S7000UK
OWNER’S GUIDE

1 20800 862 0453 www.sharkclean.eu
WHEN USING YOUR SHARK®STEAM MOP,
BASIC SAFETY PRECAUTIONS SHOULD
ALWAYS BE FOLLOWED, INCLUDING THE
FOLLOWING:
READ ALL INSTRUCTIONS BEFORE USING
YOUR SHARK® MULTI-FUNCTION STEAM MOP
LITE.
DANGER OF SCALDING.
Please use caution when using the steam mop. The
steam emitted from the steam mop is very hot.
IMPORTANT:
This appliance is not intended for use by persons
with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance by a
person responsible for their safety.
Children shall not use or play with this
appliance. Close supervision is necessary
to keep appliance out of reach of children
during use and cooling.
IMPORTANT SAFETY INSTRUCTIONS
For Household Use Only
27. Store steam mop indoors in a cool, dry place.
28. To avoid circuit overload, do not operate another
appliance on the same socket (circuit) as the
steam cleaner.
29. If an extension cord is absolutely necessary, an
extension cord rated a minimum of 15 ampere,
2.08mm2(14 AWG) cord should be used. Cords
rated for less amperage may overheat. Care
should be taken to arrange cord so that it cannot
be pulled or tripped over.
30. DO NOT leave unattended when the system is
connected to a power supply or electrical outlet.
Turn off all controls before unplugging the unit.
31. DO NOT store unit with damp or wet cleaning
pad attached. Never leave the steam mop in one
spot on any surface for any period of time with
a damp or wet cleaning pad attached as this will
damage your floors.
32. Always unplug and allow the steam mop to cool
before removing the mop head or accessory nozzle.
33. Make sure that the water tank cap is secured
tightly when using the appliance.
WARNING: Your steam mop is designed
to clean hard floor surfaces that will withstand high
heat. Do not use on unsealed wood or unglazed
ceramic floors. On surfaces that have been treated
with wax or some no wax floors, the sheen may
be removed by the heat and steam action. It is
always recommended to test an isolated area of
the surface to be cleaned before proceeding. We
also recommend that you check the use and care
instructions from the floor manufacturer.
SAVE THESE
INSTRUCTIONS
14. DO NOT put any objects into openings. Do not use
with any opening that is blocked.
15. DO NOT put hands or feet under the steam mop.
Unit gets very hot.
16. Use ONLY on flat, horizontal surfaces. Do not use
on walls, counters or windows.
17. DO NOT use on leather, wax polished furniture or
floors, synthetic fabrics, velvet or other delicate,
steam sensitive materials.
18. Liquid or steam must not be directed towards
equipment containing electrical components, such
as the interior of ovens.
19. DO NOT add cleaning solutions, scented
perfumes, oils or any other chemicals to the water
used in this appliance as this may damage the
unit or make it unsafe for use. If you live in a hard
water area, we recommend using distilled water in
your steam mop.
20. When in use, NEVER turn the appliance over or
on its side. NEVER DIRECT STEAM TOWARDS
PEOPLE, ANIMALS OR PLANTS.
21. NEVER LEAVE THE STEAM MOP IN ONE SPOT
ON ANY SURFACE FOR ANY PERIOD OF TIME
WHEN THE CLEANING PAD IS ATTACHED AS
THIS WILL DAMAGE YOUR FLOORS.
22. Carefully remove the cleaning pad immediately
after you have unplugged and allowed the steam
mop to cool.
23. When cleaning the steam mop, unplug the power
cord from the electrical outlet and clean with a dry
or damp cloth. Do not pour water or use alcohol,
benzene or paint thinner on the unit.
24. Extreme caution should be exercised when using
this appliance to clean stairs.
25. Never use steam mop functions without the
cleaning pads attached.
26. Keep your work area well lit.
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR INJURY:
1. Use the system only for its intended use.
2. DO NOT use outdoors.
3. DO NOT leave the appliance unattended when
plugged in. Always unplug the power cord
from the electrical outlet when not in use and
beforeservicing.
4. DO NOT allow the appliance to be used by
children. Close attention is necessary when used
near children, pets or plants.
5. Use only as described in this manual.
6 . Use only manufacturer’s recommended
accessories.
