Sharp LC-28HM2 User manual

LC-28HM2
OPERATION MANUAL
MODE D’EMPLOI
LC-28HM2
LCD AV MONITOR
MONITEUR AV À
CRISTAUX LIQUIDES
ENGLISH FRANÇAIS
Printed in Japan
Imprimé au Japon
TINS-7335CEZZ
Printed on post-consumer recycled paper.
Imprimé sur du papier recyclé.
MANUAL DE MANEJO
MANUAL DE OPERAÇÃO
LC-28HM2
MONITOR AV LCD
MONITOR AV DE TELA
DE CRISTAL LÍQUIDO
ESPAÑOL PORTUGUÊS
Impreso en papel reciclado.
Impresso em papel reciclado pós utilização.
Impreso en Japón
Impresso no Japão
TINS-7335CEZZ
1
1

Important Information
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER.
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral triangle,
is intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product’s enclo-
sure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a
triangle is intended to alert the user
to the presence of important operat-
ing and maintenance (servicing)
instructions in the literature accom-
panying the product.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
INFORMATION
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Relocate or adjust the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
U.S.A. ONLY
WARNING: FCC Regulations state that any unauthorized changes or modifications to this equipment not
expressly approved by the manufacturer could void the user’s authority to operate this equipment.
U.S.A. ONLY
CAUTION: Use the supplied AC cord as it is.
Do not remove the core part from the AC cord, and do not change
the way of winding cables around the core part.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according
to the manufacturer’s instructions.

ENGLISH
OPERATION MANUAL
ENGLISH
Contents
Adjusting the BRIGHT Settings ............................. 22
Adjusting the PICTURE Settings ........................... 23
Adjusting the SOUND Settings .............................. 25
Adjusting the OPTION Settings ............................. 27
Notes for Connection .................................................. 29
Connecting a DVD Video Player ............................ 29
Connecting a VCR/GAME System (AV-1 and AV-2)... 29
Connecting AV Equipment
(AV INPUT 3/ AV OUT) ............................................. 29
Connecting to a Computer ......................................... 30
Connection .............................................................. 30
Computer Control of the Display........................... 31
Commands .............................................................. 32
Computer Compatibility Chart ............................... 36
Reference ..................................................................... 37
Picture Sizes ............................................................ 37
Troubleshooting ...................................................... 39
Specifications .......................................................... 40
Dimensional Drawings ........................................... 41
Using the Wall Mount Bracket (Option) ................ 43
Safety Precautions ........................................................ 2
General Information ...................................................... 4
Supplied Accessories ............................................... 4
Optional Accessories ............................................... 4
Names of Parts .......................................................... 5
Example of Application ............................................ 8
Preparation ..................................................................... 9
Connecting the Display and AVC System............... 9
Batteries for Remote Control ................................. 11
System Connection (Example) .............................. 12
Basic Operation ........................................................... 14
Turning on POWER ................................................. 14
Switching INPUT Source ........................................ 14
Adjusting BRIGHTNESS ......................................... 15
Sound VOLUME ...................................................... 15
Adjusting the Display’s Position ........................... 16
Cleaning ................................................................... 16
Adjustments to the On-Screen Display .................... 17
Menu List ................................................................. 17
Adjusting the VIEW Settings.................................. 18
Page Page

