MODEL: HP
OPERATING INSTRUCTION
AND PARTS MANUAL
■ HP-5030D

CONTENTS
3
Shark HP Manual • Form #97-6133 • Revised 3/02
SERIAL NUMBER:
DATE PURCHASED:
FOR SALES AND SERVICE,PLEASE CONTACT:
●●
●●
●PumpVolume At Pump Head:
HP-5030D 5 GPM
●●
●●
●Pump Pressure At Pump Head:
HP-5030D 3000 PSI
●●
●●
●BurnerType:
HP-5030D Oil Fired - 380,000 BTU/Hr.
●●
●●
●Burner Fuel Pressure:
HP-5030D 120 PSI
● ●
● ●
● Machine Dimensions: HP-5030D Length = 29" Width = 41" Height = 47"
●●
●●
●MachineVoltage:
HP-5030D 120V/1Ph
●●
●●
●Total Machine Amperage:
HP-5030D 15 Amps
●●
●●
●ShippingWeight:
HP-5030D 315 Lbs.
●●
●●
●Exhaust Stack Size:
HP-5030D 3.5" x 6.5"

4
MACHINE SPECIFICATIONS
Introduction............................................................. 5
Important Safety Information ............................... 5-6
Installation ........................................................... 6,9
ComponentIdentification, HP-5030D...................... 7
Starting and Operating Instructions ........................ 8
Preventative Maintenance ................................... 8-9
Field Service of Fuel Pump................................... 10
Maintenance and Service .................................. 9-10
HP-5030D ExplodedView .................................... 11
Burner Assembly, ExplodedView ......................... 12
ExplodedViews, Parts Lists.................................. 13
Troubleshooting ............................................... 14-15
Preventative Maintenance .................................... 16
Warranty

HP SERIES OPERATOR’S MANUAL
5
INTRODUCTION
Thank you for purchasing a Shark HP.
This manual covers the operation and maintenance of
the HP-5030D heater module. All information in this
manual is based on the latest product information avail-
able at the time of printing.
TheHP isdesignedto heatwaterfroma coldwater pres-
sure washer. Maximum water flow is 5 GPM and maxi-
mum pressure is 3000 PSI. Flow rate of 3 GPM will
achieve an average temperature of about 180°F. Tem-
perature is dependent on inlet water temperature and
water flow rate.
We reserve the right to make changes at any time with-
out incurring any obligation.
Owner/User Responsibility:
The owner and/or user must have an understanding of
the manufacturer’s operating instructions and warnings
before using this hot water generator.Warning informa-
tion should be emphasized and understood. If the op-
erator isnot fluentinEnglish,themanufacturer’s instruc-
tions and warnings shall be read to and discussed with
theoperator inthe operator’snative languagebythe pur-
chaser/owner, making sure that the operator compre-
hends its contents.
Owner and/or user must study and maintain for future
reference the manufacturers’instructions.
This manual should be considered a permanent
part of the machine and should remain with it
if machine is resold.
When ordering parts, please specify model and
serial number.
IMPORTANT SAFETY
INFORMATION
CAUTION: To reduce the risk of
injury,readoperating instructions
carefully before using.
1. Read the owner's manual thor-
oughly. Failure tofollowinstruc-
tions could cause malfunction
of the machine and result in
death,serious bodilyinjuryand/
or property damage.
2. All installations must comply with local codes.Con-
tact your electrician, plumber, utility company or the
selling distributor for specific details.
WARNING
HIGH PRESSURE
SPRAY CAN PIERCE
SKIN AND TISSUES.
To comply with the National Electrical Code (NGPA
70)andprovideadditionalprotectionfrom riskofelec-
tric shock, this hot water generator is equipped with
aUL approvedgroundfaultcircuit interrupter(GFCI)
power cord.
WARNING: Flammable liquids
can create fumes which can ig-
nite causing property damage or
severe injury.
WARNING: Do not use gasoline,
crankcase drainings or oil con-
taining gasoline, solvents or al-
cohol. Doing so will result in fire
and/or explosion.
WARNING:Do not spray flammable liquids.Operate
only where an open torch is permitted.
3. This fuel burning machine shall be installed only in
locations where combustible dusts and flammable
gases or vapors are not present.
4. In these oil burning models, use only kerosene,
No. 1 home heating fuel, or diesel fuel.
5. Risk of explosion — Do not spray flammable liquids.
Operate only where open flame or torch is permitted.
WARNING: Keep water spray,
wand and high pressure hose
away from electric wiring or fatal
electric shock may result. Read
warning tag on electrical cord.
6. To protect the operator from
electrical shock, the machine
must be electrically grounded.
It is the responsibility of the
owner to connect this machine to a UL grounded
receptacle of proper voltage and amperage ratings.
Donot spraywateron ornearelectricalcomponents.
Do not touch machine with wet hands or while
standing in water. Always disconnect power before
servicing.
WARNING: Spray gun kicks back —hold with both
hands.
7. Grip cleaning wand of attached pressure washer se-
curelywithbothhands beforestarting cleaner.Failure
to do this could result in injury from a whipping wand.
WARNING:High pressure stream
of fluid that this equipment can
produce can pierce the skin and
its underlying tissues, leading
to serious injury and possible
amputation.
READ OPERATOR’S
MANUALTHOROUGHLY
PRIORTO USE.
CAUTION
WARNING
KEEPWATER SPRAY
AWAY FROM
ELECTRICALWIRING.
WARNING
RISK OF FIRE.
DO NOT USE WITH
FLAMMABLELIQUIDS.

