User's Manual
Slow Juicer
EJ-CP10BJ

2
Contents
3page
Safety Precautions 8page
Helpful Tips
9page
How to disassemble
and clean
10 page
Cleaning Tips
11 page
Troubleshooting
12 page
Product specification
4page
Product Components
5page
Preparations before use
6page
Assembly instruction
7page
How to use

3
Safety Precautions
Please read all safety warnings carefully before use.
This appliance is not intended for use by persons (including children) with•
reduced physical sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that the do not play with
appliance.
To avoid electric shock;•
Do not plug or unplug the unit into a power point with wet hands,
Only plug the unit into a correctly grounded power point,
Hold the power plug firmly when plugging or unplugging the unit, do not
pull on the power cord when unplugging,
Do not submerge or hold the unit under running water when cleaning,
Never use the appliance if the power cord or power plug is damaged,
To avoid damage to the power cord, avoid severe twists and bends in the
power cord.
If the unit jams and stops during use, switch the unit into reverse for around•
3 seconds, then back to “on” this should dislodge the food causing the
jam.
To avoid injury and damage, never disassemble the machine during use.•
Do not block the pulp outlet while the unit is operating.•
Use both hands when moving or lifting the unit, it weighs around 5kg.•
Keep out of reach of children.•
Never operate the machine when it is disassembled, it should only be used•
when it is fully assembled.
Never put your fingers or any body parts into the unit when it is operating,•
only use the “pusher” assist foods as required.
Do not use the product for more than 20 minutes at a time, excessive use•
can cause overheating which can lead to motor failure.
Always operate the unit on a flat firm surface suitable for kitchen•
appliances.
Do not operate the unit if;•
There are any unusual odours, heat or smoke,
The unit has been dropped or has any signs of damage,
The “squeezing” screw has been damaged
Do not attempt to make any repairs to the unit yourself, repairs should be•
carried out by a qualified person.
Do not operate the unit without fruit or vegetables for more than a few•
seconds, some parts can become damaged due to lack of lubrication.
Clean the product thoroughly after use.•

4
Product Components
Squeezing
Screw
2 Pitchers
Pusher
Cleaning
brush
Main Body
Drum
Pulp outlet
Juice outlet
Hopper

5
Preparations before use
Connect the power cord.
Rubber pad installation
Place container under each ejections (Juice/Pulp outlets).
Ensure that the rubber pad underneath the drum is closed
all the way each time before use.
Place the rubber pad until it reaches the line inside.
Place and use the appliance on a dry, stable, level, and
horizontal surface.

6
Assembly instruction
1 2
3
1. Assemble the drum on the Main Body.
Make sure the drum all the way into the
shaft of the main body.
2. Place and push the squeezing
screw into the centre of the drum.
3. Assemble the hopper onto the Drum.
Make sure ‘open dot’ ( ) on the hopper
points to ‘dot’ ( ) on the drum.
Turn the hopper clockwise until it clicks into
the drum.
Reverse the steps carefully
when disassembling.
For proper operation,
‘close dot’ ( ) on the hopper
should be aligned with ‘dot’
( ) on the drum.
IMPORTANT
Squeezing
Screw
Drum
Drum
Drum
Hopper

7
How to use
ON
REV
ON
OFF
REV
ON REV
OFF
O
O
N
N
O
O
N
N
OF
F
R
R
E
E
ON
REV
3 Operational buttons
“ON” activates the motor and starts making juice.
“REV” means reverse operation. Use this button when something is stuck.
It will remove the clogged material.
“OFF” stops the operation. Place the button at the centre to turn off the product.
Rinse every fruit or vegetables thoroughly before putting them into the machine.
After rinsing, put ingredients slowly into the machine. Use the pusher if necessary.
Remove any hard seeds from ingredients before juicing.
We recommend not to juice fruits and vegetables over 1kg at once as the
pulp may be blended into the juice.
Please ensure to turn off the machine after juicing.
Only touch the power button with dry hands.
Refrigerate the unused leftover juice.
Do not operate the product with wet hands.
Do not operate the product with empty drum.
ON
REV

8
Helpful Tips
Do not use the product
longer than 20 minutes.
Remove any hard seeds
from fruit or vegetables.
Do not insert too much
ingredients./
Do not insert ingredients
too fast.
Otherwise, serious product damage may
occur.
Otherwise, serious product damage
especially on the screw may occur.
Otherwise, serious product damage
may occur.
Otherwise, juice may leak upwards.
Do not use any utensils
other than the pusher.
When the machine is inoperable, follow the next steps.
1. Turn off the machine.
2. Run the product in “REV” mode for a few seconds.
3. Operate the product again.
4. If “REV” mode is inoperable, turn off and disassemble the product.
Then, reassemble the product by instructions.
5. Activate the product again.
ON
OFF
REV
The power button should be completely dried
before the product is operated.
ON
OFF
REV

