Operation
The following pages describe how to operate the SRCM using the touch-screen interface.
The screen has two basic functions. The primary mode of operation displays the Home
screen, which shows the end-user pressure values, messages, text, and other data intended
for visual pressure verication in the facility. The second mode of operation is the Ad-
ministrative Menu screen, which permits setup, conguration, and changes to how the
SRCM operates. After changes have been performed on the Menu screen, functions are
saved and operation returns to the Home screen. Note: If there is no user interaction with
the touch screen for more than 1 minute, the screen will automatically return to the Home
Screen. Many administrative settings can be written over the BACnet MS/TP network.
Home Screen Menu Screen
NOTE: All settings of the SRCM can be password protected.

5
The default screen now has 2 possible modes. If the user wants to display other room
variables in addition to Pressure they can switch to the alternate home screen that shows
up to 4 parameters per room. These Parameters can be Pressure, Temperature, Humidity,
and user-dened (ex: CO2). The User switches modes by selecting slider on/slider off on
the bottom of the administrative menu.
The Home screen is the normal continuous operating mode of the SRCM. The Home
screen shows a Condition Banner on the left one-third of the screen, and Operating Con-
ditions on the right two-thirds of the screen. There are two possible home screens, one
with a pressure only display with a slider bar representing the room pressure with respect
to the alarm setpoints. The alternate home screen can be used when there are multiple
parameters being measured in addition to pressure, such as temperature, humidity and a
user-dened option.
Pressure Value
Slider Bar and Setpoint Values
Condition Banner
Room Label
Pressure Mode
• Positive
• Negative
• Neutral (span)
• Standby
Operation
• Normal (green)
• Warning (yellow)
• Door (yellow)
• Alarm (red)
Alternate Home Screen displaying multiple
parameters, in addition to pressure.
Home Screen
Room Label
Pressure Mode
• Positive
• Negative
• Neutral (span)
• Standby
Operation
• Normal (green)
• Warning (yellow)
• Door (yellow)
• Alarm (red)
Pressure
Temperature
Humidity
User-dened
Condition Banner
Home Screen

6
The Condition Banner is the left 1/3rd portion of the screen that can be congured
by the end-user or facility manager to display a message to staff on the oor. The
Condition Banner can be Green, Yellow, Red or Blue, depending on the message
desired outside the pressurized space. The Condition Banner is set up in the Setup
Display-Condition Banner tab of the Administrative menu. There is also the op-
tion to display the Condition Banner in full screen.
The Condition Banner will change to red in alarm state regardless of the current
conguration. The banner may be changed manually, as required, by pressing the
touch-screen anywhere within the banner color region.
Green Condition Banner—shows the
Entry Permitted graphic, and user de-
ned text above and below the graphic
image. Use the GREEN banner to indi-
cate room is safe to enter.
Red Condition Banner—shows
the Stop graphic, and user dened
text above and below graphic im-
age. Use the RED banner to indicate
room is under critical use and entry
is restricted.
Yellow Condition Banner—shows the
Warning graphic, and user dened text
above and below graphic image. Use
the YELLOW banner to indicate room
is under transient use and entry is re-
stricted.
User dened text
ENTRY PERMITTED
graphic (arrow is not intended
to indicate direction of airow)
User dened text
User dened text
STOP graphic
User dened text
User dened text
Warning graphic
User dened text
Condition Banner
User dened text
ENTRY PERMITTED
graphic (arrow is not intended
to indicate direction of airow)
User dened text
BLUE Condition Banner—shows
the Entry Permitted graphic, and
user dened text above and below
graphic image. Use the BLUE ban-
ner to indicate room is safe to enter.