6 HP SERIES OPERATOR’S MANUAL
WARNING
RISK OF FIRE.
DO NOT ADD FUEL
WHEN OPERATING
MACHINE.
WARNING
RISK OF
ASPHYXIATION.
USE ONLY IN A WELL
VENTILATED AREA.
8. High pressure developed by the attached pressure
washercancause bodilyinjury ordamage.Usecau-
tion when operating. Do not point the spray gun at
anyoneor atany partof thebody.This machineis to
be used only by qualified operators.
9. Never make adjustments on machine while it is in
operation.
WARNING: High pressure spray
can cause paint chips or other
particles to become airborne and
fly at high speeds.
10. Eye safety devices must be
worn when using this equip-
ment.
WARNING: Risk of asphyxiation
—Use this product only in a well
ventilated area.
11. When the machine is work-
ing, do not cover or place in a
closedspace whereventilation
is insufficient.
WARNING: Risk of fire —Do not
add fuel when the machine is
operating or still hot.
12. Attached pressurewasherwith
a spray gun should not be op-
erated with the spray gun in
the OFF postion for extended
periods of time as this may
cause damage to the pump.
Check to make sure burner shuts off when spray
gun trigger is closed.
13. Protect from freezing.
14. To prevent a serious injury, make certain quick cou-
plerondischarge hosehaslockedbeforeusingpres-
sure washer.
15. Do notallow acids,caustic orabrasive fluidsto pass
through the HP.
16. Inlet water must be from a cold water pressure
washer (3,000 PSI maximum) .
17. Do not allow CHILDREN to operate the pressure
washer at any time.THIS MACHINE MUST BE AT-
TENDED DURING OPERATION.
18. The best insurance against an accident is precau-
tion and knowledge of the machine.
19. Do not operate this product when fatigued or under
theinfluenceofalcohol ordrugs.Keepoperatingarea
clear of all persons.
20. We will not be liable for any changes made to our
standard machines, or any components not pur-
chased from us.
21. Donot overreachor standonunstablesupport.Keep
good footing and balance at all times.
22. Follow themaintenanceinstructions specifiedin the
manual.
23. When making repairs disconnect from electrical
source.
24. Turnburneroffand openspray gunto allowwater to
flow and cool coil to 100°F before turning machine
off.
25. Before disconnecting high pressure hose from
HPwateroutlet, openspraygun torelievebackpres-
sure in hose.
CAUTION: This machine produces hot water and
must have insulated components attached to pro-
tect the operator.
INSTALLATION
Place machine in a convenient location providing ample
support, drainage and room for maintenance.
Remove bolts from pallet to foot bracket. Install rubber
feet provided as shown on page 11, item #26.
Location:
The location should protect the machine from damag-
ing environmental conditions, such as; wind, rain, and
freezing.
1. This machineshouldbe runon alevel surfacewhere
it is not readily influenced by outside sources such
as strong winds, freezing temperatures, rain, etc.It
shouldbe locatedto allowaccessibilityforrefilling of
fuel,adjustments andmaintenance.Normalprecau-
tionsshould betaken bytheoperatorof themachine
to prevent moisture from reaching the electrical
controls.
2. It isrecommended thatapartitionbe madebetween
the wash area and the machine to prevent water
spray from coming in contact with the machine. Ex-
cess moisture reaching any electric components or
electrical controls will reduce machine life and may
cause electrical shorts.
3. During installation of the machine, beware of poorly
ventilated locationsor areaswhere exhaustfansmay
cause an insufficient supply of oxygen. Sufficient
combustion can only be obtained when there is a
sufficient supply of oxygen available for the amount
of fuel being burned. If it is necessary to install a
machine in a poorly ventilated area, outside fresh
air may have to be piped to the burner and a fan
installed to bring air into the machine.
WARNING
PROTECTIVE
EYEWEAR AND
CLOTHING MUST
BE WORN.

