SFA SANITOP Operation manual

SANITOP PAGE 1
INSTALLATION AND CARE INSTRUCTIONS
INSTALLATION AND CARE INSTRUCTIONS
1. Description - THIS UNIT IS FOR DOMESTIC USE ONLY
Ex1
Inlet Connector
Hx4
Foam feet
32 x 55
x4
Hose clip
B
25 x 40
x1
Hose clip
C
Gx2
Floor mounting bracket
90 x 110
Fx1
100mm
Hose clip
20 x 32
Dx1
Hose clip
THESE INSTRUCTIONS MUST BE READ BEFORE INSTALLATION IS ATTEMPTED. FAILURE TO DO SO MAY COMPROMISE WARRANTY. FOLLOWING
INSTALLATION PLEASE LEAVE ALL PAPERWORK WITH CLIENT AS IT CONTAINS IMPORTANT INFORMATION ON HOW TO UNDERTAKE ONGOING
CARE FOR YOUR SANITOP PUMP TOGETHER WITH WARRANTY PAPERS.
Ax1
Discharge elbow
The Sanitop
Sanitop
is a compact macerator pump designed to receive and pump away sewage waste and water from one standard P-trap WC pan
alone or together with one vanity basin.
Smaller
diameter
towards
pump casing
Ix1
Pan Collar and Cable Tie
Smaller
diameter
towards
pump casing
this new generation of appliances, it is important to comply with the installation instructions in section 5, 6 and 7.
2. List of Accessories included
Please pay particular attention to the following:
Possible danger to personnel Warning of possible electrical hazard
“ATTENTION” This is a general warning that failure to follow instructions could result in poor functioning of the unit.
1. Description - THIS UNIT IS FOR DOMESTIC USE ONLY
A
I
B
F
C
G
D
HE
Smaller
diameter
towards
pump
casing

SANITOP PAGE 2
3. Dimensions and overall measurements
OUTPUT (litres/min)
HEIGHT (m)
8
7
6
5
4
3
2
1
0
0 20 40 60 80 100
EN12050-3
5m max
4m
3m
2m
1m
100806040
20
10 metres
All elbows must
be 2 x 45˚
4. Performance curve
USE ONLY Ø 20MM PRESSURE PIPE FOR VERTICAL LIFT
5. Vertical and horizontal pumping parameters
Following vertical lift, increase discharge pipe diameter by one size on the Horizontal run to Sewer or vent connection.
N.B. VERTICAL LIFT MUST PRECEDE HORIZONTAL RUN
Install Isolation Valve at beginning of pipe run
All horizontal
pipework requires a
minimum of 1:100 fall
1:100
180

SANITOP PAGE 3
6. Installation
•The Sanitop should be installed to allow full access in the event that servicing and or removal is necessary.
movement during operation.
•The Sanitop must be coupled directly to the spigot (outlet) of the P-trap WC pan.
H
• Position the pump so that it is not in contact with a partition or wall of the room.
• Place the WC pan on a level surface to ensure that the foam feet are attached to the underside of the pump.
• Apply soapy water to the WC spigot and position the pan to the pump, ensuring that there is a 20mm gap between them. The reason for
this is two-fold 1. If in contact with the pump sound vibration occurs, and 2. the pump can be removed if service is needed.
• Locate pan collar onto front of the pump, ensuring small diameter opening is secured to the pump using plastic cable tie provided.
• Pull the pan collar over the pan spigot
• Position the metal hose clip (G) over the end of the pan collar and tighten with a screwdriver.
•
WARNING! THERE SHOULD BE NO WATER DRIPPING FROM THE WC CISTERN OR ANY OTHER SANITARY FIXTURE. IF THERE IS, THIS WILL CAUSE THE UNIT
TO ACTIVATE REPEATEDLY AND CAUSE THE PUMP MOTOR TO OVERHEAT AND MALFUNCTION. IMMEDIATELY CALL A SERVICE PLUMBER TO RECTIFY.
G
20mm
1 2
G
H
TO BE UNDERTAKEN BY A REGISTERED PLUMBER IN CONJUNCTION WITH: AS3500 10:10
•The inlet port for a Vanity basin connection is located on top of theSanitop lid.
• If using the lid port use a stanley blade or hack-saw to remove the very top of the port to allow connection.
• Use rubber connectors and pipe clips (supplied) to make secure connections. Ensure connectors are facing in the right direction before
securing. See diagram Eon page 1.
Connections - Incoming waste water
Sanitop
Sanitop
• Position the pump so that it is not in contact with a partition or wall of the room ensuring that the foam feet are attached to the underside of
the pump.
• Place the WC pan on a level surface.
• Apply soapy water to the WC spigot and position the pan to the pump, ensuring that there is a 20mm gap between them. The reason for this is
two-fold 1. If in contact with the pump sound vibration occurs, and 2. the pump can be removed if service is needed.
• Locate pan collar onto front of the pump, ensuring small diameter opening is secured to the pump using plastic cable tie provided.
The other end of the pan collar has a larger opening to allow easier  tting to WC pan outlet (spigot).
• Pull the pan collar over the pan spigot
• Position the metal hose clip (G) over the end of the pan collar (Spigot end) and tighten with a screwdriver. Affi x plastic cable tie to other end of
pan collar.
• Once the pump has been positioned, use 2 screws through the  oor mounting brackets to  x it to the  oor. (optional)

