Owner’s Manual
Granite Peak
10’ x 14’ Hard Top Gazebo
Model Number: GP/GAZ14-2
SKU Number: 101642581
Note: This gazebo is designed to be used as a permanent fixture.
Scan For Video
Assembly Instructions!

2of25
Parts List
Granite Peak 10’ x 14’ Hard Top Gazebo
Letter
Illustration
Description
Qty.
A
Corner Post
4
B
Corner Post Base Plate
4
C1
Short Lintel
2
C2
Short Lintel
2
D1
Long Lintel
2
D2
Long Lintel
2
E
Lintel Corner Support Bar
8
F
Lintel Bracket
8
G2
Lintel Connector
4
H
Main Roof Corner Support
4
I
Main Roof Vertical Center Support
8

3of25
Letter
Illustration
Description
Qty.
J1
Main Roof Center Frame – Short
Connector
2
J2
Main Roof Center Frame - Long Connector
2
K1
Roof Vent - Corner Supports
4
K2
Roof Vent - Center Support
1
K3
Roof Vent Hook
1
K4
Roof Vent - Side Supports
2
L
Roof Vent - Top Trim
1
M
Main Roof – Lower Horizontal Support
8
N
Main Roof – Upper Horizontal Support
8
O
Main Roof – Center Horizontal Support
8
O1
Main Roof Connector – Corner
8
O2
Main Roof Connector – Center
16

4of25
Letter
Illustration
Description
Qty.
P1
Roof Vent Frame – Short Sides
2
P2
Roof Vent Frame – Left Sides
2
P3
Roof Vent Frame – Right Sides
2
Q1
Main Roof Corner Trim
4
Q2
Roof Vent Corner Trim
4
Q3
Main Roof Center Frame Trim -
Short Sides
4
Q4
Main Roof Center Frame Trim -
Long Sides
4
R1
Roof Vent Side Trim - Long Sides
2
R2
Roof Vent Side Trim - Short Sides
2
S1
Lintel Cover - Corner
4
S2
Lintel Cover - Center
4
T1
Main Roof Panel - Left Corner
4

5of25
Letter
Illustration
Description
Qty.
T2
Main Roof Panel - Left Side
4
T3
Main Roof Panel - Center
2
T4
Main Roof Panel - Right Side
4
T5
Main Roof Panel - Right Corner
4
T6
Main Roof Panel - Left Center
2
T7
Main Roof Panel - Right Center
2
T8
Main Roof Panel - Center
2
U1
Roof Vent Panel - Short Side
2
U2
Roof Vent Panel - Long Side (Left)
2
U3
Roof Vent Panel - Long Side (Right)
2
U4
Roof Vent Panel - Long Side (Center )
2
V
Mosquito Netting
4

6of25
Letter
Illustration
Description
Qty.
AA
M6 x 15mm Bolt with Steel Washer
244
BB
M8 x 15mm Bolt with Steel Washer
48
CC
M6 x 15mm Bolt with Plastic Washer
16
DD
M6 x 15mm Bolt
16
EE
M6 x 25mm Bolt with Plastic Washer
28
FF
M6 x 35mm Bolt with Plastic Washer
8
GG
M6 x 40mm Bolt with Plastic Washer
8
HH
M6 x 50mm Bolt with Plastic Washer
2
II
M6 x 55mm Bolt with Flat Washer & Nut
6
JJ
Mosquito Netting Hook
48
KK
Spacer
28
LL
Ground Stake
12

