ENGLISH
MODEL
HT-SB602
SOUND BAR HOME THEATER SYSTEM
OPERATION MANUAL
Thank you for purchasing this SHARP product. To obtain the best performance from this product, please
read this manual carefully. It will guide you in operating your SHARP product.
Note:
This product is recommended for 60" or larger flat panel TV (LED, LCD and Plasma).
HT-SB602 Sound Bar Home Theater system consisting of HT-SB602 (sound bar system) and CP-SW602
(active subwoofer system).
Accessories
The following accessories are included.
Remote Control
(RRMCGA331AWSA)
Subwoofer Stand x 2
(GITAUA022AW01)
Audio Cable x 1
(QCNWGA108AWPZ)
HDMI Cable x 1
(QCNWGA077AWPZ)
IR Transmitter x 1
(QCNWNC064AS01)
Wall Mount Angle x 2
(LANGKA167AW01)
Pattern Paper
(TCAUHA036AWZZ)
NFC tag x 1
(GCASP8973AW01)
Velcro tape (hook type) x 1
(PSHEZA373AW01)
Velcro tape (loop type) x 2
(PSHEZA372AW01)
TINSZB608AWZZ
Printed in Malaysia
14A R AS 1

E-1
Special Notes
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols:
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of
uninsulated “dangerous voltage” within the
product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
FOR YOUR RECORDS
For your assistance in reporting this unit in case of loss
or theft, please record below the model number and
serial number which are located on the rear of the unit.
Please retain this information.
Model number ........................................................
Serial number ........................................................
Date of purchase ........................................................
Place of purchase ........................................................
NOTE
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV
technician for help.
WARNING
FCC Regulations state that any unauthorized changes or
modifications to this equipment not expressly approved
by the manufacturer could void the user’s authority to
operate this equipment.
FCC Radiation Exposure Statement
This device complies with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. It must not
be co-located or operating in conjunction with any other
antenna or transmitter.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment should be installed and operated with
a minimum distance of 20 cm between the radiator and
person’s body (excluding extremities: hands, wrists, feet
and ankles.)
IC Radiation Exposure Statement (For users in
Canada)
The radio communications device incorporated into this
apparatus meets all requirements of the Industry Canada
Radio Frequency Exposure Rules RSS-210. This Class B
digital apparatus complies with the Canadian ICES-003
Class B specifications.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
This equipment should be installed and operated with
a minimum distance of 20 cm between the radiator and
person’s body (excluding extremities: hands, wrists, feet
and ankles.)
Note to CATV system installer:
This reminder is provided to call the CATV system
installer’s attention to Article 820 of the National
Electrical Code that provides guidelines for proper
grounding and, in particular, specifies that the cable
ground shall be connected to the grounding system
of the building, as close to the point of cable entry as
practical.
ENERGY STAR
®
Program Information
Products that have earned
the ENERGY STAR
®
are
designed to protect the
environment through
superior energy efficiency.
ENERGY STAR®is a U.S. registered mark.
Manufactured under license under U.S. Patent Nos:
5,956,674; 5,974,380; 6,487,535 & other U.S. and
worldwide patents issued & pending. DTS, the
Symbol, & DTS and the Symbol together are registered
trademarks & DTS Digital Surround and the DTS logos
are trademarks of DTS, Inc. Product includes software.
© DTS, Inc. All Rights Reserved.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
HDMI, the HDMI Logo, and High-Definition Multimedia
Interface are trademarks or registered trademarks of
HDMI Licensing LLC in the United States and other
countries.

E-2
Important Safety Instructions
Electricity is used to perform many useful functions, but it
can also cause personal injuries and property damage if
improperly handled. This product has been engineered
and manufactured with the highest priority on safety.
However, improper use can result in electric shock and/or
fire. In order to prevent potential danger, please observe
the following instructions when installing, operating and
cleaning the product. To ensure your safety and prolong
the service life of this product, please read the following
precautions carefully before use.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
Amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety. If
the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Additional Safety Information
15) Power Sources - This product should be operated
only from the type of power source indicated on the
marking label. If you are not sure of the type of power
supply to your home, consult your product dealer or
local power company. For product intended to operate
from battery power, or other sources, refer to the
operating instructions.
16) Overloading - Do not overload wall outlets, extension
cords, or integral convenience receptacles as this can
result in a risk of fire or electric shock.
17) Object and Liquid Entry - Never push objects of any kind
into this product through openings as they may touch
dangerous voltage points or short-out parts that could
result in a fire or electric shock.
To prevent fire or shock hazard, do not expose this
appliance to dripping or splashing. No objects filled with
liquids, such as vases, shall be placed on the apparatus.
18) Damage Requiring Service - Unplug this product from
the wall outlet and refer servicing to qualified service
personnel under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen
into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by
following the operating instructions. Adjust only
those controls that are covered by the operating
instructions as an improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician to
restore the product to its normal operation,
e) If the product has been dropped or damaged in
any way, and
f) When the product exhibits a distinct change in
performance - this indicates a need for service.
19) Replacement Parts - When replacement parts are
required, be sure the service technician has used
replacement parts specified by the manufacturer or
have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric
shock, or other hazards.
20) Safety Check - Upon completion of any service or
repairs to this product, ask the service technician to
perform safety checks to determine that the product is
in proper operating condition.
21) Wall or ceiling mounting - When mounting the product
on a wall or ceiling, be sure to install the product
according to the method recommended by the
manufacturer.
22) Power Lines - An outside antenna system should not
be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside antenna system, extreme care should be
taken to keep from touching such power lines or
circuits as contact with them might be fatal.
23) Protective Attachment Plug - The product is equipped
with an attachment plug having overload protection.
This is a safety feature. See Instruction Manual for
replacement or resetting of protective device. If
replacement of the plug is required, be sure the
service technician has used a replacement plug
specified by the manufacturer that has the same
overload protection as the original plug.
24) Stand - Do not place the product on an unstable cart,
stand, tripod or table. Placing the product on an
unstable base can cause the product to fall, resulting
in serious personal injuries as well as damage to the
product. Use only a cart, stand, tripod, bracket or table
recommended by the manufacturer or sold with the
product. When mounting the product on a wall, be
sure to follow the manufacturer
’ s instructions. Use
only the mounting hardware recommended by the
manufacturer.
12) Use only with the cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination
to avoid injury from tip-over.

