HARDTOP GAZEBO
MODEL #GF-18S112B
Español p. 18

2
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY
A Supporting Post 4
Z Corner Cover
4
B Decor Moulding 4
AB Roof Corner Cover
4
C Post Plate Cover 4
AG Stake
4
D Base Plate 4 4
E Left Crossbar 4 4
F Right Crossbar 4 16
G Support Bracket 8
K Outer Connector
N Right Eave Pole
O Left Eave Pole
ON
AB
K
G
F
E
D
A
AA
A
B
BBB
C
CC
C
D
DD
E
E
F
K
K
G
G
G
F
AB
AB
AB
O
ON
Z
ZZ
Z
N
AG
AG
AG AG

3
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY PART DESCRIPTION QUANTITY
H Corner Roof Pole 4 U Air Vent Screen 4
I Center Roof Pole 4 V Center Roof Cover 4
J Fixed Bracket 4 W Corner Roof Cover 4
Roof Support Bracket 1 4 X Roof Hook 1
M Roof Support Bracket 2 4 Y Roof Connector 1
P Roof Panel 1 4 AC Air Vent Roof Panel 4
Q Roof Panel 2 4 AD Air Vent Roof Cover 4
R Roof Panel 3 4 AE Roof Connector 1
S Roof Panel 4 4 AF Weather Vane 1
T Air Vent Support 4
L
H
J
L
M
P
Q
R
S
T
UV
W
X
Y
AC
AD
AF
AE
H
I
I
I
M
VV
W
L
L
M
H
I
T
AC

4
HARDWARE CONTENTS (shown actual size)
Qty. 2
Hex Wrench
II
Qty. 2
Spanner
JJ
Bolt 1
Qty. 80 + 8 Extra
AA
Qty. 8 + 2 Extra
Bolt 3
CC
Qty. 4 + 2 Extra
Bolt 2
BB DD
Qty. 8 + 2 Extra
Bolt 4
FF
Qty. 24 + 4 Extra
Metal Washer
GG
Qty. 44 + 6 Extra
Plastic Washer
HH
Qty. 8 + 2 Extra
Plastic Cap
Qty. 8 + 2 Extra
Bolt Nut
EE

5
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble or install the product.
•Three to four people are needed for assembly
•Maximum load for the roof hook: 50 lbs.
WARNING:
•Small parts like washers may pose a choking hazard to young children.
CAUTION
•If heavy snow occurs, clear snow load from roof, and check for damage before continued use.
•Fasten the base to the deck (wood or concrete) for item stability.
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts with package
contents list and hardware contents list. If any part is missing or damaged, do not attempt to
assemble the product.
Estimated Assembly Time: 3 - 4 hours
Tools Required for Assembly (not included): 6ft. Ladder
Tools Required for Assembly (included): Hex Wrench and Spanner
INSTALLATION INSTRUCTIONS
1. Insert the post plate cover (C) into the supporting
post (A). Fit the base plate (D) underneath the
supporting post (A). Insert two bolts (AA) into the
supporting post (A) and secure to the base plate (D)
using the hex wrench (II), but do not overtighten.
Slide the post plate cover (C) down into place.
Insert the decor moulding (B) into the supporting
post (A).
Repeat this step for the remaining supporting posts
(A), decor mouldings (B), post plate covers (C) and
base plates (D).
Hardware Used
AA Bolt 1 x 8
II Hex Wrench x 1
1
A
•Paint on this gazebo might peel if it is not handled properly.
•Do not use power tools to assemble this product.
•Snow load capacity: Can hold up to 2,000 lbs. (max).
B
D
C
AA
A
C
AA
D

6
INSTALLATION INSTRUCTIONS
2. Insert left crossbar (E) and right crossbar (F) into
outer connector (K). Secure together using bolts (CC)
and bolt nut (EE) through metal washers (FF). Tighten
securely with the hex wrench (II) and spanner (JJ).
Repeat the procedure for the other left crossbars (E)
and right crossbars (F).
Hardware Used
CC Bolt 3 x 8
EE Bolt Nut x 8
II Hex Wrench x 1
JJ Spanner x 1
3. Insert assembled crossbar set (E, F) onto assembled
supporting post (A). Secure together using bolts (AA)
and tighten securely with the hex wrench (II).
Hardware Used
AA Bolt 1 x 2
II Hex Wrench x 1
3
2
FF Metal Washer
HH Plastic Cap x 8
x 16
E
E
K
F
F
K
CC EE HH
FF
FE
A
A
A
AA F
FF

7
INSTALLATION INSTRUCTIONS
4. Secure another assembled crossbar set (E, F) with
another supporting post (A) together using bolt 1
(AA) and tighten securely with hex wrench (II).
5. 5
4
Hardware Used
AA Bolt 1 x 2
II Hex Wrench x 1
F
EE
F
A
E
F
AA
E
E
F
A
E
F
AA
E
F
Secure another assembled crossbar set (E, F) with
another supporting post (A) together using bolt 1
(AA) and tighten securely with hex wrench (II).
Hardware Used
AA Bolt 1 x 2
II Hex Wrench x 1