SANITOP PAGE 4
1
E
B
B
3
2
E
ø 20mm
3
C
B
1
A
1
Insert the elbow (A) into the rubber discharge pipe that rises up through the lid and turn it clockwise to the direction required and secure
with steel hose clip (B). Lubricate with soapy water or similar to make insertion easier.
2
Attach the rubber step down reducer to the discharge elbow and secure with steel hose clip (E).
3
Connect to the other end to 2Omm uPVC pressure pipe, using steel hose clip (C).
1
2(E).
3
Attach the inlet connector to the top entry using the metal hose clip (B), and use another hose clip (B) to attach to
the incoming waste pipe. The small diameter faces the pump lid, the larger diameter accepts incoming waste line.
E
2
Connections - Discharge outgoing waste water
Select discharge pipework as follows:-
•Vertical lifts must occur prior to any horizontal runs, except for the initial short run at the pump connection, this should be NO MORE than
300mm in length.
• Only ONE vertical lift is permitted in the discharge line, all changes of direction in the discharge line MUST be made with 45deg bends
rather than 90deg bends.
• For vertical pipework USE ONLY 20mm upvc (pressure pipe)
• Horizontal pipework ( following initial vertical lift ) can be upgraded by one size to 25mm.
• Once selection has been made, insert discharge elbow (supplied) into the rubber discharge pipe protruding from lid of theSanitop, trim
rubber connector to size and make connection between discharge elbow and upvc discharge pipe.
• Before securing all connections connect a PVC Ball Valve in the upvc pipework as near to the beginning of the discharge line as possible.
• Do NOT install a Non Return Valve (NRV) in the discharge line as the discharge elbow (supplied) incorporates an inbuilt nrv.
• All horizontal pipework that follows initial vertical lift must run with a constant Downhill gradient of 1:100 MIN (or better) to eventual
sewer or vent connection.

SANITOP PAGE 5
20mm
100/110mm
Isolation valve
Vertical before
horizontal
Air Admittance Valve
Ø 20mm
max. 5m
3%
Ø 25mm
001 : 1
001 : 1
Isolation valve
Connections - Venting
•Where possible venting should always be made in a manner consistent with common plumbing practice venting requirements
referred to in Australian Standa
Sanitop
rds AS 3500 10:10 & 6:7:4.
•You can use suitable pvc pipe or plastic hose to run the vent, either to the open atmosphere or to an existing vent stack located nearby.
pod is recommended approximately every 12 months.

