Sharp AF-A07CE Operation- User manual

INSTALLATION AND OPERATION
MANUAL
ROOM AIR CONDITIONER
This INSTALLATION AND OPERATION MANUAL explains the proper use of your new SHARP Air
Conditioner. Read these instructions carefully before installing or operating your air conditioner. The
INSTALLATION AND OPERATION MANUAL should be kept in a safe place for handy reference.
AF-A07CE
AF-A09CE
AF-A12CE
PAGE
CONTENTS
PART NAMES AND DIMENSIONS...... E-1
INSTALLATION INSTRUCTIONS........ E-1
OPERATION INSTRUCTIONS............. E-6
MODES OF OPERATION..................... E-7
CLEANING AND MAINTENANCE ....... E-9
BEFORE CALLING FOR SERVlCE..... E-10
ENGLISH
СТРАНИЦА
СОДЕРЖАНИЕ
НАИМЕНОВАНИЕ ЧАСТЕЙ
И РАЗМЕРЫ ........................................ R-1
ИНСТРУКЦИИ ПО УСТАНОВКЕ ....... R-1
ИНСТРУКЦИИ ПО ЭКСПЛУАТАЦИИ ... R-6
РЕЖИМЫ РАБОТЫ ............................ R-7
ОЧИСТКА И УХОД.............................. R-9
ПРЕЖДЕ ЧЕМ ОБРАЩАТЬСЯ
В СЛУЖБУ СЕРВИСНОГО
ОБСЛУЖИВАНИЯ .............................. R-10
РУССКИЙ
В настоящем РУКОВОДСТВЕ ПО УСТАНОВКЕ И ЭКСПЛУАТАЦИИ объясняется, как правильно
пользоваться Вашим новым кондиционером SHARP. Пожалуйста, перед установкой и
эксплуатациейВашего кондиционеравнимательно прочтитеэти инструкции.Это РУКОВОДСТВО
следует хранить в удобном месте для будущих консультаций.
РУКОВОДСТВО ПО УСТАНОВКЕ
И ЭКСПЛУАТАЦИИ
КОМНАТНЫЙ КОНДИЦИОНЕР

DRAIN TRAY
GASKET
GOLD SCREW (1.2cm/0.5")
GOLD SCREW (2.5cm/1")
PART NAMES AND DIMENSIONS
Front panel
Grille
Air filter (behind the grille)
Up/Down air flow adjustment louvers
Left/Right air flow adjustment louvers
Cabinet
Ventilation lever
Control panel
Stopper screws
(on left and right side)
Power cord
239
DIMENSIONS
A (mm)
B (mm)
D (mm)
E (mm)
C (mm)
33 (center 40)
583 (center 590)
350
470
255
30 (center 40)
600 (center 610)
375
560
MODEL
This equipment complies with requirements of Directives 89/336/EEC and 73/23/EEC
as amended by 93/68/EEC.
We reserve the right to change the materials and specifications without notice.
AF-A12CE
INSTALLATION INSTRUCTIONS
The long GOLD SCREW ( ) is used to secure the cabinet to the mounting frame.
The short GOLD SCREW( ) is used to secure the drain tray to the cabinet.
The DRAIN TRAY ( ) is attached to the cabinet, in case drainage is necessary in high humidity
district, or in case you do not like the splashing sound of the non-drain function.
See page E-3 for detail installation instructions.
ITEMS PACKED WITH THIS UNIT
Q'ty
9
1
1
Accessories
2
E-1
AF-A07CE, AF-A09CE
A
B
C
E
D
ENGLISH