9
How to disassemble and clean
3
1
4
2Grab and twist the hopper to unlock.
Make sure ‘open dot’ ( ) on the hopper is
aligned with ‘dot’ ( ) on the drum before pulling
off the drum.
Use the brush to clean the squeezing
screw thoroughly after operating.
Disassembly order
Hopper
Squeezing Screw
Drum
Turn machine “OFF”.
5Dry all the product parts after cleaning.
Do not dry the product parts with heating appliance.
To reduce mould build up ensure all removale parts are
cleaned throughly.
Use smooth and wet towel for
cleaning.
Do not use dishwasher or high-
temperature cleaner for cleaning.
REV

10
Cleaning Tips
You can also clean the inside of the squeezing
screw after detaching the rubber pad.
Doing so will be more hygienic.
Clean the inside and outside of the squeezing
screw with the brush provided.
- Clean and wash the product right after use.
Rinse the squeezing screw under running
water after cleaning with the brush.
The remaining pulp will be washed out.
- Do not use detergents that contain organic
solvents (solvent, thinner, etc), bleach,
chlorine, benzene or abrasives.
- Do not keep the product without cleaning
after use. Please remove pulp immediately
or within 5 minutes after juicing.
- Do not rinse the main body under running
water.
Tip
Tip
Pull out the rubber pad
gently.
Push in the rubber pad
gently in its place.

11
Troubleshooting
Users might improperly operate the product due to their unfamiliarity with how to use the
product. Check the following items to resolve such issues. If issues cannot be resolved
using these procedures, please contact the service centre.
Problem Check Possible Solutions
The product is
not working.
• Is the power cord connected? Check whether the power cord is plugged into
a 230 V to 240 V~, 50 Hz/60 Hz wall outlet.
• Is the Juicer assembled
correctly?
Assemble the product as described in this
user’s manual (refer to p. 6).
• Has the power gone off? Assemble the product as described in this
user's manual (refer to p. 6).
• Have you operated the Juicer
for over 20 minutes?
Turn off the product. Wait for a while and
reactivate the product. If you want to use the
product continuously, pause the operation for
1 hour.
The juice is too
thick or thin.
• Did you assemble the rubber
pad correctly?
Assemble the rubber pad as described in
this user’s manual (refer to p. 5 ‘Rubber pad
installation’).
• Did you use fresh ingredients?
Overripe fruits or vegetables may clog in
the motor. If you want to use the overripe
ingredients, use them after soaking in mineral
water for 10 minutes or more.
• Did you put too many
ingredients or anything else
into the machine?
Do not put too many ingredients or any liquids
into the machine.
We recommend you to clean the machine after
1 kg of juicing.
Disassemble the Drum and wash it.
The Drum cover
is too hard to
open.
• How did you open the Drum
cover?
Press the REV button and open the Drum
toward “OPEN”.
* Check directions when opening the drum.
The product
stops while in
operation.
• Did you force food into the
juicer? Do not insert too much ingredients.
• Did you put the ingredients
with hard seeds?
Press the REV button for 2 to 3 seconds and
then press the ON button again.
*After following the step above, if the
Squeezing Screw does not rotate, stop
using the product. Turn off the product,
disassemble and clean it. Then reassemble
and use your Juicer again.
The motor is
running with
loud noise and
shaking.
• Did you check that all parts
are assembled properly and in
correct position?
If the product is assembled properly, it is
normal to make noise in juicing from overripe
fruit and vegetables.
Turn the product off and clean the receptacle.
The receptacle is
vibrating in use.
• This is normal to make juice. If the product overheats, contact the local service
centre.