7
Once the messages of each of the four Condition Banners are dened in the Menu
section, the user can cycle through all four conditions by simply touching anywhere
on the left one-third of the screen. If passwords are enabled, the user will be prompted
to enter their password before proceeding. Each of the four colored screens can have
a unique message dened. See Section: Setup Display, page 11, for instructions on
how to setup the Condition Banner.
When the alarm occurs the Condition Banner will behave as follows:
1. Condition Banner will turn Red and Blink, irrespective of the color mode selected
by the user. User congured color mode: “Alarm Blink” & “Blink in Red” in the
Setup Display screen will remain same. The operation eld which displays the alarm
state of the system will also blink. When the system returns to normal user congured
settings will be retained.
2. The Message text on the bottom of the Condition Banner and User dened text on
top of the Condition Banner will be displayed as “ALARM” temporarily.
The Condition Banner can be congured so that any of the Condition Banner colors
can be set to blink when that condition occurs. For example if an alarm occurs, Red
color can be made to blink. Similarly, the yellow warning, green, and blue modes can
also be set to blink.
The Condition Banner conguration on the Display screen will have 3 options: Ac-
tive, Standby, and No Action for all four colors (Red, Yellow, Green, and Blue).
• When Active is selected, the Occupancy Status object of the SRCM will be active.
• When STANDBY is selected, then the unit shall be put into STANDBY mode (No
alarms will be generated) when the corresponding color condition is selected
• The No Action mode will do nothing other than to display the Condition Banner
screen that has been associated with the No Action mode.
Alarms Cause
Condition Banner to
Turn Red
Condition Banner
Functions
Condition Banner –
Touch Screen
Operation

8
Operating
Condition Screen
The Operating Condition screen shows the user the active operating conditions of the
pressurized space.
The Room Label at the top of the screen can be dened by the user to ensure the
viewer understands which room is being monitored by the SRCM. See Changing
Room Name page 10, to enter text for your specic room.
The PRESSURE indication shows the intended direction of airow for the space.
POSITIVE for airow out of the space, NEGATIVE for airow into the space,
NEUTRAL for airow conditions that may vary, and STANDBY for use when there
is no need to verify the direction of airow (alarms are disabled).
The OPERATION indication shows whether the pressurized space is within normal
operating parameters (within alarm thresholds), or whether there is an alarm or warn-
ing condition. If operation is within alarm thresholds, a green NORMAL indica-
tion is shown. If operation is near either high or low alarm threshold limits, a yellow
WARNING indication is shown.
If operation is at or beyond high or low threshold limits, a red ALARM indication is
shown. If Audible Alarming is Enabled, a piezo buzzer will sound and a SILENCE
menu button will appear. Pressing the SILENCE button will shut off the alarm for
the period of time dened in the alarm conguration. Alarm operation can be cong-
ured to blink or sound an audible signal. See Section, Alarm Setup, page 15, for more
about setting up ALARM and WARNING conditions.
In addition to the pressure indication, OPERATION also displays whether a door
is open. If a door switch is congured, an open door contact will display a yellow
DOOR indication.
Room Label
Pressure Mode
• Positive
• Negative
• Neutral (span)
• Standby
Operation
• Normal (green)
• Warning (yellow)
• Door (yellow)
• Alarm (red)
Pressure Value
Slider Bar and
Alarm Setpoint
Values

9
Pressure Value A black banner displays the actual pressure reading from the space, in either inches
of Water Column (“ WC) or Pascals (Pa). The resolution of display can vary, de-
pending on desired conguration; either 2, 3, or 4 signicant digits. The accuracy of
measurement remains the same regardless of the number of digits chosen.
The blue banner below the pressure value shows where the current pressure reading
is in relation to alarm setpoints. The value at the left of the blue banner is the low set-
point, and the value on the right is the high setpoint. The middle “I-beam” represents
the current measured pressure value on the setpoint scale.
If the user does not wish to see the actual slider bar, it can be turned off using the
Menu screen. Operation of the pressure sensing and alarming is unaffected. See set-
ting up Menu screen, page 7.
High alarm setpoint
“Cursor” representing where
the pressure value lies relative
to the alarm setpoint
Pressure Value
Slider Bar and
Setpoint Values
Slider bar is turned off, this dis-
plays when four parameters are
congured
Slider bar is turned off, this displays
when no parameters are congured -
Pressure still displays
Slider Bar and
Set Point Values
Slider Bar On/Off