HP SERIES OPERATOR’S MANUAL
7
Pressure Washer
3,000 PSI Maximum
(not included)
Fresh Water
Faucet
Garden Hose
(not included)
Insulated Wand
(not included)
Pressure Washer
to HP Inlet Hose
Inlet
Connection
Outlet
Connection
High Pressure Outlet Hose
(not included)
Power Cord
Diesel Fuel
Tank
Insulated
Spray Gun
(not included)
Pressure Washer Coupler
COMPONENT IDENTIFICATION
CAUTION HOT WATER:
Must use insulated
spray gun and wand.
GFCI

8 HP SERIES OPERATOR’S MANUAL
Electrical:
This machine, when installed, must be electrically
groundedin accordanceto localcodes.Check for proper
power supply using a volt meter.
Placement:
Do not locate near any combustible material. Keep all
flammable material at least 20 feet away.
Allow enough space for servicing the machine.
Local code will require certain distances from floor and
walls.(Two feet away from walls should be adequate.)
Water Source:
Thewater sourcefor thepressure washershouldbe sup-
plied by a minimum 5/8" I.D.garden hose with a city wa-
ter pressure of not less than 30 PSI. If the water supply
is inadequate, or if the garden hose is kinked, the at-
tached pressure washer will run very rough and the
burner will not fire.
Connection:
See Component Identification on page 7.
Venting:
Adding exhaust vent pipe to your oil fired burner is not
recommended because restricted air flow causes car-
bon build-up, which affects the operation, and increases
maintenance on the coil.If a stack must be used, refrain
fromusing90degreebends.Ifthepipe cannotgostraight
up then use only 45 degree bends and go to the next
size pipe.The overall pipe length must not exceed 6 feet
in length.
STARTING AND OPERATING
INSTRUCTIONS
To Start:
1. STOP!Read operator’s manual from both the pres-
sure washer and the HP before operating.Failure to
read operation and warning instructions may result
in personal injury or property damage.
2. Check fuel tank and pump oil levels on both
machines.
3. Connect garden hose to pressure washer.
CAUTION: Only use fresh water to this machine.
4. Attachhigh pressurehose betweenpressurewasher
and HP, as shown on page 7.Turn garden hose wa-
ter on. Additional adapters and couplers may be
needed to connect your brand of pressure washer
to the HP.
5. Connect the power cord into the proper electrical
outlet, then push in the GFCI reset button.
6. Start up attached pressure washer according to the
manufacturers instructions. When a steady stream
of water flows from the spray gun and wand the ma-
chine is ready for cold water cleaning.
7. For hot water washing, turn the HP burner switch to
the ON position. Adjust thermostat to desired tem-
peraturesetting.(The burner willlightautomatically.)
To Stop:
1. If using an optional detergent injector, place the de-
tergent line in a bucket of water allowing detergent
to be flushed from system.
2. TurnHP burnerswitchoff andcontinue spraying wa-
ter, allowing the water to cool.
3. After water has cooled to less than 100°F, turn the
attached pressure washer off.
4. Turn garden hose water off.Open the spray gun to
relieve remaining pressure.
5. Protect from freezing.
PREVENTATIVE
MAINTENANCE
1. Use clean fuel - kerosene, No.1 home heating fuel
ordiesel.Clean orreplace fuelfilterevery100 hours
ofoperation.Avoid watercontaminated fuel asit will
seize up the fuel pump. De-soot coils monthly. Use
an additive if diesel is being used.
2. Checktoseethat theattachedpressurewasherwa-
ter pump is properly lubricated.
3. Followwinterizinginstructionstopreventfreezedam-
age to pump and coils.
4. Always neutralize and flush detergent from system
after use.
5. If water is known tobe high inmineral content, use a
watersofteneron yourwater system,or de-scaleas
needed.
6. Do not allow acidic, caustic or abrasive fluids to be
pumped through system.
7. Always use high grade quality cleaning products.
8. Never run attached pressure washer pump dry for
extended periods of time.
9. If machine is operated with smoky or eye burning
exhaust, coils will soot up, not letting water reach
maximum operating temperature. (See section on
Maintenance and Service).
10. Never allow water to be sprayed on or near the mo-
tor or burner assembly or any electrical component.
11. Delime coils as per instructions.
It is advisable, periodically, to visually inspect the burner.
Check air inlet to make sure it is not clogged or blocked.
Wipe off any oil spills and keep equipment clean and dry.

