Sharp HT-SB500 User manual

SOUND BAR SYSTEM
MODEL
HT-SB500
OPERATION MANUAL
Thank you for purchasing this SHARP product. To obtain the best
performance from this product, please read this manual carefully. It
will guide you in operating your SHARP product.
Note:
This product is recommended for flat panel TV (LCD and
plasma).
SRS TruSurround HDTM creates an immersive, feature-rich surround
sound experience from two speakers, complete with rich bass, high
frequency detail and clear dialog.
is a trademark of SRS Labs, Inc.
TruSurround HD technology is incorporated under license
from SRS Labs, Inc.

2
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
Important Instruction
SPECIAL NOTES
NOTE
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
WARNING
FCC Regulations state that any unauthorized changes or
modifications to this equipment not expressly approved by the
manufacturer could void the user's authority to operate this
equipment.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVIC-
ING TO QUALIFIED SERVICE PERSONNEL.
Explanation of Graphical Symbols:
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product s en-
closure that may be of sufficient magnitude
to constitute a risk of electric shock to per-
sons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and main-
tenance (servicing) instructions in the lit-
erature accompanying the appliance.
FOR YOUR RECORDS
Foryourassistanceinreportingthisunitincaseoflossortheft,
pleaserecordbelowthemodelnumber and serialnumberwhich
are located on the bottom of the unit.
Please retain this information.
Model number .......................................................
Serial number .......................................................
Date of purchase .......................................................
Place of purchase .......................................................

3
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
Important Instruction
IMPORTANT SAFETY INSTRUCTIONS
Electricity is used to perform many useful functions, but it can
also cause personal injuries and property damage if improperly
handled. This product has been engineered and manufactured
with the highest priority on safety. However, improper use can
result in electric shock and/or fire. In order to prevent potential
danger, please observe the following instructions when
installing, operating and cleaning the product. To ensure your
safety and prolong the service life of this product, please read
the following precautions carefully before use.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
9) Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
11) Only use attachments/accessories specified by the
manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
Additional Safety Information
15) Power Sources - This product should be operated only from
the type of power source indicated on the marking label. If
you are not sure of the type of power supply to your home,
consult your product dealer or local power company. For
product intended to operate from battery power, or other
sources, refer to the operating instructions.
16) Overloading - Do not overload wall outlets, extension cords,
or integral convenience receptacles as this can result in a
risk of fire or electric shock.
17) Object and Liquid Entry - Never push objects of any kind into
this product through openings as they may touch dangerous
voltage points or short-out parts that could result in a fire or
electric shock. Never spill liquid of any kind on the product.

4
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
Important Instruction
IMPORTANT SAFETY INSTRUCTIONS (continued)
18) Damage Requiring Service - Unplug this product from the
wall outlet and refer servicing to qualified service personnel
under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the
product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following
the operating instructions. Adjust only those controls
that are covered by the operating instructions as an
improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the product to its normal
operation,
e) If the product has been dropped or damaged in any
way, and
f ) When the product exhibits a distinct change in
performance - this indicates a need for service.
19) Replacement Parts - When replacement parts are required,
be sure the service technician has used replacement parts
specified by the manufacturer or have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock, or other
hazards.
20) Safety Check - Upon completion of any service or repairs to
this product, ask the service technician to perform safety
checks to determine that the product is in proper operating
condition.
21) Wall or ceiling mounting - When mounting the product on a
wall or ceiling, be sure to install the product according to the
method recommended by the manufacturer.
22) Power Lines - An outside antenna system should not be
located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such
power lines or circuits. When installing an outside antenna
system, extreme care should be taken to keep from touching
such power lines or circuits as contact with them might be
fatal.
23) Outdoor Antenna Grounding - If an outside antenna or cable
system is connected to the product, be sure the antenna or
cable system is grounded so as to provide some protection
against voltage surges and built-up static charges.
Article810 of the National Electrical Code, ANSI/NFPA 70,
provides information with regards to proper grounding of the
mast and supporting strcorducture, grounding of the lead-in
wire to an antenna discharge unit, connection to grounding
electrodes, and requirements for the grounding electrode.
24) Protective Attachment Plug - The product is equipped with
an attachment plug having overload protection. This is a
safety feature. See Instruction Manual for replacement or
resetting of protective device. If replacement of the plug is
required, be sure the service technician has used a
replacement plug specified by the manufacturer that has the
same overload protection as the original plug.
25) Stand - Do not place the product on an unstable cart, stand,
tripod or table. Placing the product on an unstable base can
cause the product to fall, resulting in serious personal
injuries as well as damage to the product. Use only a cart,
stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the
product on a wall, be sure to follow the manufacturer's
instructions. Use only the mounting hardware
recommended by the manufacturer.

