M3x35 (10)
110187 Setscrew allen M3x16 (10)
110200 Pin 2.5x8 (10)
110201 Pin 3x12 (10)
110202 Pin 5x5 (10)
110203 Pin 3x14 (10)
110204 Pin 3x20 (10)
110205 Pin 3x22 (10)
110206 Pin 2.5x22 (10)
110207 Pin 2.5x12 (10)
110208 Pin nra 2x9.8 (4)
110209 Pin nra 2x18 (4)
110210 Pin 3x13 (10)
110211 Pin 2.5x13 (10)
110212 Pin 2.5x17 (10)
110213 Pin 2.5x10 (10)
110214 Pin 3x15 (10)
110215 Pin 2x12 (10)
110216 Pin 2.5x15 (10)
110217 Pin 2x9 (10)
110218 Pin 3x10 (10)
110219 Pin 2x14 (10)
110220 Pin 1.5x8 (10)
110300 E-clip 2.3 (10)
110301 E-clip 3.2 (10)
110302 E-clip 4.0 (10)
110303 E-clip 5.0 (10)
110304 E-clip 7.0 (10)
110305 Seger clip 12x1.0 (10)
110306 E-clip 6.0 (10)
110307 E-clip 9.0 (10)
110400 Shim 6.0x10x0.2(10)
110401 Shim3.2x7x0.5 (10)
110402 Nut nylock M3 (10)
110403 Nut nylock M4 (10)
110404 Shim 6x8x0.3 (10)
110405 Nut nylock M4 anged (10)
110406 Nut nylock M2.2 (10)
110407 Nut M3 (10)
110408 Shim 3X5X0.3 (10)
110409 Shim 3X5X1 (10)
110410 Shim 3X5X2 (10)
110411 Shim 3X5X4 (10)
110412 Shim 3.5X8X1 (10)
110413 Shim 3.5X12X0.2 (10)
110414 Shim 3X6X0.1 (10)
110415 Shim 3X6X0.5 (10)
110416 Shim 3X6X0.8 (10)
110417 Shim 3X6X3 (10)
110418 Shim 4X8X0.1 (10)
110419 Shim 4X9.5X1 (10)
110420 Shim 4X9.5X2(10)
110421 Shim 4X9.5X4(10)
110422 Shim 4X10X0.3 (10)
110423 Shim 5X8X0.1 (10)
110424 Shim 5X8X0.3 (10)
110425 Shim 5X10X0.3 (10)
110426 Shim 5X10X0.5 (10)
110427 Shim 5X15X0.3 (10)
110428 Shim 6.5X8X0.25 (10)
110429 Shim 6X11.75X0.2 (10)
110431 Shim 8X11X0.1 (10)
110432 Shim 8X11X0.2 (10)
110433 Shim 12X15X0.25 (10)
110434 Shim 12X18X0.3 (10)
110435 Shim 13X16X0.2 (10)
110436 Shim 3x5x3 (10)
110437 Nut M2.5 (10)
110438 Shim 2.5x6x0.5 (10)
110439 Shim 3x7.5x1 (10)
110440 Shim 2.5x5x0.4 (10)
110441 Nut nylock M3 anged (10)
110442 Shim 4x8x0.6 (10)
110443 Shim 5x15x0.2 (10)
110444 Nut M4 nylon (10)
110445 Shim 4x10x0.2 (10)