SANITOP PAGE 6
7. Electrical connection
The electrical installation should be carried out by a registered electrician.
The Sanitop pump is equiped with a 3 core electrical cable which contains Earth Active andNeutral wires,
it has a three pinmoulded plug attachment. All wires in this cable are colour coded in accordance with
International colour coding ie BROWN - ACTIVE ( LIVE), BLUE - NEUTRAL, GREEN / YELLOW - EARTH.
• All wiring connections and GPO locations must conform to AS/NZS 3000:2007 requirements.
• Supply must be protected via a 30mA RCD rated at 16amps, located at the switchboard.
•The Sanitop requires a 240V single phase 50 Hz AC power supply
• If a decision is made to hard wire, in the event that servicing is requried then cost to disconnect and re-connect will be at consumers expense.
TO BE UNDERTAKEN BY A REGISTERED ELECTRICAL CONTRACTOR IN CONJUNCTION WITH : AS/NZS 3000.2007
8. Commissioning the SANITOP pump
BEFORE COMMISSIONING THE PUMP MAKE SURE ALL CONNECTIONS ARE SECURE AND WATER-TIGHT
Once ALL connections are secure and before you switch the power on, press the full ush button on your cistern and allow water to enter
and begin discharging into the discharge pipe system. Initial run time is normally between 5 -10 secs. Duration of run time is generally
determined by the length of travel in the pump-out line and type of waste, Pump operation will shut down after this time. Should the pump
continue running for longer than the recommended time, an installation or manufacturing problem may exist, immediately contact SANIFLO
on 03 9543 3891 and speak with a tech. suppor t person, they will be only too happy to assist.
The Sanitop pump conforms to Australian and New Zealand standards AS/NZS and Watermark approvals.
A lifting plant for waste water containing faecal matter and for limited applications, and to European directives and standards applicable to
Electrical and electromagnetic compatibility.
potinaS ®
Société Française d’Assainissement
EN 12050-3
LA01-x10
220 - 240 V - 50 Hz -550 W - IP44 2.9A - - 5.4 KG
9. Approvals
10. Care and use
DO NOT... dispose of sanitary materials, plastics, wood, solvents, paints, turps, caustic acid, or other corrosive acids or cleaners.
DO NOT... dispose of hot water in excess of 40º C.
DO NOT... useBlu Loo or similar products with your Sanitop ay cause the pump to cavitate. Cavitation occurs when there is an
excessive build of of foam or froth from detergents; this may cause motor damage.
DO...
DO... periodically clean the Sanitop with a basic household detergent cleaner ie domestos, pine o clean or actizyme.
DO...
previous operation, sooner rather than later.
11. Servicing
12. Warranty
Periodical servicing may be required, depending on your usage cycle. On average we would recommend that a service be undertaken every
2 years or alternatively if you believe that yourSanitop is not functioning as it has been, then give our Technical department a call to obtain
details of your nearest Service Agent.
1300 554 779.
A 2 Yr Manufacturers Warrantyapplies to yourSanitop pump this commences from the date of purchase and is subject to CORRECT
INSTALLATION and CORRECT USAGE. Anyfailure or motor burn-out attributed to incorrect installation or consumer misuse is NOT covered
under this Warranty.
ATS 5200.101
Certificate No. 23048
Manufacturer: SFA
Brand: Saniflo
as this m
NOISE LEVELS
All Sani pumps (domestic rated) conform to the National Code of Practice for Noise Management and Protection of Hearing in a
workplace or domestic environs (NOHSC 2004-2009)
All Sanio grey water and macerator pumps are not in themselves very noisy and the sound of operation is generally not invasive.
However, noise levels can be increased/amplied due to sympathetic resonance from stud partitions, some oors and tight locations.
Example - decibel comparison
• People conversation (normal) 60-70 db
• Sanipumps (domestic) Max 65 db
• Toilet cistern ushing 75 db
• Vacuum cleaner 80 db