7. DO NOT use with damaged cord or plug.
8. DO NOT USE if the appliance is not working, has
been dropped, dropped into water, damaged or
left outdoors.
9. NO SERVICEABLE PARTS. Incorrect re-
assembly or repair can cause a risk of electrical
shock or injury to persons when the appliance is
used. Contact Customer Service.
10. To protect against a risk of electric shock, DO
NOT immerse the steam mop into water or any
other liquids.
11. DO NOT handle plug or steam mop with wet
hands or operate appliance without shoes.
12. DO NOT pull or carry by power cord, use power
cord as handle, close a door on the power
cord, or pull the power cord around sharp
edges or corners. Keep power cord away from
heatedsurfaces.
13. DO NOT unplug by pulling on power cord. To
unplug, grasp the plug not the power cord. Do not
use extension cords or outlets with inadequate
current carrying capacity.

3 40800 862 0453 www.sharkclean.eu
Contents
Getting Started ....................................................................................... 5
Assembling Your Steam Mop ................................................................... 6
Using Your Steam Mop ............................................................................ 7
Using Your Carpet Glider.......................................................................... 8
Using Your Handheld Steamer.................................................................. 9
Using Your Removable Handheld Steamer with Different Accessories.......... 10
Care of Your Steam Mop.......................................................................... 12
Troubleshooting Guide............................................................................. 14
Thank you for
purchasing the Shark®
Multi-Function Steam
Mop Lite.
This appliance complies with the WEEE-Directive 2002/96/EC on the disposal of electrical and electronic
equipment (WEEE).
This appliance complies with the European directives for electromagnetic compatibility (EMC) 2004/108/EC and its
revisions, as well as Low Voltage Directive (LVD) 2006/95/EC and its revisions.
This marking indicates that this product should not be disposed with other household wastes
throughout the EU. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable reuse of material sources. To return
your used device, please use the return and collection systems or contact the retailer where this
product was purchased. They can take this product for environmental safe recycling.
Although the product is not provided with standby mode or off mode, it still fulfills the requirements of 1275/2008/
EC - the directive for Eco-Design requirements since according to technical justification, it is considered as
inappropriate to provide standby and off modes when connecting to mains. To reduce energy consumption be sure
to unplug the unit after use.
THIS MANUAL COVERS MODEL NUMBER:
S7000UK 11
TECHNICAL SPECIFICATIONS
Voltage: 220-240V~, 50/60Hz
Power: 1250 Watts
Water Capacity: 350 ml IPX4
Guarantee: This product is unconditionally guaranteed for one year against all defects of workmanship and
materials. This guarantee does not affect your statutory rights. If this product proves unsatisfactory please contact
our customer service department on freephone 0800 862 0453 or by e-mail [e-mail].

5 60800 862 0453 www.sharkclean.eu
IMPORTANT: Always make sure the mop is
UNPLUGGED from the wall when not in use. Never
fill the mop, attach the mop head, change or remove
the cleaning pad when the mop is plugged into the
wall. To prolong the life of your Shark®Multi-Function
Steam Mop Lite we recommend using distilled water.
Make sure you only add water to the tank. Chemicals
or cleaning solution may damage the appliance and
could be unsafe for you and your family.
Assembling Your Steam MopGetting Started
When assembling your steam mop there may be a little water in or around the water tank. This is because we test all
our steam mops 100% before you buy them, so you get a quality Shark® Multi-Function Steam Mop Lite.
fig. 1 fig. 2
aMop Handle
bCord Clip (XBTECLP03)
cWater Tank Cap
dHandheld Steamer
ePower Button
fRelease Button
gRectangle Mop Head (3072SO7000)
hAll Purpose Cleaning Pad for Rectangle Head (x2) (P159W)
iCarpet Glider (XCG7000)
n
jConcentrator Nozzle (3011FO2901)
kAccessory Hose (3010FO2901)
lGrout Scrubber Brush (1081SO)
mWindow Squeegee (1078SO)
nFilling Flask (1039SO)
STEAM MOP ASSEMBLY
1Insert the Mop Handle end with the “ “ facing the
front of the unit into the handheld steamer. Push the
mop handle in until you hear it click into place. (fig. 1)
2Snap the mop head into the mop body by lining up
the groove on the back of the mop body with the
groove on the back of the mop head. Push until you
hear it latch into place. Press the release button to
remove or change the mop head. (fig. 2)
3Place the cleaning pad on the floor with the logo
side facing up. Place the Shark®Multi-Function
Steam Mop Lite on top of the pad to attach.