10
By pressing the touch-screen directly on the word POSITIVE (or NEGATIVE,
NEUTRAL, or STANDBY), the user is able to change the condition of the
room between ACTIVE and STANDBY modes. A pop-up menu appears to en-
able selection. If passwords are enabled, the user must rst enter a password to
proceed with the change.
In ACTIVE mode, the full function of the SRCM is active. In STANDBY
mode, the SRCM will perform all functions except that alarming will be dis-
abled (both audible and visual alarms). The STANDBY mode is designed to
put the SRCM into a mode where room pressurization is not critical, such as
cleaning, patient transfer, or longer-term unoccupied status. Note that this op-
eration can be password protected so that only an Operator or a Supervisor can
make this change. Passwords are set up in Setup Display Advanced tab.
Active and Standby
Modes

11
Pressing the MENU button on the Home screen brings up the Administrative Menu. If
passwords are enabled, the user is required to enter the correct password before being
authorized to make changes. From the Administrative Menu, the user can set all op-
erating parameters of the SRCM. This includes initial setup, commissioning, calibra-
tion, Network setup, customizing the displays, and warning and alarm parameters. The
menu structure is setup in such a way that the user can setup the unit by starting with
the left column and working down, moving to the next column and working down until
all setups have been made.
* Calibration is only required for highly accurate measurement needs such as those
needed to comply with federally mandated regulations. See the SRCM Product Data
Sheet for more information.
Upon initial installation, the Setup Unit screen should be used to dene installation
parameters specic to the job site.
Alarm setpoint values Save Settings and Exit
Calibration*—used to re-zero or
calibrate internal sensor
Room Label that settings
apply to (global unless
Secondary is shown)
Serial number and other
system information
Setup Alarm—setup the behavior of
how alarms are communicated to the
user
Setup Display—customizes the display
Slider ON/OFF—denes whether the
pressure value and alarm setpoints are
displayed on the home screen
Setup Unit—for initial unit setup Network Setup —congure
parameters to be read from
the network
Event Log—Alarm/
Warning History
Menu Screens

12
The SRCM can take as input, the signal from two separate pressure transducers as well
as temperature, humidity, and user dened (ex. CO2) inputs for up to two rooms. These
are congured for either Primary Room or Secondary Room (an anteroom is an example
of a secondary room). When two transducers are used, the Home screen display of the
SRCM can toggle between each space to indicate the status of each room momentarily
cycling from one to the other. Alternatively, the display can be locked on either of the
two rooms.
*If Ch1 is selected for the Primary room, it will not be an available option for the Sec-
ondary room.
Use the radio button to select the setup parameters for either the Primary Room or Sec-
ondary Room.
It may be necessary to change settings to match the sensor being used. OnBoard is the
default, which uses the sensor manufactured on-board the unit. Alternatively, an exter-
nal sensor (also known as “external transducer” such as a Setra 264 or Setra 267) may
be used. If an external sensor is used, change this selection to ADC Ch1 (Analog Input
1) or ADC Ch-2 (Analog Input 2). The FS output and range of the external sensor will
need to be entered. If the OnBoard Sensor is selected, a box is shown displaying the
pressure range and engineering unit.
It may be necessary to change settings to match sensor being used, if there is one pres-
ent. There is no specic sensor listed at the default. An external sensor (Setra 264 or
Setra 267) may be used for the secondary room, or anteroom. If an external sensor is
used, change this selection to ADC Ch1 or ADC Ch2, which use Analog Input 1 or
Analog Input 2, respectively. The FS output and range of the external sensor will need
to be entered.
Setup Unit
Primary Room sensor:
• OnBoard Sensor
• External Ch1
Secondary Room sensor:
• External Ch1*
• External Ch2
Setup selection to
congure either
Primary or
Secondary Room
Primary room pressure signal
output (AO) scale and units:
• 4-20 mA
• 0-5 Vdc
• 0-10 Vdc
Room label of selected room,
either Primary or Secondary
depending on ROOM radio button
Full Scale (FS) range of transducer
selected, Primary or Secondary
Pressure units, either “ WC or Pa
Room - Primary or
Secondary
Primary Room
Sensor
Secondary Room
Sensor