57.0~58.0 cm
(22.4"
~22.8"
)
8~20 cm(3"~8")
38.5~39.5 cm
(15.2"~15.6")
More than 20 cm
(8")
More than 20 cm(8")
48.0~49.0 cm
(18.9"
~19.3"
)
8~20 cm(3"~8")
36.0~37.0 cm
(14.2"~14.6")
More than 20 cm
(8")
More than 20 cm(8")
E-2
INSTALLATION INSTRUCTIONS
The appliance shall be installed in accordance with national wiring regulations.
Improper connection may cause the power cord and electrical outlet to overheat or fire.
Install the air conditioner to the opening dimensions shown below.
Never install the unit where any of the air inlet is blocked.
The air conditioner should be installed with a strong external support to minimize noise and
vibration, and for the purpose of safe installation, repair, replacement and secure positioning.
Avoid installing the air conditioner where it is exposed to direct sunlight.
LOCATION
Live
(brown)
Grounding wire
(green&yellow)
More than 40cm
(16")
About 1cm
(3/8")
Air inlet
Air outlet
Air inlet
More than 20cm(8")
Air inlet
Air outlet
More than 40cm(16")
Air inlet
More than 20cm(8")
For safe, trouble free operation, connect the power
cordoftheunittoaproperlyratedindependentcircuit
with a time delay fuse or a circuit breaker. See chart
for proper amp ratings for each model.
FUSE
GROUNDING
AF-A07CE,AF-A09CE AF-A12CE
Neutral
(blue)
WARNING : THIS APPLIANCE MUST BE
GROUNDED.
Fit a disconnect switch, having a contact separation of
at least 3mm in all poles, to the electricity power line.
Connectthe brownwire ofthe powersupply cordtothe
liveterminal,andthegroundingwire(greenandyellow)
to the grounding terminal of the electrical outlet. The
remaining wire should be connected to the neutral
terminal of the electrical outlet.
POWER CABLING
Maximum Permissible
System Impedance
0.41 ( AF-A09CE )
0.25 ( AF-A12CE )
10 amp.
15 amp.
AF-A12CE
AF-A07CE, AF-A09CE

E-3
INSTALLATION INSTRUCTIONS
WARNING:
Turn off and disconnect the unit before working.
INSTALLATION
1
Unscrew the 3 stopper screws of
the cabinet. (Fig.4) Keep the front
screw and the angle as they will be
used later in step 5.
Slide the chassis out from the cabi-
net by pulling on the hand hold
located at the bottom center of the
chassis. (Fig.4)
2(1)
(2)
(2) Close the grille firmly, and remove
the front panel by pulling the front
panel at the lower corners towards
you for about 3 cm (1" ). Then lift it
up and pull it towards you. (Fig.3)
Angle Fig.4
Chassis
Front panel
Fig.3
Air filter
Front panel
Fig.2
Fig.1
Grille
(1) Open the grille (Fig.1) by gently
pulling the arrow marked portion.
Remove the air filter (Fig.2) from
the front panel.
Unscrew the screw fixing the front
panel to the chassis. (Fig.2)
Keep the screw as it will be used
later.
CAUTION:
Do not open the grille extremely wide, or provide
stress to the opened grille. The grille may come
off, or the grille shaft may get damaged. If the
grille should come off, it can be replaced. Fit one
of the grille shaft into the matching hole on the
front panel, curve the grille slightly and fit in the
other grille shaft.
Hole
Front
panel
Grille shaft
Cabinet
ENGLISH

