Sharp HT-SB300 User manual

SOUND BAR SYSTEM
MODEL
HT-SB300
OPERATION MANUAL
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please read this
manual carefully. It will guide you in operating your SHARP product.
Accessories
Please confirm that only the following accessories are included.
Remote control x 1
(RRMCGA178AWSA)
RCA cable (2 pins- 2 pins) x 1
(QCNWGA041AWPZ)
( Spike + Nut ) x 4
Nut
(CLEGMA004AW01, Length: 30 mm)
AC/DC adaptor x 1
(RADPAA061AWZZ)
AC power cord x 1
(QACCDA005AWZZ)
Wall mount angle x 2
(LANGKA167AWFW)
Foot cushion x 4
(PCUSSA118AWZZ) Pattern paper x 1
(TCAUHA022AWZZ)
Spike x 4
(CLEGMA005AW01, Length: 25 mm)
Note:
This product is recommended for flat panel TV
(LCD and plasma).
is a trademark of SRS Labs, Inc.
WOW HD technology is incorporated under license from
SRS Labs, Inc.

2
HT-SB300
2008 December 5
HT-SB300_A6_EN
Important Instruction
SPECIAL NOTES
NOTE
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses,and can radiate
radio frequency energy and, if not installed and used
inaccordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
● Reorient or relocate the receiving antenna.
●
Increase the separation between the equipment and receiver.
●
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
●
Consult the dealer or an experienced radio/TV technician for
help.
WARNING
●
FCC Regulations state that any unauthorized changes or
modifications to this equipment not expressly approved by
the manufacturer could void the user's authority to operate
this equipment.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols:
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the
presence of uninsulated “dangerous
voltage” within the product’s enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the literature accompan-
ying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE
TO RAIN OR MOISTURE.
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss or
theft, please record below the model number and serial
number whichare located on the rear of the unit. Please retain
this information.
Model number ........................................................
Serial number ........................................................
Date of purchase ........................................................
Place of purchase ........................................................

3
HT-SB300
2008 December 5 HT-SB300_A6_EN
Important Instruction
IMPORTANT SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can
also cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured
with the highest priority on safety. However, improper use can
result in electric shock and/or fire. In order to prevent potential
danger, please observe the following instructions when
installing, operating and cleaning the product. To ensure your
safety and prolong the service life of this product, please read
the following precautions carefully before use.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or
table specified by the manufacturer, or sold with
the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Additional Safety Information
15) Power Sources - This product should be operated only from
the type of power source indicated on the marking label. If
you are not sure of the type of power supply to your home,
consult your product dealer or local power company. For
product intended to operate from battery power, or other
sources, refer to the operating instructions.
16) Overloading - Do not overload wall outlets, extension cords,
or integral convenience receptacles as this can result in a
risk of fire or electric shock.
17) Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.

4
HT-SB300
2008 December 5
HT-SB300_A6_EN
Important Instruction
IMPORTANT SAFETY INSTRUCTIONS (continued)
18) Damage Requiring Service - Unplug this product from the
wall outlet and refer servicing to qualified service personnel
under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the
product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its normal
operation,
e) If the product has been dropped or damaged in any
way, and
f ) When the product exhibits a distinct change in
performance - this indicates a need for service.
19) Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
20) Safety Check - Upon completion of any service or repairs to
this product, ask the service technician to perform safety
checks to determine that the product is in proper operating
condition.
21) Wall or ceiling mounting - When mounting the product on a
wall or ceiling, be sure to install the product according to the
method recommended by the manufacturer.
22) Power Lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be
fatal.
23) Outdoor Antenna Grounding - If an outside antenna or cable
system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection
against voltage surges and built-up static charges.
Article810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regards to proper grounding of the
mast and supporting structure, grounding of the lead-in wire
to an antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
24) Protective Attachment Plug - The product is equipped with
an attachment plug having overload protection. This is a
safety feature. See Instruction Manual for replacement or
resetting of protective device. If replacement of the plug is
required, be sure the service technician has used a
replacement plug specified by the manufacturer that has the
same overload protection as the original plug.
25) Stand - Do not place the product on an unstable cart, stand,
tripod or table. Placing the product on an unstable base can
cause the product to fall, resulting in serious personal
injuries as well as damage to the product. Use only a cart,
stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the
product on a wall, be sure to follow the manufacturer's
instructions. Use only the mounting hardware
recommended by the manufacturer.

