Patio Post CS62671 User manual

ASSEMBLY INSTRUCTION
ITEM CODE: CS62671
2 seat outdoor swing
For any assistance with assembly or for missing parts please Contact with us
Email: [email protected]
Web: www.lhgst.com
Adress:NO.99 South Heyang Road,Dayang Street, Linhai,zhejiang,China
Page 1

PRE-ASSEMBLY PREPARATION
Before you start:
1.Choose a clean, level, spacious assembly area. Avoid hard surfaces that
may damage the product
2.Take care when lifting. Product should be assembled as near as possible
to the point of use
3.Ensure that you have all required contents for complete assembly
4.Always read the assembly instructions carefully before beginning
assembly.
5.Keep all hardware parts and packaging out of reach of small children.
6.Do not over tighten the screws and bolts as this may damage the
threads
7.Assembly is to be carried out by a competent adult(s) ONLY
8.During assembly, children should be kept away from the product due to
possible risk to injury.
9.Do not use this item if any components are missing or damaged.
10. Please keep the instructions for future reference.
Page 2

PARTS LIST
Page 3

You will need the following
Step 1
Page 4
•Prepare a surface with a blanket or cardboard.
•Prepare 8x bolt Q sets. Thread bolt(Q) through washer(U).
•Connect part(C) and part(D) to part(A) and part(B) as shown
below.
•Secure with 2x bolt Q sets at each connection, fasten with Allen
Key(AA).

You will need the following
Step 2
•Attach the 2x swing arms(E) to the frame. The short end of the
late, closest to the rode connects to the feet(A&B). The long end
of the plate faces down.
•Secure with bolt(S), threaded from the outside, through swing
arm(E). Place the plastic washer(N) between the swing arm(E) and
the feet(A&B) Lock the inside with washer(U) and nut(V). Fasten
with Allen key(AA)and Wrench(BB), as shown below.
•Do this for all 4 connection points.
Page 5

Step 3
You will need the following
•Attach right armrest(F) to the swing arms(E) as shown below.
•Thread bolt(S) from the outside through the armrest(F). Place the
plastic washer(N) between the armrest and the swing arm. Lock
the inside with washer(U) and nut(V). Fasten with Allen key(AA)
and Wrench(BB), as shown below.
•Repeat for the left armrest(G).
Page 6

Step 4
You will need the following
•With the aid of a 2nd person, attach the base and back plate(H) to
the armrests.
•Thread bolt(S) from the outside of the middle bar of the armrest,
in through armrest and part(H). Lock the inside with washer(U)
and nut(V). Fasten with Allen key(AA) and Wrench(BB), as shown
below. You will need to bolts per armrest.
Page 7

Step 5
You will need the following
•Connect the top of the armrest to part(H).
•Prepare 2x bolt R set, thread bolt(R) through washer(H)
•Thread bolt R set from the inside of part(H) outwards. Place
plastic washer(N) between the armrest and part(H). Fasten with
Allen key(AA).
Page 8

Step 6
You will need the following
•Stand left and right tea table support(J&K) on the floor, attach
the tea table connecting part(M) to the supports, as shown below.
•Prepare 2x bolt R sets by threading bolt(R) through washer(U).
•Connect parts(J&K) to part(M) with bolt R sets, fasten with Allen
key(AA).
Page 9

Step 7
You will need the following
•Place the tea table panel(L) upside down on the prepared surface.
•Place the completed table base on to part(L), as shown below.
•Prepare 4x bolt R sets by threading bolt(R) through washer(U).
•Secure the frame to the panel with bolt R sets and fasten with
Allen key (AA).
Page 10

Step 8
You will need the following
•Place the completed table frame on the base and back plate(H),as
shown below.
•Prepare 2x bolt R sets by threading bolt(R) through washer(U)
•Secure the table to the chair with a bolt R set on either side of the
table, as shown below. Fasten with Allen key(AA).
N.B. Tabl top not shown in illustration
Page 11

Step 9
You will need the following
•Secure the bottom of the table to part(H)
•Insert bolt(T) down through the table as shown below. Insert
plastic washer(P) in-between the table and the seat. Concave side
up, flat side down. Lock the other side the bolt with washer(U)
and nut(V), as shown below.
•Fasten with Allen key(AA) and wrench(BB).
N.B. Table top not shown in illustration
Page 12

Assembly is complete