HP SERIES OPERATOR’S MANUAL
9
Gap
1/8"
3/16"
Side View
The areas around the HP should be kept clean and free
of combustible materials, gasoline and other flammable
vapors and liquids.
The flow of ventilating air to the burner must not be
blocked or obstructed in any manner.
MAINTENANCE AND SERVICE
Winterizing Procedure:
Damage due to freezing is not covered by warranty. Ad-
hereto thefollowing coldweather procedureswhenever
the washer must be stored or operated outdoors under
freezingconditions.
During winter months, when temperatures drop below
32°F, protecting your machine against freezing is nec-
essary.Store the machine in a heated room.If this is not
possible use compressed air on the short hose end. By
injecting compressed air, all water will be blown out of
the system. Run anti-freeze through the system.
Rupture Disk:
Forsafety,each machineisequipped witharupture disk.
In the event the pressure of the water should exceed
8000PSI, therupture diskwill releasepressure andwa-
ter on to the ground.
When the disk ruptures, it will need to be replaced.
NOTE:Turn burner switch off.Then open spray gun
to cool heating coil or rupture disk will burst over
time.
AdjustableThermostat:
The adjustable thermostat can be set between 100°F to
225°F (37.8°to 108°C) . The temperature is dependent
on water flow and ambient water temperature.
Cleaning of Coils:
In alkaline water areas, lime deposits can accumulate
rapidly inside the coil pipes.This growth is increased by
theextremeheat buildup inthe coil.The bestprevention
for liming conditions is to use high quality cleaning de-
tergents. In areas where alkaline water is an extreme
problem, periodic use of Deliming Powder will remove
lime and other deposits before coil becomes plugged.
Deliming CoilsWith A Pressure Washer:
Periodic flushing of coils or optional float tank is recom-
mended.
Step 1 Fill a 5 gallon bucket with 4 gallons of water,
thenadd1lb.ofdelimingpowder.Mix thoroughly.
Step 2 Removethehigh pressurenozzlefrom thepres-
sure wand and put the wand into the bucket.
Secure the trigger on the spray gun in the open
position.
Step 3 Attach ashort section(3-5 ft.)of gardenhose to
the attached pressure washer to siphon solu-
tionfrom theelevated bucket. Startup pressure
washer, allowing solutionto bepumped through
pressurewasher andintoHPcoils andback into
the bucket. Solution should be allowed to circu-
late 2-4 hours.
Step 4 After circulatingsolutionflush entiresystemwith
freshwater.
Removal of Soot In Heating Coil:
In the heating process fuel residue, in the form of soot
deposits, may develop between the heating coil pipes
andblockair flowwhich affects burnercombustion.When
soot has been detected on visual observation, the soot
on the coil must be cleaned off.
Fuel:
Use clean fuel oil that is not contaminated with water
and debris.Replace fuel filter and drain tank every 100
hoursof operation.UseKerosene No.1orNo.2 Heating
Fuel (ASTM D306) or diesel only. NEVER use gasoline
in your burner tank.Gasoline is more combustible than
fuel oil and could result in a serious explosion.NEVER
use crankcase or waste oil in your burner. Fuel machine
malfunction could result from contamination.
Ignition Circuit:
Periodicallyinspect wires,spring contactand electrodes
for condition, security and proper spacing. (CAUTION:
10,000VOLTS)
Electrode Setting:
(See illustration below)
Electrodes Check : Periodically check wiring connections.
If necessary to adjust electrodes, use diagram.