12
Product specication
Specification
Model Name EJ-CP10BJ
Voltage 230 V ~ 240 V
Frequency 50 Hz ~ 60 Hz
Power Consumption 150 W
RPM 32 Rpm
Elecrtical cord length 1400 mm
Motor DC Motor
Weight 4.8 kg
Dimensions
Width 150 mm
Length 194 mm
Height 435 mm
Standard usage time Less than 20 minutes continuously

13
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always
be followed including the following:
Read all instructions in this manual.•
Only use the product when you are familiar with all instruction and•
operating procedures.
This appliance is intended for household use, do not put anything•
other than foods recommended in this book into the appliance.
Unplug the unit from the power outlet when not in use and before•
cleaning.
Only use the attachments provided with the product.•
Do not use outdoors, the unit is designed for indoor use only.•
Do not use the product next to a heater or heating device.•

Congratulations on YourPurchase!
This Sharp product is warranted against faults in material and manufacture for the
period as stated in the table below.
If service is required during the warranty period, please contact your nearest Sharp
Approved Service Centre. These repairs would be carried out at no charge to the
owner, subject to the conditions specified herein.
This warranty does not extend to defects or injuries caused by or resulting from causes
not attributable to faulty parts or the manufacture of the product, including but not
limited to, defect or injury caused by or resulting from misuse, abuse, neglect, lack of
maintenance, accidental damage, improper voltage, liquid spillage, vermin infestation,
software, or any alterations made to the product which are not authorised by Sharp.
Please retain your sales documentation, as this should be produced to validate a
warranty claim. This warranty is in addition to and in no way limits, varies or excludes
any implied rights and remedies under any relevant legislation in the country of sale.
WARRANTY PERIODS
Home Theatre Projector 12 months
Audio/Home Theatre 12 months
Microwave / Steam Oven 12 months
Slow Juicer 12 months
Refrigerator 24 months
DVD/Blu-ray 12 months
Air Conditioner 60 months
Portable Air Conditioner 12 months
LCD Television 36 months
Air Purifier 12 months
Washing Machine 24 months
IMPORTANT NOTICE: This warranty applies only to products sold in Australia & New Zealand
SHARP CORPORATIONOF
AUSTRALIAPTY. LIMITED
ABN 40 003 039 405
1 Huntingwood Drive
Huntingwood NSW 2148
SHARP CORPORATIONOF
NEW ZEALANDLIMITED
59 Hugo Johnston Drive
Penrose, Auckland
WARRANTY
Consumer Electronic Products
SPform 040 (JUNE 2013)
Australian customers: Our goods come with guarantees that cannot be excluded
under the Australian Consumer Law. You are entitled to a replacement or refund
for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and the failure does not amount
to a major failure. The criteria of a major failure is defined in the Australian
Consumer Law. Should you require any assistance with a major failure please
contact Sharp Customer Care.
This warranty does not cover transportation to and from the Sharp Approved Service
Centre. Goods presented for repair may be replaced by refurbished goods of the same
type rather than being repaired. Refurbished parts may be used to repair the goods.
The repair of your goods may result in the loss of user generated data, please ensure
that you have saved this data elsewhere prior to repair.
(excluding lamps and air filters)
FOR LOCATION ENQUIRIES WITHIN
NEW ZEALAND
REGARDING YOUR LOCAL
SHARP CORPORATION OF NEW ZEALAND LIMITED
VISIT OUR WEBSITE AT
SHARP CUSTOMER SERVICES
TELEPHONE: [phone]
FACSIMILE: 09 573 0113
FOR LOCATION ENQUIRIES WITHIN
AUSTRALIA
REGARDING YOUR LOCAL
SHARP APPROVED SERVICE CENTRE
VISIT OUR WEBSITE AT
www.sharp.net.au
OR CALL SHARP CUSTOMER CARE
1300 135 022
SHARP CORPORATION OF AUSTRALIA PTY LTD
SPform019(AUGUST 2011)
(LOCAL CALL COST6APPLY WITHIN AUSTRALIA)
SHARP APPROVED SERVICE CENTRE
www.sharp.net.nz
CONTACT YOUR SELLING DEALER/RETAILER
OR CALL
SHARP
SHARP

FOR LOCATION ENQUIRIES WITHIN
NEW ZEALAND
REGARDING YOUR LOCAL
SHARP CORPORATION OF NEW ZEALAND LIMITED
VISIT OUR WEBSITE AT
SHARP CUSTOMER SERVICES
TELEPHONE: [phone]
FACSIMILE: 09 573 0113
FOR LOCATION ENQUIRIES WITHIN
AUSTRALIA
REGARDING YOUR LOCAL
SHARP APPROVED SERVICE CENTRE
VISIT OUR WEBSITE AT
www.sharp.net.au
OR CALL SHARP CUSTOMER CARE
1300 135 022
SHARP CORPORATION OF AUSTRALIA PTY LTD
SPform019(AUGUST 2011)
(LOCAL CALL COST6APPLY WITHIN AUSTRALIA)
SHARP APPROVED SERVICE CENTRE
www.sharp.net.nz
CONTACT YOUR SELLING DEALER/RETAILER
OR CALL
SHARP
SHARP

OM-EJCP10B-J31