a
c
d
g
e
b
h
i
f
j
k
m
l

7 80800 862 0453 www.sharkclean.eu
1Turn the water tank cap anticlockwise and remove
from the tank. (fig. 3)
2Use the filling flask and pour water into the tank. Do
not overfill. Replace the cap on the water tank. (fig. 4)
IMPORTANT: Do not use on unsealed wood or
unglazed ceramic floors. On surfaces that have been
treated with wax or some no wax floors, the sheen
may be removed by the heat and steam action. It
is always recommended to test an isolated area
of the surface to be cleaned before proceeding.
We recommend that you check the use and care
instructions from the floor manufacturer.
IMPORTANT: Make sure you do not use the mop
without attaching a cleaning pad and adding water
to the tank first. When you are using the mop for the
first time, it might take longer than the normal 30
seconds to start steaming.
Using Your Steam Mop
NOTE: To prolong the life of your Steam Mop, we
recommend using distilled water.
NOTE: Sweep or vacuum your floors prior to cleaning
with your Steam Mop.
3Pull and twist the quick release cord holder to
unwrap the power cord completely. Plug into an
electrical outlet. (fig. 5)
4Press the power button to turn the unit on. (fig. 6)
Using Your Carpet Glider
THE CARPET GLIDER
1The Carpet Glider can be used with the Rectangular
Head to lightly steam your carpet and area rugs.
Just place the mop head with cleaning pad attached
into the glider. (fig. 7)
2Move the Steam Mop back and forth across a
section of the carpet. (fig. 8)
fig. 7
fig. 8
The Steam Mop will not clean your
carpeting or area rugs. However, it is
great for grooming and freshening.
5Clean your floors with a forward and backward
motion.
6Use the reusable, all-purpose cleaning pad to lift up
and lock away all the dirt and debris.
7When the water tank is empty, the Steam Mop will
stop producing steam. You can refill the water tank
at any time as long as the mop is unplugged from
the outlet. Follow the instructions from page 4. This
applies to switching the mop head or cleaning pad
as well.
NOTE: Please wait 2-3 minutes for the Steam Mop
to cool off before switching the mop head or the
cleaning pad. Never leave the Steam Mop with a
damp/wet cleaning pad on any floor.
8When you are done, press the power button to turn
the steam mop off.
fig. 5
fig. 6fig. 4
fig. 3

9 100800 862 0453 www.sharkclean.eu
Your Shark®Multi-Function Steam Mop Lite is designed
to clean surfaces that will withstand high heat and
moisture. Do not use on unsealed wood surfaces
(especially wooden antique furniture), unglazed ceramic
tile, painted surfaces or surfaces that have been treated
with wax, oils, varnishes, or shellac. The sheen may be
removed by the heat, steam, and friction of the cleaning
tools. Lacquer and polyurethane coatings provide a hard
durable protective finish that withstands moisture, but it
is always recommended to test an isolated area of the
surface to be cleaned before proceeding.
We also recommend you check the use and care
instructions from the surface manufacturer.
When cleaning finished wood surfaces, use broad,
continuous cleaning strokes. To prevent surface damage,
avoid focusing steam or allowing the cleaning tools to sit
in one spot for any amount of time.
Using Your Handheld Steamer
1To remove the Handheld Steamer, press and hold
down the Handle Release Button while pulling out
the handle. (fig. 9)
2To remove the mop head, press the mop head
release button and pull the mop head off. (fig. 9)
fig. 9
CAUTION: Do not press the power button while
attaching or removing the Accessory Hose.
CAUTION: Do not use the Accessory Hose without
cleaning tools attached.