US 2
Dear SHARP Customer
Thank you for your purchase of a SHARP LCD product. To ensure safety and many
years of trouble-free operation of your product, please read the Safety Precautions
carefully before using this product.
Safety Precautions
Electricity is used to perform many useful functions, but it can also cause personal injuries and property
damage if improperly handled. This product has been engineered and manufactured with the highest
priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent
potential danger, please observe the following instructions when installing, operating and cleaning the
product. To ensure your safety and prolong the service life of your LCD product, please read the follow-
ing precautions carefully before using the product.
1. Read instructions—All operating instructions must be read and understood before the product is
operated.
2. Keep this manual in a safe place—These safety and operating instructions must be kept in a safe
place for future reference.
3. Observe warnings—All warnings on the product and in the instructions must be observed closely.
4. Follow instructions—All operating instructions must be followed.
5. Cleaning—Unplug the power cord from the AC outlet before cleaning the product. Use a damp
cloth to clean the product. Do not use liquid cleaners or aerosol cleaners.
6. Attachments—Do not use attachments not recommended by the manufacturer. Use of inadequate
attachments can result in accidents.
7. Water and moisture—Do not use the product near water, such as bathtub, washbasin, kitchen
sink and laundry tub, swimming pool and in a wet basement.
8. Stand—Do not place the product on an unstable cart, stand, tripod or table. Placing the product
on an unstable base can cause the product to fall, resulting in serious personal injuries as well as
damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a wall, be sure to follow the
manufacturer’s instructions. Use only the mounting hardware recommended by the manufacturer.
9. When relocating the product placed on a cart, it must be moved with utmost
care. Sudden stops, excessive force and uneven floor surface can cause the
product to fall from the cart.
10. Ventilation—The vents and other openings in the cabinet are designed for
ventilation. Do not cover or block these vents and openings since insufficient
ventilation can cause overheating and/or shorten the life of the product. Do not
place the product on a bed, sofa, rug or other similar surface, since they can block
ventilation openings. Do not place the product in an enclosed place such as a
bookcase or rack, unless proper ventilation is provided or the manufacturer’s
instructions are followed.
11. Power cord protection—The power cords must be routed properly to prevent people from step-
ping on them or objects from resting on them.
12. The LCD panel used in this product is made of glass. Therefore, it can break when the product is
dropped or applied with impact. Be careful not to be injured by broken glass pieces in case the
LCD panel breaks.
13. Overloading—Do not overload AC outlets or extension cords. Overloading can cause fire or
electric shock.
14. Entering of objects and liquids—Never insert an object into the product through vents or open-
ings. High voltage flows in the product, and inserting an object can cause electric shock and/or
short internal parts. For the same reason, do not spill water or liquid on the product.
15. Servicing—Do not attempt to service the product yourself. Removing covers can expose you to
high voltage and other dangerous conditions. Request a qualified service person to perform
servicing.

3US
General Information Preparation Basic Operation Adjustments to the
On-Screen Display Notes for
Connection Reference
Connecting
to a Computer
16.Repair—If any of the following conditions occurs, unplug the power cord from the AC outlet, and
request a qualified service person to perform repairs.
a.When the power cord or plug is damaged.
b.When a liquid was spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d.When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper
adjustment of controls not described in the instructions can cause damage, which often re-
quires extensive adjustment work by a qualified technician.
e.When the product has been dropped or damaged.
f. When the product displays an abnormal condition. Any noticeable abnormality in the product
indicates that the product needs servicing.
17.Replacement parts—In case the product needs replacement parts, make sure that the service
person uses replacement parts specified by the manufacturer, or those with the same characteris-
tics and performance as the original parts. Use of unauthorized parts can result in fire, electric
shock and/or other danger.
18.Safety checks—Upon completion of service or repair work, request the service technician to
perform safety checks to ensure that the product is in proper operating condition.
19.Wall or ceiling mounting—When mounting the product on a wall or ceiling, be sure to install the
product according to the method recommended by the manufacturer.
20.Heat sources—Keep the product away from heat sources such as radiators, heaters, stoves and
other heat-generating products (including amplifiers).
21.Power source—This product must operate on a power source specified on the specification label.
If you are not sure of the type of power supply used in your home, consult your dealer or local
power company. For units designed to operate on batteries or another power source, refer to the
operating instructions.
The LCD panel is a very high technology product with 2,949,120 thin film transistors, giving you
fine picture details.
Occasionally, a few non-active pixels may appear on the screen as a fixed point of blue, green
or red.
Please note that this does not affect the performance of your product.
OPTIONAL
speaker
system
Precautions when transporting the display
When transporting the display, never carry it by holding onto the speakers. Be sure to always
carry the display by holding it with two hands-one hand on each side of the display.

