Shadowspec SU4 User manual

SU4
Cantilever Umbrella
(with 360° Rotation & Tilting functions)
OWNERS MANUAL
Installation, Operation,
Care & Guarantee
www.shadowspec.com
www.shadowspec.com

www.shadowspec.com
2
- Dimensions
- Option 1 - In-Ground Anchor
23
SECTION 1 – Installation, Assembly & Operation
STAGE 1 - Planning the Umbrella Location
Special care is needed when selecting the best location for your umbrella.
Some key points to keep in mind are:
• Ensure that the location you have chosen has the umbrella in a position where it provides
the best possible coverage over the area that you want shaded.
• Remember the SU4 has the ability to tilt and rotate 360˚so if you wish to utlise this
function ensure that you allow the necessary space around the umbrella for this.
(see Figure 1).
CONTENTS Page
SECTION 1 - Installation, Assembly & Operation
Stage 1 - Planning the Umbrella Location
Stage 2 - Selection & Installation of the Umbrella Fixing
- Option 2 - Surface Plate (Concrete Mount)
- Option 3 - Surface Plate (Timber Deck Mount)
- Option 4 - Portable Base
Stage 3 - Assembling Notes
Stage 4 - Operating the Umbrella
SECTION 2 - Umbrella Care & Maintenance
SECTION 3 - Warranty
3
5
4
6
7
8
9
10
11
15
14
ROTATES 360º
TILTS
Figure 1
CONTENTS PAGE

3
- Dimensions
- Option 1 - In-Ground Anchor
23
SECTION 1 – Installation, Assembly & Operation
STAGE 1 - Planning the Umbrella Location
Special care is needed when selecting the best location for your umbrella.
Some key points to keep in mind are:
• Ensure that the location you have chosen has the umbrella in a position where it provides
the best possible coverage over the area that you want shaded.
• Remember the SU4 has the ability to tilt and rotate 360˚so if you wish to utlise this
function ensure that you allow the necessary space around the umbrella for this.
(see Figure 1).
CONTENTS Page
SECTION 1 - Installation, Assembly & Operation
Stage 1 - Planning the Umbrella Location
Stage 2 - Selection & Installation of the Umbrella Fixing
- Option 2 - Surface Plate (Concrete Mount)
- Option 3 - Surface Plate (Timber Deck Mount)
- Option 4 - Portable Base
Stage 3 - Assembling Notes
Stage 4 - Operating the Umbrella
SECTION 2 - Umbrella Care & Maintenance
SECTION 3 - Warranty
3
5
4
6
7
8
9
10
11
15
14
ROTATES 360º
TILTS
Figure 1

www.shadowspec.com
4
5
4
DIMENSIONS:
A
B
C
F
ED
SU4 ABCDE GH
3.5m/11’5”
Octagon 3.480m/11’4” 3.595m/11’8” 2.723m/8’11” 2.125m/7’0” 2.065m/6’8” 0.880m/4’7” 0.450m/1’5”
F
0.940m/3’1”
STAGE 2 - Selection & Installation of the Umbrella Fixing
Now that you have selected a location for your umbrella the next step is to ensure that you have
ordered the correct fixing option for your umbrella. There are three options available:
• In-ground Anchor
• Surface Plate
• Portable Base
If you are unsure as to what fixing requirements will be needed for your location please contact us
(refer contact details on back cover of this manual).
Having confirmed that the fixing option you have chosen is suited to the planned location of your
umbrella you are now ready to install the fixing.
Following are four common install scenarios as a general guide for installation. Note that these
are provided as a guide only.
G
H
NOTE: All measurements are rounded and are subject to change.

5
5
4
DIMENSIONS:
A
B
C
F
ED
SU4 ABCDE GH
3.5m/11’5”
Octagon 3.480m/11’4” 3.595m/11’8” 2.723m/8’11” 2.125m/7’0” 2.065m/6’8” 0.880m/4’7” 0.450m/1’5”
F
0.940m/3’1”
STAGE 2 - Selection & Installation of the Umbrella Fixing
Now that you have selected a location for your umbrella the next step is to ensure that you have
ordered the correct fixing option for your umbrella. There are three options available:
• In-ground Anchor
• Surface Plate
• Portable Base
If you are unsure as to what fixing requirements will be needed for your location please contact us
(refer contact details on back cover of this manual).
Having confirmed that the fixing option you have chosen is suited to the planned location of your
umbrella you are now ready to install the fixing.
Following are four common install scenarios as a general guide for installation. Note that these
are provided as a guide only.
G
H
NOTE: All measurements are rounded and are subject to change.

