Shadowspec SU4 User manual

SU2 Assembly Instructions cont...
Step 5: Move to the outer edge of the canopy and take hold of one of the double layered corners with
eyelets. Align this corner over one of the struts of the frame, ensuring the seam rising from that corner
runs upwards along the strut all the way to the hub (and is not twisted across multiple struts). You may
need to jostle the canopy slightly to achieve this.
Step 6: Take one of the screws provided and a Phillips head screw driver and pull down on the double
edged corner, and use the screw provided to fix the eyeleted corner to the plastic fitting at the end of
the strut (as shown below).
Step 4: To secure the canopy on the frame, take the canopy cover cap and partly thread it (clockwise)
into the upper hub fitting (as shown below). Do not tighten at this point.
SU2 Assembly Instructions
TOOLS REQUIRED: Phillips Head screwdriver
Note: you can execute this process as below with the aid of a step ladder, or simply follow the
process while laying the umbrella on a flat surface.
Step 1: Unpack both your SU2 Frame and SU2 Canopy, including removing all protective wrap on the
frame.
Step 2: Take your SU2 Canopy and unfold it. You will note it is folded inside out. Reach up inside it to
take hold of the peak-ring in the centre of the umbrella.
Step 3: While holding the peak ring, lift the nearest edge of the canopy up and over the frame, while
placing the peak ring over the upper hub fitting (as shown below) and spreading the canopy down over
the frame. This turns the canopy so the correct side is facing out, and ready for fixing to the frame.
Step 7: Move around the umbrella one strut at a time repeating Step 6 for all the remaining 7
struts/canopy corners until all the canopy corners are fixed to the frame.
Step 8: Now that the canopy is fully attached to the frame, thread the canopy cover cap till fully secure
by rotating clockwise till tight (as shown below).
www.shadowspec.com Umbrellas with disncon

Umbrella Care and Maintenance
Regular care and maintenance of your umbrella is essential.
The following points will assist in keeping it looking smart and clean while also ensuring its ongoing performance and reliability.
Note that we recommend that the SU2 umbrella be closed in windy conditions and where the umbrella is not positioned through
an umbrella table, the umbrella base should be securely bolted to the ground for maximum stability.
• Always place the Protection Cover over the umbrella when not in use.
• Close and cover your umbrella in adverse conditions, this includes rain, snow, hail and high wind.
• Take care when opening or closing the umbrella, always check for obstacles fi rst (ie: trees, ladders, furniture, people).
• Umbrella should never be left stored/collapsed for long periods while wet. Always ensure that the fabric is thoroughly dried
before storing or closing for long periods of time.
• Any early signs of mould or mildew must be removed immediately.
• Umbrella canopy is removable and fully washable. Clean fabric using cold or warm water and mild natural soap. Always
rinse thoroughly and leave to dry in the open air – do not put in clothes dryer.
• Never clean any part of the umbrella with a corrosive/abrasive product or a high pressure hose.
• Never use waterproofi ng or cleaning sprays on umbrella fabric without seeking appropriate advice fi rst.
• All moving parts on the umbrella are best maintained with an annual application of dry lubricator, such as dry contact
silicone spray.
FABRIC CLEANING INSTRUCTIONS:
SHADOWSPEC Umbrella canopies are manufactured from some of the most durable and state-of-the-art marine fabrics and
threads available, including Sunbrella and Dickson-Constant acrylic fabrics, along with other proven high-performance, UV
stable materials. SHADOWSPEC Umbrella canopies should be cleaned regularly before dirt is allowed to accumulate and become
embedded in the fabric. The fabric canopy can be cleaned without being removed from the frame, however, the canopy can
be completely removed from the frame if preferred. Simply brush off any loose dirt or particles, hose down and clean with a
mild soap in lukewarm water (no more than 37° C.) Rinse thoroughly to remove soap. Allow fabric to air dry. Do not use heavy
detergents.
For stubborn stains, ‘303’ Fabric Cleaner is recommended although as with any cleaner, it is advisable to trial a small area of the
fabric fi rst to ensure no adverse eff ect or discolouration occurs.
Following cleaning it is also then advisable to re-treat the fabric with a water repellency application again. We recommend ‘303’
Protectant for this purpose.
When washing or cleaning, DO NOT SUBJECT TO EXCESSIVE HEAT as the fabric will shrink. DO NOT STEAM PRESS OR DRY IN
ELECTRIC OR GAS DRYERS, but allow air to dry. In cases where the umbrella is taken down and stored during the winter season,
the canopy should be cleaned, allowed to air dry, and stored in a dry, well ventilated area. A Protection Cover should be used at
all times when umbrella is not in use to ensure the longest serviceable life.
Warranty
SHADOWSPEC umbrellas are produced with the greatest care and meet the strictest quality standards.
THE SHADOWSPEC WARRANTY
Unicrest Group Ltd guarantees that Shadowspec umbrellas that are installed in accordance with our guidelines will be free of
defects in materials and workmanship for the period of time as set out and specifi ed in the table below:
The obligation of Unicrest Group Ltd under this guarantee is limited to faulty manufacturing, defective materials and mechanical
failure when the umbrella has been used and cared for appropriately from the date of invoice. If an umbrella is repaired under
guarantee the guarantee period will not be extended.
Unicrest Group Ltd shall, at its sole discretion, determine whether repair or replacement is appropriate.
This warranty does not cover the following:
• Damage caused by an accident, negligence, storm, wind, accumulation of water or snow, incorrect installation, not following
the maintenance instructions, incorrect use or natural ageing and fading.
• Damage caused by exposure to hazardous atmospheric situations due to industry or a high slat level.
• Small colour variations between the fabric and the colour samples and between the components and profi les, which are
caused by the manufacturing process.
• Damage to a third party.
• Repair costs by a third party.
This warranty does protect against the umbrella canopy fabric becoming unserviceable due to strength loss from normal usage
and exposure conditions.
The foregoing sets out the extent of this guarantee.
Unicrest Group Ltd shall not otherwise be liable or responsible for any direct, indirect, incidental or consequential damage, costs
or losses of any kind arising out of or in connection with the umbrella or components or for any delay by Unicrest Group Ltd or
the component manufacturer in undertaking repairs or replacement under this guarantee.
Except as expressly provided herein, all other warranties, representations, conditions, undertakings, rights, duties or liabilities,
whether arising by implication of law or otherwise, are hereby expressly excluded.
If you need to make a warranty claim, please contact Unicrest Group Ltd directly or via the agent you purchased through.
New Zealand
Ph: 0800 144 155
Email: [email protected]o.nz
www.shadowspec.co.nz
Australia
Ph: 1800 144 155
Email: [email protected]om.au
www.shadowspec.com.au
USA
Ph: 844 888 5577
Email: [email protected]om
www.shadowspec.com
Please note:
*’Fabric’ warranty relates to the umbrella fabric canopy. Protection Cover warranty is 2 years for all models
In the case of commercial applications, the guarantee shall be a period of 2 years or the above specified period (whichever is the
lesser) from the date of the invoice.
Shadowspec SU3
3 Years 3 Years
Shadowspec SU6 5 Years 5 Years
www.shadowspec.com Umbrellas with disncon
Umbrella Fabric Umbrella Frame
Shadowspec SU2 2 Years 4 Years
Shadowspec SU3 2 Years 2 Years
Shadowspec SU4 5 Years 3 Years
Shadowspec SU10 5 Years 3 Years
Shadowspec Serenity™ 10 Years 6 Years
Shadowspec Unity™ 10 Years 6 Years
Model