5
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
General Information
Accessories
Please confirm that only the following accessories are included.
Note:
The AC/DC adaptor may be different from the one in the drawing.
Contents
Page
General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . 7 - 9
Preparation for Use
Speaker preparation . . . . . . . . . . . . . . . . . . . . . . 10 - 12
Placing the speaker . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Falling prevention . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Speaker connections to TVs . . . . . . . . . . . . . . . . 14 - 16
AC power connection . . . . . . . . . . . . . . . . . . . . . . . . 17
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Basic Operation
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . 19 - 21
References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . 22
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Error indicators and warnings . . . . . . . . . . . . . . . . . 24
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
CONSUMER LIMITED WARRANTY . . . . . . . Back cover
Remote control x 1
(RRMCGA200AWSA)
RCA cable (2 pins - 2 pins) x 1
(QCNWGA041AWPZ))
Spike x 4 (length: 25 mm)
(GLEGMA005AWSA)
Foot cushion x 4
(PCUSSA118AWZZ)
AC power lead x 1
(QACCDA005AWZZ)
AC/DC adaptor x 1
(RADPAA061AWZZ)
Wall mount angle x 2
(LANGKA167AW01)
(Spike + Nut) x 4 (length: 30 mm)
(GLEGMA004AWSA)
Pattern paper x 1
(TCAUHA023AWZZ)
Nut
ENERGY STAR®Program Information
ENERGY STAR®is a U.S. registered mark.
Products that have earned
the ENERGY STAR
®
are
designed to protect the
environment through
superior energy efficiency.

6
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
General Information
Precautions
General
Please ensure that the equipment is positioned in a well-
ventilated area and ensure that there is at least 4" (10 cm) of
free space along the sides and top of the equipment.
Use the speaker on a firm, level surface free from vibration.
Keep the speaker away from direct sunlight, strong magnetic
fields, excessive dust, humidity and electronic/electrical
equipment (home computers, facsimiles, etc.) which
generate electrical noise.
Do not place anything on top of the speaker.
Do not expose the speaker to moisture, to temperatures
higher than 140°F (60°C) or to extremely low temperatures.
If your system does not work properly, disconnect the AC
power cord from the AC outlet. Plug the AC power cord back
in, and then turn on your system.
In case of an electrical storm, unplug the speaker for safety.
Hold the AC power plug by the head when removing it from
the AC outlet, as pulling the cord can damage internal wires.
The AC power plug is used as a disconnect device and shall
always remain readily operable.
Do not remove the outer cover, as this may result in
electric shock. Refer internal service to your local
SHARP service facility.
This speaker should only be used within the range of
41°F - 95°F (5°C - 35°C).
Do not use an external power supply other than the 12V DC
supplied with this unit as it may be damaged.
SHARP is not responsible for damage due to improper use.
Refer All servicing to a SHARP authorised service centre.
Warning:
The voltage used must be the same as that specified on this
speaker. Using this product with a higher voltage other than
that which is specified is dangerous and may result in a fire
or other type of accident causing damage. SHARP will not be
held responsible for any damage resulting from use of this
speaker with a voltage other than that which is specified.
The supplied AC/DC adaptor contains no user serviceable
parts. Never remove covers unless qualified to do so.
It contains dangerous voltages, always remove mains plug
from the main outlet jack before any service operation or
when not in use for a long period.
The AC/DC adaptor supplied with the HT-SB500 must not be
used with other equipment.
Never use an AC/DC adaptor other than the one specified.
Otherwise, problem or serious hazards may be created.
Volume control
The sound level at a given volume setting depends on speaker
efficiency, location, and various other factors. It is advisable to
avoid exposure to high volume levels, which occurs while
turning the speaker on with the volume control setting up high,
or while continually listening at high volumes.
Precaution in using on the touch panel
 Do not use rough material to wipe the touch panel.
 Do not press the pad too hard, it can damage the touch sensor.
4" (10 cm)
4" (10 cm) 4" (10 cm)