E-3
For U.S. customer only
CONSUMER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand product (the
"Product"), when ship in its original container, will be free from defective workmanship and materials, and agrees that it will,
at its option, either repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent
at no charge to the purchaser for parts or labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product nor to the additional excluded item(s) set forth below
nor to any Product the exterior of which has been damaged or defaced, which has been subjected to improper voltage or
other misuse, abnormal service or handling, or which has been altered or modified in design or construction.
In order to enforce the rights under this limited warranty, the purchaser should follow the steps set forth below and provide
proof of purchase to the servicer.
The limited warranty described herein is in addition to whatever implied warranties may be granted to purchasers by law.
ALL IMPLIED WARRANTIES INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR USE ARE
LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. Some states do not allow
limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
Neither the sales personnel of the seller nor any other person is authorized to make any warranties other than those
described herein, or to extend the duration of any warranties beyond the time period described herein on behalf of Sharp.
The warranties described herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and
exclusive remedy available to the purchaser. Correction of defects, in the manner and for the period of time described
herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp to the purchaser with respect to the
Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability or otherwise.
In no event shall Sharp be liable, or in any way responsible, for any damages or defects in the Product which were caused
by repairs or attempted repairs performed by anyone other than an authorized servicer. Nor shall Sharp be liable or in any
way responsible for any incidental or consequential economic or property damage. Some states do not allow the exclusion
of incidental or consequential damages, so the above exclusion may not apply to you.
THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY(50) UNITED STATES, THE DISTRICT OF COLUMBIA AND
PUERTO RICO.
Model Specific Section
Your Product Model Number & Description:
Warranty Period for this Product:
Additional Item(s) Excluded from Warranty Coverage
(if any):
Where to Obtain Service:
What to do to Obtain Service:
HT-SB602 Sound Bar Home Theater System
(Be sure to have this information available when you need
service for your Product.)
One (1) year parts and labor from the date of purchase.
Non-functional accessories, supplies, and consumable
items.
At a Sharp Authorized Servicer located in the United States.
To find a location of the nearest Sharp Authorized Servicer,
call Sharp toll free at 1-800-BE-SHARP.
Ship prepaid or carry in your Product to a Sharp Authorized
Servicer. Be sure to have Proof of Purchase available. If
you ship the Product, be sure it is insured and packaged
securely.
TO OBTAIN SUPPLY, ACCESSORY OR PRODUCT INFORMATION, CALL 1-800-BE-SHARP
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
Special Notes
The Bluetooth
®
word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks
by SHARP is under license. Other trademarks and trade names are those of their respective owners.
The N Mark is a trademark or registered trademark of NFC Forum, Inc. in the United States and in other countries.

E-4
Precautions
General
Keep your equipment at least 4" (10 cm) of free space
along the sides, top and back for proper ventilation.
4" (10 cm)
4" (10 cm) 4" (10 cm)
4" (10 cm)
4" (10 cm) 4" (10 cm)
4" (10 cm)
Use the unit on a firm, level surface free from vibration.
Keep the unit away from direct sunlight, strong
magnetic fields, excessive dust, humidity and
electronic/electrical equipment (home computers,
facsimiles, etc.) which generate electrical noise.
Do not place anything on top of the unit.
Do not expose the unit to moisture, to temperatures
higher than 140°F (60°C) or to extremely low
temperatures.
If the unit does not work properly, unplug and plug it in
again. Than turn on the unit.
In case of an electrical storm, unplug the unit for
safety.
Hold the AC power plug by the head when removing
it from the AC outlet, as pulling the cord can damage
internal wires.
The AC power plug is used as a disconnect device
and shall always remain readily operable.
Do not remove the outer cover, as this may result
in electric shock. Refer internal service to your
local SHARP service facility.
This unit should only be used within the range of 41°F -
95°F (5°C - 35°C).
SHARP is not responsible for damage due to improper
use. Refer all servicing to a SHARP authorised
service center.
Warnings:
The voltage used must be the same as that specified
on this unit. Using a higher voltage is dangerous and
may result in a fire or other type of accident causing
damage. SHARP will not be held responsible for any
damage resulting from such usage.
In case of repairing, please bring the entire system set
to the service center.
Volume control
The sound level at a given volume setting depends on
speaker efficiency, location and various other factors.
It is advisable to avoid exposure to high volume levels,
which occurs while turning the unit on with the volume
control setting up high, or while continually listening at
high volumes.
Controls and indicators
Sound Bar Front Panel
1
34 5 76 8 9
2
1. Left Channel Speakers
2. Right Channel Speakers
3. On/Standby Button
4. INPUT Button
5. Pairing Button
6. Remote Sensor
7. Sound Mode Button
8. Volume Down Button
9. Volume Up Button