www.shadowspec.com
6
7
6
OPTION 2 - Surface Plate (Concrete Mount)
IMPORTANT: When concreting the in-ground anchor in place, make sure not to get slurry in
the screw threads. Either apply tape over the holes on both sides of the anchor or place the
spigot bolts in the threads and withdraw them with the concrete is set. Make sure that the
in-ground anchor is perfectly level. Allow the concrete to cure for the appropriate cure time for
your area before installing the umbrella onto the fitting.
REMOVAL:
To remove your umbrella for seasonal storage or to move it to another surface plate/
in-ground anchor, simply undo the spigot bolts and remove the umbrella from the in-ground
anchor.
STEP 1 Bolt Surface Plate to Concrete
Fix the surface plate to an existing
concrete slab using concrete bolts
STEP 2 Bolt Spigot to Surface Plate
Bolt the spigot plate to the surface plate
using the five (5) spigot bolts included with
umbrella.Insert the spigot bolts downward
through the holes in the spigot plate and
screw them into the threaded holes in the
surface plate. The spigot bolts should be left
just loose enough to allow final adjustment of
the orientation of the umbrella if necessary, then once correctly orientated,fully tighten
the spigot bolts.
You are now ready to operate your umbrella!
REMOVAL:
To remove your umbrella for seasonal storage or to move it to another surface plate or
in-ground anchor, simply undo the spigot bolts and remove the umbrella from the surface
plate.
OPTION 1 - In-Ground Anchor
STEP 2 Bolt Spigot to In-ground Anchor
Once the concrete is cured, bolt the spigot plate to the in-ground anchor plate using the five (5)
spigot bolts included with umbrella. Insert the spigot bolts downward through the holes in the
spigot plate and screw them into the threaded holes in the in-ground anchor. The spigot bolts
should be left just loose enough to allow final adjustment of the orientation of the umbrella if
necessary, then once correctly orientated, fully tighten the spigot bolts.
You are now ready to operate your umbrella!
STEP 1 Preparation
The in-ground anchor needs concreting in
the ground as per the diagram (right).
Concrete Footing
In-Ground Anchor
Ground Level
Threaded holes for
bolting Spigot plate to
In-Ground Anchor
Flare at bottom
Spigot
Spigot Plate
Spigot Bolts
Spigot Plate
Spigot Bolts
Spigot
Surface Plate
Concrete
Threaded holes for bolting spigot
plate to the Surface Plate
Countersunk holes
for bolting to concrete
Concrete
Bolts
The 1.0m deep x 0.5m wide hole size
recommended assumes the terrain is
thick clay. Should the terrain be fine soil
or sand, the hole size should be increased.
The recommended installation requires
approximately .50 cubic meters of
concrete for silty or fine soil and
approximately .25 cubic meters of
concrete for heavy clay.
(M10x100mm).

7
7
6
OPTION 2 - Surface Plate (Concrete Mount)
IMPORTANT: When concreting the in-ground anchor in place, make sure not to get slurry in
the screw threads. Either apply tape over the holes on both sides of the anchor or place the
spigot bolts in the threads and withdraw them with the concrete is set. Make sure that the
in-ground anchor is perfectly level. Allow the concrete to cure for the appropriate cure time for
your area before installing the umbrella onto the fitting.
REMOVAL:
To remove your umbrella for seasonal storage or to move it to another surface plate/
in-ground anchor, simply undo the spigot bolts and remove the umbrella from the in-ground
anchor.
STEP 1 Bolt Surface Plate to Concrete
Fix the surface plate to an existing
concrete slab using concrete bolts
STEP 2 Bolt Spigot to Surface Plate
Bolt the spigot plate to the surface plate
using the five (5) spigot bolts included with
umbrella.Insert the spigot bolts downward
through the holes in the spigot plate and
screw them into the threaded holes in the
surface plate. The spigot bolts should be left
just loose enough to allow final adjustment of
the orientation of the umbrella if necessary, then once correctly orientated,fully tighten
the spigot bolts.
You are now ready to operate your umbrella!
REMOVAL:
To remove your umbrella for seasonal storage or to move it to another surface plate or
in-ground anchor, simply undo the spigot bolts and remove the umbrella from the surface
plate.
OPTION 1 - In-Ground Anchor
STEP 2 Bolt Spigot to In-ground Anchor
Once the concrete is cured, bolt the spigot plate to the in-ground anchor plate using the five (5)
spigot bolts included with umbrella. Insert the spigot bolts downward through the holes in the
spigot plate and screw them into the threaded holes in the in-ground anchor. The spigot bolts
should be left just loose enough to allow final adjustment of the orientation of the umbrella if
necessary, then once correctly orientated, fully tighten the spigot bolts.
You are now ready to operate your umbrella!
STEP 1 Preparation
The in-ground anchor needs concreting in
the ground as per the diagram (right).
Concrete Footing
In-Ground Anchor
Ground Level
Threaded holes for
bolting Spigot plate to
In-Ground Anchor
Flare at bottom
Spigot
Spigot Plate
Spigot Bolts
Spigot Plate
Spigot Bolts
Spigot
Surface Plate
Concrete
Threaded holes for bolting spigot
plate to the Surface Plate
Countersunk holes
for bolting to concrete
Concrete
Bolts
The 1.0m deep x 0.5m wide hole size
recommended assumes the terrain is
thick clay. Should the terrain be fine soil
or sand, the hole size should be increased.
The recommended installation requires
approximately .50 cubic meters of
concrete for silty or fine soil and
approximately .25 cubic meters of
concrete for heavy clay.
(M10x100mm).

