Shadowspec SU3 User manual

SU3
Wall Mounted Umbrella
OWNERS MANUAL
Installation, Operation,
Care & Guarantee
www.shadowspec.com

fig.5
B
Afig.6
C
D
fig.2fig.1
Fixing Holes - 10mmØ Fixing Holes - 6mmØ
fig.4
fig.3
D
E
fig.7 fig.8
F
G
fig.9
10°
SU3
1000 mm
www.shadowspec.com
Assembly Instructions

Step 1() Fix the upper wall bracket on a solid wall or pol If you have any doubts consult a
profession The advised hht to x the upper wall bracket is +/- 2000mm (this heiht depends on the
hht of the operator)
Step 2() Slide the main support arm into the upper wall bracket
Step 3() Fix the lower wall bracket to the wall approximately 000mm below the upper wall bracket
Step 4 () Assemble lower wall bracket
Step 5( Lithe main support arm to its horizontal posinInstall pole support clip (A) and test
telescopic slide by liinlever (B)
Step 6() Slide the Umbrella head and pole into the end clampEnsure that the Umbrella is
orientated with the push buon (D) to the frontCheck that the t is neat, then hten knob (C)
Step 7() To open the Umbrella - Press buon (D) and pull down on the Umbrella pole so that the
Umbrella is completely openNote that the hined elbow joint (E) must be clear of the main support arm
clamp, then swinthe pole up into the pole support clip
Your SU3 Umbrella is now assembled and ready for use.
Opera�on
Telescopic Arm 1400-1800mm: To adjust the extension lenth, lilever (B) and slide the Umbrella in or
out to the desired posion
Horizontal swing: 8) Turn the handle (F) an-clockwise to loosenWhen the Umbrella is swuninto
its desired posion, turn the handle clockwise un ht to lock the Umbrella posionf the handle has
been turned a full rotaon and it is sl not ht, you can pull down on the handle so that it is in free mode
and twist it back before releasinthe handle allowinit to sprinback up and hten further
Umbrella Tilt: ()Pull on knob (G) and the Umbrella will lt 0 dees into its t posinTo set the
Umbrella back in its standard posiply pull on knob (Gn and lithe Umbrella unl it locates
back in its standard posi
Closing the Umbrella: If s extended, slide the telescopic arm back into its closed posionove the
Umbrella pole from support clip (A) and swindown so that it han vercallyPress buon (D) and push
the pole up un it clicks into its closed posinWhile sholdinonto the pole, pull knob (G) and lie the
Umbrella t inst the main support armNow lithe main support arm so that it slides partway up and
out of the upper wall bracket exposinthe pivot pointThe Umbrella can then be lowered down so that it
locates into the lower wall bracket
Always close your SUwhen not in u
www.shadowspec.com
Assembly & Installa�on

21
SECTION 2 – Umbrella Care and Maintenance
Regular care and maintenance of your umbrella is essential.
The following points will assist in keeping it looking smart and clean while also ensuring its ongoing performance and reliability.
• Always place the Protection Cover over the umbrella when not in use.
• Close and cover your umbrella in adverse conditions, this includes rain, snow, hail and high wind.
• Take care when opening or closing the umbrella, always check for obstacles first (ie: trees, ladders, furniture, people).
• Umbrella should never be left stored/collapsed for long periods while wet. Always ensure that the fabric is thoroughly dried
before storing or closing for long periods of time.
• Any early signs of mould or mildew must be removed immediately.
• Umbrella canopy is removable and fully washable. Clean fabric using cold or warm water and mild natural soap. Always
rinse thoroughly and leave to dry in the open air – do not put in clothes dryer.
• Never clean any part of the umbrella with a corrosive/abrasive product or a high pressure hose.
•Never use waterproofing or cleaning sprays on umbrella fabric without seeking appropriate advice first.
• All moving parts on the umbrella are best maintained with an annual application of dry lubricator, such as dry contact
silicone spray.
FABRIC CLEANING INSTRUCTIONS:
SHADOWSPEC Umbrella canopies are manufactured from some of the most durable and state-of-the-art marine fabrics and
threads available, including Sunbrella and Dickson-Constant acrylic fabrics, along with other proven high-performance, UV
stable materials. SHADOWSPEC Umbrella canopies should be cleaned regularly before dirt is allowed to accumulate and become
embedded in the fabric. The fabric canopy can be cleaned without being removed from the frame, however, the canopy can
be completely removed from the frame if preferred. Simply brush offany loose dirt or particles, hose down and clean with a
mild soap in lukewarm water (no more than 37° C.) Rinse thoroughly to remove soap. Allow fabric to air dry. Do not use heavy
detergents.
For stubborn stains, ‘303’ Fabric Cleaner is recommended although as with any cleaner, it is advisable to trial a small area of the
fabric first to ensure no adverse effect or discolouration occurs.
Following cleaning it is also then advisable to re-treat the fabric with a water repellency application again. We recommend ‘303’
Protectant for this purpose.
When washing or cleaning, DO NOT SUBJECT TO EXCESSIVE HEAT as the fabric will shrink. DO NOT STEAM PRESS OR DRY IN
ELECTRIC OR GAS DRYERS, but allow air to dry. In cases where the umbrella is taken down and stored during the winter season,
the canopy should be cleaned, allowed to air dry, and stored in a dry, well ventilated area. A Protection Cover should be used at
all times when umbrella is not in use to ensure the longest serviceable life.
www.shadowspec.com