5
HT-SB300
2008 December 5 HT-SB300_A6_EN
General Information
Notes
Features
SRS WOW improves the dynamic audio performance of
compressed and uncompressed audio by expanding the size of
the audio image and creating a deep, rich bass response.
Contents
Page
■
General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Controls and indicators . . . . . . . . . . . . . . . . . . 7 - 9
■
Preparation for Use
Speaker preparation . . . . . . . . . . . . . . . . . . . 10 - 12
Placing the speaker. . . . . . . . . . . . . . . . . . . . . . . . 13
Falling prevention . . . . . . . . . . . . . . . . . . . . . . . . . 14
Speaker connections to TVs . . . . . . . . . . . . 14 - 16
AC power connection . . . . . . . . . . . . . . . . . . . . . . 17
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
■ Basic Operation
General control . . . . . . . . . . . . . . . . . . . . . . . 19 - 21
■ References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . 22
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Error indicators and warnings . . . . . . . . . . . . . . . 23
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
CONSUMER LIMITED WARRANTY . . . Back cover
Manufactured under license under U.S. Patent #'s: 5,451,942;
5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S. and
worldwide patents issued & pending. DTS and DTS Digital
Surround are registered trademarks and the DTS logos and
Symbol are trademarks of DTS, Inc. © 1996-2007 DTS, Inc.
All Rights Reserved.
Manufactured under license from Dolby Laboratories.
“Dolby”, “Pro Logic”, the double-D symbol are trademarks of
Dolby Laboratories.
ENERGY STAR®Program Information
Productsthat have earned
the ENERGY STAR®are
designed to protect the
environment through
superior energy efficiency.
ENERGY STAR®isa U.S. registered mark.

6
HT-SB300
2008 December 5
HT-SB300_A6_EN
General Information
Precautions
■ General
●
Please ensure that the equipment is positioned in a well-
ventilated area and ensure that there is at least 4" (10 cm) of
free space along the sides and top of the equipment.
●
Use the speaker on a firm, level surface free from vibration.
●
Keep the speaker away from direct sunlight, strong magnetic
fields, excessive dust, humidity and electronic/electrical
equipment (home computers, facsimiles, etc.) which
generate electrical noise.
● Do not place anything on top of the speaker.
●
Do not expose the speaker to moisture, to temperatures
higher than 140˚F (60˚C) or to extremely low temperatures.
● If your system does not work properly, disconnect the AC
power cord from the AC outlet. Plug the AC power cord back
in, and then turn on your system.
● In case of an electrical storm, unplug the speaker for safety.
●
Hold the AC power plug by the head when removing it from
the AC outlet, as pulling the cord can damage internal wires.
● The AC power plug is used as a disconnect device and shall
always remain readily operable.
●
Do not remove the outer cover, as this may result in
electric shock. Refer internal service to your local
SHARP service facility.
●
This speaker should only be used within the range of
41˚F - 95˚F (5˚C - 35˚C).
Warning:
●
The voltage used must be the same as that specified on this
speaker. Using this product with a higher voltage other than
that which is specified is dangerous and may result in a fire
or other type of accident causing damage. SHARP will not be
held responsible for any damage resulting from use of this
speaker with a voltage other than that which is specified.
●
The supplied AC/DC adaptor contains no user serviceable
parts. Never remove covers unless qualified to do so.
It contains dangerous voltages, always remove mains plug
from the main outlet jack before any service operation or
when not in use for a long period.
● The AC/DC adaptor supplied with the HT-SB300 must not be
used with other equipment.
●
Never use an AC/DC adaptor other than the one specified.
Otherwise, problem or serious hazards may be created.
■ Volume control
The sound level at a given volume setting depends on speaker
efficiency, location, and various other factors. It is advisable to
avoid exposure to high volume levels, which occurs while
turning the speaker on with the volume control setting up high,
or while continually listening at high volumes.
4" (10 cm)
4" (10 cm) 4" (10 cm)