www.shadowspec.com
8
9
8
REMOVAL:
To remove your umbrella for seasonal storage or to move it to another surface plate/
in-ground anchor, simply undo the spigot bolts and remove the umbrella from the
in-ground fitting.
STEP 2 Bolt Spigot to Surface Plate
Bolt the spigot plate to the surface plate using the five (5) spigot bolts included with umbrella.
Insert the spigot bolts downward through the holes in the spigot plate and screw them into
the threaded holes in the surface plate. The spigot bolts should be left just loose enough to
allow final adjustment of the orientation of the umbrella if necessary, then once correctly
orientated,fully tighten the spigot bolts.
You are now ready to operate your umbrella!
OPTION 3 - Surface Plate (Timber Deck Mount)
Portable Base
flange
Portable
Base
OPTION 4 - Portable Base
STEP 1 Assemble Portable Base
Attach all four portable base feet to base, one to each corner. Adjust each foot to get
base level.
STEP 3 Bolt Adapter Plate
Weight the Base
Bolt the adapter plate to the Portable Base flange using the four (4) bolts provided.
Insert the bolts downward through the counter-sunk holes in the adapter plate
through the Portable Base flange and tighten the nuts securely.
STEP 4 Bolt Spigot to Adapter Plate
Bolt the spigot plate to the adapter plate using the five (5) spigot bolts included with
umbrella. Insert the spigot bolts downward throught the holes in the spigot plate and
screw them into the threaded holes in the adapter plate. Make sure they are very tight.
NOTE: The Portable Base fixing option is not as secure as the permanent fixings so
extra caution needs to be taken in windy conditions.
STEP 2
Weight the base using 8/400mmx400mmx40mm concrete pavers, two layers per
quarter. For windy locations, it is advisable to add a third layer of pavers (12 in total)
similar (refer diagram above). Bolt through the surface plate decking timber and something
solid in the deck framing such as a brace or nogs (refer example in above diagram). The
length of the bolts will depend on the depth of the decking timber and brace/nog/framing.
STEP 1 Firstly fix Surface Plate to the timber deck using four stainless steel counter-sunk bolts or
EXISTING
STRUCTURAL
DECK
FASTENING
150mmx50mm
Treated Timber
Packing Supports
SPIGOT
PLATE
SPIGOT
BOLTS
SPIGOT
S/S COUNTER-SUNK
NUTS
SURFACE PLATE
19mm TIMBER
DECKING
50mm Square Washer
S/S Nylock Nuts S/S
Threaded
Rod
150mmx50mm
JOISTS 150mmx50mm JOISTS

9
9
8
REMOVAL:
To remove your umbrella for seasonal storage or to move it to another surface plate/
in-ground anchor, simply undo the spigot bolts and remove the umbrella from the
in-ground fitting.
STEP 2 Bolt Spigot to Surface Plate
Bolt the spigot plate to the surface plate using the five (5) spigot bolts included with umbrella.
Insert the spigot bolts downward through the holes in the spigot plate and screw them into
the threaded holes in the surface plate. The spigot bolts should be left just loose enough to
allow final adjustment of the orientation of the umbrella if necessary, then once correctly
orientated,fully tighten the spigot bolts.
You are now ready to operate your umbrella!
OPTION 3 - Surface Plate (Timber Deck Mount)
Portable Base
flange
Portable
Base
OPTION 4 - Portable Base
STEP 1 Assemble Portable Base
Attach all four portable base feet to base, one to each corner. Adjust each foot to get
base level.
STEP 3 Bolt Adapter Plate
Weight the Base
Bolt the adapter plate to the Portable Base flange using the four (4) bolts provided.
Insert the bolts downward through the counter-sunk holes in the adapter plate
through the Portable Base flange and tighten the nuts securely.
STEP 4 Bolt Spigot to Adapter Plate
Bolt the spigot plate to the adapter plate using the five (5) spigot bolts included with
umbrella. Insert the spigot bolts downward throught the holes in the spigot plate and
screw them into the threaded holes in the adapter plate. Make sure they are very tight.
NOTE: The Portable Base fixing option is not as secure as the permanent fixings so
extra caution needs to be taken in windy conditions.
STEP 2
Weight the base using 8/400mmx400mmx40mm concrete pavers, two layers per
quarter. For windy locations, it is advisable to add a third layer of pavers (12 in total)
similar (refer diagram above). Bolt through the surface plate decking timber and something
solid in the deck framing such as a brace or nogs (refer example in above diagram). The
length of the bolts will depend on the depth of the decking timber and brace/nog/framing.
STEP 1 Firstly fix Surface Plate to the timber deck using four stainless steel counter-sunk bolts or
EXISTING
STRUCTURAL
DECK
FASTENING
150mmx50mm
Treated Timber
Packing Supports
SPIGOT
PLATE
SPIGOT
BOLTS
SPIGOT
S/S COUNTER-SUNK
NUTS
SURFACE PLATE
19mm TIMBER
DECKING
50mm Square Washer
S/S Nylock Nuts S/S
Threaded
Rod
150mmx50mm
JOISTS 150mmx50mm JOISTS