7
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
General Information
Controls and indicators
Front Panel
Reference page
1. Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2. Information Display. . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3. On/Stand-by Pad/Indicator . . . . . . . . . . . . . . . . . . . . . 19
4. News Pad/Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
5. Cinema/Game Pad/Indicator. . . . . . . . . . . . . . . . . . . . 19
6. Sport Pad/Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
7. Standard Pad/Indicator . . . . . . . . . . . . . . . . . . . . . . . . 19
8. Function Pad/Indicator . . . . . . . . . . . . . . . . . . . . . . . . 21
9. Volume Down Pad/Indicator . . . . . . . . . . . . . . . . . . . . 19
10. Volume Up Pad/Indicator . . . . . . . . . . . . . . . . . . . . . . 19
Reference page
11. Left Front Speaker
12. Bass Reflex Duct
13. Subwoofers
14. Left Center Speaker
15. Right Center Speaker
16. Right Front Speaker
17. Dolby Virtual Speaker Pad/Indicator . . . . . . . . . . . . 20
18. Dolby Prologic II Indicator. . . . . . . . . . . . . . . . . . . . . 20
19. DTS Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
20. Dolby Digital Indicator . . . . . . . . . . . . . . . . . . . . . . . . 20
11 12 12 1614 15
13 13
12
435
67 8 910 17
1819
20

8
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
General Information
Rear Panel
Reference page
1. Audio Line In 2 Jack . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2. Line In 1 Jacks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
3. DC Input Jack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4. Subwoofer Pre-Out Jack . . . . . . . . . . . . . . . . . . . . . . . 13
5. Optical Digital Audio Input Jack . . . . . . . . . . . . . . . . 16
6. Coaxial Digital Audio Input Jack. . . . . . . . . . . . . . . . . 16
1423 56

9
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
General Information
Controls and indicators (continued)
Note:
Before using remote control, please remove plastic shield at
battery holder.
Remote Control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . 14
2. Dolby Virtual Speaker Button . . . . . . . . . . . . . . . . . . 16
3. Cinema/Game Button. . . . . . . . . . . . . . . . . . . . . . . . . 15
4. News Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
5. Volume Up Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6. Digital 1-2 Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
7. Volume Down Button . . . . . . . . . . . . . . . . . . . . . . . . . 15
8. Dimmer/Sens On/Off Button . . . . . . . . . . . . . . . . . . . 15
9. Bass/Treble Button . . . . . . . . . . . . . . . . . . . . . . . . . . 17
10. TV Operation Buttons . . . . . . . . . . . . . . . . . . . . . . . . . 5
11. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . 15
12. Sport Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
13. Standard Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
14. Line 1-2 Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
15. Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
16. Subwoofer Level Up Button . . . . . . . . . . . . . . . . . . . 17
17. Subwoofer Level Down Button . . . . . . . . . . . . . . . . . 17
18. Center Speaker Level Up Button . . . . . . . . . . . . . . . 17
19. Center Speaker Level Down Button . . . . . . . . . . . . . 17
Notes:
Some models of SHARP TV may not be operable.
SHARP TV remote control will not work with HT-SB500
system.
2
3
4
5
6
7
8
9
10 19
18
17
16
15
14
13
12
11
1
Remote control
Plastic shield
Battery holder
TV Operation Buttons (Only SHARP TV):
On/Stand-by
Button
Sets the TV
power to “ON”
or “STAND-
BY”.
Input Select
Button (TV)
Press the
button to
switch the
input source.
Volume Up
and Down
Buttons
Turn up/down
the TV
volume.
Channel Up
and Down
Buttons
Switch up/
down the TV
channels.