US 4
General Information
Supplied Accessories
Make sure the following accessories are provided with the product.
Remote Control
(×1)
AC Power Cord (×2)
Operation Manual (×1) Size AA Dry Battery
(×2) Cable Clamp (×4)
AVC System Terminal Cover (×1)
System Cable (×1)
POWER
123
12
PC
INPUT
COMPONENT
MUTE
MENU ENTER
VOL
AV INPUT
LCD MONITOR
3 pins
Plug form Cord length
12ft.5-39/64" [3.8m] (for Display)
5ft.10-55/64" [1.8m] (for AVC system)
QACCD5023CEZZ
QACCD5024CEZZ
OPERATION MANUAL
MODE D’EMPLOI
LC-28HM2
LCD AV MONITOR
MONITEUR AV À
CRISTAUX LIQUIDES
ENGLISH FRANÇAIS
Printed in Japan
Imprimé au Japon
TINS-XXXXCEZZ
Printedon post-consumer recycled paper.
Imprimésur du papier recyclé.
Optional Accessories
• Bose System Side Speaker (Model: AN-28SP2)
• Wall Mount Bracket (Model: AN-28AG1)
TINS-7335CEZZ RRMCG1619CESA UBATU0243GEZZ LHLDW1224CEZZ
GCOVA1860CE02
QCNW-5948CEZZ

5US
General Information
Names of Parts
Display
For details on the use of each control, refer to the page number indicated in the brackets.
–+ BRIGHTNESS INPUT VOL
MAIN POWER
VOL (+)/(–) button [p.15]
INPUT button [p.14] MAIN POWER switch [p.14]
BRIGHTNESS button [p.15]
Remote sensor window [p.7]
OPTIONAL
speaker system
POWER/Standby indicator [p.14]
Table stand
Display input terminal
[p.9]
Speaker cable
connection terminals
for the optional
speaker system
AC power input
terminal [p.9]
Back cover [p.9]
System cable
cover [p.9]
Top view
Front view
Rear view
General Information

US 6
General Information
AVC System
Rear view
POWER
L- -RAUDIO VIDEO S-VIDEO
AV INPUT 2
AVC SYSTEM
L- -RAUDIO VIDEO S-VIDEO
AV INPUT 2
HEAD
PHONE
12 3 4
HEAD
PHONE
NTSC / PAL / SECAM
PC INPUT
AUDIO
AV INPUT 1
S-VIDEO VIDEO R-AUDIO-L
R-AUDIO-L
COMPONENT 1
(INPUT)
DISPLAY OUTPUTRS-232C
110-120V /
220-240V~
COMPONENT 2
(INPUT)
YP
B (C B )P R (C R )
R-AUDIO-L Y P
B (C B )P R (C R )
VIDEO R-AUDIO-L
AV INPUT 3
/ AV OUT
RGB
VIDEO
VIDEO
PC INPUT
AUDIO
R-AUDIO-L
COMPONENT 1
(INPUT)
DISPLAY OUTPUTRS-232C
110-120V /
220-240V~
COMPONENT 2
(INPUT)
YP
B (C B )P R (C R )
R-AUDIO-L Y P
B (C B )P R (C R )
RGB
VIDEO
VIDEO
NTSC / PAL / SECAM
AV INPUT 1
S-VIDEO VIDEO R-AUDIO-L
VIDEO R-AUDIO-L
AV INPUT 3
/ AV OUT
1 3 470
69
852
1S-VIDEO input terminal (AV INPUT 2) [p.12]
2VIDEO input terminal (AV INPUT 2) [p.12]
3AUDIO input terminal (AV INPUT 2) [p.12]
4HEAD PHONE jack [p.8]
1AC Power input terminal [p.9]
2RS-232C input terminal [p.31]
3PC RGB input terminal [p.30]
4PC AUDIO input terminal [p.30]
5DISPLAY output terminal [p.9]
6AUDIO/VIDEO input terminal (COMPONENT1)
[p.12]
7AUDIO/VIDEO input terminal (COMPONENT2)
[p.12]
8S-VIDEO input terminal (AV INPUT 1) [p.12]
9VIDEO/AUDIO input terminal (AV INPUT 1) [p.12]
0VIDEO/AUDIO input terminal
(AV INPUT 3/AV OUT) [pp.12, 29]
*0can also be used as video/audio output
terminals.
Front view
Note
If video input and S-video input are both connected to the AV-1 input and/or AV-2 input, S-video input has
priority.