www.shadowspec.com
10
11
10
You are now ready to operate your umbrella!
Two Person Install
The SU4 Umbrella is supplied with the spigot already bolted in place to the umbrella mast. The
spigot plate can be bolted to the In-ground Anchor/Surface Plate/Portable Base with the umbrella
left fixed to the spigot if 2 people are available for the install.
One Person Install
If not able to have 2 people on-site for the install, remove the spigot from the umbrella mast by
first removing the three small screws (refer diagram below) and slide the spigot out of the umbrella
mast. Bolt the spigot plate to the In-ground Anchor/Surface Plate/Portable Base then slide the
umbrella mast back down over the spigot and replace and fully tighten the screws (refer to
diagram below).
Once the umbrella mast is properly seated and bolted to the spigot, it will not lift off.
Use 4mm hexagon
wrench to
remove/tighten
(3) screws to frame
and internal stem
T
urning Handle
Use 4mm hexagon tool
to remove/tighten
(3) screws to
umbrella mast and
spigot
Turning Handle
STAGE 4 Operating the Umbrella
Your Shadowspec SU4 Umbrella has three positions, apart from closed:
(1) Tilt position 1
(2) Tilt position 2
(3) Horizontal position
Positions
0Closed position
1Tilt position 1 – blocks extremely angular sun
2Tilt position 2 – blocks moderately angular sun
3Horizontal position
NOTE – DO NOT USE the tilt positions in windy conditions.
0 1 2 3 POSITIONS
STAGE 3 Assembly Notes
(Alum Base Pole Cover)
An aluminium Base Pole Cover is supplied with your umbrella. It is recommended this be
assembled to the umbrella before bolting the umbrella to its fixing.
To do this, remove the spigot from the umbrella mast by first removing the three small
screws (refer diagram below) and slide the spigot out of the umbrella mast. Next slide
the aluminium Base Pole Cover over the spigot then slide the umbrella mast back down
over the spigot and replace and fully tighten the screws (refer diagram near bottom of page).
The finished result should look as per the image below.

11
11
10
You are now ready to operate your umbrella!
Two Person Install
The SU4 Umbrella is supplied with the spigot already bolted in place to the umbrella mast. The
spigot plate can be bolted to the In-ground Anchor/Surface Plate/Portable Base with the umbrella
left fixed to the spigot if 2 people are available for the install.
One Person Install
If not able to have 2 people on-site for the install, remove the spigot from the umbrella mast by
first removing the three small screws (refer diagram below) and slide the spigot out of the umbrella
mast. Bolt the spigot plate to the In-ground Anchor/Surface Plate/Portable Base then slide the
umbrella mast back down over the spigot and replace and fully tighten the screws (refer to
diagram below).
Once the umbrella mast is properly seated and bolted to the spigot, it will not lift off.
Use 4mm hexagon
wrench to
remove/tighten
(3) screws to frame
and internal stem
T
urning Handle
Use 4mm hexagon tool
to remove/tighten
(3) screws to
umbrella mast and
spigot
Turning Handle
STAGE 4 Operating the Umbrella
Your Shadowspec SU4 Umbrella has three positions, apart from closed:
(1) Tilt position 1
(2) Tilt position 2
(3) Horizontal position
Positions
0Closed position
1Tilt position 1 – blocks extremely angular sun
2Tilt position 2 – blocks moderately angular sun
3Horizontal position
NOTE – DO NOT USE the tilt positions in windy conditions.
0 1 2 3 POSITIONS
STAGE 3 Assembly Notes
(Alum Base Pole Cover)
An aluminium Base Pole Cover is supplied with your umbrella. It is recommended this be
assembled to the umbrella before bolting the umbrella to its fixing.
To do this, remove the spigot from the umbrella mast by first removing the three small
screws (refer diagram below) and slide the spigot out of the umbrella mast. Next slide
the aluminium Base Pole Cover over the spigot then slide the umbrella mast back down
over the spigot and replace and fully tighten the screws (refer diagram near bottom of page).
The finished result should look as per the image below.