10
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
Preparation for Use
Speaker preparation
Select from three installation methods according to the
preferred position.
Notes:
Option 1 or option 2 indicates spike positions based on LCD
TV stand.
When attaching the spikes, place the speaker on a cushion
or soft cloth to avoid damage.
Caution:
When using these spikes on glossy or slippery table such as on
glass top, stick foot cushions at the bottom of the spikes to avoid
slippage.
Note:
Option 1 or option 2 foot cushion positions based on LCD TV
stand.
Make sure to unplug the AC power cord before installing
the speaker or changing the position.
Tighten all spikes as shown
Option 2 Option 1
Using spikes
You may choose from the two different spike lengths provided:
25 mm and 30 mm.
Nuts (secured on 30 mm spikes) must be used when installing
either the 25 mm or 30 mm spikes.
The speaker can be levelled by adjusting the spikes and nuts.
Attach foot cushions as shown
Option 1
Option 2
Using foot cushions

11
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
Preparation for Use
Speaker preparation (continued)
Caution:
Be very careful to prevent the speaker [4.84 lbs. (2.2 kg)] from
falling when mounting on the wall.
Before mounting, check the wall strength. (Do not put on the
veneer plaster or whitewashed wall. The speaker may fall.) If
unsure, consult a qualified service technician.
Mounting screws are not supplied. Use appropriate ones.
Check all wall mount angle screws for looseness.
Select a good location. If not, accidents may occur or the
speaker may get damaged.
SHARP is not responsible for accidents resulting from
improper installation.
Driving screws
SHARP designed the speakers so you may hang them on the
wall. Use proper screws (not supplied). See below for size and
type.
Wall mount angle fixed to the wall
(Horizontal position)
(Continued to the next page)
To mount the speaker on the wall
1/8" (3.2 mm)
3/8" (9 mm)
Min. 7/8" (22 mm)
3/16"
(5 mm)
1Fix the pattern paper to the wall in horizontal position
as below.
2Make a hole on the wall following the screw point
marks on the pattern paper by using a drill.
3Fix a wall mount plug into the hole using a hammer,
until it is flush with the wall surface.
1-1/8"(29 mm)
1-1/8"(29 mm)
1-3/4" (44 mm)
1-3/4" (44 mm)
20-1/32" (509 mm)
Pattern paper
Wall surface
Wall surface
3/8" (8-9 mm)
1-1/4" (32 mm)
Wall surface
3/8" (8-9 mm)
1-1/4" (32 mm)

12
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
Preparation for Use
Note:
Make sure all screws are fully tightened. (screws are not
supplied)
Installing the speaker
4Screw the wall mount angle to the wall as shown in the
illustration. (Total screw is 8 pieces)
Wall surface
Wall mount angle
Wall mount angle
Wall surface
Wall surface
Wall mount angle
(screws x 4)
(screws x 4)
1Align the wall mount slot at the speaker to the wall
mount angle.
2Slot the speaker into the wall mount angle.
3Fix them securely.
Wall surface

13
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
Preparation for Use
Placing the speaker
Installation image:
Place the speaker as shown.
Notes:
As the sound from the speaker is omni-directional, you can
place the speaker anywhere you like. However, it is
recommended to place it as close to the TV as possible.
The front panel of the speaker is not removable.
Caution:
Do not change the installation direction when the speaker is
turned on.
Do not stand or sit on the speaker as you may be injured.
Using other subwoofer
You can connect a subwoofer with an amplifier to the
SUBWOOFER PRE-OUT jack.
Note:
No sound is heard from the subwoofer without a built-in
amplifier.
TV
VCR DVD player
Audio signal
Audio cable
(commercially available)
Commercially available
subwoofer
(amplifier built in)
To audio input jack
To SUBWOOFER PRE-OUT jack
Speaker

14
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
Preparation for Use
Falling prevention
Safety wires (not supplied) are useful to prevent the speaker
from falling off the table.
Loop the safety wires (not supplied) into each hole as shown
and tie the safety wires to the LCD TV stand.
Speaker connections to TVs
Caution:
Turn off all other equipment before making any connections.
Tuner receiving for other audio system
Placing the aerial near the speaker AC power cord may
cause noise pick up. Place the aerial away from the speaker
for better reception.
Notes:
To connect to TV, use either LINE IN 1 jacks or AUDIO LINE
IN 2 jack only.
Refer the operation manual of the equipment to be
connected.
Fully insert the plugs to avoid fuzzy pictures or noises.