7of25
MM
M8 Allen Wrench
1
NN
M6 Hex Wrench
2

8of25
Assembly Instructions
Granite Peak 10’ x 14’ Hard Top Gazebo
Note: For video instructions please visit:
https://shadenshelters.com/10x14-granite-peak-gazebo
Important:
⚫Read all the instructions before assembly. Failure to do so may result in faulty assembly and
potential injury.
⚫Before assembling the product, remove all protective materials, hardware kit(s), and identify all
parts packed in the carton are present. (Note: If any part is missing or damaged, do not attempt to
assemble). Contact Shade N’ Shelters Customer Support. See page 25.
⚫Assemble on a stable level surface to avoid damage to gazebo and possible injury.
⚫Two people are required to assemble this product.
⚫Gazebo dimensions are measured from roof corner to roof corner.
WARNING: DO NOT TIGHTEN BOLTS UNTIL NOTED AFTER EACH STEP!
Step 1: Connect Corner Post Base Plate (B) to Corner Post (A) using Bolts (AA). Repeat for all Corner Posts
and Base Plates. Tighten all Bolts. See Figure 1.
Figure 1

9of25
Step 2A: Insert Fourteen Mosquito Netting Hooks (JJ) into the channel of each Long Lintel (D2).
See Figure 2-1.
Step 2B: Attach Lintel Connector (G2) to Long Lintel (D2) using Bolts (BB). See Figure 2-2
Step 2C: Attach Long Lintel (D1) to Lintel Connector (G2) using Bolts (BB). Attach outside Lintel Brackets
(F) to Long Lintel (D1 and D2) using Bolts (AA). Attach inside Lintel Bracket (F) to Long Lintel (D1
and D2) using Bolts (BB). Tighten all Bolts. Repeat Step 2A to 2C for remaining Long Lintels
(D1 and D2). See Figure 2-3.
Step 2D: Insert ten Mosquito Netting Hooks (JJ) into the channel of each Short Lintel C2. See Figure 2-4.
Step 2E: Attach Short Lintel (C2) to Lintel Connector (G2) using Bolts (BB). Attach Short Lintel (C1) to
Lintel Connector (G2) using Bolts (BB). Note: Leave 1 Bolt Hole open on both Short Lintels (C1
and C2) for Step 2F. See Figures 2-5 and 2-6.
Step 2F: Attach Lintel Bracket (F) to Short Lintels (C1 and C2) using Bolts (BB). Tighten All Bolts. See
Figure 2-6. Repeat Step 2D to 2F for remaining Short Lintels (C1 and C2).
Figure 2-1 Figure 2-2
Figure 2-3
Figure 2-4
Figure 2-5
Figure 2-6

10 of25
Step 3A: Attach Corner Posts (A) to end of Long Lintels (D1 and D2) first with Bolts (AA) then with Bolts
(DD). Tighten all Bolts. See Figure 3-1.
Step 3B: Repeat for opposite side Long Lintels (D1 and D2) and Corner Posts (A). See Figure 3-2.
Figure 3-1
Figure 3-2

11 of25
Step 4A: Attach Corner Posts (A) to Short Lintel (C1 and C2) first with Bolts (AA) then with Bolts (DD).
Repeat for opposite side Short Lintels (C1 and C2). See Figure 4-1.
Step 4B: Attach Support Bars (E) to Lintels (C1 and D2) and Corner Post (A) with Bolts (AA).
See Figure 4-2.
Step 4C: Repeat for all Corner Posts and Lintels. Tighten all Bolts. See Figure 4-3.
Figure 4-1
Figure 4-2
Figure 4-3

12 of25
Step 5A: Attach Corner Lintel Cover (S1) to Long Lintel (D1) and Short Lintel (C2) with Bolts (AA). Repeat
for all corners. Tighten all Bolts. See Figure 5-1.
Step 5B: Attach Center Lintel Cover (S2) to Long Lintels (D1 and D2) and Short Lintels (C1 and C2).
Tighten all Bolts. See Figure 5-2.
Step 5C: Repeat for opposite sides. Tighten all Bolts. See Figure 5-3.
Figure 5-1 Figure 5-2
Figure 5-3

13 of25
Step 6A: Assemble the Main Roof Center Frame by inserting the Long Connector (J2) into the Short
Connector (J1) and attach with Bolts (AA). See Figure 6-1.
Step 6B: Repeat for opposite sides and ends. Tighten all Bolts. See Figure 6-2.
Figure 6-2
Figure 6-1