22
SECTION 3 – Warranty
SHADOWSPEC umbrellas are produced with the greatest care and meet the strictest quality standards.
THE SHADOWSPEC WARRANTY
Unicrest Group Ltd guarantees that Shadowspec umbrellas that are installed in accordance with our guidelines will be free of
defects in materials and workmanship for the period of time as set out and specified in the table below:
• Damage caused by an accident, negligence, storm, wind, accumulation of water or snow, incorrect installation, not following
the maintenance instructions, incorrect use or natural ageing and fading.
• Damage caused by exposure to hazardous atmospheric situations due to industry or a high slat level.
• Small colour variations between the fabric and the colour samples and between the components and profiles, which are
caused by the manufacturing process.
• Damage to a third party.
• Repair costs by a third party.
To avoid possible wind damage, it is recommended that your SU3 umbrella be closed in wind gusts exceeding 20km/h. This is
subject to the umbrella being sufficiently anchored.
This warranty does protect against the umbrella canopy fabric becoming unserviceable due to strength loss from normal usage
and exposure conditions.
The foregoing sets out the extent of this guarantee.
Unicrest Group Ltd shall not otherwise be liable or responsible for any direct, indirect, incidental or consequential damage,
costs or losses of any kind arising out of or in connection with the umbrella or components or for any delay by Unicrest Group
Ltd or the component manufacturer in undertaking repairs or replacement under this guarantee.
Except as expressly provided herein, all other warranties, representations, conditions, undertakings, rights, duties or liabilities,
whether arising by implication of law or otherwise, are hereby expressly excluded.
If you need to make a warranty claim, please contact Unicrest Group Ltd directly or via the agent you purchased through.
New Zealand
Ph: 0800 144 155
Email: [e-mail]
www.shadowspec.co.nz
Australia
Ph: 1800 144 155
Email: [e-mail]
www.shadowspec.com.au
USA
Ph: 844 888 5577
Email: [e-mail]
www.shadowspec.com
*’Fabric’ warranty relates to the umbrella fabric canopy. Protection Cover warranty is 2 years for all models
Please note:
In the case of commercial applications, the guarantee shall be a period of 2 years or the above specified period (whichever is the
lesser) from the date of the invoice.
The obligation of Unicrest Group Ltd under this guarantee is limited to faulty manufacturing, defective materials and mechanical
failure when the umbrella has been used and cared for appropriately from the date of invoice. If an umbrella is repaired under
guarantee the guarantee period will not be extended.
Unicrest Group Ltd shall, at its sole discretion, determine whether repair or replacement is appropriate.
This warranty does not cover the following:
www.shadowspec.com
dowspec SU3
Shadowspec SU3
3 Years
Shadowspec SU6 5 Years
Umbrella Fabric Umbrella Frame
Shadowspec SU2 2 Years 4 Years
Shadowspec SU3 2 Years 2 Years
Shadowspec SU4 5 Years 3 Years
Shadowspec SU10 5 Years 3 Years
Shadowspec Serenity™ 10 Years 6 Years
Shadowspec Unity™ 10 Years 6 Years
Model