E-5
Controls and indicators (continued)
Display
DIGITAL
DIGITAL
12
3
1. Dolby Digital Indicator
2. DTS Indicator
3. Muting Indicator
Subwoofer
5
3
4
2
6
FRONT VIEW REAR VIEW
1
1. NFC detection area
2. Power/Pairing Indicator
3. Bass Reflect Duct
4. Woofer
5. SW LINK (Subwoofer Link) button
6. AC Power Cord
Sound Bar Rear Panel
7
6
5
4
3
2
1
1. IR OUT Terminal
2. HDMI OUT (TV ARC) Jack
3. HDMI IN 1 Jack
4. HDMI IN 2 Jack
5. Optical IN Jack
6. Audio IN Terminal
7. AC Power Cord

E-6
Controls and indicators (continued)
1
2
4
5
7
8
9
12
16
17
18
19
13
15
14
3
6
11
10
20
22
23
24
26
27
29
30
33
34
35
31
32
21
25
28
Remote Control
1. Remote Control Transmitter
2. ON/STANDBY Button
3. HDMI 2 Button
4. HDMI 1 Button
5. OPTICAL Button
6. MUSIC (Sound Mode) Button
7. CINEMA (Sound Mode) Button
8. SPORT (Sound Mode) Button
9. BYPASS Button
10. 3D AUDIO Button
11. Bluetooth Skip Down Button
12. Bluetooth Pairing Button
13. Volume Up Button
14. AV SYNC Up Button
15. BASS Button
16. Volume Down Button
17. MUTE Button
18. APC Button
19. TV Operation Button
20. ( )Speaker Select Button
21. ARC Button
22. (Bluetooth) Button
23. AUDIO IN Button
24. GAME (Sound Mode) Button
25. NEWS (Sound Mode) Button
26. NIGHT (Sound Mode) Button
27. DIMMER Button
28. Bluetooth Play/Pause Button
29. Bluetooth Skip Up Button
30. SW (Subwoofer) Level Up Button
31. TREBLE Button
32. AV SYNC Down Button
33. SW (Subwoofer) Level Down Button
34. SW (Subwoofer) LINK Button
35. ECO MODE Button
TV Operation Buttons (Only SHARP TV):
On/Standby
AV Mode
Button
MUTE Button
Button
Sets the TV
Press the
button to
switch AV
mode.
Press the
button to
mute the
TV volume.
power to
“ON” or
“STANDBY”.
Input Select
Button (TV)
Press the
button to
switch the
input source.
Channel Up
and Down
Buttons
Switch up/
down the TV
channels.
Volume Up
and Down
Buttons
Tu r n u p /
down the TV
volume.
Note:
Some models of SHARP TV may not be operable.

E-7
Sound bar preparation
To mount the sound bar on the wall
Caution:
 Be very careful to prevent the sound bar [7.9 lbs. (3.7 kg)]
from falling when mounting on the wall.
 Before mounting, check the wall strength. (Do not put on
the veneer plaster or whitewashed wall. The sound bar
may fall.) If unsure, consult a qualified service technician.
 Mounting screws are not supplied. Use appropriate ones.
 Check all wall mount angle screws for looseness.
 Select a good location. If not, accidents may occur or the
sound bar may get damaged.
 SHARP is not responsible for accidents resulting
from improper installation.
Driving screws
SHARP designed the sound bar so you may hang them
on the wall. Use proper screws (not supplied). See below
for size and type.
1/8" (3.2 mm)
3/8" (9 mm)
7/8" (Min. 22 mm)
3/16"
(5 mm)
Fixing wall mount angle
(Horizontal position)
1 Fix the pattern paper to the wall in horizontal
position as below.
Wall surface
Pattern paper
44 mm
44 mm
29 mm
29 mm
926 mm
2 Make a hole on the wall following the screw
point marks on the pattern paper by using a
drill.
Wall surface
1-1/4" (32 mm)
3/8" (8-9 mm)
3 Fix a wall mount plug (not supplied) into the
hole using a hammer, until it is flush with the
wall surface.
Wall surface
1-1/4" (32 mm)
3/8" (8-9 mm)
4 Screw the wall mount angle to the wall as shown
in the illustration. (Total screw is 8 pieces)
Wall mount angle
Wall mount
angle Wall
mount
angle
(screws x 4)
(screws x 4)
Wall surface
Wall surface
Wall
surface
Note:
Make sure all screws are fully tightened. (screws are not
supplied)
Installing the sound bar
1 Align the wall mount slot at the sound bar to the
wall mount angle.
2 Slot the sound bar into the wall mount angle.
3 Fix them securely.
Wall surface

E-8
Falling prevention
Safety wires (not supplied) are useful to prevent the sound bar from falling off.
2 persons are required to perform this procedure.
When mounting on the wall
1 Loop the safety wires (not supplied) into each
hole of the wall mount angle as shown.
Wall surface
2 Loop the safety wires from wall mount angle
into each hole of sound bar as shown.
Wall surface
3 Align and fix the sound bar to wall mount angle.
Wall surface
4 Tie the safety wires tightly.
Wall surface
When placing on the shelf/table
Loop the safety wires (not supplied) into each hole as shown
and tie the safety wires to the LCD TV stand.