14 of25
Step 7A: Assemble the Main Roof Corner Supports (H) to the Short Connector (J1) on the Main Roof Center
Frame and then to the Corner Posts (A) using Bolts (AA). See Figure 7-1.
Note: You will need a second person to hold the Main Roof Center Frame while attaching the Main
Roof Corner Supports (H).
Step 7B: Repeat for all corners and Tighten all Bolts.
Note: Diagonal measurements from corner to corner must be within 5mm of the same distance.
See Figure 7-2.
Figure 7-1
Figure 7-2

15 of25
Step 7C: Attach the Main Roof Vertical Center Supports (I) to the Main Roof Center Frame (J1 and J2) and
the Lintel Brackets (F) using Bolts (AA). Hand Tighten Only. See Figure 7-3.
Step 7D: Repeat for each side. Tighten all Bolts. See Figure 7-4
Figure 7-3
Figure 7-4

16 of25
Step 8A: Assemble the Roof Vent Frame by attaching Roof Vent Corner Support (K1) to Roof Vent Center
Support (K2) with Bolts (II). See Figure 8-1.
Step 8B: Repeat for all corners. Tighten all Bolts. See Figure 8-2.
Step 8C: Attach Roof Vent Hook (K3) to Roof Vent Center Support (K2). See Figure 8-2 and Figure 8-3.
Figure 8-1 Figure 8-3
Figure 8-2

17 of25
Step 9A: Secure the Roof Vent Frame to the Main Roof Center Frame by inserting the Roof Vent Corner
Supports (K1) into the post on the Short Connector (J1) of the Main Roof Center Frame and attach
using Bolts (AA). See Figure 9-1.
Step 9B: Attach Roof Vent Side Supports (K4) to Roof Vent Center Support (K2) using Bolts (II). Attach
Roof Vent Side Supports (K4) to Main Roof Center Frame (J2) using Bolts (AA). Repeat for
opposite side. Tighten all Bolts. See Figure 9-2.
Step 9C: Attach the sides of the Roof Vent Frame by connecting the Short Side (P1) and Left/Right Side
(P2/P3) to the Roof Vent Corner Support (K1) and the Roof Vent-Side Supports (K4) using Bolts
(AA). Tighten all Bolts. See Figure 9-3.
Figure 9-1 Figure 9-2
Figure 9-3
Figure 9-4

18 of25
Step 10A: Assemble Roof Vent Panels by placing Left Roof Vent Panel (U2), Center Roof Vent Panel (U4)
and Right Roof Vent Panel (U3) on the Roof Vent Frame. Attach to Long Side of Roof Vent Frame
(P2) using Bolt (CC).
Note: Roof Vent Panels must overlap. See Figure 10-1.
Step 10B: Secure the Roof Vent Panel (U1) to the Short Side of the Roof Vent Frame (P1) using Bolt (CC).
See Figure 10-2.
Figure 10-1
Figure 10-2

19 of25
Step 10C: Repeat for opposite long and short sides. Tighten all Bolts. See Figure 10-3.
Step 10D: Attach the Long Roof Vent Trim (R1) and Short Roof Vent Trim (R2) to the Sides of Roof Vent
Frame (P1, P2 and P3) using Bolts (AA). Repeat for all sides. Tighten all Bolts.
See Figure 10-4.
Figure 10-3
Figure 10-4

20 of25
Step 11A: Attach the Roof Vent Corner Trim (Q2) to the Roof Vent Corner Support (K1) using Bolts (FF).
See Figure 11-1.
Step 11B: Repeat for all corners. Tighten All Bolts. See Figure 11-2.
Step 11C: Attach the Roof Vent Top Trim (L) to the Roof Vent Center Support (K2) using Bolts (HH).
Tighten Bolts. See Figure 11-2 and Figure 11-3.
Figure 11-1 Figure 11-3
Figure 11-2