13
The SRCM can display up to four (4) parameters for each of 2 rooms. The pa-
rameters can be Pressure, Temperature, Humidity, and the fourth user dened
(Ex., CO2). Start with the Primary Room and set up the Parameters to be moni-
tored and displayed on the default or home screen. As Parameters and inputs
are selected further selection of parameters and inputs will become self limiting
(Ex., If Temperature is selected in Parameter 2, it is not available for selection
in Parameter 3 or 4.)
Start with Parameter 1, this is the Room Pressure. Select the Input Source as
OnBoard, ADC-Ch1 or ADC-CH-2.
Parameter 2, Select None, Temperature, or Humidity. Temperature is suggest-
ed. Select Source as ADC-Ch1, ADC-Ch2, or BACnet.
Parameter 3, Select None, Temperature or Humidity. Humidity is suggested.
Select Source as ADC-Ch1, ADC-Ch2, or BACnet.
Parameter 4 Select None, User Dened.
On the display, touch the label box and using the data entry keypad, input the
Room Label for the Primary Room. This will be displayed at the top of the de-
fault screen to identify the room that the parameters refer to. Use the Primary/
Secondary Room radio buttons to select the secondary room (generally an
anteroom) and label that room as desired.
This Analog Output (AO) is used to communicate the value of the differential
pressure of the Primary Room to an external source such as a Building Man-
agement System (BMS). The value is scaled as either 4-20 mA, 0-5 VDC, or
0-10 VDC, selectable. A normalized pressure value is generated once every
100 milliseconds. The analog output is only available for the Primary room.
Units of measurement to show on the Home screen are selectable as either
inches of Water Column ("WC) or Pascals (Pa). The units are factory cali-
brated as "WC, but if the unit is changed to Pa, the rang will be change to
Pascals (Pa). This is selected from the Parameter 1 tab as it is associated with
the primary room pressure.
The SRCM is manufactured with an on-board differential pressure transducer.
This transducer is manufactured to specications for xed minimum and
maximum pressure measurement, known as the full-scale range of the trans-
ducer. When the on-board transducer is used exclusively, these values cannot
change. Alarm setpoints cannot be set above the positive value or below the
negative value. If a wider or narrower sensor range is required for the project,
an external pressure transducer such as a Setra 264 or Setra 267 may be chosen
to match the requirements. See more above under Primary Room or Secondary
Room.
If an external transducer is used, the full-scale values and other parameters
need to be congured into the SRCM so the unit understands the scale of mea-
surement being received on the inputs Analog CH1 or Analog CH2.
Room Parameters
Label
Primary Analog
Output
Engineering Unit
Sensor Range

14
If selecting Analog Ch1 or Analog Ch2 for
either Primary of Secondary Room, enter
full-scale (FS) range that matches the trans-
ducer being used
Also enter voltage or milliampere range
that matches the transducer being used
Select desired units of measure to display on the Home
screen, either “WC or Pa. The unit of measure for the exter-
nal transducer must be selected before entering range and
output of the unit. After entering all data the units may be
changed and the range will scale accordingly.
The SRCM has 2 Analog Input Channels (ADC-CH1 and ADC-CH2)
Note: If a 4-20 mA transmitter is used as an analog input then a 250 ohm resistor
must be eld installed and this will be translated into a 1-5 VDC input at the input
terminals.
This takes an analog input from any transducer or transmitter: pressure, temperature
or humidity. If an external transducer is used, the full scale values and parameters
need to be congured into the SRCM so the unit understands the scale of measure-
ment being received on inputs ADC CH-1 or ADC CH-2.
The following is an example using a pressure transducer to measure secondary room
pressures. This is showing a pressure transducer with a range of ±1"WC and output
of 4-20 mA over that range.
The following is an example using a temperature sensor to measure primary room
temperature. This is showing a temperature range of ±50°C and output of 1-10 VDC
over that range.
Analog Inputs

15
Changing Room Name
Touch anywhere within the
Room Name entry box to bring
up the on-screen keyboard and
enter text.
Press Save after text entry is
complete.
Data Entry screen with
QWERTY keyboard
Use CAP-ON button to switch between
lower-case and upper-case lettering and
other characters
When nished with data entry, select Enter to
conrm, or ESC to cancel and return to the
previous screen
The following is an example using a humidity sensor to measure primary room
relative humidity. The range is 0-98 %RH with a 0-10 VDC output.
The room name shown on the top part of the Home screen is changed using the
Room Label button. The Room Name entry box appears in the middle of the
Setup Unit display. Depending on whether the Primary or Secondary Room
radio button is enabled, the matching Room Name entry box appears. The
maximum number of characters is 18.
Press anywhere in the Room Name selection box to bring up the on-screen
keyboard to enter the desired room label text. It is not necessary to touch the
white area next to the Label, simply start entering data using the keyboard en-
try. Be sure to press the Save button under the text entered before leaving this
screen.