E-9
Placing the system
Installation image:
TV
VCR DVD player Subwoofer
Sound Bar
Place the system as shown.
Remove the protective film covering the sound bar and
subwoofer before turn on the system.
Notes:
The front panel of the sound bar is not removable.
The transmission distance of the wireless signal
between the subwoofer and sound bar is about 32
feet (10m), but may vary depending on your operating
environment. If a steel-concrete or metallic wall is
between the subwoofer and the sound bar, the system
may not operate at all, because the wireless signal
cannot penetrate metal.
Caution:
Do not change the installation direction when the
sound bar is turned on.
Do not stand or sit on the sound bar and subwoofer as
you may be injured.
Do not allow any objects to fall into or to be placed in
the bass reflex duct.
Placing the stand
Place the stand as shown.
Stand
System connections
Make sure to unplug the AC power cord before making any connections.
Subwoofer
Sound Bar
AC outlet
AC 120 V ~ 60 Hz AC outlet
AC 120 V ~ 60 Hz
CAUTION:
TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.

E-10
System connections (continued)
IR (Infrared) transmitter connection
If the TV’s remote sensor is blocked by the sound bar, use the IR transmitter to relay the signal to the TV.
1. Connect the IR transmitter to IR out terminal to allow the TV’s remote signal to pass through.
2. Place the infrared emitter near TV’s remote sensor (refer the operation manual of the TV for the location of the
sensor ).
Point the TV’s remote control at the sound bar remote sensor and operate the TV.
You may need to move the IR transmitter until the TV operates correctly.
Then secure the IR transmitter onto the sound bar using the double sided tape provided.
Note:
Do not use the IR transmitter if the TV’s remote control sensor is not blocked by the sound bar.
Infrared emitter
Double sided tape
TV remote sensor
TV
remote
control
TV
Sound Bar
(Peel off the double sided
tape separator before fixing)
Rear view
HDMI Connection
Caution:
Turn off all other equipment before making this connection.
The illustration below shows the flows of the signals.
1. Method 1
This connection is for HDMI TV with ARC (Audio Return Channel).
Digital tuner
DVD/Blu-ray
TV
Audio and Video signal
TV DVD, Blu-ray disc
player or similar
To HDMI output
terminal
To HDMI (TV ARC) input
terminal
To HDMI OUT (TV ARC) output terminal To HDMI in
p
ut terminal
Sound Bar

E-11
System connections (continued)
2. Method 2
This connection is for HDMI TV without ARC (Audio Return Channel).
TV DVD, Blu-ray disc
player or similar
To H D M I o u t p u t
terminal
To HDMI input terminal
To HDMI input terminal
To HDMI OUT (TV ARC) output terminal Sound Bar
To audio output terminal
To Headphone
terminal
To select HDMI 1, 2 or TV ARC function (Source):
Sound bar operation: Press INPUT button repeatedly until “HDMI 1”, “HDMI 2” or “TV ARC” appears on the display.
Remote control operation: Press the desired HDMI button to select.
Notes:

This sound bar supports HDMI which enables ARC (Audio Return Channel).
 To enable ARC make sure to use High Speed HDMI™ cable (with ARC).
 This ARC feature requires TV that supports ARC. Refer the operation manual of the TV to determine which terminal supports ARC.
 To listen to the sound from a non-ARC-compatible TV, connect the audio output from TV to this system’s. (refer this page)
 This sound bar can be operated (power on/off or volume up/down) via a TV or similar component which supports HDMI CEC
(Consumer Electronics Control). If this does not work, it does not mean this system is faulty. Refer to the operation manual of the
respective component on how to activate the CEC.
Example: Go to the Menu of the component to search and enable the CEC. Different brands may have different naming for the CEC.
For SHARP LCD TV, it is named as AQUOS LINK.
 The system will automatically power off if TV or similar component which supports HDMI CEC, is turned off.
 CEC is not available during Low power consumption mode.
 To listen to the sound from this system, you will need to press the ( ) button (refer page 14) or adjust the
speaker output settings within the TV menu.
For details, refer to the operation manual of the TV.
 If you are unable to select external speaker setting from the TV menu (E.g. For SHARP LCD TV, it is named as AQUOS
AUDIO SP), turn the CEC OFF and ON again.
 To enjoy 3D images, this system must be connected to a 3D-compatible TV and components (3D BD player, etc.) via High Speed
HDMI cables. Put on the 3D glasses, otherwise 3D images may not be viewed properly.
 If you want to use HDMI IN 1 jack, please use the supplied HDMI cable.
Audio connections to TVs, DVD players, VCRs, etc.
Other connection (without HDMI)
The illustration below shows the flows of audio and video signals.
DVD/Blu-ray
Disc Player
Digital tuner, etc.
TV
Audio signal
Video signal
Notes:
Refer to the operation manual of the equipment to be connected.
Fully insert the plugs to avoid fuzzy pictures or noises.
Connecting via this method may disable TV internal speakers.
In some cases, a small background noise could emit from the sound bar, when you use the RCA audio output
terminal connection from a TV-Set/DVD/Blu-ray Disc Player. In such case, please change the connection to the
HDMI/ARC or headphone terminal connection. This effect depends on the used TV/DVD/Blu-ray Disc Player-
Brand, model and age, and it is not a quality matter from the sound bar.