8
INSTALLATION INSTRUCTIONS
6. Secure remaining assembled crossbar and supporting
post (A) together using bolt (AA) and tighten securely
with wrench (II).
Attention: Please measure the distance between
supporing posts and keep the dimensions as shown.
7. Insert the bottom of support bracket (G) into
supporting post (A), then use bolts (DD) through
metal washer (FF) and assembled crossbar (E, F) to
secure support bracket (G). Tighten securely with hex
wrench (II).
Repeat the procedure for other support brackets (G).
Hardware Used
DD Bolt 4 x 8
II Hex Wrench x 1
7
6
Hardware Used
AA Bolt 1 x 2
II Hex Wrench x 1
DD
FF
F
A
E
G
G G G
x 8
FF Metal Washer
F
EE
F
A
AA E
F
155.6”
155.6”
124”
124”

9
INSTALLATION INSTRUCTIONS
8. Insert corner cover (Z) into supporting post (A) as
shown, then secure with crossbar set (E, F).
Repeat the procedure for other corner covers (Z).
9. Secure fixed brackets (J) together as shown.
8
E
E
E
F
F
F
E
A
Z
Z
F
A
9
J
J
J
J

10
INSTALLATION INSTRUCTIONS
10. Insert center roof pole (I) into assembled fixed bracket
set (J), then secure another end of center roof pole (I)
with assembled crossbar set (E, F).
11. 11
10
I
J
E
F
I
I
E
F
JI
E
F
EF
I
I
I
Insert center roof pole (I) into assembled fixed bracket
set (J), then secure another end of center roof pole (I)
with assembled crossbar set (E, F).

11
INSTALLATION INSTRUCTIONS
neht,)Y(rotcennocfoorotni)T(troppustnevriatresnI.31
secure another end of air vent support (T) with corner
roof pole (H) into fixed bracket (J) using bolt 1 (AA).
Tighten securely with hex wrench (II).
13
Hardware Used
AA Bolt 1 x 4
II Hex Wrench x 1
tekcarbdexifdelbmessaotni)H(elopfoorrenroctresnI.21
set (J), then secure another end of corner roof pole (H)
with assembled crossbar set (E, F) and supporting
post (A) using bolt 1 (AA) and plastic washer (GG).
Tighten securely with hex wrench (II).
Repeat the procedure for other corner roof poles (H).
H
AA
GG
H
H
J
H
H
A
12
Hardware Used
II Hex Wrench x 1
AA Bolt 1 x 4
x 4
GG Plastic Washer
T
H
AA
T
T
T
Y
Y
H
H
H
J
J

12
INSTALLATION INSTRUCTIONS
.51
(H) using bolt 1 (AA), then secure another end of
roof support bracket 2 (M) with left eave pole (O).
Secure roof support bracket 1 (L) with corner roof pole
(H) using bolt 1 (AA), then secure another end of
roof support bracket 1 (L) with right eave pole (N).
Repeat the procedure for other roof support bracket
(L) and (M).
15
Hardware Used
AA Bolt 1 x 16
II Hex Wrench x 1
,)H(elopfoorrenrocotni)O(elopevaetfelehttresnI.41
insert the right eave pole (N) into corner roof pole (H),
then secure another side of left eave pole (O) and
right eave pole (N) with center roof pole (I) using
bolt 1 (AA). Tighten securely with hex wrench (II).
Repeat the procedure for other left eave poles (O)
and right eave poles (N).
Hardware Used
AA Bolt 1 x 4
II Hex Wrench x 1
14
N
N
O
M
F
H
L
H
L
MAA
H
L
AA
L
N
Secure roof support bracket 2 (M) with corner roof pole
AA N
O
H
H
I
O
H
H
O
N
N
I

13
INSTALLATION INSTRUCTIONS
tif,)EA(rotcennocfoorhtiwenavrehtaeweruceS.71
roof hook (X) underneath the air vent roof and secure
with roof connector (AE).
17 AF
AE
X
16. Insert air vent roof panel (AC) into air vent support (T),
then put air vent roof cover (AD) onto the air vent roof
panel (AC) and secure by bolt 1 (AA) and plastic
washer (GG). Tighten securely with hex wrench (II).
16
Hardware Used
II Hex Wrench x 1
AA Bolt 1 x 4
x 4
GG Plastic Washer
T
AC
AC
AC AC
AA
GG
AD
AC