7US
General Information
POWER
123
12
PC
INPUT
COMPONENT
MUTE
MENU ENTER
VOL
AV INPUT
LCD MONITOR
1
3
4
6
8
0
q
5
7
9
2
Remote Control
1Infrared transmitter window
2POWER button [p.14]
•To switch on the power, press this button.
The POWER/Standby indicator lights up green.
•To switch off the power, press this button.
The POWER/Standby indicator lights up red.
3INPUT button [p.14]
Use this button to select an input source.
AV-1 AV-2 COMPONENT1
PC COMPONENT2
•The input source mode is skipped if the corre-
sponding input terminal is not connected with
external equipment (except “PC”).
•If you change the AV INPUT 3/AV OUT select,
you can select “AV-3”. See page 29 for details.
4AV INPUT buttons
Use these buttons to select an AV input terminal
directly.
•You can not select an input source to which
external equipment is not connected.
5COMPONENT buttons
Use these buttons to select a COMPONENT termi-
nal directly.
•You can not select an input source to which
external equipment is not connected.
6PC button
Use this button to select the PC mode.
7MUTE button
Use this button to temporarily turn off the sound.
Press the button again to turn the sound back to the
previous level.
8VOL (+)/(–) buttons [p.15]
Use these buttons to increase/decrease sound volume.
The sound volume can be adjusted in the range 0~60.
9MENU button [p.17]
Use this button to turn on/off the MENU screen.
0ENTER button [p.18]
Use this button to execute a command.
qCursor buttons [p.18]
Use these buttons to select a desired item on the
setting screen.
LCDMONITOR
Remote Control
Display
Remote sensor
window

US 8
General Information
POWER
L- -RAUDIO VIDEO S-VIDEO
AV INPUT 2
AVC SYSTEM
HEAD
PHONE
L- -RAUDIO VIDEO S-VIDEO
AV INPUT 2
HEAD
PHONE
Example of Application
Using Headphones
You can use any pair of headphones (9/64" [3.5mm] diameter mini-plug) to listen to the sound.
Commercially available
(9/64" [3.5mm] diameter mini-jack, 16 ohms)
Indicator
Note
•When connecting headphones, the sound from the display speakers is muted.
•“ ”indicator appears when a pair of headphones is connected.

9US
Preparation
Connecting the Display and AVC System
Use the supplied system cable.
1Remove the back cover of the display.
• Press both of your thumbs upwards against
the two tabs on lower side of the cover (✩)
and pull down the cover.
2Remove the system cable cover.
31Insert the system cable connectors into the
display input terminal on the display and the
output terminal on the AVC system until they
click.
2Connect the AC power cords to the AC
power inputs on the display and the AVC
system.
• After connecting the various cables, fasten
them using the provided cable clamps as
shown in the diagram below before mounting
the cover.
Hold this tab and slide the
cover downward.
2Removing the system
cable cover 3-1
3-2
3-2
6
3-1
Pass over the pins
Supplied
cable clamp
e.g. Cables from
the optional
speaker system
Rear view
Preparation