10 HP SERIES OPERATOR’S MANUAL
Burner Nozzle:
Keep the tip free of surface deposits by wiping it with a
clean, solvent-saturated cloth, being careful not to plug
or enlarge the nozzle.For maximum efficiency, replace
the nozzle each season. Select nozzle size based on
the pressure washer you will be using:
Nozzle PressureWasher GPM
1.50 2 - 3
1.75 3 - 4
2.00 - 2.25 4 - 5
All nozzles should be 45°W
Fuel Control System:
The HP utilizes a fuel solenoid valve located on the fuel
pumpto controlthe flowof fuelto thecombustioncham-
ber.This solenoid, which is normally closed, is activated
by a flow switch when water is flowing through it.When
an operator releases the trigger on the spray gun, the
flow of water through the flow switch stops, turning off
thecurrent tothefuel solenoid.Thesolenoidthen closes,
shutting off the supply of fuel to the combustion cham-
ber. Controlling the flow of fuel in this way gives an in-
stantaneous burn or no burn situation, thereby eliminat-
ing high and low water temperatures, and combustion
smoke normally associated with machines incorporat-
ing a spray gun.Periodic inspection is recommended to
insurethat thefuel solenoidvalvefunctions properly.This
can be done by operating the machine and checking to
see that when the trigger on the spray gun is in the off
position, the burner is not firing.
Fuel Pressure Adjustment:
To adjust fuel pressure, turn the adjusting screw with a
5/32" Allen Wrench (located on the fuel pump) clock-
wise to increase, counterclockwise to decrease. Do not
exceed 200 PSI.
FIELD REPAIR INSTRUCTIONS
HP Fuel Pump:
1. Remove the13self tappingscrewswithrecess wash-
ers from the HP hood.
2. Remove louvered HP hood.(Item #22)
3. With a1/2" wrench,loosen (DO NOT REMOVE) the
two 5/16" - 18 x 1-1/2" serrated flange bolts that se-
cure the HP front panel.
4. With a 2.5 mm hex head wrench (Allen Wrench),
loosen the three set screws that hold the fuel pump
in the blower motor housing located on Idromatic
Boiler Assembly.
5. Carefully remove the fuel pump (Item #53) from the
blower motor, leaving the flexible zinc fuel line con-
nected, carefully bend the fuel line and fuel pump
away from the blower motor.
6. Locate the fuel pump/fan motor coupling.
7. Inspect the coupling for damage. The inside diam-
eter of fuel pump coupling requires flat on one side
to engage fuel pump, and the outside diameter re-
quires two male notches to engage the blower mo-
tor.
8. Perform a check to see if the fuel pump is turning
freely. Use an open end 7mm wrench or small ad-
justable wrench on fuel pump shaft.
9. Spin the fuel pump over in both directions using the
wrench for leverage. When the fuel pump is turning
freely (almost to the point you could turn it by hand)
it is ready to reinstall.
10. Align fuel pump coupler on pump shaft/fan motor.
Slide pump into fan motor. Secure pump with the
three set screws.
11. Test machine (make sure):
❑Blower motor spins
❑Fuel is on
❑Machine has power to it
❑Switch is on
❑Flow of water through machine
❑Thermostat is turned up
❑Flow switch is adjusted properly
12. When HP is operating properly, turn machine off,
tighten front panel, and install hood and 13 self tap-
ping screws with recess washers.

HP SERIES OPERATOR’S MANUAL
11
45
24
14
26
43
44
42
30
15
23
51
13
36
50
48
22
5
28
20
49
9
29
18
12
46
17
34
42
35
HP-5030D
EXPLODED VIEW
37
55
39
56
50
58 57
38
55
59 50
48
21
19

12 HP SERIES OPERATOR’S MANUAL
Inlet
Outlet
4
To Fuel
Tank
To Terminal
Block
52
33
7
2
1
3
10
42
16
32
25
40
13
11
27
42
54
6
831
53
BURNER ASSEMBLY
EXPLODED VIEW
58
50
56
38
57
41