7
HT-SB300
2008 December 5 HT-SB300_A6_EN
General Information
Controls and indicators
■ Front Panel
Reference page
1. Sport Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2. Standard Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . 19
3. Information Display. . . . . . . . . . . . . . . . . . . . . . . . . 19
4. Cinema/Game Indicator . . . . . . . . . . . . . . . . . . . . . 19
5. News Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6. DTS Indicator. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
7. Dolby Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
8. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . 19
9. Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . 19
10. Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Reference page
11. Surround Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
12. Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
13. Remote Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
14. Dolby Virtual Speaker Indicator . . . . . . . . . . . . . . . 20
15. Dolby Prologic II Indicator. . . . . . . . . . . . . . . . . . . . 20
16. Left Front Speaker
17. Bass Reflex Duct
18. Subwoofers
19. Right Front Speaker
867 9 10 11 12 1314 15
23
16 17 17 191818
451

8
HT-SB300
2008 December 5
HT-SB300_A6_EN
General Information
Controls and indicators (continued)
■ Rear Panel
Reference page
1. Audio Line In 2 Jack . . . . . . . . . . . . . . . . . . . . . . . . . 15
2. Line In 1 Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3. DC IN Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4. Coaxial Digital Audio Input Jack . . . . . . . . . . . . . . . 16
5. Optical Digital Audio Input Jack . . . . . . . . . . . . . . . 16
6. Subwoofer Pre Output Jack . . . . . . . . . . . . . . . . . . 13
LEFTRIGHT
LINE IN 1LINE IN 2
123456

9
HT-SB300
2008 December 5 HT-SB300_A6_EN
General Information
Note:
Before using remote control, please remove plastic shield at
battery holder.
■ Remote Control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . 18
2. Dolby Virtual Speaker Button . . . . . . . . . . . . . . . . . 20
3. Cinema/Game Button. . . . . . . . . . . . . . . . . . . . . . . . 19
4. Standard Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5. Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6. Subwoofer Level Down Button . . . . . . . . . . . . . . . . 21
7. Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . . 19
8. Bass/Treble Button. . . . . . . . . . . . . . . . . . . . . . . . . . 21
9. TV Operation Buttons . . . . . . . . . . . . . . . . . . . . . . . . 9
10. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . 19
11. Sport Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
12. News Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
13. Subwoofer Level Up Button . . . . . . . . . . . . . . . . . . 21
14. Dimmer Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
15. Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
16. Line Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
17. Digital 1 Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
18. Digital 2 Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Notes:
●
Some models of SHARP TV may not be operable.
●
SHARP TV remote control will not work with HT-SB300
system.
1
10
11
14
15
12
13
16
17
18
3
2
4
5
7
6
8
9
Remote
control Plastic shield
Battery holder
TV Operation Buttons (Only SHARP TV):
On/Stand-by
Button
Sets the TV
power to “ON”
or “STAND-
BY”.
Input Select
Button (TV)
Press the
button to
switch the
input source.
Volume Up
and Down
Buttons
Turn up/down
the TV
volume.
Channel Up
and Down
Buttons
Switch up/
down the TV
channels.

10
HT-SB300
2008 December 5
HT-SB300_A6_EN
Preparation for Use
Speaker preparation
Select from three installation methods according to the
preferred position.
Notes:
●
Option 1 or option 2 indicates spike positions based on LCD
TV stand.
●
When attaching the spikes, place the speaker on a cushion
or soft cloth to avoid damage.
Caution:
When using these spikes on glossy or slippery table such as on
glass top, stick foot cushions at the bottom of the spikes to avoid
slippage.
Note:
Option 1 or option 2 foot cushion positions based on LCD TV
stand.
Make sure to unplug the AC power cord before installing
the speaker or changing the position.
Tighten all spikes as shown
Option 2 Option 1
Using spikes
You may choose from the two different spike lengths provided:
25 mm and 30 mm.
Nuts (secured on 30 mm spikes) must be used when installing
either the 25 mm or 30 mm spikes.
The speaker can be leveled by adjusting the spikes and nuts.
Attach foot cushions as shown
Option 1
Option 2
Using foot cushions