www.shadowspec.com
12
13
12
TO OPEN THE SU4 UMBRELLA CANOPY
The following instructions will walk you through the sequential progression of opening the
su4 umbrella as shown in the picture on the previous page. At any time, you may
skip a position and open to the desired position.
OPEN TO THE FIRST POSITION
1.Remove the strap that holds the SU4 umbrella to the mast when in the closed position.
Take note of the “parachute” folding method used to fold the canopy when closed.
See TO PROPERLY FOLD THE SU4 CANOPY section for more details.
2.Make sure your slider car stop pin is in the ready or horizontal position (A).
3.Begin turning the winder handle clockwise (B) until the slider car stop pin auto locates into the
lowest predetermined hole. Continue winding until the canopy is taut. The canopy will
now be in Tilt position 1.
CAUTION: NEVER FORCE THE ARMS OPEN IF YOU FEEL RESISTANCE IN THE WINDER!
If you feel resistance in the winder, you should manually pull out a few arms to help
facilitate winding (C).
OPEN TO THE SECOND POSITION
1.Open the winder handle and turn counter-clockwisefor a few revolutions to release
the pressure.
2.With your slider car stop pin again in the ready or horizontal position, quickly pull out
the pin (making sure it stays in the horizontal position), and let it slide up the slider car
manually until the pin locates in the next predetermined hole. It may be necessary
to turn the winder a few times until the pin locates into the hole. Once the pin is
located in the hole, continue winding until the canopy is taut. The canopy will now be
in Tilt position 2.
OPEN TO THE THIRD POSITION
1.Repeat steps 1-3 outlined above.
2.The canopy will now be in the Horizontal position.
HELPFUL HINT: At any time, you may skip a position and open to the desired position
by turning the slider car stop pin parallel with the mast. In this position, the pin will NOT
auto locate as it passes over the predetermined holes. If you choose to pass the tilt
position(s) and go directly to the horizontal canopy position, you may move the pin into the
parallel position and continue winding, but be sure to turn the pin back to the horizontal
position before the horizontal canopy position is attained. If you pass the top hole, take the
tension out of the canopy and then pull the slider car stop pin down and into the top hole.
TO PROPERLY FOLD THE SU4 UMBRELLA CANOPY
The 100% solution dyed canopy will last longer if you fold it as it was packed and
shipped. This technique is similar to the way a parachute is folded and is especially
important when folding the SU4 Umbrella canopy for seasonal storage or when the SU4
Umbrella is to be left in the closed position for an extended period of time.
Using this technique at all times will significantly extend the
life of the canopy.
1.When the canopy has been fully lowered, stand in front of
the canopy structure and begin the folding process by
pulling out two panels opposite the mast.
Pull the two panels together and roll tight into the canopy.
2.Once rolled tight, pull adjacent panels out one at a time
and fold to the center, alternating sides until all the panels
have been pulled out from the arms and folded into the
center.
3.Strap the canopy to the mast with the strap.
PROTECTIVE COVER
1.Screw rods together and insert into slit of the cover.
2. Unzip cover.
3. Using the rod as a guide, slide cover over yourumbrella.
4. Pull on string to zip down your cover and tie.
THROUGH 360°/ 10 POSITIONS
There are 10 holes at the top of the internal stem.
1.Raise the turning handle (D) and rotate mast to a new
position.
TO LOWER THE SU4 UMBRELLA CANOPY
1. Turn winder handle counter-clockwise (E) for several revolutions
until all pressure is released.
2. Reach up and pull slider car stop pin (F) out of hole. Continue to
turn counter clockwise to close. If slider locks, pull out.
3. Strap the canopy to the mast with the strap.
4. Pull the Protection Cover over the closed umbrella and zip closed.
TO ROTATE THE SU4 UMBRELLA LATERALLY
A
C
B
D
F
E