US 10
Preparation
4Mount the back cover of the display and the
system cable cover.
1Insert the four tabs on the upper side of the
cover (1) into the grooves on the rear of
the display.
2Press the two tabs on the lower side of the
cover (2) into the grooves on the rear of
the display until they produce a click sound.
3Press the two tabs on the lower side of the
cover (3) into the grooves on the rear of
the display until they produce a click sound.
5Connect desired external equipment (e.g. DVD
player: See page 12).
6Mount the supplied AVC system terminal cover.
1Align the protruding part in the center of the
cover (1) with the outside of the AVC
system.
2Align the two tabs on the lower side of the
cover (2) with the two grooves in the lower
side of the AVC system and push them
gently in.
3Align the two tabs on the upper side of the
cover (3) with the two grooves in the upper
side of the AVC system and push them
gently in.
Removing the AVC system terminal cover
1Press both of your thumbs against the
arrow marks (2 locations) on the upper side
of the cover and pull out gently to release
the tabs on the upper side.
2Now pull away the entire cover to release
the tabs on the lower side.
Note
•Before connecting the power cord, be sure to set the MAIN POWER button on the top-of display to “OFF”.
•When not using the unit for extended periods of time, be sure to always unplug the power cord.
•The display and the AVC system do not operate independently. Be sure to always plug-in both AC power cords in
order to operate the display.
•When connecting external equipment to the AVC system, be sure to always make the necessary connections before
plugging in the power cords.
•Do not remove the system cable while operating the unit. Doing so can cause a malfunction.
•Do not place anything over the ventilation openings on the top of the AVC system.
32
1
3
1111
233
2
2
32
1

11 US
Preparation
Batteries for Remote Control
If the remote control fails to operate the display, replace the batteries in the remote control.
1Open the battery
compartment cover. 2Load the supplied AA batteries. 3Close the battery compartment cover.
•Slide the cover in the direction
of the arrow.
•Place the batteries with their
terminals corresponding to the
(+) and (–) indications in the
battery compartment.
•Slide the cover in the direction
of the arrow.
CAUTION
Battery handling precautions
Improper use of the dry batteries can result in leakage of the battery fluid and/or rupture. Be sure to
follow the guidelines outlined below.
•Place the batteries with their terminals according to the (+) and (–) locations.
•Different types of batteries have different characteristics. Do not mix batteries of different types.
•Do not use old and new batteries together. Mixing old and new batteries can shorten the life of new
batteries and/or cause old batteries to leak battery fluid.
•Remove batteries as soon as they are exhausted. Fluid leaking from the batteries can cause a rash. If
fluid has leaked out, wipe it off with a cloth.
Remote control handling precautions
•Do not expose the remote control to excessive shock. Do not place the remote control where it can
get wet or where the humidity is high.
•Do not place the remote control in a location where it is exposed to direct sunlight.
The heat can deform its plastic exterior.
•When the remote sensor window of the display is exposed to direct sunlight or to strong light source,
remote control may prove to be difficult. Change the direction of the light source or of the display or
operate the remote control from a location closer to the remote sensor window.
Note
•The batteries included with the unit may not last as long as new batteries due to aging. Replace them when they fail
to operate the remote control.
•If the remote control is not used for extended periods of time, remove the batteries.

US 12
Preparation
System Connection (Example)
The following diagram shows an example of system connection, on which this Operation
Manual is based.
PC INPUT
AUDIO
R-AUDIO-L
COMPONENT 1
(INPUT)
DISPLAY OUTPUTRS-232C
110-120V /
220-240V~
COMPONENT 2
(INPUT)
YP
B (C B )P R (C R )
R-AUDIO-L Y P
B (C B )P R (C R )
RGB
VIDEO
VIDEO
LCDMONITOR
NTSC / PAL / SECAM
AV INPUT 1
S-VIDEO R-AUDIO-L
VIDEO R-AUDIO-L
AV INPUT 3
/ AV OUT
AVC System
Remote Control
Display
DVD Player
Computer
Cable Clamp
15-pin D-sub cable (*2)
Optional speaker system (*1)
System cable
AC Power cord
12ft.5-
39
/ 64 " [3.8m]
AC Power cord
5ft.10-55/64" [1.8m]
AC Power cord
Audio Cable (*3)
AC Power cord
To power
outlet
Component
Video cable (*3)
(*1) For the best sound quality, we recommend you purchase the optional speaker system with built-in amplifier. The
optional speakers are connected to the rear cabinet of the display.
(*2) (*3) These cables are sold separately.
To enjoy the beautiful sound with optional Bose System side speakers
1Make sure that the AV-3 setting of the OPTION mode in “OUTPUT”to “FIX”position.
Note
If it is set to “VARIABLE”position, the sound does not come out from the speakers. Change the
setting to “FIX”position so that you will be able to hear the sound. The setting procedures are shown
on page 27.
2You can control the sound volume with VOLUME (+)/(–) on the remote control or the top of the
display.