110446 Shim 5x15x0.2 (10)
110447 Shim 3x7x7 (10)
110448 Shim 3x6x6 (10)
110449 Shim 3x6x1 (10)
110450 Nut M2 (10)
110451 Nylock nut M4 anged alu (10)
110452 Nut M4 anged knurled (10)
Merchandising
1891 Serpent medium promo decal 20x12.5 (2)
1892 Serpent windowshop decal 20x12.5 (2 sided)
1893 Serpent decal XL (30x60cm)
1895 Shopping-bag Serpent orange
1897 Towel Serpent large
1898 Lanyard Serpent orange
190156 Polo shirt Serpent black-orange (S)
190157 Polo shirt Serpent black-orange (M)
190158 Polo shirt Serpent black-orange (L)
190159 Polo shirt Serpent black-orange (XL)
190160 Polo shirt Serpent black-orange (XXL)
190161 Polo shirt Serpent black-orange (XXXL)
190172 Winter jacket Serpent (S)
190173 Winter jacket Serpent (M)
190174 Winter jacket Serpent (L)
190175 Winter jacket Serpent (XL)
190176 Winter jacket Serpent (XXL)
190188 T-shirt Serpent Splash orange (S)
190189 T-shirt Serpent Splash orange (M)
190190 T-shirt Serpent Splash orange (L)
190191 T-shirt Serpent Splash orange (XL)
190192 T-shirt Serpent Splash orange (XXL)
190193 T-shirt Serpent Splash orange (XXXL)
190194 T-shirt Serpent Splash black (S)
190195 T-shirt Serpent Splash black (M)
190196 T-shirt Serpent Splash black (L)
190197 T-shirt Serpent Splash black (XL)
190198 T-shirt Serpent Splash black (XXL)
190199 T-shirt Serpent Splash black (XXXL)
190201 Hoody sweater Serpent black-zip (S)
190202 Hoody sweater Serpent black-zip (M)
190203 Hoody sweater Serpent black-zip (L)
190204 Hoody sweater Serpent black-zip (XL)
190205 Hoody sweater Serpent black-zip (2XL)
190206 Hoody sweater Serpent black-zip (3XL)
190207 Hoody sweater Serpent black-zip (4XL) )
190208 Winter jacket Serpent (4XL)
190215 T-shirt Serpent WC edition black (S)
190216 T-shirt Serpent WC edition black (M)
190217 T-shirt Serpent WC edition black (L)
190218 T-shirt Serpent WC edition black (XL)
190219 T-shirt Serpent WC edition black (XXL)
190220 T-shirt Serpent WC edition black (XXXL)
Pit equipment
190500 Pit-caddy
190501 Tool-bag
190502 Pit-bag medium. 3 drawers
190504 Ballcup tool
190508 Toolset for offroad (20pcs) with Tools bag
190509 Allen wrench 1.5 x 120mm
190510 Allen wrench 2.0 x 120mm
190511 Allen wrench 2.5 x 120mm
190512 Allen wrench 3.0 x 120mm
190513 Ball driver Hex wrench 2.0 x 120mm
190514 Ball driver Hex wrench 2.5 x 120mm
190515 Ball driver Hex wrench 3.0 x 120mm
190516 Tool tip allen wrench 1.5 x 120mm
190517 Tool tip allen wrench 2.0 x 120mm
190518 Tool tip allen wrench 2.5 x 120mm
190519 Tool tip allen wrench 3.0 x 120mm
190520 Tool tip Ball driver Hex wrench 2.0 x 120mm
190521 Tool tip Ball driver Hex wrench 2.5 x 120mm
190522 Tool tip Ball driver Hex wrench 3.0 x 120mm
190523 Turnbuckle wrench 3mm
190524 Turnbuckle wrench 4mm
190525 Turnbuckle wrench 5mm
190526 Flat head screwdriver 3.0 x 150mm
190527 Flat head screwdriver 4.0 x 150mm
190528 Phillips screwdriver 2.0 x 45mm
190529 Phillips screwdriver 3.5 x 120mm
190530 Phillips screwdriver 5.8 x 120mm
190531 Nut driver 5.0 x 100mm
190532 Nut driver 5.5 x 100mm
190533 Nut driver 7.0 x 100mm
190534 Reamer with end cap for lexan body
190535 Exhaust spring / Caster clip remover
190536 Wrench-glowplug / Clutchnut - 10mm long
190537 Flywheel wrench tool wheel nut for 1/8 off road buggy
190538 Flywheel wrench
190539 Nut driver 4.5 x 100mm
Page
13
Transmitter, reciver, servo, parts
210000 Transmitter set DTS-1 with display 2.4 Ghz
210001 Transmitter DTS-1 with display 2.4Ghz
210002 Receiver DRS-1 on 2.4Ghz
210003 Servo digital 0.19s/10.5kg MG
210005 Servo case for #210003
210007 Servo gear set for #210003
Speed controller, motors, parts
211003 Speed controller DS8 WP-120A - BL 1650 motor
211006 Speed controller DS8 WP-120A - BL 2490 motor
211007 Motor brushless BL 8 2490kv
Bodies and accessories
213016 Body 1/8 GT clear
213017 Body 1/8 GT semi painted red
213018 Body 1/8 GT semi painted blue
213019 Body 1/8 GT semi painted green
Tyres rubber onroad and wheels
215016 1/8 GT tyre medium mounted white rim (2)
215017 1/8 GT tyre medium mounted black rim (2)
215018 1/8 GT tyre soft mounted white rim (2)
215019 1/8 GT tyre soft mounted black rim (2)
215020 1/8 GT tyre super soft mounted white rim (2)
215021 1/8 GT tyre super soft mounted black rim (2)
Additions / notes
All rights reserved. Parts may change without prior notice.