Cutthegaskettoanappropriatelength
and stuff it into the gap around the
mounting frame and the unit to seal
outside air. (Fig.8) E-4
INSTALLATION INSTRUCTIONS
At this step, make sure the cabinet is
inclined approximately 1cm (3/8") to
the back (Fig.9).
If the cabinet is not properly inclined,
the water collected in the bottom tray
duringoperationwillnotdrainproperly
andmayflow into the roomwherethe
air conditioner is installed.
When drainage is necessary
If water drainage is necessary in high
humidity district, or if you do not like the
splashing sound of the non-drain func-
tion, remove the rubber cap on the
bottom of the chassis. Cut the rubber
cap in cross, working from the bottom
and remove the rubber pieces with a
plier.(Fig.6)
A hose of an appropriate length have to
be attached to the drain tray's drain
outlet. (Fig.7)
(3)
(1)
4(2)
Installthecabinetintotheinstallation
opening.(Fig.8)
Secure the cabinet to the mounting
frame using the 9 long gold screws.
(2.5cm/1"). (Fig.8)
Chassis
Rubber cap
Fig.6
Fig.7
Cabinet
Drain tray
Cabinet
Fig.8
Gasket
WARNING: cabinet
mounting
frame
incline backwards about 1cm
(3/8") Fig.9
Fig.5
Drain tray
Cabinet
Attach the provided drain tray to the
cabinet in case drainage becomes nec-
essary. Use the 2 short gold screws
(1.2cm/0.5") to fix it. (Fig.5)
3

E-5
INSTALLATION INSTRUCTIONS
(3)
(1)
(2)
5Slide the chassis back into the
cabinet. (Fig. 10)
Replace the front panel. (Fig.12)
Slidethecrankshaftintotheopen-
ing of the louver link at the back of
the front panel. (Fig.13)
(4)
Fig.10
Fig.11
Chassis
Angle
SlitCabinet
Louver link
Crank shaft
Front panel
Front panel back view
Fig.12 Fig.13
Grille Fig.14
Front panel
Secure the chassis to the cabinet
usingthescrewandangleremoved
in step 2. Push the angle into the
gap between the chassis and the
cabinet. Hook the angle to the slit
of the cabinet, next screw it on to
the chassis. (Fig. 11)
Openthegrilleandsecurethefront
panel with the screw removed in
step 1 (Fig.14). Replace the air
filter and close the grille firmly.
ENGLISH

INDOOR TEMP. OUTDOOR TEMP.
upper limit 32˚C D.B. 43˚C D.B.
COOLING 23˚C W.B. -
lower limit 21˚C D.B. 21˚C D.B.
15˚C W.B. -
D.B. = Dry-bulb W.B. = Wet-bulb
A built-in protective device might pre-
vent the unit from operating when used
out of this range.
Condensation might form on the air out-
let when the unit operates continuously
in the COOL mode when the humidity is
over 80 percent.
POWER CORD REPLACEMENT
WARNING: For replacement, use only the manufacturer specified power cord.
Replacemantshouldbeconductedbyaqualifiedtechnicianoraserviceman.Consultyourdealer
for detailed information concerning replacement of the power cord.
E-6
OPERATION INSTRUCTIONS
PRECAUTIONS
OPERATION INSTRUCTIONS
VENTILATE THE ROOM PERIODICALLY DURING USE, ESPECIALLY IF GAS APPLIANCES ARE
USED.
ALWAYS USE A FUSE WITH THE PROPER AMP RATING
Neverusewire, pins or anythingotherthantheproperfuse. Theproductmaybedamagedand
fire or other hazards may be resulted. In replacing a blown fuse, or if there is the problem of
constant fuse blowing, contact your dealer or our service center.
WAIT FOR 3 MINUTES BEFORE RESTARTING THE COOLING OPERATION
Wheneveryouturn theair conditionerOFF, waitfor atleast three (3) minutes before restarting
the unit.
If you restart the air conditioner within three minutes, a protective device in the unit may cause
the air conditioner to shut off. This protective device will prevent cooling operation for about 5
minutes.
POWER SUPPLY VOLTAGE
Ifthepowersuppliedtotheunitisnotwithinplus/minus10%ofthespecifiedrating,theunitmay
not function and the fuse may blow.
NOTES ON OPERATION
WATER IN THE BOTTOM TRAY
Waterwillbecollectedatthebottom trayoftheunit. Thisisnormalcondition. Watercondenses
on the evaporator coil in the front part of the unit and is channeled to the rear where it is picked
up by the condenser fan. The water is blown onto the condensor coil fins, this creates a
"splashing" sound which is normal. When the tray is filled up with water, excessive water will be
drained outside through a grooved channel in the tray.
OPERATING TEMPERATURE RANGE
IF A POWER FAILURE OCCURS DURING OPERATION, MAKE SURE TO TURN OFF THE AIR
CONDITIONER
After resumption of power supply, restart the air conditioner . If the power was off for less
than three minutes, make sure to wait for at least three minutes before restarting the unit.
If the air conditioner is not turned off during a power failure, the resumption of power supply
will cause excessive voltage. The air conditioner will be over-loaded and will not operate for
about 5 minutes.
TO STOP THE UNIT, TURN THE SELECTOR KNOB TO THE "OFF" POSITION.
NOISE LEVEL
As the surrounding environment is comparatively silent at night, noise from the air conditioner
maybe louderatnight thaninthe daytime.If youfeelthat noiseofthe air conditioneris too loud,
switch the "SELECTOR" knob to the "LOW COOL" position.