11
HT-SB300
2008 December 5 HT-SB300_A6_EN
Preparation for Use
Caution:
●
Be very careful to prevent the speaker [3.86 lbs. (1.75 kg)]
from falling when mounting on the wall.
●
Before mounting, check the wall strength. (Do not put on the
veneer plaster or whitewashed wall. The speaker may fall.) If
unsure, consult a qualified service technician.
●
Mounting screws are not supplied. Use appropriate ones.
●
Check all wall mount angle screws for looseness.
● Select a good location. If not, accidents may occur or the
speaker may get damaged.
●
SHARP is not responsible for accidents resulting from
improper installation.
■ Driving screws
SHARP designed the speakers so you may hang them on the
wall. Use proper screws (not supplied). See below for size and
type.
■ Wall mount angle fixed to the wall
(Horizontal position)
(Continued to the next page)
To mount the speaker on the wall
1/8" (3.2 mm)
3/8" (9 mm)
Min. 7/8" (22 mm)
3/16"
(5 mm)
1
Fix the pattern paper to the wall in horizontal position
as below.
2
Make a hole on the wall following the screw point
marks on the pattern paper by using a drill.
3
Fix a wall mount plug into the hole using a hammer,
until it is flush with the wall surface.
29 mm
29 mm
44 mm
44 mm
509 mm
Pattern paper
Wall surface
Wall surface
3/8" (8-9 mm)
1-1/4" (32 mm)
Wall surface
3/8" (8-9 mm)
1-1/4" (32 mm)

12
HT-SB300
2008 December 5
HT-SB300_A6_EN
Preparation for Use
Speaker preparation (continued)
Note:
Make sure all screws are fully tighten. (screws are not supplied)
■ Installing the speaker
4
Screw the wall mount angle to the wall as shown in the
illustration. (Total screw is 8 pieces)
Wall surface
Wall mount angle
Wall mount angle
Wall surface
Wall surface
Wall mount angle
(screws x 4)
(screws x 4)
1
Align the wall mount slot at the speaker to the wall
mount angle.
2
Slot the speaker into the wall mount angle.
3
Fix them securely.
Wall surface

13
HT-SB300
2008 December 5 HT-SB300_A6_EN
Preparation for Use
Placing the speaker
Installation image:
Place the speaker as shown.
Notes:
●
As the sound from the speaker is omni-directional, you can
place the speaker anywhere you like. However, it is
recommended to place it as close to the TV as possible.
●
The front panel of the speaker is not removable.
Caution:
●
Do not change the installation direction when the speaker is
turned on.
● Do not stand or sit on the speaker as you may be injured.
■ Using other subwoofer
You can connect a subwoofer with an amplifier to the
SUBWOOFER PRE OUT jack.
Note:
No sound is heard from the subwoofer without a built-in
amplifier.
TV
VCR DVD player
Audio signal
Audio cable
(commercially
available)
Commercially available
subwoofer
(amplifier built in)
To audio input
jack
To SUBWOOFER PRE
OUT jack
Speaker

14
HT-SB300
2008 December 5
HT-SB300_A6_EN
Preparation for Use
Falling prevention
Safety wires (not supplied) are useful to prevent the speaker
from falling off the table.
Loop the safety wires (not supplied) into each hole as shown
and tie the safety wires to the LCD TV stand.
Speaker connections to TVs
Caution:
Turn off all other equipment before making any connections.
Tuner receiving for other audio system
●
Placing the antenna near the speaker AC power cord may
cause noise pick up. Place the antenna away from the
speaker for better reception.
Notes:
●
To connect to TV, use either LINE IN 1 jacks or AUDIO LINE
IN 2 jack only.
●
Refer the operation manual of the equipment to be
connected.
● Fully insert the plugs to avoid fuzzy pictures or noises.