16
Setup Display The Setup Display screen permits authorized users (based on password level) to
congure Condition Banner messages and other Home screen options. There are
four tabs for display customization; General, Advanced, Condition Banner, Set
Time and Date.
The General tab allows the user to dene messages for each Condition Banner
color. Pressing anywhere in the colored region of the Condition Banner changes
each selection between GREEN, YELLOW, RED, and BLUE. By pressing on
the colored region of text, the on-screen keyboard pops up, enabling data entry.
If User Dened Text is Disabled, then data entry on the Condition Banner will
not be permitted. Change User Dened Text to enabled to change the text of
each banner.
In the Setup Display General tab you can congure the text to be displayed
above and below the center symbol by enabling the User dened text. If you
want the banner to blink, Enable the Blink selection.
If any alarm occurs, the condition banner will turn to red and text above and
below the center symbol will display ALARM
Congure whether the user can
change the text of the Condition
Banner. Enabled or Disabled
Congure if you want to enable
banner
When nished making changes,
press Save & Exit to store the
modications. Or press Exit to
discard changes and return to
the previous screen.
Change color and text of
Condition Banner by pressing
anywhere in the colored region
Select Home screen language
desired, English or French
General Tab —
Customizing the
Condition Banner

17
The Advanced tab allows the user to make renements in how information
is displayed on the Operating Condition section of the Home screen. The
Display contrast level is adjusted using Adjust Contrast Level, with selec-
tions from 1-4. After modifying this parameter, press Save & Exit to view
the brightness and contrast on the Home screen display. Depending on the
lighting and viewing conditions in the nal space, different contrast levels can
improve readability of the SRCM.
This function is used to improve the stability of the pressure value displayed
on the Home screen, so signicant digits do not change rapidly. It is used
more often in environments where the user requires higher display resolution
(4 digits) but the ambient pressure is unstable. By increasing the number, the
effective number of measured data points is increased and a weighted aver-
age is developed. Input the number in tenths of a second for the response time
of the display to a pressure change. There is no ratcheting of the display or
a deadband. The pressure change is very smooth. For example, entering 10
equates to the display reaching nal value in 1 second. Entering 2 equates to
nal value in 2 seconds.
Display Averaging does not affect the Analog Output response time, only the
apparent stability of the pressure display. Display Averaging also does not af-
fect Alarm Thresholds or Alarm Delay.
This function denes what pressure value is shown on the Home screen under
normal operating conditions. This can be Primary Only, Secondary Only, or
Toggle, depending on what room is most important for visual pressure veri-
cation.
If this is set to Primary Only, then the Home screen will show the pressure
value read by the primary pressure transducer (either on-board, or the alter-
nate primary transducer congured from a separate transducer, if one is used).
If a secondary transducer is in use, and an alarm condition occurs in the sec-
ondary room, the display will toggle and remain on the secondary room and
pressure value as long as the alarm condition is present in that space.
Advanced Tab–
Customizing the Operation
Condition Screen
When nished making changes, press Save & Exit to store
the modications. Or press Exit to discard changes and return
to the previous screen
Primary Pressure Resolution
The number of signicant digits
displayed for the pressure value
(1-4)
Contrast level of Home
screen. Adjust from 1-4 for
readability in varying
lighting conditions
Dene Supervisor and Operator
passwords. Enable or Disable use of
passwords
Display Averaging.
Select a value from 1-40
What Pressure To Display:
• Primary Only
• Secondary Only
• Toggle
Congure if you want to enable
banner
Display Averaging
(tenths of seconds)
What Pressure To
Display