E-12
Audio connections to TVs, DVD players, VCRs, etc. (continued)
Connecting a TV, or DVD player, etc.
Connect to the TV using an optical digital cable or an audio cable.
TV
Audio cable
(commercially
available)
To AUDIO IN
input terminals
Optical digital
audio cable
(commercially
available)
Sound Bar
Audio signal
To optical
digital audio
output
terminal
To audio output terminals
To
HEADPHONE
terminal
To O P T I C A L
IN (optical)
input terminal
or
Blu-Ray/
DVD player/Digital
Tu n e r
To select OPTICAL function:
Sound bar operation: Press INPUT button repeatedly until “OPTICAL” appears on the display.
Remote control operation: Press the “OPTICAL” button.
To select AUDIO IN function:
Sound bar operation:Press INPUT button repeatedly until “AUDIO IN” appears on the display.
Remote control operation: Press the “AUDIO IN” button.
Remote control
Battery installation
Use 2 “AAA” size battery (UM-4, R03, HP-16 or similar).
Batteries are not included.
1 Open the battery cover.
2 Insert the batteries according to the direction
indicated in the battery compartment.
When inserting or removing the battery, push them
toward the battery terminals.
3 Close the battery cover.
Caution:
Remove the battery if the sound bar will not be used
for a long period of time. This will prevent potential
damage due to battery leakage.
Do not use rechargeable battery (nickel-cadmium
battery, etc.).
Installing the battery incorrectly may cause the sound
bar to malfunction.
Batteries (battery pack or battery installed) shall not
be exposed to excessive heat such as sunshine, fire
or the like.
Notes concerning use:
Replace the battery if the operating distance is reduced
or if the operation becomes erratic.
Periodically clean the transmitter on the remote control
and the sensor on the sound bar with a soft cloth.
Exposing the sensor on the sound bar to strong light
may interfere with operation. Change the lighting or the
direction of the sound bar.
Keep the remote control away from moisture, heat,
shock, and vibrations.

E-13
Remote control (continued)
Test of the remote control
Point the remote control directly at the remote sensor on
the sound bar.
The remote control can be used within the range
shown below:
Remote sensor
8" - 20'
(0.2 m - 6 m) 15°15°
General control
Make sure to enable the HDMI CEC when making
HDMI connection. For details, refer to the operation
manual of the TV.
To turn the power on
Press the ON/STANDBY button on the sound bar or the
remote control.
The power turns on and the subwoofer indicator turns
blue. If the power does not turn on, check whether the
AC power cord is plugged in properly.
The system will automatically power on if TV or similar
component which supports HDMI CEC, is turned on.
To set the sound bar to standby mode:
Press the ON/STANDBY button again on the sound bar or
the remote control and the subwoofer indicator turns red.
Notes:
A slight audio delay after TV is turned ON does not
mean that the system is faulty. This is normal.
“AQUOS speaker is enabled” message will be
displayed if SHARP LCD TV does not detect HT-SB602
during power on. However the message “AQUOS
audio with AQUOS LINK is enabled” will be displayed
soon as HT-SB602 is detected. These messages may
vary for other TV model.
Demonstration mode
The first time the unit is plugged in, it will enter the
STANDBY (demonstration) mode.
To cancel the STANDBY (demonstration) mode, press
and hold the ECO MODE button (remote control) during
power standby mode. The unit will enter the low power
consumption mode.
To return to the STANDBY (demonstration) mode,
press the ECO MODE button again.
During STANDBY condition, NFC function is activated
once your device touches the supplied NFC tag when
there is no HDMI connection.
Connecting the wireless Subwoofer
The sound bar and subwoofer will link automatically
(wirelessly) when turned on as it is already pre-linked at
the factory. If the link cannot be established, please set the
connection by the following method.
1. Press and hold the PAIRING button on the sound bar
or SW LINK on the remote control for more than 3
seconds.
2. Within 2 minutes, press and hold the SW LINK button
on the subwoofer for more than 3 seconds.
During pairing process:
On sound bar: “SW LINK” will blink.
On subwoofer: indicator will blink in blue.
When pairing is successful:
On sound bar: “SW LINK” disappears.
On subwoofer: indicator turns blue.
SW LINK
SW LINK
Sound Bar Remote
Control Subwoofer
Notes:
If a device such as microwave oven, wireless LAN card,
Bluetooth device or any other device that uses the
same 2.4GHz frequency near the system, some sound
interruption may be heard due to interference.
The transmission distance of the wireless signal between
the subwoofer and sound bar is about 32 feet (10m), but
may vary depending on your operating environment. If a
steel-concrete or metallic wall is between the subwoofer
and the sound bar, the system may not operate at all,
because the wireless signal cannot penetrate metal.
Caution:
Keep the subwoofer away from water and moisture.
To get the optimum listening performance, make sure
the area around the sound bar and subwoofer is clear
of any obstacles.