1First attach the Accessory Hose to the Handheld
Steamer by snapping the Accessory Hose into the
main nozzle. (fig. 10)
2Select the desired cleaning tool for use. Follow the
cleaning tool sub-assembly instructions for the
selected tool. (fig. 11)
3To remove the Accessory Hose, press and hold
down the Handheld Release Buttons. Then slide out
the Accessory Hose using the grip.
fig. 10
Release
Button
Using Your Removable Handheld Steamer
with the Different Accessories
fig. 11

11 120800 862 0453 www.sharkclean.eu
USING THE WINDOW SQUEEGEE
Cleaning Tip: To use the window squeegee, work with
the vapor jet down using top to bottom movements. To
do this without leaving streaks, use lateral movements
from the top to the bottom of the surface.
CAUTION: Always avoid any sudden changes
in temperature to prevent breakage of cracks in
windows.
1Attach the Window Squeegee by snapping into the
handle of the Accessory Hose until it clicks into
place. (fig. 14)
2Press the power button to start steaming.
3To remove the Window Squeegee, press and hold
down the Accessory release button. Then slide out
the Window Squeegee.
CAUTION: Turn the unit off before attaching or
removing the Window Squeegee.
Using Your Removable Handheld Steamer
with the Different Accessories - cont.
fig. 12
USING THE CONCENTRATOR NOZZLE
Cleaning Tip: The Concentrator Nozzle creates direct
steam spray to clean and sanitise hard to reach nooks &
crannies and other places where germs may build up. Use
the Concentrator Nozzle to loosen and dislodge compact
dirt often found in corner and tight places where traditional
methods and cleaning tools tend to push dirt into, making
it tough to reach and clean. Spray direct steam and wipe
clean with a wet cloth or paper towel.
1 Attach the Concentrator Nozzle by pressing the
nozzle onto the Accessory Hose until it clicks into
place. (fig. 12)
2Press the power button to start the steamer.
For effective cleaning, hold the steam output nozzle
1-2 inches away from the surface you’re cleaning.
CAUTION: Do not press the power button until the
Concentrator Nozzle is snapped into the accessory
hose of your Handheld Steamer.
3To remove the Concentrator Nozzle, press and hold
the accessory release button, then pull it out of the
Accessory Hose.
CAUTION: Do not press the power button while
removing the Concentrator Nozzle. Avoid touching
the tip of the Concentrator Nozzle, as this will be very
hot after steaming.
NOTE: The Handheld Steamer may continue to emit
steam for a few seconds after the power button is
pressed to turn the unit off. This is normal, and the
steaming will eventually come to a stop.
fig. 14
AFTER USE AND STORAGE
1Press the power button to turn the unit off. Unplug
the cord from the outlet and place the mop into the
upright position. Let the unit cool for 2-3 minutes.
2When you have finished using the Handheld Steamer,
reattach the handle to the handheld steamer.
3Remove the cleaning pad from the mop head by
placing one foot on the tab of the all-purpose carpet
pad and lifting the Shark®Multi-Function Steam Mop
Lite, avoiding bare skin contact with the hot pad or dirt.
4Empty the water tank before storage. Remove the
water tank cap and empty the tank over a sink.
Replace the water cap.
5To store the Shark®Multi-Function Steam Mop Lite
hanging up, first remove the head (after it has cooled
and the steam has been released) then hang on a
large hook. (fig. 15)
Care of Your Steam Mop
fig. 15
USING THE GROUT SCRUBBER
Cleaning Tip: The Grout Scrubber is designed for
removing stubborn messes in hard-to-reach nooks,
corners and in grout where focused scrubbing power
may be needed. It can loosen and dislodge compact dirt
often found in corners and tight places where traditional
methods and cleaning tools tend to push dirt into,
making it difficult to reach and clean. Scrub with the
Grout Scrubber and wipe clean with a cleaning cloth.
1Attach the Grout Scrubber by snapping into the
handle of the Accessory Hose until it clicks into
place. (fig. 13)
2Press the power button to start steaming.
3To remove the Grout Scrubber, press and hold down
the Accessory release button. Then slide out the tool
out.
CAUTION: Turn the unit off before attaching or
removing the Grout Scrubber
.
fig. 13

13 140800 862 0453 www.sharkclean.eu
DECALCIFYING YOUR STEAM MOP
Calcium and mineral deposits can build up and
impact the performance of your steam mop
over time. To extend the life of your product we
recommend that you use distilled water.