SANITOP PAGE 7
For the most part, any inconsistencies in the operation of the unit will be minor and easily rectied. Please refer to the chart below.
If the problem cannot be easily remedied in this way, please call us on 1300 554 779.
IN ALL CASES, YOU MUST DISCONNECT THE MACERATOR FROM THE POWER SUPPLY.
ALL WORK INVOLVING DISMANTLING OF THE APPLIANCE MUST BE CARRIED OUT BY AN APPROVED REPAIR AGENT.
13. Fault Finding / Remedies
SYMPTOMS PROBABLE CAUSES REMEDIES
• The unit stops
• An object is blocking the blades
• The unit has been running for too long and the
(self re-setting) thermal cut out has engaged
• Call approved service engineer.
• The unit will reset itself.
• The motor intermittently activates
• The connected xtures are dripping
• The non-return valve is faulty
• Cistern is leaking
• Check the installation upstream
• Clean or replace the non-return valve
(externally mounted)
• Call plumber to replace ush pipe seal
• The water in the WC pan goes down very
slowly and is pumped away in bursts
• The air vent (under carbon lter) is clogged up
• The WC pan is partially blocked
• Clear the air vent.
• Clear the WC pan
• The motor operates normally, but continues to
run for a long time
• The length or height of the installation is
over the specication, or there are too many
bends/elbows
• The pump chamber is blocked
• An electrical component has failed
• Check the installation
• Call approved service engineer
• The motor does not activate • The electrical power supply is not active
• The motor or the control system is defective
• Restore the electrical supply
• Call approved service engineer
• The motor emits a rattling or crunching sound,
hums, but does not run
• Foreign object in the pump
• Problem with the motor or the control system • Call approved service engineer
7. Electrical connection
The electrical installation should be carried out by a registered electrician.
The Sanitop pump is equiped with a 3 core electrical cable which contains Earth Active andNeutral wires,
it has a three pinmoulded plug attachment. All wires in this cable are colour coded in accordance with
International colour coding ie BROWN - ACTIVE ( LIVE), BLUE - NEUTRAL, GREEN / YELLOW - EARTH.
• All wiring connections and GPO locations must conform to AS/NZS 3000:2007 requirements.
• Supply must be protected via a 30mA RCD rated at 16amps, located at the switchboard.
•The Sanitop requires a 240V single phase 50 Hz AC power supply
• If a decision is made to hard wire, in the event that servicing is requried then cost to disconnect and re-connect will be at consumers expense.
TO BE UNDERTAKEN BY A REGISTERED ELECTRICAL CONTRACTOR IN CONJUNCTION WITH : AS/NZS 3000.2007
8. Commissioning the SANITOP pump
BEFORE COMMISSIONING THE PUMP MAKE SURE ALL CONNECTIONS ARE SECURE AND WATER-TIGHT
Once ALL connections are secure and before you switch the power on, press the full ush button on your cistern and allow water to enter
and begin discharging into the discharge pipe system. Initial run time is normally between 5 -10 secs. Duration of run time is generally
determined by the length of travel in the pump-out line and type of waste, Pump operation will shut down after this time. Should the pump
continue running for longer than the recommended time, an installation or manufacturing problem may exist, immediately contact SANIFLO
on 03 9543 3891 and speak with a tech. suppor t person, they will be only too happy to assist.
The Sanitop pump conforms to Australian and New Zealand standards AS/NZS and Watermark approvals.
A lifting plant for waste water containing faecal matter and for limited applications, and to European directives and standards applicable to
Electrical and electromagnetic compatibility.
potinaS ®
Société Française d’Assainissement
EN 12050-3
LA01-x10
220 - 240 V - 50 Hz -550 W - IP44 2.9A - - 5.4 KG
9. Approvals
10. Care and use
DO NOT... dispose of sanitary materials, plastics, wood, solvents, paints, turps, caustic acid, or other corrosive acids or cleaners.
DO NOT... dispose of hot water in excess of 40º C.
DO NOT... use Blu Loo or similar products with your Sanitop ay cause the pump to cavitate. Cavitation occurs when there is an
excessive build of of foam or froth from detergents; this may cause motor damage.
DO...
DO... periodically clean the Sanitop with a basic household detergent cleaner ie domestos, pine o clean or actizyme.
DO...
previous operation, sooner rather than later.
11. Servicing
12. Warranty
Periodical servicing may be required, depending on your usage cycle. On average we would recommend that a service be undertaken every
2 years or alternatively if you believe that yourSanitop is not functioning as it has been, then give our Technical department a call to obtain
details of your nearest Service Agent.
1300 554 779.
A 2 Yr Manufacturers Warrantyapplies to yourSanitop pump this commences from the date of purchase and is subject to CORRECT
INSTALLATION and CORRECT USAGE. Anyfailure or motor burn-out attributed to incorrect installation or consumer misuse is NOT covered
under this Warranty.
ATS 5200.101
Certificate No. 23048
Manufacturer: SFA
Brand: Saniflo
as this m

SANITOP PAGE 8
14. Parts
1
35
34
36
56
64
12
11
9
13
8
7c
63
4
62
2b
2a
26b
26
24
21a 21c 28b
21d
15
41b
40a
17
41a
5
50
18
48
14
38
40b
42
39
20b
20
10a
61
3
White
casing

SANITOP PAGE 9
1 2
3 4
5 6
7 8
9 10
1 2
3 4
5 6
7 8
9 10
1 2
3 4
5 6
7 8
9 10
1 2
3 4
5 6
7 8
9 10
1 2
3 4
5 6
7 8
9 10
All horizontal pipes should have a minimum fall of 1:100.
Discharge pipework should be solvent UPVC.
Do not “pushfit” pipework/fittings.
If a vertical rise is needed, this should be at the start of the run
(within 30cm of the unit).
Bends should be smooth/long radius, not tight elbows.
Examples of uPVC Pressure Pipe and fittings shown.
Waste Pipes entering the Saniflo unit should have a
gravity fall of 1:40
2 x 45˚ Offset
Plastic Elbows
Where the pipework falls below floor level, fit an air admittance
valve at the highest point capable of withstanding 10psi neg
pressure, or upsize pipe coming down to break syphonage.
Each Saniflo discharge pipe should run separately to the sewer/vent
pipe. If wastes are combined, it can only be connected to a larger pipe.
This pipe must gravity fall to connection point.
The unit should be easily accessible and removable in the event of service
or maintenance being required. If boxed in, the boxing should be easily
removed. Any extension between the WC pan spigot and wall should not
exceed 150mm and have a 1.40 fall.
As close coupled cistern dimensions vary it may be
necessary with certain designs to utilise a spacer between
cistern and wall.
Position the Saniflo unit directly behind the toilet pan,
not underneath it.
Connect to power according AS/NZS 3000: 2007 Electrical Regulation
as rules apply depending on location. In ALL CASES
supply must be protected by a 30mA RCD rated at 16A.
Easily
removable
panels
Air admittance
valve
1:100
PVC
Ball Value
ELECTRICAL CLASS 1 PRODUCT
After sales contact information: info@saniflo.com.au
15. Ten golden rules for correct installation