HP SERIES OPERATOR’S MANUAL
13
HP-5030D
EXPLODED VIEW PARTS LIST
ITEM PART NO. DESCRIPTION QTY
1 2-0036 Tee, 1/2", Fem., Steel Pipe 2
2 2-0046 Tee, 1/2", Street 1
3 2-0052 Nipple, 1/2" JIC x 1/2" Pipe 1
4 2-0103 Grommet, Rubber, Nozzle Holder 2
5 2-01153 Cap, Fuel Tank, Plastic 1
6 2-1085 Hose Barb,
1/4" Barb x 1/4" ML Pipe 2
7 2-3408 Disk, Rupture Assy, 8000 PSI 1
8 2-9000 Clamp, Screw, #4 6
9 2-99031 Filter, Diesel Fuel, Disposable 1
10 4-02047716 Hose, 3/8" x 16", 2 Wire,
Pressure Loop 1
11 4-02100000 Hose, 1/4", Push-On,
Fuel Line Per Ft. 7
12 4-0303 Wheel & Tire, 4" Steel Rim 2
13 4-05088 Thermostat, Adjustable, 302F 1
14 6-01062 GFCI, 120V 15A, w/36' 12-3 Cord 1
15 6-020240 Switch, Rocker,
Carling w/Green Lens 1
16 6-02175 Switch, Flow, ST-6 1
17 6-05152 Strain Relief, Strt,
LQ Tite 3231 Small 1
18 90-20041 Collar, 5/8" Bore Shaft 3010 2
95-07102225 ▲ Axle, Hotbox 1
19 95-07100122 Bracket, Fuel Tank, Left 1
95-07100124 Bracket, Fuel Tank, Right 1
20 95-07100125 Frame Assy, Hotbox 1
90-1996 ▲ Bolt, 3/8" x 3/4", Whiz 4
90-2020 ▲ Nut, Cage, 3/8" x 12 GA 4
90-2022 ▲ Nut, Cage, 1/4" x 16 GA 4
95-07102288 ▲ Guard, Boiler/Plumbing, Hotbox1
21 10-08018 Label, Warning, Service Cord 1
22 95-07200123 Hood, Hotbox, Cover Panel 1
11-0101 ▲ Label,Warning, Pictorial 1
10-02025A ▲ Label, Hot/Caliente
w/Arrows 1
23 95-07200121 Panel, Hotbox, Front 1
6-05040 ▲ Block, Terminal, 8 Pole 1
24 95-07102287 Strap, Fuel Tank, Hotbox 2
25 91-01017 Boiler, Hotbox 1
26 2-01015 Bumber, Rubber 1" w/Bolt,
5/16" x 1-1/4" 2
27 4-02047722 Hose, 3/8" x 22", 2 Wire,
Pressure Loop 1
ITEM PART NO. DESCRIPTION QTY
28 2-01039 Grommet, Fuel Tank 1
2-011507 Tank, Encore 5 Gal Fuel 1
7-80320 Valve, Fuel Tank Shut-Off 1
2-1084 ▲ Hose Barb, 1/4" x 1/8" Pipe 2
29 95-07200120 Panel, Hotbox, Back 1
30 2-2007 Nipple, 3/8" x 3/8" NPT ST Male1
31 7-0009633 Kit, Solenoid Valve, Hotbox 1
32 2-00601 Elbow, 1/2" JIC x 3/8" Fem, 90°1
33 2-00602 Elbow, 1/2" JIC x 1/2" Fem, 90°1
34 2-2002 Coupler, 3/8" Fem, Brass 1
35 2-0031 Elbow, 3/8" Street 1
36 11-0110 Label, Hotbox, Control Panel 1
37 11-013 Label, Shark Logo, X-Large
Die Cut 2
38 7-726679 Ignition Wire / Silicon Cable 2
39 95-07102279 Bracket, Transformer Mount,
Hotbox 1
40 6-02174 Reed, Replacement, ST6 1
41 2-1046 ▲ Plug, 1/4" Countersunk 1
42 2-11039 Connector, 3/8" Anchor 2
43 11-1010 Decal, Discharge 1
44 11-1019 Decal, Inlet 1
45 2-01103 Grip, 1" Sqr, Handle 2
46 90-20061 Nut, 5/16", Cap 2
47 90-1010 Bolt, 5/16" x 1-3/4" 4
90-4001 Washer, 5/16", Flat 4
90-20012 Nut, Whiz Loc, 5/16" Flange 4
48 90-19711 Screw, 1/4" x 1/2", Whiz Loc 4
90-20291 Nut, Cage, 1/4" x 12 Ga. 4
49 90-1004 Bolt, 1/4" x 1-1/2" 2
90-4001 Washer, 5/16", Flat 2
90-200012 Nut, 1/4" Flange 2
50 90-2018 Nut, Cage, 10/32" x 16 Ga. 13
51 4-0204509 Hose, 3/8" x 9', 2 Wire,
3/8" SW, x 3/8" SOL 1
52 2-3480 Replacement, Disk 8000 PSI 1
53 7-0009 Fuel Pump 1
54 2-0051 Nipple, 1/2" JIC x 3/8" Pipe 1
55 90-1991 Screw, 10/32" x 1/2" 2
56 90-200430 Nut, 6/32", Keps 2
57 90-1987 Screw, 6/32" x 2" 2
58 7-726680 Transformer, 115V 1
59 10-08021 Label, Disconnect Pwr Supply 1
▲ Not Shown