CARE OF YOUR CLEANING PADS
1 We recommend washing your cleaning pads
separately from other fabrics to avoid picking up
lint. For optimal cleaning performance, the pads
may need to be washed up to (3) three times. Only
use liquid detergent (no powder detergent). Do not
use any fabric softeners or bleach. Line dry. Do not
tumble dry. (fig. 16)
2If there are loose threads on the cleaning pads,
carefully cut the thread with scissors. Do not pull on
them or cut at the base. (fig. 17)
IMPORTANT: The cleaning pads may be very hot
from the steam. Use caution when removing. Let the
unit cool for 2-3 minutes.
fig. 17
CLEANING THE NOZZLE
NOTE: To prevent clogging, it is recommended that
you periodically clean the Direct Steam Nozzle and
the extension hose stem.
1Your Handheld Steamer should not normally require
cleaning, however, should you notice a decrease in
the steam output, it may be necessary to remove
mineral deposits built up around the nozzles.
2Unplug the cleaner from the electrical outlet.
3Use a small diameter stiff metal wire, such as a
straightened metal paperclip, and carefully insert the
end of the wire into the nozzle orifice. See illustration
above. (fig. 18)
4Move the wire back and forth several times to remove
any deposits.
5Plug in the appliance to the power outlet and test
steam output.
fig. 18
fig. 16
40°
Troubleshooting Guide
PROBLEM POSSIBLE REASONS & SOLUTIONS
The Shark®Multi-Function
Steam Mop Lite will not
turn-on.
Your steam mop should be securely plugged into an electrical outlet only.
Check your fuse or breaker.
The unit will not make steam.
Is there water in the water tank? If not, add water to your steam mop following
instructions on page 4.
When using the unit in the handheld mode, ensure that you are holding the
handheld unit horizontally to optimize the steam output. Do not hold the
handheld unit vertically as this will impede steam production. Use the hose with
your chosen accessory to reach difficult areas and above floor cleaning whilst
maintaining the horizontal position of the handheld unit.
If the unit still does not make steam, follow the instructions on page 13 to clean
the nozzle.
The Shark®Multi-Function
Steam Mop Lite leaves water
on the floor.
Check to see if your cleaning pad is too wet. We recommend you unplug the
steam mop and change the cleaning pad.
Make sure the cleaning pad is attached correctly.
The Shark®Multi-Function
Steam Mop Lite left a white
spot on the floor.
Do not leave your steam mop on the floor with a damp or wet cleaning pad.
If you’re using tap water, we recommend switching to distilled water.
Make sure the cap is securely on the water tank.
Floors are cloudy, streaky or
spotty after steaming.
The cleaning pad might be dirty. Change the cleaning pad.
If you washed the cleaning pad with powder detergent, then your pad could be
damaged and require replacement. Replacement pads are available at
www.sharkclean.eu.
This could also be an indication of prior soap or grease residue that has
accumulated on the floor. As our steam mops use only a small amount of
water, it may not be wet enough to rinse off the accumulation that the steam
is bringing to the surface. We suggest rinsing the floor with nothing but water,
letting it dry, and then steam mopping again with a clean pad. One or more
rinses generally removes the residue.
A more stubborn case may require you to rinse the floor with a mix of one part
vinegar and two parts water.
The Shark®Multi-Function
Steam Mop Lite is hard to
push.
Make sure the cleaning pad is attached correctly.
Check to see if the cleaning pad is excessively dirty. If so, replace the cleaning
pad.
Care of Your Steam Mop- cont.

IPX4
Euro-Pro Europe LTD
15 Mariner Court
Calder Park
Wakefield
WF4 3FL
0800 862 0453
www.sharkclean.eu
Technical Details
Model number: S7000UK 11
Input: 1250 Watts
Main unit voltage: 220-240V~, 50/60Hz
Euro-Pro and Shark are trademarks of Euro-Pro
Operating LLC. All other brand names may be
trademarks of their respective owners.
COPYRIGHT © EURO-PRO OPERATING LLC 2014
Illustrations may differ from actual product.
PRINTED IN CHINA
S7000UK_11_IB_E_150623_4