14
INSTALLATION INSTRUCTIONS
slenapfoorotno)V(revocfoorretnececalP.91
(P, Q, R, S), secure center roof cover (V) with center
roof pole (I) using bolt 2 (BB) and plastic washer (GG)
as shown, then secure center roof cover (V) with center
roof pole (I) using bolt 1 (AA) and plastic washer (GG)
as shown. Tighen securely all bolts with hex wrench (II).
Repeat procedure for other center roof covers (V).
19
18. Place roof panel 1 (P) onto center roof pole (I) and
corner roof pole (H), then place roof panel (Q) onto
center roof pole (I) and corner roof pole (H). Slide the
hole on the roof panel and roof support bracket (M),
secure roof panels (P, Q) on the roof support bracket
(M) using bolt 1 (AA).
Place roof panel 1 (R) onto center roof pole (I) and
corner roof pole (H), then place roof panel (S) onto
center roof pole (I) and corner roof pole (H). Slide the
hole on the roof panel and roof support bracket (L),
secure roof panels (R, S) on the roof support bracket
(L) using bolt 1 (AA).
Repeat procedure for other roof panels (P, Q, R, S).
Hardware Used
II Hex Wrench x 1
AA Bolt 1 x 16
x 16
GG Plastic Washer
18
GG
Q
AA
PS
R
L
GG
AA
R
S
L
Hardware Used
II Hex Wrench x 1
AA Bolt 1 x 4
x 8
GG Plastic Washer
BB Bolt 2 x 4
V
AA
GG
BB
VJ
R
P
QS

15
INSTALLATION INSTRUCTIONS
sa)T(troppustnevriahtiw)U(neercstnevriaeruceS.20.
shown.
Repeat the procedure for other air vent screens (U).
21. Insert corner roof cover (W) onto air vent support (T)
and secure corner roof cover (W) with corner roof pole
(H) using bolt 1 (AA) and plastic washer (GG), then
secure roof corner cover (AB) with corner roof pole (H)
using bolt 1 (AA) and washer (GG). Tighten securely
all bolts with hex wrench (II).
Repeat procedure for other corner roof covers (W)
and roof corner covers (AB).
21
20 T
UU
T
TT
U
Hardware Used
II Hex Wrench x 1
AA Bolt 1 x 12
x 12
GG Plastic Washer
H
AB
T
GG
AA
W
W
AB
W
AA
W
AB
GG

16
INSTALLATION INSTRUCTIONS
etalpesabehtniselohehthguorht)GA(sekatstresnI.22
(D) and into the ground to secure the gazebo. 22
AG
C
D
A
CARE AND MAINTENANCE
•Slight pinholes will be present in the tubing, which is customary of original steel work and should
not be considered a defect.
•Wash with soap and water.
•Before storing, remove leaves and dirt, drain all water that may have accumulated in or around the
frame. If not drained properly, water can cause freeze damage including bursting or cracking of
metal tubing.
3 years.

II JJ
AA CCBB DD FF GG HH EE
AA
BB
CC
DD
EE
FF
GG
HH
II
875051-AA
875051-BB
875051-CC
875051-DD
875051-EE
875051-FF
875051-GG
875051-HH
875051-II
Bolt 1
Bolt 2
Bolt 3
Bolt 4
Bolt Nut
Plastic Washer
Metal Washer
Plastic Cap
Hex Wrench
JJ 875051-JJ Spanner
17
Other large components that not list in below list is also available to customers for replacement.

¿Preguntas, problemas, piezas faltantes? Antes de volver a la tienda, llame a nuestro
Departamento de Servicio al Cliente al 1-866-439-9800, de lunes a viernes de 8 a.m. a 8 p.m.,
hora estándar del Este.
18
ADJUNTE SU RECIBO AQUÍ
Número de serie____________ Fecha de compra ____________
welcoming • sophisticated • inspiring
MT
ARTÍCULO #0875051
GAZEBO CON CUBIERTA RÍGIDA
MODELO #GF-18S112B

19
CONTENIDO DEL PAQUETE
PIEZA DESCRIPCIÓN CANTIDAD PIEZA DESCRIPCIÓN CANTIDAD
A Poste de apoyo 4
Z Cubierta para esquinas
4
B Moldura decorativa 4
AB Cubierta de techo para esquina
4
CCubierta de la placa del poste 4
AG Estaca
4
D Placa de base 4 4
E Barra transversal izquierda 4 4
F Barra transversal derecha 4 16
G Abrazadera de soporte 8
K Conector exterior
N Vara del alero derecho
O Vara del alero izquierdo
ON
AB
K
G
F
E
D
A
AA
A
B
BBB
C
CC
C
D
DD
E
E
F
K
K
G
G
G
F
AB
AB
AB
O
ON
Z
ZZ
Z
N
AG
AG
AG AG

20
CONTENIDO DEL PAQUETE
PIEZA DESCRIPCIÓN CANTIDAD PIEZA DESCRIPCIÓN CANTIDAD
H Vara de techo para esquina 4 U Malla del respiradero 4
I Vara de techo central 4 V Cubierta de techo central 4
J Abrazadera fija 4 W Cubierta de techo para esquina 4
Abrazadera de soporte para techo 1 4 X Gancho del techo 1
MAbrazadera de soporte para techo 2 4 Y Conector para techo 1
P Panel de techo 1 4 AC Panel de techo del respiradero 4
Q Panel de techo 2 4 AD Cubierta de techo del respiradero 4
R Panel de techo 3 4 AE Conector para techo 1
S Panel de techo 4 4 AF Veleta 1
T Soporte del respiradero 4
L
H
J
L
M
P
Q
R
S
T
UV
W
X
Y
AC
AD
AF
AE
H
I
I
I
M
VV
W
L
L
M
H
I
T
AC