14 HP SERIES PRESSUREWASHER OPERATOR’S MANUAL
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
BURNER WILL NOT
LIGHT Disconnected or short in electrical wiring All wire contacts should be clean and tight. No breaks in wire.
Burner motor thermal protector
tripped If tripped, check voltage, connections and extensions for cause. Check fuel pump shaft
rotation for binding, causing motor to overheat.
ON/OFF switch defective Check continuity through burner switch.
Heavy sooting on coil and burner,
can cause interruption of air flow and
shorting of electrodes
Clean as required.
Improper electrode setting Clean and test according to diagram in
operator's manual.
Fuel not reaching combustion
chamber Check fuel pump for proper flow. Check solenoid flow switch on machines with spray
gun control for proper ON/OFF flow switch.
Fuel solenoid malfunction Check by placing screwdriver inside coil then
turn machine on, open spray gun and check for
magnetic pull.
Clogged burner nozzle Replace.
Water not turned on Turn on water to activate burner flow switch.
Flow switch malfunction Remove, test for continuity and replace as
needed.
MACHINE SMOKES Improper fuel or water in fuel Drain tank and replace contaminated fuel.
Low fuel pressure Adjust fuel pump pressure to specifications.
Air leaks in fuel lines Check fuel lines for leaks or air bubbles.
Tighten or replace as needed.
Plugged or dirty burner nozzle Replace.
Faulty burner nozzle spray pattern Replace nozzle.
Heavy accumulation of soot on coils
and burner assembly Remove coils and burner assembly. Clean thoroughly.
Misaligned electrode Realign electrodes to specifications.
Fuel filter partially clogged Replace as needed.
Obstruction in smoke stack Check for insulation blockage or other foreign
objects.
Soot build-up on coils Clean coils with soot remover.
Lime build-up in coils Clean inside of coils using coil cleaner.

HP SERIES PRESSUREWASHER OPERATOR’S MANUAL
15
TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
LOW WATER
TEMPERATURE Improper fuel or water in fuel Drain fuel tank and replace with proper fuel.
Low fuel pressure Increase fuel pressure.
Weak fuel pump Check fuel pump temperature. Replace pump
if needed.
Fuel filter partially clogged Replace as needed.
Soot build up on coils Clean coils with soot remover.
Lime build up on coils Clean inside of coils using Shark's coil
cleaner.
Improper burner nozzle See specifications.
WATER
TEMPERATURE
TOO HOT
Incoming water to machine warm or
hot Lower incoming water temperature.
Fuel pump pressure too high Lower fuel pressure.
Fuel pump defective Replace fuel pump.
Detergent line sucking air Tighten all clamps.Check detergent line for
holes.
Defective high limit switch (thermostat) Replace.
Incorrect fuel nozzle size See Burner Nozzle section.
Insufficient water supplied Check GPM to machine.
Restricted water flow Check nozzle for obstruction, proper size.