Page
14
600559
600623
1396
110127
600215
600562
600209
600627
600147
600210
1394
600425
600210
600425
600215
600562
Complete FR/RR 44T diff 600501
Complete centerdiff 46T 600324
Complete DIFF uni 600325
FRONT
REAR
CENTER
600421 600627 1396
600627
600421
600559
1394
110124
110102
600446 600446
600624
600443
600324
600324
DIFFERENTIAL ASSEMBLIES
TRANSMISSION CENTER

Page
15
REAR ASSEMBLY
600583
110145
110144
110159
600126
110159
600126
600545
600545
903343
903343
110116
110116
110175 600550
600130
600553
600633
600634
110138
600365
110141
1396
1337
600538
600112
600536
600112
600495
110z147
600532
1393
600534
600112
600551
600126
110107
600112
110118
110431
1395
600131
600126
600544
600193
600543
110301
600193
600225
600557
110301
110301
110301
110148
600641
110212
600131
600541
600131
110167
110167
140439
140439
110401
600553
110402
110402
110401
600691
600553
600130
600238
600691
110116
110116
600546
600546
110145
600583
600583

Page
16
110148
110212
600183
600183
600326
600131
600326
600326
600553
600326
600135
110301
110301
600131
600540
600137
600268
600126
600131
600544 600193
110137
1396
600481
600539
600223 600539
110115
1337 110216
600535
110105
110138
110107
600548
600548
600548
600126
600545
600545
600129
600495
1395
600532
1393
600112
600533 600129
600549
110402 600553 110401
110439 110140
600690
110107
600126
110431
110147
903343
903343
110116
600241
600546
600582
600614
600582
110141
110126 110127 110126
110126
110127
110127
600546 110116
600129
600690 110116
110116
110116
110107
600537
600197
110432
FRONT ASSEMBLY

Page
17
STEERING ASSEMBLY
SHOCK ASSEMBLY
110402
110402
110402
600558
600168
600557
110402
110402
1321
600170
600128
110439
600128
1321
1321
110159
600555
600167
600555
110140
110140
110127
110439
110439
110439
110402
1321
600105
600109
600169
600555
600574
600573
600111
600689
600113
600158
600234
600235
600118
600118
600118
600592
600180600145
110407
600597 Spring Fr/Rr Red 811 GT 18 lbs (2)
600598 Spring Fr/Rr Purple 811 GT 21 lbs (2)
600599 Spring Fr/Rr Yelow 811 GT 29 lbs (2)
600600 Spring Fr/Rr White 811 GT 31.5 lbs (2)
600601 Spring Fr/Rr Silver 811 GT 34.5 lbs (2)
600112
600112
600131
110159
110159
600592
600131
600556
600112

Page
18
RADIO ASSEMBLY
110132
600437
600499
600437
110127
110146
600436
110140
600436
1667
1667
600479
600436
110102
110102
600436
110116
110102
600442
600552
110402
110112
600436
1606
110149
110149
110116
110108
600555
600500
600436
110146
600437
110437
110402
110104
600554
110407

Page
19
FINAL ASSEMBLY
600581
600581
110132
110219
110132
110132
110151
600685
600224
600571
600184
600224
600184
110405
110137
600456
110118
600447
110151
600568
110137
110132
110405
110132
600581
600583
110219
110219
600581
600583
600222
1601
1601

Page
www.serpent.com - [email protected]
#82385Manual / ref guide S811 GTe RTR version 1