15
HT-SB300
2008 December 5 HT-SB300_A6_EN
Preparation for Use
■ Connecting to a TV
If the TV/monitor has an audio output, connect it to the LINE IN
1 jacks on the rear of the speaker.
To select LINE IN 1 function:
●
On speaker: Press FUNCTION button repeatedly until “L1” is
displayed.
●
On remote control: Press LINE button repeatedly until “L1” is
displayed.
■ Connecting to a TV (with Headphone jack)
If the TV/monitor has headphone jack, connect it to the LINE IN
2 jack on the rear of the speaker.
To select LINE IN 2 function:
●
On speaker: Press FUNCTION button repeatedly until “L2” is
displayed.
●
On remote control: Press LINE button repeatedly until “L2” is
displayed.
Notes:
●
If the TV volume is continuously in low level, the speaker will
automatically power off. Increase the TV output volume to
enjoy the sound from the speaker.
●
If the speaker volume is continuously in very high level, the
speaker will mute and recover after 3 seconds.
RIGHT LEFT
LINE IN 1
LINE IN 2
To audio output jacks
RCA cable (supplied)
Speaker
TV
To LINE IN 1
jacks
RIGHT LEFT
HEADPHONE
LINE IN 1LINE IN 2
To HEADPHONE jack
Audio cable (not supplied)
Speaker
TV
To AUDIO
LINE IN 2 jack

16
HT-SB300
2008 December 5
HT-SB300_A6_EN
Preparation for Use
Speaker connections to TVs (continued)
■ Connecting a digital tuner, etc.
Connect to the digital tuner, etc. using an optical digital audio
cable or a coaxial digital audio cable.
To select DIGITAL 1 (coaxial input) or DIGITAL 2 (optical
input) function:
● On speaker: Press FUNCTION button repeatedly until “d1” or
“d2” is displayed.
● On remote control: Press DIGITAL 1 or DIGITAL 2 button and
“d1” or “d2” is displayed.
Note:
When connecting with an optical digital cable, set the digital
output of the digital tuner to PCM. Refer to the operation manual
of the digital tuner.
Coaxial digital audio cable
(commercially available) Optical digital
audio cable
(commercially
available)
To COAXIAL
input jack
To the TV (video)
To OPTICAL
input jack
Speaker
To coaxial digital audio output jack
Audio signal
Audio signal
To optical
digital audio
output jack

17
HT-SB300
2008 December 5 HT-SB300_A6_EN
Preparation for Use
AC power connection
After checking all the connections have been made correctly,
connect the AC power cord to the AC power input jack, then to
the AC outlet.
■ Using with the AC/DC adaptor
Notes:
● Unplug the AC/DC adaptor from the AC outlet if the speaker
will not be used for a prolonged period of time.
●
Use only the supplied AC/DC adaptor. Using other AC/DC
adaptor may cause an electric shock or fire.
1
Plug the AC power cord into the AC/DC adaptor.
2
Plug the AC/DC adaptor cable into the DC IN jack on
the speaker.
3
Plug the AC power cord into an AC outlet. The STAND-
BY indicator will turn RED when AC power is applied.
The power indicator will turn GREEN when the system
in “ON”.
RIGHT LEFT
LINE IN 1LINE IN 2
2
1
3
AC/DC Adaptor Cable
DC IN jack
(DC 12 V)
AC/DC Adaptor
AC Outlet
(AC 100 - 240 V ~ 50/60 Hz)
AC power cord

18
HT-SB300
2008 December 5
HT-SB300_A6_EN
Preparation for Use
Remote control
■ Battery installation
This product contains a CR Coin Lithium Battery which contains
Perchlorate Material – special handling may apply, California
residents, see www.dtsc.ca.gov/hazardouswaste/perchlorate/
Precautions for battery use:
● Remove the battery if the speaker will not be used for long
periods of time. This will prevent potential damage due to
battery leakage.
Caution:
● Do not use rechargeable battery (nickel-cadmium battery,
etc.).
●
Danger of explosion if battery is incorrectly replaced.
●
Replace only with the same or equivalent type.
●
Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
●
Installing the battery incorrectly may cause the speaker to
malfunction.
Notes concerning use:
●
Replace the battery if the operating distance is reduced or if
the operation becomes erratic. Purchase “CR 2025”, coin
lithium battery.
●
Periodically clean the transmitter on the remote control and
the sensor on the speaker with a soft cloth.
●
Exposing the sensor on the speaker to strong light may
interfere with operation. Change the lighting or the direction
of the speaker if this occurs.
●
Keep the remote control away from moisture, heat, shock,
and vibrations.
■ Test of the remote control
Point the remote control directly at the remote sensor on the
speaker .
The remote control can be used within the range shown
below:
Press the ON/STAND-BY button. Does the power turn on?
Now, you can enjoy your system.
1
Insert pin into the hole as shown and pull to open the
battery holder.
2
Remove the old battery from the battery holder, insert
the new battery and then slide the battery holder back
into the remote control.
Back of
remote control
Pin
Battery holder
Polarity (+) symbol
Battery type
Locking tab Positive (+) side up
15˚ 15˚
Remote sensor
8” - 20’
(0.2 m - 6 m)