15
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
Preparation for Use
Speaker connections to TVs (continued)
Connecting to a TV
If the TV/monitor has an audio output, connect it to the LINE IN
1 jacks on the rear of the speaker.
To select LINE IN 1 function:
On speaker: Press FUNCTION button repeatedly until “L1” is
displayed.
On remote control: Press LINE 1-2 button repeatedly until
“L1” is displayed.
Connecting to a TV (with Headphone jack)
If the TV/monitor has headphone jack, connect it to the LINE IN
2 jack on the rear of the speaker.
To select LINE IN 2 function:
On speaker: Press FUNCTION button repeatedly until “L2” is
displayed.
On remote control: Press LINE 1-2 button repeatedly until
“L2” is displayed.
Notes:
If the TV volume is continuously in low level, the speaker will
automatically power off. Increase the TV output volume to
enjoy the sound from the speaker.
If the speaker volume is continuously in very high level, the
speaker will mute and recover after several seconds.
The information display on the sound bar system will not
display anything when increasing or decreasing the volume
level.
To audio output jacks
RCA cable (supplied)
Speaker
TV
To LINE IN 1
jacks
HEADPHONE
To HEADPHONE jack
Audio cable (not supplied)
Speaker
TV
To AUDIO LINE
IN 2 jack

16
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
Preparation for Use
Connecting a digital tuner, etc.
Connect to the digital tuner, etc. using an optical digital audio
cable or a coaxial digital audio cable.
To select DIGITAL 1 (optical input) or DIGITAL 2 (digital
input) function:
On speaker: Press FUNCTION button repeatedly until “D1”
or “D2” is displayed.
On remote control: Press DIGITAL 1 - 2 button repeatedly to
select “D1” or “D2”.
Note:
When connecting with an optical digital cable, set the digital
output of the digital tuner to PCM. Refer to the operation manual
of the digital tuner.
Coaxial digital audio cable
(commercially available)
Optical digital
audio cable
(commercially
available)
To COAXIAL
input jack
To the TV (video)
To OPTICAL
input jack
Speaker
To coaxial digital audio
output jack
Audio signal
Audio signal
To optical digital
audio output jack

17
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
Preparation for Use
AC power connection
Using with the AC/DC adaptor
Notes:
Unplug the AC/DC adaptor from the AC outlet if the speaker
will not be used for a long period of time.
Use only the supplied AC/DC adaptor. Using other AC/DC
adaptor may cause an electric shock or fire.
1Plug the AC power cord into the AC/DC adaptor.
2Plug the AC/DC adaptor cable into the DC IN jack on
the speaker.
3Plug the AC power cord into a AC outlet. The STAND-
BY indicator will turn ORANGE when AC power is
applied. The power indicator will turn GREEN when
the system in “ON”.
AC/DC Adaptor Cable
DC IN jack
(DC 12 V)
AC/DC Adaptor
AC outlet
(AC 100 - 240 V ~ 50/60 Hz)
AC power cord

18
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
Preparation for Use
Remote control
Battery installation
Precautions for battery use:
Remove the battery if the speaker will not be used for a long
period of time. This will prevent potential damage due to
battery leakage.
Caution:
 Do not use rechargeable battery (nickel-cadmium battery, etc.).
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Batteries (battery pack or batteries installed) shall not be
exposed to excessive heat such as sunshine, fire or the like.
Installing the battery incorrectly may cause the speaker to
malfunction.
Notes concerning use:
Replace the battery if the operating distance is reduced or if
the operation becomes erratic. Purchase “CR 2025”, coin
lithium battery.
Periodically clean the transmitter on the remote control and
the sensor on the speaker with a soft cloth.
Exposing the sensor on the speaker to strong light may
interfere with operation. Change the lighting or the direction
of the speaker if this occurs.
Keep the remote control away from moisture, heat, shock,
and vibrations.
Test of the remote control
Point the remote control directly at the remote sensor on the
speaker .
The remote control can be used within the range shown
below:
Press the ON/STAND-BY button. Does the power turn on? Now,
you can enjoy your system.
1Insert pin into the hole as shown and pull to open the
battery holder.
2Remove the old battery from the battery holder, insert
the new battery and then slide the battery holder back
into the remote control.
Back of remote
control
Pin
Battery holder
Polarity (+) symbol
Battery type
Locking tab Positive (+) side up
15° 15°
Remote sensor
8” - 20’
(0.2 m - 6 m)