13 US
Preparation
If you connect your audio amplifier or system speakers to the unit, please refer to the system example
below.
PC INPUT
AUDIO
R-AUDIO-L
COMPONENT 1
(INPUT)
DISPLAY OUTPUTRS-232C
110-120V /
220-240V~
COMPONENT 2
(INPUT)
YP
B (C B )P R (C R )
R-AUDIO-L Y P
B (C B )P R (C R )
RGB
VIDEO
VIDEO
NTSC / PAL / SECAM
AV INPUT 1
S-VIDEO R-AUDIO-L
VIDEO R-AUDIO-L
AV INPUT 3
/ AV OUT
AVC System
DisplaySpeaker Speaker
DVD Player
Amplifier
Cable Clamp
System cable
AC Power
cord AC Power cordAudio cable
AC Power cord
Audio Cable
(Sold separately)
Sold separately
To power
outlet
Component
Video cable
Using an external speaker system
1Connect an audio cable from the audio input terminal (LINE-IN) of the
amplifier to the AV INPUT 3/AV OUT terminal on the rear of the AVC
system.
2Set the AV-3 setting of the OPTION mode in “OUTPUT”(VARIABLE).
See page 27 for the setting procedure.
3Press VOLUME (+) on the top of the display or the remote control to
increase sound volume.
4Set the maximum volume for the connected amplifier.
5Check the volume level of the connected DVD player or VCR, then
adjust VOLUME (–)on the remote control to set the appropriate
volume.
POWER
123
12
PC
INPUT
COMPONENT
MUTE
MENU ENTER
VOL
AV INPUT
LCD MONITOR

US 14
Basic Operation
Turning on POWER
When the POWER/Standby indicator is “OFF”:
Press MAIN POWER on the top panel of the display.
If the power cannot be switched on by pressing MAIN POWER, first
press MAIN POWER in the “OFF” position, then while keeping INPUT
pressed, press MAIN POWER again.
When the POWER/Standby indicator lights up “red”:
Press POWER on the remote control.
• When the power is switched on, the POWER/Standby indicator
lights up green and a mode indicator appears on the upper right
corner of the display.
CAUTION
Never pull the plug of the power cord before you switch off the power
by using the MAIN POWER button on the top panel.
Note Unless external AV equipment is connected, the indicator “AV-1”
appears on the display.
Switching INPUT Source
Press INPUT and select the applicable input source.
Note
•The input source mode is skipped if the corresponding input terminal is not
connected with external equipment (except “PC”).
•If you change the AV INPUT 3/AV OUT select, you can select “AV-3”. See
page 29 for details.
POWER/Standby indicator
BRIGHTNESS MAIN POWER
Top view
BRIGHTNESS INPUT
COMPO-1
Indicator (Example)
AV-1 AV-2 COMPONENT1 COMPONENT2 PC
AV-1
Indicator (Example)

15 US
Basic Operation
Basic Operation
Adjusting BRIGHTNESS
Press BRIGHTNESS and adjust the brightness of the display.
DARK BRIGHT NORMAL
Sound VOLUME
Press VOL (+) to increase sound volume.
Press VOL (–)to decrease sound volume.
* No sound is output under the following conditions.
By pressing MUTE on the remote control, you can temporarily turn the
sound off.
To turn the sound on again, press MUTE once more, or VOL (+)/(–)
on the remote control or on top of the display.
BRIGHTNESS INPUT
–+ INPUT VOL Indicator
Set to “Line output”with an
external amplifier connected
(page 13)
When headphones are
connected (page 8)
Mark Meaning
DARK
Indicator (Example)
Indicator