13
13
12
TO OPEN THE SU4 UMBRELLA CANOPY
The following instructions will walk you through the sequential progression of opening the
su4 umbrella as shown in the picture on the previous page. At any time, you may
skip a position and open to the desired position.
OPEN TO THE FIRST POSITION
1.Remove the strap that holds the SU4 umbrella to the mast when in the closed position.
Take note of the “parachute” folding method used to fold the canopy when closed.
See TO PROPERLY FOLD THE SU4 CANOPY section for more details.
2.Make sure your slider car stop pin is in the ready or horizontal position (A).
3.Begin turning the winder handle clockwise (B) until the slider car stop pin auto locates into the
lowest predetermined hole. Continue winding until the canopy is taut. The canopy will
now be in Tilt position 1.
CAUTION: NEVER FORCE THE ARMS OPEN IF YOU FEEL RESISTANCE IN THE WINDER!
If you feel resistance in the winder, you should manually pull out a few arms to help
facilitate winding (C).
OPEN TO THE SECOND POSITION
1.Open the winder handle and turn counter-clockwisefor a few revolutions to release
the pressure.
2.With your slider car stop pin again in the ready or horizontal position, quickly pull out
the pin (making sure it stays in the horizontal position), and let it slide up the slider car
manually until the pin locates in the next predetermined hole. It may be necessary
to turn the winder a few times until the pin locates into the hole. Once the pin is
located in the hole, continue winding until the canopy is taut. The canopy will now be
in Tilt position 2.
OPEN TO THE THIRD POSITION
1.Repeat steps 1-3 outlined above.
2.The canopy will now be in the Horizontal position.
HELPFUL HINT: At any time, you may skip a position and open to the desired position
by turning the slider car stop pin parallel with the mast. In this position, the pin will NOT
auto locate as it passes over the predetermined holes. If you choose to pass the tilt
position(s) and go directly to the horizontal canopy position, you may move the pin into the
parallel position and continue winding, but be sure to turn the pin back to the horizontal
position before the horizontal canopy position is attained. If you pass the top hole, take the
tension out of the canopy and then pull the slider car stop pin down and into the top hole.
TO PROPERLY FOLD THE SU4 UMBRELLA CANOPY
The 100% solution dyed canopy will last longer if you fold it as it was packed and
shipped. This technique is similar to the way a parachute is folded and is especially
important when folding the SU4 Umbrella canopy for seasonal storage or when the SU4
Umbrella is to be left in the closed position for an extended period of time.
Using this technique at all times will significantly extend the
life of the canopy.
1.When the canopy has been fully lowered, stand in front of
the canopy structure and begin the folding process by
pulling out two panels opposite the mast.
Pull the two panels together and roll tight into the canopy.
2.Once rolled tight, pull adjacent panels out one at a time
and fold to the center, alternating sides until all the panels
have been pulled out from the arms and folded into the
center.
3.Strap the canopy to the mast with the strap.
PROTECTIVE COVER
1.Screw rods together and insert into slit of the cover.
2. Unzip cover.
3. Using the rod as a guide, slide cover over yourumbrella.
4. Pull on string to zip down your cover and tie.
THROUGH 360°/ 10 POSITIONS
There are 10 holes at the top of the internal stem.
1.Raise the turning handle (D) and rotate mast to a new
position.
TO LOWER THE SU4 UMBRELLA CANOPY
1. Turn winder handle counter-clockwise (E) for several revolutions
until all pressure is released.
2. Reach up and pull slider car stop pin (F) out of hole. Continue to
turn counter clockwise to close. If slider locks, pull out.
3. Strap the canopy to the mast with the strap.
4. Pull the Protection Cover over the closed umbrella and zip closed.
TO ROTATE THE SU4 UMBRELLA LATERALLY
A
C
B
D
F
E