19
HT-SB500
2009 October 29 HT-SB500_A6_EN_US.fm
Basic Operation
General control
To turn the power on
Press the ON/STAND-BY button on the remote control or touch
anywhere on the display panel. All the indicators will be
displayed to indicate pad positions.
The power indicator turns green. If the power does not turn
on, check whether the power cord is plugged in properly.
To set the speaker to stand-by mode:
Press the ON/STAND-BY button again on the remote control
or touch ON/STAND-BY pad on the speaker.
The STAND-BY indicator turns orange.
Display brightness control
Press the DIMMER ON/OFF button to adjust the brightness of
the display and sound mode indicator.
Volume auto fade-in
If you turn off and on the speaker with the volume set to 40 or
higher, the volume starts at 20 and fades in to the last set level.
Volume control
Remote control operation:
Press the VOLUME + button to increase the volume and the
VOLUME – button to decrease the volume.
Preset sound mode
Speaker operation:
Touch a desired sound mode on the speaker.
Remote control operation:
Press a desired sound mode on the remote control.
Sound mode indicator and display bright. Display will off after 5
seconds without any button/pad operation.
Sound mode indicator and display dim. Display will off after 5
seconds without any button/pad operation.
VOL VOL
Speaker operation:
Touch volume up pad to increase the
volume and touch volume down pad
to decrease the volume.
Muting
The volume is muted temporarily when pressing
the MUTE button on the remote control. Press
again to restore the volume.
NEWS TruSurround HD on for news
CINEMA/GAME TruSurround HD on for cinema/game
sound effect
SPORT TruSurround HD on for sport broadcasting
STANDARD TruSurround HD on for standard sound
effect
00 01 02 ..... 59 60

20
HT-SB500
2009 October 29HT-SB500_A6_EN_US.fm
Basic Operation
Dolby Virtual Speaker (DVS) sound mode
The Dolby Virtual Speaker (DVS) creates virtual surrounds
comparable to the 5.1ch sound produced by the 3.1ch speaker.
When setting DVS to “ON” for 2 channel stereo signals, Dolby
Pro Logic II brings out virtual sound effects through the signals
converted into 5.1ch.
Press the Dolby Virtual Speaker button.
The Dolby Virtual Speaker indicator lights up.
Notes:
Monaural signals do not generate surround effects.
DVS sound effect may not be obtained depending on signal
types (the Dolby Virtual Speaker indicator blinks). In this
case, set the DVS mode to “OFF”.
If you turn ON DVS, SRS Trusurround HD will automatically
turn OFF.
The DVS can be turned OFF by selecting other preset sound
modes.
This product incorporates decoders supporting the Dolby Digital
system and DTS system.
The Dolby Virtual Speaker creates multichannel-like
sound effects.
Compared with the cinema mode, the bass sound
level is slightly reduced.
The Dolby Pro Logic II indicator also lights up if 2ch
sound signals are detected.
DTS (Digital The-
atre Systems)
One of the digital audio systems for
theatrical use. As the sound quality is
emphasised, you can enjoy the realistic
sound effect in the home theatre
system.
Lights up when detecting DTS signal.
Dolby Digital
One of the digital audio systems for
theatrical use. You can also enjoy the
stereophonic effect in the home theatre
system.
Lights up when detecting Dolby Digital
signal.
Dolby Pro Logic II
System expanding 2ch stereo sound to
more spacious sound. When setting
Dolby Virtual speaker to “ON”, Dolby
Pro Logic II is activated to enjoy the
stereo sound effect.
Lights up when Dolby Pro Logic II is
activated.
ON