E-14
General control (continued)
Display brightness control
Press the DIMMER button to adjust the brightness of the
display.
( Display is dim )
(Display gets dimmer)
(
Display is bright )
DIMMER 1
DIMMER 2
DIMMER OFF
Volume auto fade-in
If you turn off and on the sound bar with the volume set
to 80 or higher, the volume starts at 40 and fades in to
the last set level.
Volume control
Sound bar operation:
Press the VOLUME +
button to increase the
volume and the VOLUME –
button for decreasing.
MIN MAX
2 99
.....
1
Remote control operation:
Press the VOL + button to increase the volume and the
VOL – button to decrease the volume.
Muting
The volume is muted temporarily when pressing the
(MUTE) button on the remote control. Press again to
restore the volume.
Note:
When the sound bar is turned off and back on again,
muting is canceled.
Sound Mode
Sound bar operation:
To change to a different mode, press the SOUND MODE
button repeatedly until the desired sound mode is
displayed.
Remote control operation:
Press the desired sound mode button.
CINEMA (for cinema sound effect)
MUSIC (for standard sound effect)
GAME (for game sound effect)
SPORT (for sport broadcasting)
NEWS (for news)
NIGHT (for night)
BYPASS (for flat sound effect)
Bass and Treble Control
Bass and Treble control is applicable during BYPASS
mode only.
Bass Control
1. Press the BASS button.
2. Within 5 seconds, press the VOL (+ or –) button to
adjust the bass.
Treble Control
1. Press the TREBLE button.
2. Within 5 seconds, press the VOL (+ or –) button to
adjust the bass.
Subwoofer level control
The subwoofer level can be
adjusted.
To increase the level, press
the SW LEVEL button.
+5–5 –4 +4
.....
To decrease the level, press the SW LEVEL button.
Notes:
When sound from the speaker is distorted, decrease
the subwoofer level.
When changing the subwoofer level, the output level
of the subwoofer is also changed.
AV SYNC level control
The AV SYNC level can be
adjusted.
To increase the level, press
the AV SYNC + button. 0+1 +3
.....
To decrease the level, press the AV SYNC – button.
 Speaker output selection (HDMI connection)
Press button on the remote control until “TV
SPEAKER” or “SB SPEAKER” appears on the display to
toggle sound output between this sound bar or TV.
Function
TV ARCHDMI 2 OPTICAL AUDIO IN HDMI 1 BLUETOOTH
Sound bar operation:
Press the INPUT button repeatedly to select the desired
input source.
Remote control operation:
Press the desired function button.
Note:
The backup function will protect the memorized function
mode for a few hours should there be a power failure or
the AC power cord becomes disconnected.

E-15
General control (continued)
APC (Auto Power Off Control)
This sound bar can be set to turn off automatically if
no signal is detected. (During Audio In and Optical In
function)
1. Press the APC button repeatedly to select the time.
APC 15 MIN
A
PC 20 MIN
APC 10 MINAPC 5 MIN
2. The sound bar will enter the power standby mode
automatically if no signal is detected after the preset
time has elapsed.
Auto detect signal
During standby mode, the unit will automatically power
on if it detects audio signal from AUDIO IN or OPTICAL
IN terminal.
Auto power off function
The unit will enter standby mode if:
BLUETOOTH: No connection for 60 seconds.
Audio Return Channel (ARC)
(Audio Return Channel submenu)
The audio return channel (ARC) function enables an
HDMI ARC-capable TV to send the audio stream to the
HDMI OUT jack of the receiver. To use this function, you
must select the TV ARC input and your TV must supports
the ARC.
3D sound mode
S+ 3D technology creates 3D sound through speakers
regardless of the type of sound source, whether it is
monaural, stereo or multichannel. It simulates sound
transmission characteristics using digital signal
processing to create a widening effect on the sound in
the ambient space around the sound source.
By using this technology, multichannel surround sound
can be produced from 2.1ch source.
Press the 3D AUDIO button repeatedly to select:
3D AUDIO 1 : Sound effect that emphasizes 3D
sound.
3D AUDIO 2 : Sound effect that maintains the 3D
sound and improve vocal clarity.
3D AUDIO OFF : 3D sound effect off.
This product incorporates decoders supporting the
Dolby Digital system and DTS system.
DTS (Digital
Theater
Systems)
One of the digital audio systems for
theatrical use. As the sound quality
is emphasized, you can enjoy the
realistic sound effect in the home
theater system.
Lights up when detecting DTS signal.
Dolby Digital One of the digital audio systems for
theatrical use. You can also enjoy
the stereophonic effect in the home
theater system.
Lights up when detecting Dolby Digital
signal.
PCM
(Pulse Code
Modulation)
This is a general term for digitally
encoded audio signals on a CD or
DVD.
This sound bar lets you enjoy playback
of digital signals from sources such as
CD or DVD.