US 16
Basic Operation
Adjusting the display’s position
The display can be inclined between 10°to the front and 8°to the back. In addition it can be rotated from
left to right and vice versa within a range of 20°.
Cleaning
Make sure to always switch the MAIN POWER button at the top of the display “OFF”, and then remove
the AC power cord.
If the screen becomes dirty, wipe it off with a damp cloth.
Taking care of the screen of your LCD display
•Never spray liquid directly on the display.
•When dust has accumulated on the screen, use a commercially available cleaning brush (anti-static
brush).
•To protect the screen, do not wipe with a dry cloth or a chemically treated cloth.
Taking care of the cabinet
•Wipe dirt off using a soft cloth made of flannel, for example.
•Never use volatile agents such as benzene or thinner as they will deteriorate the exterior and the
coating.
•Never apply other volatile chemicals such as insecticides.
Never let the exterior stay in contact with rubber or vinyl surfaces for long periods of time. This could
cause the cabinet to deteriorate or the coating to peel off.
10°
8°
10°
10°

17 US
Adjustments to the On-Screen Display
Menu List
The list below shows all the items you can set and adjust. See the following pages for details on each
setup procedure.
AV Mode
VIEW (p.18)
BRIGHT. (p.22)
PICTURE (p.23)
SOUND (p.25)
OPTION (p.27)
SIDE BAR
CINEMA
WIDE
BRIGHT
NORMAL
DARK
NORMAL
MOVIE
GAME
NORMAL
MOVIE
GAME
WIDE VIEW
AV-3
C-SYSTEM
DISPLAY
RESET
:Factory setting
SIDE BAR
CINEMA
FULL
DOT BY DOT
BRIGHT
NORMAL
DARK
CONTRAST
BRIGHT
RED
BLUE
RESET
TREBLE
BASS
BALANCE
LOUDNESS
RESET
AUTO SYNC
AV-3
SIGNAL INFO
DISPLAY
RESET
PC Mode
AV Mode Factory Setting Details
CONTRAST
TINT
COLOR
BRIGHT. (Black level)
SHARP (SHARPness)
BLACK (Black stretching: sense of depth)
VDE (Vertical Detail Enhancement) *Only for N358
F-TONE (Flesh Tone)
C-TEMP (Color TEMPerature)
*Only for PAL/PAL-60/PAL-M
TREBLE
BASS
BALANCE
LOUDNESS
PRO.
SOUND
NORMAL
60
0
0
0
0
OFF
OFF
ON
0
0
0
0
OFF
MOVIE
50
0
0
–5
0
OFF
OFF
ON
0
0
0
0
OFF
GAME
45
0
0
0
–20
OFF
OFF
OFF
0
0
0
0
OFF
NORMAL
FULL
OUTPUT
AUTO
ON
+30
0
0
0
0
0
0
OFF
NORMAL
OUTPUT
ON
Adjustments to the
On-Screen Display
VIEW (p.18)
BRIGHT. (p.22)
PICTURE (p.23)
SOUND (p.25)
OPTION (p.27)

US 18
–30 +30
+1
V-POSI.
–30 +30
0
H-POSI. RESE
T
V-POSI.
SIDE BAR
WI
D
CINEMA
MENU VIEW BRIGHT
H-POSI. RESET V-POSI.
SIDE BAR
WIDE
CINEMA
NU VIEW BRIGHT
SIDE BAR
WIDE
CINEMA
SIDE BAR
NU VIEW BRIGHT
Adjusting the VIEW Settings
This menu allows you to select a picture size manually.
Details of modes and adjustment items are described on the following pages.
1Press MENU to display the Menu screen.
Press \| to move the cursor to VIEW
and then press ENTER.
2Press \| to move the cursor and select
the desired mode.
Then press ENTER.
Adjusting the Position of the Picture
Continue the following procedure if you want to adjust the position
vertically/horizontally.
3Press \| to move the cursor and select
the desired adjustment.
Then press ENTER.
4Press \| to make the adjustment and
then press ENTER.
Adjustments to the On-Screen Display
POWER
123
12
PC
INPUT
COMPONENT
MUTE
MENU ENTER
VOL
AV INPUT
LCD MONITOR