16 HP SERIES OPERATOR’S MANUAL
PREVENTATIVE MAINTENANCE
MAINTENANCE SCHEDULE
Machine Clean Daily
Water Lines Check Daily
Fittings Check Daily
Fuel Filter Clean Weekly
Inlet Strainer Clean Weekly
Fuel Nozzle Clean Weekly
Fuel Tank Clean Weekly
Electrodes Adjust Monthly
Fuel Pump Strainer Clean Monthly
Electrode Wires Check Monthly

HP SERIES HEATER MODULE
WARRANTY
SHARK LIMITED NEW PRODUCTWARRANTY
PRESSURE WASHERS
WHAT THIS WARRANTY COVERS
All SHARK PRESSUREWASHERS are warranted by SHARK to the original purchaser to be free from defects in materials and
workmanship under normal use, for the periods specified below.This LimitedWarranty is subject to the exclusions shown below,
is calculated from the date of the original purchase, and applies to the original components only. Any parts replaced under this
warranty will assume the remainder of the part’s warranty period.
LIMITED LIFETIME PARTS WARRANTY:
Components manufactured by SHARK, such as frames, handles, coil wraps, float tanks, and belt guards. All heating coils will
have a three year warranty. Internal components on the oil-end of all pressure washer pumps will have a seven year warranty.
ONE YEAR PARTS WARRANTY:
All other components, excluding normal wear items as described below, will be warranted for one year on parts. Warranty on
these parts will be for one year regardless of the duration of the original component manufacturer’s part warranty.
WARRANTY PROVIDED BY OTHER MANUFACTURERS:
Motors, generators, and engines, which are warranted by their respective manufacturers, are serviced through these manufac-
turers’local authorized service centers. SHARK cannot provide warranty on these items.
WHAT THIS WARRANTY DOES NOT COVER
This warranty does not cover the following items:
1. Normal wear items, such as nozzles, guns, discharge hoses, wands, quick couplers, seals, filters, gaskets, O-rings,
packings, pistons, pump valve assemblies, strainers, belts, brushes, rupture disks, fuses, pump protectors.
2. Damage or malfunctions resulting from accidents, abuse, modifications, alterations, incorrect installation, improper
servicing, failure to follow manufacturer’s maintenance instructions, or use of the equipment beyond its stated usage
specifications as contained in the operator’s manual.
3. Damage due to freezing, chemical deterioration, scale buildup, rust, corrosion, or thermal expansion.
4. Damage to components from fluctuations in electrical or water supply.
5. Normal maintenance service, including adjustments, fuel system cleaning, and clearing of obstructions.
6. Transportation to service center, shop labor charges, field labor charges, or freight damage.
WHAT YOU MUST DO TO OBTAIN WARRANTY SERVICE
While not required for warranty service, we request that you register your SHARK pressure washer by returning the completed
registration card. In order to obtain warranty service on items, you must return the product to an Authorized LANDA or HOTSY
Dealer, freight prepaid, with proof of purchase, within the applicable warranty period.If the product is permanently installed, you
must notify your Authorized HOTSY or LANDA Dealer of the defect. The Authorized Dealer will file a claim, which must subse-
quently verify the defect. In most cases, the part must be returned to HOTSY or LANDA freight prepaid with the claim. For
warranty service on components warranted by other manufacturers, the Authorized Dealer can help you obtain warranty service
through these manufacturers’local authorized service centers.If you are unable to resolve the warranty claim satisfactorily, write
to SHARK at 4275 N.W.Pacific Rim Blvd., Camas,WA 98607, ATTN:Warranty Dept., detailing the nature of the defect, the name
of the Authorized Dealer, and a copy of the purchase invoice.
LIMITATION OF LIABILITY
SHARK’S liability for special, incidental, or consequential damages is expressly disclaimed. In no event shall SHARK’S liability
exceed the purchase price of the product in question.SHARK makes every effort to ensure that all illustrations and specifica-
tions are correct, however, these do not imply a warranty that the product is merchantable or fit for a particular purpose, or that
the product will actually conform to the illustrations and specifications. THEWARRANTY CONTAINED HEREIN IS IN LIEU OF
ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTY OF FITNESS FOR A PAR-
TICULAR PURPOSE. SHARK does not authorize any other party, including authorized Dealers, to make any representation or
promise on behalf of SHARK, or to modify the terms, conditions, or limitations in any way.It is the buyer’s responsibility to ensure
that the installation and use of SHARK products conforms to local codes. While SHARK attempts to assure that its products
meet national codes, it cannot be responsible for how the customer chooses to use or install the product.
SHARK PRESSURE WASHERS
4275 N.W. Pacific Rim Blvd. •Camas, WA 98607 •USA •1-800-771-1881

4275 N.W.Pacific Rim Blvd. •Camas,WA 98607 •1-800-771-1881
Form #97-6133 •Revised 3/02 •Printed in U.S.A.