E-16
Bluetooth one touch connection via NFC
About NFC technology
Near Field Communication (NFC) is a set of standards for
devices (smartphones/tablets) to establish radio communi -
cation with each other by touching/tapping them together or
bringing them into close proximity.
Using NFC in this product simplifies the pairing method of
Bluetooth connectivity.
This audio system supports NFC-enabled device
with Android 4.1, Jelly Bean and higher.
For device with a lower Android version, refer the
operation manual of the device for recommended
app (application).
Unlike other wireless technology, NFC requires no
discovery or pairing.
Simply tap the source device to the NFC detection area
on the subwoofer or NFC tag to instantly enjoy seamless
connectivity between your smart device and the audio
system.
NFC detection area
NFC detection area location may vary depending on the
device (smartphone / tablet). Refer operation manual of the
device for detail.
A Bluetooth audio
source device
(smartphone /
tablet).
NFC tag
NFC
detection area
Or
(
durin
g
standb
y
mode
)
M
a
n
u
a
l
B
l
u
e
t
o
o
t
h
s
e
t
t
i
n
g
Switch ‘ON’
Bluetooth
Search /
scan
Pairing
Connect
NFC tag set up
The NFC tags can be placed anywhere convenient to you.
The velcro tapes supplied will help to secure the tags onto
the desired location.
Caution :
Make sure that the NFC tag is placed on a flat and level
surface.
If you choose not to use the velcro tape, do not place
the NFC tag near metal surface to avoid connection
interference during tagging.
Important:
NFC tag provided has unique ID for each sound bar.
SHARP will not be held liable for the damages caused
by rewriting the tags.
Keep all small parts away from children as they may be
accidentally swallowed.
1 Peel the separator off the velcro tape (loop type)
and stick it on a desired surface.
Separator
Velcro
tape (loop
type)
2 Peel the separator off the velcro tape (hook type)
and stick it to the rear of the NFC tag. Then place
the tag onto the desired location.
Separator
Rear view of the
NFC tag
Velcro tape
(hook type)

E-17
Bluetooth one touch connection via NFC (continued)
NFC connection for audio playback
Check that:
Your device (smartphone / tablet) has an NFC function.
NFC function on your device is turned on.
Screen lock function of the device is off.
This unit is not in Eco mode.
1 Touch your device to the NFC detection area on the
subwoofer or supplied NFC tag.
NFC tag
NFC detection area
Or
2 A pop-up window asking whether to proceed with the
Bluetooth connection appears on the device. Select
<YES>.
The ‘connected’ message appears when the connec-
tion is complete.
3 Playback will start automatically. Otherwise, press
play (on remote control or source device).
Sound will be heard from the speakers of this unit via
audio streaming.
Your device must be within 10 meters from the sound
bar.
Bluetooth operation buttons (remote control only)
Press the button to play or pause.
Press the button to skip up.
Press and hold to fast forward.
Press the button to skip down.
Press and hold to fast reverse.
Notes:
To disconnect, simply touch your device to the NFC
detection area on the subwoofer or NFC tag again.
To listen to audio via Bluetooth connectivity without
NFC tag - refer “Pairing with other Bluetooth source
devices” on page 18.
It takes about 6-8 seconds for a Bluetooth enabled device
(eg. smartphone) to establish Bluetooth connection with
this unit via NFC or manual connection.
Listening to Bluetooth enabled devices
Bluetooth
Bluetooth wireless technology is a short-range radio
technology that enables wireless communication between
various types of digital devices, such as mobile phone or
computer. It operates within a range of about 10 meters (30
feet) without the hassle of having to use cables to connect
these devices.
This unit supports the following:
Communication System: Bluetooth Specification version
2.1 Bluetooth + Enhanced Data Rate (EDR).
Support Profile : A2DP (Advanced Audio Distribution Profile)
and AVRCP (Audio/Video Remote Control Profile)
Notes when using unit with a mobile phone
This unit cannot be used to talk over the telephone even
when there is a Bluetooth connection made to a mobile
phone.
Please refer to the operating manual supplied with the
mobile phone for details on operation of your mobile
phone while transmitting the sound using a Bluetooth
connection.
Pairing Bluetooth devices
Bluetooth devices need to be initially paired first before they
can exchange data. Once paired, it is not necessary to pair
them again unless:
Pairing is made with more than 8 devices. Pairing can
only be made one device at a time. This unit can be
paired to a maximum of 8 devices. If subsequent device
is paired, the oldest device paired, will be deleted and
replaced with the new one.
This unit is reset. All pairing information is deleted when
unit is reset.
Pairing information is deleted while re-pairing, etc.