18
If this is set to Secondary Only, then the Home screen will show the pres-
sure value read by the secondary pressure transducer (anteroom for ex-
ample). In this case, if an alarm condition occurs in the primary room, the
display will toggle and remain on the primary room and pressure value as
long as the alarm condition is present in that space. If no Secondary Room
is congured on the Setup Unit screen, attempts to choose Secondary Only
will result in the error “Secondary room source is NONE.”
If the function is set to Toggle, then the Home screen will show the pres-
sure value for both rooms, alternating back and forth momentarily (approx-
imately 10 seconds apart). If an alarm condition occurs in either room, the
display will toggle to the appropriate room and pressure value and remain
on that room as long as the alarm condition is present. If both rooms are in
alarm, then the alarm condition and pressure values will toggle.
This setting shows the number of digits after the decimal point
for the default screen pressure displays. This setting affects the
primary and secondary room settings.
The password function provides security against changed congurations by
unauthorized users. This is accomplished by using two levels of password
protection. These can be enabled or disabled.
The Operator level allows access to change between Active and Standby
room modes, but no other changes.
The Operator is the person that has day-to-day interaction with the monitor
to change operating modes from Active mode to Standby (where no alarms
are active). the operator can also respond to local audible and visual alarms.
This could be a Nurse or a Lab Technician. The SRCM was designed to
make interaction with the unit as easy as possible for the Operator. Chang-
es to messages and to the room mode requires simply touching active areas
of the display. If Operator Password is enabled then a password will be
needed before the change can be made.
The Supervisor Level allows full access to all levels of the menu structure.
This mode is used during initial conguration and follow-on recongura-
tion.
NOTE: The master Supervisor password is 351, and will work for any
condition where a user may need to reset passwords.
Pressure Resolution
Supervisor and
Operator Passwords

19
The Condition Banner can be used for control function as well as pure communi-
cation. There are three choices for each color: Active, Standby, and No Action.
The Condition Banner tab allows the user to choose whether certain parts of the
screen blink or not. Blinking components on the Home screen are intended to
draw more attention to the Condition Banner or the OPERATION indicators. This
is for the purpose of making exception conditions more noticeable to staff con-
cerned with room pressurization status.
Alarm Blink Denes the behavior of the red ALARM
indicator on the Home screen. Normal
Blink is used for the green NORMAL
indicator.
Warning Blink Applies to the yellow WARNING, DOOR
indicator.
Blink in Red/Green/Yellow/Blue Applies to the Condition Banner messages
and icon on the left one-third of the Home
screen.
Full CB Display If this is selected the left 1/3rd of the
condition banner will become full screen
after 15 seconds. If an alarm is in progress
or occurs while the Condition Banner is
full screen, the standard default screen
will display. Touching the display will
return it to the 1/3rd, 2/3 standard display
mode. This is useful when users want a
very simple interface. Touching the screen
at any time will momentarily display the
Home screen.
Save & Exit Saves the selections made on this screen.
Condition Banner Tab-
Customizing Blinking
Screens
Used for setting
actions that is
associated with
each banner color
These apply to the right
side of the Home Screen

20
Full Screen Condition
Banner and Active Standby
Mode Application
Customers may want a minimal user interface and want to switch be-
tween Active and Standby Modes and clearly convey the status of the
room.
Note: Any color can be associated with any action: Active, Standby, or
No Action.
The following example uses GREEN for Active and YELLOW for
Standby.
1. On the setup Display/General tab set User dened Text to Enabled.
2. Tap the condition banner screen until the green screen is displayed.
Setup the desired green screen text message to be displayed in the Ac-
tive mode. Text can be entered so that it displays in the boxes above
and below the center "Clear to Enter" symbol. Touch the top box and
enter the desired text using the Data Entry keypad. Save by pressing
the Enter button when complete. Perform the same steps for the bottom
box.
3. Setup the desired yellow screen text message in the Setup Display/
General tab. Text can be entered so that it displays in the boxes above
and below the center "Warning Triangle" symbol. Touch the top box
and enter the desired text using the Data Entry keypad. Save by press-
ing the Enter button when complete. Perform the same steps for the
bottom box.
4. Setup the Condition Banner to display Full Screen rather than 1/3
left of screen display that is the default "as shipped" setup. To do this
go to the Setup Display/Condition Banner tab and set the full Condi-
tion Banner Display to Enabled. Press Save and Exit.