www.shadowspec.com
14
15
14
SECTION 2 – Umbrella Care and Maintenance
Regular care and maintenance of your umbrella is essential.
The following points will assist in keeping it looking smart and clean while also ensuring its
ongoing performance and reliability.
• Always place the Protection Cover over the umbrella when not in use.
•Close and cover your umbrella in adverse conditions, this includes rain, snow, hail and high wind.
•Take care when opening or closing the umbrella, always check for obstacles first
(ie: trees, ladders, furniture, people).
• Umbrella should never be left stored/collapsed for long periods while wet. Always ensure that
the fabric is thoroughly dried before storing or closing for long periods of time.
•Any early signs of mould or mildew must be removed immediately.
•Umbrella canopy is removable and fully washable. Clean fabric using cold or warm water and
mild natural soap. Always rinse thoroughly and leave to dry in the open air – do not put in
clothes dryer.
• Never clean any part of the umbrella with a corrosive/abrasive product or a high pressure hose.
•Never use waterproofing or cleaning sprays on umbrella fabric without seeking appropriate
advice first.
•All moving parts on the umbrella are best maintained with an annual application of dry
lubricator, such as dry contact silicon spray.
FABRIC CLEANING INSTRUCTIONS:
SHADOWSPEC Umbrella canopies are manufactured from some of the most durable and
state-of-the-art marine fabrics and threads available, including Sunbrella and
Dickson-Constant acrylic fabrics, along with other proven high-performance, UV stable
materials. SHADOWSPEC Umbrella canopies should be cleaned regularly before dirt is
allowed to accumulate and become embedded in the fabric. The fabric canopy can be
cleaned without being removed from the frame, however, the canopy can be completely
removed from the frame if preferred. Simply brush off any loose dirt or particles, hose
down and clean with a mild soap in lukewarm water (no more than 37° C.) Rinse
thoroughly to remove soap. Allow fabric to air dry. Do not use heavy detergents.
For stubborn stains, ‘303’ Fabric Cleaner is recommended although as with any cleaner,
it is advisable to trial a small area of the fabric first to ensure no adverse effect or
discolouration occurs. Following cleaning it is also then advisable to re-treat the fabric
with a water repellency application again. We recommend ‘303’ Protectant for this
purpose.
When washing or cleaning, DO NOT SUBJECT TO EXCESSIVE HEAT as the fabric will shrink.
DO NOT STEAM PRESS OR DRY IN ELECTRIC OR GAS DRYERS, but allow air to dry. In cases
where the umbrella is taken down and stored during the winter season, the canopy should
be cleaned, allowed to air dry, and stored in a dry, well ventilated area. A Protection Cover
should be used at all times when umbrella is not in use to ensure the longest serviceable life.
SECTION 3 – Warranty
SHADOWSPEC umbrellas are produced with the greatest care and meet the strictest quality standards.
THE SHADOWSPEC WARRANTY
Unicrest Group Ltd guarantees that Shadowspec umbrellas that are installed in accordance with our guidelines will be free of
Please note:
The obligation of Unicrest Group Ltd under this guarantee is limited to faulty manufacturing, defective materials and mechanical
*’Fabric’ warranty relates to the umbrella fabric canopy. Protection Cover warranty is 2 years for all models
In the case of commercial applications, the guarantee shall be a period of 2 years or the above specified period (whichever is the
lesser)from the date of the invoice.
failure when the umbrella has been used and cared for appropriately from the date of invoice. If an umbrella is repaired under
guarantee the guarantee period will not be extended.
Unicrest Group Ltd shall, at its sole discretion, determine whether repair or replacement is appropriate.
This warranty does not cover the following:
• Damage caused by an accident, negligence, storm, wind, accumulation of water or snow, incorrect installation, not following
the maintenance instructions, incorrect use or natural ageing and fading.
• Damage caused by exposure to hazardous atmospheric situations due to industry or a high slat level.
•
caused by the manufacturing process.
• Damage to a third party.
• Repair costs by a third party.
To avoid possible wind damage, it is recommended that your SU4 umbrella be closed in wind gusts exceeding 40km/h. This is
subject to the umbrella being sufficiently anchored.
This warranty does protect against the umbrella canopy fabric becoming unserviceable due to strength loss from normal usage
and exposure conditions.
The foregoing sets out the extent of this guarantee.
Unicrest Group Ltd shall not otherwise be liable or responsible for any direct, indirect, incidental or consequential damage,
costs or losses of any kind arising out of or in connection with the umbrella or components or for any delay by Unicrest Group
Ltd or the component manufacturer in undertaking repairs or replacement under this guarantee.
Except as expressly provided herein, all other warranties, representations, conditions, undertakings, rights, duties or liabilities,
whether arising by implication of law or otherwise, are hereby expressly excluded.
If you need to make a warranty claim, please contact Unicrest Group Ltd directly or via the agent you purchased through.
Umbrella Fabric Umbrella Frame
Shadowspec SU3 2 Years 2 Years
Shadowspec SU2 2 Years 4 Years
Shadowspec SU4 3 Years 3Years
Shadowspec SU6 5 Years 5Years
Shadowspec SU7 5 Years 5Years
Shadowspec SU8 5 Years
Shadowspec SU10 5 Years
3 Years
3 Years
New Zealand
Ph: 0800 144 155
Email: [e-mail]
www.shadowspec.co.nz
Australia
Ph: 1800 144 155
Email: [e-mail]
www.shadowspec.com.au
USA
Ph: 844 888 5577
Email: [e-mail]
www.shadowspec.com