E-18
Listening to Bluetooth enabled devices (continued)
Indicators:
Indicator Condition Bluetooth status
Blinks In waiting or pairing mode
Lights up Connected
No indication Unconnected
However, the indication status is not displayed during
standby mode.
Pairing with other Bluetooth source devices
1 Press the POWER ON/STANDBY button to turn the
power on.
2 Press the INPUT button (sound bar) repeatedly or
(Bluetooth) button (remote control) to select Bluetooth
function. “BLUETOOTH” appears on the display.
3 Sound bar operation: Press PAIRING button.
Remote control operation: Press
and hold the
PAIRING button for 3 seconds or more.
“START PAIRING” appears on the display. The unit is
now in pairing mode and is ready to be paired with
other Bluetooth source device.
4 Perform pairing procedure on the source device to
detect this unit. “HT-SB602 SHARP” will appear in
the detected devices list (if available) in the source
device. (Refer the source device operating manual for
details).
Notes:
Place the devices to be paired within 3 feet (1 meter)
of each other when pairing.
Some source devices are unable to display lists of
detected devices. To pair this unit with the source
device, refer to the source device operating manual
for details.
5 Select “ HT-SB602 SHARP” from the source list. If
Passcode* is required, enter “0000”.
* Passcode may be called PIN Code, Passkey, PIN
number or Password.
6 “CONNECTED” appears on the display once the
unit is successfully paired with the source device.
(Pairing information is now memorized in the unit.)
Some audio source devices may connect with the unit
automatically after pairing is completed, otherwise
follow the instructions in the source device operating
manual to start connection.
7 Press the play button on sound bar, remote control or
source device to start Bluetooth streaming playback.
Notes:
If a device such as microwave oven, wireless LAN card,
Bluetooth device or any other device that uses the
same 2.4 GHz frequency near the system some sound
interruption may be heard.
The transmission distance of the wireless signal
between the device and the sound bar is about 10
m (32 ‘), but may vary depending on your operating
environment. If a steel concrete or metallic wall is
between the device and the sound bar, the system may
not operate at all, because the wireless signal cannot
penetrate metal.
If this unit or the source device is turned off before
Bluetooth connection is completed, pairing will not
be completed and the pairing information will not be
memorized. Repeat step 1 onwards to start pairing again.
To pair with other devices, repeat steps 1 - 5 for each
device. This unit can be paired to a maximum of 8
devices. If subsequent device is paired, the oldest device
paired, will be deleted and replaced with the new one.
Once a device is ousted or deleted from the pairing list,
the pairing information for the device is also deleted. To
listen to the sound from the device again, it needs to be
re-paired. Perform steps 1 - 5 to pair the device again.
Listening to the sound
Check that:
The source device Bluetooth functionality is ON.
Pairing of this unit and the source device is completed.
Unit is in connected mode.
1 Press the POWER ON/STANDBY button to turn the
power on.
2 Press the FUNCTION button to select Bluetooth
function.
3 Start the Bluetooth connection from the Bluetooth
stereo audio source device.
4 Press the Bluetooth /button.
Notes:
For various Bluetooth operations, refer “NFC
connection for audio playback” on page 17.
If the source device has an extra bass function or
equalizer function, set them to off to avoid sound
distortion.
Note:
Make the Bluetooth connection again if the source device
is not turned on, or its Bluetooth functionality is off or is
in sleep mode.
To disconnect the Bluetooth device
Perform any of the followings.
– Disconnect the Bluetooth connection on the audio source
device. Refer the operating manual supplied with the
device.
– Turn off the Bluetooth stereo audio source device.
– Turn off this unit.
Note:
The volume of this unit may not be controlled as intended
depending on the device.
Auto power on
During Standby mode, when music is played from your
device, the unit will automatically power on when the
Bluetooth connection has been set up between the sound
bar and your device. They remain connected if there is no
HDMI connection.
Note:
This function is not applicable during Demonstration mode
off.

E-19
Operating the TV with the remote
control
You can operate Sharp TVs with this system’s remote
control.
Watching TV
Point the remote control at the TV.
1 Press the TV ( ) ON/STANDBY button to turn
on the TV.
2 Pressing the TV CH + or – button enables TV
channel switching.
3 Press the TV VOL + or – button to adjust the TV
volume.
Other operable button
Input Select Button
Mute (TV)
AV mode
Troubleshooting chart
Many potential problems can be resolved by the owner without
calling a service technician.
If something is wrong with this product, check the following
before calling your authorized SHARP dealer or service center.
General
Symptom Possible cause

No sound is heard.  Is the input signal (selection) set
properly?
 Is the volume level set to “MIN”?
 Is muting activated?
 Is HDMI compliant equipment
being used?
 Is the HDMI cable connected
correctly?
Connect the HDMI cable correctly
and then perform the reset
procedure. (refer page 20)
 Do not connect or disconnect
an HDMI cable while power is
on. This may lead to operation
problems.
 The sound from
subwoofer is not
well balanced.
 Is the subwoofer level set to the
minimum or maximum level?
 Power turns off
suddenly.
 Is the HDMI cable connected
correctly? Connect the HDMI
cable correctly and then perform
the reset procedure.
 Noise is heard
during playback.
 Move the speaker away from any
computers or mobile phones.
 When a button
is pressed, the
sound bar does not
respond.
 Set the sound bar to the standby
mode and then turn it back on.
 The power is not
turned on.
 Is the sound bar unplugged?
 The protection circuit may be
activated. Unplug and plug in the
power cord again after 5 minutes
or more.
 3D images not
displayed on the
TV.
 Depending on the TV and Video
component, 3D images may not
be displayed.
Check the operation manual of the
respective component.
 HDMI cable not support 3D image.
 Background noise
appears when
connecting with
RCA audio output
terminal connection
from a TV-set/
DVD/Blu-ray Disc
Player.
 Please change to HDMI/ARC or
headphone terminal from TV-Set/
DVD/Blu-ray Disc Player. This
effect may occur depending on
TV/DVD/Blu-ray Disc Player-
Brand, model and age, and it is
not the sound bar problem.
 Wireless
connection cannot
be established.
 Check the distance between the
sound bar and subwoofer (less
than 32 feet (10m)).
 Make sure there is no other
wireless devices near the unit.