AUTO SWING
OFF
10
29
38
47
56
FAN
LOW
COOL
MED
COOL
HIGH
COOL
Super
Quiet
COOLER
WAIT THREE MINUTES BEFORE RESTARTING
THERMOSTAT
1
SELECTOR
E-7
Control panel
Auto swing switch
Thermostat knob
Selector knob
Ventilation lever
MODES OF OPERATION
NOTE FOR COOLING OPERATION
When operating the air conditioner under extremely
high outdoor temperature, set the air conditioner as
shown in the chart at right for efficient performance.
SELECTOR : HIGH COOL
VENTILATION : LEFT (CLOSED) position
THERMOSTAT : 8, 9 or 10
SELECTOR KNOB
Use to select the desired mode.
PART NAMES
Both the fan and cooling operation are off.
Thissettingcanbeusedtocirculateairwhenevercoolingisnotdesirable.
The air conditioner will perform fan operation at medium speed.
Fan operates at medium speed; cooling power at medium.
Fan and cooling at maximum power.
Cooling for sleeping comfort with low fan speed.
FAN
OFF
LOW
COOL
HIGH
COOL
MED
COOL
ENGLISH

Ventilation lever
CLOSED OPEN
E-8
Use to adjust the desired room temperature setting.
The air conditioner will automatically maintain the room temperature according to the
THERMOSTATsetting.Thehigher the numbers, the coolertheroom temperature becomes.
Experiments may be needed in order to find out the most suitable setting.
THERMOSTAT KNOB
MODES OF OPERATION
Up/Down air flow
adjustment louvers Left/Right air flow
adjustment louvers
(Auto Swing)
Use to activate automatic louver movement during LOW COOL, MED COOL and
HIGH COOL.
AUTO SWING SWITCH
Adjust the louvers to change the direction of air flow for uniform and efficient cooling of the
room. Set the AUTO SWING switch ON ( ), and the Left/Right air flow adjustment louvers
willswing continuously to provide better circulation of cool air. Thelouvers will be stopped at
thepositionwhentheswitchisturnedoff. YoucanalsousetheswitchtoadjusttheLeft/Right
air flow adjustment louvers to the desired position. Never attempt to move the Left/Right air
flow adjustment louvers manually, or manually force the louver movement to stop during
swing operation.
The AUTO SWING switch will not activate the louvers when the SELECTOR KNOB is set to
FAN.
If air in your room is stale, set the VENTILATION lever to the RIGHT (OPEN) position. This
will remove stale air from the room. The VENTILATION lever should normally be kept in the
LEFT (CLOSED) position during cooling operation for maximum cooling effect.
VENTILATION LEVER
Airflow direction can be adjusted by moving the airflow adjustment louvers upward or down-
ward. To avoid condensation on the louvers, please do not adjust these louvers to extremely
downward position during LOW COOL, MED COOL and HIGH COOL operation modes for a
long time.
UP/DOWN AIR FLOW ADJUSTMENT