15
15
14
SECTION 2 – Umbrella Care and Maintenance
Regular care and maintenance of your umbrella is essential.
The following points will assist in keeping it looking smart and clean while also ensuring its
ongoing performance and reliability.
• Always place the Protection Cover over the umbrella when not in use.
• Close and cover your umbrella in adverse conditions, this includes rain, snow, hail and high wind.
•Take care when opening or closing the umbrella, always check for obstacles first
(ie: trees, ladders, furniture, people).
• Umbrella should never be left stored/collapsed for long periods while wet. Always ensure that
the fabric is thoroughly dried before storing or closing for long periods of time.
•Any early signs of mould or mildew must be removed immediately.
• Umbrella canopy is removable and fully washable. Clean fabric using cold or warm water and
mild natural soap. Always rinse thoroughly and leave to dry in the open air – do not put in
clothes dryer.
• Never clean any part of the umbrella with a corrosive/abrasive product or a high pressure hose.
•Never use waterproofing or cleaning sprays on umbrella fabric without seeking appropriate
advice first.
• All moving parts on the umbrella are best maintained with an annual application of dry
lubricator, such as dry contact silicon spray.
FABRIC CLEANING INSTRUCTIONS:
SHADOWSPEC Umbrella canopies are manufactured from some of the most durable and
state-of-the-art marine fabrics and threads available, including Sunbrella and
Dickson-Constant acrylic fabrics, along with other proven high-performance, UV stable
materials. SHADOWSPEC Umbrella canopies should be cleaned regularly before dirt is
allowed to accumulate and become embedded in the fabric. The fabric canopy can be
cleaned without being removed from the frame, however, the canopy can be completely
removed from the frame if preferred. Simply brush off any loose dirt or particles, hose
down and clean with a mild soap in lukewarm water (no more than 37° C.) Rinse
thoroughly to remove soap. Allow fabric to air dry. Do not use heavy detergents.
For stubborn stains, ‘303’ Fabric Cleaner is recommended although as with any cleaner,
it is advisable to trial a small area of the fabric first to ensure no adverse effect or
discolouration occurs. Following cleaning it is also then advisable to re-treat the fabric
with a water repellency application again. We recommend ‘303’ Protectant for this
purpose.
When washing or cleaning, DO NOT SUBJECT TO EXCESSIVE HEAT as the fabric will shrink.
DO NOT STEAM PRESS OR DRY IN ELECTRIC OR GAS DRYERS, but allow air to dry. In cases
where the umbrella is taken down and stored during the winter season, the canopy should
be cleaned, allowed to air dry, and stored in a dry, well ventilated area. A Protection Cover
should be used at all times when umbrella is not in use to ensure the longest serviceable life.
SECTION 3 – Warranty
SHADOWSPEC umbrellas are produced with the greatest care and meet the strictest quality standards.
THE SHADOWSPEC WARRANTY
Unicrest Group Ltd guarantees that Shadowspec umbrellas that are installed in accordance with our guidelines will be free of
Please note:
The obligation of Unicrest Group Ltd under this guarantee is limited to faulty manufacturing, defective materials and mechanical
*’Fabric’ warranty relates to the umbrella fabric canopy. Protection Cover warranty is 2 years for all models
In the case of commercial applications, the guarantee shall be a period of 2 years or the above specified period (whichever is the
lesser)from the date of the invoice.
failure when the umbrella has been used and cared for appropriately from the date of invoice. If an umbrella is repaired under
guarantee the guarantee period will not be extended.
Unicrest Group Ltd shall, at its sole discretion, determine whether repair or replacement is appropriate.
This warranty does not cover the following:
• Damage caused by an accident, negligence, storm, wind, accumulation of water or snow, incorrect installation, not following
the maintenance instructions, incorrect use or natural ageing and fading.
• Damage caused by exposure to hazardous atmospheric situations due to industry or a high slat level.
•
caused by the manufacturing process.
• Damage to a third party.
• Repair costs by a third party.
To avoid possible wind damage, it is recommended that your SU4 umbrella be closed in wind gusts exceeding 40km/h. This is
subject to the umbrella being sufficiently anchored.
This warranty does protect against the umbrella canopy fabric becoming unserviceable due to strength loss from normal usage
and exposure conditions.
The foregoing sets out the extent of this guarantee.
Unicrest Group Ltd shall not otherwise be liable or responsible for any direct, indirect, incidental or consequential damage,
costs or losses of any kind arising out of or in connection with the umbrella or components or for any delay by Unicrest Group
Ltd or the component manufacturer in undertaking repairs or replacement under this guarantee.
Except as expressly provided herein, all other warranties, representations, conditions, undertakings, rights, duties or liabilities,
whether arising by implication of law or otherwise, are hereby expressly excluded.
If you need to make a warranty claim, please contact Unicrest Group Ltd directly or via the agent you purchased through.
3 Years
Shadowspec SU6 5 Years
Umbrella Fabric Umbrella Frame
Shadowspec SU2 2 Years 4 Years
2 Years 2 Years
Shadowspec SU4 5 Years 3 Years
Shadowspec SU10 5 Years 3 Years
Shadowspec Serenity™ 10 Years 6 Years
Shadowspec Unity™ 10 Years 6 Years
Model
Shadowspec SU3
New Zealand
Ph: 0800 144 155
Email: [e-mail]
www.shadowspec.co.nz
Australia
Ph: 1800 144 155
Email: [e-mail]
www.shadowspec.com.au
USA
Ph: 844 888 5577
Email: [e-mail]
www.shadowspec.com