19
HT-SB300
2008 December 5 HT-SB300_A6_EN
Basic Operation
General control
■ To turn the power on
Press the ON/STAND-BY button.
●
The power indicator turns green. If the power does not turn
on, check whether the power cord is plugged in properly.
To set the speaker to stand-by mode:
●
Press the ON/STAND-BY button again.
The STAND-BY indicator turns red.
■ Display brightness control
Press the DIMMER button to adjust the brightness of the display
and sound mode indicator.
■ Volume auto fade-in
If you turn off and on the speaker with the volume set to 40 or
higher, the volume starts at 20 and fades in to the last set level.
■ Volume control
Remote control operation:
Press the VOLUME + button to increase the volume and the
VOLUME – button to decrease the volume.
■ Preset sound mode
Main unit operation:
When the SURROUND button is pressed, the current mode
setting will light up. To change to a different mode, press the
SURROUND button repeatedly until the desired sound mode
lights up.
Remote control operation:
Press a desired sound mode on the remote control.
Sound mode indicator and display bright
Sound mode indicator and display dim
Sound mode indicator and display off. Pressing
any button will light up the display for 3 seconds only.
Speaker operation:
Press volume up (VOL. +) to increase
the volume and press volume down
(VOL. – ) to decrease the volume.
■ Muting
The volume is muted temporarily when pressing
the MUTE button on the remote control. Press
again to restore the volume.
00 01 02 ..... 59 60
NEWS
WOW HD off
WOW HD onfor cinema/game sound effect
WOW HD onfor news
WOW HD onfor sport broadcasting
STANDARD
CINEMA/GAME
NEWS
SPORT
STANDARD
SPORT
CINEMA/GAME

20
HT-SB300
2008 December 5
HT-SB300_A6_EN
Basic Operation
General control (continued)
■ Dolby Virtual Speaker (DVS) sound mode
The Dolby Virtual Speaker (DVS) creates virtual surrounds
comparable to the 5.1ch sound produced by the 2.1ch speaker.
When setting DVS to “ON” for 2 channel stereo signals, Dolby
Pro Logic II brings out virtual sound effects through the signals
converted into 5.1ch.
Press the DVS button.
The Dolby Virtual Speaker indicator lights up.
Notes:
●
Monaural signals do not generate surround effects.
●
DVS sound effect may not be obtained depending on signal
types (the Dolby Virtual Speaker indicator blinks). In this
case, set the DVS mode to “OFF”.
● DVS can only be turned on using remote control.
●
If you turn ON DVS, WOW HD will automatically turn OFF.
●
The DVS can be turned OFF by pressing any of the preset
sound mode buttons.
This product incorporates decoders supporting the Dolby Digital
system and DTS system.
The Dolby Virtual Speaker creates multichannel-like
sound effects.
Compared with the cinema mode, the bass sound
level is slightly reduced.
The Dolby Pro Logic II indicator also lights up if 2ch
sound signals are detected.
DTS (Digital Theater
Systems)
One of the digital audio systems for
theatrical use. As the sound quality
is emphasized, you can enjoy the
realistic sound effect in the home
theater system.
Lights up when detecting DTS
signal.
Dolby Digital
One of the digital audio systems for
theatrical use. You can also enjoy
the stereophonic effect in the home
theater system.
Lights up when detecting Dolby
Digital signal.
ON
